Symbol M2005-I290, M2007-I200, M2004-I290, M2005-I200, M2007-I290 Quick Reference Manual

Cyclone

TM

M2000 Series

CycloneTM

M2000 Series

 2000-03 SYMBOL TECHNOLOGIES, INC. All rights reserved.

Symbol reserves the right to make changes to any product to improve reliability,
function, or design.

Symbol does not assume any product liability arising out of, or in connection with, the
application or use of any product, circuit, or application described herein.

No license is granted, either expressly or by implication, estoppel, or otherwise under
any patent right or patent, covering or relating to any combination, system,
apparatus, machine, material, method, or process in which Symbol products might
be used. An implied license only exists for equipment, circuits, and subsystems
contained in Symbol products.

Symbol and the Symbol logo are a registered trademarks of Symbol Technologies,
Inc. Other product names mentioned in this manual may be trademarks or registered
trademarks of their respective companies and are hereby acknowledged.

Symbol Technologies, Inc.
One Symbol Plaza
Holtsville, N.Y. 11742-1300
http://www.symbol.com

Patents

This product is covered by one or more of the following U.S. and foreign Patents:
U.S. Patent No. 4,593,186; 4,603,262; 4,607,156; 4,652,750; 4,673,805; 4,736,095;
4,758,717; 4,760,248; 4,806,742; 4,816,660; 4,845,350; 4,896,026; 4,897,532; 4,923,281;
4,933,538; 4,992,717; 5,015,833; 5,017,765; 5,021,641; 5,029,183; 5,047,617; 5,103,461;
5,113,445; 5,130,520; 5,140,144; 5,142,550; 5,149,950; 5,157,687; 5,168,148; 5,168,149;
5,180,904; 5,216,232; 5,229,591; 5,230,088; 5,235,167; 5,243,655; 5,247,162; 5,250,791;
5,250,792; 5,260,553; 5,262,627; 5,262,628; 5,266,787; 5,278,398; 5,280,162; 5,280,163;
5,280,164; 5,280,498; 5,304,786; 5,304,788; 5,306,900; 5,324,924; 5,337,361; 5,367,151;
5,373,148; 5,378,882; 5,396,053; 5,396,055; 5,399,846; 5,408,081; 5,410,139; 5,410,140;
5,412,198; 5,418,812; 5,420,411; 5,436,440; 5,444,231; 5,449,891; 5,449,893; 5,468,949;
5,471,042; 5,478,998; 5,479,000; 5,479,002; 5,479,441; 5,504,322; 5,519,577; 5,528,621;
5,532,469; 5,543,610; 5,545,889; 5,552,592; 5,557,093; 5,578,810; 5,581,070; 5,589,679;
5,589,680; 5,608,202; 5,612,531; 5,619,028; 5,627,359; 5,637,852; 5,664,229; 5,668,803;
5,675,139; 5,693,929; 5,698,835; 5,705,800; 5,714,746; 5,723,851; 5,734,152; 5,734,153;
5,742,043; 5,745,794; 5,754,587; 5,762,516; 5,763,863; 5,767,500; 5,789,728; 5,789,731;
5,808,287; 5,811,785; 5,811,787; 5,815,811; 5,821,519; 5,821,520; 5,823,812; 5,828,050;
5,848,064; 5,850,078; 5,861,615; 5,874,720; 5,875,415; 5,900,617; 5,902,989; 5,907,146;
5,912,450; 5,914,478; 5,917,173; 5,920,059; 5,923,025; 5,929,420; 5,945,658; 5,945,659;
5,946,194; 5,959,285; 6,002,918; 6,021,947; 6,029,894; 6,031,830; 6,036,098; 6,047,892;
6,050,491; 6,053,413; 6,056,200; 6,065,678; 6,067,297; 6,082,621; 6,084,528; 6,088,482;
6,092,725; 6,101,483; 6,102,293; 6,104,620; 6,114,712; 6,115,678; 6,119,944; 6,123,265;
6,131,814; 6,138,180; 6,142,379; 6,172,478; 6,176,428; 6,178,426; 6,186,400; 6,188,681;
6,209,788; 6,209,789; 6,216,951; 6,220,514; 6,243,447; 6,244,513; 6,247,647; 6,308,061;
6,250,551; 6,295,031; 6,308,061; 6,308,892; 6,321,990; 6,328,213; 6,330,244; 6,336,587;
6,340,114; 6,340,115; 6,340,119; 6,348,773; 6,380,949; 6,394,355; D305,885; D341,584;
D344,501; D359,483; D362,453; D363,700; D363,918; D370,478; D383,124; D391,250;
D405,077; D406,581; D414,171; D414,172; D418,500; D419,548; D423,468; D424,035;
D430,158; D430,159; D431,562; D436,104.
Invention No. 55,358; 62,539; 69,060; 69,187, NI-068564 (Taiwan); No. 1,601,796; 1,907,875;
1,955,269 (Japan); European Patent 367,299; 414,281; 367,300; 367,298; UK 2,072,832;
France 81/03938; Italy 1,138,713
rev. 06/02

Quick Reference

Introduction

The CycloneTM M2000 Series scanner combines the benefits of
multiple scan patterns (omni-directional, 2D raster, single scan­line and semi-omni directional scan pattern) with a light-weight,
hands-free/hand-held design. The scanner’s built-in stand
seamlessly accommodates both counter-top and hand-held use.
The scanner can be programmed to emit the preferred scan
pattern for both counter-top and hand-held use.

The following models are available:

• M2004-I200 (RS-232C) contains on-board discrete RS­232C communications for connecting to RS-232C asynchro­nous terminals and host systems. It also accommodates
Synapse™ Smart Cables which allow you to connect to a
wide variety of host systems.

• M2004-I290 (RS-232C with EAS) also supports Checkpoint
VII Electronic Article Surveillance (EAS).

• M2005-I200 (IBM 468X/469X) is fully compatible with the en­tire line of IBM 468X/469X terminals. It also accommodates
Synapse Smart Cables.

• M2005-I290 (IBM 468X/469X with EAS) provides additional
signal lines for EAS deactivation (Checkpoint VII).

• M2007-I200 (USB) supports USB connectivity. It also ac­commodates Synapse Smart Cables.

• M2007-I290 (USB with EAS) provides additional signal lines
for EAS deactivation (Checkpoint VII).

1

CycloneTM

M2000 Series

Setting Up your Scanner

1. Listen for click.

3. Connect power
supply (if necessary).

Interface Cable

2. Connect to host.

If you are using a Synapse cable, the scanner autodetects your
host. If you are using another cable, set the M2000 to
communicate with your particular POS host by scanning the
appropriate bar code(s) in the Cyclone

TM

M2000 Series Product

Reference Guide.

Power up the host. The green LEDs on top of the scanner flash 3
times while 3 power-up beeps sound, indicating the scanner is
operational.

2

Quick Reference

Removing the Interface Cable

Different cables are required for different hosts. To remove the
interface cable:

1. Unplug the cable’s modular connector by depressing the
connector clip through the access hole on the bottom of the
scanner with a screwdriver or paper clip.

Access Hole

2. Carefully slide out the cable.

Wall Mounting the Scanner

An optional wall-mount bracket is available for using the M2000 in
“scanning from above” applications. To wall-mount the M2000:

1. Place the bracket in its desired location on the wall, and
place a pencil mark on the wall through each keyhole in the
bracket.

2. Remove the bracket, and insert three #6 screws into the pen­cil marks on the wall. Do not tighten them all the way; leave
enough space for the bracket’s keyholes to slide onto.

3
