Sylvania SY4100 User Manual
OWNER’S
MANUAL
BEFORE INSTALLING OR
OPERATING THE SYSTEM,
PLEASE READ THIS MANUAL,
SY4100
WIRELESS HOME
SECURITY SYSTEM
INSTALLATION AND OPERATION
MODEL:
Table of Contents
3
Introduction…………………………………………………………………………….…...
System Package…………………………………………………………….….
Optional Accessories…………………………………………………………...
Planning for Installation
Choosing a Location………………………………………………………..…...
Setting Alarm Zones………………………………………………………….....
Installing the Back-up Battery……………………………………………….....
Powering the Main Console…………………………………………………….
Connecting the Telephone Line……………………………………………...…
Setting the Antenna………………………………………………………….….
Mounting the Main Console…………………………………………………..…
About Passwords…..………………………………………………………….....
Others………………………………………………………………………….….
Operation – Main Console……………………………………………………………….…
LCD Panel Illustration…………………………………………………………...
Function for Installer Menu…………………………………….……………….
System Option Menu…………………………………………………….………
Sequence Programming Menu…………………………………………………
Replacement Menu………………………………………………………………
Clear Menu……………………………………………………………………….
Function for Master Menu……………………………..…………….………….
Check Function…………………………………………………………………..
Speed Dial Function……………………………………………………………..
Arm or Disarm via the Telephone Line………………………………………..
Auto Dialer Priority………………………………………………………………
LCD Messages…………………………………………………………………..
24 Hour, Home & Away Functions……………………………………………………….
Remote Control Handset…………………………………………………………….…….
PIR Motion Detector………………………………………………………………………..
Door/Window Detector…………………………………………………………………….
Mini Siren……………………………………………………………………………………
Summary of Program – Main Console…………………………………………………..
Summary of Sensors and Zone Settings………………………………………………..
Specifications………………………………………………………………………………
Installation Template………………………………………………………………………
Table of Contents
3
3
4
4
4
4
5
5
5
5
5
6
6
7
8
10
11
11
12
13
13
14
14
15
15
16
17
19
22
23
24
25
26
1
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHO
CK, DO NOT
IMPORTANT NOTE: IF YOU RETURN TO YOUR PREMISES AND FIND THAT
Important Safety Instructions
EXPOSE THIS APPLIANCE OR POWER ADAPTER TO WATER OR MOISTURE
• Read Instructions – All the safety and operating instructions should be read before
operating this equipment. These instructions should be retained for future reference
• Heed Warnings – All warnings on the equipment and in the operating instructions
should be adhered to. All instructions regarding care and operation of this
equipment should be followed.
• Pow er Sources – Equipment should only be connected to the power supply
specified in the operating instructions or as marked on the equipment.
• Grounding or Polarization – Take precautions that the equipment is properly
grounded. Take note that the power supply is fitted in the correct input jack (
marked DC 12V ), and auxiliary units ( external siren and strobe light ) are fitted into
the correct external jack points.
• Power-Cord Protection – Keep cable cords and plugs clear of other objects,
particularly at the point where they exit the equipment.
• Cleaning – Clean the equipment by wiping with a soft cloth, ( do not use any
abrasive agents or water ).
• Non-use Periods – Power cords should be unplugged from the outlet when left
unused for a long period of time.
• Object and Liquid Entry – Take care not to drop objects or liquids on any part of
the equipment.
• Damage Requiring Service – The alarm should be serviced by a qualified service
personnel when:
• Servicing – Do not attempt to service the appliance beyond that described in the
• System Maintenance – Under normal use your system requires virtually no
- The power-supply cord or the plug has been damaged, or
- Objects have fallen, or liquid has been spilled onto the equipment, or
- The equipment has been exposed to rain, or
- The equipment does not appear to operate normally or exhibits a marked
change in performance, or
- The equipment has been dropped, and/or the enclosure has been
damaged.
operating instructions. All other servicing should be referred to a Qualified
Distributor’s Service Personnel.
maintenance other than regular testing. It is recommended that you test your
system once a week, and replace the batteries at least once every 6 months (or as
needed).
THE ALARM IS IN PROGRESS, DO NOT ENTER, AS A FIRE OR AN INTRUDER
MAY BE PRESENT. GO TO A NEIGHBOR AND CONTACT THE RELEVANT
LOCAL AUTHORITIES FROM THERE.
2
MD 410
Introduction
Thank you for choosing the Sylvania® SY4100 Wireless Home Security System. These
security systems are high-quality, reliable and versatile. This system has a built in Autodialer for increased security. To ensure the best performance of your system, please
read this manual thoroughly and follow the precautions and instructions presented.
These systems are designed to be simple and easy to install and maintain.
Wireless easy to use : No messy and expensive wiring is required to install the
Expandability : You can add different types of accessories to the system to
Flexibility : You can choose the type of sensors and response actions for
Personalized : Program the system to notify whoever you choose in the case
System Package
Main Console
Remote Control (KT 410)
PIR Motion Detector (MD 410)
Door/Window Sensor (DT 410)
Wired Mini Siren
Optional Accessories
SD 410 Smoke Detector SS 410 Wired Outside Siren with Strobe Light
DT 410 Door/Window Detector (9V) BP 410 Rechargeable Battery (for SY 4100)
GD 410 Gas Detector
KT 410 Key- chain Remote Control
system.
create a more complex system as your future needs may
require.
the system.
of an alarm activation.
X 1
X 1
X 1
X 1
X 1
PIR Motion Detector
3
00
HOME
SECURITY
Welcome
Planning for Installation
The security system is designed to be as flexible as possible in order to meet your
present needs, and also to adapt as your needs change. For the reason, we recommend
that you read and consider the following information and plan your system before
installing these devices.
Choosing Location
It is important to try and place the Main Console in an area central to the alarm sensors.
This way, all of the sensors can transmit signals with maximum efficiency. The Main
Console must be placed near a power outlet and telephone jack.
Setting Alarm Zones
Before installation, you should have the sensors programmed on the Main Console via
the systems learning mode on the Main Console. This system allows you to install a
maximum of 63 wireless sensors.
Installing the Back-up Battery-Optional Accessory(Not included)
1. Remove the battery cover at the back of the Main Console
2. Locate the connector plug and connect the rechargeable back-up battery (BP 410) to
this connector
3. Re-install the battery cover
Powering the Main Console
1. Attach the end of the adapter into the connector provided at the top of the console.
2. Plug the AC adaptor into the power outlet.
3. When the power is installed on the main console you will see the LCD (shown below)
Disarmed
4
Connecting the Telephone Line
To connect the Main Console to the telephone line, Please follow these steps:
1. Locate the two phone jacks at the top of the main console. These phone jacks are
marked “ Phone “ and “ Line “.
2. Connect one end of the telephone cord that came with the system into the
connector, labeled” Line”. Connect the other end of that cord into the wall jack.
3. Connect a telephone to the Main Console through the phone jack.
Note: The system will only work with “Touch Tone” service
Setting the Antenna
Carefully extend the antenna upward in order to maximize the range of communication
between the sensors and the Main console. Remember, that the maximum distance from
an sensor back to the main console is 100 ft
Mounting the Main Console
The Main Console may be set on a table top, or mounted on a wall. To mount the
console on a wall, follow these steps.
1. Remove the two top black rubber pads and store them away for future use.
2. Measure and fix screws into the wall so that the two screws fit into the grooves left
under the removed pads. (You may use the Installation Template on the last page
of this Manual)
3. Connect all wire connections to the jacks at the top of the console
4. Set the console onto the screws and carefully allow the console to drop into the
groove securely.
About Passwords
This system provides two sets of password for setting the system. ”Install ”, ”Master ”
”Install ” : You can use this password to set the system, such as telephone numbers
or record message…etc
”Master ” : This password is used for setting “ Arm”( Arm away or Arm home),
“Disarming” the system….etc
When the system installation is finished, family members will only need to “ Arm” or
“Disarm” the system.
Others
We recommend that you install the console after programming the other wireless devices
(sensors) into the main console. This is to ensure that all of the wireless devices are
working together properly.
5
1. Numeric keys and
Operation – Main Console
The Main Console is the heart of the security system. It monitors the sensors and
responds according to how it is programmed, whenever a sensor is activated. The
illustration shown for the Main Console may look complex at first, however, most
procedures are straightforward and easy. Please review the illustration below, which
labels all the parts of the Main Console.
LCD Panel Illustration
1 2 3
4
5 6
7 8 9
0
#
MICROPROCESSOR CONTROL KEYPAD
LEGEND
1 . NUMERIC AND #, BUTTONS
2 . BURGLARY BUTTON
3 . FIRE BUTTON
4 . MEDICAL EMERGENCY BUTTON
5 . SP DIAL BUTTON
6 . CHECK BUTTON
7 . CANCEL BUTTON
8 . ENTER BUTTON
9 . AWAY BUTTON 17 . OUTPUT TERMINAL JACKS
11 . MIC
12 . POWER LED INDICATOR
13 . ARMED LED INDICATOR
14 . LCD PANEL
15 . SPEAKER
16 . ANTENNA
18 . TELEPHONE JACKS10 . HOME BUTTON
19 . TEL LINE JACK
20 . DC POWER JACK
# keys
2. Burglary Button : Press the SP DIAL & Burglary Buttons together
3. Fire Button : Press the SP DIAL & Fire Buttons together
4. Medical
Emergency
5. SP DIAL button : Press the SP DIAL button together with 4, 5 or 6 to activate
6. Check : Press the CHECK button to review sensor settings and to check
7. Cancel : Press the CANCEL button to go back to the previous menu or to
8. Enter : Press ENTER to confirm program entry.
9. Away : Key-in the “ Master ” code, then press the AWAY button to arm
10. Home : Key-in the “ Master ” code then press the HOME button to arm the
11. Mic
12. Power LED : Indicates whether the AC Adaptor power is on or off.
: For telephone setting include the pound and star keys.
: Press the SP DIAL & Fire Buttons together
one of the 3-emergency dialing numbers
recorded message.
delete the M essage
the system in the away mode
system in the home mode
and for two way communication voice
input.
6
13. Armed LED : W
hen the light is ‘on’, the system is armed; When the light is ‘off’,
SYS_OPTS:
0-
SYS_OPTS
Access Granted
Home Security
14. LCD Panel : Displays messages
15. Speaker : Sounds alarm and plays back messages
16. Antenna : Used for wireless reception
17. Output Jack : Connects to the external siren
18. Phone Jack : Connects to the phone set
19. Line Jack : Connect to the Telephone line from the wall
20. DC Power Jack : DC supply input
the system is disarmed.
3.0: Function for Installer Menu – Factory Default Password :123456
1. E nter the password to start the menu setting as shown below
(i) An incorrect password entered will show “ Access Denied” and will emit a beep
sound warning.
(ii) If 3 incorrect passwords are entered, the keyboard will become disabled and
locked (LCD shown below). Try it again after one minute or use the Remote
Control Handset ( DISARM button) to unlock the system.
Note: The remote control handset can be used to unlock the system,
however, if It is not programmed into the system, it can not be used
to unlock the system. Please make sure to enter the correct password
when the system is turned “ON” for the first time.
(iii) If 9 incorrect passwords are entered, and 3 consecutive “Keyboard Lock” occurs,
then the system will trigger the alarm for a set duration and will be
locked/disabled. The LCD will display as shown below. The dialer will not dial out
any of the phone numbers programmed. The disarm button on the remote control
handset can be used to disarm/unlock the system.
2. If the password is correct (default 123456), the system will emit a beeping sound
and the LCD panel will look like this (shown below).
3. Select the System Menu Number
Code : ******
Access Denied
Keyboard Locked
System Lock
Install Mode
1 – SEQ 2 – REPLAC 3 - CLR
7
Setting : 0
–
T 1 2 3 4 5 6
– P
CODE
Setting : Time 1
-
Exit
Setting : Time
Setting :
Time
Setting : Time
Setting : Phone Num : 1
3.1: System Option menu : Press 0 to start setting
(1) 0-T : For time setting (Default is 30 seconds.) minimum 1 second, maximum
255 seconds.
Press the 0 button, to go to the time setting (exit, alarm, entry) time
Press the 1 button, to set the delay time for exiting the house. The default time is
30 Sec, You can set the time from 1 to 255 Sec. Press the Enter button to finish the
setting.
Press 2 button, setting alarm time for triggering alarm, The default time is 30
Sec, you can set the time from 1 to 255 Sec. Press Enter button to finish the
setting.
Press 3 button, setting delay time for entering house, The default time is 30
Seconds. You can set the time from 1 to 255 Sec. Press Enter button to finish
the setting.
(2) 123456-P Numeric key : To set the telephone number (you can program up to 6
telephone numbers, each one being up to 20 digits
each)
E xample: Press the 1 Button, the LCD panel will appear as shown below.
Enter the phone number, then press the ENTER button to program.
Press the 2 button to program Phone number 2………
Setting 1 , 2 or 3 : For neighbors, relatives, friends and family
Setting 4 : The first priority dial in case of Burglary. (check
7 – MSG 8 – DIAL 9 -
2 – Alarm 3 - Entry
1 – Exit : 30 Sec
2 – Alarm : 30 Sec
3 – Entry : 30 Sec
********************
members to notify in case of emergencies.
with the police dept. if this is acceptable)
8
Loading...
