PPOC-4010
Push to Talk over cellular
Two-way Radio
Instruction Manual
THANKS
Indicator display
Current state of charge
Red light
Charging
Green light
End of charging
Thank you for choosing Syco poc radio, we believe it is a wise choice to choose us because we have
the latest technology, the most stable components, the most advanced production technology, Syco
radio will provide you with the reliable performance and high quality you demand.
This user manual apply to: Syco PPOC-4010
ACCESSORIES
FIRST USE
To prevent damage and to comply with the warranty, be sure to charge the battery with a original
charger. Put the radio or battery into the charging stand to charge.
Charger indicator status:
USB charging: This charging method can only be charged when the power is turned on. Note: If the
battery is exhausted(cannot be turned on), it will not be charged.
Installing/removing battery: Press the battery bump on the aluminium housing card slot and press the
battery; when removing the battery, first turn off the radio. Then press the release latch and remove
the battery pack from the transceiver.
Mounting antenna: Hold the antenna base and screw the antenna clockwise into the connector on the
top of the radio until it is tight.
Mounting/removing the belt clip: Use two screws to lock the belt clip. Remove screws to remove belt
clip.
KEY OPERATIONS
Key
Operations
SK1
Long Press: Lock the radio, Short Press: Display
On/Off
PTT
Transmit button
SK2
Programmable button (short/long press)
SK3
Programmable button (short/long press)
Confirm
Confirm change/ Selection in Menu input
Knob
Turn Left/Right: Volume Adjustment
Long Press: Power On/Off
Back
Back to previous UI/Function
Left/Right/Up/Down
Select in Menu
Red key
Long Press: Settings menu
Short Press: Back to Group
TK1
SOS button (if programmed)
SK1
PTT
SK2
SK3
Confirm
Back
Long Press: Settings
TK1
Long Press: Power On/Off
Turn: Volume adjustment
You can program some functions and the programmable buttons by the SycoPTT programming
software.
Check www.syco.eu/ptt to get latest CPS version.
RADIO INSTRUCTION
Function
Operation
Network set
Check network SIM-card information. APN, Preferred network, data roaming
WLAN
Check/Set Wifi (Connect, available, on/off)
BT
Bluetooth
Location
Location on/off (enable/disable GPS, privacy)
Sound
Modify power on/off sound (enable/disable)
Phone state
Check mmodel version, RSSI
Base on Public Network, Android system and traditional portable radio structure, Syco high-tier PoC
radio PPOC-4010 presents top quality, comprehensive application solutions.
Features
Professional structure with easy operation
Support internal, external Bluetooth
GPS positioning, support text information
Map, Tracking
2G/3G/4G/Wifi network
SMS group sending, recording
2.0” display with full keypad
Globally communication
IP67 Dustproof/Waterproof
ANDROID SYSTEM SETTINGS
Long press the red key to enter the settings menu
