Sybase PATRIOTcompliance Solution User Manual

Upgrade Guide

PATRIOTcompliance Solution

Version 2.2

DOCUMENT ID: DC00148-01-0220-01 LAST REVISED: August 2004

Information in this document is subject to change without notice. The software described herein is furnished under a license agreement, and it may be used or copied only in accordance with the terms of that agreement.

To order additional documents, U.S. and Canadian customers should call Customer Fulfillment at (800) 685-8225, fax (617) 229-9845. Customers in other countries with a U.S. license agreement ma y co ntac t Customer Fulfillment via the above fax number. All other

international customers should contact their S ybase subsidiary or local distributor. Upgrades are provided only at regularly scheduled software release dates. No part of this publication may be reproduced, transmitted, or translated in any form or by any means, electronic, mechanical, manual, optical, or otherwise, without the prior written permission of Sybase, Inc.

Sybase, the Sybase logo, AccelaTrade, ADA Workbench, Adaptable Windowing Environment, Adaptive Component Architecture, Adaptive Server, Adaptive Server Anywhere, Adaptive Server Enterprise, Adaptive Server Enterprise Monitor, Adaptive Server Enterprise Replication, Adaptive Server Everywhere, Adaptive Server IQ, Adaptive W arehouse, Anywhere Studio, Application Manager, AppModeler, AP T W orkbench, APT-Build, APT -Edit, AP T -Execute, APT-Translator, AP T -Library , Backup Server, BizTracker , ClearConnect, Client-Library, Client Services, Convoy/DM, Copernicus, Data Pipeline, Data Workbench, DataArchitect, Database Analyzer, DataExpress, DataServer, DataWi ndow, DataWindow.NET , DB-Library, dbQueue, Developers Workbench, Direct Connect Anywhere, DirectConnect, Distribution Director, e-ADK, E-Anywhere, e-Biz Impact, e-Biz Integrator, E-Whatever, EC Gateway, ECMAP, ECRTP, eFulfillment Accelerator, Embedded SQL, EMS, Enterprise Application Studio, Enterprise Client/Server, Enterprise Connect, Enterprise Data Studio, Enterprise Manager, Enterprise SQL Server Manager, Enterprise Work Architecture, Enterprise Work Designer, Enterprise Work Modeler, eProcurement Accelerator, EWA, Financial Fusion, Financial Fusion Server, Gateway Manager, GlobalFIX, iAnywhere, iAnywhere Application Alerts, iAnywhere Mobile Delivery, iAnywhere Mobile Document Viewer, iAnywhere Mobile Inspection, iAnywhere Mobile Marketing Channel, iAnywhere Mobile Pharma, iAnywhere Mobile Sales, iAnywhere Pylon, iAnywhere Pylon Application Server, iAnywhere Pylon Conduit, iAnywhere Pylon PIM Server, iAnywhere Pylon Pro, iAnywhere Solutions, ImpactNow, Industry Warehouse Studio, InfoMaker, Information Anywhere, Information Everywhere, InformationConnect, InternetBuilder, iScript, Jaguar CTS, jConnect for JDBC, Mail Anywhere Studio, MainframeConnect, Maintenance Express, Manage Anywhere Studio, M-Business Channel, M-Business Network, M-Business Server, MDI Access Server, MDI Database Gateway, media.splash, MetaWorks, My iAnywhere, My iAnywhere Media Channel, My iAnywhere Mobile Marketing, MySupport, NetGateway, Net-Libr ary, New Era of Networks, ObjectConnect, ObjectCycle, OmniConnect, OmniSQL Access Module, OmniSQL Toolkit, Open Biz, Open Cl i ent, Open Cli entConnect, Open Client/ Server, Open Client/Server Interfaces, Open Gateway, Open Server, Open ServerConnect, Open Solutions, Optima++, Orchestr a tion Studio, PB- Gen , PC APT Execute, PC DB-Net, PC Net Library, PocketBuilder, Pocket Power B uilder, Power++, power.stop, PowerAMC, PowerBuilder, PowerBuilder Foundation Class Library, PowerDesigner, PowerDimensions, PowerDynamo, PowerJ, PowerScript, PowerSite, PowerSocket, Powersoft, PowerStage, PowerStudio, PowerTips, Powersoft Portfolio, Powersoft Professional, PowerWare Desktop, PowerWare Enterprise, ProcessAnalyst, Rapport, RepConnector, Replication Agent, Replication Driver, Replication Server, Replication Server Manager, Replication Toolkit, Report-Execute, Report Workbench, Resource Manager, RW-DisplayLib, RW-Library, S-Designor, SDF, Secure SQL Server, Secure SQL Toolset, Security Guardian, SKILS, smart.partners, smart.parts, smart.script, SQL Advantage, SQL Anywhere, SQL Anywhere Studio, SQL Code Checker, SQL Debug, SQL Edit, SQL Edit/TPU, SQL Everywhere, SQL Modeler, SQL Remote, SQL Server, SQL Server Manager, SQL SMART, SQL Toolset, SQL Server/CFT, SQL Server/DBM, SQL Server SNMP SubAgent, SQL Station, SQLJ, STEP, SupportNow, S.W.I.F.T. Message Format Libraries, Sybase Central, Sybase Client/Server Interfaces, Sybase Financial Server, Sybase Gateways, Sybase MPP, Sybase SQL Desktop, Sybase SQL Lifecycle, Sybase SQL Workgroup, Sybase User Workbench, SybaseWare, Syber Financial, SyberAssist, SyBooks, System 10, System 11, System XI (logo), SystemTools, Tabular Data Stream, TotalFix, TradeForce, Transact-SQL, Translation T oolkit, UltraLite, UltraLite.NET, UNIBOM, Unilib, Uninull, Unisep, Unistring, URK Runtime Kit for UniCode, VisualWriter, VQL, WarehouseArchitect, Warehouse Control Center, Warehous e Studio, Warehouse WORKS, Watcom, W atcom SQL, Watcom SQL Server, Web Deployment Kit, Web.PB, W eb.SQL, W ebSights, W ebV iewer, W orkGroup SQL Server, XA-Library, XA-Server and XP Server are trademarks of Sybase, Inc. 05/04

Unicode and the Unicode Logo are registered trademarks of Unicode, Inc. All other company and product names used herein may be trademarks or registered trademarks of their respective companies. Use, duplication, or disclosure by the government is subject to the restrictions set forth in subparagraph (c)(1)(ii) of DFARS 52.227-7013

for the DOD and as set forth in FAR 52.227-19(a)-(d) for civilian agencies. Sybase, Inc., One Sybase Drive, Dublin, CA 94568.

Contents

About This Book............................................................................................................................ v

CHAPTER 1 Introduction..................................................................................... 1

PATRIOTcompliance Solution overview .......................................... 2

CHAPTER 2 Upgrading to version 2.2................................................................ 3

Overview .......................................................................................... 4

Issues addressed in this release............................................... 4

Contents of the 2.2 release ....................................................... 6

Verifying system environment variables........................................... 7

Upgrading the PATRIOT database .................................................. 8

Modifying PATRIOT connection caches.................................... 9

Upgrading Process Server process definitions .............................. 11

Upgrading formats.......................................................................... 12

Importing the new formats....................................................... 12

Upgrading EAServer components.................................................. 13

Updating the filter properties file.............................................. 17

Setting the PATRIOTAct component properties...................... 18

Configuring Portlets........................................................................ 20

Installing updated portlets ....................................................... 21

Creating directories for the class files ..................................... 22

Installing the Account Management portlet............................. 23

Verifying the Account Management portlet deployment.......... 24

Setting up Account Management for the pacuser................... 25

Creating the Account Management portlet for pacuser........... 26

Verifying deployment of the new and updated portlets ........... 26

Setting up the new portlets for pacuser................................... 27

Creating portlet pages for pacuser.......................................... 28

Index ............................................................................................................................................. 29

Upgrade Guide iii

Contents

PATRIOTcompliance Starter Kit

About This Book

This book describes how to upgrade and configure products in the PATRIOTcomp liance Solution.

Audience How to use this book

PATRIOTcompliance Solution overview

The Sybase PATRIOTcompliance Solution allows financial institutions to automate name filtering, intra-day and historical transaction filtering, and enterprise wide customer activity monitoring to meet the requirements of the USA P A TRIOT (U niting and Strengtheni ng America by Providing Approp riate Tools Required to Intercept and Obstruct Terrorism) legislation.

The PATR IOTcomplian ce Starter Kit provides the infrastructure components needed for the Sybase PATRIOTcompliance Solution, including:

• New Era of Networks Business Process Integration (BPI) Suite

• New Era of Networks Adapter for Flat Files

• Sybase Enterprise Portal

• TightLi nk CIS The PATRIOTcomp liance Solution templates allow the installation and

configuration of the separate products into a single solution. These templates include metadata to assemble the products, application server components, and database stored procedures to perform complex, highly-specialized functions.

2 PATRIOTcompliance Starter Kit

CHAPTER 2

Upgrading to version 2.2

This chapter tells you how to upgrade your system to version 2.2 of the PATRIOTcomp liance Solution.

Heading Page

Overview 4 Verifying system environment variables 7 Upgrading the PATRIOT database 8 Upgrading Process Server process definitions 11 Upgrading formats 12 Upgrading EAServer components 13 Configuring Portlets 20

Upgrade Guide 3

Overview

This upgrade to the PATRIOTcompliance Solution includes an updated ROLLUP version of the PATRIOT Compliance Starter Kit. Sybase recommends that you install this updated Software Release as soon as possible.

This upgrade is distributed as a zip file and is available for downlo ad from the EBFs/Maintenance page

Warning! Sybase strongly recommends that a backup of all components be

done before you begin this upgrade. You must re-create any customization of the PATRIOT solution templates.

Issues addressed in this release

CR# Description

CR#332858 Previous versions of PATRIOT Starter Kit sometimes allowed

users to log in more than once with the same logi n name. Updates to the portalinterface.properties allow you to restrict users to a single login at a time.

This step is optio nal a nd n ot req uire d fo r su cces sful d eplo ymen t.

CR# 332855 Changes to security.properties allow you to set the number of

days, months or years that a password remains valid; the default is 0, which means passwords are valid indefinitely.

Duration parameters are expressed in the <number> of days, months, or ye ars th e pass word re mains valid. Count begins from the day you create or modify the password. Changing the password via the Account Management portlet before the expiration date resets the count.

EP Security locks users who fail to change their passwords within set duration parameters out of the system.

CR# 327011 Pat LoggedIn Users is a new portlet that identifies all users

currently logged into the system.

at http://www.sybase.com/downloads.

4 PATRIOTcompliance Starter Kit

CHAPTER 2 Upgrading to version 2.2

CR# Description

CR# 333653 PATRIOTcompliance Starter Kit 2.2 in cludes a script which

creates a mechanism for customers who want t o make their EP instance use non-sa da tabase logins. These logins include sufficient permissi ons to let EP applications(s) connect to the patriot database, portal i nt erface, and search cache

Adding a non-sa user connection involves running a script,

ep_login.sql, that creates three new login names

PATRIOTdbConnection, PortalInterfaceCache, and epSearchCache. You then open Jaguar Manage in EAserver to

add the actual connections. This step is optional and not requ ired for successful dep loyment.

CR# 334386, CR# 336723

Customers, employees, or external accounts may be placed on a cleared list to allow their transactions to pass through the PATRIOT Solution without being flagged as a hit. Use the Pat Cleared List Adm portlet to administer the cleared list. In this portlet, you can search entries, make entries, or flag entries as inactive.

Changes to the

Pat Cleared List Admin portlet now allow you to

clear customers, employees, or external accounts from multiple lists at the same time. A new column in the search list identifie s users who make changes to the cleared list.

CR# 334776 Stop words are words that occur frequently in transactions and

are irrelevant to the suspect search. The

portlet

is a new portlet which identifies how frequently certain

Stop Words Candidate

words appear in various lists. Use this portlet to identify potential candidates for th e stop words list.

CR# 328827, CR# 323431

Pat Search List portlet to look up a suspect, employee,

Use the customer, country, or address with the search engine. Pat Search List returns a score that indicates the percent cert ainty for each match.

Previous versions of the

Pat Search List portlet limited suspect

searches to name. Customers can now search for susp ect s by country and address. Country and address check boxes now appear just above the Search for Suspect button. Country is the default search criteria; to search by street address you must click the Address button.

Upgrade Guide 5

Overview

Contents of the 2.2 release

Refer to the descriptions of the files below for individual instal lation instructions. Directory paths below are in UNIX notation. For Windows, change the forward slashes to back slashes.

T arget direc tory Filename

\.. patnfg22.pdf

\database ep_login.sql

\edl pPostFilter.edl

\formats custcomp.exp

\jaguar Filter.properties

\portlets onelogin.zip

\tightlink clientNew.xml

pat_upgrade.pdf pat_cop.pdf patsag.pdf EBF1208x_README.HTML EBF1208x_Buglist.txt EBF1208x_Filelist.txt

PatriotDB2.2_Upgrade.sql

lPatriot.edl

stdcustrecformats.exp stdcustrecformatscomp.exp stdmoneytransformats.exp stdmoneytransformatscomp.exp

dispatcher.jar

PatAcctManagementPortlet.pz PatriotPortlets22.pz

clientupdate212.xml Tightlink212Upgrade.doc

❖ Loading Release 2.2

You must have 2.1.2 installed or upgrade from 2.1.1 prior to adding the EBF. 1 Backup the current PATRIOT related directories to a safe place.

• %PATRIOT%

• %JAGUAR%\java\classes\com\sybase\patriotact\filter

6 PATRIOTcompliance Starter Kit

CHAPTER 2 Upgrading to version 2.2

• %JAGUAR%\html\classes\com\sybase\ep\portalinterface\tasks

• %JAGUAR%\Repository\IDL\com\sybase\patriotact\filter

2 Extract the PATRIOT EBF files into a temporary location.

The target directory of unzipping the EBF archive will be the installation directory of PATRIOT (%PATRIOT% for Windows; $PATRIOT for Solaris)

3 Make sure you have ASE and EAServer up and running.

Verifying system environment variables

Follow these steps to verify or set the environment variables required for

configuration.

1 Verify that the SYBASE environment variable is set. The SYBASE

environment variable is the root directory of Sybase applications. For example, SYBASE=/software/sybase (Solaris) or SYBASE=c:\Sybase (Windows).

2 Verify that the SYBASE_ASE environment variab le is set. This is the

directory under $SYBASE (Solaris) or %SYBASE% (Windows) where Adaptive Server Enterprise has been installed. For example, SYBASE_ASE=ASE-12_5.

3 Verify that the SYBASE_OCS environment variable is set. This is the

directory under $SYBASE (Solaris) or %SYBASE% (Windows) where Open Client/Server has been installed. For example, SYBASE_OCS=OCS- 12_5.

4 Set the JAGUAR environment variable. This is the directory under

$SYBASE (Solaris) or %JAGUAR% (W indows 2000) where EAServer has been installed.

Solaris example: JAGUAR=/software/sybase/EAServer Windows 2000 example: JAGUAR=c:\Sybase\EAServer

5 Set the $JAVA_HOME (Solaris) or %JAVA_HOME% (Windows)

environment variable. This environment variable points to a directory where a Java JDK is installed.

Solaris example: JAVA_HOME=$JAGUAR/jdk/jdk1.3

Upgrade Guide 7

Upgrading the PATRIOT database

Windows example: JAVA_HOME=$JAGUAR\shared\sun\ jdk\jdk.3 6 Set the PATRIOT environment variable. This is the directory where you

initially copied the contents of the PATRIOTcompliance Starter Kit

Solution Template CD.

Solaris example: PATRIOT=$PATRIOT

Windows example: PATRIOT=%PATR IOT%

Upgrading the PATRIOT database

Release 2.2 includes scripts that allow you to upgrade the PATRIOT database (Patriotdb) and New Era of Networks databas e (NNSYdb) . There are s epara te instructions for Solaris and Windows-based installations.

Solaris

Windows

Use these instructions to upgrade your database on Solaris. 1 Open a command window. Navigate to the

$PATRIOT/release2.2/database directory. 2 Execute the PatriotDB2.2_Upgrade.sql script, with the following syntax:

isql -S <ASE server name> -U <ASE_username> -P <ASE_password> -i PatriotDB2.2_Upgrade.sql -o

3 Review and correct any errors in the output file. Use these instruction to upgrade your database on Windows. 1 Open a command window. Navigate to the %PATRIOT%\databa se

directory. 2 Execute the PatriotDB2.2_Upgrade.sql script, with the following syntax:

isql -S <ASE server name> -U <ASE_username> -P <ASE_password> -i PatriotDB2.2_Upgrade.sql -o

3 Review and correct any errors in the output file.

8 PATRIOTcompliance Starter Kit

Modifying PATRIOT connection caches

PATRIOTcompliance Starter Kit 2.2 includes a script which creates a

mechanism for customers who want to make their EP inst ance use non-sa

database logins. These logins include sufficient permissions to let EP

applications(s) connect to the patriot database, portal interface, and search

cache.

CHAPTER 2 Upgrading to version 2.2

Adding a non-sa user connection involves running a script,

that creates three new login names PATRIOTdbConnection,

PortalInterfaceCache, and epSearchCache. You then open Jaguar Manager

in EAserver to add the actual connections.

This step resolves CR# 333653 is optional and not required for successful

deployment.

Executing the upgrade script

This section tells you how to execute the upgrade script. There are separate

instructions for Solaris and Windows-based installations.

Solaris

Windows

Use these instructions if you are upgrading a Solaris-based installation.

1 Open a command window, and navigate to the

$PATRIOT/release2.2/database directory.

2 Execute the ep_login.sql script, with the following syntax:

3 Review and correct any errors in the output fi le.

Use these instructions if you are upgrading a Windows-based installation.

1 Open a command window, and navigate to the

%PATRIOT%\release2.2\database directory.

ep_login.sql,

isql -S <ASE server name> -U sa -P <ASE_password> i ep_login.sql -o <outputfile>

2 Execute the ep_login.sql script, with the following syntax:

isql -S <ASE server name> -U sa -P <ASE_password> i ep_login.sql -o <outputfile>

3 Review and correct any errors in the output fi le.

Adding the connection caches

The next series of steps adds the connection properties for the new login

names.

Upgrade Guide 9

Upgrading the PATRIOT database

❖ Adding the P ATRIOTdbConnection

1 Connect to Jaguar Manager as jagadmin. 2Expand Jaguar Manager | Connection Caches. 3 Right-click PATRIOTdbConnection, choose Connection Cache

Properties.

When the Connection Cache Properties sheet appears, the General tab is

in focus. 4In the User Name box, change the sa user name to patriotlogin. 5In the Password box, type password. 6 Click Refresh, then click Ping to test the connection. 7 Click OK to return to Jaguar Manager.

❖ Adding the PortalInterfaceCache connection

1 Right-click PortalInterfaceCache, choose Connection Cache

Properties.

The Connection Cache Properties panel appears. 2In the User Name box, change the sa user name to portaliflogin. 3In the Password box, type password. 4 Click Refresh, then click Ping to test the connection. 5 Click OK to return to Jaguar Manager.

❖ Adding the epSearchCache connect ion

1 Right-click epSearchCache and select Connection Cache Properties. 2In the User Name box, change the sa user name to epsearchlogin. 3In the Password box, type password. 4 Click Refresh, then click Ping to test the connection. 5 Click OK to return to Jaguar Manager. 6 Shut down and restart Jaguar Server.

Known issue

Non-sa user connection caches to the PATRIOT database lack the appropriate authority to retrieve data from ASE sybsecurity database. Granting system security officer role (sso_role) to the user of patriot database connection resolves this issue. You must run the following procedure for the Pat Audit Trail portlet to work properly.

10 PATRIOTcompliance Starter Kit

CHAPTER 2 Upgrading to version 2.2

Although there is a work around, this issue has been logged in QTS as CR#

361596 and will be addressed in a future release.

❖ Granting an sso_role to a patriot db connection user

1 Open a command window, and run the following statements:

isql -S <ASE server name> -U sa -P <ASE_password>

2 Run the following scripts:

use master

grant role sso_role to patriotlogin

3 Shut down and restart Jaguar Server.

Upgrading Process Server process definitions

This procedure overwrites all process definitions and plug-ins. There are

separate procedures for Windows and Solaris based installations.

Windows

Use these instructions if you are upgrading a Windows-based installation.

1 Copy the contents of the %PATRIOT%\Release2.2\edl directory to

%SYBASE%\ProcessServer-3_9\bin\edl. This overwrites the set of existing files.

2 Open a command window , and change to the %SYBASE%\ProcessServer-

3_9\bin\edl directory.

3 Run the following commands:

call EDLUtil put ..\edl\lPatriot.edl call EDLUtil put ..\edl\pPostFilter.edl

Solaris

Use these instructions if you are upgrading a Solaris-based installation.

1 Copy the contents of the $PATRIOT/Release2.2/edl direct or y to

$SYBASE/ProcessServer-3_9/bin/edl.

2 Open a command window, and change to the $SYBASE/ProcessServer-

3_9/edl directory.

3 Run the following commands:

Upgrade Guide 11

Upgrading formats

The standard money transaction and customer record fo rmats have changed for this release.

The following files have been updated.

• custcomp.exp

• stdcustrecformats.exp

• stdcustrecformatscomp.exp

• stdmoneytransformat s.exp

• stdmoneytransformat scomp.exp

EDLUtil put ..\edl\lPatriot.edl EDLUtil put ..\edl\pPostFilter.edl

Importing the new formats

You will need to import the new formats. Make sure you set NNSY_ROOT to the %SYBASE%\nnsy (Windows) or $SYBASE/nnsy (Solaris) directory.

Windows

12 PATRIOTcompliance Starter Kit

Use these instructions if you are importing the formats to a Windows-based installation. Perform this step if you have not updated your formats.

1 Create the directory %SYBASE%\nnsy\formats if it does not already exist. 2 Copy the format files from the %PATRIOT%\Release2.2\formats\*

directory to the %SYBASE%\nnsy\formats directory. 3 Open a command window , and change to the %SYBASE%\nnsy directory . 4 Run the following commands:

NNFie -i formats\custscomp.exp -s new_format_demo -o

NNFie -i formats\stdcustrecformatscomp.exp -s new_format_demo -o

NNFie -i formats\stdmoneytransformatscomp.exp -s new_format_demo -o

CHAPTER 2 Upgrading to version 2.2

Solaris

Use these instructions if you are importing the formats to a Solaris-based

installation. Perform this step if you have not updated your formats

1 Create the directory $SYBASE/nnsy/formats if it does not already exist.

2 Copy the format files from the $P A TRIOT/Relea se2.2/form ats/* director y

to the $SYBASE/nnsy/formats directory. 3 Open a command window, and change to the $SYBASE/nnsy directory. 4 Run the following commands:

NNFie -i formats\custscomp.exp -s new_format_demo -o

NNFie -i formats/stdcustrecformatscomp.exp -s new_format_demo -o

NNFie -i formats/stdmoneytransformatscomp.exp -s new_format_demo -o

Note

Running the NNFie commands overwrites formats in your database and generates conflict warnings. Beca use f ield names do not change and old maps are not affected, you can ignore these warnings.

Upgrading EAServer components

A new version of the PATRIOT Act EJB and an update to the j Connect files are included with this upgrade.

❖ Deleting the existing PATRIOTAct package

Before you can upgrade to 2.2, you must remove the current package. 1 Connect to Jaguar Manager as ' 2 Expand Jaguar Manager | Packages. 3 Right-click PatriotAct, choose Delete Package, then click Yes to delete

the package. 4 Expand Jaguar Manager | Servers | Jaguar | Installed Services. 5 Right-click Loader, choose Remove Service, then click OK to re move

the loader.

Upgrade Guide 13

jagadmin'

Upgrading EAServer components

6 Right click Scheduler, choose Remove Service, then click OK to remove

the scheduler.

7Expand Jaguar Manager | Servers | Jaguar and select Shutdown. 8 Right-click Jaguar, choose Shutdown.

Make sure the %JAGUAR%\Repository\Component\PatriotAct directory (Windows) or $JAGUAR/Repository/Component/PatriotAct (Solaris) directory does not exist. If it does, start Jaguar again and redo steps 1 - 7.

9 Start Jaguar Server.

❖ Deploying the new dispatcher.jar to Jaguar

Importing an EJB into the J aguar Service allows the component to register with the application server.

1Expand Jaguar Ma nager , right click Packages, point to Deploy, choose

EJB Jar.

2 When the Deploy Wizard appears, click Browse, navigate to one of the

following directories:

• %PATRIOT%\Release2.2\jaguar (Windows)

• $PATRIOT/Release2.2/jaguar (Solaris) Choose dispatcher.jar, click Select.

3 Verify the following deployment options.

Option Group Opt ions

Deployment Strategy Full Deployment Deployment Options • Prompt before overwr iting objects

• Automatically generate EJB stubs and skel etons

• Use Interoperable Naming

4 Click Next to deploy the file, then click Close to return to Jaguar Manager . 5Expand Jaguar Manager | Servers | Jaguar. 6 Right-click Installed Packages, choose Install an Existing Package,

select PatriotAct, then click OK.

❖ Creating the Scheduler component

Follow the steps in this section to create a Scheduler component. 1Expand Jaguar Manager | Servers | Jaguar | Installed Packages .

14 PATRIOTcompliance Starter Kit

CHAPTER 2 Upgrading to version 2.2

2 Right-click PatriotAct, choose New Component. 3When the Component Wizard appears, choose Define New Component,

click Next, and Next again. 4In the Component name box, type Scheduler, c lick Finish. 5When the Component Properties sheet appears, the General ta b is in

focus. Modify the Java Class name to read

com.sybase.patriotact.filter.SchedulerImpl, then click OK to return to

Jaguar Manager . 6 Expand the Scheduler component, right-click Interfaces, choose Add

Interfaces.

The Install Interface dialog appears. 7From the Available IDL Interfaces drop down box, choose CtsServices.

Three CtsServices appear in the right pane. 8 Select CtsServices::Generic Service, click Add, then click Install.

The Scheduler component is now available as part of the PatriotAct

package. 9 Expand Servers | Jaguar. 10 Right-click Installed Services, choose Install Service, select

PatriotAct/Scheduler from the list, then click OK to return to Jaguar

Manager.

❖ Creating the Loader component

1 Expand Jaguar Manager | Servers | Jaguar | Installed Packages. 2 Right click PatriotAct, choose New Component. 3 When the Component Wi zard app ears , choo se Define New Component,

click Next, then click Next again. 4In the Component Name box, type Loader, then click Finish. 5When the Component Properties sheet appears, the General ta b is in

focus. Modify the Java Class name to read

com.sybase.patriotact.filter.LoaderImpl, then click OK to return to Jaguar

Manager. 6 Expand the new Loader component, right-click Interfaces, select Add

Interfaces. 7From the Available IDL Interfaces drop down box, choose CtsServices.

Upgrade Guide 15

Upgrading EAServer components

Three CtsServices appear in the right pane

8 Select CtsServices::Generic Service, click Add, then click Install.

The Loader component is now available.

9Expand Servers | Jaguar. 10 Right-click Installed Services, choose Install Service, select

PatriotAct/Loader from the list, then click OK to return to Jaguar Manager.

❖ Generating Scheduler stubs and skeletons

Generating Java stubs and skeletons ensures that the J aguar Server has the information necessary to interact with the components.

1Expand Servers | Jaguar | Installed Packages | PatriotAct. 2 Right-click on the Scheduler component, choo se Generate

Stub/Skeleton.

3 When the Generate Stubs and Skeletons dialog appears, choose the

following options:

• Generate Stubs

• Generate Java Stubs and choose CORBA from the drop down box

• Generate Java Files and use the default directory

• Compile Java Stubs

• Generate Skeletons and use the default directory

• Compile Java Skeletons and use the default directory

• Leave everything else as default

4 Click Generate. 5 After the code generates successfully, click OK to return to Jaguar

Manager.

❖ Generating Loader stubs and skeletons

1 Right-click on the Loader component, choose Generate Stub/Skeleton. 2 When the Generate Stubs and Skeletons dialog appears, choose the

following options:

• Generate Stubs

• Generate Java Stubs and choose CORBA from the drop down box

16 PATRIOTcompliance Starter Kit

CHAPTER 2 Upgrading to version 2.2

• Generate Java Files and use the default directory

• Compile Java Stubs

• Generate Skeletons and use the default directory

• Compile Java Skeletons and use the default directory

• Leave everything else as default

3 Click Generate. 4 After the code generates successfully, click OK to return to Jaguar

Manager.

❖ Generating PatriotAct stubs and skeletons

1 Right-click on the PatriotAct component, choose Generate

Stub/Skeleton.

2 When the Generate Stubs and Skeletons dialog appears, choose the

following options:

• Generate Stubs

• Generate Java Stubs and choose EJB from the drop down box

• Generate Java Files and use the default directory

• Compile Java Stubs

• Generate Skeletons and use the default directory

• Compile Java Skeletons and use the default directory

• Leave everything else as default

3 Click Generate. 4 After the code generates successfully, click OK to return to Jaguar

Manager.

Updating the filter properties file

Add the following settings into the existing Filter.properties file in %JAGUAR%\bin (Windows) or $JAGUAR/bin (Solaris):

#PatStopWords

select_preMatchStopWords = select word from

PatStopWords where is_active = 1

Upgrade Guide 17

Upgrading EAServer components

select_scoreMatchStopWords = select word from PatStopWords where priority = 1 and is_active = 1

QuickWordsThreshhold=30

Setting the PATRIOTAct component properties

Follow the instructions in this section to set the PATRIOTAct component properties.

❖ Setting Controller component proper ties

1Expand Servers | Jaguar | Installed Packages | PatriotAct. 2 Right-click Controller, choose Component Properties. 3 When the Controller properties sheet appears, click the Transactions tab,

choose Not Supported.

4 Click the Run As Identity tab, do this:

• Set the Run As Identity property to system.

• Set the Mapped to Jaguar Identity prop erty to system.

5 Click the Resource Refs tab, do this:

•In the Resource factories referenced in code group, set the Sharing

Scope of the jms/JMSQCFactory to shareable, then choose

javax.jms.QueueConnectionFactory as the Resource Link.

•In the Resource factories referenced in code group, set the Sharing

Scope of the jdbc/DBConnection to shareable, then choose

PATRIOTdbConnection as the Resource Link.

6 Click the Resource Env Refs tab, do this:

•In the Resource environmental references group, click

jms/ErrorQueue, then set the Link Value to error.

•In the Resource environmental references group, click

jms/ResultQueue then set the Link Value to from_filters.

7 Click the MDB Type tab, set the Name property to to_filters. 8 Click OK to return to Jaguar Manager.

❖ Setting the FTPLoad component properties

1 Right-click FTPLoad, choose Component Properties.

18 PATRIOTcompliance Starter Kit

CHAPTER 2 Upgrading to version 2.2

2 When the Connection Properties sheet appears, click the Transactions

tab, choose Not Supported 3 Click the EJB Refs tab, do this:

In the EJBs referenced in code group, click ejb/NightlyFilter, then set the

Link Value to PatriotAct/NightlyFilter. 4 Click the Resource Refs tab, do this:

In the Resource factories referenced in code group, set the Sharing

Scope of the jdbc/CacheName to shareable, then set the Resource Link

to PATRIOTdbConnection. 5 Click OK to return to Jaguar Manager.

❖ Setting the Loader component properties

1 Right-click Loader, choose Component Properties. 2 When the Connection Properties sheet appears, click the Transactions

tab, choose Not Supported. 3 Click OK to return to Jaguar Manager.

❖ Setting the NightlyFilter component properties

1 Right-click NightlyFilter, choose Component Properties. 2 When the Connection Properties sheet appears, click the Transactions

tab, choose Requires New. 3 Click the Resource Refs tab, do this:

•In the Resource factories refer enced in code group, set the Sharing

Scope of the jdbc/CacheName to sharable, then set th e Resource Link to PATRIOTdbConnection.

• In the Resource factories referenced in code group, set the Sharing Scopeof the jdbc/D BConnection to shareable, then set the Resource Link to PATRIOTdbConnection.

4 Click OK to return to Jaguar Manager.

❖ Setting the Scheduler component properties

1 Right-click Scheduler, choose Component Properties. 2 When the Connection Properties sheet appears, click the Transactions

tab, choose Not Supported.

3 Click OK to return to Jaguar Manager.

Upgrade Guide 19

Configuring Portlets

❖ Setting the TableClean component properties

1 Right-click TableClean, choose Component Properties. 2 When the Connection Properties sheet appears, click the Transactions

tab, choose Requires New.

3 Click the Resource Refs tab, do this:

In the Resource factories referenced in code group, set the Sharing Scope of the jdbc/CacheName to shareable, then set the Resource Link to P ATRIOTdbConnection.

4 Click OK to return to Jaguar Manager. 5 Shutdown and restart EAServer.

Configuring Portlets

This section tells you how to install and configure the 2.2 portlets.

❖ Setting single login properties

Previous versions of PATRIOT Starter Kit sometimes allowed users to login more than once with the same login name. Updates to the portalinterface.properties allow you to restrict users to a single login at a time.

1 Back up the following files.

Note

Directory paths below are in UNIX notation. For DOS, change forward slashes to back slashes; change $JAGUAR to %JAGUAR%.

Subdirectory Filename

$JAGUAR/html/classes PI_Errors.properties $JAGUAR/html/classes/com/

sybase/ep/portalinterface $JAGUAR/html/classes/com/sybase/ep/

portalinterface/services $JAGUAR/META-INF MANIFEST.MF

Errors.class.

SecurityServiceImpl.class

2 Extract onelogin.zip into $JAGUAR.

20 PATRIOTcompliance Starter Kit

If WinZip notifies you that you are about to overwrite existing files, click

Yes to confirm the file overwrite. 3 Back up $JAGUAR/html/classes/portalinterface.properties. 4 Use a text editor to open portalinterface.properties. 5 Add the following properties to the end of the file:

security.cache.name=SecDboCache enforce.single.login=true

6 Save the portalinterface.properties file. 7 Shut down and restart Jaguar Server.

Installing updated portlets

This section tells you how to install updates to the portlets. There are separate instructions for Windows and Solaris-based installations .

CHAPTER 2 Upgrading to version 2.2

Windows

Solaris

Use these instructions to install the 2.2 portlets on Windows. 1 Copy the *.pz files from %PATRIOT%\portlets to

%SYBASE%\PortalInterface-2_5\bin. 2 With ASE and Jaguar Server running, open a command window and

navigate to %SYBASE%\PortalInterface-2_5\bin. 3Run pz.bat with the following syntax:

pz.bat -H <ASE_hostname> -N <ASE_Port> -U <ASE_username> -P <ASE_password> -F PatriotPortlets22.pz.

4 Select Import Portlet from Archive and press ENTER. 5 Select Import Archived Portlets and then press

ENTER.

This step imports the portlets. Choose ALL to any overwrite question;

choose No to any create duplicate question. An Import Done message

notifies you when this process is complete. 6 Select X and X to exit the PortalZipper tool. 7 Shut down and restart Jaguar Server. Use these instructions in install the 2.2 portlets on Solaris. 1 Copy the *.pz files from $PATRIOT/portlets to $SYBASE/PortalInterface-

2_5/bin.

Upgrade Guide 21

Configuring Portlets

2 With ASE and Jaguar Server running, open a command window, and

change to the $SYBASE/PortalInterface-2_5/bin directory.

3Run pz.sh with the following syntax:

pz.sh -H <ASE_hostname> -N <ASE_Port> -U

<ASE_username> -P <ASE_password> -F

PatriotPortlets22.pz.

4 Select Import Portlet from Archive and press ENTER. 5 Select Import Archived Portlets and then press

This step imports the portlets. Choose ALL to any overwrite question; choose No to any create duplicate question. An Import Done message notifies you when this process is complete.

6 Select X and X to exit the PortalZipper tool. 7 Shut down and restart Jaguar Server.

Creating directories for the class files

If the following directories do not exist, create these directories for the new class files.

Note

Directory paths below are in UNIX notation. For Windo ws, chang e forw ard slashes to back slashes; change $JAGUAR to %JAGUAR%.

• $JAGUAR/html/classes/com/sybase/ilab

• $JAGUAR/html/classes/com/sybase/ilab/utils

• $JAGUAR/html/classes/com/sybase/ilab/pi

• $JAGUAR/html/classes/com/sybase/ilab/pi/pim

ENTER.

• $JAGUAR/html/classes/com/sybase/ilab/pi/pim/tasks

• $JAGUAR/html/classes/com/sybase/ilab/pi/security

• $JAGUAR/html/classes/com/sybase/ilab/pi/security/beans

• $JAGUAR/html/classes/com/sybase/ilab/pi/security/services

22 PATRIOTcompliance Starter Kit

CHAPTER 2 Upgrading to version 2.2

Installing the Account Management portlet

This section tells you how to install the Account Management portlet. There are separate instructions for Windows and Solaris-based installations.

Windows

Use these instructions to install the Account Management po rtlet on W in dows. 1 With ASE and Jaguar Server running, o pen a command wind ow , and co py

%PATRIOT%\Portlets\PatAcctManagementPortlet.pz to

%SYBASE%\PortalInterface-2_5\bin.

2 Change to the %SYBASE%\PortalInterface-2_5\bin directory. 3Run pz.bat with the following syntax:

pz.bat -H <ASE_hostname> -N <ASE_port_number> -F PatAcctManagementPortlet.pz

4 Select Import Portlet from Archive and press ENTER. 5 Select Import Archived Portlets and then press

ENTER.

This step imports the portlets. Choose ALL to any overwrite question;

choose No to any create duplicate question. An Import Done message

notifies you when this process is complete. 6 Select X and X to exit the PortalZipper tool. 7 Change to %JAGUAR%\html\portal\html\v4 directory, and use an editor

to change the properties of the ilab_changeInfo.html and

ilab_changePWD.html files. In both files, change the line that reads:

<jtf:setProperty name="IIOP_URL" value="iiop://yongming-pc:9000"/>

<jtf:setProperty name="IIOP_URL" value="iiop://<yourhost>:<yourport>"/>

8 Change to the %JAGUAR%\html\classes\com\sybase\ilab\pi\pim\tasks

directory, and rename PIMControl.class to PIMControl.class.old 9 Shut down and restart Jaguar Server.

Solaris

Use these instructions to install the Account Management portlet on Solaris. 1 With ASE and Jaguar Server running, o pen a command wind ow , and co py

$PATRIOT/Portl ets/PatAcctManagementPortlet.pz to

$SYBASE/PortalInterface-2_5/bin. 2 Change to the $SYBASE/PortalInterface-2_5/bin directory.

Upgrade Guide 23

Configuring Portlets

3Run pz.sh with the following syntax:

pz.sh -H <ASE_hostname> -N <ASE_port_number> -F

PatAcctManagementPortlet.pz

4 Select Import Portlet from Archive and press ENTER. 5 Select Import Archived Portlets and then press

ENTER.

This step imports the portlets. Choose ALL to any overwrite question. An Import Done message notifies you when this process is complete.

6 Select X and X to exit the PortalZipper tool. 7 Change to the $JAGUAR/html/portal/html/v4 directory, and use an editor

to change the properties of the ilab_changeInfo.html and ilab_changePWD.html files. In both files, change the line that reads:

<jtf:setProperty name="IIOP_URL"

value="iiop://yongming-pc:9000"/>

<jtf:setProperty name="IIOP_URL"

value="iiop://<yourhost>:<yourport>"/>

8 Change to the $JAGUAR/html/classes/com/sybase/ilab/pi/pim/tasks

directory, and rename PIMControl.class to PIMControl.class.old

9 Shut down and restart Jaguar Server.

Verifying the Account Management portlet deployment

This step tells you how to test the Account Manager portlet. 1 Start Internet Explorer and enter the URL:

http://<jaguar_hostname>:8080/.

2 Log into Portal Interface using the user ID, pso, with the password

123qwe.

3 Click the Admin link at the top of the page. 4On the Admin Entry Page, click Choose Portlets from the Admin

Portal Control.

5On the Choose Portlets panel, move the Accou nt Management portlet

from the A vailable Portlets box to the Select ed Portlets box, c lick Done.

6From the Customize drop down box, choose the PATRIOT Test page.

24 PATRIOTcompliance Starter Kit

CHAPTER 2 Upgrading to version 2.2

The PATR IOT Test page should display with the new portlet accessible.

Setting up Account Management for the pacuser

To enable access to each of the PATRIOT portlets for pacuser, you need to modify the properties for each portlet and include the PIUser Role as detailed below. These instruction assume that you are logged in as ‘pso’.

1 Select the Admin link on the Welcome bar at the top of the browser to

enter Administrative mode. 2From the Select a Page drop down box in the upper right-hand corner of

the page, select the PATRIOT Test page.

The PATRIOT Test page appears with the new Account Management

portlet accessible. 3For the Account Management portlet, do this:

• Click the Edit link in the title bar and modify the URL property from

iiop://yongming-pc:9000

iiop://<yourhost>:<yourport>

then click Done.

•From the Select a Page drop down box, select the PATRIOT Test

page to return to the Admin Entry Page.

• Select the PATRIOT Test link in the snail trail to navigate back to the PATRIOT Test page

• Select the icon located next to the Edit hyperlink in each of the portlet title bars on the page.

•On the Window Properties panel, sele ct the Edit Portlet Pr operties link to display the Edit Portlet panel containing the portlet properties.

•In the Portlet Rights section, select the PIUser role from the Role

List and click the right arrow to move it to the Roles with Rights to this Portlet list on the right.

• Click Done.

4 Log out of Portal Interface.

Upgrade Guide 25

Configuring Portlets

5 Change to the %JAGUAR%\html\classes\com\sybase\ilab\pi\pim\tasks

directory (Windows) or $JAGUAR/html/classes/com/sybase/ilab/pi/pim/tasks (Solaris) and rename PIMControl.class.old to PIMControl.class.

6 Shut down and restart Jaguar Server.

Creating the Account Management portlet for pacuser

Multiple portlet pages will be created for the PATRIOTcompliance Solution, and each page includes a number of the po rtlets imported into the Portal Interface.

1 Start Internet Explorer and enter the URL:

http://<jaguar_hostname>:8080/

2 Log into Portal Interface using the user ID pacuser with the password

pacuser.

3 Click Add Page in the Portal Control. Name this page Account

Managment and click Done.

4 When the Choose Portlets panel appears, select Account Management

from the A vailable Portlets box on the left and click the right arrow to move each portlet to the Selected Portlets box on the right.

5 Click Done to save the portlet page with the selected portlets. 6 Log out of Portal Interface and close the browser.

Verifying deployment of the new and updated portlets

Test the newly deployed p ortlets. 1 If you are not logged in as pso, start Internet Explorer and en ter the URL:

http://<jaguar_hostname>:8080/, and log into Portal Interface with the user ID pso and password 123qwe.

2 Select the Admin link on the Hello, New Portal User bar at the top of the

page to enter the Admin Entry Page.

3From the Customize drop down box, choose the page you want to use to

test the portlets, PATRIOT Test, for example. Or you can create a new page to test the portlets. Click Done.

26 PATRIOTcompliance Starter Kit

4 On the Choose Port lets panel , choose the new and updat ed portlets from

the Available Portlets box and move them into the Selected Portlets box. These include:

• Pat Logged In Users

• Pd Exp Notification

• Stop Words Candidate

5 Click Done. 6From the Customize drop down box, choose the page where you added

the portlets, PATRIOT Test for example.

The test page appears with the portlets you selected.

Setting up the new portlets for pacuser

This series of steps tell you how to grant pacuser access rights to the new and updated portlets. This section assumes you are logged in as pso.

Note

The Pat Logged In Users portlet is intended for pso users only. Do not grant access rights to this portlet to pacuser.

CHAPTER 2 Upgrading to version 2.2

1On the Admin Entry Page, choose the test page, PATRIOT Test for

example, where you added the new portlets from the Customize drop down box.

2 When the test page appears, do this for each new portlet on the page.

• Click the icon next to the Edit link on the title bar, and when the the Window Properties panel appears , click Edit Portlet Properties.

•On the Edit Portlet panel, in the Portlet Rights group, move PIUserfrom the Role List into the Roles with Rights to this Portlet box.

• Click Done.

• Choose the test page, PATRI OT Test for example, where you added the new portlets from the Customize drop down box.

3 Log out of Portal Interface.

Upgrade Guide 27

Configuring Portlets

Creating portlet pages for pacuser

1 If you are not logged in as pacuser, start Internet Explorer, enter the URL:

http://<jaguar_hostname>:8080/, and log into Portal Interface with the user ID pacuser and password pacuser.

2On the Home Page, click Add Page from the Portal Control, name the

page, cli ck Done.

3On the Choose Portlets panel, move the appropriate portlets from the

Available Portlets box into the Selected Portlets box on the right. Click Done.

Each Patriot portlet page should now be accessible from the Personalize drop down box in the upper right- hand corn er. Select each of these pages

to verify that the portlets have been installed and confi gured properly. 4 Repeat steps 2-3 to add the appropriate portlets for each new portlet page 5 Log out of Portal Interface and close the browser.

28 PATRIOTcompliance Starter Kit

Index

Account Management portlet

creating 26 deploying 24 installing 23 pacuser 25

compliance solution

introduction 1 overview 2

component properties

controller 18 FTPLoad 18 loader 19 NightlyFilter 19 scheduler 19 setting 18 TableClean 20

components

loader 15 scheduler 14 stubs and skeletons 16

connection caches 9

epSearchCache 10 know issue 10 PATRIOTActdbConnection 10

PortalInterfaceCache 10 contents 6 controller

component properties 18

database upgrade 8 definitions

upgrade Process Server 11

dispatcher jar

deploying 14

EAServer components

component properties 18 deleting PATRIOTAct pa ckage 13 dispatcher jar 14 filter properties 17 loader 15 scheduler 14 stubs and skeletons 16, 17

upgrading 13 environmenatal variables 7 execute

upgrade scripts 9

filter properties 17 formats

importing 12

upgrading 12 FTPLoad

component properties 18

introduction

compliance solution 1 issues addressed in this release 4

Upgrade Guide 29

Index

loader

component properties 19 creating 15

stubs and skeletons 16 loading 6 login properties 20

NightlyFilter

component properties 19

overview

compliance solution 2

upgrading 4

pacuser

account management portlet setup 25

creating account ma nagement portlet 26

creating portlet pages for 28

new portlet setup 27 PATRIOT database

modifying connection caches 9

upgrading 8 PATRIOTAct

stubs and skeletons 17 PATRIOTAct package

deleting 13 Portlets

account management 23, 24, 25, 26

class file directories 22

configuring 20

installing new portlets 21

new portlets and pacuser 27

pacuser pages 26

pacuser portlet pages 28

setting up pacuser 25

verifying deployment 24

verifying new portlets 26 preface v Process Server

upgrade definitions 11 process server definition s

importing 12

upgrading 11

release contents 6

scheduler

component prope rties 14, 19

creating 14

stubs and skeletons 16 scripts

execute upgrade 9 stubs and skeletons

loader 16

PATRIOTAct 17

scheduler 16 system environment

verify variables 7

TableClean

component prope rties 20

upgrade

execute scripts 9

Process Server definitions 11

version 2.1 3 upgrading

contents 6

database upgrade 8

PATRIOTcompliance Starter Kit

EAServer components 13 environmenatal variables 7 formats 12 issues addressed in this release 4 loading 6 modifying conn e ct i on ca che s 9 overview 4 portlets 20 Process Server definitions 11

upgrading database 8

variables

verify system environment 7

verify

system environment 7

version 2.1

upgrade 3

Index

Upgrade Guide 31

Index

PATRIOTcompliance Starter Kit

Sybase PATRIOTcompliance Solution User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

About This Book

PATRIOTcompliance Solution overview

Overview

Issues addressed in this release

Contents of the 2.2 release

Verifying system environment variables

Upgrading the PATRIOT database

Modifying PATRIOT connection caches

Executing the upgrade script

Adding the connection caches

Upgrading Process Server process definitions

Upgrading formats

Importing the new formats

Upgrading EAServer components

Updating the filter properties file

Setting the PATRIOTAct component properties

Configuring Portlets

Installing updated portlets

Creating directories for the class files

Installing the Account Management portlet

Verifying the Account Management portlet deployment

Setting up Account Management for the pacuser

Creating the Account Management portlet for pacuser

Verifying deployment of the new and updated portlets

Setting up the new portlets for pacuser

Creating portlet pages for pacuser

Index
