Canterbury
Roman Tub Faucet SRT-4570, SRT-4572
Specification Submittal
Model Numbers
SRT-4572 Roman Tub Faucet with Handspray
SRT-4570 Roman Tub Faucet
Finish Options
Append appropriate -sux to model number.
-STN Satin Nickel Finish
- Polished chrome (standard nish)
Feature Highlights
■ Two handle Roman Tub Faucet with quarter turn
ceramic control components.
■ Handspray with separate push button diverter
(SRT-4572 series only)
■ 1/2 rigid copper tubing connections
■ Cast brass spout
■ Metal construction
■ Standard nish is polished chrome
Standards / Certifications
ASME A112.18.1-2005/CSA B125.1-05
™
Options / Modifications
Append appropriate -sux to model number.
Warranty
■ Limited Lifetime - to the original end purchaser in
consumer installations.
■ 5 years - for commercial installations
Dimensions Canterbury Roman Tub Faucet, SRT-4570
2-1/16" (52 mm) dia.
3-1/8"
(80 mm)
Finished deck thickness
1-3/8" (35 mm) max.
3-3/8" (86 mm) max.
*
for TT style faucet
1" dia. (25 mm)
1-1/16" (27 mm) min.
1-1/2" (38 mm) max.
Note: Use TT style faucet if deck thickness is 1-3/8" to 3-3/8" (35 mm - 86 mm),
*
Contact Symmons customer service to special order TT style faucet, model number SRT-4570-TT-BDY
Hole size
Symmons supplied copper tubing
4"
102 mm
8" (203 mm) min.
18-1/4" (464 mm) max. with
3-13/16"
96 mm
Connect using
1/2" copper tubing
1-15/16"
48 mm
10-11/16" (272 mm)
3-15/16" (101mm)
5-15/16" (151mm)
TT style faucet
*
8-9/16" (218 mm)
3"
76 mm
3-1/4"
83 mm
Dimensions Canterbury Roman Tub Faucet, SRT-4572
Symmons Industries, Inc. ■ 31 Brooks Drive ■ Braintree, MA 02184
Phone: (800) 796-6667 ■ Fax: (800) 961-9621
Website: www.symmons.com ■ Email: gethelp@symmons.com
©2008-2014 Symmons Industries, Inc. Printed in U.S.A. ■ ZV-678 ■ Rev A ■ 100314
