Introduction

The AP 300 Access Port, a component of the Symbol Wireless Switch
System, links wireless 802.11a/b/g devices to the switch, enabling
incremental growth of your wireless network with a cost-effective
alternative to standard access points. For optimal performance, the AP
300 provides two placement options: wall and ceiling. Wall mount slots
fit onto two screws provided; marks on the AP 300 case guide placement
of the screws. Clips on the back of the case fit onto a suspended ceiling
T-bar.

The AP 300 receives all power and transfers data through the same
CAT-5 cable without any strain relief. There is no additional power
supply.

Technical Specifications

Dimensions & Weight

Operating Voltage 48VDC typical; 36-57VDC

range

Power Over Ethernet

Operating Current 10mA to 165mA
Peak Current 250mA
Operating

Temperature

-20°C to 50°C (-4°F to 122°F)

Operating Humidity 5% to 95% non-condensing
Storage Temperature -40°C to 70°C (-40°F to

158°F)
Storage Humidity 85%
Altitude 2438m (8,000ft.) maximum operating

4572m (15,000ft.) maximum storage
Drop 91cm (36in.) to concrete Without antenna modules
Electrostatic

Discharge

+/-15kV air; +/-8kV contact;

+/-2kV pin

Length 21.1cm (8.31in)
Width 17.1cm (6.74in.)
Height 5.1cm (2.0in.)
Weight 0.45kg (1.0lbs)

2

AP 300 Quick Reference Guide FINAL.Not for distribution.

Radio Characteristics

The AP 300 is an IEEE 802.11a/b/g-compliant device with the
appropriate radio option configured. The table below shows the
characteristics for each device compliance.

Package Contents

The AP 300 package contains the following items:

• AP 300 Access Port

• Two wide-shoulder screws

Device Mbps Data Rate

Support

Utilizing

Diversity

GHz

802.11a 6, 9, 12, 18, 24, 36, 48,

and 54

Transmit and

receive 4.9 to 5.875 range

802.11g* 1.0, 2.0, 5.5, 6, 9, 12, 18,

24, 36, 48, and 54

Transmit and

receive

2.4 to 2.5 ISM range

*The supported 802.11g modes include either CCK only or OFDM only.

3

FINAL.Not for distribution.

Description

The AP 300 has two radios capable of concurrent 802.11a/b/g radio
configurations. The AP 300 takes power from any 802.3af-compatible
Power Over Ethernet (PoE) switch or power injector.

Features

• One RJ-45 connector

• LED indicators

• Point for a safety cable loop

• Kensington© Lock Port

• Slots for wall mounting

• Clips for ceiling T-bar mounting

The AP 300 has one RJ-45 connector for a 10/100 Ethernet port
connecting to a wireless switch with a standard CAT-5 cable, straight
through or cross-over, without any strain relief.

Top View

LEDs

Mount Slot

Bottom View

Mount Slot

Lock Port

T-bar Mount

RJ-45

Safety Cable
Tie Point

Alignment Arrows

T-bar Mount

Safety Cable Tie Point

RJ-45 Connector

Lock Port
