USER MANUAL
Online UPS: Avenger Series
Rack Mount (RM)
120 VAC ‒ 220 VAC
Capacity: 1 KVA ~ 1.5 KVA ~ 2 KVA ~ 3 KVA
REVISION
DESCRIPTION
DATE
Rev. 1.3
Formal Release
2017/02/03
Danger: For your safety
Improper use on this equipment can lead to an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
Warning: Caution
Unsafe practices that could endanger health, safety and cause financial damage.
Important
Any important technical and operating information on the equipment, should not
neglected.
Annotation
Sy-G reserves the right to alter the features of its products without prior notice.
CONTENTS
1. Safety Warning .......................................................................................................................... 2
1.1. Transportation .................................................................................................................... 2
1.2. Preparation .......................................................................................................................... 3
1.3. Installation ........................................................................................................................... 3
1.4. Operation ............................................................................................................................. 4
1.5. Maintenance, service and faults .................................................................................. 4
2. Installation and Setup ............................................................................................................. 5
2.1. Rear Panel View ................................................................................................................. 5
2.2. Operating Principle .......................................................................................................... 6
2.3. Install the UPS ................................................................................................................... 6
2.4. Setup the UPS .................................................................................................................... 7
2.5. Battery Replacement ...................................................................................................... 12
2.6. Battery Kit Assembly……………………………………………………………………………….13
3. Operations ................................................................................................................................ 15
3.1. Button Operation ............................................................................................................ 15
3.2. LCD Panel ........................................................................................................................... 16
3.3. Audible Alarm................................................................................................................... 17
3.4. LCD display wordings index ........................................................................................ 17
3.5. UPS Setting ....................................................................................................................... 18
3.6. Operating Mode Description ...................................................................................... 25
3.7. Faults Reference Code................................................................................................... 26
3.8. Warning indicator ........................................................................................................... 26
4. Troubleshooting ...................................................................................................................... 27
5. Storage and Maintenance ................................................................................................... 29
6. Technical Specifications ....................................................................................................... 30
Page | 2
1. Safety Warning
Please comply with all warnings and operating instructions in this manual strictly. Save
this manual properly and read carefully the following instructions before installing the
unit. Do not operate this unit before reading through all safety information and
operating instructions carefully.
1.1. Transportation
Please transport the UPS system only in the original package to protect against shock
and impact.
1.2. Preparation
o Condensation may occur if the UPS system is moved directly from cold to
warm environment.
The UPS system must be absolutely dry before being installed.
PLEASE ALLOW AT LEAST TWO HOURS FOR THE UPS SYSTEM TO ACCLIMATE THE
ENVIRONMENT.
o Do not install the UPS system near water or in moist environments.
o Do not install the UPS system where it would be exposed to direct sunlight or
near heater.
o Do not block ventilation holes in the UPS housing.
1.3. Installation
o Do not connect appliances or devices which would overload the UPS system
(e.g. laser printers) to the UPS output sockets.
o Place cables in such a way that no one can step on or trip over them.
o Do not connect domestic appliances such as hair dryers to UPS output
sockets.
o The UPS can be operated by any individuals with no previous experience.
o Connect the UPS system only to an earthed shockproof outlet which must be
easily accessible and close to the UPS system.
o Please use only VDE-tested, CE-marked (or UL-marked for
100/110/115/120/127 VAC models) mains cable (e.g. the mains cable of your
Page | 3
computer) to connect the UPS system to the building wiring outlet
(shockproof outlet).
o Please use only VDE-tested, CE-marked (or UL-marked for
100/110/115/120/127 VAC models) power cables to connect the loads to the
UPS system.
o When installing the equipment, it should ensure that the sum of the leakage
current of the UPS and the connected devices does not exceed 3.5mA.
o Temperature Rating - Units are considered acceptable for use in a maximum
ambient of 40 °C (104 °F).
o For Pluggable Equipment - The socket-outlet shall be installed near the
equipment and shall be easily accessible.
1.4. Operation
o Do not disconnect the mains cable on the UPS system or the building wiring
outlet (shockproof socket outlet) during operations since this would cancel the
protective earthing of the UPS system and of all connected loads.
o The UPS system features its own, internal current source (batteries). The UPS
output sockets or output terminals block may be electrically live even if the
UPS system is not connected to the building wiring outlet.
o In order to fully disconnect the UPS system, first press the OFF/Enter button
to disconnect the mains (commercial power).
o Prevent no fluids or other foreign objects from inside of the UPS system.
1.5. Maintenance, service and faults
THE UPS SYSTEM OPERATES WITH HAZARDOUS VOLTAGES. REPAIRS MAY BE
CARRIED OUT ONLY BY QUALIFIED MAINTENANCE PERSONNEL.
o Caution - Risk of electric shock. Even after the unit is disconnected from the
mains (commercial power), components inside the UPS system are still
connected to the battery and electrically live and dangerous.
o Before carrying out any kind of service and/or maintenance, disconnect the
batteries and verify that no current is present and no hazardous voltage exists
in the terminals of high capability capacitor such as BUS-capacitors.
o Only persons are adequately familiar with batteries and with the required
precautionary measures may replace batteries and supervise operations.
Unauthorized persons must be kept well away from the batteries.
o Caution - Risk of electric shock. The battery circuit is not isolated from the
Page | 4
input voltage. Hazardous voltages may occur between the battery terminals
and the ground. Before touching, please verify that no voltage is present!
o Do not dispose of batteries in a fire. The batteries may explode.
o Do not open or mutilate batteries. Released electrolyte is harmful to the skin
and eyes. It may be toxic.
o Batteries may cause electric shock and have a high short-circuit current.
Please take the precautionary measures specified below and any other measures
necessary when working with batteries:
1) Remove watches, rings, or other metal objects.
2) Use tools with insulated handles.
3) Wear rubber gloves and boots.
4) Do not lay tools or metal parts on top of batteries.
5) Disconnect charging source and load prior to installing or
maintaining the battery.
6) Remove battery grounds during installation and maintenance to
reduce likelihood of shock.
7) Remove the connection from ground if any part of the battery is
determined to be grounded.
o When changing batteries, install the same number and same type of batteries
or battery packs.
For UPS with internal mounting Batteries
o Instructions shall carry sufficient information to enable the replacement of the
battery with a suitable manufacturer and catalogue number.
o Safety instructions to allow access by Service Personnel shall be stated in the
installation/service handbook.
o If batteries are to be installed by Service Personnel, instructions for
interconnections, including terminal torque, shall be provided.
o Do not attempt to dispose of batteries by burning them. This could cause
battery explosion.
o Do not open or destroy batteries. Escaping electrolyte can cause injury to the
skin and eyes. It may be toxic.
o Please replace the fuse only with the same type and amperage in order to
avoid fire hazards.
o Do not dismantle the UPS system.
Page | 5
2. Installation and Setup
Before installation, please inspect the unit. Be sure that nothing inside the
package is damaged. Please keep the original package in a safe place for future use.
There are two different types of connector for the UPS (In and Out) online. Please
see the following model table.
2.1. Rear Panel View
Description UPS
Programmable outlets: connect to
non-critical loads.
RS-232 communication port.
Output receptacles: connect to
mission-critical loads.
SNMP intelligent slot.
AC input
Emergency power off function
connector (EPO).
Network/Fax/Modem surge
protection.
External battery connection.
USB communication port.
Page | 6
2.2. Operating principle
The operating principle of the UPS is show as below:
EMI/RFI
Filters
Battery
Charger
Battery
DC-to-DC
Converter
Inverter
Rectifier
/PFC
Input
Output
The UPS is composed of mains input,
EMI/RFI filters, rectifier/PFC,
inverter, battery charger, DC-to-DC
converter, battery, dynamic bypass and
UPS output.
Dynamic
Bypass
The UPS is composed of mains input, EMI/RFI filters, rectifier/PFC, inverter, battery
charger, DC-to-DC convert, battery, dynamic bypass and UPS output.
2.3. Install the UPS
For safety consideration, the UPS is shipped out from factory without connecting battery
wires. Before install the UPS, please follow below steps to re-connect battery wires first.
STEP 1
STEP 2
STEP 3
Remove front panel.
Connect the AC input and re-
connect battery wires.
Put the front panel back to the
unit.
Page | 7
Rack mount installation
Stand alone installation
2.4. Setup the UPS
Before installing the UPS, please read below to select proper location
to install UPS.
1. UPS should be placed on the flat and clean surface. Place it in an area away from
vibration, dust, humidity, high temperature, flammable liquids, gases, corrosive and
conductive contaminants. Install the UPS indoors in a clean environment, where it is
away from window and door. Maintain minimum clearance of 100mm in the bottom
of the UPS to avoid dust and high temperature.
Page | 8
2. Maintain an ambient temperature range of 0 ºC to 45 ºC for UPS optimal operation.
For every 5ºC above 45ºC, the UPS will derate 12% of nominal capacity at full load.
The highest working temperature requirement for UPS operation is 50 ºC.
3. It is necessary to maintain a maximum altitude of 1.000 meters to maintain normal
operation of the UPS at full load. If used in high altitude areas, reduce the connected
load. The decrease of the energy with respect to the altitude are describe below:
ALTITUDE (m)
Derating factor
[1]
1.000
1.500
2.000
2.500
3.000
3.500
4.000
4.500
5.000
1.0
0.95
0.91
0.86
0.82
0.78
0.74
0.7
0.67
Based on density of dry air = 1.225 kg/m3 at sea-level +15 °C.
[1] – Since fans lose efficiency with altitude, forced air-cooled equipment will have a smaller derating.
4. Place UPS:
The equipment has a fan for cooling. Therefore, place the UPS in a wellventilated area. It’s required to maintain minimum clearance of 100mm in
the front of the UPS and 300mm in the back and two sides of the UPS for
heat dissipation and easy-maintenance.
Page | 9
5. Connect to External Battery Pack
When connecting external battery packs, please be sure to connect polarity correctly.
Connect positive pole of battery pack to positive pole of external battery connector in
UPS and negative pole of battery pack to negative pole of external battery connector in
UPS. Reversing the polarity will cause UPS internal fault. It’s recommended to add
one breaker between positive pole of battery pack and positive pole of external battery
connector in UPS to prevent damage to battery packs from internal fault.
The required specification of breaker: voltage ≧ 1.25 x battery voltage/set; current ≧ 50A
Please choose battery size and connected numbers according to backup time
requirement and UPS specifications. To extend battery lifecycle, it’s recommended to
use them in the temperature range of 15 ºC to 25 ºC.
Step 1: External battery connection
Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using
extension cords.
o For 200/208/220/230/240 VAC models: The power cord is supplied in
the UPS package.
o For 100/110/115/120/127 VAC models: The power cord is attached to
the UPS.
The input plug is a NEMA 5-15P for 1 KVA and 1.5 KVA models, NEMA 5-20P for 2
KVA model and NEMA 5-30P for 3KVA model.
NOTE: Check if the site wiring fault indicator lights up in LCD panel. It will be illuminated
when the UPS is plugged into an improperly wired utility power outlet (Refer to
Troubleshooting section). Please also check if there is a circuit breaker against over
current and short circuit between the mains and AC input of the UPS for safety
operation. The recommended protection value as following:
Page | 10
o For 200/208/220/230/240 VAC models: 10A for the 1KVA and 1.5KVA
models, 16A for the 2KVA and 3KVA models.
o For 100/110/115/120/127 VAC models: 15A for the 1K and 1.5K
models, 20A for 2K model and 30A for 3K model.
Step 2: UPS input connection
There two kinds of outputs: programmable outlets and general outlets. Please
connect non-critical devices to the programmable outlets and critical devices
to the general outlets.
During power failure, you may extend the backup time to critical devices by
setting shorter backup time for non-critical devices.
Step 3: Communication connection
Communication Ports
USB
RS-232
Intelligent
To allow for unattended UPS shutdown/start-up and status monitoring, connect
the communication cable one end to the USB/RS-232 port and the other to the
communication port of your PC. With the monitoring software installed, you can
schedule UPS shutdown/start-up and monitor UPS status through PC.
The UPS is equipped with intelligent slot perfect for either SNMP or AS400 card.
When installing either SNMP or AS400 card in the UPS, it will provide advanced
communication and monitoring options.
Step 4: Network connection
Network (IN)
Fax
Phone surge port (OUT)
Connect a single modem/phone/fax line into surge-protected “IN” outlet on the
back panel of the UPS unit. Connect from “OUT” outlet to the equipment with
another modem/fax/phone line cable.
Page | 11
Step 5: Disable and enable EPO function
This UPS is equipped with EPO function. By default, the UPS is delivered from
factory with PIN 1 and PIN 2 closed (a metal plate is connected to PIN 1 and
PIN 2) for UPS normal operation. To activate EPO function, remove two screws
on EPO port and metal plate will be removed.
NOTE: The EPO function logic can be set up via LCD setting. Please refer to program 16
in UPS setting for the details.
Step 6: Turn on the UPS
Press the ON/Mute button on the front panel for two seconds to power on the
UPS.
NOTE: The battery charges fully during the first five hours of normal operation. Do not
expect full battery run capability during this initial charge period.
Step 7: Install software
For optimal computer system protection, install UPS monitoring software to fully
configure UPS shutdown. Use supplied RS-232 or USB communication cable to
connect RS-232/USB port of UPS and RS-232/USB port of PC. Then, follow
below steps to install monitoring software.
1. Insert the included installation CD into CD-ROM drive and then follow the on-
screen instructions to proceed software installation. If there no screen shows 1
minute after inserting the CD, please execute setup.exe file for initiating
software installation.
2. Follow the on-screen instructions to install the software.
3. When your computer restarts, the monitoring software will appear as an
orange plug icon located in the system tray, near the clock.
Page | 12
2.5. Battery Replacement
NOTICE: This UPS is equipped with internal batteries and user can replace the
batteries without shutting down the UPS or connected loads. (Hot-swappable
battery design) Replacement is a safe procedure, isolated from electrical hazards.
NOTE: Upon battery disconnection, equipment is not protected from power outages.
CAUTION!! Consider all warnings, cautions, and notes before replacing batteries.
Page | 13
2.6. Battery kit Assembly (OPTIONAL)
NOTICE: Please assemble battery kit first before installing it inside of UPS.
Please select correct battery kit procedure below to assemble it.
Battery Kit - 2 Units
Battery Kit - 3 Units
Page | 14
Battery Kit - 4 Units
Battery Kit - 6 Units
Page | 15
3. Operations
3.1. Button Operation
BUTTON
FUNCTION
ON/Mute
Button
o Turn on the UPS: Press and hold ON/Mute button for at least 2
seconds to turn on the UPS.
o Mute the alarm: After the UPS is turned on in battery mode, press and
hold this button for at least 3 seconds to disable or enable the alarm
system. But it is not applied to the situations when warnings or errors
occur.
o Up key: Press this button to display previous selection in UPS setting
mode.
o Switch to UPS self-test mode: Press ON/Mute buttons for 3 seconds
to enter UPS self-testing while in AC mode, ECO mode, or converter
mode.
OFF/Enter
Button
o Turn off the UPS: Press and hold this button at least 2 seconds to turn
off the UPS. UPS will be in standby mode under power normal or
transfer to bypass mode if the bypass enable setting by pressing this
button.
o Confirm selection key: Press this button to confirm selection in UPS
setting mode.
Select
Button
o Switch LCD message: Press this button to change the LCD message for
input voltage, input frequency, input current, battery voltage, battery
current, battery capacity, ambient temperature, output voltage, output
frequency, load current and load percent.
o Setting mode: Press and hold this button for 3 seconds to enter UPS
setting mode when Standby and Bypass mode.
o Down key: Press this button to display next selection in UPS setting
mode.
ON/Mute +
Select
Button
o Switch to bypass mode: When the main power is normal, press
ON/Mute and Select buttons simultaneously for 3 seconds. Then
UPS will enter to bypass mode. This action will be ineffective when the
input voltage is out of acceptable range.
o Exit setting mode or return to the upper menu: When working in
setting mode, press ON/Mute and Select buttons simultaneously for
0.2 seconds to return to the upper menu. If it’s already in top menu,
press these two buttons at the same time to exit the setting mode.
Page | 16
3.2. LCD Panel
DISPLAY
FUNCTION
Backup time information
Indicates the estimated backup time.
H: hours, M: minute, S: second.
Configuration and fault information
Indicates the configuration items, and the configuration
items are listed in details in section 3-5.
Indicates the warning and fault codes, and the codes are
listed in details in section 3-7 and 3-8.
Mute operation
Indicates that the UPS alarm is disabled.
Input, Battery, Temperature, Output & Load information
Indicate the input voltage, input frequency, input current,
battery voltage, battery current, battery capacity, ambient
temperature, output voltage, output frequency, load
current and load percent.
k: kilo, W: watt, V: voltage, A: ampere, %: percent, ℃ :
centigrade degree, Hz: frequency
Load information
Indicates the load level by 0-24%, 25-49%, 50-74% and
75-100%.
Indicates overload.
Programmable outlets information
Indicates that programmable management outlets are
working.
Mode operation information
Indicates the UPS connects to the mains.
Indicates the battery is working.
Indicates charging status
Indicates the bypass circuit is working.
Indicates the ECO mode is enabled.
Page | 17
Indicates the AC to DC circuit is working.
Indicates the PFC circuit is working.
Indicates the inverter circuit is working.
Indicates the UPS is working in converter mode.
Indicates the output is working.
Battery information
Indicates the battery level by 0-24%, 25-49%, 50-74%,
and 75-100%.
Indicates low battery.
3.3. Audible Alarm
Battery Mode
Sounding every 5 seconds.
Low Battery
Sounding every 2 seconds.
Overload
Sounding every second.
Fault
Continuously sounding.
Bypass Mode
Sounding every 10 seconds.
3.4. LCD display wordings index
ABBREVIATION
DISPLAY CONTENT
MEANING
ENA
Enable
DIS
Disable
ESC
Escape
HLS
High loss
LLS
Low loss
AO
Active open
AC
Active close
EAT
Estimated autonomy time
RAT
Running autonomy time
OK
OK
ON
ON
BL
Battery Low
OL
Over Load
OI
Over input current
NC
Battery No Connect
Page | 18
OC
Over Charge
SF
Site wiring fault
EP
EPO
TP
Temperature
CH
Charger
BF
Battery Fault
BV
Bypass Out Range
FU
Bypass frequency unstable
BR
Battery Replace
EE
EEPROM error
3.5. UPS Setting
Parameter 1: It’s for program alternatives. Refer to below table.
Parameter 2 is the setting options or values for each program.
Parameter 1
Parameter 2
01: Output voltage setting.
INTERFACE
SETTING
Parameter 2: Output voltage
For 200/208/220/230/240 VAC models, you may choose
the following output voltage:
200: presents output voltage is 200Vac.
208: presents output voltage is 208Vac.
220: presents output voltage is 220Vac.
230: presents output voltage is 230Vac (Default).
240: presents output voltage is 240Vac.
For 100/110/115/120/127 VAC models, you may choose
the following output voltage:
100: presents output voltage is 100Vac.
110: presents output voltage is 110Vac.
115: presents output voltage is 115Vac.
120: presents output voltage is 120Vac (Default).
127: presents output voltage is 127Vac.
Page | 19
02: Frequency Converter enable/disable.
INTERFACE
SETTING
Parameter 2: Enable or disable converter mode.
CF ENA: Converter modes enable.
CF DIS: Converter mode disable (Default).
03: Output frequency setting.
INTERFACE
SETTING
Parameter 2: Output frequency setting.
You may set the initial frequency on battery mode:
BAT 50: presents output frequency is 50Hz.
BAT 60: presents output frequency is 60Hz.
If converter mode enable, you may choose the
following output frequency:
CF 50: presents output frequency is 50Hz.
CF 60: presents output frequency is 60Hz.
04: ECO enable/disable.
INTERFACE SETTING
Parameter 2: Enable or disable ECO function.
ENA: ECO mode enable.
DIS: ECO mode disable (Default).
05: ECO voltage range setting.
INTERFACE SETTING
Parameter 2: Set the acceptable high voltage point
and low voltage point for ECO mode.
Press the Down key or Up key.
HLS: High loss voltage in ECO mode.
For 200/208/220/230/240 VAC models, the setting
range are from +7V to +24V of the nominal voltage
(Default: +12V).
Page | 20
For 100/110/115/120/127 VAC models, the setting
range is from +3V to +12V of the nominal voltage
(Default: +6V).
LLS: Low loss voltage in ECO mode.
For 200/208/220/230/240 VAC models, the setting
range is from -7V to -24V of the nominal voltage.
(Default: +12V).
For 100/110/115/120/127 VAC models, the setting
range is from -3V to -12V of the nominal voltage
(Default: -6V).
06: Bypass mode enable/disable.
INTERFACE
SETTING
Parameter2: Enable or disable Bypass function.
ENA: Bypass mode enable.
DIS: Bypass mode disable (Default).
07: Bypass voltage range setting.
INTERFACE SETTING
Parameter2: Set the acceptable high voltage point
and acceptable low voltage.
Press the Down key or Up key to set.
HLS: Bypass high voltage point.
For 200/208/220/230/240 VAC models:
230-264: setting the high voltage point from
230Vac to 264Vac (Default: 264Vac).
For 100/110/115/120/127 VAC models:
120-140: setting the high voltage point from
115Vac to 132Vac (Default: 132Vac).
LLS: Bypass low voltage point.
For 200/208/220/230/240 VAC models:
170-220: setting the low voltage point from
170Vac to 220Vac (Default: 170Vac).
For 100/110/115/120/127 VAC models:
85-115: setting the high voltage point from
85Vac to 115Vac (Default: 85Vac).
Page | 21
08: Bypass frequency range setting.
INTERFACE SETTING
Parameter 2: Set the acceptable high frequency
point and acceptable low frequency point for
Bypass mode.
By pressing the Down key or Up key.
HLS: Bypass high frequency point
For 50Hz output frequency models:
51-55Hz: setting the frequency high loss point
from 51Hz to 55HZ (Default: 53.0Hz)
For 60Hz output frequency models:
61-65Hz: setting the frequency high loss point
from 61Hz to 65Hz (Default: 63.0Hz)
LLS: Bypass low Frequency point
For 50Hz output frequency models:
45-49Hz: setting the frequency low loss point from
45Hz to 49HZ (Default: 47.0Hz)
For 60Hz output frequency models:
55-59Hz: setting the frequency low loss point from
55Hz to 59Hz (Default: 57.0Hz)
09: Programmable outlets enable/disable
INTERFACE SETTING
Parameter 2: Enable or disable programmable
outlets.
ENA: Programmable outlets enable.
DIS: Programmable outlets disable (Default)
10: Programmable outlets setting
INTERFACE SETTING
Parameter 2: Set up backup time limits for
programmable outlets.
0-999: setting the backup time limits in minutes
from 0-999 for programmable outlets which
connect to non-critical devices on battery mode.
(Default: 999)
Page | 22
11: Autonomy limitation setting
INTERFACE SETTING
Parameter 2: Set up backup time on battery mode
for general outlets.
0-999: setting the backup time in minutes from 0-
999 for general outlets on battery mode.
DIS: Disable the autonomy limitation and the
backup time will depend on battery
capacity. (Default)
NOTE: When setting as “0”, the backup time will be
only 10 seconds.
12: Battery total AH setting
INTERFACE SETTING
Parameter 2: Set up the battery total AH of the UPS.
7-999: setting the battery total capacity from 7-999
in AH.
Please set the correct battery total capacity if external
battery bank is connected.
13: Maximum current setting
INTERFACE SETTING
Parameter 2: Set up the charger maximum current.
For low voltage model with 24/36/48 VDC
1/2/4/6/8: setting the charger maximum current.
1/2/4/6/8 in Ampere. (Default: 2A)
For low voltage and high voltage model with 72/96 VDC
1/2/4/6/8 setting the charger maximum current.
1/2/4/6/8 in Ampere. (Default: 2A)
NOTE: Please set the appropriate charger current
based on battery capacity used. The recommended
charging current is 0.1C~0.3C of battery capacity as
following table for reference:
Page | 23
Battery capacity(AH)
Total charging current (A)
7~20
2
20~40
4
40~60
6
60~80
8
80~100
10
100~150
12
14: Charger Boost voltage setting
INTERFACE SETTING
Parameter 2: Set up the charger boost voltage.
2.25-2.40: setting the charger boost voltage from
2.25 V/cell to 2.40V/cell. (Default:
2.36V/cell)
15: Charger Float voltage setting
INTERFACE SETTING
Parameter 2: Set up the charger float voltage.
2.20-2.33: setting the charger float voltage
from 2.20 V/cell to 2.33V/cell. (Default:
2.28V/cell)
16: EPO logic setting
INTERFACE SETTING
Parameter 2: Set EPO function control logic.
AO: Active Open (Default).
When AO is selected as EPO logic, it will activate EPO
function with PIN 1 and PIN 2 in open status.
AC: Active Close.
When AC is selected as EPO logic, it will activate EPO
function with PIN 1 and PIN 2 in close status.
Page | 24
17: External output isolation transformer connection
INTERFACE SETTING
Parameter 2: Allow or disallow external output
isolation transformer connection.
AO: Active Open (Default).
ENA: If selected, It’s allowed to connect to an
external output isolation transformer.
DIS: If selected, (Default) It’s not allowed to
connect to external output isolation
transformer.
18: Display setting for autonomy time
INTERFACE SETTING
Parameter 2: Set up the display setting for
autonomy time.
EAT: If EAT is selected, (Default)
It will display the remaining autonomy
time.
RAT: If RAT is selected, It will show
accumulated autonomy time so far.
19: Acceptable input voltage range setting
INTERFACE SETTING
Parameter 2: Set the acceptable high voltage point
and acceptable low voltage.
By pressing the Down key or Up key.
HLS: Input high voltage point
For 200/208/220/230/240 VAC models:
280/290/300: setting the high voltage point in
parameter 2. (Default: 300Vac)
For 100/110/115/120/127 VAC models:
140/145/150: setting the high voltage point in
parameter 2. (Default: 150Vac)
LLS: Bypass low voltage point
For 200/208/220/230/240 VAC models:
110/120/130/140/150/160: setting the low voltage
point in parameter 2. (Default: 110Vac)
For 100/110/115/120/127 VAC models:
55/60/65/70/75/80: setting the low voltage point
in parameter 2. (Default: 55Vac)
Page | 25
00: Exit setting
INTERFACE
SETTING
Exit the setting mode.
3.6. Operating Mode Description
OPERATING MODE
DESCRIPTION
LCD DISPLAY
Online mode
When the input voltage is within acceptable
range, UPS will provide pure and stable AC
power to output. The UPS will also charge
the battery at online mode.
ECO mode
Energy saving mode:
When the input voltage is within voltage
regulation range, UPS will bypass voltage to
output for energy saving. The UPS will also
charge the battery at ECO mode.
Frequency
Converter mode
When input frequency is within 40 Hz to 70
Hz, the UPS can be set at a constant output
frequency, 50 Hz or 60 Hz. The UPS will still
charge battery under this mode.
Battery mode
When the input voltage is beyond the
acceptable range or power failure, the UPS
will backup power from battery and alarm is
sounding every 5 seconds.
Standby mode
UPS is powered off and no output supply
power, but still can charge batteries.
Fault mode
When a fault has occurred, the ERROR icon
and the fault code will be displayed.
Page | 26
3.7. Faults Reference Code
FAULT EVENT
FAULT
CODE
ICON
FAULT EVENT
FAULT
CODE
ICON
Bus start fail
01
x
Battery voltage too high
27
x
Bus over
02
x
Battery voltage too low
28
x
Bus under
03
x
Charger output short
2A
x
Inverter soft start fail
11
x
Over temperature
41
x
Inverter voltage high
12
x
Overload
43
Inverter voltage Low
13
x
Charger failure
45
x
Inverter output short
14
x
Over input current
49
x
3.8. Warning indicator
WARNING
ICON (FLASHING)
CODE
ALARM
Low Battery
Sounding every 2 seconds
Overload
Sounding every second
Over input current
Sounding 2 beep every 10 seconds
Battery is not connected
Sounding every 2 seconds
Over Charge
Sounding every 2 seconds
Site wiring fault
Sounding every 2 seconds
EPO enable
Sounding every 2 seconds
Over temperature
Sounding every 2 seconds
Charger failure
Sounding every 2 seconds
Battery fault
Sounding every 2 seconds (At this
time, UPS is off to remind users
something wrong with battery)
Out of bypass voltage range
Sounding every 2 seconds
Bypass frequency unstable
Sounding every 2 seconds
Battery replacement
Sounding every 2 seconds
EEPROM error
Sounding every 2 seconds
NOTE: “SITE WIRING FAULT” function can be enabled/disable via software.
Page | 27
4. Troubleshooting
If the UPS system does not operate correctly, please solve the problem by using the
table below.
SYMPTOM
POSSIBLE CAUSE
REMEDY
No indication and alarm even
though the mains are normal.
The AC input power is not
connected well.
Check if input power cord
firmly connected to the
mains.
The AC input is connected
to the UPS output.
Plug AC input power cord
to AC input correctly.
The icon and the warning code
flashing on LCD display and
alarm is sounding every 2 seconds.
EPO function is activated.
Set the circuit in closed
position to disable EPO
function.
The icon , and the
warning code flashing on LCD
display and alarm is sounding every
2 seconds.
Line and neutral
conductors of UPS input
are reversed.
Rotate mains power socket
by 180° and then connect
to UPS system.
The icon , and the
warning code flashing on LCD
display and alarm is sounding every
2 seconds.
The external or internal
battery is incorrectly
connected.
Check if all batteries are
connected well.
Fault code is shown as 27 on LCD
display and alarm is continuously
sounding.
Battery voltage is too high
or the charger is fault.
Contact your dealer.
Fault code is shown as 28 on LCD
display and alarm is continuously
sounding.
Battery voltage is too low
or the charger is fault.
Contact your dealer.
The icon , and the warning
code flashing on LCD display
and alarm is sounding every
second.
UPS is overload
Remove excess loads from
UPS output.
UPS is overloaded.
Devices connected to the
UPS are fed directly by the
electrical network via the
Bypass.
Remove excess loads from
UPS output.
After repetitive overloads,
the UPS is locked in the
Bypass mode. Connected
devices are fed directly by
the mains.
Remove excess loads from
UPS output first. Then shut
down the UPS and restart
it.
Fault code is shown as 49 on LCD
display and alarm is continuously
sounding.
UPS is over input current.
Remove excess loads from
UPS output.
Page | 28
Fault code is shown as 43 and the
icon is lighting on LCD display.
Alarm is continuously sounding.
The UPS shut down
automatically because of
overload at the UPS
output.
Remove excess loads from
UPS output and restart it.
SYMPTOM
POSSIBLE CAUSE
REMEDY
Fault code is shown as 14 on
LCD display and alarm is
continuously sounding.
The UPS shut down
automatically because
short circuit occurs on the
UPS output.
Check output wiring and if
connected devices are in
short circuit status.
Fault code is shown as 01, 02, 03,
11, 12, 13 and 41 on LCD display
and alarm is continuously
sounding.
A UPS internal fault has
occurred. There are two
possible results:
1. The load is still supplied,
but directly from AC power
via bypass.
2. The load is no longer
supplied by power.
Contact your dealer
Battery backup time is shorter
than nominal value.
Batteries are not fully
charged
Charge the batteries for at
least 5 hours and then
check capacity. If the
problem still persists,
consult your dealer.
Batteries defect
Contact your dealer to
replace the battery.
Fault code is shown as 2A on
LCD display and alarm is
continuously sounding.
The short circuit occurs on
the charger output.
Check if battery wiring of
connected external pack is
in short circuit status.
Fault code is shown as 45 on
LCD display. At the same time,
alarm is continuously sounding.
The charger does not have
output and battery voltage
is less than 10V/PC.
Contact your dealer.
Page | 29
5. Storage and Maintenance
Operation
The UPS system contains no user-serviceable parts. If the battery service life (3~5 years
at 25°C ambient temperature) has been exceeded, the batteries must be replaced. In this
case, please contact your dealer.
Storage
Before storing, charge the UPS 5 hours. Store the UPS covered and upright in a cool, dry
location. During storage, recharge the battery in accordance with the following table:
STORAGE TEMPERATURE
RECHARGE FREQUENCY
CHARGING DURATION
-25°C - 40°C
Every 3 months
1-2 hours
40°C - 45°C
Every 2 months
1-2 hours
BE SURE TO DELIVER THE SPENT BATTERY TO A RECYCLING FACILITY OR SHIP IT
TO YOUR DEALER IN THE REPLACEMENT BATTERY PACKING MATERIAL.
Page | 30
6. Technical Specifications
MODEL 1.5 KVA 3 KVA
Phase
Capacity
[1]
1500 VA / 1500 W 3000 VA/3000 W
Nominal Voltage
Frequency Range
Power Factor
Harmonic Distortion (THDi)
Rectifier
Output Voltage
AC Voltage Regulation (Batt. Mode)
Frequency Range (Synchronized Range)
Frequency Range (Batt. Mode)
Current Crest Ratio
Harmonic Distortion (THDv)
Transfer Time
Waveform
AC Modo
ECO Mode
Battery Mode
Battery Type 12 V / 9 Ah 12 V / 7 Ah 12 V / 9 Ah 12 V / 9 Ah 12 V / 7 Ah 12 V / 9 Ah
Numbers 2 3 3 4 6 6
Typical Recharge Time
Charging Voltage 27.4 VDC ± 1% 41.1 VDC ±1% 41.1 VDC ± 1% 54.8 VDC ± 1% 82.1 VDC ± 1% 82.1 VDC ± 1%
LCD Display
Battery Mode
Low Battery
Overload
Fault
Dimensions (DxWxH) (mm) 410 x 438 x 88 510 x 438 x 88 630 x 438 x 88 630 x 438 x 88
Net Weight (without battery) (kg) 6.6 7.8 8.1 9.4 10.6 12.4
Net Weight (w/built-int battery) (kg) 11.6 14.1 15.5 19.5 23.3 27.5
Running Humidity & Temperature
Noise Level
Smart RS-232 /USB
Optional SNMP
Quality
Compliance
ENVIRONMENT
MANAGEMENT
STANDARDS & CERTIFICATIONS
EFFICIENCY
BATTERY
INDICATORS
PHYSICAL
ALARM
Sounding every 2 seconds
Sounding every second
Continuously sounding
Charging Current
Default 2 A; max. 8A adjustable
UPS status, Load level, Battery level, Input/Output voltage, Discharge timer, and Fault conditions
410 x 438 x 88
20 - 90 % RH (Non-condensing) @ 0 - 40°C
Zero (AC to DC) ; 4 ms (Inverter to Bypass)
100/110/115/120/127 VAC models: default 2A, max. 8A adjustable
200/208/220/230/240 VAC models: default 2A, max. 12A adjustable
Pure Sine Wave
≥ 89% @ full charged battery
≥ 91% @ full charged battery
≥ 96 % @ full charged battery
≥ 88%
Sounding every 5 seconds
Voltage Range
Single phase with ground
1000 VA / 1000 W
2000 VA / 2000 W
100/110/115/120/127 VAC or 200/208/220/230/240 VAC
55-150 VAC ± 5% or 110-300 VAC ± 5% @ 50% load
80-150 VAC ± 5% or 160-300 VAC ± 5% @ 100% load
INPUT
< 50 dB @ 1 meter
Supports Windows® 2000/2003/XP/Vista/2008, Windows®7/8, Linux, Unix and MAC
Power management from SNMP manager and web browser
SY-G reserves the right to change or modify product design, construction, specifications, or materials without prior notice and without incurring any obligation to make such changes and modifications on SY-G products
previously or subsequently sold.
[1] - Derate capacity to 80% when the output voltage is adjusted to 100VAC/200VAC/208VAC.
ISO 9001 ; ISO 14001
EMC, EN62040-2 C1, EN62040-2 C2
40 Hz - 70 Hz
3:1 (max)
3 hours recover to 95% capacity for internal battery @ 2A charging current
1 KVA
≥ 0.99 @ full load
≤ 5%
IGBT
≥ 90%
± 1%
57-63 Hz or 47-53 Hz
60 Hz ± 0.1 Hz or 50 Hz ± 0.1 Hz
≤ 2% THD (Linear Load) , ≤ 4% THD (Non-linear Load)
2 KVA
100
[1]
/110
[1]
/115
[1]
/120/127 VAC or 200
[1]
/208
[1]
/220/230/240 VAC
OUTPUT
Loading...
