1 General information
1.1 Information on the user guide
This translation of the original user guide is an integral part of the
WAVE 221 PC and provides you with information on the set-up, use,
storage and disposal of the device.
Before beginning any work, read the user guide and always keep it in
an accessible place.
This user guide is aimed solely at authorized specialists. None of the
content of this user guide may be put to practice by anyone other than
trained specialists.
Our user guides are updated regularly. Please send us your suggested
improvements and other hints by e‑mail, phone or fax. This will help us
to ensure that our documentation is as intelligible and user-friendly as
possible.
You will find our contact information on the inside of the front cover or
under “Site information”.Ä Chapter 10 “Site information” on page 41
1.2 Copyright notice
This user guide is protected by copyright.
Other than for internal purposes, making this user guide available to
third parties, duplicating it in any form, in whole or in part, and utilization or distribution of its contents are permitted only with the written
permission of the manufacturer.
Any violation of this requirement will render you liable for damages.
The right to make further claims is reserved.
General information
Copyright notice
WAVE 221 PC - Industrial PC
5
General information
Copyright notice
WAVE 221 PC - Industrial PC
6
2 Safety
2.1 Designated use
WAVE 221 PC is an HMI PC system. WAVE 221 PC is used to implement
control and operating concepts and to display and manipulate information in industrial and commercial environments.
It is nonetheless possible for improper use to introduce hazards. For
correct operation and safe use it is therefore important to comply with
the information and instructions in this document.
Have the following work carried out only by professionals:
n Installation
n Deinstallation
n Wiring
n Implementing
Have the following work carried out only by Systec & Solutions
GmbH :
n Repairs
n Servicing
n Maintenance
n Modifications
The device may not be used in the following areas:
n areas subject to explosion hazards
n areas subjected to harmful radiation
n areas and applications that are subject to vibration and impacts
n for carrying out safety functions such as
– air traffic control / flight control systems
– monitoring / controlling nuclear reactions
– monitoring / controlling mass transportation facilities
– monitoring / controlling medical systems
– monitoring / controlling weapons systems
Contravening these instructions voids all warranties and manufacturer’s responsibilities.
2.2 Safety notices
Please read these instructions attentively right through. It constitutes a
part of the device it describes and must be held available at all times.
Use the device only in accordance with its designated use (see
Ä
Chapter 2.1 “Designated use” on page 7).
For your own safety, always comply with the following safety instructions.
Warnings signal safety-related information.
You will find warnings within sequences of procedures prior to a step
that involves a hazard to people or material property.
Safety
Safety notices
WAVE 221 PC - Industrial PC
7
Three levels of warnings appear depending on the seriousness of the
hazard:
DANGER!
This signals an unusually hazardous situation. Failure to
comply with these instructions will result in serious irreversible injuries or death.
WARNING!
This signals an unusually hazardous situation. Failure to
comply with these instructions may result in serious irreversible or fatal injuries.
CAUTION!
This signals a hazardous situation. Failure to comply with
these instructions may result in minor or moderate injuries.
NOTICE!
This signals a hazard for material property. Failure to
comply with these instructions may cause material
damage.
This signals useful hints within a series of work processes.
2.3 Important safety notes
WARNING!
Risk of injury from electric shock!
Assembling and connecting plug connectors while
voltage is connected may lead to life-threatening injuries.
– All work on the device must be carried out when the
supply line is free of voltage.
– Never plug in or unplug the power supply plug when
live with voltage.
– The supply cable must not be supplied with voltage
until assembly has completely finished.
Safety
Important safety notes
WAVE 221 PC - Industrial PC
8
WARNING!
Danger of injury from hot surfaces.
Power transmission and regulatory components become
hot in operation and may lead to injuries.
– Allow these components to cool down before you
begin dismounting the device.
WARNING!
Danger of injury due to excessive load.
Working on heavy equipment may lead to serious injuries.
– Always have two people when working with heavy
equipment.
DANGER!
Electric shock hazard if the device is connected to the
mains supply incorrectly.
Connecting the device incorrectly to the mains supply
may expose people to injuries from electric shocks.
– Before connecting up the device always disconnect
the line from the power supply.
– Before connecting up always check that the lines are
at zero voltage.
NOTICE!
This total discharge protection may result in data
being lost.
Total discharge protection is activated when the charge
capacity reaches a critical level (ca. 3%). The total discharge protection facility powers the device down, which
may cause data to be lost.
– Save your data regularly.
– Check the charge capacity regularly.
– Don’t allow it to drop below 5%.
Safety
Important safety notes
WAVE 221 PC - Industrial PC
9
Safety
Important safety notes
WAVE 221 PC - Industrial PC
10
3 Product description
3.1 Overview
HMI systems from Systec & Solutions GmbH are user interfaces for managing and observing ongoing production processes. All devices are
highly available units designed in stainless steel, particularly suited to
harsh conditions in the process industry and, in addition, they guarantee IP65 protection.
Fig. 1: WAVE 221 PC
No. Designation Description
1 Display Used to display information.
2 Optional On/Off button Switches the device on and off.
Optional USB connection Used to connect a USB stick.
Hard disk LED (optional,
only possible for an HDD
disk)
Flashes when accessing data on
the internal HDD disk.
Fig. 2: Rear view of PC
The OSD button on the back of the monitor is used to switch the PC ON
and OFF.
HMI system WAVE 221 PC
Device
OSD (on-screen display)
Product description
Overview
WAVE 221 PC - Industrial PC
11
Fig. 3: WAVE 221 PC
No. Designation Description
1 Camera/Microphone Used to record images and sound.
2 Loudspeaker (behind the
display)
Used to reproduce sounds.
3.2 Type plate
The product designation and identification will be found on the type
plate. This is always located on the rear of the device and contains the
following information:
Fig. 4: Position of type plate
Multimedia kit (optional)
Product description
Type plate
WAVE 221 PC - Industrial PC
12
6
7
1
2
3
5
4
Fig. 5: Type plate
No. Description
1 Product name
2 Serial number
3 Power supply and consumption, charge current
and battery capacity (only for devices with an inte-
grated battery)
4 CE mark
5 Manufacturer’s logo
6 QR code (S/N + product name)
7 Manufacturer’s address
3.3 Technical data for the device
System
Model WAVE 221
Variant Industrial PC
Housing material Housing of stainless steel 1.4301, rear wall of aluminum AlMg3
Surface glass-beaded, sanded (optional)
IP protection factor IP65
PC
CPU
Intel ® Atom™ D2550 1.86 GHz
Intel ® Core™ i3
Intel ® Core™ i7-3555LE 3.20 GHz
RAM 2 GB DDR3, max. 8 GB DDR3 (Atom max. 4GB)
Product description
Technical data for the device
WAVE 221 PC - Industrial PC
13
PC
Storage capacity 120 GB SSD (optional HDD)
Operating system
Windows® 7 Professional 32 Bit/64 Bit (Atom 32 Bit)
Display
Type of display 21.5" IPS LCD display with LED backlight
Display area 476.64 x 268.11mm
Native (maximum) resolution 1920 x 1080 (Full HD)
Page ratio 16:9
Colors 16.7 million
Brightness
300 cd/m
2
Contrast 5000:1
Response time 16 ms
Horizontal frequency (KHz)
Vertical Frequency (Hz)
30 ‒ 83 kHz
50 ‒ 76 Hz
Touchscreen (optional) mouse compatible, analog resistive or PCT (projected capacitive) multi-
touch, optical bonding optional
Interfaces
Standard interfaces 4 x RS232 (3 x with Atom), 4 x USB, 1 x Ethernet
Other connections 1 x USB external (optional)
Power supply / consumption
(depending on the device variant)
Extra-low voltage power supply
12 ‒ 24 V DC, 10 ‒ 5 A
Protection of supply lead (Extra-low
voltage DC)
max. 10 A, the supply lead should be specified.
Low voltage power supply
100 ‒ 240 V AC, 50 ‒ 60 Hz, 2,0 ‒ 0,9 A
Protection of supply lead (Low voltage
AC)
max. 16 A, the supply lead should be specified.
Mean power consumption in operating mode
65 - 80 W (depending on configuration)
Product description
Technical data for the device
WAVE 221 PC - Industrial PC
14
Environmental conditions
Storage
-20 °C ‒ +60 °C
Operation
0 °C ‒ +40 °C
Humidity
10 % ‒ 90 %; non condensing
Dimensions (in mm without keyboard hinge)
Width 567
Height 390
Depth 55
Weight
Net weight ca. 10 kg
3.4 Dimensions
380
268
567
477
Fig. 6: Dimensions of front of device
Product description
Dimensions
WAVE 221 PC - Industrial PC
15
120,5
150,5
100
130
Fig. 7: Dimensions of back of device
55
30
210
390
Fig. 8: Dimensions of side view
3.5 External connectors
3.5.1 Overview of external connections
The following illustration shows the connectors that are located on the
back of the WAVE 221 PC.
Fig. 9: Overview of the interfaces on the back (depending on the configuration)
Product description
External connectors > Overview of external connections
WAVE 221 PC - Industrial PC
16
3.5.2 Description of the external connections
Your device will not incorporate all of the following connectors (see
Ä
Chapter 3.3 “Technical data for the device” on page 13).
= 9-pole Sub-D socket for connecting serial devices
Fig. 10: Serial connection (RS‑232)
= 24-pole DVI socket for connecting to the basic computer
Fig. 11: DVI socket with pinout
= 19-pole HDMI socket for connecting to the basic computer
Fig. 12: HDMI socket with pinout
= 15-pole HD-D "VGA" socket for connecting basic computer
Fig. 13: VGA socket with pinout
= 4-pole USB socket (type A) for connecting components:
n VoIP hardware components and/or
n touchscreen and/or
n keyboard
Fig. 14: USB socket with pinout
Serial connection (RS‑232)
DVI port
HDMI port
VGA port
USB connection
Product description
External connectors > Description of the external connections
WAVE 221 PC - Industrial PC
17
= 8-pole Ethernet socket for connecting to a network
Fig. 15: Ethernet socket with pinout
3.5.2.1 Power supply
NOTICE!
Risk of material damage if the device is connected to
an incorrect power supply.
Connecting the device to an incorrect power supply may
cause material damage.
– Check the power rating of your device.
Power is supplied via a 2-pole Phoenix socket of type DFK-PC /2GF-7,62. The corresponding plug carries the designation Phoenix Contact PC 4/ 2-ST-7,62.
Fig. 16: 2-pole Phoenix Contact socket for the power supply
Pin Designation Significance
1
-
Ground (GND) 0V
2 + Power supply +
Ethernet (RJ45)
Power supply in the extra low voltage
range (12‑24V DC)
Product description
External connectors > Description of the external connections
WAVE 221 PC - Industrial PC
18
Power is supplied via a 3-pole Phoenix socket of type DFK-PC /3GF-7,62. The corresponding plug carries the designation Phoenix Contact PC 4/ 3-ST-7,62.
Fig. 17: 3-pole Phoenix Contact socket for the power supply
Pin Designation Significance
1 PE Surge protectors
2 L Phase
3 N Neutral conductor
3.6 Conformity
Systec & Solutions GmbH
WAVE 219-221-224-232-255
Industrie-PC/-Monitor
n ZWECK
Für das o.g. Erzeugnis in der Ausführung mit einer Versorgungsspannung von 12 – 24 V DC wird hiermit bestätigt, dass es den
wesentlichen Schutzanforderungen entspricht, die in der Richtlinie
2004/108/EG über die elektromagnetische Verträglichkeit festgelegt sind.
Das o.g. Erzeugnis in der Ausführung mit einer Versorgungsspannung von 100 – 240 V AC entspricht außerdem den Bestimmungen
der EG-Richtlinie 2006/95/EG über die Niederspannung.
n GELTUNGSBEREICH
Oben aufgeführtes Produkt erfüllt die Anforderungen der EMV
Richtlinie 2004/108/EG auf Basis der folgenden Normen:
– EN 55022:1998 + A1:2000 + A2:2003 Class A
– EN 55024:1998
– EN 61000-6-2:2005
– EN 61000-4-2:2007
Oben aufgeführtes Produkt erfüllt die Anforderungen der Richtlinie
2006/95/EG auf Basis der folgenden Norm:
– EN 60950-1:2006
n BESCHEINIGUNG
Die Einhaltung der Schutzanforderung wurde festgestellt am allseitig geschlossenem Gehäuse.
Power supply in the low-voltage
range (100 – 240 V AC, 50 – 60 Hz)
Konformitätserklärung
Product description
Conformity
WAVE 221 PC - Industrial PC
19
This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct
the interference at his own expense.
n MODEL
WAVE 221
n CLASSIFICATION
Only compliant with DC version.
We hereby declare that the equipment bearing the trade name and
model number specified above was tested conforming to the applicable FCC rules under the most accurate measurement standards possible, and that the necessary steps have been taken and are in force to
assure that production units of the same equipment will continue to
comply with the Commission’s requirements.
Systec & Solutions GmbH
Emmy-Noether-Straße 17
D–76131 Karlsruhe
Germany
Phone +49 721 6634 400
Fax +49 721 6634 444
talk@systec-solutions.com
www.systec-solutions.com
Karlsruhe, December 1, 2014
Karl G. Linder
CEO
Product description
Conformity
WAVE 221 PC - Industrial PC
20
4 Starting up
4.1 Unpacking the device
1. Check the packaging for damage.
2. Remove the packaging carefully to avoid damaging the contents.
3. Check the device for damage.
If you find the packaging or the device to be damaged,
immediately inform the haulage company and the
supplier. Document the damage in some appropriate
way (e.g. incoming goods report, photos).
4. Check the delivered goods against your order and the delivery
papers to make sure everything is present and correct.
5. Retain the original packaging.
Retain the original packaging so that it can be reused
for
– storage,
– transport and
– return for disposal
as and when necessary.
If you fail to do this it will no longer be possible to guar-
antee protection from damage or other harmful influences.
4.2 Setting up the device
The device is approved for operation in enclosed premises.
1. Prior to initial commissioning:
n If necessary, disinfect the device (spray or wipe with disinfec-
tant) (refer to the device’s chemical resistance
data
Ä
on page 27).
n Slowly acclimatize the device to room temperature.
2. In the event of condensation: Do not switch the device on until it
is absolutely dry.
3. To avoid overheating during subsequent operation:
n Do not expose the device to solar radiation or other sources
of heat
n Make sure the ambient temperature does not exceed the
specified maximum value (see
Ä
Chapter 3.3 “Technical data
for the device” on page 13).
When installing the equipment also observe Ä Chapter 3.4 “Dimensions” on page 15.
Starting up
Setting up the device
WAVE 221 PC - Industrial PC
21
4.3 Mounting the device
1. Make sure the device is installed in a location with adequate air
circulation to ensure its operating temperature remains within
the permitted limits.
The device is cooled by means of an internal fan. This
device has no ventilation holes because waste heat is
conducted away via the metal housing.
2.
WARNING!
Danger of injury due to excessive load.
Working on heavy equipment may lead to serious
injuries.
– Always have two people when working with
heavy equipment.
Hold the WAVE 221 PC firmly so that it is level with the equipment rack adapter.
Starting up
Mounting the device
WAVE 221 PC - Industrial PC
22
3.
WARNING!
Risk of injury from electric shock!
Assembling and connecting plug connectors while
voltage is connected may lead to life-threatening
injuries.
– All work on the device must be carried out
when the supply line is free of voltage.
– Never plug in or unplug the power supply plug
when live with voltage.
– The supply cable must not be supplied with
voltage until assembly has completely finished.
There must be a cut-off device provided in the electric
supply cable of the device.
– If being permanently connected to the building
installation, an easily accessible cut-off device
must be in place.
– In the case of plug-in connection, the power socket
must be installed near the device and must be
easily accessible.
Connect the electrical supply cable with the device.
Please consider also
– the technical data for the external connec-
torsÄ Chapter 3.5 “External connectors”
on page 16
– and the requirement for the electrical supply
lead
Ä
Chapter 3.3 “Technical data for the device”
on page 13.
Starting up
Mounting the device
WAVE 221 PC - Industrial PC
23
Fig. 18: Interface plate on the rear of the WAVE 221 PC (depending on the
configuration)
4. Connect up all the cables between the interface plate and the
equipment rack adapter.
5. Tighten the screws on the mains plug.
Fig. 19: Screw connections on the equipment rack adapter
6. Fasten the WAVE 221 PC to the equipment rack adapter using the
four M5 x 16 screws.
You will find a view of the backplane in section
Ä
Chapter 3.4
“Dimensions” on page 15.
ð
The WAVE 221 PC is now mounted.
Starting up
Mounting the device
WAVE 221 PC - Industrial PC
24
5 Operation
5.1 Switching the device on
Fig. 20: ON/OFF button for switching on and off
Press the ON/OFF button between the dummy plugs on the lefthand side of the WAVE 221 PC.
ð
The system goes into operation.
5.2 Switching the device off
NOTICE!
Loss of data due to failure to save it.
Failure to save your data or failure to close down the
industrial PC in an orderly fashion may cause you to lose
data and may also damage the components.
– Save your data regularly.
– Always close down the industrial PC in an orderly
fashion.
Close the system down in an orderly fashion.
ð
The system is switched off.
The system cannot be closed down in an orderly fashion.
Hold the ON/OFF button pressed for about five seconds.
ð
The system is switched off.
5.3 Operating the touchscreen
With PCT (projected capacitive) multi-touch there is no need
to install a driver.
Install the installation files on the supplied USB stick.
Installing the driver
Windows XP
Operation
Operating the touchscreen
WAVE 221 PC - Industrial PC
25
If the stick is not available: Send an e‑mail to
support@systec-hardware.com.
Install the installation files on the supplied USB stick.
If the stick is not available: Send an e‑mail to
support@systec-hardware.com.
With G-Touch controller there is no need to install the driver
manually.
1. Launch Touch screen control panel in Windows’ Control Panel.
ð
A new window opens up.
2. Choose the Calibration option.
3. Further instructions follow.
ð
The touchscreen is correctly calibrated.
When G-Touch Controller:
1. Launch Tablet PC Settings in Windows’ Control Panel.
ð
A new window opens up.
2. Choose the Calibration option.
3. Further instructions follow.
ð
The touchscreen is correctly calibrated.
5.4 Cleaning the device
To prevent malfunctions or incorrect data entry due to inadvertent
operations: Switch the device off before cleaning it (see Ä Chapter 5.2
“Switching the device off” on page 25).
Windows 7 and higher
Calibrating the touchscreen
Windows XP
Windows 7
Operation
Cleaning the device
WAVE 221 PC - Industrial PC
26
NOTICE!
Damage caused by cleaning.
Cleaning the device may give rise to material damage.
– Firmly close all screw connections.
– Do not use high-pressure or steam cleaning equip-
ment.
– Do not use any abrasives or hard materials.
– Clean the display without applying any excessive pres-
sure.
1. Regularly clean the surface of the device using a soft, moist, lint-
free cloth.
2. For more significant soiling: Use isopropanol as cleaning agent.
Note the information in the following chemical resistance data:
Systec & Solutions
TOUCHSCREEN Films
Chemical resistance
n RESISTANCE
to solvents and environmental influences.
The film usually used is based on a polyester film with biaxial orienta-
tion, which therefore has a better resistance to solvents. It can withstand pencil hardness 3HB.
The front film is able to withstand over 24 hours exposure to the following chemicals at 50°C without visible damage. Concentration 100%
(except where otherwise stated):
Acetaldehyde Dioctyl phthalate Caustic soda <10%
Acetone Dioxane Paraffin oil
Acetonitrile Dowandol DRM/PM Perchlorethylene
Aliphatic hydrocar-
bons
Ferrous chloride
(FeCl2)
Phosphoric acid
<10%
Alkaline carbonate Ferric chloride(FeCl2) Castor oil
10% formic acid Acetic acid <10% Nitric acid <10%
Ammonia <10% Ethanol Hydrochloric acid
<10%
Amyl acetate Ethyl Salt water
Ethanol Ethyl acetate Oxygen
Ether Varnish Sulfuric acid <10%
Operation
Cleaning the device
WAVE 221 PC - Industrial PC
27
Ethyl acetate Chlorofluorocarbons Silicone oil
Gasoline Formaldehyde 37% -
42%
Turpentine substitute
Benzene Glycol Toluol
Bichromate Glycerine Triacetin
Ferrocyanide salts Heating oil III-trichloroethane
Drilling emulsion Isopropanol Trichloroethylene
Brake fluid Potash soap Trichloroacetic acid
<10%
Butyl cellosolve Potassium hydroxide
<30%
Tricresyl phosphate
Sodachlorine <20% Kerosene Thinner (white spirit)
Cyclohexanol Cresol phenol soaps
in solution
Soaps, dishwasher
and detergent solu-
tions
Decon Methanol Water <100°C
Diacetone alcohol Methyl ethyl ketone Hydrogen peroxide
<25%
Diethylformamide Molecular chlorine Fabric softener
Dibutyl phthalate N-butyl acetate Xylene
Diesel oil Sodium bisulfate
Diethylether Sodium carbonate
The front film is not resistant to the following chemicals:
Concentrated mineral
acids
Concentrated alkaline
solutions
High pressure steam
above 100°C
A number of other substances may give rise to changes in the surface
structure. This should be examined and evaluated in each case.
Resistant to 24-hours' exposure to household chemicals at 50°C
with no visible damage:
Ariel Gumption Top Job
Ajax Jet Dry Grape juice
Domestos Coffee Vim
Downey Lenor Vortex
Fantastic Milk Wisk
Formula 409 PersiI Windex
Operation
Cleaning the device
WAVE 221 PC - Industrial PC
28
Slight discoloration was detectable for the following materials:
Mustard Tomato ketchup
Tomato juice Lemon juice
n SCOPE
This customer information applies to the following devices manufactured by Systec & Solutions GmbH:
– CONTROL 217 | 218 | 219 | 221 | 224 | 232
– PILOT 215 | 217 | 218 | 219 | 221
– SLICE 219 | 226
– WAVE 219 | 221 | 224 | 232 | 255
n PURPOSE
This document serves to inform customers about product attributes. The information is provided by the manufacturer or supplier.
The information and recommendations it contains are made to the
best of our knowledge and belief. Users should carry out their own
investigations to establish usage and application recommendations relating to products’ suitability for their particular purpose.
KI-0002-DE.11 · Version dated: 07.2013
Systec & Solutions GmbH
Emmy-Noether-Straße 17 | 76131 Karlsruhe | Germany
Phone +49 721 6634 400 | Fax +49 721 6634 444
talk@systec-solutions.com | www.systec-solutions.com
5.5 Using the optional USB connection
Unscrew and remove the dummy plug on the left-hand side of
the WAVE 221 PC.
ð
The optional USB connection is now accessible.
When closing the USB connection, make sure it is
screwed tight, otherwise the IP65 protection level can
no longer be guaranteed.
Firmly screw the dummy plug into place on the left-hand side of
the WAVE 221 PC.
ð
The optional USB connection is firmly screwed shut.
5.6 Setting up the WLAN (optional)
The WLAN antenna together with the WLAN USB stick are
located in the equipment rack adapter.
Opening dummy plugs
Closing dummy plugs
Operation
Setting up the WLAN (optional)
WAVE 221 PC - Industrial PC
29
The WLAN USB stick may be connected only directly to a USB
interface with no interposed USB hub.
Install the WLAN driver from the supplied USB stick.
ð
The WLAN is set up.
5.7 Hard disk LED (optional)
The hard disk LED flashes when the internal HDD hard disk is
accessed.
This is, however, possible only for HDD disks.
Operation
Hard disk LED (optional)
WAVE 221 PC - Industrial PC
30
6 Repairs
If you encounter a product fault while using the device:
– immediately switch it off (see Ä Chapter 5.2 “Switching
the device off” on page 25).
The device is defective.
1. Send an e‑mail to support@systec-hardware.com or
2. Fill out a support form at
http://www.systec-hardware.com/de/hardware-support.html.
Repairs
WAVE 221 PC - Industrial PC
31
Repairs
WAVE 221 PC - Industrial PC
32
7 Storage
7.1 Unmounting the device
WARNING!
Risk of injury from electric shock!
Assembling and connecting plug connectors while
voltage is connected may lead to life-threatening injuries.
– All work on the device must be carried out when the
supply line is free of voltage.
– Never plug in or unplug the power supply plug when
live with voltage.
– The supply cable must not be supplied with voltage
until assembly has completely finished.
WARNING!
Danger of injury due to excessive load.
Working on heavy equipment may lead to serious injuries.
– Always have two people when working with heavy
equipment.
WARNING!
Danger of injury from hot surfaces.
Power transmission and regulatory components become
hot in operation and may lead to injuries.
– Allow these components to cool down before you
begin dismounting the device.
NOTICE!
Danger of material damage from live equipment.
Working on live equipment may give rise to material
damage.
– Before you carry out any work on a device: Disconnect
it from the power supply.
You will need the following tools:
n Allan key (4) for M5 x 16
Storage
Unmounting the device
WAVE 221 PC - Industrial PC
33
1.
Clean the device (see Ä Chapter 5.4 “Cleaning the device”
on page 26).
Fig. 21: Screw connections on the equipment rack adapter
2. Release the screw connections on the equipment rack adapter.
3. Lift the device off the equipment rack adapter and hold it firmly.
ð
You can now see the interface plate on the rear of the device.
Fig. 22: Interface plate on the rear of the WAVE 221 PC (depending on the
configuration)
4. Release the screws on the mains plug.
5. Disconnect the device from the power supply.
6. Disconnect all the cables from the interface plate.
ð
The device is now unmounted.
Storage
Unmounting the device
WAVE 221 PC - Industrial PC
34
7.2 Storing the device
NOTICE!
Material damage caused by incorrect storage.
Incorrect storage can damage the device.
– Pay attention to the handling symbols on the pack-
aging.
– Comply with the stated storage conditions (see
Ä
Chapter 7.2 “Storing the device” on page 35).
When storing the device, comply with the following requirements:
n Use the original packaging.
n Do not apply any localized pressure to the display.
n Do not store in the open air.
n Always store in a dry, non-dusty place.
n Always shield the equipment from solar radiation.
n Avoid mechanical vibration and shocks.
n Avoid cold weather and extreme temperature fluctuations.
n Pay attention to the information in the “Technical data” section.
Ä
Chapter 3.3 “Technical data for the device” on page 13
Storage conditions
Storage
Storing the device
WAVE 221 PC - Industrial PC
35
Storage
Storing the device
WAVE 221 PC - Industrial PC
36
8 Packaging and transport
8.1 Packaging the device
The packaging protects the contents from damage or other deleterious
effects that could adversely affect their quality.
Retain the original packaging so that it can be reused for
– storage,
– transport and
– return for disposal
as and when necessary.
If you fail to do this it will no longer be possible to guarantee
protection from damage or other harmful influences.
8.2 Transporting the device
NOTICE!
Material damage caused by inappropriate transport.
Inappropriate transport may damage the device.
– Pay attention to the handling symbols on the trans-
port packaging.
– Comply with the stated transport requirements (see
Ä
“Transport requirements” on page 37).
When transporting the device you should comply with the following
requirements:
n Always shield the equipment from solar radiation.
n Avoid mechanical vibration and shocks.
n Avoid extreme temperature fluctuations.
n Pay attention to the information in the “Technical data” section.
When the consignment is delivered, immediately check it for
possible transport damage and deal appropriately with any
detected transport damage or non-obvious defects.
Transport requirements
Packaging and transport
Transporting the device
WAVE 221 PC - Industrial PC
37
Packaging and transport
Transporting the device
WAVE 221 PC - Industrial PC
38
9 Disposal
This device is subject to the WEEE Directive and the corresponding
national statute (ElektroG).
n WEEE registration number: 79305117
Systec & Solutions GmbH undertakes to take back and dispose properly
of all devices. Under our General Terms and Conditions and in fulfillment of the conditions of the sales agreement, the customer undertakes to return all equipment to Systec-Services GmbH for proper disposal.
Do not dispose of the equipment via your local municipal collection centers. Under the WEEE Directive these may be used
only for privately used equipment.
Disposal
WAVE 221 PC - Industrial PC
39
Disposal
WAVE 221 PC - Industrial PC
40
10 Site information
Systec & Solutions GmbH
Emmy-Noether-Straße 17
D–76131 Karlsruhe
Germany
Phone: +49 721 6634 400
Fax: +49 721 6634 444
E-mail: talk@systec-solutions.com
Internet: www.systec-solutions.com
Support: support@systec-hardware.com
Support form:
http://www.systec-solutions.com/en/hardware-support.html
n Karl G. Linder
n Andreas König
Court of registration: Mannheim District Court
Registration number: HRB 717236
VAT ID no. as per §27a Value Added Tax Act:
n DE 815434969
©Systec & Solutions GmbH / All rights reserved
Technical modifications reserved
All trademarks and registered trademarks mentioned are the property
of their respective owners
Authorized representatives and directors
Site information
WAVE 221 PC - Industrial PC
41
Loading...
