542TSD
Degas

Specification Submittal

Model Number Specifications

™

Diverter Tub Spout

542TSD Degas Diverter Tub Spout

Modifications

-ORB Oil rubbed bronze finish

-STN Satin nickel finish

Note: Append appropriate -sufx to model number.

Dimensions

8" diverter tub spout (542TSD) made from brass
materials plated in standard polished chrome nish.

Compliance

N/A

Warranty

Limited Lifetime - to the original end purchaser in

consumer installations.
5 Years - for commercial installations.

Refer to www.symmons.com/warranty for complete
warranty information.

Measurements

A Ø 2 1/2”, 64 mm

BAA

B

CC

Note: Dimensions are subject to change without notice.

D

D

B 1/2”, 13 mm

C 8”, 203 mm

D 1/2” - 14 NPT

Required for Installation

Teon Tape
