INSTRUCTION MANUAL
DSP COLOR CAMERA
1/3" INTERLINE TRANSFER CCD
STANDARD RESOLUTION
HIGH RESOLUTION
Please read this manual thoroughly before use, and keep it handy for future reference.
ISSUE 1 – DECEMBER 2004
ii
WARNINGS AND CAUTIONS
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT
ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS
OR OTHER OPENINGS ON THE EQUIPMENT.
CAUTION
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instruction in the
literature accompanying the product.
iii
FCC COMPLIANCE STATEMENT
INFORMATION TO THE USER: THIS EQUIPMENT HAS BEEN TESTED AND FOUND
TO COMPLY WITH THE LIMITS FOR A CLASS B DIGITAL DEVICE, PURSUANT TO
PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE
REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE IN A
RESIDENTIAL INSTALLATION. THIS EQUIPMENT GENERATES, USES AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTIONS, MAY CAUSE HARMFUL INTERFERENCE
TO RADIO COMMUNICATIONS. HOWEVER, THERE IS NO GUARANTEE THAT
INTERFERENCE WILL NOT OCCUR IN A PARTICULAR INSTALLATION. IF THIS
EQUIPMENT DOES CAUSE HARMFUL INTERFERENCE TO RADIO OR TELEVISION
RECEPTION, WHICH CAN BE DETERMINED BY TURNING THE EQUIPMENT OFF
AND ON, THE USER IS ENCOURAGED TO TRY TO CORRECT THE INTERFERENCE
BY ONE OR MORE OF THE FOLLOWING MEASURES:
- REORIENT OR RELOCATE THE RECEIVING ANTENNA
- INCREASE THE SEPARATION BETWEEN THE EQUIPMENT AND
RECEIVER
- CONNECT THE EQUIPMENT INTO AN OUTLET ON A CIRCUIT DIFFERENT FROM
THAT TO WHICH THE RECEIVER IS CONNECTED
- CONSULT THE DEALER OR AN EXPERIENCED RADIO/TV TECHNICIAN
FOR HELP
CAUTION: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE
MANUFACTURED COULD VOID THE USER'S AUTHORITY TO OPERATE THE
EQUIPMENT.
THIS CLASS B DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003.
CET APPAREIL NUMÉRIQUE DE LA CLASSE B EST CONFORME À LA NORME NMB003 DU CANADA.
iv
IMPORTANT SAFEGUARDS
1. READ AND RETAIN INSTRUCTIONS
Read the instruction manual before
operating the equipment. Retain the
manual for future reference.
2. CLEANING
Turn the unit off and unplug from the
power outlet before cleaning. Use a
damp cloth for cleaning. Do not use
harsh cleansers or aerosol cleaners.
3. ATTACHMENTS
Do not use attachments unless
recommended by manufactured as they
may affect the functionality of the unit
and result in the risk of fire, electric
shock or injury.
4. MOISTURE
Do not use equipment near water or
other liquids.
5. ACCESSORIES
Equipment should be installed in a safe,
stable location. Any wall or shelf
mounting accessory equipment should
be installed using the manufacture’s
instructions. Care should be used
when moving heavy equipment. Quick
stops, excessive force, and uneven
surfaces may cause the equipment to
fall causing serious injury to persons
and objects.
6. VENTILATION
Openings in the equipment, if any, are
provided for ventilation to ensure
reliable operation of the unit and to
protect if from overheating. These
openings must not be blocked or
covered
7. POWER SOURCES
The equipment should be operated only
from the type of power source indicated
on the marking label. If you are not
sure of the type of power supplied at
the installation location, contact your
dealer. For equipment designed to
operate from battery power, refer to the
operating instructions.
8. GROUNDING OR POLARIZATION
Equipment that is powered through a
polarized plug (a plug with one blade
wider than the other) will fit into the
power outlet only one way. This is a
safety feature. If you are unable to
insert the plug fully into the outlet, try
reversing the plug. Do not defeat the
safety purpose of the polarized plug.
Alternate Warning: If the equipment is
powered through a three-way
grounding-type plug, a plug having a
third (grounding) pin, the plug will only
fit into a grounding-type power outlet.
This is a safety feature. Do not defeat
the safety purpose of the groundingtype plug. If your outlet does not have
the grounding plug receptacle, contact
your local electrician.
9. CORD AND CABLE PROTECTION
Route power cords and cables in a
manner to protect them from damage
by being walked on or pinched by items
places upon or against them.
10. LIGHTNING
For protection of the equipment during
a lightning storm or when it is left
unattended and unused for long
periods of time, unplug the unit from
the wall outlet. Disconnect any
antennas or cable systems that may be
connected to the equipment. This will
prevent damage to the equipment due
to lightning or power-line surges.
11. OVERLOADING
Do not overload wall outlets and
extension cords as this can result in a
risk of fire or electric shock.
12. SERVICING
Do not attempt to service the video
monitor or equipment yourself as
opening or removing covers may
expose you to dangerous voltage or
other hazards. Refer all servicing to
qualified service personnel.
v
13. DAMAGE REQUIRING SERVICE
Unplug the equipment from the wall
outlet and refer servicing to qualified
service personnel under the following
conditions:
A. When the power supply cord or the
plug has been damaged.
14. REPLACEMENT PARTS
When replacement parts are required,
be sure the service technician uses
replacement parts specified by the
manufacturer or that have the same
characteristics as the original part.
Unauthorized substitutions may result
in fire, electric shock, or other hazards.
B. If liquid has spilled or objects have
fallen into the unit.
C. If the equipment has been
exposed to water or other liquids.
D. If the equipment does not operate
normally by following the operating
instructions, adjust only those
controls that are covered by the
operating instructions. Improper
adjustment of other controls may
result in damage to the unit.
E. If the equipment has been dropped
or the casing damaged.
F. When the equipment exhibits a
distinct change in performance.
15. SAFETY CHECK
Upon completion of any service or
repairs to the equipment, ask the
service technician to perform safety
checks to verify that the equipment is in
proper operating condition.
16. FIELD INSTALLATION
The installation of equipment should be
made by a qualified service person and
should conform to all local codes.
vi
TABLE OF CONTENTS
INTRODUCTION ......................................................................................1
CAMERA OVERVIEW ...........................................................................2
CONTENTS OF PACKAGE......................................................................6
MANUAL IRIS LENS ADJUSTMENT .......................................................6
VIDEO-TYPE AUTO-IRIS LENS INSTALLATION
AND ADJUSTMENT .................................................................................6
DC-TYPE AUTO-IRIS LENS INSTALLATION
AND ADJUSTMENT .................................................................................8
BACKFOCUS ADJUSTMENT ................................................................10
ZOOM LENS BACKFOCUS ADJUSTMENT ..........................................11
TROUBLESHOOTING AND MAINTENANCE........................................12
SPCIFICATIONS..................................................................................... 13
vii
THIS PAGE INTENTIONALLY LEFT BLANK.
viii
ABOUT THE 1/3" DSP COLOR CAMERA
INTRODUCTION
The 1/3" DSP color security camera provides SONY, true-color images
especially for closed-circuit television (CCTV) and security surveillance
applications.
Features:
• High-performance 1/3" SONY DSP color CCD technology
• NTSC: 330 lines of resolution (Standard)
480 lines of resolution (High)
• PAL: 320 lines of resolution (Standard)
470 lines of resolution (High)
• 0.5 lux @ F1.2 sensitivity (Standard)
0.8 lux @ F1.2 sensitivity (High)
• C/CS, backfocus cam for easy adjustment
• Auto electronic shutter [1/60(1/50) ~ 1/100,000] and manual
electronic shutter modes
• Auto and manual white balance modes
• Compatible with video- or DC-type lenses with dip switch select
• Quick connect for video or DC lens with 4-pin connector
• Flicker less, BLC, AGC select(Normal/High), AGC, Sync
adjustments
• 12VDC or 24VAC
IMPORTANT: The user of this camera is
responsible for checking and complying with
local, state, and federal laws and statutes
concerning the recording and monitoring of
audio signals.
1
CAMERA OVERVIEW
W
C Mount Ring
( C MOUNT LENS )
( CS MOUNT LENS )
Back Focus Ring
SIDE VIE
Back Focus Lock Screw
Camera Mounting Bracket
BACK VIEW (12VDC / 24VAC)
V. Phase Potentiometer
Level potentiometer
(for DC type A/I lens)
Function
Switch
Power Input
Terminal
LEVEL PHASE PWR
~ G ~
12VDC / 24VAC CLASS 2
LENS
VIDEO OUT
FRONT VIEW
Power LED
Auto Iris Lens
Connector
Video Out BNC
Connector
1. Back focus Lock Screw – Allows the user to secure the backfocus
setting.
Continued on next page
2
2. C/CS Back focus Adjust Ring – Allows the user to adjust the back
focal length or picture focus by rotating this ring clockwise for Cmount and
counter-clockwise for CS-mount lenses.
3. Mounting Bracket Hole – This threaded ¼"-20 hole is used to
mount the camera onto a mounting bracket or tripod.
4. Iris Adjustment Pot (Potentiometer) – This control allows the user
to adjust the level of the auto iris when the A/I lens selection switch
is set to DC and a DC lens is mounted on the camera. The switch
should be in the video position when an auto iris video lens is
mounted on the camera. If a video auto-iris lens is used, this control
has no function.
5. Phase Adjustment – This is used in a multi-camera system when
power is supplied from different sources, causing the camera to be
out of phase. This situation affects auto-switching of the cameras by
causing a vertical flip or roll during the switch interval. The vertical
phase adjustment allows the camera’s line lock sync to be adjusted
from 0 to 360 degrees with reference to zero line crossing of the AC
power source. Ensure that all cameras are powered from the same
electrical source and wired in a similar fashion. Adjust the phase
control on the back of the camera until there is no vertical flip or roll
on the monitor while using an auto switcher.
6. Power LED – This green LED illuminates while power is supplied to
the camera.
7. Auto-iris Lens Connector – This four-pin female connector
supplies the power and either video signal or DC control signal to
the auto-iris lens.
8. Function Switches – This compartment houses switches for
camera operation. A switch is in the ON position if it is positioned
toward the front of the camera. If the position is set toward the back
of the camera, the switch is OFF. The switches include:
Continued on next page
• SHTR Switch (Aes/Mes) – This switch allows the user to choose
between auto exposure and manual exposure. Position the
switch toward the front of the camera for auto exposure, whereby
3
the exposure is performed by the electronic iris and AGC control.
Position the switch toward the back of the camera for manual
exposure, whereby the shutter speed can be set by the shutter
adjust.
*Manual Exposure (SW1= Manual Exposure)
Switch Position
Shutter Speed
SW1 SW2 SW3 SW4
Switch
SW1 2 3 4
MES up up up 1/60(1/50)
MES down up up 1/100(1/120)
MES up down up 1/250
MES down down up 1/500
MES up up down 1/1000
MES down up down 1/2000
MES up down down 1/4000
MES down f down down 1/10000
• Flickerless Switch (off/on) – (SW1=Auto Exposure) This
function is used for removing flicker, when camera signal format
does not coincide with power source frequency being used.
• BLC Switch (on/off) – (SW1=Auto Exposure) This on/off switch
controls backlight compensation. When set to ON, the camera
will automatically try to maintain proper exposure in the specific
area even if the lighting level changes.
• E/I (on/off) – (SW1=Auto Exposure)
When set to the ON position, the electronic iris switch
automatically varies the camera’s shutter to mimic auto-iris
control, allowing fixed or manual iris lenses to be used in a wider
range. When this switch is set to ON, turn the F/F switch OFF.
• A/I Switch (dc/video) – The auto iris switch allows the user to
select the supplied auto-iris control signal for the lens. Position
the switch toward the front of the camera to choose DC when the
auto-iris control lens requires DC control signal. Position the
switch toward the back of the camera to choose Video when the
auto-iris control lens requires video signal.
Continued on next page
• AGC Select Switch (Normal/Hi)
AGC Normal : AGC Middle Gain.
AGC High : AGC Max Gain.
Only AGC Switch (Function, s/w No. 7Pin) ON.
4
• AGC Switch (off/on) – The auto gain control switch allows the
video signals to maintain a constant level. This switch is useful
when using the camera at low-light levels and when lighting
levels change over time. For best low light conditions, this switch
should set to ON.
• AWB1, AWB2 Switch (on/off) – This camera have four white
balance setting
ATW (auto tracing white balance) – The camera automatically
aim to maintain white objects as white even if the light color
changes.
AWB (auto white balance) – Quick ATW.
Indoor – improves the color balance in areas where a mixture of
light sources exist.
Outdoor – Improves the color balance in arrears where day light
is the main source of light.
Switch Position
Mode
SW8 SW9
Switch
SW8 9
on on ATW
on off AWB
off on Indoor
off off Outdoor
• Sync Select Switch (int/LL) – Use this switch to set the camera
synchronization mode internal (int) or Line Lock (LL).
9. Power Input Terminal – This terminal accepts a DC12V or AC24V
power source from a DC12V or AC24V ac +/- 10% 60/50Hz +/- 1Hz
using a UL-listed Class 2 power supply only.
10. Video Out BNC Connector – This BNC connector provides a 1.0
Vp-p/75 Ohms composite video signal.
CONTENTS OF PACKAGE
5
Installation of the camera must be performed by qualified service
personnel in accordance with all local and national electrical and
mechanical codes.
Carefully remove the color camera and its accessories from the carton
and verify that they were not damaged in shipment.
The contents of the package includes:
1. Color CCD camera
2. Mini-DIN connector (for video-or dc-type auto-iris lens)
MANUAL IRIS LENS ADJUSTMENT
When using a manual iris lens, turn the iris ring on the lens to the OPEN
position and adjust the manual iris for the appropriate range. Adjust
during the brightest conditions, opening the lens to the minimum f-stop
yielding a good picture under the brightest scene conditions. Do not
saturate the picture.
The manual iris is used in indoor applications where lighting from
windows can considerably affect the light level of the room.
VIDEO AUTO IRIS
INSTALLATION & ADJUSTMENT
The camera supports video-type auto iris lenses which adjust to
changing light levels. Perform the following steps to install and adjust a
video-type auto iris lens.
1. If necessary, solder the lens control wires to the connector supplied
with the camera.
6
Pin 3
Pin 1
Pin 2
Rib
Pin 4
Connector
Cover
Heat
Shrinkable
Tubes
Automatic
Iris Lens
Iris Control
Cable
Connector
PIN NAME WIRE COLOR
1 Voltage + Red
2 Open 3 Video White
4 Ground Black
2. Attach the video-type auto iris lens to the lens mount on the front of
the camera.
3. IMPORTANT: The minimum Plug the connector from the lens into
the auto iris jack on the back of the camera. The connector is
polarized and can only be inserted into the jack one way.
4. The E/I switch should be in the “OFF” position.
5. The A/I switch should be in the “VIDEO” position.
6. Apply power to the camera.
7. Adjust the focus ring on the lens for an optimum picture. If a picture
is not visible, set the lens for proper exposure by adjusting the ALC
(Automatic Level Control) and the level on the lens. The ALC
setting can range between AVG (average) or PK (peak). A
midrange setting is appropriate for most applications.
For ALC adjustments:
AVG To slow the reaction of the lens to changing light, set the
range to the AVG setting to average the video level from the
camera. Use when there are bright spots in the picture such
as lights or glare from the sun.
7
PK To increase the speed of the lens reaction to the changing
light, set the lens adjustment to PK so the lens will adjust to
the brightest or peak object in the video. Use this setting if
you want to see the brightest object and not the background
objects.
For Level adjustments:
Adjust the level control for the best picture during the day. A night
adjustment may not provide the proper setting for controlling the
light during the day.
8. Set the back focus of the camera before the final adjustment of the
video level.
9. If the auto iris has a gain adjustment and the picture oscillates
between open and closed under bright lights, slowly turn the gain
adjustment counter clockwise until the oscillating stops. Increase
the light getting to the camera by adjusting the level control and readjusting the gain control.
DC AUTO IRIS LENS
INSTALLATION & ADJUSTMENT
The camera supports DC-type auto iris lenses. Perform the following
steps to install and adjust a DC-type auto iris lens.
1. Solder the lens control wires to the connector supplied with the
camera.
Rib
Pin 3
Pin 1
Pin 4
Pin 2
Connector
Cover
Heat
Shrinkable
Tubes
Automatic
Iris Lens
Iris Control
Cable
Connector
8
PIN NAME WIRE COLOR
1 Damp Coil - Blue
2 Damp Coil + Red
3 Drive Coil + White
4 Drive Coil - Green
2. Attach the DC-type auto iris lens to the lens mount on the front of
the camera.
3. Plug the connector into the auto iris jack on the back of the camera.
The connector is polarized and can only be inserted into the jack
one way.
BACK VIEW
4. The E/I switch should be in the “OFF” position.
5. The A/I switch should be in the “DC” position.
6. Apply power to the camera.
7. Adjust the auto iris lens for an optimum picture using the LEVEL
control on the back of the camera.
9
BACK FOCUS ADJUSTMENT
For best results, perform back focus adjustments at night or while using
a #6 or #8 welders glass in front of the lens. The focus of the camera
will change slightly if the camera iris was adjusted on a light scene, then
changes to a dark scene. However, the camera will remain in focus if
the iris was focused on a dark scene and the scene lightens.
1. The lens should be mounted on the camera before applying power.
2. If a picture is visible, focus on the picture. If the picture is not
visible, open the iris on the lens. Open the lens as wide as possible
by placing the welder’s glass in front of the lens and forcing the lens
to automatically open.
3. When the iris is open to the widest point, re-adjust the focus for
clear picture. If a clear picture is not possible, set the focus ring to
midrange.
4. Loosen the back focus lock screw.
5. Adjust the back focus ring for a clear picture.
6. Tighten the back focus lock screw.
7. Fine tune the focus with the focus ring on the lens.
8. Remove the welder’s glass from in front of the lens.
9. Adjust the iris of the lens for the best picture quality.
10
ZOOM LENS BACK FOCUS ADJUSTMENT
The objective of back focusing a zoom lens is similar to that of a fixed
focal length camera except the back focus is also adjusted to maintain
the focus when “zooming” the lens in and out on a scene.
1. Choose an object at the farthest range set for viewing with a zoom
lens.
2. Make sure the iris of the lens is wide open. Do this by adjusting the
camera at night or use a welders glass in front of the lens.
3. Adjust the focus to the stop on the far range.
4. Adjust the zoom on the lens to obtain the widest picture.
5. Loosen the back focus lock screw.
6. Adjust the back focus ring for the clearest picture.
7. Tighten the back focus lock screw.
8. Adjust the zoom on the lens to the far telephoto position.
9. Adjust the back focus ring for the clearest picture.
10. Adjust the zoom on the lens back to the widest picture.
11. Loosen the back focus screw.
12. Re-adjust the back focus for the clearest picture.
13. Tighten the back focus lock screw.
14. Repeat the previous steps as necessary to maintain a clear picture
throughout the entire zoom range.
11
TROUBLESHOOTING AND MAINTENANCE
TROUBLESHOOTING
If problems occur, verify the installation of the camera with the
instructions in this manual and with other operating equipment. Isolate
the problem to the specific piece of equipment in the system and refer to
the equipment manual for further information.
PROBLEM AREA TO CHECK
No Video 1. Verify power is applied to all pieces of the
equipment in the system. The camera LED
should be ON.
2. Verify that the video cables are connected
correctly.
3. Verify that the lens cap has been removed
from the lens and the iris of the lens is
open.
Video but no
control
Dark Video 1. Adjust iris.
PREVENTIVE MAINTENANCE
Preventive maintenance allows detection and correction of minor faults
before they become serious and cause equipment failures.
Every three months perform the following maintenance:
1. Inspect all connecting cables for deterioration or other damage.
2. Clean components with a clean damp cloth.
3. Verify that all mounting hardware is secure.
Power down the system for one minute then
re-apply power.
2. Check A/I connections.
12
SPECIFICATIONS
* Standard Resolution DSP Color Camera *
Power
Power Source, Consumption : 24VAC +/-10%, 60(50)Hz +/-1Hz,
12VDC +/-10%
3.2Watts.
Power Indicator : Green LED
Sensor Information and General
Processing Technology : Sony DSP
Image Sensor : 1/3" interline transfer CCD (sony
Picture Element : 537(H) x 505(V), NTSC
Chip Size : 5.59mm(H) x 4.68mm(V)
Unit Cell Size : 9.6µm(H) x 7.5µm (V), NTSC
Scanning System : 2:1 Interlace
Scanning Frequency : 15.75KHz(H) x 60Hz(V), NTSC
Sync System : Line Lock / Internal
Vert Phase Adjust Range : 0 deg. To 360 deg.
Electronic Shutter : 1/60(1/50) ~ 1/100000 sec.
Operating Temperature / Humidity : 14°F to 122°F (-10°C to +50°C)
chip set)
537(H) x 597(V), PAL
9.8µm(H) x 6.3µm (V), PAL
15.625KHz(H) x 50Hz(V), PAL
/ <96% (non-condensing)
Video
Signal Format : NTSC, 525 Lines
Resolution : NTSC, 330TV Lines
Minimum Illumination: 0.5 Lux (F1.2)
Video Output: 1.0 Vp-p, 75 Ohms, unbalanced
Video Iris Output: 650mV at video out 1.0 Vp-p
S/N Ratio : 50dB(AGC Off)
BLC Size : 40% Center
Sync Level : 40 IRE, PAL 300mV
White Clip : 120 IRE, PAL 850mV
PAL, 625 Lines
PAL, 320TV Lines
13
Function
Auto/Man Shutter Control(E.S.) : Auto(On), Man(Off) (Dip Switch)
Manual Shutter Control : 1/60(1/50), 1/100(1/120), 1/250,
1/500, 1/1000, 1/2000, 1/4000,
1/10,000(Dip Switch)
Flickerless(F.F) : ON/OFF (Dip Switch)
BLC : ON/OFF (Dip Switch)
EI : ON/OFF (Dip Switch)
Auto Iris Lens : DC/Video (Dip Switch)
AGC Select : Normal/High (Dip Switch)
AGC : ON/OFF (Dip Switch)
White Balance : ON/OFF (Dip Switch)
Auto, Quick, Indoor, Outdoor
Sync : Internal / Line Lock (Dip Switch)
Vert Phase Adjust : Adjustable (POT)
DC Iris Level Adjust : Adjustable (POT)
Connector and Mechanical
Video Output : BNC Connector
Power Input : 3-pin Terminal Block
AI/DC Output : 4-pin mini din jack (Standard
Connection)
Lens Mount : C/CS (Selected through back
focus)
Mounting Hole : 1/4" UNC Top and Bottom
External Dimensions : 2.44W x 2.1H x 5.0D inch
(62W x 54H x 127D mm)
Weight : 9.34oz (265g)
* High Resolution DSP Color Camera *
14
Power
Power Source, Consumption : 24VAC +/-10%, 60(50)Hz +/-1Hz,
12VDC +/-10%
3.2 Watts.
Power Indicator : Green LED
Sensor Information and General
Processing Technology : Sony DSP
Image Sensor : 1/3" interline transfer CCD (sony
chip set)
Picture Element : 811(H) x 508(V), NTSC
795(H) x 596(V), PAL
Chip Size : 5.59mm(H) x 4.68mm(V)
Unit Cell Size : 6.35µm(H) x 7.4µm (V), NTSC
6.5µm(H) x 6.25µm (V), PAL
Scanning System : 2:1 Interlace
Scanning Frequency : 15.75KHz(H) x 60Hz(V), NTSC
15.625KHz(H) x 50Hz(V), PAL
Sync System : Line Lock / Internal
Vert Phase Adjust Range : 0 deg. to 360 deg.
Electronic Shutter : 1/60(1/50) ~ 1/100,000 sec.
Operating Temperature / Humidity : 14°F to 122°F (-10°C to +50°C)
/ <96% (non-condensing)
Video
Signal Format : NTSC, 525 Lines
PAL, 625 Lines
Resolution : NTSC, 480 TV Lines
PAL, 470 TV Lines
Minimum Illumination: 0.8 Lux (F1.2)
Video Output: 1.0 Vp-p, 75 Ohms, unbalanced
Video Iris Output: 650mV at video out 1.0 Vp-p
S/N Ratio : 50dB(AGC Off)
BLC Size : 40% Center
Sync Level : 40 IRE, PAL 300mV
White Clip : 120 IRE, PAL 850mV
Function
Auto/Man Shutter Control(E.S.) : Auto(On), Man(Off) (Dip Switch)
15
Manual Shutter Control : 1/60(1/50), 1/100(1/120), 1/250,
1/500, 1/1000, 1/2000, 1/4000,
1/10,000(Dip Switch)
Flickerless(F.F) : ON/OFF (Dip Switch)
BLC : ON/OFF (Dip Switch)
EI : ON/OFF (Dip Switch)
Auto Iris Lens : DC/Video (Dip Switch)
AGC Select : Normal/High (Dip Switch)
AGC : ON/OFF (Dip Switch)
White Balance : ON/OFF (Dip Switch)
Auto, Quick, Indoor, Outdoor
Sync : Internal / Line Lock (Dip Switch)
Vert Phase Adjust : Adjustable (POT)
DC Iris Level Adjust : Adjustable (POT)
Connector and Mechanical
Video Output : BNC Connector
Power Input : 3-pin Terminal Block
AI/DC Output : 4-pin mini din jack (Standard
Lens Mount : C/CS (Selected through back
Mounting Hole : 1/4" UNC Top and Bottom
External Dimensions : 2.4W x 2.1H x 5.0D inch
Weight : 9.34oz (265g)
Connection)
focus)
(62W x 54H x 127D mm)
DSP COLOR CAMERA
1/3” INTERLINE TRANSFER CCD
STANDARD RESOLUTION
HIGH RESOLUTION
50301598D
16
Loading...
