Symphonic SC309C User Manual
OWNER’S
As an ENERGY STAR
Partner, our company has
determined that this product meets
the E
NERGY STAR guidelines for
energy efficiency. E
NERGY STAR is
a U.S. registered mark.
®
®
®
MANUAL
9-INCH COLOR TV/VCR
SC309C
This Owner’s Manual is made of
recycled paper.
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
If you need additional assistance for set-up or operating
after reading owner’s manual, please call
TOLL FREE : 1-800-242-7158.
Please read before using this equipment
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE
PORTABLE CART WARNING
S3126A
TO RAIN OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The caution marking is located on the rear of the cabinet.
1.Read instructions-All the safety and operating instructions
should be read before the appliance is operated.
2.Retain Instructions-The safety and operating instructions
should be retained for future reference.
3.Heed Warnings-All warnings on the appliance and in the
operating instructions should be adhered to.
4.Follow Instructions-All operating and use instructions
should be followed.
5.Cleaning-Unplug TV/VCR from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use
a damp cloth for cleaning.
EXCEPTION: Aproduct that is meant for uninterrupted
service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to
unplugging the appliance in the cleaning description otherwise required in item 5.
6.Attachments-Do not use attachments not recommended by
the TV/VCR manufacturer as they may cause hazards.
7.Water and Moisture-Do not use this TV/VCR near water-
for example, near a bath tub, wash bowl, kitchen sink, or
laundry tub, in a wet basement, or near a swimming pool,
and the like.
8.Accessories-Do not place this TV/VCR on an unstable cart,
stand, tripod, bracket, or table. The TV/VCR may fall, causing serious injury to someone, and serious damage to the
appliance. Use only with a cart, stand, tripod, bracket, or
table recommended by the manufacturer, or sold with the TV/VCR. Any
mounting of the appliance should
follow the manufacturer’s instructions and should use a mounting
accessory recommended by the manufacturer. An appliance and cart
combination should be moved with
care.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
GEROUS VOLTAGE CONSTITUTING A
RISK OF ELECTRIC SHOCK IS PRESENT
WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE
ARE IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE
APPLIANCE.
IMPORTANT SAFEGUARDS
Quick stops, excessive force, and uneven surfaces may
cause the appliance and cart combination to overturn.
9.Ventilation-Slots and openings in the cabinet and the back
or bottom are provided for ventilation and to ensure reliable
operation of the TV/VCR and to protect it from overheating, and these openings must not be blocked or covered.
The openings should never be blocked by placing the
TV/VCR on a bed, sofa, rug, or other similar surface. This
TV/VCR should never be placed near or over a radiator or
heat register. This TV/VCR should not be placed in a builtin installation such as a bookcase or rack unless proper
ventilation is provided or the manufacturer’s instructions
have been adhered to.
10.Power Sources-This TV/VCR should be operated only
from the type of power source indicated on the marking
label. If you are not sure of the type of power supply to
your home, consult your appliance dealer or local power
company. For TV/VCRs intended to operate from battery
power, or other sources, refer to the operating instructions.
11.Grounding orPolarization-This TV/VCR is equipped
with a polarized alternating-current line plug(a plug having
one blade wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you
are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
12.Power-Cord Protection-Power-supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles,
and the point where they exit from the appliance.
THIS SYMBOL INDICATES THAT DAN-
- 2 - EN
9J27
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELE CTRICAL CODE
S2898A
FIGURE A
ELECTRIC
SERVICE
EQUIPMENT
NEC - NATIO NAL EL ECTR ICAL CODE
GROUND
CLAMP
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNI T
(NEC SECTIO N 810 -20)
GROUNDING CONDUCTORS
(NEC SECTIO N 810 -21)
GROUND CL AMPS
POWER SERVICE GRO UNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
13.Outdoor Antenna grounding-If an outside antenna or
cable system is connected to the TV/VCR, be sure the
antenna or cable system is grounded so as to provide some
protection against voltage surges and built-up static
charges. Article 810 of the National Electrical Code,
ANSI/NFPA No. 70, provides information with respect to
proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit,
size of grounding conductors, location of antenna-discharge
unit, connection to grounding electrodes, and requirements
for the grounding electrode. (Fig. A)
14.Lightning-For added protection for this TV/VCR receiver
during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall
outlet and disconnect the antenna or cable system. This will
prevent damage to the TV/VCR due to lightning and
power-line surges.
15.Power Lines-An outside antenna system should not be
located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them
might be fatal.
16.Overloading-Do not overload wall outlets and extension
cords as this can result in a risk of fire or electric shock.
17.Object and Liquid Entry-Never push objects of any kind
into this TV/VCR through openings as they may touch dangerous voltage points or short out parts that could result in
a fire or electric shock. Never spill liquid of any kind on
the TV/VCR.
18.Servicing-Do not attempt to service this TV/VCR yourself
as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
19.Damage Requiring Service-Unplug this TV/VCR from
the wall outlet and refer servicing to qualified service per-
sonnel under the following conditions:
a. When the power-supply cord or plug is damaged or frayed.
b. If liquid has been spilled, or objects have fallen into the
TV/VCR.
c. If the TV/VCR has been exposed to rain or water.
d. If the TV/VCR does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions, as improper adjust-
ment of other controls may result in damage and will often
require extensive work by a qualified technician to restore
the TV/VCR to its normal operation.
e. If the TV/VCR has been dropped or damaged in any way.
f. When the TV/VCR exhibits a distinct change in perfor-
mance-this indicates a need for service.
20.Replacement Parts-When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer that have the same character-
istics as the original part. Unauthorized substitutions may
result in fire, electric shock, injury to persons or other haz-
ards.
21.Safety Check-Upon completion of any service or repairs to
this TV/VCR, ask the service technician to perform routine
safety checks to determine that the TV/VCR is in proper
operating condition.
22.Heat-This TV/VCR product should be situated away from
heat sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.
- 3 - EN
9J27
PRECAUTIONS
LOCATION
For safe operation and satisfactory performance of
your TV/VCR, keep the following in mind when
selecting a place for its installation:
Shield it from direct sunlight and keep it away
•
from sources of intense heat.
Avoid dusty or humid places.
•
Avoid places with insufficient ventilation for proper
•
heat dissipation. Do not block the ventilation holes
at the top and bottom of the unit. Do not place the
unit on a carpet because this will block the ventilation holes.
Install unit in a horizontal position.
•
Avoid locations subject to strong vibration.
•
Do not place the TV/VCR near strong magnetic fields.
•
Avoid moving TV/VCR to locations where temper-
•
ature differences are extreme.
AVOID THE HAZARDS OF
ELECTRICAL SHOCK AND FIRE
Do not handle the power cord with wet hands.
•
Do not pull on the power cord when disconnecting
•
it from an AC wall outlet. Grasp it by the plug.
If, by accident, water is spilled on your unit, unplug
•
the power cord immediately and take the unit to our
Authorized Service Center for servicing.
Do not put your fingers or objects into the
•
TV/VCR cassette holder.
Do not place anything directly on top of the unit.
•
WARNING
Moisture condensation may occur inside the unit
when it is moved from a cold place to a warm place,
or after heating a cold room or under conditions of
high humidity. If a tape is played in a TV/VCR
which has moisture, it may damage the tape and
TV/VCR. Therefore when the condensation occurs
inside the unit, turn the POWER button on and allow
at least 2 hours for the unit to dry out.
IMPORTANT COPYRIGHT INFORMATION
Unauthorized recording or use of broadcast television programming, video tape, film or other copyrighted material may violate applicable copyright
laws. We assume no responsibility for the unauthorized duplication, use, or other acts which infringe
upon the rights of copyright owners.
FCC WARNING- This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause
harmful interference unless the modifications
are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change
or modification is made.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment
and receiver.
3) Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4) Consult the dealer or an experienced radio/TV
technician for help.
The serial number of this product may be found on the back of the unit. No other TV/VCR has the same serial
number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.
Date of Purchase
Dealer Purchase from
Dealer Address
Dealer Phone No.
Model No.
Serial No.
- 4 - EN
9J27
TABLE OF CONTENTS
C IMPORTANT SAFEGUARDS . . . . . . . . . . . . .2
C PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . .4
C FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
C SUPPLIED ACCESSORIES . . . . . . . . . . . . . . .6
C OPERATING CONTROLS AND FUNCTIONS 7
C PREPARATION FOR USE . . . . . . . . . . . . . . . .9
C SET UP FOR USE . . . . . . . . . . . . . . . . . . . . . .11
CHANNEL SET UP FOR THE FIRST TIME . .11
CLOCK SET UP (AUTO / MANUAL) . . . . . .12
CHANNEL SET UP AGAIN . . . . . . . . . . . . . .13
DELETING (OR ADDING) CHANNEL . . . . .13
SELECTING THE LANGUAGE . . . . . . . . . . .14
DAYLIGHT-SAVING TIME . . . . . . . . . . . . . .14
C TV OPERATION . . . . . . . . . . . . . . . . . . . . . . .15
WATCHING ATV PROGRAM . . . . . . . . . . . .15
GAME MODE . . . . . . . . . . . . . . . . . . . . . . . . .15
DEGAUSSING . . . . . . . . . . . . . . . . . . . . . . . .15
PICTURE CONTROL . . . . . . . . . . . . . . . . . . .15
C PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . .16
NORMAL PLAYBACK . . . . . . . . . . . . . . . . . .16
AUTO REPEAT PLAYBACK . . . . . . . . . . . . .16
SEARCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
STILL PICTURE . . . . . . . . . . . . . . . . . . . . . . .17
NOISE CANCEL (in the Still mode) . . . . . . . .18
VERTICALHOLD CONTROL . . . . . . . . . . . .18
TRACKING ADJUSTMENT . . . . . . . . . . . . . .18
RENTAL PLAYBACK . . . . . . . . . . . . . . . . . . .18
CC
RECORDING . . . . . . . . . . . . . . . . . . . . . . . . .18
NORMAL RECORDING . . . . . . . . . . . . . . . . .19
SKIPPING UNWANTED SCENES DURING
RECORDING . . . . . . . . . . . . . . . . . . . . . . . . .19
OTR (One Touch Recording) . . . . . . . . . . . . . .19
TIMER RECORDING . . . . . . . . . . . . . . . . . . .20
HINTS FOR AUTOMATIC TIMER
RECORDING . . . . . . . . . . . . . . . . . . . . . . . . .22
AUTO RETURN . . . . . . . . . . . . . . . . . . . . . . .22
WAKE UP TIMER . . . . . . . . . . . . . . . . . . . . . .22
SLEEP TIMER . . . . . . . . . . . . . . . . . . . . . . . . .23
C COPYING A VIDEO TAPE . . . . . . . . . . . . . . .23
C ON SCREEN DISPLAY . . . . . . . . . . . . . . . . .24
C SPECIAL FEATURES . . . . . . . . . . . . . . . . . .24
REAL TIME TAPE COUNTER . . . . . . . . . . . .24
AUTO REWIND-EJECT . . . . . . . . . . . . . . . . .24
C MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . .24
C TROUBLESHOOTING GUIDE . . . . . . . . . . .25
C SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . .26
C CABLE CHANNEL DESIGNATIONS . . . . . .26
C WARRANTY . . . . . . . . . . . . . . . . . . .Back Cover
INDICE
CONTROLES DE OPERACIÓN Y
SUS FUNCIONES . . . . . . . . . . . . . . . . . . . . . . . .27
CONEXIONES DE ANTENA/CABLE . . . . . . . .29
INSTALACIÓN DE LAS PILAS . . . . . . . . . . . . .30
A NOTE ABOUT RECYCLING
This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in
accordance with your local recycling regulations.
Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.
MODO DE ENTRADA EXTERNA . . . . . . . . . . .30
PREPARACIÓN DE CANALES POR
PRIMERA VEZ . . . . . . . . . . . . . . . . . . . . . . . . . .31
AJUSTE DEL RELOJ . . . . . . . . . . . . . . . . . . . . .31
- 5 - EN
9J27
FEATURES
Infrared remote control
•
Bilingual on screen menu display selectable in
•
English or Spanish
Real time counter–This shows the elapsed recording or
•
playback time in hours, minutes, and seconds. The “–”
indication will appear when the tape is rewound further
than the tape counter position “0:00:00”.
181 channel capability PLL frequency synthesizer
•
tuner with direct station call–(A converter may be nec-
essary to view scrambled cable channels.)
Auto Clock Setting–Allows you to set the clock function
•
from a PBS broadcast station.
Game mode–Automatically sets external input mode and
•
allows TV/VCR display to be suitable for use with TV
games.
Auto power on and off system–Automatically turns on
•
the TV/VCR when you insert the cassette, turns off after
auto-rewind, and ejects when the beginning of the tape is
reached.
Auto rewind when the end of a tape is reached–This
•
function doesn’t occur when using timer recording.
2 Step picture search operation–You can view a video
•
program at a high speed or super high speed in either a
forward or reverse direction in LP and SLP mode. For
SP mode only high speed.
Three different playback tape speeds :SP/LP/SLP
•
Two different recording tape speeds : SP/SLP
•
Auto Head Cleaner–Automatically cleans video heads as
•
you insert or remove a cassette.
Zero Return–The tape returns to counter of 0:00:00 by
•
rewinding or fast forwarding.
Still–“Freeze” the picture at any time, for close viewing
•
of a particular scene. Only tapes recorded in SLP mode
will show a fairly clear picture.
Digital Auto Tracking (DTR)–Automatically adjusts the
•
tracking for each tape you play.
Rental play mode–Improves playback picture quality
•
from worn tapes, such as rental tapes.
Auto repeat–Allows you to repeat the playing of a tape
•
indefinitely without pressing the PLAY button.
Time search–Let you set the TV/VCR to advance the
•
tape by entering the desired playback time you want to
skip.
OTR (One Touch Recording)–Instant timed recording
•
from 30 to 480 minutes is possible at the push of the
REC/OTR button.
1 Year, 8 events (including Daily and Weekly Timer
•
Recording)–The built-in timer allows you to record up
to 8 programs at different times on different channels up
to 1 year in advance. The Daily timer allows recordings
to be made of daily broadcasts, and the Weekly timer
allows recording to be made once a week up to the end
of the tape.
Auto return–After timer recording is finished, the
•
TV/VCR can return to the beginning of the recording.
Wake up/Sleep timer–Allows you to have the TV/VCR
•
automatically turn on or off at a desired time.
Timer Program Extension–Allow you to shift the time
•
schedule for automatic timer recording.
Two- way power–Allows you to power the TV/VCR
•
with standard household AC or your vehicle’s battery,
using the supplied car-battery cord.
SUPPLIED ACCESSORIES
Remote Control Unit
PART NO. (N0150UD)
If you need to replace these accessories, please refer to the PART NO. under the illustrations and call 1-800-
•
242-7158.
Depending on your antenna system, you may need different types of Combiners (Mixer) or Separators
•
(Splitter). Contact your local electronics store for these items.
We do not recommend the use of universal remote controls. Not all of the functions may be controlled with
•
a universal remote control. If you decide to use a universal remote control with this unit, please be aware
that the code number given may not operate this unit. In this case, please call the manufacturer of the universal remote control.
Dipole Antenna
(300ohm-75ohm)
(1813641 or 1780258 or
UCPGANTPK004)
2 AA Batteries
(0EMN00723 or
0EMN01183)
- 6 - EN
Car Battery CordMatching Adapter
WPZ0202GA004
AC Cord
WPV0182LW001/WPV0182HHH01
9J27
OPERATING CONTROLS AND FUNCTIONS
AUDIO VIDEO
STOP/EJECT
REW PLAY F.FWD VOLUME CHANNEL
EARPHONE
REC/OTR
POWER
REC
1 92 3 4 5 6 7 8 12 1310 11 14
POWER
WAKE-UP
/SLEEP
123
456
789
+100
0
EJECT
CHANNEL
RETURN
REW
PLAY
STOP
F.FWD
GAME
RECORD
PAUSE/STILL
SPEED
TIME SEARCH
CHANNEL
T-PROG.
CLEAR
COUNTER
RESET
DISPLAY MUTE
MENU
VOLUME
5
15
12
6
16
7
10
18
19
20
6
24
11
9
8
22
21
23
17
25
- TV/VCR FRONT PANEL -
- REMOTE CONTROL -
1 AUDIO input jack– Connect to the audio output
2 VIDEO input jack– Connect to the video output
3 RECORD indicator– Flashes during recording.
4 Remote Sensor Window– Receives the infrared
jack of your audio equipment, video camera or
another VCR.
jack of your video camera or another VCR.
Lights up in the Stand-by mode for Timer
Recording.
signals from the remote control.
5 POWER button– Press to turn TV/VCR on and off.
Press to activate timer recording.
6 STOP button– Press to stop the tape motion.
EJECT button– Press in the Stop mode to remove
tape from TV/VCR.
L button–
Press to select setting modes from the on screen
•
menu.
Press to enter digits when setting program.
•
(for example: setting clock or timer program)
7 REW button– Press to rewind the tape, or to view
the picture rapidly in reverse during playback
mode. (Rewind Search)
s button–
Press to select a mode from a particular menu.
•
(for example: LANGUAGE or USER’S SET UP)
8 PLAY button– Press to begin playback.
K button–
Press to select setting modes from the on screen
•
menu.
Press to enter digits when setting program.
•
(for example: setting clock or timer program)
9 F.FWD button– Press to rapidly advance the tape,
or to view the picture rapidly in forward during
playback mode. (Forward Search)
B button–
When setting program (for example: setting clock
•
or timer program), press to determine your selection and proceed to the next step you want to
input.
Press to determine setting modes from on screen
•
menu.
Press to select a mode from a particular menu.
•
(for example: LANGUAGE or USER’S SET UP)
- 7 - EN
9J27
- REAR VIEW - [Fig.3]
26
ANT
DC 13.2V
AC 120V
27
28
10 REC button– Press for manual recording.
OTR button–Activates One Touch Recording.
(only on the TV/VCR)
11 VOLUME
XX/ YY
buttons– Adjust the volume
level.
12 CHANNEL K / L buttons– Press to select the
desired channels for viewing or recording.
You may display the main menu on the TV screen
by pressing repeatedly this button on the
TV/VCR.
TRACKING function– Press to minimize video
‘noise’ (lines or dots on screen) during playback
mode. (See page 18.)
13 EARPHONE jack– Connects to earphones (not
supplied) for personal listening. The size of jack is
1/8” monaural (3.5mm).
14 Cassette compartment
15 Number buttons– Press to select desired channels
for viewing or recording. To select channels from
1 to 9, first press the 0 button and then 1 to 9.
+100 button– When selecting cable channels
which are higher than 99, press this button first,
then press the last two digits. (To select channel
125, first press the “+100” button then press “2”
and “5”.)
16 MENU button– Press to display the main menu on
the TV screen.
17 DISPLAY button– Display the counter or the cur-
rent channel number and current time on the TV
screen. (See page 24.)
18 SPEED button– Press to choose the desired
recording speed:SP/SLP.
19 T-PROG. CLEAR button– Press to cancel a setting
of timer program. (See page 22.)
COUNTER RESET button– Press to reset counter
to 0:00:00.
20 GAME button– Sets the game mode and external
input mode at the same time. (See page 15.)
21 TIME SEARCH button– Press to activate Time
Search mode.
22 PAUSE/STILL button– Press to temporarily stop
the tape during the recording or to view a still picture during playback.
23 MUTE button– Mutes the sound. Press it again to
resume sound.
24 CHANNEL RETURN button– Press to go back to
the previously viewed channel. For example,
pressing this button once will change channel display from 3 (present channel) to 10 (previously
viewed channel), and pressing it a second time
will return from 10 to 3.
25 WAKE-UP/SLEEP button– Sets the Wake up or
Sleep Timer. (See page 22 and 23.)
26 ANT. terminal– Connect to an antenna or cable
system.
27 DC 13.2V jack– Connect to the Car Battery Cord.
28 AC 120V jack– Connect to the AC cord.
- 8 - EN
9J27
ANT.
IN
OUT
ANT
DC 13.2V
AC 120V
PREPARATION FOR USE
Satellite Box or
Cable Box
(Not supplied)
From
Cable System
From Cable System or
Satellite Dish
75-ohm Coaxial
Cable (Not
supplied)
or
Dipole Antenna
(Supplied)
Flat twin-lead cable
ANTENNA/CABLE
CONNECTIONS
DIPOLE ANTENNA HOOK UP
1. Push the stem of the Dipole Antenna (accessory)
into the hole for antenna at the back of TV/VCR.
2. Connect the flat twin-lead cable from the Dipole
Antenna to the 300/75 ohm Matching Adapter
(accessory).
3. Plug the Matching Adapter to ANT terminal of
TV/VCR as shown in drawing.
For the best reception, extend the Dipole Antenna
and adjust its length and position. (Avoid handling
the top section when making adjustments.)
NOTE: If it is difficult to get good reception with
the indoor antenna, the use of an outdoor antenna is
recommended. Before an outdoor antenna is connected to the set, the indoor antenna should be disconnected.
VHF/UHF Antenna
(Not supplied)
VHF Antenna
(Not supplied)
UHF Antenna
or
VHF/UHF
Combiner
or
(Not supplied)
or
Flat twin-lead cable
(Not supplied)
Fig.4
VHF/UHF COMBINED ANTENNA
A VHF UHF 75 ohm combination antenna can be
connected to ANT terminal.
VHF/UHF SEPARA TE ANTENNAS
In some areas it will be necessary to use an outdoor
antenna.
CABLE WITHOUT CONVERTER/
DESCRAMBLER BOX
Use this connection if your cable system connects
directly to your TV/VCR without a converter box.
By using this connection you can:
1) Use the TV/VCR remote to select channels.
2) Program one or more unscrambled channels for
Automatic Timer Recording.
NOTE: This unit will ONLY record and view the
same channel.
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.
Antenna/Cable Connections Continued on the Next Page.
- 9 - EN
9J27
CABLE WITH CONVERTER/
ANT.
DC13.2V
DC13.2V
AC 120V
DESCRAMBLER BOX OR SATELLITE
BOX
If your cable service supplies you with a converter
box or if you use a satellite system, you can use the
basic connection shown in drawing.
By using this connection you can also record scrambled channels. However, channel selection must be
made with the converter box or satellite box. This
means that channels cannot be changed using the
TV/VCR Remote Control. Unattended timer recording is limited to one channel at a time.
TO RECORD A SCRAMBLED/UNSCRAMBLED
CHANNEL
1. Set the TV/VCR channel selector to the output
channel of the Cable Converter Box or Satellite
Box. (Ex. CH3)
2.Select the channel to record from your Cable
Converter Box or Satellite Box.
INSTALLING THE BATTERIES
1)Open the battery compartment cover by pressing
the cover on the remote unit in the direction of the
arrow.
2)Insert 2 “AA” penlight batteries into the battery
compartment in the direction indicated by the
polarity (+/-) markings.
3)Replace the cover.
MOBILE CONNECTION
WARNING:The driver should never watch
the TV/VCR while operating a motor vehicle.
CAUTION: If you use the TV/VCR with the
vehicle’s engine off, recharge the vehicle’s
battery after about every 4 hours of use to
prevent it from running down. After you finish using the TV/VCR be sure you unplug the
car-battery cord from the cigarette-lighter
socket.
1) The supplied indoor antenna is adequate when
your vehicle is stationary. For best reception on
the road, use a high-quality VHF/UHF mobile TV
antenna.
2) Attach the car battery cord to the DC13.2V (12V)
connector on the back of the TV/VCR. Then, connect the other end to your vehicle’s cigarettelighter socket.
NOTES:
Be sure your vehicle has a 13.2-volt (12-volt), neg-
•
ative-ground electrical system.
Be sure you use only the supplied car battery cord.
•
Using another cord could damage the TV/VCR.
Be sure the socket is free of ashes and other debris.
•
Be sure to push the car battery cord’s plug com-
•
pletely into the cigarette-lighter socket.
Always unplug the car battery from the cigarette-
•
lighter socket before you unplug it from the
TV/VCR.
You must disconnect the car battery cord from the
•
TV/VCR before you can use the AC power.
Be sure to replace the fuse with only the same
•
type, 5A, 250V.
EXTERNAL INPUT MODE
When using an external input signal (another VCR or
video camera), connect the player’s audio/video output cables to the AUDIO IN/ VIDEO IN jacks of
your TV/VCR. Then press the CHANNEL K or L
button until “AUX” appears on the screen.
To the vehicle's
cigarette-lighter socket
VHF/UHF Combination
Mobile Antenna
(Not supplied)
Car battery cord
(Supplied)
AUX
- 10 - EN
9J27
Loading...
