DiskStation DS916+
Safely centralize all your digital assets with Synology DiskStation DS916+. Powered by an Intel®
Pentium® N3710 quad-core processor with AES-NI hardware encryption engine, DS916+ provides
outstanding performance and data encryption acceleration along with real-time transcoding
of 4K Ultra HD source contents for small and medium-sized businesses and IT enthusiasts. DS916+
also comes with 2GB or 8GB memory options, being more exible for multitasking applications.
Synology DS916+ is backed with Synology’s 3-year limited warranty.
Highlights
● Quad-core 4-bay NAS optimized for
intensive tasks and encryption
● Scalable storage up to 9 drives with
DX513
● Comes with 2 RAM options: 2GB
and 8GB
● Single H.264/H.265 4K or triple
Full HD online transcoding
● Advanced Btrfs le system offering
65000 system-wide snapshots and
1024 snapshots per shared folder
● Outstanding throughput at over
225.91 MB/s reading, 221.04 MB/s
writing
● Encryption performance at over
225.83 MB/s reading and 209.35
MB/s writing
● Ideal MailPlus solution comes with 5
free email accounts
● Brightness-adjustable front LED with
schedule control
1
Satisfy Your Need for Both Performance and Data Security
Synology DS916+ is a full-featured 4-drive-bay network attached storage solution specically
designed for small and medium-sized business users and IT enthusiasts who care about
high performance throughput and safety for data sharing and backup. DS916+ is equipped
with an Intel® Pentium® N3710 quad-core processor with AES-NI hardware encryption
engine and 2GB or 8GB memory options, providing outstanding throughput at over 225.91
MB/s reading and 221.04 MB/s writing, and an astonishing encryption acceleration at over
225.83 MB/s reading and 209.35 MB/s writing under a RAID 5 conguration in a Windows®
environment with Link Aggregation enabled1.
With scalable drive management of up to 9 drives with Synology Expansion Unit DX5132
and real-time 1-channel H.264/H.265 4K Ultra HD or 3-channel Full HD3 video transcoding
support, DS916+ is also ideal for sharing and storing ultra-high denition media contents.
Btrfs: Next Generation Storage Efciency
DS916+ introduces the Btrfs le system, bringing the most advanced storage technologies
to meet the management needs of modern businesses:
● Built-in data integrity check detects data and le system corruption with data and
meta-data checksums and improve overall stability.
● Flexible Shared Folder/User Quota System provides comprehensive quota control on
all user accounts and shared folders.
● Advanced snapshot technology with customizable backup schedule allows up to 1024
copies of shared folder backups in a minimum 5-minute interval without occupying
huge storage capacity and system resources.
● File or folder level data restoration brings huge convenience and saves time for users
who wish to restore only a specic single le or folder.
● Cloud Station with le versioning reduces down to half of storage consumption when
compared with the Ext4 le system.
Page 2
1 2 3 4 5 6 7 …14
1
2
3
4 5
1
2
3
1
Next Generation Storage Eciency
The Btrfs le system brings storage
management to the next level by
providing more ecient storage utilization,
scheduled shared folder snapshot, and
le/folder-level data restoration.
Flexible Scalability
DS916+ can expand its capacity on-the-y
and enlarge volumes across its expansion
unit for storage or backup.
Comprehensive Business Applications
Powered by the innovative Synology DiskStation Manager (DSM), DS916+ comes fullyequipped with applications and features designed specically for SMB users:
● Easy integration with existing business network environments through Windows® AD
and LDAP directory services without recreating user accounts.
● Windows ACL support provides ne-grained access control and ecient privilege
settings, allowing DS916+ to t seamlessly into current infrastructure.
● Internet le access is simplied by the encrypted FTP server and the web-based le
explorer, Synology File Station. HTTPS, rewall, and IP auto-block support ensure le
sharing over the Internet is protected with a high level of security.
● Synology Cloud Station allows users to sync les among multiple devices, including
Windows PC, Mac, Linux, iOS and Android tablets or smart phones, eortlessly keeping
everything up-to-date.
Virtualization Ready
With iSCSI support in DSM, DS916+ provides seamless storage solutions for virtualization
environments, including VMware®, Citrix®, and Hyper-V®. With VMware vSphere 5 and VAAI
integration, DS916+ helps ooad specic storage operations and optimizes computation
power for unparalleled performance and eciency in VMware environments. It is the ideal
alternative to SAN solutions for businesses. Fast and cost-eective, iSCSI allows SMB users to
consolidate storage into data center storage arrays while providing hosts with the illusion of
locally-attached disks.
Easy Backup Solutions
With block-level incremental backup and cross-version deduplication, Synology Hyper
Backup provides multi-version backup with optimized storage utilization and allows
multiple backup destinations to local shared folders, external hard drives, network shared
folders, rsync server, and public cloud services. Synology High Availability Manager ensures
seamless transition between clustered servers in the event of server failure with minimal
impact to applications to decrease the risk of unexpected interruptions and costly downtime.
24/7 Security Solution
Synology Surveillance Station oers a centralized interface to manage IP cameras
deployed in your working environment, allowing users traveling miles away to safeguard
the environment by watching live views, recording events, and taking snapshots with
a computer or mobile device. DS916+ is an ideal surveillance solution as it is capable of
hosting up to 40 IP cameras (30 FPS at 720p). In addition to its intuitive setup and hasslefree interface, Surveillance Station features an optimized live view experience with on-screen
operations, smart analytic tools like motion detection, and an alert system that sends instant
notication through DS cam, SMS, and e-mail.
Energy Efcient and Easy Management Design
Synology DS916+ is designed and developed with energy eciency in mind. Compared with
the average storage server counterparts, DS916+ consumes only 30W in regular operation.
The support of Wake on LAN/WAN and power schedule further reduces power consumption
and operation cost. HDD hibernation can be congured to take eect automatically when
the system has been inactive for a specied period of time. This not only saves energy but
also extends the lifespan of the hard disks.
All Synology products are produced with RoHS compliant parts and packed with recyclable
packing materials. Synology acknowledges the responsibility as a global citizen to
continually work to reduce the environmental impact of every product produced.
Page 3
Connections & Buttons
1
2
3
4
6
5107119
8
1
5
9
LED indicator
System fan
Power port
USB 3.0 port
2
Kensington Security Slot
6
eSATA port
10
Technical Specications
Hardware
CPU
Hardware encryption engine
Floating point unit
Hardware transcoding engine
RAM size
Compatible drive type
Maximum internal raw capacity
External ports
Size (HxWxD)
Weight
LAN
Wake on LAN/WAN
Wireless support
Scheduled power on/o
AC input power voltage
Power frequency
Operating temperature
Storage temperature
Relative humidity
Intel Pentium N3710 quad-core 1.6GHz, burst up to 2.56GHz
Yes (AES-NI)
Yes
Supported codecs: H.264 (AVC), H.265 (HEVC), MPEG-2 and VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 30
DDR3 2GB/8GB
3.5”/2.5” SATA III/II x 4 (hard drives not included)
40TB (10TB HDD x 4) (actual capacity dependent on volume types)
USB 3.0 x 3, eSATA x 1
165 mm x 203 mm x 233.2 mm
2.04 Kg
Gigabit (RJ-45) x 2
Yes
Yes (wireless dongles not included)
Yes
100V to 240V AC
50Hz to 60Hz, single phase
5°C to 40°C (40°F to 104°F)
-20°C to 60°C (-5°F to 140°F)
5% to 95% RH
3
7
11
Power button
Reset button
USB 3.0 port
Drive tray cover
4
Gigabit (RJ-45) LAN port
8
General
Networking protocols
File system
Storage management
Supported RAID type
File sharing capability
Privilege
Directory service
Security
CIFS, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN™ , L2TP)
Internal: Btrfs, ext4
External: Btrfs, ext4, ext3, FAT, NTFS, HFS+
Maximum single volume size: 108TB, Maximum internal volume: 512, Maximum iSCSI Target: 32, Maximum iSCSI LUN: 256,
iSCSI LUN clone/snapshot support; SSD read/write cache support
Synology Hybrid RAID (SHR), Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
Maximum user account: 2048, Maximum group: 256, Maximum shared folder: 512,
Maximum concurrent CIFS/AFP/FTP/File Station connection: 512 (2GB RAM) / 2048 (8GB RAM)
Windows Access Control List (ACL)
Windows AD Integration: Domain Users login via Samba (CIFS)/AFP/FTP/File Station, LDAP integration
FTP over SSL/TLS, IP Auto-Block, Firewall, Encrypted Network Backup over Rsync, HTTPS Connection
Page 4
Utilities
Supported clients
Supported browsers
Language
Applications
File Station
Backup solutions
FTP Server
High Availability Manager
Printer Server
Security Advisor
iOS/Android™ applications
Windows Phone® applications
Add-on Packages
Antivirus Essential
Cloud Station Server
Cloud Sync
DLNA/UPnP® Media Server
Download Station
Log Center
MailPlus
MailPlus Server
Note Station
Storage Analyzer
Surveillance Station
VPN Server
Web Station
Other packages
Synology Web Assistant, Cloud Station Drive, Cloud Station Backup, Cloud Sync Decryption Tool, Evidence Integrity Authenticator, Photo Station Uploader,
Snapshot Manager for VMware, Snapshot Manager for Windows, NFS Plug-in for VMware VAAI
Windows 7 onwards and Mac OS X® 10.10 onwards
Chrome™, Firefox®, Internet Explorer® 9 onwards, Safari® 8 onwards, Safari (iOS® 7 onwards on iPad®), Chrome (Android 4.0 onwards on tablets)
English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svensk, Nederlands, Русский, Polski, Magyar,
Português do Brasil, Português Europeu, Türkçe, Český,
Virtual drive, remote folder, Windows ACL editor, compress/extract archived les, bandwidth control for specic users or groups, create sharing links, transfer
logs
Network backup; local backup; desktop backup; conguration backup; OS X Time Machine; backup data to public cloud;
shared folder sync - maximum task number: 8
Bandwidth control for TCP connections, custom FTP passive port range, anonymous FTP, FTP SSL/TLS and SFTP protocols, boot over the network with TFTP
and PXE support, transfer logs
Combines two DS916+ into one high-availability cluster
Maximum printer: 2, printing protocols: LPR, CIFS, IPP, iOS printing, Google Cloud Print™, multi functional print server (MFP functions are for Windows PC
only)
Malware detection/removal, user account/password, network, system-related security scan
DS cloud, DS le, DS nder, DS cam, DS note, DS audio, DS download, DS photo, DS video
DS le, DS nder, DS audio, DS download, DS photo, DS video
Full system scan, scheduled scan, white list customization, virus denition auto update
Maximum concurrent le transfers: 512 (2GB RAM) / 2000 (8GB RAM), retain historical and deleted le versions
One or two-way synchronization with public cloud storage providers including Amazon Cloud Drive, Amazon S3-compatible storage, Baiduyun, Box,
Dropbox, Google Cloud Storage, Google Drive, hubiC, Megafon Disk, Microsoft OneDrive, OpenStack Swift-compatible storage, WebDAV servers, Yandex Disk
DLNA certied, PS3®/PS4®/Xbox 360®/Xbox One® support
Supported download protocols: BT/HTTP/FTP/NZB/eMule; Maximum concurrent download task: 80
SSL connection, log rotation: 6 months, 1 year, 2 years, 3 years, email notication
Intuitive webmail interface for MailPlus Server; customizable mail labels, lters and user interface
Secure, reliable, and private mail server solution with High-availability, load balancing, security and ltering design
(Including free MailPlus licenses for 5 mail accounts. Procurement of additional licenses is required.)
Rich-text note organization with versioning, encryption, sharing, media embedding and attachments
Volume and quota usage, total size of les, volume usage and trends based on past usage, size of shared folders, largest/most/least frequently modied les
Maximum IP camera: 40 (total of 1200 FPS at 720p, H.264) (Including two free camera licenses. Procurement of additional licenses is required.)
Maximum connections: 20; supported VPN protocols: PPTP, OpenVPN™, L2TP
Virtual host (up to 30 websites), PHP/MariaDB®, 3rd-party applications support
Photo Station, Audio Station, iTunes® Server, 3rd-party packages
Environment and Packaging
Environment
Package content
Optional accessories
Warranty
*Model specications are subject to change without notice. Please refer to www.synology.com for the latest information.
1. Performance gures may vary depending on environment, usage and conguration.
2. DS916+ supports one Synology Expansion Unit DX513/DX213, sold separately.
3. DS916+ can transcode 4K video to 1080p or lower. The concurrent channels of Full HD video transcoding may vary depending on the video codec, resolution, bitrate and FPS.
SYNOLOGY INC.
Synology is dedicated to taking full advantage of the latest technologies to bring businesses and home users reliable and affordable ways to centralize data storage, simplify data
backup, share and sync les across different platforms, and access data on-the-go. Synology aims to deliver products with forward-thinking features and the best in class customer
services.
Copyright© 2016, Synology Inc. All rights reserved. Synology, the Synology logo are trademarks or registered trademarks of Synology Inc. Other product and company names
mentioned herein may be trademarks of their respective companies. Synology may make changes to specication and product descriptions at anytime, without notice. Printed in
Taiwan.
DS916+-2016-ENU-REV002
Headquarters
Synology Inc. 3F-3, No. 106, Chang An W. Rd., Taipei, Taiwan Tel: +886 2 2552 1814 Fax: +886 2 2552 1824
China
Synology Shanghai
20070, Room 516, No. 638
Hengfeng Rd., Zhabei Dist.
Shanghai, China
RoHS Compliant
DS916+ main unit, Welcome note, accessory pack, AC power adapter, RJ-45 LAN cable x 2
Camera License Pack, VS360HD, Synology Expansion Unit DX513/DX213
3 years
France
Synology France SARL
39 rue Louis Blanc
92400 Courbevoie, France
Tel: +33 147 176288
North & South America
Synology America Corp.
3535 Factoria Blvd SE #200
Bellevue, WA 98006, USA
Tel: +1 425 818 1587
United Kingdom
Synology UK Ltd.
Unit C, Denbigh West Business Park
Third Avenue, Bletchley
Milton Keynes, MK1 1DH, UK
Tel: +44 1908 366380
Germany
Synology GmbH
Grafenberger Allee 125
40237 Düsseldorf
Deutschland
Tel: +49 211 9666 9666
Loading...
