USER MANUAL
EX-LUXB
D&D BULLET CAMERA
1/3" SONY 960H EX-VIEW HAD CCD∥
Features
- High Resolution 700TV Lines
- Super Low Light Camera (0.0003Lux @F1.2)
- Weatherproof Housing
- Simple OSD Setting
- 3D-DNR, WDR, Sense-up (X512)
- De-Fog Function
- Video Test Output
- Cable Hidden Bracket
AVE. 20 DE NOVIEMBRE NO.805 COL. CENTRO. C.P. 31000,
CHIHUAHUA, CHIH., MEXICO
SYSCOM VIDEO
MODEL : EX-LUXB(4mm)
ROHS
WEATHER
PROOF
SYSCOM VIDEO
Connector
Accessories
INSTALLATION
▶
Video
Test Cable
▶
Screw &
Anchor for fixing
▶ Manual
▶ L-Wrench
< Functions >
CAUTIONS
WARRANTY
1. Assemble the main body of the camera with lens quickly at a clear place to avoid dust.
2. Be careful not to drop this camera and not to impact on it. CCTV camera is a precision machine.
3. Do not install the camera opposite of the sun so that it be avoided direct light.
4. The camera must be installed at a steady place without shaking or something else.
5. Do not pull the cable. if you pull the cable, it will make electrical problems such as disconnection.
6. Installation this
camera aat safety place where is no water. If the camera has some problems with water accidently. You have to contact
A/S center that sold the camera to you.
7. If you would like to relocate the already installed product, be sure to turn off the power and then move or reinstall it.
1. Products are supplied with 2 year limited warranty from the date of purchase. We will repair or replace the defective item with a new or
factory rebuilt replacement.
2. Transportation of the product to our service center is the responsibility of the user. Repaired or replaced product will be returned prepaid
during the warranty period.
3. This warranty applies to the original purchaser only.
4. This warranty will be invalid if unauthorized repair or modifications are made to the unit or in any ca
se of accident, misuse or damage
caused by improper installation or altered serial numbers.
5. The liability of the company has limited the cost of repair/replacement of the unit under warranty.
!
When you install the camera, please glue up the end of cable to keep it stable in
order to protect the camera from the humidity problems.
5. The liability of the company has limited the cost of repair/replacement of the unit under warranty.
6. If you need warranty service, please return the product to your distributor/dealer. Proof of pruchase may be required.
DND-B900
H.Resolution
1020(H) x 508(V)(NTSC), 1020(H) x 596(V) (PAL)
976(H) x 494(V)(NTSC), 976(H) x 582(V) (PAL)
ITEM
Dimension & Specification
Image Sensor 1/3'' 960H EX-VIEW HAD CCD II (SONY)
Total Pixels
Effective Pixels
Scanning System 2:1 Interlace
700TV Lines
Sync. System Internal
[Unit:mm][Unit:mm][Unit:mm]
69.9W)mm x 238mm(H) x 99.8(D)mm
f4mm / f6mm / f8mm Board Lens (F1.1)
English, Korean, Janpanese, German, French, Italian,Polish, Russian, Portuguese,
spanish, Turkish, Arabic, Heb
OFF / AUTO (X2 ~ X512)
DC 12V - 130mA / AC 24V - 2W
Storage Temperature
-10℃~ 50℃ (Humidity : 0%RH ~ 80%RH)
-20
℃
~ 60℃ (Humidity : 0%RH ~ 85%RH)
OFF / V-FLIP / MIRROR / ROTATE
OFF, ON (8 AREAS)
OFF, ON (8 AREAS)
OFF / WDR / D-WDR / BLC / HSBLC
OFF / ON (x1 ~ x16)
Signal Process
Digital Signal Process
OFF / LOW / MIDDLE / HIGH
1/60~1/120,000 (NTSC) 1/50~1/120,000 (PAL)
DAY / AUTO / NIGHT / SMART IR
0.0003Lux @ 30IRE, F1.2
ATW (1,700'K ~ 11,000'K) / AUTO / AWC-> SET KEY / MANUAL
3D-DNR (Level Adjustment, 0~100)
Min. Illumination
Iris Adjustment ALC / ELC
LENS
S/N Ratio More than 50dB (AGC Off)
SENSE-UP
DAYNIGHT
BACKLIGHT
Digital Zoom
WHITE BALANCE
AGC
Shutter Speed
Operating Temperature
3D-DNR
Digital Effect
MOTION DETECTION
PRIVACY
LANGUAGE
Power Consumption
69.9W)mm x 238mm(H) x 99.8(D)mm
Weight
Approx. 850g
Dimension
OSD MENU
BRIGHTNESS
SENS-UP
EXIT
ATW -
AUTO -
AWC->SET KEY -
MANUAL RED/BULE/EXIT
DAY -
BURST
EXIT
BURST
LEVEL
DWELL TIME
EXIT
BURST
DAY/NIGHT
AUTO
NIGHT
BACK LIGHT
(OFF/WDR/D-WDR/BLC/HSBLC)
AGC
SHUTTER
ALC/ELCEXPOSURE
WHITE BALANCE
LEVEL
POSITION
SIZE
EXIT
EXIT -
OFF -
AREA SETUP
SENSITIVITY
DISPLAY
ALARM OUT
EXIT
3D-DNR ON/OFF -
OFF -
RECTANGLE
CIRCLE
POLYGON
EXIT
D-ZOOM ON/OFF
D-EFFECT OFF/V-FLIP/ROTATE/MIRROR
SHARPNESS (0~100)
COLOR (0~100)
DEFOG -
SYNC INT/L&L
USER TITLE OFF/ON
LANGUAGE 14 LANGUAGES SELECTABLE
EXIT -
FACTORY RESET -
CAMERA ID
PROTOCAL
BAUD RATE
SAVE&REBOOT
EXIT
SPECIAL
COMMUNICATION
SMART IR
PRIVACY MASK
SYSTEM
MOTION DET
ON
ON
DEFECT PIXEL -
EXIT -
EXIT RET/TOP/END -
