Sylvania 6319CE, 6313CE User Manual
COLOR TV/VCR
6313CE (13 inch)
6319CE (19 inch)
OWNER’S
MANUAL
If you need additional assistance for set-up or operating after
reading owner’s manual, please call TOLL FREE : 1-800-968-3429.
Or visit our WEB SITE at
http://www.SylvaniaConsumerElectronics.com
Please read before using this equipment
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
YXY
X
b
O
a
PN
19" MODEL ILLUSTRATED
1.Read instructions - All the safety and operating instructions
should be read before the appliance is operated.
2.Retain Instructions - The safety and operating instructions
should be retained for future reference.
3.Heed Warnings - All warnings on the appliance and in the
operating instructions should be adhered to.
4.Follow Instructions - All operating and use instructions
should be followed.
5.Cleaning - Unplug unit from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
EXCEPTION: A product that is meant for uninterrupted
service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to
unplugging the appliance in the cleaning description otherwise required in item 5.
6.Attachments - Do not use attachments not recommended by
the unit manufacturer as they may cause hazards.
7.Water and Moisture - Do not use this unit near water-for
example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and
the like.
8.Accessories - Do not place this unit on an unstable cart,
stand, tripod, bracket, or table. The unit may fall, causing
serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the unit.
Any mounting of the appliance should follow the manufacturer’s instructions and should use
a mounting accessory recommended by the manufacturer. An appliance and cart combination should
be moved with care.
Quick stops, excessive force, and
uneven surfaces may cause the
appliance and cart combination to
overturn.
AMEUBLES - Cet appareil ne doit être placé que sur un
meuble (avec ou sans roulettes)
recommandé par le fabricant. Si vous
l’installez sur un meuble à roulettes,
déplacez les deux ensembles avec
précaution. Un arrêt brusque, l’utilisation d’une force excessive et des surfaces irrégulières risquent de déstabiliser l’ensemble et de le renverser.
9. Ventilation - Slots and openings in the cabinet and the
back or bottom are provided for ventilation and to ensure
reliable operation of the unit and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the
unit on a bed, sofa, rug, or other similar surface. This unit
should never be placed near or over a radiator or heat register. This unit should not be placed in a built-in installation
such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered
to.
10.Power Sources - This unit should be operated only from
the type of power source indicated on the marking label. If
you are not sure of the type of power supply to your home,
consult your appliance dealer or local power company. For
units intended to operate from battery power, or other
sources, refer to the operating instructions.
11.Grounding or Polarization - This unit is equipped with a
polarized alternating-current line plug(a plug having one
blade wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you
are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
12.Power-Cord Protection - Power-supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles,
and the point where they exit from the appliance.
- 2 - EN
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
IMPORTANT SAFEGUARDS
The caution marking is located on the rear of the cabinet.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
THIS SYMBOL INDICATES THAT
DANGEROUS VOLTAGE
CONSTITUTING A RISK OF ELECTRIC
SHOCK IS PRESENT WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE
ARE IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE
APPLIANCE.
PORTABLE CART WARNING
S3126A
SYMBOLE D'AVERTISSEMENT POUR
LES COMPOSANTES
APPAREIL ET MEUBLE A ROULETTES
S3126A
- 3 - EN
13.Outdoor Antenna grounding - If an outside antenna or
cable system is connected to the unit, be sure the antenna
or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA
No. 70, provides information with respect to proper
grounding of the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements for
the grounding electrode. (Fig. A)
14.Lightning - For added protection for this unit receiver dur-
ing a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall
outlet and disconnect the antenna or cable system. This will
prevent damage to the unit due to lightning and power-line
surges.
15.Power Lines - An outside antenna system should not be
located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them
might be fatal.
16.Overloading - Do not overload wall outlets and extension
cords as this can result in a risk of fire or electric shock.
17.Object and Liquid Entry - Never push objects of any
kind into this unit through openings as they may touch dangerous voltage points or short out parts that could result in
a fire or electric shock. Never spill liquid of any kind on
the unit.
18.Servicing - Do not attempt to service this unit yourself as
opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified
service personnel.
19.Damage Requiring Service - Unplug this unit from the
wall outlet and refer servicing to qualified service person-
nel under the following conditions:
a. When the power-supply cord or plug is damaged or frayed.
b. If liquid has been spilled, or objects have fallen into the
unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by following the oper-
ating instructions. Adjust only those controls that are cov-
ered by the operating instructions, as improper adjustment
of other controls may result in damage and will often
require extensive work by a qualified technician to restore
the unit to its normal operation.
e. If the unit has been dropped or damaged in any way.
f. When the unit exhibits a distinct change in performance,
this indicates a need for service.
20.Replacement Parts - When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer that have the same character-
istics as the original part. Unauthorized substitutions may
result in fire, electric shock, injury to persons or other haz-
ards.
21.Safety Check - Upon completion of any service or repairs
to this unit, ask the service technician to perform routine
safety checks to determine that the unit is in proper operat-
ing condition.
22.Heat - This unit product should be situated away from heat
sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
EXAMPLE OF ANTENNA GROUNDING AS PER
CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE
LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
NATIONAL ELECTRICAL CODE
S2898A
FIGURE A
ELECTRIC
SERVICE
EQUIPMENT
NEC - NATIONAL ELECTRICAL CODE
GROUND
CLAMP
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNI T
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDI NG
ELECTRODE SYSTEM
(NEC ART 250, PART H)
AV OID THE HAZARDS OF
ELECTRICAL SHOCK AND FIRE
RADIO-TV INTERFERENCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment
and receiver.
3) Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4) Consult the dealer or an experienced radio/TV
technician for help.
- 4 - EN
PRECAUTIONSPRECAUTIONS
LOCATION
For safe operation and satisfactory performance of
your unit, keep the following in mind when selecting
a place for its installation:
•
Shield it from direct sunlight and keep it away
from sources of intense heat.
•
Avoid dusty or humid places.
•
Avoid places with insufficient ventilation for proper
heat dissipation. Do not block the ventilation holes
at the top and bottom of the unit. Do not place the
unit on a carpet because this will block the ventilation holes.
•
Install the unit in a horizontal position.
•
Avoid locations subject to strong vibration.
•
Do not place the unit near strong magnetic fields.
•
Avoid moving unit to locations where temperature
differences are extreme.
•
Be sure to unplug the AC power cord from the outlet before carrying the unit.
•
Do not handle the power cord with wet hands.
•
Do not pull on the power cord when disconnecting
it from an AC wall outlet. Grasp it by the plug.
•
If, by accident, water is spilled on your unit, unplug
the power cord immediately and take the unit to our
Authorized Service Center for servicing.
•
Do not put your fingers or objects into the unit cassette holder.
•
Do not place anything directly on top of the unit.
WARNING
Moisture condensation may occur inside the unit
when it is moved from a cold place to a warm place,
or after heating a cold room or under conditions of
high humidity. If a tape is played in a unit which has
moisture, it may damage the tape and unit. Therefore
when the condensation occurs inside the unit, turn
the unit on and allow at least 2 hours for the unit to
dry out.
IMPORTANT COPYRIGHT INFORMATION
Unauthorized recording or use of broadcast television programming, video tape, film or other copyrighted material may violate applicable copyright
laws. We assume no responsibility for the unauthorized duplication, use, or other acts which infringe
upon the rights of copyright owners.
FCC WARNING- This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause
harmful interference unless the modifications
are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change
or modification is made.
The serial number of this product may be found on the back of the unit. No other unit has the same serial
number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.
Date of Purchase
Dealer Purchase from
Dealer Address
Dealer Phone No.
Model No.
Serial No.
- 5 - EN
TABLE OF CONTENTS
A NOTE ABOUT RECYCLING
Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.
C IMPORTANT SAFEGUARDS . . . . . . . . . . . . .2
C PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . .4
LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
AVOID THE HAZARDS OF ELECTRICAL
SHOCK AND FIRE . . . . . . . . . . . . . . . . . . . . . .4
WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
C TABLE OF CONTENTS . . . . . . . . . . . . . . . . . .5
C FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
C SUPPLIED ACCESSORIES . . . . . . . . . . . . . . .6
C OPERATING CONTROLS AND FUNCTIONS 7
INSTALLING THE BATTERIES . . . . . . . . . . .8
C PREPARATION FOR USE . . . . . . . . . . . . . . . .9
ANTENNA/CABLE CONNECTIONS . . . . . . .9
USING FRONT A/V INPUT JACKS
. . . . . . . . .10
C TV OPERATION AND SETTINGS . . . . . . . . .10
WATCHING A TV PROGRAM . . . . . . . . . . . .10
PICTURE CONTROL . . . . . . . . . . . . . . . . . . .11
GAME MODE . . . . . . . . . . . . . . . . . . . . . . . . .11
DEGAUSSING . . . . . . . . . . . . . . . . . . . . . . . .11
WAKE UP TIMER . . . . . . . . . . . . . . . . . . . . . .11
SLEEP TIMER . . . . . . . . . . . . . . . . . . . . . . . . .12
CLOSED CAPTION SYSTEM . . . . . . . . . . . .12
CHANNEL SET UP . . . . . . . . . . . . . . . . . . . .12
CLOCK SET UP (AUTO / MANUAL) . . . . . .13
DAYLIGHT-SAVING TIME . . . . . . . . . . . . . .15
MENU LANGUAGE . . . . . . . . . . . . . . . . . . . .15
V-CHIP SET UP . . . . . . . . . . . . . . . . . . . . . . . .16
C VIDEO CASSETTE . . . . . . . . . . . . . . . . . . . . .17
C PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . .18
NORMAL PLAYBACK . . . . . . . . . . . . . . . . . .18
TRACKING ADJUSTMENT . . . . . . . . . . . . . .18
STILL PICTURE . . . . . . . . . . . . . . . . . . . . . . .18
C SPECIAL PLAYBACK . . . . . . . . . . . . . . . . . .19
RENTAL PLAYBACK . . . . . . . . . . . . . . . . . . .19
AUTO REPEAT PLAYBACK . . . . . . . . . . . . .19
C SEARCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
ZERO RETURN . . . . . . . . . . . . . . . . . . . . . . .20
PICTURE SEARCH . . . . . . . . . . . . . . . . . . . .20
TIME SEARCH . . . . . . . . . . . . . . . . . . . . . . . .20
C SPECIAL FEATURES . . . . . . . . . . . . . . . . . .21
REAL TIME TAPE COUNTER . . . . . . . . . . . .21
AUTO REWIND-EJECT . . . . . . . . . . . . . . . . .21
C RECORDING . . . . . . . . . . . . . . . . . . . . . . . . .21
NORMAL RECORDING . . . . . . . . . . . . . . . . .21
SKIPPING UNWANTED SCENES DURING
RECORDING . . . . . . . . . . . . . . . . . . . . . . . . .21
OTR (One Touch Recording) . . . . . . . . . . . . . .22
COPYING A VIDEO CASSETTE
(Requires a VCR or camcorder) . . . . . . . . . . . .22
C TIMER RECORDING . . . . . . . . . . . . . . . . . . .23
AUTOMATIC TIMER RECORDING . . . . . . .23
AUTO RETURN . . . . . . . . . . . . . . . . . . . . . . .24
C ON SCREEN DISPLAY . . . . . . . . . . . . . . . . .25
C CABLE CHANNEL DESIGNATIONS . . . . . .25
C TROUBLESHOOTING GUIDE . . . . . . . . . . .26
C SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . .27
C MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . .27
C WARRANTY . . . . . . . . . . . . . . . . . . .Back Cover
INDICE
CONTROLES DE OPERACIÓN Y
SUS FUNCIONES . . . . . . . . . . . . . . . . . . . . . . . .28
C PREPARACIÓN PARA LA UTILIZACIÓN . . .30
CONEXIONES DE ANTENA/CABLE . . . . . . . .30
C FUNCIONES Y AJUSTES . . . . . . . . . . . . . . . .30
PA RA MIRAR UN PROGRAMA DE TV . . . . . . .30
AJUSTE DEL RELOJ . . . . . . . . . . . . . . . . . . .30
IDIOMA DEL MENÚ . . . . . . . . . . . . . . . . . . .31
REPRODUCCION NORMAL . . . . . . . . . . . . .31
GRABACIÓN NORMAL . . . . . . . . . . . . . . . . .31
Rod Antenna
(Supplied with 13"model only)
PA RT NO. (0EMN00673,
0EMN01599 or 0EMN01755)
2 AA Batteries
Remote Control Unit
PA RT NO.
(N0150UD or
N0107UD )
FEATURES
•
Infrared remote control
•
Trilingual on screen menu display selectable in
English, Spanish or French
•
Real time counter–This shows the elapsed record-
ing or playback time in hours, minutes and seconds. The “–” indication will appear when the tape
is rewound further than the tape counter position
“0:00:00”.
•
181 channel capability PLL frequency synthesizer tuner with direct station call–
(A converter may
be necessary to view scrambled cable channels.)
•
Auto Clock Setting–Allows you to set the clock
function from a PBS broadcast station.
•
Closed caption system–You may view specially
labeled (cc) TV programs, movies, news, prerecorded tapes, etc. with either a dialogue caption or
text display added to the program.
•
Game mode–Automatically sets external input
mode and allows unit display to be suitable for use
with video games.
•
Auto power on and off system–Automatically
turns on the unit when you insert the cassette, turns
off after auto-rewind, and ejects when the beginning of the tape is reached.
•
Auto rewind when the end of a tape is reached
(This function doesn’t occur when using timer
recording.)
•
2 Step picture search operation–You can view a
video program at a high speed or super high speed
in either a forward or reverse direction in LP and
SLP mode. For SP mode only high speed is available.
•
Three different playback tape speeds : SP/LP/SLP
•
Two different recording tape speeds : SP/SLP
•
Auto Head Cleaner–Automatically cleans video
heads as you insert or remove a cassette.
•
Zero Return–The tape returns to counter of
0:00:00 by rewinding or fast forwarding.
•
Still–Freeze the picture at any time, for close view-
ing of a particular scene. Only tapes recorded in
SLP mode will show a fairly clear picture.
•
Digital Auto Tracking (DTR)–Automatically
adjusts the tracking for each tape you play.
•
Rental play mode–Improves playback picture
quality from worn tapes, such as rental tapes.
•
Auto repeat–Allows you to repeat the playing of a
tape indefinitely without pressing the PLAY button.
•
Time search–Let you set the unit to advance the
tape by entering the desired playback time you
want to skip.
•
OTR (One Touch Recording)–Instant timed
recording from 30 to 480 minutes is possible at the
push of the REC/OTR button.
•
1 Year, 8 events (including Daily and Weekly)
Timer Recording–
The built-in timer allows you to
record up to 8 programs at different times on different channels up to 1 year in advance. The Daily
timer allows recordings to be made of daily broadcasts and the Weekly timer allows recording to be
made once a week up to the end of the tape.
•
Auto return–After timer recording is finished, the
unit can return to the beginning of the recording.
•
Wake up/Sleep timer–Allows you to have the unit
automatically turn on or off at a desired time.
•
Timer Program Extension–Allow you to shift the
time schedule for automatic timer recording.
•
V-CHIP–Enables parents to prevent their children
from watching inappropriate material on TV.
SUPPLIED ACCESSORIES
•
If you need to replace these accessories, please refer to the PART NO. under the illustrations and call our
help line mentioned on the front page.
•
Depending on your antenna system, you may need different types of Combiners (Mixer) or Separators
(Splitter). Contact your local electronics store for these items.
•
We do not recommend the use of universal remote controls. Not all of the functions may be controlled with
a universal remote control. If you decide to use a universal remote control with this unit, please be aware
that the code number given may not operate this unit. In this case, please call the manufacturer of the universal remote control.
- 6 - EN
Owner’s Manual
(1EMN20215)
Owner's Manual
- 7 - EN
OPERATING CONTROLS AND FUNCTIONS
1 VIDEO input jack– Connect to the Video output
jack of a video camera or VCR.
2 AUDIO input jack– Connect to the Audio output
jack of an audio equipment, video camera or
VCR.
3 POWER button– Hit to turn the unit on and off.
Hit to activate timer recording.
4 VOLUME
XX/YY
buttons– Adjust the volume level.
5 CHANNEL
XX/YY
buttons– Press to select the
desired channels for viewing or recording.
TRACKING function– Press to minimize video
‘noise’ (lines or dots on screen) during playback
mode. (Refer to page 18.)
6 Remote Sensor Window– Receives the infrared
signals from the remote control.
- REMOTE CONTROL -
Y
X
VIDEO AUDIO VOLUMEPOWER
STOP/EJECT
REW PLAY F.FWD REC/OTR
EARPHONE
CHANNEL
Y
X
a
O
b
PN
1 92
3
5 6 7 8
13
10 11
14
12
4
POWER
WAKE-UP
/SLEEP
123
456
789
+100
0
EJECT
CHANNEL
RETURN
REW
PLAY
STOP
F.FWD
GAME
RECORD
PAUSE/STILL
SPEED
TIME SEARCH
CHANNEL
T-PROG.
CLEAR
COUNTER
RESET
DISPLAY MUTE
MENU
VOLUME
3
15
5
27
16
8
19
20
21
22
18
26
4
10
9
24
23
25
17
28
7 STOP/EJECT
PP NN
button– Hit to stop the tape
motion. Hit in the stop mode to remove the
cassette from the unit.
8 REW
bb
button– Hit to rewind the tape or to
view the picture rapidly in reverse during playback mode. (Rewind Search)
ss
button– (Remote control)
•
Hit to select a mode from the setting menu.
9 PLAY
OO
button– Hit to start playback.
K
button– (Remote control)
•
Hit to select a mode or figure from the setting
menu.
10 F.FWD
aa
button– Hit to rapidly advance the
tape or to view the picture rapidly in forward during playback mode. (Forward Search)
B button– (Remote control)
•
Hit to determine your selection and proceed to
the next step in the setting menu.
11
REC/OTR button – Hit to start manual recording.
Hit repeatedly to start One Touch Recording
(OTR).
12 Record indicator– Flashes during recording.
Lights up in the stand-by mode for Timer
Recording.
13 EARPHONE jack– Connects to earphones (not
supplied) for personal listening. The size of jack
is 1/8" (3.5mm) monaural.
14 Cassette compartment
15 Number buttons– Press to select desired chan-
nels for viewing or recording. To select a singledigit channel, hit
[0] first and then [1] to [9].
+100 button– When selecting cable channels
which are higher than 99, hit this button first,
then press the last two digits. (To select channel
125, first hit [+100] button then hit [2] and [5].)
16 MENU button– Hit to enter or exit the setting
menu.
- TV/VCR FRONT PANEL -
This manual covers 13" and 19". The operation of the two models are exactly the same except
the appearance. 19" model is illustrated in this manual.
- 8 - EN
ANT.
29 30
17 DISPLAY button– Hit to display the counter or
the current channel number and current time on
the TV screen. (Refer to page 25.)
18 STOP button– Hit to stop the tape motion.
L
button– (Remote control)
•
Hit to select a mode or figure from
the setting menu.
19 RECORD button– Hit to start manual recording.
20 SPEED button– Hit to choose the desired record-
ing speed:SP/SLP.
21 T- PROG. CLEAR button– Hit to cancel a setting
of timer program. (Refer to page 24.)
COUNTER RESET button– Hit to reset counter to
0:00:00.
22 GAME button– Hit to set the Game mode and
external input mode at the same time. (Refer to
page 11.)
23 TIME SEARCH button– Hit to activate Time
Search mode.
24 PAUSE/STILL F button– Hit to temporarily stop
the tape during the recording or to view a still picture during playback.
25 MUTE button– Hit to mute the sound. Hit it again
to restore the sound.
26 CHANNEL RETURN button– Hit to go back to
the previously viewed channel. Hit again to return
to the present channel.
27 EJECT A button– Hit in the stop mode to remove
the cassette from the unit.
28 WAKE-UP/SLEEP button– Sets the Wake up or
Sleep Timer. (Refer to page 11 or 12.)
29 Power cord– Connect to a standard AC outlet
(120V/60Hz). (Refer to page 10.)
30 ANT(ENNA). jack– Connect to an antenna, cable
system or satellite system. (Refer to page 9.)
INSTALLING THE BATTERIES
1)Open the battery compartment cover by pressing
the cover on the remote unit in the direction of the
arrow.
2)Insert 2 “AA” penlight batteries into the battery
compartment in the direction indicated by the
polarity (+/-) markings.
3)Replace the cover.
[BATTERY PRECAUTIONS]
•
Be sure to follow the correct polarity as indicated
in the battery compartment. Reversed batteries
may cause damage to the device.
•
Do not mix different types of batteries together
(e.g. Alkaline and Carbon-Zinc) or old batteries
with fresh ones.
•
If the device is not to be used for a long period of
time, remove the batteries to prevent damage or
injury from possible battery leakage.
•
Do not try to recharge batteries not intended to be
recharged; they can overheat and rupture.
- REAR VIEW -
- 9 - EN
PREPARATION FOR USE
ANTENNA/CABLE CONNECTIONS
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and in particular, specifies that the cable ground shall be connected to the grounding
system of the building as close to the point of cable entry as practical.
Plug the incoming cable into the ANT. jack on the rear of the unit.
If your cable service supplies you with a converter box or if you use a
satellite system, connect the box with this unit as shown below.
ANT.
Cable
TV signal
Antenna
or
ANT.
IN
OUT
Rod Antenna
(Supplied)
Rod Antenna Connection:
Yo u can use the Rod Antenna
(Supplied) if incoming cable
is not available
.
ANT.
ANT.
NOTE:
Before plugging the antenna into the ANT. jack of the
unit, check that the pin is not bent. If it is bent, straighten
the pin as illustrated, then plug the pin into the ANT.
jack of the unit.
For your safety and to avoid damages to the unit, unplug the antenna cable from the ANT. jack
before moving the unit.
Bent pin
Cable Plug
(Needs to be
straightened)
(Straight pin)
Rear of the unit
*NOTE (DO NOT DISCONNECT FROM BOX)
Some cable TV systems use scrambled signals and
require a special converter to receive these channels.
Consult your local cable company.
OR
Incoming cable from home Antenna /
Cable Company (No Cable Box)
Incoming cable from Cable Company
or Satellite Antenna
Cable Box or
Satellite Box*
- 10 - EN
USING FRONT A/V INPUT JACKS
When you watch a program recorded on another source (VCR or video camera), use the
AUDIO/VIDEO input jacks on the front of the unit.
Connect the Audio/Video output jacks of another source to the AUDIO L/R and VIDEO
jacks of this unit.
Then press [CHANNELKK/LL] until “AUX” appears on the screen.
AUX
TV OPERATION AND SETTINGS
WATCHING A TV PROGRAM
1 Plug in the unit power cord
Plug the unit power cord into a standard
AC outlet.
NOTE:
•
If any digits appear in the corner of the
screen, hit [POWER] without unplugging the power cord.
2 Turn on the unit
Hit [POWER] to turn on the unit.
3 Select the channel number
Press [CHANNELKK/LL] or the Number buttons to
select your desired channel number.
Note for using the Number buttons:
¡You must precede single-digit channel numbers
with a zero (for example: 02, 03, 04 and so on).
¡When selecting cable channels which are higher
than 99, hit [+100] first, then press the last two
digits. (Example: to select channel 125, first hit
[+100] then hit [2] and [5].)
4 Adjust sound
Press [VOLUME XX/YY] to adjust
the volume.
Hit
[MUTE] to instantly mute the
sound.
Hit it again to restore the previous sound level.
TO WATCH CABLE OR SATELLITE
CHANNEL
•
If the unit is connected to a cable box or satellite
box, press [CHANNELKK/LL] to select CH3 or
CH4 according to the output channel setting of the
device and select desired channel on that device.
TO WATCH EXTERNAL INPUT
•
When an external equipment is connected to the
front AUDIO/VIDEO input jacks,
press [CHAN-
NEL
KK/LL
] repeatedly until “AUX” appears on
the screen.
VOLUME 20
C C C C C C C C C C C C
[Front of the unit]
To the Audio output jack
To the Video output jack
(OUT)
(IN)
(OUT)
(IN)
Audio cable
(commercially available)
Video cable (commercially available)
VIDEO AUDIO VOLUMEPOWER
VIDEO AUDIO
X
Y
STOP/EJECT
CHANNEL
X
Y
REW PLAY F.FWD REC/OTR
PN
b
a
O
EARPHONE
ex.
VCR or video camera
, etc.
Loading...
