Operating instructions
RSL wireless wall switch 2 channel
Item no. 1761744
Latest operating instructions
Download the latest operating instructions via the
link www.conrad.com/downloads or scan the QR
code shown. Follow the instructions on the website.
Explanation of symbols
The lightning symbol inside a triangle is used when the-
re is a potential risk of personal injury, such as electric
shock.
An exclamation mark in a triangle indicates important ins-
tructions in this operating manual that absolutely have to
be observed.
The arrow symbol indicates specic tips and advice on
operation.
Delivery content
• RSL wireless wall switch
• Battery 12 V/23 A
• Operating instructions
Intended use
This 2-channel wireless wall switch is designed to turn on and off two
appropriate receivers (e.g. wireless power socket, wireless outdoor
socket, wireless inbuilt switch etc.). In addition, this 2-channel wireless
wall switch has a dimming function (for example, to control a wireless
plug-in dimmer, wireless inbuilt dimmer etc.).
For each control channel, a maximum of 10 receivers can be programmed.
The wireless wall switch is powered by a 12 V battery (type: 23A).
It is intended for indoor use only. Do not use it outdoors. Contact with
moisture, e.g. in bathrooms, must be avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify
this product. If you use the product for purposes other than those
described above, the product may be damaged. In addition, improper
use can cause hazards such as short circuiting, re, electric shock
etc. Read the instructions carefully and keep them. Make this product
available to third parties only together with its operating instructions.
This product complies with the statutory national and European
requirements. All company names and product names are trademarks
of their respective owners. All rights reserved.
Safety instructions
Read the operating instructions carefully and especially observe the safety information. If you do not follow the safety instructions and information on proper
handling in this manual, we assume no liability for any
resulting personal injury or damage to property. Such
cases will invalidate the warranty/guarantee.
a) General
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. This may
become dangerous playing material for children.
• Protect the product from extreme temperatures, direct sunlight,
strong jolts, high humidity, moisture, ammable gases, vapours and
solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of
operation and protect it from any accidental use. Safe operation can
no longer be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions
or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even
from a low height can damage the product.
• Also observe the safety and operating instructions of any other
devices which are connected to the product.
• Check the product for damage before each use! If you notice any
damage, do not use the product any longer! There is a risk of a lifethreatening electric shock!
• Ensure that the insulation for the entire product is neither damaged
nor destroyed. Never disassemble the product! There are no serviceable parts inside.
• Do not use this product in hospitals or medical institutions. Although
the product emits only relatively weak radio signals, these may lead
to the malfunction of life-support systems. The same may also be
the case in other areas.
• Keep the product away from strong magnetic elds occurring near
machines, electric motors or loudspeakers.
• Consult an expert when in doubt about operation, safety or
connection of the device.
• Maintenance, modications and repairs are to be performed
exclusively by an expert or at a qualied shop.
• If you have questions which remain unanswered by these operating
instructions, contact our technical support service or other technical
personnel.
b) Batteries
• Correct polarity must be observed while inserting the battery.
• The battery should be removed from the device if it is not used for
a long period of time to avoid damage through leaking. Leaking or
damaged batteries might cause acid burns when in contact with
skin, therefore use suitable protective gloves to handle corrupted
batteries.
• Batteries must be kept out of reach of children. Do not leave batteries lying around, as there is risk, that children or pets swallow them.
• Batteries must not be dismantled, short-circuited or thrown into
re. Never recharge non-rechargeable batteries. There is a risk of
explosion!
Installation and Connection
The wireless wall switch is only intended for use in
dry indoor locations.
• Carefully lift the front cover of the wireless wall switch (e.g. with a screw
driver) and remove it (see picture on
the right).
• Remove the mounting plate. The
mounting plate for the wireless wall
switch is xed to the electronic part
of the wireless wall switch with 4
clamps (see picture on the right).
• The mounting plate has two mounting holes (see the picture on the
right). Remove the mounting plate
and mark the mounting holes on
the wall.
• Drill the holes.
• Attach the mounting plate to the wall,
using suitable mounting material.
• Attach the electronic part of the wireless wall switch to the mounting
plate.
• Insert a 12V-battery (type: 23A) in
the battery compartment of the wireless wall switch, paying attention to the correct polarity.
• Attach the front plate to the wireless wall switch.
Programming a receiver for the wireless wall
switch
For each control channel, a maximum of 10 receivers can
be programmed.
• Set the receiver to the programming mode. Please follow these operating instructions when so doing.
• Press the desired “I” button on the wireless wall switch to which
the receiver is to be programmed. The programming has been
completed successfully.
Deleting programmed receivers from the wireless
wall switch
• Press the buttons “I” and “O” on the wireless wall switch to which the
receiver is programmed. The LED on the receiver starts ashing.
• Now press the button “O” on the wireless wall switch. The LED on
the receiver goes out. The receiver has now been deleted from the
wireless wall switch.
The wireless wall switch’s dimmer function
• Turn on the dimmer, by briey pressing the “I” button on the wireless
wall switch once.
• Press the “I” button on the wall switch again. The dimmer function
is activated.
• Press the “I” button on the wall switch again. The dimmer function
is deactivated.
Start-up, Function Test
Commission the receiver in the correct way (follow the receiver’s operating instructions).
By pressing the appropriate “I” or “O” button on the wireless wall
switch, the receiver is turned on or off.
Transmission range
• The transmission range of the radio signals between the wireless
wall switch and an appropriate receiver is up to 70 m under optimal
conditions.
This value, however, is the so-called “open space
range” (range the transmitter and receiver are visible
to each other, without interfering influences).
In practical operation, however, there are walls, cei-
lings of rooms etc. between the transmitter and the
receiver, which reduce the range accordingly.
Due to the different influences on the radio transmis-
sion, no specific range can be guaranteed.
However, trouble-free operation is usually possible in
a detached house.
The range can sometimes be limited considerably by:
- Walls, reinforced concrete ceilings
- Coated/metallised insulated glass
- Proximity to metal & conducting objects (e.g. radiators)
- Proximity to human bodies
- Broadband interferences, e.g. in residential areas (DECT telephones, mobile phones, radio-controlled headphones, radiocontrolled speakers, radio-controlled weather stations, baby
phones etc.)
- Proximity to electric motors, transformers, power-supply units,
computers
- The proximity to improperly shielded or uncovered operating
computers or other electric appliances
Care and cleaning
The product does not require any maintenance and
should never be opened or disassembled for any reason.
• Only clean the product with a soft, clean, dry cloth.
• Never use aggressive cleaning agents or chemical solutions
since these might damage the surface of the casing or impair the
operation.
Declaration of Conformity (DOC)
Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau hereby declares that this product conforms to the 2014/53/EU directive.
Click on the following link to read the full text of the EU
declaration of conformity: www.conrad.com/downloads
Select a language by clicking on a ag symbol and enter
the product order number in the search box. You can then
download the EU declaration of conformity in PDF format.
Disposal
a) Product
Electronic devices are recyclable waste and must not be
disposed of in the household waste. At the end of its service life, dispose of the product according to the relevant
statutory regulations.
Remove any inserted batteries and dispose of them sepa-
rately from the product.
b) Batteries
You as the end user are required by law (Battery Ordi-
nance) to return all used batteries. Disposing of them in
the household waste is prohibited.
Contaminated batteries are labelled with this symbol to
indicate that disposal in the domestic waste is forbidden.
The designations for the heavy metals involved are: Cd =
Cadmium, Hg = Mercury, Pb = Lead (name on batteries,
e.g. below the trash icon on the left).
Used batteries can be returned to collection points in your municipality, our stores or wherever batteries are sold.
You thus full your statutory obligations and contribute to the
protection of the environment.
Technical data
Power supply ............................1x 12 V battery, type “23A”
Transmission frequency............433.05 - 434.79 MHz
Range ....................................... max. 70 m
Transmission power..................4.98 dBm
Internal LED .............................. Lights up briey on the use of the
Programmable receiver ............ a maximum of 10 for each control
Operating temperature .............0 to +35 °C
Dimensions (W x H x D) ...........approx. 80 x 80 x 20 mm
Weight ......................................approx. 54 g (excl. batteries)
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240
Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g.
photocopy, microlming, or the capture in electronic data processing systems
require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE. *1761744_V2_0419_02_mxs_m_en
(in open space, see chapter
“Transmission range”)
buttons
channel
