PRODUCT SPEC SHEET
SYMBOL DS4308-HC
PROTECT PATIENT HEALTH WITH NEXT GENERATION BAR CODE SCANNING
SYMBOL DS4308-HC
IMPROVE PATIENT SAFET Y AND INCREASE CAREGIVER PRODUCTIVIT Y WITH NEXT GENERATION SCANNING.
Bar code scanning at patient bedside is crucial in preventing medication and specimen mixups — two of the potentially deadliest
errors in a hospital. But scanning bar codes in a hospital can be a challenge. There are many types of bar codes including
traditional paper-based, those displayed on an electronic screen, codes printed on curved surfaces, high density codes printed
on very small items and bar codes in all types of conditions — from smudged to scratched and poorly printed. Now, you can give
your healthcare workers the ability to scan them all with the DS4308-HC. This feature-rich next generation 2D imager resets the
bar for scanning performance, scanning range, versatility and ease-of-use. The result? The priceless peace of mind that the right
patient received the right medication and the right test results, every time. The DS4308-HC — the ideal companion for laptops on
workstation-on-wheels (WOWs) and other types of car ts in your hospital.
PRZM Intelligent Imaging technology
for next generation performance
Resets the bar for 2D imaging by
improving decode performance and
snappiness, ensuring the virtually instant
capture of bar codes required in the
mission critical world of healthcare.
Megapixel sensor and advanced
algorithms enable first time capture
of any bar code, on any medium — in
virtually any condition
Give your healthcare workers true peace of
mind with the ability to scan virtually any
1D, 2D or PDF417 bar code, as well as the
many challenging bar codes in healthcare
— including the tiny dense codes wrapped
around the cur ved surface of a vial to bar
codes that are stained or smudged.
Largest “sweet spot” for can’t-miss
point-and-shoot scanning simplicity
A decode range allows healthcare workers
to scan any bar code type at any density
nearer and farther than any other scanners
in its class, making scanning truly second
nature. And with omni-directional scanning,
healthcare workers never need to waste
valuable time aligning bar code and scanner.
Withstands constant disinfecting
IP42 sealing and a specially designed
disinfectant-ready plastic housing allow
safe wipe-down with a wide variety
of harsh chemicals to help prevent the
spread of germs.
Unsurpassed aiming technology
The crisp and bright aiming dot has the
reach and brightness needed to ensure
the fast capture of data.
Durable design for superior uptime
Built to survive a 6 ft./1.83 m drop
to concrete, the DS4308-HC delivers
reliable operation, despite the inevitable
everyday drops.
Day and night ‘do-not-disturb’ modes
Healthcare workers can choose to mix
and match the decode feedback that is
right for the moment: visual (green light/
red light), haptic (vibration) and an
audible tone.
Superior out-of-box experience
The DS4308-HC is up and running almost
instantly. Smart auto-host detect cables
automatically determine which interface
is at tached, eliminating the need to scan
numerous configuration bar codes. Over
90 international keyboards are hosted
within the scanner for easy setup, all
around the world.
Easy on the eyes
Thanks to a special LED wavelength
and recessed lighting, when a bar code
is scanned, the light that is emitted is
soft and unobtrusive, preventing eye
fatigue and improving the environment for
patients and healthcare workers.
GIVE YOUR HEALTHCARE WORKERS THE POWER TO CAPTURE ANY BAR CODE, ON ANY
MEDIUM, IN ANY CONDITION — AND MAKE YOUR HOSPITAL A SAFER PLACE.
For more information, visit www.motorolasolutions.com/ds4308hc or access our
global contact directory at www.motorolasolutions.com/contactus
PAGE 1
PRODUCT SPEC SHEET
SYMBOL DS4308-HC
SPECIFICATIONS CHART
PHYSICAL CHARACTERISTICS
Dimensions 6.48 in. H x 3.86 in. L x 2.64 in. W
Weight (w/o cable) 5.71 oz. / 162 g
Power 5 VDC ± 10% @ 360 mA (RMS t ypical)
Inter faces
Suppor ted
PERFORMANCE CHARACTERISTICS
Light Source Aiming pattern: 617 nm LED
Imager Field of View 36° (H) x 22.5° (V)
Roll
Pitch
Yaw
Print Contrast 20% minimum reflective difference
Motion Tolerances Up to 30 in. / 76.2 cm per second
SYMBOLOGY DECODE CAPABILITY
1D UPC/EAN, UPC/EAN with supplementals,
2D PDF417, MicroPDF417, Composite Codes,
Postal Australian Post, US PLANET, Royal Mail 4
Minimum Resolution
USER ENVIRONMENT
Operating Temp. 32° F to 122° F/0° C to 50° C
Storage Temp. -40° F to 158° F/-40° C to 70° C
Humidit y 5% to 95%, non-condensing
Drop Specification Withstands multiple 6 f t./1.83 m
Ambient Light
Immunit y
16.5 cm H x 9.8 cm L x 6.7 cm W
USB, RS232, Keyboard Wedge, RS485
(IBM 46x x) , SSI
The scanner supports the following
protocols over USB: HID Keyboard
(default mode), SNAPI, IBM SurePOS
(Yellowstone) (IBM Handheld, IBM
Tabletop, OPOS), USB CDC, SSI over
USB CDC, Toshiba TEC
The scanner support s the following
protocols over RS 232: Standard, Wincor
Nixdor f, ICL, Fujit su, Olivet ti, Omron
and CUTE
Illumination: 660 nm LEDs
0 - 360°
± 65° or greater
± 60° or greater
Bookland EAN, ISSN, UCC Coupon
Extended Code, Code 128, GS1-128, ISBT
128, Code 39, Code 39 Full ASCII, Trioptic
Code 39, Code 32, Code 93, Code 11, Matrix
2 of 5, Interleaved 2 of 5, Discrete 2 of 5,
Codabar, MSI, Chinese 2 of 5, GS1 DataBar
variants, Korean 3 of 5, ISBT Concat
TLC-39, Data Matrix, Maxicode, QR Code,
MicroQR, Az tec, Han Xin
State Customer, US POSTNET, KIX Code
(Dutch), UK Postal, Japan Post, UPU 4
State Postal FICS (Post US4), USPS 4 State
Postal (Post US3), Canadian Post (Postbar)
SR: Code 39 4 mil, UPC 60% 7.8 mil,
PDF417 5 mil, Datamatrix 7.5 mil
HD: Code 39 3 mil, UPC 60% 7.8 mil,
PDF417 4 mil, Datamatrix 5 mil
drops to concrete
Immune to normal indoor lighting up to 1600
Lux; immune to sunlight up to 86,000 Lux
ACCESSORIES
Hands-Free Options Gooseneck Intellistand
Power Supplies Power supplies are available for
applications that do not supply power
over the host cable
REGULATORY
Electrical Safety UL60950-1 2nd ed, CSA C22.2 No. 60950-1
LED Safety IEC 62471:2006 and EN 62471:2008
EMI/RFI FCC Part 15 Class B, ICES-003 Class B,
Environment al Compliant with RoHS directive 2011/65/EU
2nd ed, EN60950-1/IEC60950-1 2nd ed.
EN55022 Class B, EN55024, Medical
Electrical Equipment: EN60601-1-2
WARRANTY
Subject to the terms of Motorola’s hardware warranty statement,
the DS4308-HC is warranted against defects in workmanship and
materials for a period of 5 years from the date of shipment. For the
complete Motorola hardware product warranty statement, go to:
http://www.motorolasolutions.com/warranty
RECOMMENDED SERVICES
Enjoy easy access to fast repair and expert suppor t with Service
from the Star t; add “next business day” replacement with
Advanced Exchange.
DECODE RANGES
SR FOCUS RANGE
Bar Code
Type
Code 39 3.0 mil 1.5 in. / 3.8 cm 5.4 in / 13.7 cm
Code 39 5.0 mil 0 in. / 0 cm 11.0 in / 27.9 cm
PDF417 6.6 mil 1.1 in. / 2.8 cm 8.0 in / 20.3 cm
UPC 13.0 mil 0 in. / 0 cm 28.0 in / 71.1 cm
Data Matrix 10.0 mil 2.0 in / 5.1 cm 9.0 in / 22.9 cm
Code 39 20.0 mil 0 in / 0 cm 53.0 in / 134.6 cm
QR 10.0 mil 1.1 in./2.8 cm 8.5 in./21.6 cm
QR 20.0 mil 0.9 in./2.3 cm 16.2 in./41.1 cm
Symbol
Densit y
TYPICAL WORKING RANGES
Near Far
HD FOCUS RANGE
Bar Code
Type
Code 128 3.0 mil 1.0 in / 2.5 cm 3.0 in / 7.6 cm
Code 39 3.0 mil 0.5 in / 1.3 cm 5.8 in / 14.6 cm
Code 39 5.0 mil 0.0 in / 0.0 cm 10.0 in / 25.4 cm
Micro PDF 4 mil 1.0 in /2.5 cm 4.7 in / 11.9 cm
PDF417 6.6 mil 0.2 in / 0.5 cm 7.8 in / 19.7 cm
UPC 13 mil 0 in / 0 cm 16.5 in / 41.9 cm
DataMatrix 5 mil 1.2 in / 3.0 cm 3.5 in / 8.9 cm
DataMatrix 7.5 mil 1.0 in / 2.5 cm 6.5 in / 16.5 cm
DataMatrix 10.0 mil 0.8 in / 1.9 cm 8.2 in / 20.8 cm
Code 39 20.0 mil 0 in / 0 cm 30.0 in / 76.2 cm
QR 10.0 mil 0 in / 0 cm 7.0 in / 17.8 cm
QR 20.0 mil 0.5 in / 1.3 cm 11.0 in / 27.9 cm
Symbol
Densit y
TYPICAL WORKING RANGES
Near Far
THE DS4308-HC
IDEAL FOR...
• Medication administration
• Blood product administration
• Specimen tracking
• Medication tracking in
the pharmacy and on the
pharmacy cart
• Electronic healthcare
record access
• Patient identification
COMPLIMENTARY
MANAGEMENT TOOLS
Simplify and reduce the cost of
everyday management with our nocost tools. 123Scan
Management Ser vice (SMS)
work hand-in-hand to reduce
management time and cost by
automating initial configuration
and enabling remote management
of your DS4308-HC scanners.
123Scan2
Programs scanner parameters,
upgrades firmware, provides scanned
bar code data and prints reports.
www.motorolasolutions.com/123Scan
Scanner Management
Service (SMS)
Remotely manages your Motorola
scanner and queries its asset
information.
www.motorolasolutions.com/sms
Scanner SDK
Generates a fully-featured scanner
application, including documentation,
drivers, test utilities and sample
source code.
www.motorolasolutions.com/windowsSDK
2
and Scanner
