Sylvania CDVL100D User Manual

OWNER’S
MANUAL

If you need additional assistance for set-up or operating
after reading owner’s manual, please call

TOLL FREE : 1-800-287-4871

Please read before using this equipment.

DVD PLAYER

PORTABLE CART WARNING
(Symbol provided by RETAC)

S3125A

CDVL100D

WARNING

:

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

:

IMPORTANT SAFEGUARDS

1) Read Instructions - All the safety and operating instructions
should be read before the product is operated.

2) Retain Instructions - The safety and operating instructions
should be retained for future reference.

3) Heed Warnings - All warnings on the product and in the oper­ating instructions should be adhered to.

4) Follow Instructions - All operating and use instructions should
be followed.

5) Cleaning - Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.

6) Attachments - Do not use attachments not recommended by
the product manufacturer as they may cause hazards.

7) Water and Moisture - Do not use this product near water - for
example, near a bath tub, wash bowl, kitchen sink, or laundry
tub; in a wet basement; or near a swimming pool; and the like.

8) Accessories - Do not place this product on an unstable cart,
stand, tripod, bracket, or table. The product may fall, causing
serious injury to a child or adult, and serious damage to the
product. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the product.
Any mounting of the product should follow the manufacturer’s
instructions, and should use a mounting accessory recom­mended by the manufacturer.

9) A product and cart combination should be
moved with care. Quick stops, excessive
force, and uneven surfaces may cause the
product and cart combination to overturn.

10)Ventilation - Slots and openings in the cabi­net are provided for ventilation and to
ensure reliable operation of the product and
to protect it from overheating, and these
openings must not be blocked or covered.
The openings should never be blocked by placing the product
on a bed, sofa, rug, or other similar surface. This product
should not be placed in a built-in installation such as a book­case or rack unless proper ventilation is provided or the manu­facturer's instructions have been adhered to.

11)

Power Sources - This product should be operated only from the type
of power source indicated on the marking label. If you are not sure
of the type of power supply to your home, consult your product deal­er or local power company. For products intended to operate from
battery power, or other sources, refer to the operating instructions.

12)

Grounding or Polarization - This product may be equipped with
a polarized alternating-current line plug (a plug having one blade
wider than the other). This plug will fit into the power outlet only
one way. This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the plug should
still fail to fit, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the polarized plug.

13)

Power-Cord Protection - Power-supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon

The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.

The exclamation point within an equilateral trian­gle is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.

or against them, paying particular attention to cords at plugs, conve­nience receptacles, and the point where they exit from the product.

14)Lightning - For added protection for this product during a light­ning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect
the antenna or cable system. This will prevent damage to the
product due to lightning and power-line surges.

15)Power lines - An outside antenna system should not be locat­ed in the vicinity of overhead power lines or other electric light
or power circuits, or where it can fall into such power lines or
circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching such power lines
or circuits as contact with them might be fatal.

16)Overloading - Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in a risk of
fire or electric shock.

17)Object and Liquid Entry - Never push objects of any kind into
this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.

18)

Servicing - Do not attempt to service this product yourself as
opening or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service personnel.

19)Damage Requiring Service - Unplug this product from the wall
outlet and refer servicing to qualified service personnel under
the following conditions:
a) When the power-supply cord or plug is damaged,
b)

If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the

operating instructions. Adjust only those controls that are

covered by the operating instructions as an improper adjust-

ment of other controls may result in damage and will often

require extensive work by a qualified technician to restore

the product to its normal operation,
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance

- this indicates a need for service.

20)Replacement Parts - When replacement parts are required, be
sure the service technician has used replacement parts speci­fied by the manufacturer or have the same characteristics as
the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.

21)

Safety Check - Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.

22)Heat - The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

PRECAUTIONS

LASER SAFETY

This player employs a laser. Only a qualified service person should remove the cover or attempt to service this
device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER

THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO

NOT STARE INTO BEAM.

LOCATION: INSIDE, ON THE DECK MECHANISM.

FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifica­tions to this equipment may cause harmful interference unless the modifications are expressly
approved in the instruction manual.The user could lose the authority to operate this equipment if an
unauthorized change or modification is made.

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in
accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regula­tions concerning chemical wastes.

About Copyright

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.
This product incorporates copyright protection technology that is protected by method claims of certain U.S.
patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of
this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home
and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineer­ing or disassembly is prohibited.

–2–

EN

TABLE OF CONTENTS

■

PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

LASER SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

About Copyright. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

■

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Supplied Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Symbols Used in this Manual. . . . . . . . . . . . . . . . . . . . . 4

■

ABOUT THE DISCS . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Playable Discs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Disc Types. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

■

FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

■

FUNCTIONAL OVERVIEW . . . . . . . . . . . . . . . . . . . . . . 6

FRONT PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

REAR VIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . 6

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Displays During Operation . . . . . . . . . . . . . . . . . . . . . . . 7

Loading the Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . 7

■

HOOK UPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Connecting to a TV using a VIDEO OUT Jack

or a S-VIDEO OUT Jack . . . . . . . . . . . . . . . . . . . . . . . . 7

Connecting to an Amplifier Equipped with Digital Input

Jacks such as MD deck or DAT deck . . . . . . . . . . . . . . . 8

Connecting to a Dolby Digital decoder . . . . . . . . . . . . . . 8

Connecting to a TV or a Stereo TV that has Component

VIDEO In Jacks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

■

PLAYING A DISC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Basic Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

General Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Disc Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Title Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

CALLING UP A MENU SCREEN DURING

PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Step by Step Playback. . . . . . . . . . . . . . . . . . . . . . . . . . 9

Resume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Fast Forward / Reverse Search . . . . . . . . . . . . . . . . . . 10

Slow Forward / Slow Reverse . . . . . . . . . . . . . . . . . . . 10

Zoom. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Track . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Title / Chapter Search . . . . . . . . . . . . . . . . . . . . . . . . . 10

Time Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Repeat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

REPEAT TITLE / CHAPTER. . . . . . . . . . . . . . . . . . . 10

REPEAT TRACK . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

REPEAT A-B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Program (CD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Random Playback (CD) . . . . . . . . . . . . . . . . . . . . . . . . 11

MP3 Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

On-Screen Information. . . . . . . . . . . . . . . . . . . . . . . . . 11

Track Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Random Playback (MP3) . . . . . . . . . . . . . . . . . . . . . . . 12

Programm (MP3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Audio Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Stereo Sound Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Subtitle Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Camera Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Changing the On-Screen Display . . . . . . . . . . . . . . . . . 12

Parental Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

PARENTAL LEVEL . . . . . . . . . . . . . . . . . . . . . . . . . . 13

IF YOU FORGET THE PASSWORD . . . . . . . . . . . . . 13

CONTROL LEVELS . . . . . . . . . . . . . . . . . . . . . . . . . 13

Marker Setup Screen. . . . . . . . . . . . . . . . . . . . . . . . . . 13

■

DVD SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Audio Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Black Level Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Virtual Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Display Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Language Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

■

TROUBLESHOOTING GUIDE. . . . . . . . . . . . . . . . . . . 15

■

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

■

MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

–3–

EN

INTRODUCTION

1

Supplied Accessories Symbols Used in this Manual

• Remote control

• Two AA batteries

• Owner’s Manual

• VIDEO/AUDIO cables

Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of
Dolby Laboratories.

The following symbols appear below in some headings and
notes in this manual, with the following meanings!

DVD-V

: Description refers to playback of DVD video discs.

CD

: Description refers to playback of audio CDs.

MP3

: Description refers to playback of MP3 discs.

QUICK

: Description refers to the items to be set in the QUICK

mode.

ABOUT THE DISCS

Playable Discs

The following discs can be played back on this DVD player.

¡

DVD video

¡

DVD+R/RW*

¡

CD-R/RW*

*Depending on the types or the writing method of the medium some discs can not be played.

• Some DVD-R/RW, DVD+R/RW, or CD-R/RW discs made on personal computers, or on DVD recorders may not be played
back properly due to the factors such as scratches, dirt or special properties of the disc.

• Discs made on personal computers may not be played back properly due to the different environment or the settings of the
application you use. We recommend always to use the standardized, rightly formatted discs. (Please contact the sales
agency for more detail).

This player conforms to the NTSC color system.You cannot play discs recorded in other color systems such as PAL or SECAM.

• Some discs include region codes as shown below.

¡

DVD-R/RW*

¡

Audio CD

¡

MP3*

• The number inside the symbol refers to a region of the world, and a disc encoded in a specific region format can only be
played back on DVD player with the same region code.

For Customer Use:
Read carefully the information located at the bottom of your DVD player and enter below the Serial No.Retain this informa­tion for future reference.
Model No. DVD player
Serial No. __________________________

The following discs cannot be played back on this DVD player.

¡

DVD with region codes other than 1 or ALL.

¡

DVD-ROM

¡

DVD-RAM (Never play back, otherwise malfunction may result.)

¡

CD-ROM

¡

VSD

¡

CDV (Only plays back the audio part.)

¡

CD-G (Only plays back the sound.)

¡

CD-I (Never play back, otherwise malfunction may result.)

¡

SACD

¡

Photo CD (Never play back, otherwise malfunction may result.)

¡

Video CD (Never play back, otherwise malfunction may result.)

Any other discs without compatibility indications.

–4–

EN

ABOUT THE DISCS

Example

Track 1 Track 2 Track 3 Track 4 Track 5 Track 6

Example

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1 Chapter 2Chapter 3 Chapter 4

Example

Group 1 Group 2

Track 1 Track 2 Track 1 Track 2Track 3 Track 4

Disc Types

[DVD]

Data on a DVD is divided into sections called "titles", and then
into subsections called "chapters", each of which is given a title
or chapter number. Playback conditions are preset on some
DVD video discs, and these playback conditions take priority
over user operations on this player. If a function you selected do
not run as desired, refer to the manual accompanying the disc.

[Audio CD]

Data on an audio CD is divided into sections called “tracks”,
each of which is given a track number.

[MP3]

Data on a MP3 is divided into sections called "groups", and
then into subsections called "tracks", each of which is given
a group or track number.

FEATURES

¡Dolby Digital sound

This player can handle Dolby Digital surround sound hav­ing 5.1 channels when connected to a Dolby Digital
decoder.

¡Still/fast/slow/step playback
¡Random playback for audio CD and MP3
¡Program playback for audio CD and MP3
¡DVD menus in a desired language
¡Screen saver/Auto power-off functions

The screen saver program starts when there is no input from
the player for five minutes in the stop mode. When the
screen saver program is activated for 30 minutes, the power
is automatically turned off.

¡Subtitles in a desired language
¡Selecting a camera angle
¡Choices for audio language and sound mode
¡Parental lock
¡Automatic detection of discs

This player automatically detects if a loaded disc is DVD,
audio CD or MP3 on disc.

¡Playing an MP3 disc
¡Direct Search
¡On-screen display

Information about the current operation can be displayed
on a TV screen, allowing you to confirm the currently
active functions (such as program playback), on the TV
screen using the remote control.

¡Search

Chapter search / Title search / Track search / Time search

¡Repeat

Chapter / Title / Track / Group / All / A-B

¡Zoom
¡Marker

The part designated by user can be called back.

¡Resume Play
¡Virtual Surround
¡Component Video Out Jacks

Jacks located on the back of the DVD Player which are
used to send high-quality video to a TV via Component
Video In Jacks.

¡Dimmer
¡Bit rate indication
¡DRC (Dynamic range control)

You can control the range of sound volume.

¡Black Level Setting

–5–

EN

AUDIO OUT

DIGITAL AUDIO OUT
PCM / BITSTREAM

YCr

COMPONENT

VIDEO OUT

CbLRCOAXIAL

VIDEO

OUT

S-VIDEO OUT

10

111213 15

14

RETURN

ZOOM

MODE

MENU

SKIPPAUSEA-B

REPEAT

ANGLE

AUDIO

SUB

TITLE

CLEAR

TITLE

STOP

PLAY

FWDREV

SETUP

ENTER

OPEN/
CLOSE

SEARCH

MODE

DISPLAY

123

456

789

0 +10

POWER

1

2
3

4

5
6
7

8

9
10
11

14

12
13

15

18

19

17
16

21
20

22

23

24

25

FUNCTIONAL OVERVIEW

FRONT PANEL

2 435

REAR VIEW

1. POWER

to switch the player to ON or OFF

2. Disc tray

3. OPEN/CLOSE

to open/close the disc tray

4. PLAY

to start or resume disc playback

5. STOP

to stop playback

6. SKIP G / SEARCH

gg

goes to next chapter or track during playback; press and
hold for 1.5 seconds for a forward search

7. SKIP H / SEARCH

hh

goes to previous chapter or track during playback; press
and hold for 1.5 seconds for a reverse search

8. PAUSE

to pause the current disc operation

9. Display

REMOTE CONTROL

1. DISPLAY

to access or remove the display screen during DVD or
Audio CD playback

2. POWER

switch DVD player ON or OFF

3. AUDIO

to choose audio languages or sound modes

4. SUBTITLE

subtitle language DVD selector

5. ANGLE

6. REPEAT

7. REPEAT A-B

8. CLEAR

select DVD camera angle

repeat chapter, track, title, all.

repeat a specific segment

to reset the setting

[Fig. 3]

19 87 6

10. MAIN (AC Power Cord)

connect to a standard AC outlet

11. COAXIAL (Digital audio out)

connect to AUDIO inputs of a digital (coaxial) audio
equipment

12. AUDIO OUT (Left/Right)

connect to AUDIO inputs of an amplifier, receiver or
stereo system

13. VIDEO OUT

connect to the Video Input of a TV.

14. COMPONENT VIDEO OUT

connect to a TV with Component video in jacks.

15. S-VIDEO OUT

connect to a TV with S-Video inputs

Caution: Do not touch the inner pins of the jacks on the
rear panel. Electrostatic discharge may cause permanent
damage to the player.

9. PAUSE

pause playback temporarily / frame-by-frame playback

10. REV

hh

to view DVD picture in fast reverse motion

11. PLAY

to start a DVD disc playback

12. SETUP

to access or remove the DVD setup menu

13. MODE

to set up programmed or random playback (Audio CD)
to set the black level and virtual surround during DVD
playback

14. ZOOM

enlarge DVD video image

15. TITLE

to display title menu of a disc

16. ENTER

acknowledge menu selection

17. RETURN

to return previous or remove setup menu

18. Arrow (sB

KK LL

)

(left/right/up/down) select an item in the menu

19. MENU

to display the menu of the DVD disc

20. STOP

to stop a DVD disc playback

21. FWD

gg

to view DVD picture in fast forward motion

22. SKIP H,G

to skip chapter/tracks

23. 0-9 numerical buttons

select numbered items in a menu

+10

use this button to enter number 10 and above

24. OPEN/CLOSE

to open/close the disc tray

25. SEARCH MODE

to locate a desired point

–

6 –

[Fig. 1]

[Fig. 2]

EN
