HYDAPIPE
Surface Mounted Shower System
1-803S: Standard length
1-804S: Short length
Pressure Balancing mixing valve integral service stops and adjustable stop
screw to limit handle turn. Super shower head on institutional type head
bracket fitting. Attached soap dish and matching cover with ceiling flange
to conceal supplies to ceiling. Stainless steel covering to be 18 gauge with
#4 brush finish.
Modifications:
Add:
Suffix 285: Fre-Flo, all brass, fixed spray (no ball joint)
Suffix 21: Single supply, manual shut off, 4 arm handle
Suffix 60: Single supply, metering shut off
Suffix 56: Pressure Balance and metering combination
Delete:
Suffix S: If soap dish is not required
SYMMONS PRODUCTS MEET
ANSI A112.18.1M, EPA ‘92
AND ALL KNOWN FLOW RATE
REQUIREMENTS.
Shower Heads and Hand Showers
2.5 GPM (9.5 L/min)
Job/Location
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
Engineer
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
Contractor
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
For ADA compliance (Americans with
Disabilities Act) consult ADAAG or your
state regulations for proper product choice
and mounting locations.
Symmons Industries, Inc. ■ 31 Brooks Drive ■ Braintree, MA 02184
(800) 796-6667, (781) 848-2250 ■ Fax (800) 961-9621, (781) 843-3849
Website: www.symmons.com ■ Email: customerservice@symmons.com
©2011 Symmons Industries, Inc. Printed in U.S.A. ■ 062011
