Symphonic SC309E User Manual

Download

OWNER’S

As an ENERGY STAR

Partner, our company has determined that this product meets the E

NERGY STAR guidelines for

energy efficiency. E

NERGY STAR

is a U.S. registered mark.

MANUAL

9-INCH COLOR TV/VCR

SC309E

This Owner’s Manual is made of

recycled paper.

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

If you need additional assistance for set-up or operating after

reading owner’s manual, please call TOLL FREE : 1-800-242-7158.

Or visit our WEB SITE at

Please read before using this equipment

http://www.funai-corp.com

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The caution marking is located on the rear of the cabinet.

IMPORTANT SAFEGUARDS

1.Read instructions-All the safety and operating instructions

should be read before the appliance is operated.

2.Retain Instructions-The safety and operating instructions

should be retained for future reference.

3.Heed Warnings-All warnings on the appliance and in the

operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions

should be followed.

5.Cleaning-Unplug TV/VCR from the wall outlet before

cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6.Attachments-Do not use attachments not recommended by

the TV/VCR manufacturer as they may cause hazards.

7.Water and Moisture-Do not use this TV/VCR near water-

for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8.Accessories-Do not place this TV/VCR on an unstable cart,

stand, tripod, bracket, or table. The TV/VCR may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the TV/VCR. Any mounting of the appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

PORTABLE CART WARNING

S3126A

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

AMEUBLES- Cet appareil ne doit être

placé que sur un meuble (avec ou sans roulettes) recommandé par le fabricant. Si vous l’installez sur un meuble à roulettes, déplacez les deux ensembles avec précaution. Un arrêt brusque, l’utilisation d’une force excessive et des surfaces irrégulières risquent de déstabiliser l’ensemble et de le renverser.

9. Ventilation-Slots and openings in the cabinet and the back

or bottom are provided for ventilation and to ensure reliable operation of the TV/VCR and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the TV/VCR on a bed, sofa, rug, or other similar surface. This TV/VCR should never be placed near or over a radiator or heat register. This TV/VCR should not be placed in a builtin installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10.Power Sources-This TV/VCR should be operated only

from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For TV/VCRs intended to operate from battery power, or other sources, refer to the operating instructions.

11.Grounding or Polarization-This TV/VCR is equipped

with a polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

12.Power-Cord Protection-Power-supply cords should be

routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

SYMBOLE D'AVERTISSEMENT POUR

LES COMPOSANTES

APPAREIL ET MEUBLE A ROULETTES

S3126A

- 2 - EN

9J27

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

S2898A

FIGURE A

ELECTRIC SERVICE EQUIPMENT

NEC - NATIONAL ELE CTRI CAL CO DE

GROUND

CLAMP

ANTENNA

LEAD IN WIRE

ANTENNA

DISCHARGE UNI T (NEC SECTION 810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDI NG ELECTRODE SYSTEM (NEC ART 250, PART H)

13.Outdoor Antenna grounding-If an outside antenna or

cable system is connected to the TV/VCR, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14.Lightning-For added protection for this TV/VCR receiver

during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV/VCR due to lightning and power-line surges.

15.Power Lines-An outside antenna system should not be

located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16.Overloading-Do not overload wall outlets and extension

cords as this can result in a risk of fire or electric shock.

17.Object and Liquid Entry-Never push objects of any kind

into this TV/VCR through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the TV/VCR.

18.Servicing-Do not attempt to service this TV/VCR yourself

as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19.Damage Requiring Service-Unplug this TV/VCR from

the wall outlet and refer servicing to qualified service per-

sonnel under the following conditions: a. When the power-supply cord or plug is damaged or frayed. b. If liquid has been spilled, or objects have fallen into the

TV/VCR. c. If the TV/VCR has been exposed to rain or water. d. If the TV/VCR does not operate normally by following the

operating instructions. Adjust only those controls that are

covered by the operating instructions, as improper adjust-

ment of other controls may result in damage and will often

require extensive work by a qualified technician to restore

the TV/VCR to its normal operation. e. If the TV/VCR has been dropped or damaged in any way. f. When the TV/VCR exhibits a distinct change in perfor-

mance-this indicates a need for service.

20.Replacement Parts-When replacement parts are required,

be sure the service technician has used replacement parts

specified by the manufacturer that have the same character-

istics as the original part. Unauthorized substitutions may

result in fire, electric shock, injury to persons or other haz-

ards.

21.Safety Check-Upon completion of any service or repairs to

this TV/VCR, ask the service technician to perform routine

safety checks to determine that the TV/VCR is in proper

operating condition.

22.Heat-This TV/VCR product should be situated away from

heat sources such as radiators, heat registers, stoves, or

other products (including amplifiers) that produce heat.

CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

- 3 - EN

9J27

PRECAUTIONS

LOCATION

For safe operation and satisfactory performance of your TV/VCR, keep the following in mind when selecting a place for its installation:

Shield it from direct sunlight and keep it away

•

from sources of intense heat. Avoid dusty or humid places.

•

Avoid places with insufficient ventilation for proper

•

heat dissipation. Do not block the ventilation holes at the top and bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

Install unit in a horizontal position.

•

Avoid locations subject to strong vibration.

•

Do not place the TV/VCR near strong magnetic fields.

•

Avoid moving TV/VCR to locations where temper-

•

ature differences are extreme.

AV OID THE HAZARDS OF

ELECTRICAL SHOCK AND FIRE

Do not handle the power cord with wet hands.

•

Do not pull on the power cord when disconnecting

•

it from an AC wall outlet. Grasp it by the plug. If, by accident, water is spilled on your unit, unplug

•

the power cord immediately and take the unit to our Authorized Service Center for servicing.

Do not put your fingers or objects into the

•

TV/VCR cassette holder. Do not place anything directly on top of the unit.

•

WARNING

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, or after heating a cold room or under conditions of high humidity. If a tape is played in a TV/VCR which has moisture, it may damage the tape and TV/VCR. Therefore when the condensation occurs inside the unit, turn the POWER button on and allow at least 2 hours for the unit to dry out.

IMPORTANT COPYRIGHT INFORMATION

Unauthorized recording or use of broadcast television programming, video tape, film or other copyrighted material may violate applicable copyright laws. We assume no responsibility for the unauthorized duplication, use, or other acts which infringe upon the rights of copyright owners.

FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

The serial number of this product may be found on the back of the unit. No other TV/VCR has the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase Dealer Purchase from Dealer Address Dealer Phone No. Model No. Serial No.

- 4 - EN

9J27

TABLE OF CONTENTS

C IMPORTANT SAFEGUARDS . . . . . . . . . . . . .2

C PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . .4

C FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

C SUPPLIED ACCESSORIES . . . . . . . . . . . . . . .6

C OPERATING CONTROLS AND FUNCTIONS 7

C PREPARATION FOR USE . . . . . . . . . . . . . . . .9

C SET UP FOR USE . . . . . . . . . . . . . . . . . . . . . .11

SELECTING THE LANGUAGE . . . . . . . . . . .11

CLOCK SET UP (AUTO / MANUAL) . . . . . .11

DAYLIGHT-SAVING TIME . . . . . . . . . . . . . .13

CHANNEL SET UP . . . . . . . . . . . . . . . . . . . . .14

DELETING (OR ADDING) CHANNEL . . . . .14

C TV OPERATION . . . . . . . . . . . . . . . . . . . . . . .15

WATCHING A TV PROGRAM . . . . . . . . . . . .15

GAME MODE . . . . . . . . . . . . . . . . . . . . . . . . .15

DEGAUSSING . . . . . . . . . . . . . . . . . . . . . . . .15

PICTURE CONTROL . . . . . . . . . . . . . . . . . . .15

C PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . .16

NORMAL PLAYBACK . . . . . . . . . . . . . . . . . .16

AUTO REPEAT PLAYBACK . . . . . . . . . . . . .16

SEARCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

STILL PICTURE . . . . . . . . . . . . . . . . . . . . . . .17

NOISE CANCEL (in the Still mode) . . . . . . . .18

VERTICAL HOLD CONTROL . . . . . . . . . . . .18

TRACKING ADJUSTMENT . . . . . . . . . . . . . .18

RENTAL PLAYBACK . . . . . . . . . . . . . . . . . . .18

NORMAL RECORDING . . . . . . . . . . . . . . . . .19

SKIPPING UNWANTED SCENES DURING

RECORDING . . . . . . . . . . . . . . . . . . . . . . . . .19

OTR (One Touch Recording) . . . . . . . . . . . . . .19

TIMER RECORDING . . . . . . . . . . . . . . . . . . .20

HINTS FOR AUTOMATIC TIMER

RECORDING . . . . . . . . . . . . . . . . . . . . . . . . .22

AUTO RETURN . . . . . . . . . . . . . . . . . . . . . . .22

WAKE UP TIMER . . . . . . . . . . . . . . . . . . . . . .22

SLEEP TIMER . . . . . . . . . . . . . . . . . . . . . . . . .23

C COPYING A VIDEO TAPE . . . . . . . . . . . . . . .23

C ON SCREEN DISPLAY . . . . . . . . . . . . . . . . .24

C SPECIAL FEATURES . . . . . . . . . . . . . . . . . .24

REAL TIME TAPE COUNTER . . . . . . . . . . . .24

AUTO REWIND-EJECT . . . . . . . . . . . . . . . . .24

C MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . .24

C TROUBLESHOOTING GUIDE . . . . . . . . . . .25

C SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . .26

C CABLE CHANNEL DESIGNATIONS . . . . . .26

C WARRANTY . . . . . . . . . . . . . . . . . . .Back Cover

RECORDING . . . . . . . . . . . . . . . . . . . . . . . . .18

INDICE

CONTROLES DE OPERACIÓN Y

SUS FUNCIONES . . . . . . . . . . . . . . . . . . . . . . . .27

CONEXIONES DE ANTENA/CABLE . . . . . . . .29

INSTALACIÓN DE LAS PILAS . . . . . . . . . . . . .30

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

MODO DE ENTRADA EXTERNA . . . . . . . . . . .30

SELECCION DE IDIOMA . . . . . . . . . . . . . . . . .30

AJUSTE DE CANAL . . . . . . . . . . . . . . . . . . . . . .31

AJUSTE DEL RELOJ . . . . . . . . . . . . . . . . . . . . .31

- 5 - EN

9J27

FEATURES

Infrared remote control

•

Trilingual on screen menu display selectable in

•

English, Spanish or French Real time counter–This shows the elapsed recording or

•

playback time in hours, minutes, and seconds. The “–” indication will appear when the tape is rewound further than the tape counter position “0:00:00”.

181 channel capability PLL frequency synthesizer

•

tuner with direct station call–(A converter may be nec-

essary to view scrambled cable channels.)

Auto Clock Setting–Allows you to set the clock function

•

from a PBS broadcast station.

Game mode–Automatically sets external input mode and

•

allows TV/VCR display to be suitable for use with TV games.

Auto power on and off system–Automatically turns on

•

the TV/VCR when you insert the cassette, turns off after auto-rewind, and ejects when the beginning of the tape is reached.

Auto rewind when the end of a tape is reached–This

•

function doesn’t occur when using timer recording.

2 Step picture search operation–You can view a video

•

program at a high speed or super high speed in either a forward or reverse direction in LP and SLP mode. For SP mode only high speed.

Three different playback tape speeds : SP/LP/SLP

•

Two different recording tape speeds : SP/SLP

•

Auto Head Cleaner–Automatically cleans video heads as

•

you insert or remove a cassette.

Zero Return–The tape returns to counter of 0:00:00 by

•

rewinding or fast forwarding.

Still–“Freeze” the picture at any time, for close viewing

•

of a particular scene. Only tapes recorded in SLP mode will show a fairly clear picture.

Digital Auto Tracking (DTR)–Automatically adjusts the

•

tracking for each tape you play.

Rental play mode–Improves playback picture quality

•

from worn tapes, such as rental tapes.

Auto repeat–Allows you to repeat the playing of a tape

•

indefinitely without pressing the PLAY button.

Time search–Let you set the TV/VCR to advance the

•

tape by entering the desired playback time you want to skip.

OTR (One Touch Recording)–Instant timed recording

•

from 30 to 480 minutes is possible at the push of the REC/OTR button.

1 Year, 8 events (including Daily and Weekly Timer

•

Recording)–The built-in timer allows you to record up

to 8 programs at different times on different channels up to 1 year in advance. The Daily timer allows recordings to be made of daily broadcasts, and the Weekly timer allows recording to be made once a week up to the end of the tape.

Auto return–After timer recording is finished, the

•

TV/VCR can return to the beginning of the recording.

Wake up/Sleep timer–Allows you to have the TV/VCR

•

automatically turn on or off at a desired time.

Timer Program Extension–Allow you to shift the time

•

schedule for automatic timer recording.

Two- way power–Allows you to power the TV/VCR

•

with standard household AC or your vehicle’s battery, using the supplied car-battery cord.

SUPPLIED ACCESSORIES

Remote Control Unit

PA RT NO.

(N0150UD or N0107UD)

If you need to replace these accessories, please refer to the PART NO. under the illustrations and call 1-800-

•

242-7158. Depending on your antenna system, you may need different types of Combiners (Mixer) or Separators

•

(Splitter). Contact your local electronics store for these items. We do not recommend the use of universal remote controls. Not all of the functions may be controlled with

•

a universal remote control. If you decide to use a universal remote control with this unit, please be aware that the code number given may not operate this unit. In this case, please call the manufacturer of the universal remote control.

Dipole Antenna

(0EMN00723 or

0EMN01183)

Matching Adapter

(300ohm-75ohm)

(1813641 or 1780258 or

UCPGANTPK004)

2 AA Batteries

- 6 - EN

Car Battery Cord

WPZ0202GA004

9J27

OPERATING CONTROLS AND FUNCTIONS

VIDEO AUDIO

STOP/EJECT

REW PLAY F.FWD VOLUME CHANNEL

EARPHONE

REC/OTR

POWER

REC

1 92 3 4 5 6 7 8 12 1310 11 14

POWER

WAKE-UP

/SLEEP

123

456

789

+100

EJECT

CHANNEL

RETURN

REW

PLAY

STOP

F.FWD

GAME

RECORD

PAUSE/STILL

SPEED

TIME SEARCH

CHANNEL

T-PROG.

CLEAR

COUNTER

RESET

DISPLAY MUTE

VOLUME

10 18

19 20

22 21

- TV/VCR FRONT PANEL -

- REMOTE CONTROL -

3 RECORD indicator– Flashes during recording.

4 Remote Sensor Window– Receives the infrared

VIDEO input jack– Connect to the video output

jack of your video camera or another VCR.

AUDIO input jack– Connect to the audio output

jack of your audio equipment, video camera or another VCR.

Lights up in the Stand-by mode for Timer Recording.

signals from the remote control.

5 POWER button– Press to turn TV/VCR on and off.

Press to activate timer recording.

STOP button– Press to stop the tape motion. EJECT button– Press in the Stop mode to remove

tape from TV/VCR.

button–

Press to select setting modes from the on screen

•

menu.

Press to enter digits when setting program.

•

(for example: setting clock or timer program)

REW button– Press to rewind the tape, or to view

the picture rapidly in reverse during playback mode. (Rewind Search)

button–

Press to select a mode from a particular menu.

•

(for example: LANGUAGE or USER’S SET UP)

PLAY button– Press to begin playback.

button–

Press to select setting modes from the on screen

•

menu.

Press to enter digits when setting program.

•

(for example: setting clock or timer program)

F.FWD button– Press to rapidly advance the tape,

or to view the picture rapidly in forward during playback mode. (Forward Search)

button–

When setting program (for example: setting

•

clock or timer program), press to determine your selection and proceed to the next step you want to input.

Press to determine setting modes from on screen

•

menu.

Press to select a mode from a particular menu.

•

(for example: LANGUAGE or USER’S SET UP)

- 7 - EN

9J27

- REAR VIEW - [Fig.3]

10 REC(RECORD) button– Press for manual recording.

OTR button– Activates One Touch Recording.

(only on the TV/VCR)

VOLUME XX/ YYbuttons– Adjust the volume

level.

CHANNEL K / L buttons– Press to select the

desired channels for viewing or recording. You may display the main menu on the TV screen

by pressing repeatedly this button on the TV/VCR.

TRACKING function– Press to minimize video

‘noise’ (lines or dots on screen) during playback mode. (See page 18.)

EARPHONE jack– Connects to earphones (not

supplied) for personal listening. The size of jack is 1/8” monaural (3.5mm).

Cassette compartment

15 Number buttons– Press to select desired channels

for viewing or recording. To select channels from 1 to 9, first press the 0 button and then 1 to 9.

+100 button– When selecting cable channels

which are higher than 99, press this button first, then press the last two digits. (To select channel 125, first press the “+100” button then press “2” and “5”.)

MENU button– Press to display the main menu on

the TV screen.

DISPLAY button– Display the counter or the cur-

rent channel number and current time on the TV screen. (See page 24.)

SPEED button– Press to choose the desired

recording speed:SP/SLP.

T- PROG. CLEAR button– Press to cancel a setting

of timer program. (See page 22.)

COUNTER RESET button– Press to reset counter

to 0:00:00.

GAME button– Sets the game mode and external

input mode at the same time. (See page 15.)

TIME SEARCH button– Press to activate Time

Search mode.

PAUSE/STILL button– Press to temporarily stop

the tape during the recording or to view a still picture during playback.

MUTE button– Mutes the sound. Press it again to

resume sound.

CHANNEL RETURN button– Press to go back to

the previously viewed channel. For example, pressing this button once will change channel display from 3 (present channel) to 10 (previously viewed channel), and pressing it a second time will return from 10 to 3.

WAKE-UP/SLEEP button– Sets the Wake up or

Sleep Timer. (See pages 22 and 23.)

ANT. terminal– Connect to an antenna or cable

system.

DC 13.2V jack– Connect to the Car Battery Cord.

Power cord– Connect to a standard AC outlet

(120V/60Hz).

- 8 - EN

9J27

PREPARATION FOR USE

Satellite Box or Cable Box (Not supplied)

From Cable System

From Cable System or Satellite Dish

OUT

75-ohm Coaxial Cable (Not supplied)

ANT.

Dipole Antenna (Supplied)

Flat twin-lead cable

Matching Adapter (Supplied)

VHF/UHF Combiner

(Not supplied)

VHF/UHF Antenna (Not supplied)

VHF Antenna (Not supplied)

UHF Antenna (Not supplied)

Flat twin-lead cable

CABLE WITHOUT CONVERTER/

ANTENNA/CABLE

CONNECTIONS

DIPOLE ANTENNA HOOK UP

1. Push the stem of the Dipole Antenna (supplied) into the hole for antenna at the back of TV/VCR.

2. Connect the flat twin-lead cable from the Dipole Antenna to the 300/75 ohm Matching Adapter (supplied).

3. Plug the Matching Adapter to ANT terminal of TV/VCR as shown in drawing.

For the best reception, extend the Dipole Antenna and adjust its length and position. (Avoid handling the top section when making adjustments.)

NOTE: If it is difficult to get good reception with the indoor antenna, the use of an outdoor antenna is recommended. Before an outdoor antenna is connected to the set, the indoor antenna should be disconnected.

VHF/UHF COMBINED ANTENNA

A VHF UHF 75 ohm combination antenna can be connected to ANT terminal.

VHF/UHF SEPARATE ANTENNAS

In some areas it will be necessary to use an outdoor antenna.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

DESCRAMBLER BOX

Use this connection if your cable system connects directly to your TV/VCR without a converter box.

By using this connection you can:

1) Use the TV/VCR remote to select channels.

2) Program one or more unscrambled channels for Automatic Timer Recording.

NOTE: This unit will ONL

Y record and view the

same channel.

CABLE WITH CONVERTER/ DESCRAMBLER BOX OR SATELLITE BOX

If your cable service supplies you with a converter box or if you use a satellite system, you can use the basic connection shown in drawing.

By using this connection you can also record scrambled channels. However, channel selection must be made with the converter box or satellite box. This means that channels cannot be changed using the TV/VCR Remote Control. Unattended timer recording is limited to one channel at a time.

TO RECORD A SCRAMBLED/UNSCRAMBLED CHANNEL

1. Set the TV/VCR channel selector to the output channel

of the Cable Converter Box or Satellite Box. (Ex. CH3)

2.Select the channel to record from your Cable

Converter Box or Satellite Box.

- 9 - EN

Fig.4

9J27

INSTALLING THE BATTERIES

DC13.2V

ANT.

1)Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.

2)Insert 2 “AA” penlight batteries into the battery compartment in the direction indicated by the polarity (+/-) markings.

3)Replace the cover.

EXTERNAL INPUT MODE

When using an external input signal (another VCR or video camera), connect the player’s audio/video output cables to the AUDIO IN/ VIDEO IN jacks of your TV/VCR. Then press the CHANNEL K or L button until “AUX” appears on the screen.

AUX

MOBILE CONNECTION

To the vehicle's cigarette-lighter socket

VHF/UHF Combination Mobile Antenna (Not supplied)

Car battery cord (Supplied)

NOTES:

Be sure your vehicle has a 13.2-volt (12-volt), neg-

•

ative-ground electrical system. Be sure you use only the supplied car battery cord.

•

Using another cord could damage the TV/VCR. Be sure the socket is free of ashes and other debris.

•

Be sure to push the car battery cord’s plug com-

•

pletely into the cigarette-lighter socket. Always unplug the car battery from the cigarette-

•

lighter socket before you unplug it from the TV/VCR.

You must disconnect the car battery cord from the

•

TV/VCR before you can use the AC power. Be sure to replace the fuse with only the same type,

•

5A, 250V. Be sure the AC cord is wound as shown below.

•

WARNING:The driver should never watch the TV/VCR while operating a motor vehicle.

CAUTION: If you use the TV/VCR with the vehicle’s engine off, recharge the vehicle’s battery after about every 4 hours of use to prevent it from running down. After you finish using the TV/VCR be sure you unplug the car-battery cord from the cigarette-lighter socket.

1) The supplied indoor antenna is adequate when your vehicle is stationary. For best reception on the road, use a high-quality VHF/UHF mobile TV antenna.

2) Attach the car battery cord to the DC13.2V (12V) connector on the back of the TV/VCR. Then, connect the other end to your vehicle’s cigarettelighter socket.

- 10 - EN

9J27

SET UP FOR USE

SELECTING THE LANGUAGE

1 Plug in the TV/VCR power cord

Plug the TV/VCR power cord into a standard AC outlet.

NOTE:

If some digits appear in the corner of

•

the screen, press the POWER button without unplugging the power cord.

Make sure ...

Press the POWER button to turn on the TV/VCR.

•

NOTE: This function effects only the language on the screen menu and not the audio source.

2 Select “LANGUAGE”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L button to point to “LANGUAGE”.

3 Select “ENGLISH”, “ESPAÑOL” or

“FRANÇAIS”

Select “ENGLISH”, “ESPAÑOL”= Spanish or “FRANÇAIS”= French using the F.FWD/B or REW/s button.

4 Exit the Language mode

Press the MENU button on the remote control to return to TV mode.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK CHANNEL SET UP USER’S SET UP

B LANGUAGE [ENGLISH]

ZERO RETURN TIME SEARCH

CLOCK SET UP

(AUTO / MANUAL)

The TV/VCR clock must be set correctly before VCR timer recording is possible. It is suggested that the clock be set manually when first setting up the TV/VCR. Then, set to [ON] the auto clock setting which will periodically correct the setting if necessary.

NOTE: If you cannot receive a station with time signals, auto clock setting cannot be performed. Use manual setting only.

MANUAL CLOCK SETTING

Make sure ...

The TV/VCR is turned on.

•

In the example below, the clock is to be set to:

DATE May 6th, 2004 SETTING TIME 5:40PM

1 Select “SETTING CLOCK”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L button to point to “SETTING CLOCK”.

Then, press the F.FWD/B button.

2 Select “MANUAL CLOCK SET”

Press the PLAY/K or STOP/L button to point to “MANUAL CLOCK SET”.

Then, press the F.FWD/B button.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP LANGUAGE [ENGLISH] ZERO RETURN TIME SEARCH

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH AUTO CLOCK CH [ 02 ]

B MANUAL CLOCK SET

D.S.T. [OFF]

NOTE: If for some reason the menu is in Spanish or French, press the MENU button on the remote control, press the PLAY/K button to point to “IDIOMA [ESPAÑOL]” or “LANGAGE [FRANÇAIS]”, then press the F.FWD/B button, then press the MENU button on the remote control.

3 Select the month

Press the PLAY/K or STOP/L button until your desired month appears. (Example: May → 05)

Then, press the F.FWD/B button.

4 Select the day

Press the PLAY/K or STOP/L button until your desired day appears. (Example: 6th → 06)

Then, press the F.FWD/B button.

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / – – – – – – – – –

HOUR MINUTE

– – : – – – –

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 – – – – – – –

HOUR MINUTE

– – : – – – –

- 11 - EN

9J27

5 Select the year

Press the PLAY/K or STOP/L button until your desired year appears. (Example: 2004)

Then, press the F.FWD/B button.

6 Select the hour

Press the PLAY/K or STOP/L button until your desired hour appears. (Example: 5, PM)

Then, press the F.FWD/B button.

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 THU 2 0 0 4

HOUR MINUTE

– – : – – – –

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 THU 2 0 0 4

HOUR MINUTE

0 5 : – – PM

system connection using the ANT. terminal on the rear of the TV/VCR.

NOTE:

If a cable converter box is being used, make sure it

•

is powered on. You must use the TV/VCR remote control to per-

•

form the clock setting procedure. If the TV/VCR is connected directly to a cable

•

converter box or satellite box, the local PBS station must be selected on the cable box itself, and the TV/VCR must be set to the output channel of the cable converter box or satellite box (usually channel 3 or 4), to be able to set up or correct the clock automatically.

7 Select the minute

Press the PLAY/K or STOP/L button until the desired minute appears. (Example: 40)

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 6 THU 2 0 0 4

HOUR MINUTE

0 5 : 4 0 PM

8 Start the clock

Press the MENU button on the remote control.

Although seconds are not displayed, they begin counting from 00 when you press the MENU button on the remote control. Use this feature to synchronize the clock with the correct time.

NOTE:

When unplugging the AC cord or if there is a power failure for more than 3 seconds, you may have to reset the clock.

5:40 PM

TO CHANGE CLOCK SETTING

If you want to change the clock,

1)Follow steps [1] and [2].

2)Select where you want to change using the F.FWD/B or REW/s button.

3)Enter correct numbers using the PLAY/K or STOP/L button.

4)Press the MENU button on the remote control to start the clock.

PLEASE NOTE:

If there is no local PBS station in your area or on your cable system, select “AUTO CLOCK” and press the F.FWD/B or REW/s button to turn [OFF] this function. Then you can manually adjust the clock.

AUTOMATIC CLOCK SETTING

Make sure ...

The TV/VCR is turned on.

•

Confirm the TV/VCR is receiving a RF (Radio

•

Frequency) signal from either an antenna or cable

1 Select “SETTING CLOCK”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L button to select “SETTING CLOCK”.

Press the F.FWD/B button to enter “SETTING CLOCK” menu.

2 Set “AUTO CLOCK” to [ON]

Press the F.FWD/B button until “AUTO CLOCK [ON]” appears.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP LANGUAGE [ENGLISH] ZERO RETURN TIME SEARCH

– SETTING CLOCK –

B AUTO CLOCK [ON]

AUTO CLOCK CH SEARCH AUTO CLOCK CH [ 02 ] MANUAL CLOCK SET D.S.T. [OFF]

3 Begin “AUTO CLOCK CH SEARCH”

Press the STOP/L button to select “AUTO CLOCK CH SEARCH”.

Press the F.FWD/B button.

The TV/VCR is now searching

•

for the station which contain the auto clock set signal. The search for a signal may take up to 20 seconds per channel.

“_ _” appears at the lower left of

•

the screen when the search has ended.

Auto Clock station- write down

•

the number(s) that appear on the screen. These are the auto clock station(s) in your area. See item 4 below.

If no number(s) appear on the TV screen, there are

•

no stations in your area which contain the Auto Clock signal. Auto Clock Setting is not possible. Please use Manual Clock Setting on page 11.

Press the MENU button to exit the screen. NOTE: During Auto Clock CH Search, the picture

may be distorted. This is normal.

- 12 - EN

– SETTING CLOCK –

AUTO CLOCK [ON]

B AUTO CLOCK CH SEARCH

AUTO CLOCK CH [ 02 ] MANUAL CLOCK SET D.S.T. [OFF]

– AUTO CLOCK CH SEARCH –

08 10 13

_ _

9J27

4 Enter the channel number that contains the

Automatic Clock Setting Signal

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L button to select “SETTING CLOCK”.

Press the F.FWD/B button to enter

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP LANGUAGE [ENGLISH] ZERO RETURN TIME SEARCH

“SETTING CLOCK” menu. Press the STOP/L button to select

“AUTO CLOCK CH”. Press the F.FWD/B or REW/s

buttons until you locate Auto Clock

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH

B AUTO CLOCK CH [ 45]

MANUAL CLOCK SET D.S.T. [OFF]

Set station number. See item 3 above.

Press the MENU button to exit the screen.

5 Turn off the TV/VCR

Once the TV/VCR is turned off , it will periodically check and set the correct date and time.

DAYLIGHT-SAVING TIME

Select this feature and the TV/VCR’s clock automatically will advance one hour in April, then reverse one hour in October.

When Daylight-Saving Time is ON, the clock will change automatically as follows:

First Sunday of April : At 2 AM the clock imme-

•

diately changes to 3 AM. Any timer programming you have set to occur between 2 AM and 3 AM will not record.

Last Sunday of October : At 2 AM the clock

•

immediately changes to 1 AM.

Make sure ...

Press the POWER button to turn on the TV/VCR.

•

1 Select “SETTING CLOCK”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L button to point to “SETTING CLOCK”.

Then, press the F.FWD/B button.

2 Set “D.S.T.” (Daylight-Saving Time) to [ON]

Press the PLAY/K or STOP/L button to point to “D.S.T.”.

Then, press the F.FWD/B or REW/s button until [ON] appears.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL

B SETTING CLOCK

CHANNEL SET UP USER’S SET UP LANGUAGE [ENGLISH] ZERO RETURN TIME SEARCH

– SETTING CLOCK –

AUTO CLOCK [ON] AUTO CLOCK CH SEARCH AUTO CLOCK CH [ 02 ] MANUAL CLOCK SET

B D.S.T. [ON]

3 Exit the Daylight-Saving Time mode

Press the MENU button on the remote control to return to TV mode.

TO CANCEL THE DAYLIGHT-SAVING TIME

Repeat steps [1] to [2], select [OFF] using the F.FWD/B or REW/s button. Then, press the MENU button to return to TV mode.

- 13 - EN

9J27

CHANNEL SET UP

You can program the tuner to scan all the channels you receive in your area.

NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just select the TV/VCR channel selector to the output channel of the cable box or satellite box (Ex CH3). Then select the channel to be viewed on the Cable Box or Satellite Box.

Make sure ...

Press the POWER button to turn on the TV/VCR.

•

1 Select “CHANNEL SET UP”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L button to point to “CHANNEL SET UP”.

Then, press the F.FWD/B button.

2 Begin auto ch programming

Press the PLAY/K or STOP/L button to point to “AUTO CH PROGRAMMING”.

Then, press the F.FWD/B button. The tuner scans and memorizes all

the active channels in your area.

3 After scanning

The tuner stops on the lowest memorized channel.

When AUTO CH PROGRAMMING is activated

•

where there is no TV signal input, “NO TV SIGNALS” will appear on the display after the completion of the channel scanning.

The TV/VCR may recognize TV channels to be

•

CATV channels by the receiving conditions. In this case, try auto ch programming again in the fine receiving conditions.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK

B CHANNEL SET UP

USER’S SET UP LANGUAGE [ENGLISH] ZERO RETURN TIME SEARCH

– CHANNEL SET UP –

ADD / DELETE CH (CATV)

B AUTO CH PROGRAMMING

DELETING (OR ADDING)

CHANNEL

The channels you no longer receive or seldom watch can be deleted from the memory. (Of course, you can add the deleted channel into the memory again.)

1 Select “CHANNEL SET UP”

Press the MENU button on the remote control. Then press the PLAY/K or STOP/L button to point to “CHANNEL SET UP”.

Then, press the F.FWD/B button.

2 Select “ADD/DELETE CH”

Press the PLAY/K or STOP/L button to point to “ADD/DELETE CH”.

Press the F.FWD/B button.

3 Enter the desired channel number

Press the PLAY/K or STOP/L button until your desired channel number appears. (You can also use the number buttons or the CHANNEL K/L button to enter it.) (Example: CH8)

4 Delete (or add) it from (into) memory

Press the F.FWD/B or REW/s button. The channel number changes to light red. The channel is deleted from memory.

To delete another channel, repeat steps [3] and [4].

•

If you press the F.FWD/B or REW/s button

•

again, the channel is memorized again.

Added channel: Light blue. Deleted channel: Light red.

5 Exit the channel setup mode

Press the MENU button on the remote control to returns to TV mode.

NOTE: To confirm that channel(s) has been deleted or added, press the CHANNEL K or L button.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK

B CHANNEL SET UP

USER’S SET UP LANGUAGE [ENGLISH] ZERO RETURN TIME SEARCH

– CHANNEL SET UP –

B ADD / DELETE CH (CATV)

AUTO CH PROGRAMMING

ADD / DELETE

- 14 - EN

9J27

TV OPERATION

WATCHING A TV PROGRAM

1 Turn on the TV/VCR

Press the POWER button to turn on the TV/VCR.

2 Select the channel number

Press the CHANNEL K or L button to select your desired channel number or press the number buttons on the remote control.

Remember: If the TV/VCR is connected to a cable box or satellite box, the TV/VCR must be on CH3 or CH4, then the channel to be viewed must be selected on the cable box or satellite box.

3 Adjust sound

Press the VOLUME XXor YYbutton to adjust the volume.

VOLUME 20

C C C C C C C C C C C C

GAME MODE

This function enables you to decrease the TV screen contrast and making it suitable for use with a TV GAME.

NOTE: This function CANNOT be set during recording.

Press the GAME button on the remote control. “GAME” appears on the screen.

When you press the GAME button;

The TV/VCR comes on automatically if it is off.

•

The TV/VCR will be in external input mode auto-

•

matically.

GAME

PICTURE CONTROL

The TV/VCR’s picture controls – BRIGHT, CONTRAST, COLOR, TINT and SHARPNESS – are

preset to factory specifications. Although they are usually the best, you may need to make some further adjustments for a natural looking image.

NOTES:

Procedures must be followed within 5 seconds or

•

the Picture Control mode will be cancelled. When setting the Picture Control, the Game mode

•

will be cancelled.

Make sure ...

TV/VCR power must be turned on.

•

1 Select “PICTURE CONTROL”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L button to point to ”PICTURE CONTROL”.

Then, press the F.FWD/B button.

2 Select item you want to adjust

Press the PLAY/K or STOP/L button until desired control is displayed.

BRIGHT CONTRAST COLOR TINT SHARPNESS

3 Adjust the picture control

Press the F.FWD/B or REW/s button to adjust to your desired level.

– M E N U –

TIMER PROGRAMMING

B PICTURE CONTROL

SETTING CLOCK CHANNEL SET UP USER’S SET UP LANGUAGE [ENGLISH] ZERO RETURN TIME SEARCH

BRIGHT

PP PP PP PP PP PP PP CC PP PP PP PP PP PP PP

–

TO CANCEL THE GAME MODE

Press the GAME button or CHANNEL K or L button on the remote control.

DEGAUSSING

Magnetism from nearby appliances might affect the color of the TV picture.

If this happens, move this unit away from the appliance. If the color is still not correct, disconnect power cord from AC outlet then reconnect it after 30 minutes.

REW/s F.FWD/B

BRIGHT to decrease to increase

brightness brightness

CONTRAST to decrease to increase

contrast contrast

COLOR to pale to brilliant TINT to purple to green

SHARPNESS to soft to clear

If there is a power failure of any kind, the unit will

•

retain its memory for this feature.

- 15 - EN

9J27

PLAYBACK

This TV/VCR will operate with any cassette that has the mark. For best results, we recommend the use of high-quality tapes. Do not use poor quality or damaged tapes.

INSERTING A CASSETTE

Insert the cassette in the direction as shown. Push in gently, but continuously, on the center-back of the cassette until it is drawn into the TV/VCR. The TV/VCR will automatically turn on.

Window

CORRECT

WRONG

PRECAUTIONS

Avoid moisture. Moisture condensation may occur

•

on the tape if it is moved from a cold place to a warm place or visa versa. Before using a tape with these conditions, to avoid damage of the tape and your TV/VCR, wait until the tape has warmed to room temperature and the moisture has evaporated.

Avoid extreme heat, high humidity and magnetic

•

fields. Do not tamper with the cassette mechanism.

•

Do not touch the tape with your fingers.

•

NORMAL PLAYBACK

Make sure ...

TV/VCR power must be turned on.

•

AUTO REPEAT PLAYBACK

The TV/VCR has the auto repeat function that allows you to repeat a tape indefinitely without touching the PLAY button.

ALL REPEAT: Repeat playback from the beginning

to the end of the tape.

BLANK REPEAT: Repeat playback from the begin-

ning to a blank part, which is blank for more than 10 seconds.

1 Select “USER’S SET UP”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L button to point to “USER’S SET UP”.

Then, press the F.FWD/B button.

2 Select “ALL” or “BLANK”

Press the PLAY/K or STOP/L button to point to “REPEAT PLAY”.

Press the F.FWD/B or REW/s button repeatedly until your desired selection [ALL] or [BLANK] appears.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

LANGUAGE [ENGLISH] ZERO RETURN TIME SEARCH

USER’S SET UP

–

RENTAL [OFF]

B REPEAT PLAY [ALL]

AUTO RETURN [OFF]

–

1 Insert a prerecorded tape

If the erase-protection tab has been removed, the TV/VCR will start playback automatically.

2 To begin playback

Press the PLAY button. Note: If any menu is activated on

the screen, the PLAY button does not function. Press the MENU button to clear the menu. then, press the PLAY button.

3 To stop playback

Press the STOP button when playback is completed.

PLAY

STOP

3 Exit the Repeat Play setting

Press the MENU button on the remote control to return to the TV mode.

4 Start playback

Press the PLAY button to start the Repeat Play. ”REPEAT PLAY B” appears.

Once you select the Repeat Play mode, it stays in

•

effect even after you turn off the TV/VCR. If the Rental mode is set [ON], the “RENTAL

•

PLAY B” display has priority.

TO CANCEL THE REPEAT PLAY MODE

Repeat steps [1] and [2], select [OFF] using the F.FWD/B or REW/s button on the remote control. Press the MENU button on the remote control to return to TV mode.

If there is a power failure of any kind, the unit will retain its memory for this feature.

- 16 - EN

9J27

PICTURE SEARCH

This feature is very useful in finding or skipping over a particular scene on a tape. In this mode, the sound will be muted.

1)You may view a video tape at a high speed in either a forward or reverse direction by pressing the F.FWD or REW button during playback. (in the SP / LP / SLP modes)

2)Press it again and the TV/VCR will now search in super high speed. (in the LP / SLP modes only)

NOTE: Tapes recorded in the SP or LP mode will display a noise bar on the TV screen and the picture may revert to Black and White. This is normal.

3)Press the PLAY button to return to normal speed.

ZERO RETURN

This function allows you to search easily a beginning point that you want to review by rewinding or fast forwarding.

NOTE:

Zero Return WILL blank portion of a tape.

1 Stop a tape at your desired point

Rewind or fast forward the tape to the beginning point at which you want to review.

NOT work on a blank tape or a

NOTES:

Time Search can be set up to a maximum of 9

•

hours 50 minutes (9:50) by 10 minutes at a time. This function will not operate in recording mode.

•

In the example below: To watch a program after 2 hour 50 minutes from the present position, in either direction.

1 Insert a tape.

2 Select “TIME SEARCH” mode

Press the TIME SEARCH button (with each push it will increase by 10 minute).

3 Enter your desired time

Press the PLAY/K or STOP/L but-

TIME SEARCH

2 : 50

ton until your desired time appears. (Example: “2:50” stands for 2 hours 50 minutes)

If you wish to cancel the Time Search at this point, press the MENU button on the remote control.

4 Begin Time Search

By pressing the REW/s or F.FWD/B button, the TV/VCR will rewind or fast forward to the specified point.

The time counts down as the searching progresses. When 0:00 is reached, the tape will start playback automatically.

2 Reset the counter to 0:00:00

Press the COUNTER RESET button repeatedly.

3 Begin recording or playback

Press the RECORD or PLAY button. Press the STOP button when recording or playback is

completed.

4 To activate “ZERO RETURN” mode

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L button to point to “ZERO RETURN”.

Then, press the F.FWD/B button. The counter will appear on the TV

screen. The tape will automatically stop when the counter

returns to 0:00:00.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK CHANNEL SET UP USER’S SET UP LANGUAGE [ENGLISH]

B ZERO RETURN

TIME SEARCH

The Time Search function makes it possible to quickly advance the tape to your desired position simply by entering the exact amount of playback time you want to skip.

TO CANCEL THE TIME SEARCH at this point

Press the STOP/EJECT button on the TV/VCR or the remote control. This will delete the selected time.

STILL PICTURE

You can view a still picture on the TV screen during playback (the Still mode). Press the PAUSE/STILL button during playback. Only tapes recorded in the SLP mode will show the least amount of lines. Press the PLAY button to return to playback.

NOTES:

Usually there will be video “noise” lines (black

•

and white streaks or dots) on the screen. This is normal.

If the tape was originally recorded in SP or LP mode, the still picture will be black and white in addition to the “noise” lines.

This is not a fault of the machine, but is a byproduct of the technology involved in producing a TV/VCR with 2 video heads.

If it is left in the Still mode for more than five min-

•

utes, the TV/VCR will automatically switch to the Stop mode.

- 17 - EN

9J27

NOISE CANCEL

(in the Still mode)

RENTAL PLAYBACK

This feature allows you to reposition or reduce the noise lines of a still picture. Press the PAUSE/STILL button so that the noise lines change position on the screen so you can see the picture in its entirety without distracting noise lines.

NOTE: This feature can be activated ONLY when viewing a tape recorded in the SLP mode. If the tape was originally recorded in the SP or LP mode, the still picture may revert to black and white in addition to the “noise bars”. This is normal.

VERTICAL HOLD CONTROL

In the Pause/Still mode only, when the picture begins to vibrate vertically, stabilize the picture by pressing the CHANNEL K or L button.

NOTE:

If there are video noise lines on the screen, reposition or reduce them. Refer to “NOISE CANCEL”.

TRACKING ADJUSTMENT

Tracking adjustment will be set automatically

•

(Digital Tracking function) when you start playback.

However when playing pre-recorded tapes or tapes

•

recorded on units other than your own, noise lines (black and white streaks) may appear on the playback picture. If this occurs, you can adjust the tracking control manually by pressing the CHANNEL K or L button until the streaks disappear. To return to the DTR function, stop the tape once and start playback again.

This function enables you to improve the picture quality when playing back worn cassettes such as rented tapes.

1 Select “USER’S SET UP”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L but-

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

LANGUAGE [ENGLISH] ZERO RETURN TIME SEARCH

ton to point to “USER’S SET UP”. Then, press the F.FWD/B button.

2 Set “RENTAL” to [ON]

Press the PLAY/K or STOP/L button to point to “RENTAL”.

–

B RENTAL [ON]

REPEAT PLAY [OFF] AUTO RETURN [OFF]

–

USER’S SET UP

Press the F.FWD/B or REW/s button until [ON] appears.

3 Exit the Rental setting

Press the MENU button on the remote control to return to the TV mode.

4 Start playback

Press the PLAY button to start playback. “RENTAL PLAY B” appears.

Once you select the Rental mode, it stays in effect

•

even after you turn off the TV/VCR.

TO CANCEL THE RENTAL MODE

Repeat steps [1] and [2], select [OFF] using the F.FWD/B or REW/s button on the remote control. Press the MENU button on the remote control to return to TV mode.

If there is a power failure of any kind, the unit will retain its memory for this feature.

RECORDING

TWO DIFFERENT TAPE SPEEDS

Before recording, select the tape speed from : SP mode (Standard Play) or SLP mode (Super Long

Play). The table below shows the maximum recording/play-

back time using T60, T120 or T160 tapes in each mode.

Tape Speed Recording/Playback Time

Type of tape

SP mode 1 hour 2 hours 2-2/3 hours SLP mode 3 hours 6 hours 8 hours

Note: You can play back a tape recorded in LP mode (Long Play).

T60 T120 T160

ERASE PREVENTION

You can prevent accidental erasing of recording by breaking off the tab on the back edge of the cassette.

Ta b

If you decide to record on the tape again, cover the hole with plastic tape.

Plastic Tape

- 18 - EN

9J27

Make sure ...

TV/VCR power must be turned on.

•

Insert a cassette tape with its erase prevention tab in place. (If necessary, rewind or fast forward the tape to

•

the point at which you want to begin recording.)

NOTE: This unit will ONL

Y record and view the same channel.

NORMAL RECORDING

You can ONL being recorded.

1 Select the channel to be recorded

Press the number buttons on the remote control or the CHANNEL K or L button.

Remember: If the TV/VCR is connected to a cable box or satellite box, the TV/VCR must be on CH3 or CH4, then the channel to be recorded must be selected on the cable box or satellite box.

2 Select the tape speed

Press the SPEED button to select the desired tape speed (SP/ SLP).

3 Begin recording

Press the RECORD button.

4 Stop recording

Press the STOP button when recording is completed.

Y watch the same TV program that is

CH 10

REC

SKIPPING UNWANTED

SCENES DURING RECORDING

Press the PAUSE/STILL button to temporarily stop recording.

Press the PAUSE/STILL or RECORD button to resume recording.

NOTES:

After five minutes, the TV/VCR will automatically

•

switch to the Recording mode to prevent tape damage.

PAUSE

OTR (One Touch Recording)

This function enables you to set a recording length simply by pressing the REC/OTR button on the TV/VCR.

Make sure ...

TV/VCR power must be turned on.

•

Insert a cassette tape with its erase prevention tab

•

in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.)

NOTES:

This function CANNOT be done from the remote

•

control. Recording starts immediately when the REC/OTR

•

button is pressed. When the REC/OTR button is pressed 18 times, the

•

TV/VCR returns to the Normal Recording mode. To stop the OTR operation, press the STOP button

•

on the TV/VCR or on the remote control. To show the remaining time, press the DISPLAY

•

button on the remote control so that “OTR” appears on the TV screen. (It will show up momentarily then disappear.)

Recording stops when 0:00 is reached.

•

Please note that in the SLP mode maximum record-

•

ing time, assuming the tape is started at the beginning, is 8 hours using T-160 (or 6 hours using T-120).

If the tape runs out before the end time, the

•

TV/VCR will switch to the Stop mode immediately, ejects the tape and turns itself off.

If you press the power button during OTR, the

•

TV/VCR continues recording until the selected length is reached.

1 Select the channel to be recorded

Press the number buttons on the remote control or the CHANNEL K or L button.

Remember: If the TV/VCR is connected to a cable box or satellite box, the TV/VCR must be on CH3 or CH4, then the channel to be recorded is selected on the cable box or satellite box.

2 Select the tape speed

Press the SPEED button to select the desired tape speed (SP/ SLP).

- 19 - EN

9J27

3 Begin OTR

9:00AM 10:00AM 12:00PM

Program 1 10:00AM-11:00AM Program 2 9:00AM-10:00AM Program 3 9:30AM-12:00PM

11:00AM

Recording Sequence

*Recording period is SHADED

OTR(2 : 30)

Press the REC/OTR button on the TV/VCR as many times as needed. The recording length will be determined by the number of times you

press the REC/OTR button. Each additional push will increase the recording time by 30 minutes. It is set up to 8 hours.

Push(es) Display Recording length

1 push (normal recording) 2 pushes 0:30 30 minutes 3 pushes 1:00 60 minutes

17 pushes 8:00 480 minutes

TIMER RECORDING

You may set the TV/VCR to start and end a recording while you are away. You can set 8 programs to record on specific days, daily or weekly within a 1 year period.

In the example below, the timer is being set to record:

DATE: July 5th, 2004 SETTING TIME: from 7:30PM to 8:50PM CHANNEL: CH61 TAPE SPEED: SP

Make sure ...

If a cable box or satellite box is connected with the

•

TV/VCR you will be limited to record only one channel. And the channel selector on the TV/VCR must be selected to the output channel of the boxes CH 3 or CH 4 and then the actual channel to be recorded must be selected on the boxes.

Clock must be set to the correct time and date

•

before setting the timer. TV/VCR power must be turn on to program it.

•

Insert a cassette tape with its erase prevention tab

•

in place. (If necessary, rewind or fast forward the tape to the point at which you want to begin recording.)

The channel you want to record is properly set in

•

advance.

Avoid over lap of programs ...

There is a chance that a program will not be recorded. when programs overlap;

The program with an earlier start has priority.

•

Once the earliest program finishes, the overlapping

•

programs will begin recording in sequence. The illustration below demonstrates the sequence

•

of recordings.

1 Select “TIMER PROGRAMMING”

Press the MENU button on the remote control. Confirm “TIMER PROGRAM-

MING” is pointed by pressing the PLAY/K button.

And press the F.FWD/B button.

If you have not yet set the clock,

•

– M E N U –

B TIMER PROGRAMMING

PICTURE CONTROL SETTING CLOCK CHANNEL SET UP USER’S SET UP LANGUAGE [ENGLISH] ZERO RETURN TIME SEARCH

“MANUAL CLOCK SET” appears. If so, follow steps [3] to [8] on pages 11 and 12. Then set the timer recording.

2 Select your desired program position (1~8)

Press the PLAY/K or STOP/L button to select the desired program position.

Then, press the F.FWD/B button.

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

3 Set the channel number

Press the PLAY/K or STOP/L button until the desired channel number appears.

(Example: CH61) Then, press the F.FWD/B button. Remember: If the TV/VCR is connected to a cable

box or satellite box, the TV/VCR must be on CH3 or CH4, then the channel to be recorded is selected on the cable box or satellite box.

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

4 Select once, every day or weekly recording

For once recording :

Press the PLAY/K (up) button until the desired date appears. (Example: “7/05” for July 5th). Then, press the F.FWD/B button.

- 20 - EN

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 7/05 MON -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

9J27

For every day recording : To r ecord a TV program at the same time on the same channel every day. (Example: Monday through Sunday)

Press the STOP/L (down) button

until “EVRY DAY” appears.

Then, press the F.FWD/B but-

ton.

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 EVRY DAY -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

10 Finish setting the program

Press the F.FWD/B or REW/s button. The program is now completed.

To set another program, repeat steps [2] to [10].

•

Press the MENU button on the remote control to

•

return to original mode.

For weekly recording : To r ecord a TV program at the same time on the same channel every week. (Example: every Monday)

Press the STOP/L (down) button

until “EVRY” and your desired

day of the week appear together.

Then, press the F.FWD/B but-

ton.

5 Set beginning hour

Press the PLAY/K or STOP/L button until the desired hour appears. (Example: “ 7, PM” for 7:30PM)

Then, press the F.FWD/B button.

6 Set beginning minute

Press the PLAY/K or STOP/L button until the desired minute appears. (Example: “30” for 7:30PM)

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 EVRY MON -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 7/05 MON 7:12

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 7/05 MON 7:30

- - -/- - - - - -:- - -:- - - -

M -:- - - -

Then, press the F.FWD/B button.

7 Set end hour

Press the PLAY/K or STOP/L button until the desired hour appears. (Example: “8, PM” for 8:50PM)

Then, press the F.FWD/B button.

8 Set end minute

Press the PLAY/K or STOP/L button until the desired minute appears. (Example: “50” for 8:50PM)

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 7/05 MON 7:30

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 7/05 MON 7:30

- - -/- - - - - -:- - -:- - - -

8:30 - -

8:50 - -

Then, press the F.FWD/B button.

9 Set the tape speed

Press the PLAY/K or STOP/L button until the desired tape speed appears. (Example: SP)

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - 61 7/05 MON 7:30

- - -/- - - - - -:- - -:- - - -

8:30 SP

11 Set the timer

Press the POWER button to set automatic timer recording. The TIMER REC indicator lights up.

You must turn off the TV/VCR to activate automat-

•

ic timer recording. If power is not turned off and you continue watch-

ing TV, “TIMER REC STANDBY” starts flashing on the TV screen 2 minutes before the programmed start time.

To shift the time schedule of an automatic timer recording.

1)Press the POWER button.

2)Repeat step [1] on page 20.

3)Press the RECORD button and select the desired program using the PLAY/K or STOP/L button.

4)Press the RECORD button again. Each additional push will shift forward the

begin/end time for recording by 10 minutes. When the recording is already in progress, each additional push will shift forward the end time only. If you want to cancel while setting, press the PAUSE/STILL button on the remote control. The recording time returns to the original time.

NOTE: When you shift forward the time schedule during recording, the recording speed will automatically be set to the SLP mode.

5)Press the F.FWD/B or REW/s button to exit the setting menu. Then press the MENU button on the remote control to return to original mode.

TO CORRECT A PROGRAM

While setting a program; press the REW/s but-

•

ton to go back one step and enter the correct numbers using the PLAY/K or STOP/L button.

After setting a program;

•

1)Press the POWER button.

2)Repeat steps [1] - [2] on page 20.

3)Press the F.FWD/B button (or press the REW/s

button to go back one step) until the part you want to correct begins flashing, then make the changes pressing the PLAY/K or STOP/L button.

4)Press the POWER button to set automatic timer

recording.

- 21 - EN

9J27

TO CANCEL AN AUTOMATIC TIMER RECORDING

After setting a program;

•

1)Press the POWER button.

2)Repeat steps [1] ~ [2] on page 20 and select a program you want to cancel.

3)Press the T-PROG. CLEAR button.

4)Press the MENU button on the remote control to return to TV mode.

While recording is in progress;

•

1)Press POWER button.

2)Press the STOP/EJECT button on the

TV/VCR.

TO CHECK THE BEGIN/END TIME

1)Press the POWER button so that the REC indicator goes off.

2)Press the MENU button on the remote control.

3)Confirm “TIMER PROGRAMMING” is pointed.

4)Press the F.FWD/B button. The details of programs appear on the TV screen.

5)Press the MENU button on the remote control to return to TV mode.

HINTS FOR AUTOMATIC

TIMER RECORDING

Make sure the channel you want to record is prop-

•

erly set in advance. It is not necessary to press the RECORD button for

•

timer recording. Recording begins automatically at the Start time.

•

If you are recording using a Timer mode, you may

•

not operate the unit manually. The erase-prevention tab on the cassette must be in

•

place (or you must put tape over the hole). If the erase-prevention tab is removed, the cassette

•

will be ejected when the POWER button is pressed to off.

If the tape runs out before the end time, the

•

TV/VCR will switch to the Stop mode immediately, and the tape will be ejected.

AUTO RETURN

With this feature, after timer recording is finished, the beginning of the recorded program(s) can be searched for automatically.

2 Set “AUTO RETURN” to [ON]

Press the PLAY/K or STOP/L button to point to “AUTO RETURN”.

–

RENTAL [OFF] REPEAT PLAY [OFF]

B AUTO RETURN [ON]

–

USER’S SET UP

Press the F.FWD/B or REW/s button until [ON] appears. Then, press the MENU button on the remote control to return to TV mode.

3 Auto Return will begin

When all the timer recordings are completed, the TV/VCR will rewind to the beginning of the recorded program(s).

NOTE:

If you press the POWER button while tape is

•

rewinding, the Auto Return will stop.

4 Watch the recorded program

Press the PLAY button.

TO CANCEL THE AUTO RETURN MODE

Repeat steps [1] and [2], select [OFF] using the F.FWD/B or REW/s button. Then, press the MENU button on the remote control to return to TV mode.

If there is a power failure of any kind, the unit will retain its memory for this feature.

WAKE UP TIMER

The Wake Up Timer function turns on the TV/VCR without using the POWER button after a desired period of time.

NOTES:

Use the remote control for this procedure.

•

Clock must be set to the correct time before setting

•

the timer. If you want to select [TAPE], you must insert a

•

cassette tape in the TV/VCR. The tape will start playback automatically on your desired time.

1 Select “WAKE UP TIMER”

Press the WAKE-UP/SLEEP button on the remote control once, and confirm “ON/OFF” is pointed.

Press the F.FWD/B or REW/s button until [ON] appears.

WAKE UP BON/OFF [ON] TIMER TV/TAPE [TV]

TIME [12:00AM]

1 Select “USER’S SET UP”

Press the MENU button on the remote control.

Press the PLAY/K or STOP/L button to point to “USER’S SET UP”.

Then, press the F.FWD/B button.

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK CHANNEL SET UP

B USER’S SET UP

LANGUAGE [ENGLISH] ZERO RETURN TIME SEARCH

2 Select “TV” or “TAPE”

Press the PLAY/K or STOP/L button until to point to “TV/TAPE”.

Press the F.FWD/B or REW/s button, and select [TV] or [TAPE].

- 22 - EN

WAKE UP ON/OFF [ON] TIMER BTV/TAPE [TV]

TIME [12:00AM]

9J27

3 Set wake up time

Press the PLAY/K or STOP/L button until to point to “TIME”.

Press the F.FWD/B or REW/s button until your desired wake up time appears.

WAKE UP ON/OFF [ON] TIMER TV/TAPE [TV]

BTIME [12:00AM]

Each additional push will increase (or decrease) the time by 10 minutes.

4 Exit the Wake Up Timer setting

Press the MENU button on the remote control to return to TV mode.

TO CANCEL THE WAKE UP TIMER

Press the WAKE-UP/SLEEP button on the remote control once, and confirm “ON/OFF” is pointed.

Press the F.FWD/B or REW/s button until [OFF] appears.

SLEEP TIMER

The Sleep Timer function turns off the TV/VCR without using the POWER button after a desired period of time.

NOTE:

This function does not operate during Recording

•

mode.

1 Select “SLEEP TIMER”

Press the WAKE UP/SLEEP button on the remote control until “SLEEP TIMER” appears.

2 Set sleep time

Press the PLAY/K, STOP/L, F.FWD/B or REW/s button until your desired sleep time appears.

Each additional push will increase the time by 30 minutes up to 120 minutes.

Press the MENU button on the remote control to exit the Sleep Timer setting.

TO CANCEL THE SLEEP TIMER

Press the WAKE-UP/SLEEP button on the remote control until “SLEEP TIMER” appears.

To view the time left for sleep timer, press the WA KE-UP/SLEEP button twice, then press the MENU button on the remote control to exit the sleep timer setting.

SLEEP TIMER [2:00]

COPYING A VIDEO TAPE

You can make copies of video tapes made by friends or relatives for your enjoyment.

WARNING: Unauthorized recordings of copyrighted video tapes may be an infringement of copyright laws.

Connect your TV/VCR and a Source (Playing) VCR using the following diagram.

VIDEO AUDIO

REC

Audio/Video adapter cable (not supplied)

POWER

[The TV/VCR]

[Ex: Source (playing) VCR or camcorder]

AUDIO

INOUT

VIDEO

1)Insert a pre-recorded video cassette into the Source (Playing) VCR or camcorder.

2)Insert a blank video cassette, or one you want to record over, into the TV/VCR’s cassette compartment.

3)Press the SPEED button on remote control for the TV/VCR to select the desired recording speed (SP/SLP).

4)Press the CHANNEL K or L button on the TV/VCR until “AUX” appears on the screen.

NOTE: “AUX” is found below the lowest memorized channel. (Example: CH2)

5)Press the RECORD button on the TV/VCR.

6)Begin playback of the tape in the source (Playing) VCR or camcorder.

NOTE: For best results during dubbing, use the TV/VCR’s front panel controls whenever possible. The remote control might affect the source (Playing) VCR’s playback operation.

7)To stop copying, press STOP/EJECT button on the TV/VCR, then stop the tape on the source VCR or camcoder.

- 23 - EN

9J27

ON SCREEN DISPLAY

COUNT 0:12:34

5:40PM

CH2

Press once

To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows:

Counter mode: After 5 seconds, only

•

the counter remains. To clear it, press the DISPLAY button.

Clock mode: After 5 seconds, only

•

the clock and the channel number remain. To clear them, press the DISPLAY button.

SPECIAL FEATURES

REAL TIME TAPE COUNTER

This shows the elapsed recording or playback time in hours, minutes, and seconds. (The displayed time will not change on a blank tape or blank portions on the tape.)The “–” indication will appear when the tape has rewound further than “0:00:00” on the tape counter.

MAINTENANCE

CABINET CLEANING

Wipe the front panel and other exterior surfaces of

•

the TV/VCR with a soft cloth immersed in lukewarm water and wrung dry.

Never use a solvent or alcohol. Do not spray insec-

•

ticide liquid near the TV/VCR. Such chemicals may cause damage and discoloration to the exposed surfaces.

AUTO HEAD CLEANING

Automatically cleans video heads as you insert or

•

remove a cassette, so you can see a clear picture. Playback picture may become blurred of interrupt-

•

ed while the TV program reception is clear. Dirt accumulated on the video heads after long periods of use, or the usage of rental or worn tapes can cause this problem. If a streaky or snowy picture appears during playback, the video heads in your TV/VCR may need to be cleaned.

AUTO REWIND-EJECT

When the end of a tape is reached during record-

•

ing, playback, or fast-forward, the tape will automatically rewind to the beginning. After rewinding finishes, the TV/VCR will eject the tape and turn itself to off.

This function is operative when Repeat Play is set

•

to the [OFF] position. The tape will not auto-rewind during timer record-

•

ing or One Touch Recording.

1.Please visit your local Audio/Video store and purchase a good quality VHS Video Head Cleaner.

2.If a Video Head Cleaner does not solve the problem, please call our help line at 1-800-242-7158, to locate an Authorized Service Center.

NOTES:

Remember to read the instructions included with

•

the video head cleaner before use. Clean video heads only when problems occur.

•

SERVICING

Should your TV/VCR become inoperative, do not

•

try to correct the problem by yourself. There are no user-serviceable parts inside. Turn off, unplug the power cord, and please call our help line at 1-800242-7158, to locate an Authorized Service Center.

- 24 - EN

9J27

TROUBLESHOOTING GUIDE

If you have followed the instructions contained in this manual and have difficulty in operating your TV/VCR, locate the PROBLEM in the left column below. Check the corresponding CORRECTIVE ACTION column to remedy the problem.

PROBLEM CORRECTIVE ACTION

No power.

No picture and sound.

No picture or poor picture on TV/VCR.

No sound or poor sound.

Timer recording is not possible.

Cannot go into Record mode.

Playback picture is partially noisy.

No picture but the audio is OK in playback.

No operation by infrared Remote Control. Video or color fades in and out

when making a copy of a video tape Can not set the auto clock to ON. Different color makes on screen.

Make sure the AC cord is connected to an AC outlet.

•

Make sure the car battery cord is connected to vehicle’s cigarette

•

lighter socket and to DC 13.2V (12V) jack on back of the TV/VCR. Check the fuse (5A, 250V) in car battery cord.

•

Make sure the power is turned on.

•

Make sure the AC cord is connected to an AC outlet.

•

Check antenna connection.

•

Let the TV/VCR program it's tuner memory.

•

Adjust direction or replace antenna.

•

Adjust picture controls.

•

Adjust volume control on remote control or main unit.

•

Press the MUTE button to restore sound.

•

Make sure the timer recording is set correctly.

•

Make sure the power is off.

•

Make sure the TV/VCR clock is set correctly.

•

Make sure the tape has an erase-prevention tab. If need, cover the

•

hole with plastic tape.

•

Adjust tracking control for a better picture using the CHANNEL K

•

or L button on the TV/VCR.

•

Head cleaning may be necessary. Refer to “AUTO HEAD

•

CLEANING” on page 24.

•

Make sure the AC cord is connected to an AC outlet.

•

Check batteries in remote control.

•

You can not copy a copyrighted video tape. You are experiencing

•

.•copy guard protection.

Make sure the AC cord is connected to an AC outlet.

•

Magnetism from nearby appliances and geomagnetism might affect

•

the color of the TV picture. Move the TV/VCR away from the appliances, the TV/VCR can repair itself automatically. If you want to repair immediately, unplug the TV/VCR power cord, then plug it in again 30 minutes or so later.

- 25 - EN

9J27

SPECIFICATIONS

TV Display

CATV channel

TV Display

W+80 W+81 W+82 W+83 W+84

W+65 W+66 W+67 W+68 W+69 W+70 W+71 W+72 W+73 W+74 W+75 W+76 W+77 W+78 W+79

W+55 W+56 W+57 W+58 A-4 A-3 A-2 A-1 W+59 W+60 W+61 W+62 W+63 W+64

W+40 W+41 W+42 W+43 W+44 W+45 W+46 W+47 W+48 W+49 W+50 W+51 W+52 W+53 W+54

W+25 W+26 W+27 W+28 W+29 W+30 W+31 W+32 W+33 W+34 W+35 W+36 W+37 W+38 W+39

W+10 W+11 W+12 W+13 W+14 W+15 W+16 W+17 W+18 W+19 W+20 W+21 W+22 W+23 W+24

A-5

RSTUVWW+1 W+2 W+3 W+4 W+5 W+6 W+7 W+8 W+9

CDEFGHI JKLMNOPQ

5A 2 3 4 5 6 7 8 9 10 11 12 13 A B

123456789101112131415

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

46 47 48 49 50 51 52 53 54 55 56 57 58 59 60

61 62 63 64 65 66 67 68 69 70 71 72 73 74 75

76 77 78 79 80 81 82 83 84 85 86 87 88 89 90

91 92 93 94 95 96 97 98 99 100 101 102 103 104 105

106 107 108 109 110 111 112 113 114 115 116 117 118 119 120

121 122 123 124 125

CATV channel

GENERAL SPECIFICATIONS

CRT : 9 inch in-line gun, 90˚

deflection tube Television system : NTSC-M Video Heads : Rotary two-head Tape width : 1/2 inch Tape speed

SP : 33.40mm/sec. LP : 16.67mm/sec. SLP : 11.12mm/sec.

Tuner channel

TV VHF Low : #2~#6 TV VHF High : #7~#13 TV UHF : #14~#69 CATV VHF : 5A MID band : A5~A1, A~I SUPER band : J~W HYPER band : W+1~W+84

Terminals

Antenna input : VHF/UHF 75 ohms

unbalanced

Video input : RCA connector [ 1 Audio input : RCA connector [ 1 Earphone : 1/8” monaural (3.5 mm)

ELECTRICAL SPECIFICATIONS

Video input level : 0.5~2.0Vp-p Audio input level : -15dBs

Video S/N ratio : More than 46dB Audio S/N ratio : More than 43dB

OTHER SPECIFICATIONS

Power requirement : AC 120V/60Hz

DC 13.2V Power consumption : AC 55W / DC 60W Dimensions : H:12-7/8” (326mm)

W:12-1/16” (306mm)

D:12-3/4” (324mm) Weight : 18.5 lbs (8.4kg)

Designs and specifications are subject to change

•

without notice. If there is a discrepancy between languages, the

•

default language will be English.

CABLE CHANNEL DESIGNATIONS

If you subscribe to cable TV, the channels are displayed as 1-125. Cable companies often designate channels with letters or letter-number combinations. Please check with your local cable company. The following is a chart of common cable channel designations.

- 26 - EN

9J27

CONTROLES DE OPERACIÓN Y SUS FUNCIONES

POWER

WAKE-UP

/SLEEP

123

456

789

+100

EJECT

CHANNEL

RETURN

REW

PLAY

STOP

F.FWD

GAME

RECORD

PAUSE/STILL

SPEED

TIME SEARCH

CHANNEL

T-PROG.

CLEAR

COUNTER

RESET

DISPLAY MUTE

VOLUME

10 18

19 20

22 21

NOTA:

No recomendamos utilizar mandos a distancia universales. No todas las funciones pueden ser controladas mediante un mando a distancia universal. Si decide utilizar un mando a distancia universal con esta unidad, tenga en cuenta que con el número de código dado tal vez no se pueda controlar la unidad. En este caso, póngase en contacto con el fabricante del mando a distancia universal.

- PANEL DELANTERO -

VIDEO AUDIO

POWER

REC

REW PLAY F.FWD VOLUME CHANNEL

REC/OTR

EARPHONE

STOP/EJECT

1 92 3 4 5 6 7 8 12 1310 11 14

- CONTROL REMOTO -

6 Botón de parada (STOP)– Púlselo para detener

la cinta. Botón de expulsión (EJECT)–Púlselo en el

modo de parada para expulsar la cinta del televisor/videograbadora.

Botón L–

Púlselo para seleccionar los modos de ajuste desde

• el menúde la pantalla.

Púlselo para introducir dígitos cuando establezca

• un programa.

(Por ejemplo: Para ajustar el reloj o establecer un programa de temporizador)

7 Botón de rebobinado (REW)– Púlselo para

rebobinar la cinta, o para ver la imagen en retroceso rápido durante el modo de reproducción. (Búsqueda con rebobinado)

Botón s–

Púlselo para seleccionar un modo desde un menú-

• particular.

1 Toma de entrada de vídeo (VIDEO)–

Conéctela a la toma de salida de vídeo de su videocámara u otra videograbadora.

2 Toma de entrada de audio (AUDIO)–

Conéctela a la toma de salida de audio de su equipo de audio, videocámara u otra videograbadora.

3 Indicador de grabación (RECORD)– Parpadea

durante la grabación. Se enciende en el modo de espera de la grabación

con temporizador.

4 Ventanilla sensora del mando a distancia–

Recibe las señales infrarrojas procedentes del mando a distancia.

5 Botón de la alimentación (POWER)– Púlselo

para encender y apagar el televisor/videograbadora. Púlselo para activar la grabación con temporizador.

(Por ejemplo: IDIOMA o ADJUST DE USER)

8 Botón de reproducción (PLAY)– Púlselo para

iniciar la reproducción. Botón K–

Púlselo para seleccionar los modos de ajuste desde

• el menú de la pantalla.

Púlselo para introducir dígitos cuando establezca

• un programa.

(Por ejemplo: Para ajustar el reloj o establecer un programa de temporizador)

9 Botón de avance rápido (F.FWD)– Púlselo para

avanzar rápidamente la cinta, o para ver la imagen en avance rápido durante el modo de reproducción. (Búsqueda con avance rápido)

Botón B–

Cuando establezca un programa (por ejemplo: para

• ajustar el reloj o para establecer un programa de

temporizador), púlselo para determinar su elección y vaya al paso siguiente que quiera introducir.

Púlselo para determinar los modos de ajuste desde

• el menú de la pantalla.

- 27 - EN

9J27

- PANEL TRASERO -

Púlselo para seleccionar un modo desde un menú-

• particular.

(Por ejemplo: IDIOMA o ADJUST DE USER)

10 Botón de grabación (REC)– Púlselo para ini-

ciar la grabación manual.

Botón de grabación de un toque (OTR)–

Activa la grabación de un toque. (Sólo en el televisor/videograbadora)

11 Botones de volumen (VOLUME XX/ YY)–

Ajustan el nivel del volumen.

12 Botones de canales (CHANNEL K/ L)–

Púlselos para seleccionar los canales deseados para ver o grabar. Se puede mostrar el menú principal en la pantalla del televisor pulsando repetidamente este botón del televisor/videograbadora. Función de seguimiento– Pulse los botones para minimizar el ruido de vídeo (líneas o puntos en la pantalla) durante la reproducción.

13 Toma de auriculares (EARPHONE)– Para

conectar los auriculares (no suministrados) y escuchar en privado. La toma es mono y tiene un tamaño de 1/8”(3.5 mm).

14 Compartimiento del videocasete 15 Botones numerados– Púlselos para seleccionar

los canales deseados para ver o grabar. Para seleccionar canales del 1 al 9, pulse primero el botón 0 y luego el botón 1 a 9. Botón +100– Cuando seleccione canales de televisión por cable cuyo número sea superior al 99, pulse primero este botón, y luego pulse los dos últimos dígitos. (Para seleccionar el canal 125, pulse primero el botón “+100” y luego el “2” y el “5”.)

16 Botón de menú (MENU)– Púlselo para visu-

alizar el menú principal en la pantalla del televisor.

17 Botón del visualizador (DISPLAY)– Visualiza

el contador o el número del canal actual y la hora actual en la pantalla del televisor.

18 Botón de velocidad de cinta (SPEED)–

Púlselo para elegir la velocidad de grabación deseada: SP/SLP.

19 Botón T-PROG. CLEAR– Púlselo para cancelar

un programa de temporizador.

Botón de reposición del contador (COUNTER RESET)– Púlselo para reponer el

contador a 0:00:00.

20 Botón de juego (GAME)– Establece el modo

del juego y el modo de entrada externa al mismo tiempo.

21 Botón de búsqueda con tiempo (TIME

SEARCH)– Púlselo para activar el modo de

búsqueda con tiempo.

22 Botón de pausa/imagen fija

(PAUSE/STILL)– Púlselo para detener temporal-

mente la cinta durante la grabación o para ver una imagen fija durante la reproducción.

23 Botón de silenciamiento (MUTE)– Silencia el

sonido. Púlselo de nuevo para recuperar el sonido.

24 Botón de retorno de canal (CHANNEL

RETURN)– Púlselo para volver al canal anterior.

Por ejemplo, pulsando una vez este botón, la visualización del canal cambiará de 3 (canal actual) a 10 (canal anterior), y al pulsarlo por segunda vez, el canal cambiará del 10 al 3.

25 Botón del temporizador despertador/para

dormir (WAKE-UP/SLEEP)– Ajusta el tempo-

rizador para despertarse/dormir.

26 Terminal de antena (ANT.)– Para conectar una

antena o sistema de televisión por cable.

27 DC 13.2V– Conecta el cordón para la batería del

automóvil. Cordón de alimentación– Conéctelo a la toma

de CA estándar (120V/60Hz).

- 28 - EN

9J27

Caja de CATV o caja de emisiones vía satélite (no incluído)

Desde el sistema de Cable

Cable coaxial de 75 ohm (no incluído)

CONEXIONES DE ANTENA/CABLE

Desde el cable coaxial o caja de emisiones vía satélite de 75 ohm del sistema de Cable

OUT

ANT.

Antena Dipolar (incluído)

Adaptador de acoplo (incluído)

Combinador de VHF/UHF (no incluído)

Antena combinada de VHF/UHF (no incluído)

Antena VHF (no incluído)

Antena UHF (no incluído)

Cable bifilar plano

CONEXION DE LA ANTENA BIPOLAR

1.Introduzca la varilla de la antena bipolar (incluído) en el orificio destinado para la antena, en la parte trasera de la TV/VCR.

2.Conecte el cable bifilar plano de la antena bipolar al adaptador de acoplo (

incluído) de 300/75 ohm.

3.Enchufe el adaptador de acoplo al terminal ANT de la TV/VCR, como lo muestra el dibujo.

Para obtener una mejor recepción, extienda la antena de varilla y regule su longitud y posición. (Evite tocar su parte superior mientras hace los ajustes.)

NOTAS: Si es difícil obtener una buena recepción con la antena de interiores, se recomienda usar una antena de exteriores. Antes de instalar una antena de exteriores al aparato, se debe desconectar la antena de interiores.

ANTENA COMBINADA DE VHF/UHF

Una antena de combinación de 75 ohm para VHF/UHF puede ser conectada al terminal ANT.

ANTENAS SEPARADAS DE VHF/UHF

En algunos lugares será necesario utilizar una antena exterior.

CABLE SIN CONVERTIDOR/DESCODIFICADOR

Utilice esta conexión si su sistema de televisión por cable se conecta directamente a su televisor/videograbadora sin convertidor.Utilizando esta conexión usted podrá:

1)Utilizar el mando a distancia del televisor/videograbadora para seleccionar canales.

2)Programar uno o más canales sin codificar para

realizar la grabación automática con temporizador.

NOTA: Con esta unidad SÓLO se podrá grabar y ver un mismo canal al mismo tiempo

CABLE CON CONVERTIDOR/DESCODIFICADOR O CONVERTIDOR DE EMISIONES VÍA SATÉLITE

Si su servicio de televisión por cable le suministra un convertidor, o si usted utiliza un sistema de emisiones vía satélite, usted podrá utilizar las conexiones básicas.

Utilizando estas conexiones, usted también podrá grabar canales codificados. Sin embargo, la selección de los canales deberá hacerse con el convertidor de televisión por cable con el convertidor de emisiones vía satélite. Esto significa que los canales no podrán ser cambiados con el mando a distancia del televisor/videograbadora. La grabación inatendida se limita a un canal cada vez.

PARA GRABAR UN CANAL CODIFICADO/DESCODIFICADO

1.Ajuste el selector de canales del televisor/videograbadora al canal de salida del convertidor de televisión por cable o del convertidor de emisiones vía satélite. (Ej.: CA3)

2.Seleccione el canal que desee grabar de su convertidor de televisión por cable o del convertidor de emisiones vía satélite.

Aviso a los instaladores de sistemas CATV:

Este aviso se incluye para que los instaladores de sistemas CATV tenga en cuenta el Artículo 820-40 del NEC, que proporciona consejos para hacer una conexión apropiada a tierra y, en particular, especifica que el cable de tierra deberá conectarse a un sistema de puesta a tierra del edificio tan cerca del punto de entrada del cable como sea posible.

- 29 - EN

9J27

CONEXION MOVIL

DC13.2V

ANT.

ADVERTENCIA: El conductor nunca debe ver programas del televisor o del videobgrabadora mientras está conduciendo un vehículo.

PRECAUCIÓN: Si usted usa la TV/VCR con el motor del vehículo apagado, recargue la batería del vehículo aprox. cada 4 horas de uso, para evitar que ésta se agote. Cuando termine de usar la TV/VCR, siempre desenchufe el cordón para la batería del automóvil del zócalo del encendedor de cigarrillos.

1)La antena de interiores incluída es adecuada para usar cuando el vehículo está inmóvil. Para obtener una mejor recepción en ruta, utilice una antena de VHF/UHF para TV móvil de alta calidad.

2)Enchufe el cordón para batería de automóvil al conector DC13.2V (12V) en la parte posterior de la TV/VCR. Luego conecte el otro extremo en el zócalo para el encendedor de cigarrillos del automóvil.

NOTAS:

Confirme que su vehículo tlene un sistema eléctrico

• a tierra negativo de 13.2 (12) voltios.

Confirme que está usando sólo el cordón provisto

• para la batería del automóvil. El uso de otro cordón

puede dañar su TV/VCR. Asegúrese que no haya cenizas ni otro restos en el

• zócalo del encendedor.

Asegúrese de introducir completamente el enchufe

• del cordón de la batería del automóvil en el zócalo

del encendedor de cigarrillos. Siempre desenchufe primero del zócalo del

• encendedor de cigarrillos el cordón para la batería

del coche, antes de desconectarlo de la TV/VCR. Antes de usar la alimentación de CA, usted debe

• desconectar de la TV/VCR el cordón para la batería

del automóvil. Solamente reemplace un fusible por otro del mismo

•

5A, 250V.

tipo Asegúrese de que el cable de CA esté bobinado

• como se muestra más abajo.

Al zócalo del encendedor de cigarrillos el cordón para la batería del coche

Antena de VHF/UHF para TV móvil

(no incluído)

Cordón para la batería del automóvil

INSTALACIÓN DE LAS PILAS

1)Abra la tapa del compartimiento de las pilas del mando a distancia presionándola en el sentido de la flecha.

2)Inserte 2 pilas tamaño “AA” en el compartimiento de las pilas, en el sentido indicado por las marcas de polaridad (+/-).

3)Vuelva a poner la tapa.

MODO DE ENTRADA EXTERNA

Cuando utilice una señal de entrada externa (otra videograbadora o una videocámara), conecte los cables de salida de audio/vídeo del equipo de reproducción a las tomas AUDIO IN/VIDEO IN de su televisor/videograbadora. Y luego pulse el botón CHANNEL K o L hasta que “AUX” aparezca en la pantalla.

Usted puede programar el temporizador para que explore todos los canales que puedan recibirse en su zona.

SELECCION DE IDIOMA

1 Enchufe el cordón de alimentación

del televisor/videograbadora

Enchufe el cordón de alimentación del televisor/videograbadora en una toma de CA estándar.

NOTA:

Si aparecen algunas cifras en la esquina

•

de la pantalla, pulse el botón POWER sin desenchufar el cordón de alimentación.

- 30 - EN

9J27

Asegúrese de que ...

Pulse el botón POWER para encender el televi-

•

sor/videograbadora.

NOTA: Esta función afecta sólo el idioma en el menú de la pantalla y no la fuente de audio.

A continuación, pulse el botón F.FWD/B.

El sintonizador busca y memoriza todos los canales activos en su localidad.

AJUSTE DE CANAL

–

AGREGAR/BORRAR (CATV)

B AUTOPROGRAMACION DE CA.

–

2 Seleccione “LANGUAGE”

Pulse el botón MENU en el mando a distancia.

Pulse el botón PLAY/K o STOP/L

– M E N U –

TIMER PROGRAMMING PICTURE CONTROL SETTING CLOCK CHANNEL SET UP USER’S SET UP

B LANGUAGE [ENGLISH]

ZERO RETURN TIME SEARCH

para señalar “LANGUAGE”.

Seleccione “ENGLISH”, “ESPAÑOL” o “FRANÇAIS”

Seleccione “ENGLISH”, “ESPAÑOL” o “FRANÇAIS” con el botón F.FWD/B y pulse el botón REW/s en el mando a distancia.

4 Salga del modo de idioma

Pulse el botón MENU en el mando a distancia para volver al modo del televisor.

NOTA: Si, por alguna razón, el menú está en español o francés, pulse el botón MENU en el mando a distancia, pulse el botón PLAY/K para señalar el “IDIOMA (ESPAÑOL)” o “LANGAGE (FRANÇAIS)”, a continuación, pulse el botón F.FWD/B y pulse el botón MENU en el mando a distancia.

AJUSTE DE CANAL

Puede programar el sintonizador para buscar todos los canales que recibe en su localidad.

NOTA: El canal preparado NO es necesario cuando esté conectado a una caja de cable o caja de satélite. Sólo tiene que seleccionar con el selector de canal del televisor/videograbadora al canal de salida de la caja de cabe o caja de satélite (por ejemplo el canal CH3). Seleccione el canal a ver en la caja de cable o caja de satélite.

Asegúrese de que ...

Pulse el botón POWER para encender el televi-

•

sor/videograbadora.

1 Seleccione “AJUSTE DE CANAL”

Pulse el botón MENU en el mando a distancia.

Pulse el botón PLAY/K o el botón STOP/L para señalar “AJUSTE DE CANAL”.

A continuación, pulse el botón F.FWD/B.

– M E N U –

COMO PROGRAMAR CONTROL DE IMAGEN AJUSTE RELOJ

B AJUSTE DE CANAL

AJUSTE DE USER IDIOMA [ESPAÑOL]` RETORNO A CERO BUSQUEDA DE HORA

2 Empiece el prefijado automático

Pulse el botón PLAY/K o STOP/L para señalar “AUTOPROGRAMACION DE CA”.

3 Después de buscar

El sintonizador se detiene en el canal memorizado más bajo.

Cuando se activa AUTOPROGRAMACION DE

•

CA, donde no hay entrada de señal del televisor, aparecerá “NO HAY SEÑAL DE TV” en la pantalla después de terminar la búsqueda de canales.

El televisor/videograbadora puede reconocer los

•

canales de TV para que sean canales de TV de antena de cable con las condiciones de recepción. En este caso, pruebe nuevamente con el prefijado automático en las condiciones de recepción fina.

AJUSTE DEL RELOJ

Cerciórese...

La alimentación del televisor/videograbadora

• deberá estar conectada.

En el ejemplo de abajo, el reloj va a ajustarse así:

FECHA: 6 de mayo de 2004 HORA: 5:40 PM

1) Pulse el botón MENU en el mando a distancia. Pulse el botón PLAY/K o STOP/L para indicar

“AJUSTE RELOJ”. Luego, pulse el botón F.FWD/B.

2)Pulse el botón PLAY/K o STOP/L para indicar “AJUSTE MANUAL RELOJ”.

Luego, pulse el botón F.FWD/B.

3)Pulse el botón PLAY/K o STOP/L hasta que aparezca el mes deseado. (Ejemplo: Mayo - 05)

Luego, pulse el botón F.FWD/B.

4)Pulse el botón PLAY/K o STOP/L hasta que aparezca el día del mes deseado. (Ejemplo: 6 - 06)

Luego, pulse el botón F.FWD/B.

5)Pulse el botón PLAY/K o STOP/L hasta que aparezca el año deseado. (Ejemplo: 2004)

Luego, pulse el botón F.FWD/B.

6)Pulse el botón PLAY/K o STOP/L hasta que aparezca la hora deseada. (Ejemplo: 5, PM)

Luego, pulse el botón F.FWD/B.

7)Pulse el botón PLAY/K o STOP/L hasta que aparezca el minuto deseado. (Ejemplo: 40)

8)Pulse el botón MENU en el mando a distancia. Aunque los segundos no se visualizan, éstos empiezan a contar desde 00 cuando se pulsa MENU en el mando a distancia. Utilice esta función para sincronizar el reloj con la hora correcta.

- 31 - EN

9J27

FUNAI CORPORATION

LIMITED WARRANTY

FUNAI CORP. will repair this product, free of charge in the USA in the event of defect in materials or workmanship as follows:

DURATION: PARTS:

LABOR: FUNAI CORP. will provide the labor without charge for a period of ninety (90) days from the date

LIMITS AND EXCLUSIONS:

This warranty is extended only to the original retail purchaser. A purchase receipt or other proof of original retail purchase will be required together with the product to obtain service under this warranty.

This warranty shall not be extended to any other person or transferee.

This warranty is void and of no effect if any serial numbers on the product are altered, replaced, defaced, missing or if service was attempted by an unauthorized service center. This FUNAI CORPORATION Limited warranty does not apply to any product not purchased and used in the United States.

This warranty only covers failures due to defects in material or workmanship which occurs during normal use. It does not cover damage which occurs in shipment, or failures which are caused by repairs, alterations or product not supplied by FUNAI CORP., or damage which results from accident, misuse, abuse, mishandling, misapplication, alteration, faulty installation, improper maintenance, commercial use such as hotel, rental or office use of this product or damage which results from fire, flood, lightning or other acts of God.

THIS WARRANTY DOES NOT COVER PACKING MATERIALS, ANY ACCESSORIES (EXCEPT REMOTE CONTROL), ANY COSMETIC PARTS, COMPLETE ASSEMBLY PARTS, DEMO OR FLOOR MODELS.

FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the date of original retail purchase. Two (2) years for Picture Tube. Certain parts are excluded from this warranty.

of original retail purchase.

FUNAI CORP. AND ITS REPRESENTATIVES OR AGENTS SHALL IN NO EVENT BE LIABLE FOR ANY GENERAL, INDIRECT OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR OCCASIONED BY THE USE OF OR THE INABILITY TO USE THIS PRODUCT. THIS WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND OF ALL OTHER LIABILITIES ON THE PART OF FUNAI, ALL OTHER WARRANTIES INCLUDING THE WARRANTY OF MERCHANTABILITY, AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED BY FUNAI AND ITS REPRESENTATIVES IN THE UNITED STATES. ALL WARRANTY INSPECTIONS AND REPAIRS MUST BE PERFORMED BY A FUNAI AUTHORIZED SERVICE CENTER. THIS WARRANTY IS VALID WHEN THE UNIT IS CARRIED-IN TO FUNAI AUTHORIZED SERVICE FACILITY.

IMPORTANT:

THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE, IF, AT ANY TIME DURING THE WARRANTY PERIOD, YOU ARE UNABLE TO OBTAIN SATISFACTION WITH THE REPAIR OF THIS PRODUCT, PLEASE CONTACT FUNAI CORP.

ATTENTION:

FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY DESIGN OF THIS PRODUCT WITHOUT PRIOR NOTICE.

To locate your nearest FUNAI Authorized Service Center or for general service procedure, please call 1-800-242-7158 or write to the following:

FUNAI CORPORATION, INC.

SERVICE CENTER

19900 Van Ness Avenue, Torrance, CA 90501

Tel :1-800-242-7158

http://www.funai-corp.com

Head Office: 100 North Street, Teterboro, NJ 07608

PLEASE DO NOT SHIP YOUR UNIT TO THE TETERBORO ADDRESS.

Printed in Malaysia 0EMN02466

T4501UB * * * * *

Symphonic SC309E User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
