Sylvania 6900DTD User Manual
ATSC/NTSC STB
As an ENERGY STAR
®
Partner, our company has determined
that this product meets the E
NERGY
STAR® guidelines for energy efficiency.
E
NERGY STAR
®
is a U.S. registered mark.
OWNER S
MANUAL
If you need additional assistance for set-up or operating
after reading owner’s manual, please call
TOLL FREE : 1-800-968-3429
Please read before using this equipment.
6900DTD
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
Table of Contents
1 Before Using . . . . . . . . . . . . . . . . . 3
Important Safeguards. . . . . . . . . . . . . . . 3
Precautions . . . . . . . . . . . . . . . . . . . . . . 5
Information on digital broadcasting . . . . 6
Major features of STB . . . . . . . . . . . . . . 7
Location of controls. . . . . . . . . . . . . . . . 8
Accessories . . . . . . . . . . . . . . . . . . . . . . 11
Installing batteries . . . . . . . . . . . . . . . . . 11
Reference to SETUP menu . . . . . . . . . . 12
2 Connections. . . . . . . . . . . . . . . . . . 16
Connections to antenna . . . . . . . . . . . . . 16
Connections to other devices . . . . . . . . . 18
3Initial Setups (Setup Wizard) . . . . . 25
Initial setup . . . . . . . . . . . . . . . . . . . . . . 25
4Basic Operation . . . . . . . . . . . . . . . 30
Watching TV . . . . . . . . . . . . . . . . . . . . . 30
Channel banner . . . . . . . . . . . . . . . . . . . 33
Choosing audio and language . . . . . . . . 35
Picture Still . . . . . . . . . . . . . . . . . . . . . . 37
On screen messages. . . . . . . . . . . . . . . . 38
6 Appendix . . . . . . . . . . . . . . . . . . . . 86
Troubleshooting. . . . . . . . . . . . . . . . . . . 86
Specifications . . . . . . . . . . . . . . . . . . . . 88
Glossary and acronyms . . . . . . . . . . . . . 88
Indice
7 Guía para rápida consulta
(Español) . . . . . . . . . . . . . . . . . . . . 90
Ubicación de los controles. . . . . . . . . . . 90
Instalación de las pilas. . . . . . . . . . . . . . 91
Conexiones de antena . . . . . . . . . . . . . . 92
Conexión del STB a un SDTV
utilizando la salida VIDEO . . . . . . . . . . 93
Configuración inicial . . . . . . . . . . . . . . . 94
Warr anty . . . . . . . . . . . . . . . . . . . . .
Back Cover
5Advanced Operation . . . . . . . . . . . 39
Electronic Program Guide (EPG). . . . . . 39
Setup menu for preference. . . . . . . . . . . 42
CHANNEL
Adding channels . . . . . . . . . . . . . . . . . . 43
Deleting channels . . . . . . . . . . . . . . . . . 46
Adjusting antenna . . . . . . . . . . . . . . . . . 49
Receiving channels . . . . . . . . . . . . . . . . 51
DISPLAY
Selecting screen formats
(Screen ratio and Display mode) . . . . . . 54
CLOCK
Setting the clock . . . . . . . . . . . . . . . . . . 59
DETAIL
Setting a new password . . . . . . . . . . . . . 66
Setting for V-CHIP/CC . . . . . . . . . . . . . 69
Setting MPAA rating . . . . . . . . . . . . . . . 73
Setting TV rating. . . . . . . . . . . . . . . . . . 77
Selecting CC options . . . . . . . . . . . . . . . 81
Choosing the screen language . . . . . . . . 84
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
1 Before Using
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The caution marking is located on the rear of the cabinet.
IMPORTANT SAFEGUARDS
1.Read instructions-All the safety and operating instructions
should be read before the appliance is operated.
2.Retain Instructions-The safety and operating instructions
should be retained for future reference.
3.Heed Warnings-All warnings on the appliance and in the
operating instructions should be adhered to.
4.Follow Instructions-All operating and use instructions
should be followed.
5.Cleaning-Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use
a damp cloth for cleaning.
EXCEPTION: A product that is meant for uninterrupted
service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to
unplugging the appliance in the cleaning description otherwise required in item 5.
6.Attachments-Do not use attachments not recommended by
this product manufacturer as they may cause hazards.
7.Water and Moisture-Do not use this product near water-for
example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and
the like.
8.Accessories-Do not place this product on an unstable cart,
stand, tripod, bracket, or table. This product may fall, causing serious injury to someone, and serious damage to the
appliance. Use only with a cart, stand, tripod, bracket, or
table recommended by the manufacturer, or sold with this
product. Any mounting of the appliance should follow the manufacturer’s instructions and should use a
mounting accessory recommended
by the manufacturer. An appliance
and cart combination should be
moved with care.
Quick stops, excessive force, and
uneven surfaces may cause the
appliance and cart combination to
overturn.
THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A
RISK OF ELECTRIC SHOCK IS PRESENT
WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE
ARE IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE
APPLIANCE.
AMEUBLES- Cet appareil ne doit être
placé que sur un meuble (avec ou sans
roulettes) recommandé par le fabricant.
Si vous l’installez sur un meuble à
roulettes, déplacez les deux ensembles
avec précaution. Un arrêt brusque, l’utilisation d’une force excessive et des surfaces irrégulières
risquent de déstabiliser l’ensemble et de le renverser.
9. Ventilation-Slots and openings in the cabinet and the back
or bottom are provided for ventilation and to ensure reliable
operation of this product and to protect it from overheating,
and these openings must not be blocked or covered. The
openings should never be blocked by placing this product
on a bed, sofa, rug, or other similar surface. This product
should never be placed near or over a radiator or heat register. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is
provided or the manufacturer’s instructions have been
adhered to.
10.Power Sources-This product should be operated only from
the type of power source indicated on the marking label. If
you are not sure of the type of power supply to your home,
consult your appliance dealer or local power company. For
this products intended to operate from battery power, or
other sources, refer to the operating instructions.
11.Grounding or Polarization-This product is equipped with
a polarized alternating-current line plug(a plug having one
blade wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you
are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat
the safety purpose of the polarized plug.
12.Power-Cord Protection-Power-supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles,
and the point where they exit from the appliance.
EN
3
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
S2898A
FIGURE A
ELECTRIC
SERVICE
EQUIPMENT
NEC - NATIONAL ELECTRICAL CODE
GROUND
CLAMP
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNI T
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDI NG
ELECTRODE SYSTEM
(NEC ART 250, PART H)
13.Outdoor Antenna grounding-If an outside antenna or
cable system is connected to this product, be sure the
antenna or cable system is grounded so as to provide some
protection against voltage surges and built-up static
charges. Article 810 of the National Electrical Code,
ANSI/NFPA No. 70, provides information with respect to
proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit,
size of grounding conductors, location of antenna-discharge
unit, connection to grounding electrodes, and requirements
for the grounding electrode. (Fig. A)
14.Lightning-For added protection for this product receiver
during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall
outlet and disconnect the antenna or cable system. This will
prevent damage to this product due to lightning and powerline surges.
15.Power Lines-An outside antenna system should not be
located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them
might be fatal.
16.Overloading-Do not overload wall outlets and extension
cords as this can result in a risk of fire or electric shock.
17.Object and Liquid Entry-Never push objects of any kind
into this product through openings as they may touch dangerous voltage points or short out parts that could result in
a fire or electric shock. Never spill liquid of any kind on
this product.
18.Servicing-Do not attempt to service this product yourself
as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
19.Damage Requiring Service-Unplug this product from the
wall outlet and refer servicing to qualified service personnel under the following conditions:
a. When the power-supply cord or plug is damaged or frayed.
b. If liquid has been spilled, or objects have fallen into this
product.
c. If this product has been exposed to rain or water.
d. If this product does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions, as improper adjustment of other controls may result in damage and will often
require extensive work by a qualified technician to restore
this product to its normal operation.
e. If this product has been dropped or damaged in any way.
f. When this product exhibits a distinct change in perfor-
mance-this indicates a need for service.
20.Replacement Parts-When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may
result in fire, electric shock, injury to persons or other hazards.
21.Safety Check-Upon completion of any service or repairs to
this product, ask the service technician to perform routine
safety checks to determine that this product is in proper
operating condition.
22.Heat-This product should be situated away from heat
sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE
LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
4
EN
PRECAUTIONSPRECAUTIONS
LOCATION
For safe operation and satisfactory performance of
your this product, keep the following in mind when
selecting a place for its installation:
Shield it from direct sunlight and keep it away
•
from sources of intense heat.
Avoid dusty or humid places.
•
Avoid places with insufficient ventilation for proper
•
heat dissipation. Do not block the ventilation holes
at the top and bottom of the unit. Do not place the
unit on a carpet because this will block the ventilation holes.
Install unit in a horizontal position.
•
Avoid locations subject to strong vibration.
•
Do not place this product near strong magnetic fields.
•
Avoid moving this product to locations where tem-
•
perature differences are extreme.
AV OID THE HAZARDS OF
ELECTRICAL SHOCK AND FIRE
Do not handle the power cord with wet hands.
•
Do not pull on the power cord when disconnecting
•
it from an AC wall outlet. Grasp it by the plug.
If, by accident, water is spilled on your unit, unplug
•
the power cord immediately and take the unit to our
Authorized Service Center for servicing.
Do not put your fingers or objects into this product
•
cassette holder.
Do not place anything directly on top of the unit.
•
IMPORTANT COPYRIGHT INFORMATION
Unauthorized recording or use of broadcast television programming, video tape, film or other copyrighted material may violate applicable copyright
laws. We assume no responsibility for the unauthorized duplication, use, or other acts which infringe
upon the rights of copyright owners.
FCC WARNING- This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause
harmful interference unless the modifications
are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change
or modification is made.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment
and receiver.
3) Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4) Consult the dealer or an experienced radio/TV
technician for help.
1 Before Using
The serial number of this product may be found on the back of the unit. No others has the same serial number
as yours. You should record the number and other vital information here and retain this book as a permanent
record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.
Date of Purchase
Dealer Purchase from
Dealer Address
Dealer Phone No.
Model No.
Serial No.
EN
5
Before Using
NTSC
Analog/digital
terrestrial antenna
Analog/digital
terrestrial signals
ATSC
STB
Receives both
ATSC and NTSC
TV
Information on digital broadcasting
Digital broadcasting is the most advanced format of broadcasting, employing a new technology for
compression of audio and video signals which allows broadcasters to transmit digital signals using existing
terrestrial systems.
Due to this dramatic progress, new features of broadcasting service such as widescreen formats and higher
definition can provide a way to experience the full benefits of digital transmission.
High Definition Television (HDTV*) broadcasts can provide pictures twice as sharp as a conventional
broadcast and features sound encoded with Dolby® digital* 5.1 surround sound. When connected to a
receiver (sold separately) that features Dolby® digital decoding will provide a true theater experience in the
home.
Digital broadcasting has overcome problems experienced with analog television such as ghosting, "snowy"
pictures and interference. Digital television has a dramatic effect on these problems by its very nature.
In addition, the number of channels available has dramatically increased, so that you can make the best choice
among the variety of programs anytime with a clear picture.
The benefits extend not only to HDTV. It will also be possible to transmit multiple Standard Definition
Television (SDTV*) programs within the same bandwidth. Some data capacity could also be allocated to
provide more effective closed captioning or multiple language soundtracks.
Your current TV should be used for its entire service life.
STB will make this possible.
6
EN
Major features of STB
• Capable of receiving digital (ATSC*), analog (NTSC*), and cable (NTSC) broadcasts
• Capable of receiving High Definition TV broadcasts
• Capable of receiving Dolby® digital 5.1 audio
• Alternate languages for OSD are available.
(English, Spanish, French)
• Component video output jacks (Y/ Pb/ Pr)
• Sub-channels* are available through a single digital channel.
ATSC:
HDTV:
High Definition Television:
HDTV signal formats are 1080i (interlaced scan) and
720p (progressive scan). HDTV provides the highest
resolution picture and audio in either stereo or 5.1
channel surround sound.
Dolby® Digital:
Dolby® Digital (when available) provides 6
independent soundtrack channels through the coaxial
output jack.
STB has a Dolby Digital output (labeled DIGITAL
AUDIO (COAXIAL)) that can be connected to an
external Digital Audio receiver/ decoder equipped
with a coaxial input. With additional equipment you
can enjoy more dynamic and realistic sound at home.
SDTV:
Standard Definition Television:
SDTV signal formats are 480p and 480i. SDTV
provides lower resolution, yet presents a very sharp,
clear picture. Lower resolution allows broadcasters to
transmit multiple programs per channel.
ATSC (Advanced Television Systems Committee) is
the group that has been working to establish the
standards for digital television broadcasting and
digital television equipment - including both SDTV
and HDTV.
NTSC:
NTSC (National Television Standards Committee)
refers to the group that first established the standards
used for conventional analog television broadcasting
and TV equipment.
Sub-Channel:
Because of the compression of audio and video
signals, each digital channel is able to carry different
programs on sub-channels through a single channel.
You can select them by simply pressing CH
buttons on your remote control when available.
Before Using
1 Before Using
o / p
EN
7
Before Using
Location of controls
FRONT PANEL
12 3 4 567
1POWER button:
Turns STB on and off.
2POWER indicator:
Lights up while STB is on.
NOTE:
When turning the STB on, the power indicator will blink first and light up.
When turning the STB off, the power indicator will blink first and go off.
3Remote control sensor:
Receives signals from your remote control and enables you to control STB from a distance.
4Navigation buttons
Press to move the selected item or menu up, down, left or right.
5 SETUP button:
Press to enter or exit SETUP menu.
6 ENTER button:
In SETUP menu, press to determine your selection.
7 CHANNEL
Press to change the channels up or down.
o / p buttons:
o / p / s / B:
8
EN
REAR PANEL
Before Using
1 Before Using
135
1 ANT. IN Jack:
Use to connect an antenna to STB.
2 DIGITAL AUDIO (COAXIAL) Jack:
Use to connect a decoder or an amplifier to STB with a digital coaxial cable.
NOTE:
You must use this jack and a Dolby® Digital receiver for Dolby® Digital 5.1 playback.
3AUDIO R/ L Jacks: (2 pairs)
Use to connect your TV, a stereo system or a VCR to STB with standard audio cables.
NOTE for audio output:
There will be both digital audio output and analog audio output during digital broadcast. There will be
only analog audio output during analog broadcast. When you want digital audio output during digital
broadcast, the digital audio (coaxial) jack must be used.
Refer to the page describing the connection to a decoder with Dolby® Digital.
42 8 76
4 VIDEO Jack: (Composite)
Use to connect your TV or a VCR to STB with a standard video cable.
5 S-VIDEO Jack:
Use to connect your TV to STB with an S-Video cable.
NOTE:
When you use an S-Video cable, a composite video cable (yellow) is not necessary.
6 COMPONENT VIDEO Jacks (Y/ Pb/ Pr):
Use to connect your TV to STB with component video cables.
NOTE:
This connection is required to display a high definition broadcast.
Y (green), Pb (blue), Pr (red)
7 Resolution selection switch (1080i/ 480p/ 480i):
Use to select the STB video output resolution 1080i, 480p and 480i. The default setting is 480i.
8AC power cord:
Connect to AC outlet.
9
EN
Before Using
REMOTE CONTROL
6
1POWER button:
Turns STB on and off.
1
2
3
4
5
7
8
9
10
11
2 Number buttons:
Use to input channel numbers and passwords, and
to set time.
3 ENTER button:
In SETUP menu, press to determine your
selection.
4 CH
o / p buttons:
Press to change the channels up or down.
5Navigation buttons
Press to move the highlight up, down, left or
right.
The video pauses by pressing STILL o button
while you can listen to the program audio.
6 SETUP button:
Press to enter or quit SETUP menu.
7AUDIO button:
Use to select an alternate audio track while
watching a TV program.
8 PREVIOUS button:
Use to go back to the previous screen in SETUP
menu or to exit.
o / p / s / B:
10
EN
9 INFO button:
Use to display further information on the channel
banner or to exit.
10 EPG button:
Use to display EPG (Electronic Program Guide)
or to exit.
11 CH RETURN button:
Use to return to the channel you were last
watching.
Accessories
You will find STB and the following accessories
when unpacking the carton box of STB:
STB
6900DTD
Remote controller unit and AA batteries (x2)
(PART No.: NE120UD)
Before Using
1 Before Using
Installing batteries
1 Unsnap the battery cover from the back
of the remote control.
2Install two AA batteries making sure
the polarity (+ / -) direction is correct.
Owners manual (PART No.: 0EMN02308)
NOTE:
When replacing batteries, make sure to replace them
in pairs.
3 Snap the battery cover back.
CAUTION:
•
Do not mix battery types.
(alkaline and manganese)
• Do not recharge, short-circuit, heat, burn or
disassemble batteries.
A NOTE ABOUT RECYCLING
This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in
accordance with your local recycling regulations.
Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.
11
EN
Before Using
Reference to SETUP menu
SETUP WIZARD
( Refer to page 25 through page 29. )
SETUP WIZARD
SETUP WIZARD guides you
through initial setup.
"Create new setup"
"SETUP"
:
"Keep old setup"
"QUIT"
:
QUIT SETUP
Language for screen (1/8)
( Refer to page 25. )
SETUP WIZARD 1/8
Setting the clock (Manual)
(5/8)
( Refer to page 27. )
SETUP WIZARD 5/8
Channel scanning (2/8) Setting the clock (Auto)
( Refer to page 26. )
SETUP WIZARD 2/8
Daylight savings time
(DST) (3/8)
( Refer to page 26.)
SETUP WIZARD 3/8
Now the system is scanning for channels.
34%
Digital
Analog
SKIP
Do you observe daylight saving time
(DST)?
OFF
ON
(6/8)
( Refer to page 28. )
Screen ratio (7/8)
( Refer to page 29. )
SETUP WIZARD 6/8
SETUP WIZARD 7/8
Enter current time.
2001YEAR
--
-- ---
DATE
-- -- --
TIME
SET
Select a channel for auto clock setting.
Searching.
2
Select screen ratio.
OFF
16:9
4:3
1
2
3
4
Time zone (4/8) Display mode (8/8)
( Refer to page 26. ) ( Refer to page 29. )
SETUP WIZARD 4/8
Select your time zone.
CENTRAL
12
EN
SETUP WIZARD 8/8
Select display mode.
LETTERBOX
ZOOM
FULL
Before Using
CHANNEL DISPLAY
( Refer to page 43, 46, 49, 51.) ( Refer to page 54, 56.)
CHANNEL
QUIT
ADD/DELETE
ANTENNA
CHANNEL
AUTOSCAN
DISPLAY
CLOCK
DETAIL
Adding channels /
Deleting channels
( Refer to page 43, 46. ) ( Refer to page 54. )
ADD/DELETE
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
ADD
DELETE
13-0
13
22
23
55
Adjusting antenna
ANTENNA
QUIT
WEAK STRONG
CHANNEL
NOW
DISPLAY
CLOCK
DETAIL
75
PREVIOUS
26-1
75
PEAK
DISPLAY
QUIT
SCREEN RATIO
DISPLAY MODE
CHANNEL
DISPLAY
CLOCK
DETAIL
Selecting screen formats
(Screen ratio)
Selecting screen formats
(Display mode)
( Refer to page 56. )( Refer to page 49. )
4:3
LETTERBOX
DISPLAY
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
DISPLAY
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
SCREEN
DISPLAY
SCREEN
Select display mode.
DISPLAY
1 Before Using
Select screen ratio.
16:9
4:3
LETTERBOX
ZOOM
FULL
Receiving channels (Autoscan)
( Refer to page 51. )
AUTOSCAN
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
AutoScan will rescan all channels.
This may take a while to complete.
PREVIOUS
NEXT
13
EN
Before Using
CLOCK
( Refer to page 59, 60, 62, 64. )
CLOCK
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
2002/ 1/31( THU ) 2 50PM
DST
TIME ZONE
MANUAL
AUTO
Setting the clock (Daylight Savings Time)
( Refer to page 60. )
Setting the clock (Time Zone)
( Refer to page 60. )
Setting the clock (Manual)
( Refer to page 62. )
Adjusting the clock automatically
( Refer to page 64. )
ON
CENTRAL
OFF
CLOCK
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
CLOCK
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
CLOCK
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
CLOCK
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
Do you observe daylight saving time
(DST)?
ON
OFF
Select your time zone.
CENTRAL
Enter current time.
YEAR 2002
DATE 311 THU
TIME 50 PM2
SET
Select a channel for auto clock setting.
Searching.
2
OFF
1
2
3
4
14
EN
Before Using
DETAIL
( Refer to page 66, 69, 70, 71, 73, 77, 81, 84. )
DETAIL
QUIT
V-CHIP / CC
CHANNEL
MENU LANGUAGE ENGLISH
DISPLAY
CLOCK
DETAIL
Setting for V-CHIP/CC
( Refer to page 69. ) ( Refer to page 71. )
V-CHIP / CC
QUIT
V-CHIP / CC
MPAA RATING
CHANNEL
TV RATING
DISPLAY
CC SELECTION OFF
CLOCK
NEW PASSWORD
DETAIL
V-CHIP/CC password
window
( Refer to page 70. )
V-CHIP / CC
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
Enter password.
Choosing the screen language
( Refer to page 84. )
DETAIL
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
V-CHIP / CC
MENU LANGUAGE
STB
Select menu language.
Setting for V-CHIP/CC
V-CHIP / CC
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
Setting MPAA rating
( Refer to page 73. )
V-CHIP / CC
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
Setting TV rating
( Refer to page 77. )
V-CHIP / CC
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
Setting CC options
( Refer to page 81. )
V-CHIP / CC
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
Setting a new password
( Refer to page 66. )
V-CHIP / CC
QUIT
CHANNEL
DISPLAY
CLOCK
DETAIL
Choose either STB or TV for
V-CHIP/CC setting.
If you choose "TV",
V-CHIP/CC functions are
processed in TV, not in STB.
Set MPAA rating
Set TV rating
TV-MA
TV-14
TV-PG
TV-G
TV-Y7
TV-Y
V-CHIP / CC
MPAA RATING
TV RATING
CC SELECTION
NEW PASSWORD
STB
X
NC-17
R
PG-13
PG
G
NR
FV V S L D
Enter password.
Confirm password.
TV
Select CC.
OFF
CC1
CC2
CC3
CC4
TEXT1
TEXT2
TEXT3
TEXT4
1 Before Using
15
EN
Connections
STB connection to the antenna
Rear panel of STB
To the antenna
To the antenna
WHEN CONNECTING TO CABLE BOX ALSO:
NOTE:
Antenna and antenna cable are not included.
ANT. IN
Incoming cable
signals
NOTE:
Antenna, antenna cable and Cable box are not included.
STB
CABLE BOX
TV
ANT-IN
Jack
Refer to following
pages for the
connection to TV.
ANT
IN
ANT
OUT
Antenna cable
Connections to antenna
Use a standard antenna cable to connect the wall jack to the ANT IN Jack on STB.
1 Use a standard antenna cable to connect the wall jack to the
ANT IN Jack on STB.
NOTE:
Refer to the following pages for the connection to TV.
2 Use an incoming cable to connect to an antenna input jack on
the cable box.
3 Use a standard antenna cable to connect an antenna output jack
on the cable box to an antenna input jack on the TV.
4 After completing the connection to TV, plug the AC power
cord of the TV into the AC outlet, then turn the TV on.
5 Select the output channel from the cable box e.g., ch3 or ch 4.
NOTE:
Refer to the TV owner’s manual for further information.
6 Plug the AC power cord of STB into the AC outlet, then turn
STB on.
16
EN
Note to the Cable TV System
Installer :
This reminder is provided to call
the Cable TV system installer’s
attention to Article 820-40 of the
National Electrical Code, which
provides guidelines for proper
grounding - in particular,
specifying that the cable ground
shall be connected to the grounding
system of the building, as close to
the point of cable entry as possible.
Connections
e.g.: Connection to VCR
When you connect the antenna cable to another device, be sure to use a splitter as shown below.
CAUTION
Right
Splitter
ANT. IN
ANT. IN
RF-IN
RF-OUT
e.g.: Connection to VCR
STB
Wrong
RF-IN
RF-OUT
Antenna cable
Antenna
cables
Antenna
cables
NOTE:
Antenna, antenna cable and Splitter are not included.
STB
2 Connections
17
EN
Connections
STB connection using COMPONENT video output to TV
e.g.: Connection to HDTV
Rear panel of STB
Audio cable
Component
video cable
To audio input jacks (L, R)
To component video input jacks (Y/ Pb/ Pr)
Position of Resolution Selection Switch
If your TV is capable of displaying 1080i,
then select 1080i as shown.
If your TV is capable of displaying 480p,
then select 480p as shown.
If your TV is capable of displaying 480i,
then select 480i as shown.
1080i
480p
480i
TV Format
NOTE:
Component video cable and audio cable are not included.
Resolution Selection Switch (1080i, 480p, 480i)
Refer to the TV owner s manual for the video resolution of your TV.
Connections to other devices
There will be various ways of connecting STB to other devices. Make your connection according to your
choice of devices, screen format, and sound format.
You will find some sample connections in the following pages.
• All jacks on STB will not need to be connected.
• When you change the connections, all devices should be turned off.
• Refer to each owner’s manual for further information on other devices.
18
EN
Connections
1 Use a standard antenna cable to connect the wall jack to the ANT IN jack on STB.
2 Use a standard audio cable to connect the audio output jacks (L, R) of STB to the audio input jacks (L, R) on
the TV.
NOTE:
If your TV is monaural (MONO) and has only one audio jack, use a standard audio cable (white) to
connect the audio output jack (white) on STB to the audio input jack (white) on the TV. The red cable and
jack will not be used.
3 Use a component video cable to connect the component video output jacks (Y/ Pb/ Pr) on STB to the
component video input jacks (Y/ Pb/ Pr) on the TV.
4 Set the video resolution selection switch to “1080i.”
NOTE:
For the capability of your TV and further information, refer to TV owner’s manual.
5 After completing the connection to the TV, plug the AC power cord of the TV into the AC outlet, then turn
the TV on.
6 Set the TV to the input mode.
NOTE:
Refer to the TV owner’s manual for further information.
7 Plug the AC power cord of STB into the AC outlet, then turn STB on.
2 Connections
19
EN
Connections
STB connection using S-VIDEO output to SDTV
Rear panel of STB
Audio cable
To audio input jacks (L, R)
To S-video input jack
S-video cable
NOTE:
S-video cable and audio cable are not included.
1 Use a standard antenna cable to connect the wall jack to the ANT IN jack on STB.
2 Use a standard audio cable to connect the audio output jacks (L, R) of STB to the audio input jacks (L, R) on
the TV.
3 Use an S-video cable to connect the S-VIDEO output jack on STB to an S-video input jack on the TV.
4 Set the resolution selection switch to “480i.”
5 After completing the connection to the TV, plug the AC power cord of the TV into the AC outlet, then turn
the TV on.
6 Set the TV to the input mode.
NOTE:
Refer to the TV owner’s manual for further information.
7 Plug the AC power cord of STB into the AC outlet, then turn STB on.
NOTE:
When using an S-video cable to connect, the resolution of the video signal output will always be 480i.
20
EN
Connections
Rear panel of STB
Audio cable Video cable
To audio input jacks (L, R)
To a video input jacks
NOTE:
Audio cable and video cable are not included.
STB connection using VIDEO output to SDTV
2 Connections
1 Use a standard antenna cable to connect the wall jack to the ANT. IN jack on STB.
2 Use a standard audio cable to connect the audio output jacks (L, R) of STB to the audio input jacks (L, R) on
the TV.
NOTE:
If your TV is monaural (MONO) and has only one audio jack, connect a standard audio cable (white) from
the audio output jack (white) on STB to an audio input jack (white) on the TV. The red cable and jack will
not be used.
3 Use a standard video cable to connect the video output jack on STB to a video input jack on the TV.
4 Set the resolution selection switch to “480i.”
5 After completing the connection to the TV, plug the AC power cord of the TV into the AC outlet, then turn
the TV on.
6 Set the TV to the input mode.
NOTE:
Refer to the TV owner’s manual for further information.
7 Plug the AC power cord of STB into the AC outlet, then turn STB on.
NOTE:
When using a standard video cable to connect, the resolution of the video signal output will always be 480i.
21
EN
Connections
STB connection to a standard stereo system
STEREO COMPONENT
Rear panel of STB
Audio cable
To audio input jacks
(L, R)
To component video input
jacks (Y/ Pb/ Pr)
Component video cable
NOTE:
Component video cable and audio cable are not included.
1 Use a standard antenna cable to connect the wall jack to the ANT. IN jack on STB.
2 Use a standard audio cable to connect the audio output jacks (L, R) on STB to the audio input jacks (L, R)
on the stereo.
3 Connect STB and the TV with a video cable.
NOTE:
Refer to the pages describing the connection to TV.
4 Set the video resolution selection switch to “1080i.”
NOTE:
For the capability of your TV and further information, refer to TV owner’s manual.
5 Plug the AC power cord of the stereo into the AC outlet, then turn the stereo on.
6 Set the stereo to the input mode to which you connected the audio from the STB.
NOTE:
Refer to the stereo owner's manual for further information.
7 Plug the AC power cord of STB into the AC outlet, then turn STB on.
22
EN
1 Use a standard antenna cable to connect the wall jack to the ANT. IN jack on STB.
STB connection to a decoder with Dolby Digital
Digital Decoder
Coaxial digital
audio cable
To Coaxial digital
audio input jack
Rear panel of STB
To component video input
jacks (Y/ Pb/ Pr)
Component
video cable
NOTE:
Coaxial digital audio cable and component video cable are not included.
Connections
2 Connections
2 Connect a coaxial digital audio cable (purchase locally) from DIGITAL AUDIO (COAXIAL) output jack
on STB to a coaxial digital audio input jack on the digital decoder.
3 Connect STB and the TV with a video cable.
NOTE:
Refer to the pages describing the connection to TV for connecting to the TV.
4 Set the video resolution selection switch to “1080i.”
NOTE:
For the capability of your TV and further information, refer to TV owner’s manual.
5 Plug the AC power cord of the decoder into an AC outlet, then turn the decoder on.
6 Set the decoder to the input mode.
NOTE:
Refer to the decoder owner's manual for further information.
7 Plug the AC power cord of STB into an AC outlet, then turn them on.
NOTE:
STB will output the sound from the DIGITAL AUDIO (COAXIAL) output only when receiving a digital
broadcast.
Dolby® information:
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks
of Dolby Laboratories.
23
EN
Connections
STB connection to TV and Video devices (VCR, DVD recorder, etc)
e.g.: Connection to VCR
Rear panel of STB
VCR
Audio cable
Video cable
Video
cable
Audio
cable
To video input
jack
To audio input
jacks (L, R)
NOTE:
Audio cables and video cables are not included.
1 Use a standard antenna cable to connect the wall jack to the ANT IN jack on STB.
2 Use a standard audio cable to connect the set of audio output jacks (L, R) on STB to the set of audio input
jacks (L, R) on the VCR.
NOTE:
If your VCR is monaural (MONO) and has only one audio jack, use a standard audio cable (white) to
connect the audio output jack (white) on STB to the audio input jack (white) on the VCR. The red cable
and jack will not be used.
3 Use a standard video cable to connect the video output jack on STB to the video input jack on the VCR.
4 Set the video resolution selection switch to “480i.”
NOTE:
No matter where the switch is, the video resolution with this connection will be always 480i.
For screen ratio and display mode, the settings in Setup menu will be effective.
For the capability of your TV and further information, refer to TV owner’s manual.
5 Use a standard video cable to connect the video output jack on the VCR to the video input jack on the TV.
6 Use a standard audio cable to connect the set of audio output jacks (L, R) on the VCR to the audio input
jacks (L, R) on the TV.
7 Plug all AC power cords into AC outlets, then turn all devices on.
8 Set the TV and VCR to input mode.
NOTE:
Refer to the owner’s manuals of the TV and the VCR for further information.
NOTE:
When using a standard video cable to connect, the resolution of the video signal output will always be 480i.
24
EN
SETUP WIZARD 1/8
SETUP WIZARD guides you
through initial setup.
"Create new setup"
"Keep old setup"
"SETUP"
"QUIT"
QUIT SETUP
:
:
SETUP WIZARD
1,2,3,6,7,
8,9,10,11,
12,13
1,2,3,6,7,
8,10,12,
13
8
Initial Setups (Setup Wizard)
Initial setup
SETUP WIZARD
SETUP WIZARD is the very convenient menu for
you to make the initial settings of STB.
When STB is turned on for the first time after
connecting the AC power cord, SETUP WIZARD is
displayed on the screen automatically. You can
complete the following items for the initial Setups
through this menu.
• Language for screen
• Channel Scanning
• Daylight savings time (DST)
• Time zone
• Year/ date/ time
• Clock
• Screen ratio and display mode
1 SETUP WIZARD will appear.
Screen:
2 Select SETUP using
ss/ BB
navigation
buttons, then press ENTER.
• SETUP WIZARD 1/8 will appear.
Remote:
3 Initial Setups
(Setup Wizard)
25
EN
EN
EN
SETUP WIZARD 4/8
Select your time zone.
CENTRAL
SETUP WIZARD 3/8
Do you observe daylight saving time
(DST)?
OFF
ON
Initial Setups (Setup Wizard)
3 Select a desired language using
navigation buttons, then press ENTER.
• The selected language will be activated.
• SETUP WIZARD 2/8 will appear.
Now the system is scanning for channels.
Digital0%Analog
SKIP
oo/ pp
5 SETUP WIZARD 3/8 will appear.
6 Select ON or OFF for Daylight Savings
Time (DST) using
ss/ BB
navigation
buttons, then press ENTER.
• SETUP WIZARD 4/8 will appear.
4 STB starts scanning channels.
• Wait until the scanning is complete.
• When the scanning is complete, “100%” will be
indicated in the box, then the next screen appears.
SETUP WIZARD 2/8
Now the system is scanning for channels.
To skip the scanning:
Press ENTER.
34%
SKIP
Digital
Analog
26
EN
EN
EN
SETUP WIZARD 5/8
Enter current time.
2001YEAR
12
DATE
13
10 30 PM
TIME
SET
THU
or
SETUP WIZARD 5/8
Enter current time.
2001YEAR
--
DATE
-- ---
-- -- --
TIME
SET
Initial Setups (Setup Wizard)
7 Select the desired time zone using
BB
/ ss/
navigation buttons, then press
ENTER.
• SETUP WIZARD 5/8 will appear.
oo/ pp
8 Enter YEAR, DATE and TIME using
BB
/ ss/
navigation buttons or number
oo/ pp
buttons.
• Every time you enter a number, press ENTER to
move the cursor.
• When going back and forth, press
navigation buttons to move the cursor.
s /B
3 Initial Setups
(Setup Wizard)
NOTE :
Refer to “INFORMATION on Time Zones ” on page
61.
NOTE:
After all information is entered, the cursor will move
to SET.
TIP:
To enter the YEAR, enter the last 2 digits of the year.
The year will be entered. (e.g., Enter “03” using
number buttons; 2003 will be shown.)
27
EN
EN
EN
CLOCK
Select a channel for auto clock setting.
34
48
52
71034
Searching.
5
4
3
2
OFF
Initial Setups (Setup Wizard)
9 Press ENTER when the cursor is on
SET.
• Your settings will be activated.
• SETUP WIZARD 6/8 will appear, then STB will
start searching channels with Automatic Clock
Adjustments to keep the time correct.
SETUP WIZARD 6/8
Select a channel for auto clock setting.
Searching.
2
OFF
2
3
4
5
10 Select the desired channel to search
from the channel map using
oo/ pp
navigation buttons.
SETUP WIZARD 6/8
Select a channel for auto clock setting.
Searching.
34
71034
48
52
3
4
5
6
7
28
EN
EN
EN
NOTE:
The channel numbers with clock data will become
black in the channel map.
NOTE:
: Indicates that there are more channels above or
below.
: Indicates the top or bottom of the channel map.
When not using the auto-clock setting:
Select OFF on the channel map, then press ENTER.
TIP:
OFF is located at the top of the channel map. Keep
pressing o navigation button to search.
11 Press ENTER.
26-1
World News 25
WWOR
ENGLISH STEREO
SETUP WIZARD 8/8
Select display mode.
LETTERBOX
ZOOM
FULL
SETUP WIZARD 7/8
Select screen ratio.
16:9
4:3
• SETUP WIZARD 7/8 will appear.
Initial Setups (Setup Wizard)
NOTE:
Refer to “Selecting screen formats” on page 54 for
further information.
13 Select the desired display mode using o /
navigation buttons, then press ENTER.
p
• SETUP WIZARD is completed.
STB will now start receiving broadcasts.
3 Initial Setups
(Setup Wizard)
12 Select the desired screen ratio using
pp
navigation buttons, then press
ENTER.
• SETUP WIZARD 8/8 will appear.
oo
/
NOTE:
Refer to “Selecting screen formats” on page 54 for
further information.
29
EN
EN
EN
Loading...
