Release Bulletin
Adaptive Server® IQ 12.4.0
for
Digital UNIX
Document ID: 74950-01-1240-01
Last revised: September 10, 1999
Topic Page
1. Product summary 1
2. Restrictions 3
3. Installation Instructions 5
4. Documentation for this version 5
5. Special migration instructions 6
6. Changed functionality in this version 7
7. Known problems 9
8. Product compatibilities 14
9. Documentation updates and clarifications 14
10. Technical Support 49
11. Other sources of information 50
1. Product summary
Enclosed is Adaptive Server™ IQ version 12.4.0, which is comp atible
with the following platform and operating system configuratio ns:
• Digital UNIX V4.0d
• Digital UNIX V4.0e
Copyright 1989-1999 by Sybase, Inc. All rights reserved. Sybase, the Sybase logo, Data Workbench, InfoMaker,
PowerBuilder, Powersoft, SQL Advantage, SQL Debug, Transact-SQL, Adaptive Server, Adaptive Server Anywhere, Adaptive Server Enterpr ise, Adaptive Server Enterprise Monitor,AnswerBase, Backup Server, ClearCon
nect, Client-Library, DB-Library, dbQueue, DirectConnect, Distribution Agent, Embedded SQL, Enterprise Client/Server, Enterprise Connect, InformationConnect, KnowledgeBase, MainframeConnect, MAP, Net-Gateway,
NetImpact, Net-Library, ObjectConnect, OmniConnect, OmniSQL Access Module, Open Client, Open ClientConnect, Open Client/Server, Open Gateway, Open Server, Open ServerConnect, PC DB-Net, PowerDesigner, Replication Agent, Replication Driver , Replication Serve r, Replicatio n Server Manager , R W -Library , Secure SQL Server ,
Security Guardian, SQL Anywhere, S QL Remote, SQL Server , SQL Server Ma nager, SQL T oolset, Sybase Centra l,
Sybase IQ, Sybase SQL Desktop, Sybase SQ L Workgroup, SyBooks, System 10, System 11, Watcom SQL,
Web.SQL, WorkGroup SQL Server, XA-Library, XA-Server, and XP Server are trademarks of Sybase, Inc. Other
product names used herein may be trademarks or registered trademarks of S ybase or other companies. 1/99
Required Operating System Patches Adaptive Server IQ 12.4.0
• Digital Unix V4.0f
Note The product name Digital UNIX has recently been changed to Tru64
UNIX. However the Adaptive Server IQ documentation still uses the old
Digital UNIX name.
The following operating system command shows the level of your base system
software:
% sizer -v
Tru64 UNIX V4.0D (Rev. 878);
Wed Jul 15 12:31:49 EDT 1998
Adaptive Server IQ 12.4.0 has been built to take advantag e of certain
performance features found in the Digital Alpha EV5.6 (21164A) and later
chip architecture.
1.1 Required Operating System Patches
You must install the patches listed in this section to run Adaptive Server IQ on
Digital UNIX.
2
• Digital UNIX V4.0d requires the March 1998 patch kit as the absolute
minimum.
Normally, it is best to install the latest patch kit. However, as of Adaptive
Server IQ 12.4.0 certification, the latest patch kits contain a problem in the
pthreads library which causes a one to two times performance slowdown in
Adaptive Server IQ, most notably in loads and multi-user activity. For this
reason, you should avoid using those patches and use the previous patch kits.
The following table shows you which kits to avoid (the middle column) and
which you should use (the last column).
For this operating
system version
DUNIX 4.0D duv40das0004-
DUNIX 4.0E duv40eas0002-
DUNIX 4.0F duv40fas0001-
Do NOT use this patch
kit Use this patch kit
duv40das00003-
19990723
19990208
duv40eas00001-
19990617
19990202
None required
19990609
This problem should be resolved in the next release of these patch kits .
Release Bulletin for Digital UNIX
Adaptive Server IQ 12.4.0 Converting 12.0.x databases to 12.4.0
To obtain patches, download them from the website at
http://www.service.digital.com/ or contact your Digital representative.
Note These patches require that you rebuild your kernel. You must halt your
system and then boot from the console after the new kernel is put into place.
When installing patches, log in as the “root” (superuser) and follow the
directions provided with the patch. All tasks for adjusting the operating system
configuration must be performed as “root”.
Failure to install the appropriate patches before starting Adaptive Server IQ
requires reinstalling Adaptive Server IQ.
2. Restrictions
Read this section! Your system may produce unexpected results if you ignore
the restrictions and ot her instructions listed below.
If you are upgrading from version 1 1.x to 12.4.0 , see chapter 3 of the Adaptive
Server IQ Installation and Feature Guide for further restrictions.
Converting 12.0.x
databases to 12.4.0
Before you can use a database created with earlier versions of Adaptive Server
IQ, you must run the script upgrasiq.sql, located in the $ASDIR/scripts
directory. For example, to update a database named old.db:
% dbisql -c "uid=dba;pwd=sql;dbn=old;eng=servername"
$ASDIR/scripts/upgrasiq.sql
If you do not run this scr ipt , errors like the fo llo wing m ay o ccur when y ou us e
certain front end tools with the ODBC driver to import or link to a table:
The operation failed. There are too many indexes
on table ’amadbdbo_midtown’.
Delete some of the indexes on the table
and try the operation again.
Release Bulletin for Digital UNIX 3
Insert into table from remote SQL database not supported Adaptive Server IQ 12.4.0
You must run upgrasiq.sql once for each 12.0.x database to upgrade it to
12.4.0.
Note For Adaptive Server IQ versions 12.0.3, 12.03.1, and 12.4.0: Due to a
timing related issue, the database server process will sometimes hang if an IQ
database is started on the command line. For a wo rkaround, see the readme file
included with the software.
Insert into table from
remote SQL databas e
not supported
CREATE DATABASE
restrictions
Query restrictions
Adaptive Server IQ for Digital UNIX does not include Open Client Libraries.
Current communications libraries (up to and including EBF 8263) do not
support native kernel-threading. Therefore, using current communications
libraries, you will be unable to insert data directly from Adaptive Server
Enterprise using the
such data in an ASCII file and load it using the
INSERT INTO tablename LOCATION command. Place
LOAD command.
For this release, to obtain the best performance, Sybase recommends the
following minimum IQ page sizes:
•32 KB (
IQ PAGE SIZE 32768) for a database containing up to 10 millio n
rows.
•64 KB (
IQ P AGE SIZE 65536) for a data base contai ning up to 100 millio n
rows. Note that this is the default IQ page size.
• 128 KB (
IQ P AGE SIZE 131072) for databases with more than 100 million
rows.
• Do not create any databases with an
IQ PAGE SIZE of less than 16KB.
• By default Adaptive Server IQ cursors are scrollable, meaning that
Adaptive Server IQ keeps all the query results in a buffer so that you can
scroll backwards. If the query returns more than a few thousand rows of
output, you can improve performance b y issuing the follo wing com mand
before running the query:
SET TEMPORARY OPTION Force_No_Scroll_Cursors = ’ON’
4
• Adaptive Server IQ does not support Transact-SQL style outer joins on
expressions. The workaround is to use ANSI style outer joins instead.
For example, statements containing clauses like the following are
unsupported:
SUBSTRING(COL1 ...) *= SUBSTRING(COL2 ...)
The following outer join format is supported:
FROM t1 LEFT OUTER JOIN t2 ON (SUBSTRING(COL1 ...) =
Release Bulletin for Digital UNIX
Adaptive Server IQ 12.4.0 Setting the LD_LIBRARY_PATH Environment Variable
SUBSTRING(COL2 ...)
3. Installation Instructions
For complete installation instructions, see Adaptive Server IQ Installation and
Feature Guide for Compaq Digital UNIX.
3.1 Setting the LD_LIBRARY_PATH Environment Variable
You must set the LD_LIBRARY_PATH environment variable before running
Adaptive Server IQ and utilities.
For instructions on setting the LD_LIBRARY_PATH environment variable,
see the Adaptive Server IQ Installation and Feature Guide.
4. Documentation for this version
The table below lists the documentation for Adaptive Server IQ version 12.4.0.
All documentation for Version 12.4.0 is available in one of two formats:
* indicates document found on the Adaptive Server IQ Technical Library
CD. Hard copy documentation can be ordered separately.
** indicates document may be provided in hard copy.
Table 1: Current Adaptive Server IQ documentation
Part Number Book Title
74950-01-1240-01 Release Bulletin Adaptive Server IQ for Digital
Unix**
34359-01-1240-01 Adaptive Server IQ Installation and Feature Guide
for Digital Unix**
38152-01-1200-01 Adaptive Server IQ Administration an d Performance
Guide*
38151-01-1200-01 Adaptive Server IQ Reference*
38159–01–1200–01 Introduc tio n to Ada p tiv e Serv er IQ*
If you are also using Adaptive Server IQ Multiplex, please refer to the
following documentation for further instructions:
35008–01–1240–01 Adaptive Server IQ Multiplex Installa tion and
Feature Guide for Digital UNIX
Release Bulletin for Digital UNIX 5
Accessing Current Release Bulletin Information Adaptive Server IQ 12.4.0
Depending on how you use Adaptive Server IQ, you may also need to refer to
the documentation for Adaptive Server Anywhere. R efer to the Version 6.02
edition of Adaptive Server Anywhere documentation on the Sybase Technical
Library Web site, for the most current information that applies to Adaptive
Server IQ. Older editions of the Adaptive Server Anywhere User’s Guide and
Adaptive Server Anywher e Pr ogramming Interfaces Guid e are included on the
Adaptive Server IQ Technical Library CD and in the printed documentation
set.
4.1 Accessing Current Release Bulletin Information
A more recent version of this Release Bulletin may be available on the World
Wide Web. To check for critical product or document information added after
the release of the product CD, use the Sybase Technical Library Product
Manual Web site.
T o access release bulletins at the Technical Library Product Manual W eb site:
1Go to support.sybase.com
2 Click the Manuals tab.
3 From the drop-down list choose Adaptive Server IQ.
4 In the window on the right, under Platform-Specific Collections, choose
the appropriate version li n k.
5 In the window on the right, choose the release bulleti n for you r platfo rm.
.
5. Special migration instructions
See the Adaptive Server IQ Installa tion an d Feature Guide for instructions on
migrating to Adaptive Server IQ 12.4.0 from earlier versions.
If you participated in the Adaptive Server IQ Beta Program and have not yet
upgraded to any GA (General Availability) version, please call technical
Support before upgrading to Version 12.4.0
The “Restrictions” in this Release Bulletin lists late-breaking requirements.
Please read this section before running a new version of Adaptive Server IQ.
5.1 Obtaining query plans
6
Release Bulletin for Digital UNIX
Adaptive Server IQ 12.4.0 Changed functionality in Adaptive Server IQ 12.4.0
In version 11.x, you could out pu t the query plan usin g the comman d
QUERYINFO ON
. In Adaptive Server IQ 12.0, run the following command to
output the query plan:
SET TEMPORARY OPTION Query_Plan = ’on’
The plan will be in the .IQMSG file.
If you want additional detail or are send ing the plan to Technical Support you
can use:
SET TEMPORARY OPTION Query_Detail = ’ON’
6. Changed functionality in this version
The following sections describe changes since the Adaptive Server IQ
documentation set was updated.
6.1 Changed functionality in Adaptive Server IQ 12.4.0
This section summarizes new features and other changes to Adaptive Server IQ
12.4.0. Details of most of these features are provided in “Documentation
updates and clarifications” on page 14.
• Improved handling of out-of-space conditions If you run out of disk
space, Adaptive Server IQ now provides better assurance that you will be
able to add space where you need it.
IQ SET
•Adaptive Server IQ now reserves space so you can issue a
dbspace
setting two new options,
Reserved_Temp_DBSpace_MB. For details on these options, see
command. You can control the amount of space reserved by
Reserved_Main_DBSpace_MB and
create
“New options for reserving space” on page 34.
•The error message now specifies the amount of space you need to add in
megabytes, and matches the syntax in
create dbspace.
It is extremely unlikely that you will ever need to bring down the server to
add space. For revised documentation on what to do if you run out of
space, see “Insufficient disk space” on page 35.
• Forced recovery and leaked space recovery Adaptive Server IQ
12.4.0 adds better support for recovering from crashed and potentially
corrupt databases. It also adds support for recovering leaked storage space.
For details of these features, see “Forced recovery and leaked space
recovery” on page 36.
Release Bulletin for Digital UNIX 7
Improved stored procedure output Adaptive Server IQ 12.4.0
• Improved stored procedure output Stored procedures now display
output in units that are easier to unde rs tand.
• Minimum password length Database administrators can specify a
minimum password length, to discourage easily discovered passwords.
For more information, see “MIN_PASSWORD_LENGTH option” on
page 42
• ODBC 3.51 The ODBC driver has been updated to ODBC 3.51. T his
version of ODB C includes suppor t for Unicode applications.
For more information, see “ODBC conformance” in the online edition of
the Adaptive Server Anywhere Programming Interfaces Guide, Version
6.02.
• Control of allowed JOIN syntax In previous releases, some multi-
table queries have been allowed that have ambiguous join clauses. In the
present release, you can set an option to disallow such queries.
For more information, see “EXTENDED_JOIN_SYNTAX option” on
page 28.
• Zero-length data storage If the length of a CHAR or V ARCHAR cell is
zero and the cell is not NULL, Adaptive Server IQ creates a zero-length
cell, not a NULL. This change reverts to the original behavior in Adaptive
Server IQ 12, as documented Chapter 5 of the Adaptive Server IQ
Administration and Performance Guide.
6.2 Changed functionality in Adaptive Server IQ 12.03.1
This section summarizes new features and other changes to Adaptive Server IQ
added in Version 12.03.1 and not yet included in the documentation.
• sp_iqstatus displays IQ Page Size See “SP_IQSTA TUS no w displays
IQ Page Size” on page 42 for more information.
• LOAD_MEMORY_MB option This option replaces several older options
for adjusting memory use during l oads. For more information see
“LOAD_MEM ORY_MB option” on page 30.
• JOIN_PREFERENCE option Two new values were added for the
JOIN_PREFERENCE option. For more information see
“JOIN_PREF ERENCE Option” on page 31.
• Command-line options for server caching Two new server switches
override the database cache parameters you set with the
command:
8
Release Bulletin for Digital UNIX
SET OPTION
Adaptive Server IQ 12.4.0 stop_asiq utility
•
-iqmc sets the size of the main buffer cache
•
-iqtc sets the size of the temporary buffer cache
See “Additions to the start_asiq or as iqsrv12 command-line options” on
page 15 for details.
• stop_asiq utility Y ou can stop the server using the s top_asiq utility. For
more information see “stop_asiq utility” on page 18.
6.3 Changed functionality in Adaptive Server IQ 12
Adaptive Server IQ 12 takes a giant step forward from earlier versions. Amon g
the most important new features it includes are:
• Transactional database capabilities with table-level versioning
• The ability to update the database concurrently with queries by multiple
users
• A new, more efficient database format
• More intelligent index loadi ng, allowing faster loads for many indexes
• Syntactic compatibility with Adaptive S e rver Anywhere, allowing
Anywhere users to build on their existing knowledge base as t hey begin to
use Adaptive Server IQ
• Support for Transact-SQL
• Additional query and view supp ort
• Improved front end support
See the Adaptive Server IQ Installation and Feature Guide Chapter 3,
“Migrating Data from Prior Versions,” for importan t notes about how new
features change database creation and connection.
7. Known problems
For a description of known problems in Adaptive Serv er IQ version 12.4.0, see
the following sections. If there is a workaround for a problem, it is provided.
See also “Restrictions” for more information.
“Documentation updates and clarifications” contains details that were not
documented in time for this release.
Release Bulletin for Digital UNIX 9
Data definition Adaptive Server IQ 12.4.0
7.1 Data definition
This section reports problems with data definition.
7.1.1 Temporary tables in procedures
When you include an automatically created temporary table in a procedure, the
table should be dropped automatically when the procedure completes.
In Adaptive Server IQ 12.4.0, however, the table is not dropped. As a result, it
becomes visible outside the procedure, and a new instance of the table is
created each time the procedure executes. These tables instances are not
dropped until you disconnect.
This problem will be corrected in a future release. As a workaround in this
release, put an explicit
drop table
#temp_table_name
at the end of the procedure.
For example, the following procedure has been corrected so that the
automatically created temporary table, #temp0, is explicitly dropped and will
not be replicated.
create procedure foo
begin
select * into #temp0 from table
drop table #temp0 /* this line fixes the problem*/
end
7.2 Adaptive Server IQ Queries
This section reports problems with Adaptive Server IQ queries.
7.2.1 ANY, SOME, and ALL subquery support
Adaptive Server IQ does not yet support subq ueries that use the ANY, ALL or
SOME keywords. For example:
•> ALL
• >= ALL
•< ALL
10
• <= ALL
Release Bulletin for Digital UNIX
Adaptive Server IQ 12.4.0 Large IN subqueries
•= ALL
•!= ALL
If you use an unsupported query in this group, Adaptive Server IQ returns an
error like the following:
Feature, ANY, not yet implemented
Queries of this type can always be expressed in terms of IN subqueries or scalar
subqueries using MIN and MA X set functions.
7.2.2 Large IN subqueries
There is a known performance limitation in Adaptive Server IQ version 12 that
affects IN subqueries that return more than 1 million distinct values; such
queries should be rewritten in term of correlated EXISTS subqueries until this
server limitation is addressed.
7.3 Adaptive Server IQ Operations
This section reports problems with Adaptive Serv er IQ operatio ns.
7.3.1 Output to file in DBISQL
There are known problems in using the output to file feature from a DBISQL
session that will cause a server to abort. Do not use this feature in this release.
Instead, put
>
filename
on the end of a select statement.
The cases that cause the abort are:
• Using the feature when the IQ option
ON
• Performing a rollback command following the
select * from ....;
output to file;
rollback;
7.3.2 Changing length of DBISQL column values
By default, the maximum length of column values displayed by DBISQL is 30
characters. This may be inadequate fo r disp laying outpu t of store d procedur es
such as
Release Bulletin for Digital UNIX 11
sp_iqstatus.
Force_No_Scroll_Cursors is set to
output to command, as in
User-defi ned variable issue Adaptive Se rver IQ 12.4.0
T o avoid truncated output, incr ease the length by setting the
option as follows:
SET OPTION DBO.TRUNCATION_LENGTH = 80
Alternatively, fro m the DBISQL menu select Command→Options and enter a
higher value for Limit Display Columns and/or Limit Output Columns.
7.3.3 User-defined variable issue
User-defined variables will core dump if used in IQ queries.
7.3.4 DBSPAWN ERROR when starting a server
When attempting to start a server, you may get the following message:
DBSPAWN ERROR -96 -- database engine already running
This means that dbspawn is finding the shared memory segment of a
previously started server, and is unable to create a shared memory segment.
To resolve this issue, subsequent servers should be started with the parameter
-hs which will turn off shared memory. For example:
start_asiq @kent.cfg kent.db -hs
All servers can be started with shared memory “off”. Note that if shared
memory is turned off, then you will have to connect to the server using TCP/IP ,
instead of using the default shared memory connection.
truncation_length
7.3.5 Unsupported terminal types cause DBISQL error
If you set the terminal type to “dumb” or “unknown”, then start DBISQL,
Adaptive Server IQ returns an error. For example:
% setenv TERM dumb % dbisql
Error at line 1
Unable to initialize screen routines
To avoid problems, use an xterm window to run DBISQL on UNIX systems.
For example, you can start an xterm window with a scroll bar as follows:
% xterm -sb
7.3.6 Adding a raw disk dbspace
Do not specify the optional SIZE clause when adding a raw disk dbspace.
Adaptive Server IQ will correctly calculate the size of the raw disk without it.
12
Release Bulletin for Digital UNIX
Adaptive Server IQ 12.4.0 Sybase Central
7.4 Sybase Central
This section reports problems with the Adaptive Server IQ plug-in for Sy bas e
Central.
7.4.1 Problems with Add User-defined Data Type wizard
When you create a user-defined data type, the Adaptive Server IQ plug-in
allows you to specify a default value incompatible with the user-defined base
data type. For example, if you specify base type integer, you may insert a
character string ’test’ as default value.
In the Set Properties screen, the Add User-defined Data Type wizard lets you
select, “Do not allow null values.” Currently, you may select this option, but
after you finish and open properties on the data type, it displays Yes next to
“Allows null.”
7.4.2 DSE not installed on Windows client systems
On Microsoft Wi ndows 95 or 98 client system s, running the Directory Serv ices
Editor (DSE) utility from Sybase Central returns the following error:
Error Executing dsedit. Check
that the applications location
is in your Search path.
The Directory Services Editor is not installed with the Adapti ve Server IQ
Client Components on Windows 95 or Windows 98 systems. If you do not
install Open Client, you cannot run Open Client utilities.
7.4.3 Add Service utility installed only with Server Components
Adaptive Server IQ NT Service Manager is not installed with the Cl ient
Components. Do not use the Add Service utility on Windows NT unless you
have the Adaptive Server IQ Server Comp onents run ning on the same system.
If you attempt to do so, Sybase Central returns the following error:
Error Executing ASIQ Service. Check
that the applications location
is in your Search path.
If you do not install Open Client, you cannot run Open Client utilities.
7.4.4 Notification message setting omitted from Index Properties
Release Bulletin for Digital UNIX 13
Data Type column in Table Editor retains focus Adaptive Server IQ 12.4.0
When you use the Add Index Wizard to create a new index, the Choose IQ
Index T ype s creen lets yo u specify the numb er of records t hat should be added
before sending a notification message. The p roperties screen for the index do es
not display this setting, however.
7.4.5 Data Type column in Table Editor retains focus
In rare situations in the Table Editor, the focus may stay on the Data Type
column when tabbing through the Table Editor.
8. Product compatibilities
See the Adaptive Server IQ Installation and Feature Guide for Digital UNIX
for a list of client application tools that have been certified with Adaptive
Server IQ version 12.4.0.
9. Documentation updates and clarifications
This section contains information omitted from documentation and new
information that needs emphasis. It is organized into the following categories:
• Startup, shutdown, and connection
• Data definition (DDL)
• Data manipulation (DML)
• Backup and system administration
• Client application
• Help file
9.1 Startup, shutdown, and connection
9.1.1 Server startup requir e me nts
The following clarification should be added to the Adaptive Server IQ
Administration and Performance Guide.
14
You sh ould always us e the
platforms. If you do not, among the tasks you must do which the utility
normally does for you are:
Release Bulletin for Digital UNIX
start_asiq utility to start the server on UNIX
Adaptive Server IQ 12.4.0 Additions to the start_asiq or asiqsrv12 command-line options
• Remove all limits, and then set limits on the stack size and descriptors. To
do so, go to the C shell and issue these commands:
% unlimit
% limit stacksize 8192
% limit descriptors 4096
Note Note that unlimit affects soft limits only. If you have any hard limits,
you must change them by setting kernel parameters.
• Set all server parameters appropriately in the asiqsrv12 command.
9.1.2 Additions to the start_asiq or asiqsrv12 command-line options
T wo server startup switches for database caching are new as of version 12.03.1.
The following details about these new options will be added to the next update
of the Adaptive Server IQ Administration and Performance Guide and the
Adaptive Server IQ Reference.
T wo parameters f or the
override the database cache parameters that are set using the
command. If the user has not set the parameters, the defaults are 8MB for the
main cache size and 4MB for the temporary cache size. The following new
server switches override values of the database options.
Switch Description
-iqmc number_of_MB Specify main cache size in MB. (Overrides
-iqtc number_of_MB Specify temporary cache size in MB. (Overrides
Two other new command-line options,
database recovery , and r ecover leaked space. See “Forced recover y and leaked
space recovery” on page 36 for details.
9.1.3 Specifying server switches
The range of permissible values for the -iqsmem switch was listed incorrectly
in Chapters 2 and 12 of the Adaptive Server IQ Administration and
Performance Guide, and in Chapter 2 of the Adaptive Server IQ Reference. The
correct range is platform-specific. For Digital UNIX systems the range is up to
28,000 MB. The
systems.
start_asiq (on UNIX) or the asiqsrv12 command line
SET OPTION
default.)
default.)
-iqfrec and -iqdroplks, let you force
start_asiq utility does not set this switch on Digital UNIX
Release Bulletin for Digital UNIX 15
-gm command line option Adaptive Server IQ 12.4.0
The
-iqmt switch is not set by start_asiq on Digital UNIX systems. The setting
listed in the Adaptive Se rver IQ Administration and Performance Guide and
the Adaptive S erver IQ Instal lation and Feat ure Guid e is incorrect. The default
value is calculated from the number of connections and the number of CPUs,
and is usually adequate.
9.1.4 -gm command line option
The description of the server parameter -gm in the Adaptive Server IQ
Reference Manual shoul d read as fol lows.
-gm
num
Limit the number of connections to the server that can be active
at one time. If this number is greater than the number that is allowed under
licensing constraints, it has no effect. The value should approximate the
number of users expected to connect to the server.
9.1.5 -gn command-line option
The -gn server parameter should be added to Chapte r 2 o f the Ad aptive Server
IQ Reference Manual and to “Controlling performance from the command
line” in Chapter 2 of the Adaptive Server IQ Administration and Performance
Guide.
Function
Syntax asiqsrv12 -gn
Applies to
Description
Set the number of execution threads for the Catalog Store.
integer
All operating systems and servers.
Set the number of execution threads that will be used for the Catalog S tore and
connectivity while running with m ultiple users.
On Windows NT you need to specify this parameter in the
command. To calculate its value use the following formula:
gn_value
=
gm_value
Specify a minimum of 25.
On UNIX platforms, the
start_asiq utility sets this parameter. See the Adaptive
Server IQ Installation and Feature Guide for your plat form for more
information.
9.1.6 Using -v switch on 64-bit platforms
16
Release Bulletin for Digital UNIX
...
- (( 2 *
num_CPUs
asiqsrv12
) + 10)
Adaptive Server IQ 12.4.0 Confirming connections
The following note should be added to Chapt er 2, “The Database Server ,” after
the descript ion of the
Note In order to display the version on 64–bit platforms, you must do the
-v server switch.
following:
•Run
start_asiq -v instead, which will set up the correct paths, environment,
iq parameters, etc... Anything you pass to
asiqsrv12. End users should always use start_asiq.
• Add
$ASDIR/lib/iqstubs to the beginning of the library path. However,
remember, once you set this you will not be able to u se any executables in
$SYBASE, as they will now pick up the wrong libraries.
9.1.7 Confirming connections
In Chapter 2 of the Adaptive Server IQ Administration and Performance
Guide, in the section “Introduction to connections”, the second paragraph
incorrectly states that
select db.name() can be used to confirm a connection.
The correct syntax is:
select db_name()
to display the current database, or
select db_name([
to display any database you sp ecify.
9.1.8 Using ODBC connectivity with UNIX
On UNIX systems, Adaptive Server IQ installation installs onl y the ODBC
driver, and not the driver man ager. If you are using an ODBC application that
uses libodbc.so (libodbc.so.1) or libodbcinst.so (libodbcinst.so.1), simply
create symbolic links for these that point to $SYBASE/as iq12/lib/dbodbc6. so.1.
If you are creating a custom ODBC application, you can link directly to
dbodbc6.so.
database_id
start_asiq will be passed to
])
References to ODBC functions are resolved at run time. On UNIX, ODBC data
sources are held in a file named .odbc.ini. Edit this file with any text editor to
specify data sources. For details, see “Using ODBC data sources on UNIX,” in
Chapter 2 of the Adaptive Server IQ Administration and Performance Guide.
Release Bulletin for Digital UNIX 17
Using a .odbc.ini file Adaptive Server IQ 12.4.0
If Adaptive Server IQ does not detect the presence of an ODBC driver
manager, i t wi ll u se ~/.o dbc. ini for data source information. Otherwise, it will
query the driver manager for data source info rmation.
9.1.9 Using a .odbc.ini file
The following corrections apply to “Using ODBC data sources on UNIX,” in
Chapter 2 of the Adaptive Server IQ Administration and Performance Guide.
When creating a .odbc.ini file on any UNIX system, you must use the long
form of each identifier, as follows:
[My Data Source]
EngineName=myserver
CommLinks=tcpip
UserID=dba
Password=sql
The database server looks for the .odbc.ini file in:
1 The directory specified by the ODBCHOME environment variable
2 The directory specified by the HOME environment variables
3The path
The database server ignores the ODBC_HOME, ODBC_INI and ODBCINI
environment variables.
9.1.10 stop_asiq utility
The stop_asiq utility is new for version 12.03.1. Use this command to shut
down an Adaptive Server IQ server and close all user connections to it.
When you issue the stop_asiq command, Adaptive Server IQ lists Adaptive
Server IQ processes for your user ID and asks if you want to stop them. For
example:
18
Release Bulletin for Digital UNIX
express@janed> stop_asiq
Checking system for ASIQ 12 Servers ...
The following 1 process(es) were found.
UID PID PPID C STIME TTY TIME CMD
janed 6331 1 1 14:42:21 pts/1 0:19 asiqsrv12
@/express1/users/janed/sybase/asiq12/demo/asiqdemo.cfg
/express1/user
Do you want to stop the above process(es) <Y/N>?
Adaptive Server IQ 12.4.0 Addition to STOP DATABASE statement
Y
------------------------------------------------------
-
If you type Y (yes), the following message displays:
------------------------------------------------------
-
Shutting down asiqsrv12 ......... (server shutdown).
-------------------------------------------------
If you type N, you are returned to the system promp t and IQ does not shut down
the server. I f no running servers were star ted by your user ID, Adaptive Server
IQ displays information about processes run by other users, as follows:
----------------------------------------------- express@janed> stop_asiq
Checking system for ASIQ 12 Servers ...
There are no ASIQ 12 Servers on this system owned by
’janed’
There were 6 other ASIQ 12 processes(s) found
UID PID PPID C STIME TTY TIME CMD
aharring 13870 13869 0 Jun 07 ? 1:20 asiqsrv12
-c 16m -gc 6000 -gd all -gr 6000 -gm 10 -gp 4096 -ti
4400 -tl 300 asi
teds 16255 5843 0 Jun 07 pts/27 0:03 asiqsrv12 gd all -tl 120 -gm 10 -n writer -gp 4096 -x
tcpip{port=6907}
jamesfay 3683 1 0 23:32:14 ? 14:33 asiqsrv12
-gc 6000 -gr 6000 -gm 10 -n express_daily_49765 -c 16M
-gp 4096 -gd a
redisch 5486 1 4 10:10:40 pts/6 348:20 asiqsrv 12
-c 16m -gc 6000 -gd all -gr 6000 -gm 10 -gp 4096 -ti
4400 -tl 300 -n
maryc 16800 1 0 Jun 07 ? 30:10 asiqsrv12
@mary.cfg asiqdemo.db -o
/express1/users/maryc/12031/asiq12/logfiles/
ambler 26982 1 0 Jun 09 pts/18 13:11 asiqsrv12
@asiqdemo.cfg -N 6
-----------------------------------------------
Be sure to check with users before shutting down their servers.
9.1.11 Addition to STOP DATABASE statement
Release Bulletin for Digital UNIX 19
Error in DBSTOP exampl e Adaptive Server IQ 12.4.0
The following in formation should be added to the
in the Adaptive Server IQ Reference.
When you issue
STOP DATABASE
the database-name is the name specified in the -n parameter when the database
is started, or in the
typically the file name of the database file that holds the Catalog Store, without
the .db extension.
9.1.12 Error in DBSTOP example
The Introduction to Adaptive Server IQ documentation on the Stop utility is
incomplete. In the section “Shutting down a database server,” in Chapter 3, the
UNIX system example shows no command parameters.
When you stop the server with the
same parameters as when you started the server. Using a configuration file to
start the server ensures that you will be able to find these parameters when you
need them.
9.1.13 Disconnect details omitted
The following information was omitted from the Introductio n to Adaptive
Server IQ: It should be added in Chapter 4 after the section titled “Viewing
connected users”:
STOP DA T ABASE statement
database-name
DBN (DatabaseName) connection parameter . This name is
DBSTOP command, you need to specify the
Disconnecting users
If there are multiple connected users, Sybase Central lists them when you
attempt to disconnect.
When you choose Tools —> Disconnect —> Adaptive Server IQ, a Filter
Objects dialog box appears. Each database name is qualified by a server name,
for example:
myserver.asiqdemo (DBA)
Select the desired database to disconnect and click OK.
9.1.14 Configuration files do not accept quotes
Do not use either single or double quotes when specifying server switches in
configuration files.
20
Release Bulletin for Digital UNIX
Adaptive Server IQ 12.4.0 -Z switch must be uppercase
The parameter string in the sample configuration file shown in Chapter 2 of the
Adaptive Server IQ Administration and Performance Guide should be
corrected to:
-n Elora
-c 16M
-x tcpip(port=2367)
-gm 10
-gp 4096
path\mydb.db
9.1.15 -Z switch must be uppercase
In Chapter 2 of the Adaptive Server IQ Administration and Performance
Guide, in the seventh bulleted item under “What to do if you can't connect to
an Adaptive Server IQ database, the
-z command-line option should be -Z. This
switch must always be specified uppercase.
9.2 Data definition (DDL)
9.2.1 Change to CREATE DATA BASE statement
The defaults and minimums for the IQ SIZE and TEMPORARY SIZE
parameters of CREATE DATABASE, for operating system f iles only, were
stated incorrectly in the Adaptive Server IQ Reference. The default and
minimum value depend on
IQ PAGE SIZE.
Table 2: Default and minimum sizes of IQ and Temporary Stores
Minimum
Minimum
IQ PAGE
SIZE
1024 512000 256000 1MB 1MB
2048 512000 256000 1MB 1MB
4096 512000 256000 1MB 1MB
8192 512000 256000 1MB 1MB
16384 1024000 512000 1MB 1MB
32768 2048000 1024000 2MB 1MB
65536 4096000 2048000 4MB 2MB
131072 8192000 4096000 8MB 4MB
262144 16384000 8192000 16MB 8MB
524288 32768000 16384000 32MB 16MB
IQ SIZE
default
TEMPORARY
SIZE default
explicit IQ
SIZE
explicit
TEMPORARY
SIZE
Release Bulletin for Digital UNIX 21
MESSAGE PATH Adaptive Server IQ 12.4.0
9.2.2 MESSAGE P ATH
In the MESSAGE PA TH clause of C REATE DATABASE you must specify an
operating system file. The message file cannot be on a raw partition. This is a
correction to the Adaptive Server IQ Reference.
9.2.3 Low_Disk functions as High_Group
LD (Low_Disk) has been changed to function like HG (High_Group). It is no
longer supported by a separate index and therefore does not offer any benefit
beyond using HG . LD is still a valid syntax and may be used for compatibility
with older versions.
9.2.4 Column Limit Correction
In Chapter 13 of the Adaptive Server IQ Reference the limit is incorrectly
specified as 999 columns. The correct limit is 10,000 columns.
9.2.5 Joint Virtual Table (JVT) definition
A Join Virtual Table is a denormalized table which looks like a regular table; it
has a name, columns, rows, and indexes. Unlike a regular table, however, a
JVT cannot be created, modified or deleted by the user. It is created by
Adaptive Server IQ as a result of a Create Join Index for internal processing
purposes. It is deleted when the user does a Drop Join Index.
Error messages relating to join virtual tables appear only when a user tries to
use or modify a JVT directly.
9.2.6 IQ database file paths must be unique
When you create a database or a dbspace, the path for the Temporary Store
must differ from the path for the IQ Store. If your
CREAT E DBSPACE command specifies the identical path and filename for
these two stores, you receive an error. This requirement was om itted from the
Adaptive Server IQ Refer en ce and the Adaptive Server IQ Administration a nd
Performance Guide.
You can cause a unique path in any of these ways:
• Specify a different extension for each file (for example, mydb.iq and
mydb.iqtmp)
• Specify a different file name (for example, mydb.iq and mytmp.iq)
22
Release Bulletin for Digital UNIX
CREATE DATABASE or
Adaptive Server IQ 12.4.0 Error documenting IQ PATH
• Specify a different pathname (for example, /iqfiles/main/iq and
/iqfiles/temp/iq or different raw partitions
• Omit
TEMPORARY PATH when you create the d atabase. In this case, the
temporary store is created in the same path as the Catalog Store, with the
default name and extension dbname.iqtmp where dbname is the database
name.
Warning! On UNIX platforms, you must be careful not to specify filenames
that are links to the same file. IQ cannot detect where linked files point to. If
the filenames in the command differ but they point to the same file, your
database will be corrupted.
In Sybase Central, the Create Database utility fails if you do not provide
extensions for file names. The Introduction to Adaptive Server IQ fails to
mention this and also does not mention that file extensions are needed when
operating system files are used.
9.2.7 Error documenting IQ PATH
In Chapter 3 of the Adaptive Server IQ Administration and Performance
Guide, the example shown in the section titled “Specifying an IQ PATH”
should be corrected. The example shows where Adaptive Server IQ puts the
message and log files when you do not specify the Temporary and Message
PATHS. It should read:
The Temporary Store is in
/disk1/iqdata/company.iqtmp
The IQ message log file is in /disk1/iqdata/company.iqmsg
9.2.8 Error in raw partition limit
The Adaptive Server IQ Reference contains an error in the CREATE
DATABASE
statement description of the IQ PATH clause. The statement that
raw partitions cannot be larger than 2GB is incorrect. The current limit is
128GB per file or dbspace, with a limit of 2047 dbspaces.
9.2.9 Error on CREATE DBSPACE
The CREATE DBSPACE command may occasionally return the following
message:
1999-02-05 16:09:45 0002 [20152]:
You have run out of IQ STORE dbspace
Release Bulletin for Digital UNIX 23
SIZE clause of CREATE DBSPACE Adaptive Server IQ 12.4.0
in database /tech1/iq/cdrdb.db.
In another session, please issue a CREATE DBSPACE ...
IQ STORE command
and add a dbspace of at least 1000 blocks.
After commit and checkpoint messages, the following error displays:
1999-02-05 16:12:53 0001
Exception Thrown from hos_ion.cxx:170,
Err# 4, tid 102 origtid 102
1999-02-05 16:12:53 0001
O/S Err#: 2, ErrID: 522 (hos_ioexception)
1999-02-05 16:12:53 0001 File does not exist.
File: /tech1/iq/cdrdb.iq2
-- (hos_ion.cxx 170)
After many intervening commit and checkpoint messages, the following
message displays:
The DBA has added 1 IQ STORE dbspaces
to database /tech1/iq/cdrdb.db.
Adaptive Server IQ (TM) is no longer
waiting for more dbspace.
1999-02-05 16:14:52 0002 [20902]: Insert completed.
Index ’CDR.DBA.CDR_FE_FP_lf’,
These messages are only informational. This is normal behavior as the server
verifies that the dbspace does not yet exist, and no action is required. Such
messages will be suppressed in a future release.
9.2.10 SIZE clause of CREATE DBSPACE
This clarification affects the Adaptive Server IQ Refer ence and Adaptive Server
IQ Administration and Performance Guide.
Y ou can onl y specify
SIZE for the IQ Store and IQ T empor ary Store, not for the
Catalog Store.
9.2.11 Addition to DROP DATABASE statement
The following information should be added to the DROP DATABASE
statement in the Adaptive Server IQ Reference.
The database must be stopped before you can drop it. If the connection
24
parameter
statement.
Release Bulletin for Digital UNIX
AUTOSTOP=no is used, you may need to issue a STOP DAT ABASE
Adaptive Server IQ 12.4.0 Recommended index types
9.2.12 Recommended index types
In the Adaptive Server IQ Administration and Performance Guide, Chapter 4,
“Adaptive Server IQ Indexes,” in Table 1–2, Query type/index, the
recommende d index types for
COUNT and range predicate are incorrect. The
correct types are:
Ty pe of Query Usage Recommended Index Type
COUNT argument LF or HG
As
In range predicate in WHERE clause (>,
<, >=, <=,
Note While HNG is recommended, in certain cases LF or HG is faster, and is
often used in place of
the performance of
BETWEEN
HNG. HNG tends to give consistent performance, while
LF or HG with ranges depends on the size of the range
LF or HNG
selected.
9.2.13 Changes to “Using join indexes”
The section “Using join indexes” in the Adaptive Server IQ Administration and
Performance Guide, Chapter 4, “Adaptive Server IQ Indexes, has several
errors, described below.
Privileges needed to create a join index
The book states that you must be the owner of a table or the DBA to create,
alter, or synchronize a join index that includes that table.
If you are not the DBA, you need to be owner of the table and have
RESOURCE authority in order to create a join index.
One-to-many relationship
The following changes apply to the subsection “O ne-to-many relationship.”
The first sentence of the third paragraph should read, “If the join column is
made up of more than one column, the combination of the values must be
unique on the “one” side.
The example described in the thir d and four th paragr aphs is chan ged to match
the asiqdemo database, and include sample rows that were omitted. The
warning that follows these paragraphs is also changed. The corrected
paragraphs read as follows:
Release Bulletin for Digital UNIX 25
Changes to “Using join indexes” Adaptive Server IQ 12.4.0
If the join column is made up of more than one column, the combination of the
values must be unique. For example, in the asiqdemo database, the id in the
customer table and the cust_id in the sales_or der table each con tain a customer
ID. The customer table contains one row for each customer and, therefore, has
a unique value in the id column in each row . The sales_ order table contains on e
row for each transaction a customer has made. Presumably, there are many
transactions for each customer, so there are multiple rows in the sales_order
table with the same value in the cust_id column.
So, if you join customer.id to sales_order.cust_id, the join relationship is one-
to-many . As you can see in the follo wing example, fo r every row in customer,
there are potentially many matching rows in sales_order.
select sales_order.id, sales_order.cust_id,
customer.lname
from sales_order, customer
where sales_order.cust_id = customer
id cust_id id lname
2583,101,101,’Devlin’
2001,101,101,’Devlin’
2005,101,101,’Devlin’
2125,101,101,’Devlin’
2206,101,101,’Devlin’
2279,101,101,’Devlin’
2295,101,101,’Devlin’
2002,102,102,’Reiser’
2142,102,102,’Reiser’
2318,102,102,’Reiser’
2338,102,102,’Reiser’
2449,102,102,’Reiser’
2562,102,102,’Reiser’
2585,102,102,’Reiser’
2340,103,103,’Niedringhaus’
2451,103,103,’Niedringhaus’
2564,103,103,’Niedringhaus’
2587,103,103,’Niedringhaus’
2003,103,103,’Niedringhaus’
2178,103,103,’Niedringhaus’
2207,103,103,’Niedringhaus’
2307,103,103,’Niedringhaus’
26
Warning! If the one-to-many relationship is incorrect, the join cannot be
synchronized until you remove the extra rows from the “one” tab le. If y ou try
to synchronize, you get a Duplicate Row error, and the transaction rolls back.
Release Bulletin for Digital UNIX
Adaptive Server IQ 12.4.0 Changes to “Using join indexes”
Creating star joins
The following should be added to Chapter 4 of the Adaptive Server IQ
Administration and Performance Guide just after the figure that shows the
sales_order table in a star join.
You can create this table using the following commands:
CREATE TABLE "DBA"."sales_order"
(
"id" integer NOT NULL,
"cust_id" integer NOT NULL
REFERENCES "DBA"."customer" ("id")
UNENFORCED,
"order_date" datetime NOT NULL,
"fin_code_id" char(2) NULL
REFERENCES "DBA"."fin_code" ("code")
UNENFORCED,
"region" char(7) NULL,
"sales_rep" integer NOT NULL
REFERENCES "DBA"."employee" ("emp_id")
UNENFORCED,
PRIMARY KEY ("id"),
);
Release Bulletin for Digital UNIX 27
Error in DISK_STRIPING default Adaptive Server IQ 12.4.0
9.3 Error in DISK_STRIPING default
The Adaptive Server IQ Reference contains an error in the General Database
Options table in Chapter 5, “Database Options.” The
DISK_STRIPING option
default should be ON.
9.4 Data manipulation (DML)
9.4.1 DISK_STRIPING default
The Adaptive Server IQ Reference contains an error in the General Database
Options table in Chapter 5, “Database Options.” The
default is ON for Windows NT, and OFF for UNIX.
9.4.2 Correction to Introduction
The first item under “Adaptive Server IQ benefits” in Chapter 1,
to Adaptive Server IQ
• Intelligent query processing: Adaptive Server IQ uses index-only access
plans to process only the data needed to satisfy any type of query
, should read:
DISK_STRIPING option
Introduction
9.4.3 STRIP load option clarification
The following clarification should be adde d to the Adaptive Server IQ
Administration and Performance Guide.
The
STRIP load option does not apply to ASCII fixed-width inserts. For
example, the
load table dba.foo
STRIP option in the following statement is ignored:
(col1 ascii(3), col2 ascii(3))
from foo_data
quotes off escapes off strip off
9.4.4 EXTENDED_JOIN_SYNTAX option
This option is new in Version 12.4.0 and should be add e d to the Adaptive
Server IQ Reference Manual.
Function
Allowed values
28
Controls whether queries with an ambiguous syntax for multi-table joins are
allowed, or reported as an error.
ON, OFF
Release Bulletin for Digital UNIX
Adaptive Server IQ 12.4.0 Default
Default
Description
ON
This option reports a syntax error for those queries containing outer joins that
have ambiguous syntax due to the presence of duplicate correlation names on
a null-supplying table.
The following join clause illustrates the kind of query that is report e d.
( R left outer join T , T join S on ( C1 ) )
where C1 is a condition. If the option is set to ON, this query is interpreted as
follows.
( R left outer join T on ( C1 ) ) join S on ( C2 )
where C1 and C2 are conditions.
9.4.5 Support for joins between stores or databases
This section clarifies current support for joins between stores or between
databases.
Any joins within a given IQ database are supported. This means that you can
join any system or user tables in the Catalog Store with any tables in the IQ
Store, in any order.
Joins of IQ tables with tables in an Adaptive Server Enterprise database are
supported under the following conditions:
• On UNIX platforms, the IQ dat abase must be t he remote databas e, and the
Adaptive Server Enterprise database must be the local database. In other
words, on ASE you must add the IQ server a remote server, and define the
IQ tables as proxy tables.
• On Windows NT, the IQ database can be either the local database or the
remote database.
Release Bulletin for Digital UNIX 29
New and changed general database options Adaptive Server IQ 12.4.0
• In order to join a local ASE table with a remote IQ 12 table, the ASE
version must be 11.9.2, and you must use the server class cd ASAnywhere.
Note Adaptive Server Enterprise 11.9.2 introduces new server classes to
be used for accessing remote databases fro m the ASE 11.9.2 system. Y o u
must use server class ASAnywhere to access Adaptive Server IQ 1 2.0x or
Adaptive Server Anywhere 6.x from ASE 11.9.2. Yo u use server class
ASIQ to access Adaptive Server IQ 11.5.1, 1 1.5.2, ... 11. 5.x (that is, 11.5.1
or later as stated in New Functionality in Sybase Adaptive Server
Enterprise 11.9.2 is not correct for ASIQ 12).
• When you join a local IQ table with any remote table, the local IQ table
must appear first in the FROM clause. This means that the local IQ table
is the outermost table in the join.
• The CHAR data type is incompatible between Adaptive Server Anywhere
and Adaptive Server IQ when the database is built with BLANK
PADDING OFF. If you want to perform cross-database joins between
ASA and ASIQ tables using character data as the join key, use the
VARCHAR data type or use CHAR with BLANK PADDING ON.
9.4.6 New and changed general database options
The following changes in general database options will be added to the next
update of the Adaptive Server IQ Administration and Performance Guide and
the Adaptive Server IQ Reference.
LOAD_MEMORY_MB option
This version includes a new option to simplify user control of heap memory
allocation during a load.
Function
Allowed Values
Default
30
Specifies an upper bound on the amount of heap memory subsequent loads can
use.
0 to 500
0 (zero)
Release Bulletin for Digital UNIX
Adaptive Server IQ 12.4.0 Description
Description
This option specifies an up per bound (in MB) on the amount of heap memory
subsequent loads can use. The default setting, 0 (zero), means that there is no
upper bound, and Adaptive Server IQ can use as much heap memory as
necessary to perform the load. A non-zero value means that the user has set an
upper bound. This option is typically used for LOAD statements, but af fects all
operations where loads occur, including SYNCHRONIZE and DELETE
operations.
Setting a non-zero value for this option is typically done to avoid
overallocating the physical memory on the machine and exhausting virtual
memory during a load operation. Given a user-specified upper limit, the load
process will attempt to ensure that the load can succeed even if it means
incurring degradation in load performance. However , every load requires some
minimal amount of heap memory. If the user-specified limit is lower than this
amount, the user will receive the following error:
The load user approximately <x> MB, but only <y> MB was specified
where <x> is a rough approximation of the minimum amount of heap memor y
needed and <y> is the upper limit set by the user. If this error occur s, then the
user must increase or turn off the Load_Memory_MB option and try again.
We are removing the following options and replacing them with the new
LOAD_MEMORY_MB option:
• INSERT_ NUMBER_PRODUCERS
• INSERT_ NUMBER_MT_B UFFERS
• INSERT_ NUMBER_RAW_IO_BUFFERS
• INSERT_NUMBER_ ROWS_PER_BUFFER
• INSERT_ NUMBER_ROWS_PER _RAW_IO_BUFFER
JOIN_PREFERENCE Option
This version includes two new option values, 6 and –6 to p refer or avoid usi ng
a join index.
Function
Allowed Values
Default
Controls the choice of algorithms when processing joins.
-6 to 6
0
Release Bulletin for Digital UNIX 31
Description Adaptive Server IQ 12.4.0
Description
For joins within a query, the IQ optimizer has a choice of several algorithms
for processing the join. This option allows you to override the optimizer’s
cost—based decision when choosing the algorithm to use. It does not override
internal rules that determine whether an algorithm is legal within the query
engine. If you set it to any non-zero value, it affects every join in a query; it
cannot be used to selectively modify one join out of several in a query.
This option is normally used for internal testing, and only experienced DBA's
should use it. The following table describes the valid values for this option and
their action.
Value Action
0 Let the optimizer choose
1 Prefer sort/merge
2 Prefer nested loop
3 Prefer nested loop push-down
4 Prefer hash
5 Prefer hash push-down
6 Prefer join index
-1 Avoid sort/merge
-2 Avoid nested loop
-3 Avoid nested loop push-down
-4 Avoid hash
-5 Avoid hash push-down
–6 Avoid join index
9.4.7 Corrections to INSERT LOCATION
These corrections apply to the Adaptive Server IQ Reference Manual and the
Adaptive Server IQ Administration and Performance Guide.
32
If you plan to use the
command), the Adaptive Server Enterprise server you are connecting to must
exist in the interfaces file on the local machine.
Also, the syntax in the Adaptive Server IQ Reference Manual is incorrect. The
servername.dbname must be enclosed in single quotes, and the
statement must be in braces. An example of correct syntax is:
INSERT CUSTOMERS LOCATION ’BOSTON.PUBS2’
Release Bulletin for Digital UNIX
INSERT LOCA TION command (syntax 3 of t he INSERT
SELECT
Adaptive Server IQ 12.4.0 String function REPEAT is supported
{ SELECT * FROM CUSTOMERS }
Note This syntax is not currently supported on Digital UNIX.
9.4.8 String function REPEAT is supported
The string function REPEA T is supported in Adaptive Server IQ version 12.x.
It is documented as follows:
REPEAT function
[String]
Function
Returns a string composed of integer-expression instances of stringexpression, concatenated together.
Syntax
REPEAT ( string-expression, numeric-expres sion )
Parameters
string-expression The string-expression to be repeated.
integer-expression The number of times the string-expres sion will be repeated .
Examples
The statement
SELECT REPEAT( ’repeat’, 3 )
returns the value repeatrepeatrepeat.
Standards and compatibility
SQL/92 Vendor extension.
Sybase REPEAT is not supported in Adaptive Server Enterprise, but
REPLICATE provides the same cap abilities.
9.4.9 Correction to CHAR function
The Adaptiv e Server IQ Refer ence Manual incorrectly lists the CHAR function
as accepting a string-expr argument. The correct syntax is
CHAR (
integer-expr
9.4.10 Number(*) function not supported
Release Bulletin for Digital UNIX 33
)
Using ISNULL() and COALESCE() Adaptive Server IQ 12.4.0
The
NUMBER(*) function is not supported and should be deleted from the
Adaptive Server IQ Reference Manual.
9.4.1 1 Using ISNULL() and COALESCE()
ISNULL() and COALESCE() can be used to convert NULL values into
something else. If these are used with an outer join, the production of this
expression gets pushed below the outer join. This behavior is acceptable on the
row-preserving side of the join, but on t he side that NULLs are added to, it can
produce incorrect results. The ISNULL is processed in the vertical cursor, then
NULLs are added in the outer join.
9.5 Backup and system administration
9.5.1 New options for reserving space
T wo new options let you control the amo unt of space reserved for adding mor e
disk space.
RESERVED_MAIN_DBSPACE_MB
Function
Controls the amount of space Adaptive Server IQ reserves for adding dbspaces
to the main IQ Store.
Allowed Values
Default
Description
Integer greater than zero, in megabytes
1
This option lets you control the amoun t of space Adaptive Serv er IQ sets aside
space in your main IQ St ore, so tha t if you run out of disk space there you can
add a new dbspace.
Adaptive Server IQ sets aside 1 MB by default. This value is usually sufficient
to run the DDL commands.
You do not need to set aside room to hold the new dbspace. This option only
provides space for executing related DDL commands.
RESERVED_TEMP_DBSPACE_MB
Function
Controls the amount of space Adaptive Server IQ reserves for adding dbspaces
to the Temporary IQ Store.
Allowed Values
34
Integer greater than zero, in megabytes
Release Bulletin for Digital UNIX
Adaptive Server IQ 12.4.0 Default
Default
Description
1
This option lets you control the amount of space Adaptive Server IQ sets aside
space in your temporary IQ Store, so that if you run ou t of disk space there you
can add a new dbspace.
Adaptive Server IQ sets aside 1 MB by default. This value is usually sufficient
to run the DDL commands.
You do not need to set aside room to hold the new dbspace. This option only
provides space for executing related DDL commands.
9.5.2 Change to error message
The following error message has been changed.
Full message text
You have run out of ’%1’ dbspace in database ’%2’. In another session, please
issue a CREATE DBSPACE ... ’%3’ command and add a dbspace of at least
’%4’ MB.
Item Value
SQLCode 1009131L
Constant EMSG_IQSTORE_OUTOFDISK_HEADER
SQLState QSB31
ODBC State 200152
Parameter 1 IQ STORE or IQ TEMPORARY STORE
Parameter 2 Name of the database that needs more space
Parameter 3 IQ STORE or IQ TEMPORARY STORE
Parameter 4 Minimum number of megabytes to add
9.5.3 Insufficient disk space
The following changes apply to the section “Insufficient disk space” in
“Appendix A, Troubleshooting Hints” of the Adaptive Server IQ
Administration and Performance Guide.
Replace the second and third Action items with the following text.
Actions
Main IQ Blocks Used:,10188 of 12288, 82%, Max Block#: 134840
• Try to connect to the database from a new connection. If this works, you
know that the datab ase server is r unning, even tho ugh the query is wai ting.
Then run
• Check the
Release Bulletin for Digital UNIX 35
sp_iqstatus to get more information.
sp_iqstatus output for the following two lines:
Effect of checkpoints Adaptive Server IQ 12.4.0
Temporary IQ Blocks Used:,163 of 6144, 2%, Max Block#: 97
If the percentage of blocks used is in the nineties , you need to add more
disk space with the
CREA TE DBSPACE command. In this example, 82%
of the Main IQ Blocks and 2% of the Temporary IQ Blocks are used, so
more space will soon be needed in the Main IQ Store.
Effect of checkpoints
Insert the following text at the start of the section “Effect of checkpoints on out
of disk space conditions.”
If Adaptive Server IQ has already run out of space when a checkpoint is
requested, the
You have run out of space during the CHECKPOINT
operation.
checkpoint command fails with the error:
You must add additional dbspace before any new checkpoints can proceed.
Adding the wrong ty pe
of space
Assume, for example, the temporary dbspace has run out of space, but you
accidentally add a main dbspace by omitting the
create dbspace command. Your cre ate dbspace command ha ngs, waiting for
you to add space to the first dbspace.
To continue, connect to the database from a new connection and create the
needed temporary dbspace. Once this is done, the other
main) completes and all waiting connections resume running.
9.5.4 Forced recovery and leaked space recovery
This section describes parameters, options, and procedures that allow forced
recovery and leaked space recovery. This information will be added to the
Adaptive Server IQ Administration and Performance Guide and the Adaptive
Server IQ Reference Manual in the next update.
Forced recovery
Under certain conditions, previous versions of Adaptive Server IQ 12 could
fail to recover a database after a system crash. Adaptive Server IQ 12.4.0
resolves this problem by adding a forced recovery option. The forced reco very
option returns the database to its last known consiste nt state. Forced recovery
should only be used when normal database recovery fails to restore the
database to a running state.
temporary keyword in the
create dbspace (for
36
Normal database recovery differ s from forced datab ase recovery in these ways:
• Forced recovery marks all storage within the database as in use. In
order to recover a potentially corrupt free list (allocation map) all storage
within the database is marked as in use. You can return the storage
allocation to its correct value by using the server startup paramet er
-iqdroplks and the sp_iqcheckdb storage procedure. See details below.
Release Bulletin for Digital UNIX
• Incremental backups are disabled After the database is opened in
forced recovery mode, incremental backu ps are disabled. The next backup
must be a full backup. Doing a full backup reenables incrementals.
• Forced recovery affects all databases opened The forced recovery
parameter applies to all opens of the database while th e server is up.
Therefore, after the database is opened, the DBA needs to bring the server
back down, and then restart the server without the forced recovery flag, to
be sure that subsequent opens run in regular mode. Repeated opens of the
database with forced recovery on do not harm the database, but could be
confusing to the DBA because each forced recovery open marks all the
storage within the database as in use.
• Use the -gd switch during forced recovery. Sybase recommends that
you start the IQ server with the
-gd switch set to restrict access to the
server to the DBA. Forced recovery operates in all modes, but restricted
access gives the DBA greater control over inadvertent opens of the
database.
Leaked space
recovery
New server startup
parameters
Either through system failure or as a result of opening a database with forced
recovery, a database’s allocation map may not reflect the true allocation of its
usage. When this occurs, we say that it has “leaked” storage. Adaptive Server
IQ 12.4.0 resolves this problem by adding the ability to recover leaked storage.
When leaked storage is being recovered, other transactions that alter the
allocation map are shut out. Such operations include checkpoints, and
commands that modify the database.
T wo new server startup p arameters,
run-time setting,
dbcc_option, support the new forced recovery and leaked
-iqfrec and -iqdroplks, and one additional
storage recovery feature.
The following table describes the new server startup parameters.
Parameter Scope Description
-iqfrec
dbname
-iqdroplks
dbname
database Marks the specified
database as in use an d
restores database to its last
known consistent state.
database Allows the sp_iqcheckdb
stored procedure to recover
leaked storage within the
specified database.
37
To verify that the data is not corrupt and set the database storage to its actu a l
value, you start the server with the
database. You then set the option
-iqdroplks switch and connect to the
dbcc_option and run the sp_iqcheckdb
stored procedure. Dependin g on resul ts, you may need to reset t his opti on and
rerun the procedure. See the discussion below for details.
New set option
dbcc_option option
Function
Allowed values
Default
Description
A new set option, dbcc_option, controls the actions performed by
sp_iqcheckdb. This option applies only to the database you are connected to
when you set the option.
Overrides the default operation of sp_iqcheckdb
0 - 3
0
The value of this option determines the processing that sp_iqcheckdb does.
Value Action
0 Runs default action:
• If
-iqdroplks was specified during server startup, runs
CheckStorage Fix. Checks for leaked blocks and corrupt
database pages by walking all the block maps in the system and
reading every database page. If no error is detected, resets
database free list to calculated allocation map. If an error is
found, it is reported in
• If -iqdroplks was not specified during server startup, runs
.iqmsg file, but free list is not altered.
GatherStatistics. Produces report. If severe error found,
server may terminate.
In this read-only mode,
database to prevent other writers. Therefore, it may incorrectly
report that leaks were detected, because it did not see new
versions of objects outside its transactional scope.
1Runs CheckAllocation. Checks for leaked blocks by walking all
block maps in the system. Runs very fast (about 1 second per GB
of data). Produces a report of findings. Does not reset the free list.
This option provides a fast method of determining if the data ba se
has potentially leaked any storage.
sp_iqcheckdb does not lock the
38
Value Action
2Runs CheckStorage. Checks for leaked bloc ks and corrupt
database pages by walking all the block maps in the system and
reading every da tabase page. Runs about 50 times slower th an
option 1. Produces a repo rt of fi nding s. Doe s not re set the free list.
This option is the same as the default optio n whe n
passed to the server except that it runs in read-only mode.
3Runs CheckAllocation Fix. Server must have been started with -
iqdroplks
maps in the system. Runs very fast (abo ut 1 second per GB of
data). Produces a report of findings. If no error is detected, resets
database free list to calculated allocation map.
Sybase recommen ds that you use this option to recover the
database free list only when the default option cannot do so due to
errors encountered during processing, and no backed up version is
available to restore.
switch. Checks for leaked blocks by walking all block
-iqdroplks is
Running
sp_iqcheckdb
In order to recover leaked storage within a database, first start the server with
the
-iqdroplks switch in the asiqsrv12 command.
Next, connect to your database and issue the command:
sp_iqcheckdb
The stored procedure reads all storage within the database. On successful
completion, it updates the database free list to reflect the true storage allocation
for the database. It then generates a report listing the working and actions it has
performed.
If it finds an error,
sp_iqcheckdb reports the name of the object and the type
of error found. It does not update the free list if any errors are detected.
Because it reads the entire database,
sp_iqcheckdb may take a long time to
run. The length of time depends on the size of the database and the size of the
machine it executes on. Typically,
sp_iqcheckdb can process between 20GB
and 100GB per hour.
The
dbcc_option settings of 1 and 3 provide a fast way to check for leaked
storage within the sy stem. They do th is by walking the var ious bl ock maps , or
object directories, that make up the database. The underlying database pages
that make up the actual tables and indexes are not read. Therefore, successful
completion of
sp_iqcheckdb using op tion 1 or 3 does not guaran tee absolutely
that the database is not corrupt.
39
The dbcc_option settings of 0 and 3, when combined with the server option
-iqdroplks, update the free list if no errors are detected. In order to perform this
function, write transactions are prevented before and during the running of
sp_iqcheckdb. The stored procedure ensures this by taking the appropriate
locks during its execution. Any write transactions are blocked while
sp_iqcheckdb is running.
If it detects transactions that are not committed or not checkpointed,
sp_iqcheckdb may refuse to recover leaked blocks. If this occurs, issue a
checkpoint command and r erun sp_iqchec kdb. If sp_iqchec kdb still refuses
to run, other users with active write transactions are connected to the database.
❖ To recover leaked space:
In the event that the default option (dbcc_option = 0) cannot recover the free
list, and a previous backup i s no t avai labl e, us e the f ol lowi ng pro cedur e t o try
to recover the database.
1 Start the server with the
-iqdroplks switch in the start_asiq command (on
UNIX) or asiqsrv12 command.
2 Set dbcc_option to 3, as a temporary option:
SET TEMPORARY OPTION dbcc_option = 3
3 Run the stored procedure:
sp_iqcheckdb
Note If this procedure fails, it is likely that the database is corrupt and
beyond repair.
4 Set dbcc_option to 2, as a temporary option:
SET TEMPORARY OPTION dbcc_option = 2
5 Run the stored procedure again:
sp_iqcheckdb
6 From the report generated, drop the objects reporti ng errors.
7 With dbcc_option still set to 2, rerun the stored procedure to ensure no
errors are present:
sp_iqcheckdb
8 Reset dbcc_option to the default value, 0:
40
SET OPTION dbcc_option = 0
Example
Assume that the DBA cannot successfully open and connect to database foo,
because of reported IQ errors during database open and recovery. To force
recovery and correct leaked space, follow the steps below.
Note Do not confuse an inability to connect to a database with an IQ server-
level error while IQ is trying to open a database.
1 Start the database server with the
asiqsrv12 -iqfrec foo ... -gd dba ... foo.db
or on UNIX
start_asiq -iqfrec foo ... -gd dba ... foo.db
2 Connect to the database (foo).
The .iqmsg file repo rts that the database was opened in forced recovery
mode.
3 Bring down the server as you would no rmally . (If you u se
down the server, be sure to include
4 Start up the server again with the
asiqsrv12 -iqdroplks foo ... -gd dba ... foo.db
5 Connect to the database. It will be fully allocated.
6 To correct the leaks created by the forced recovery open, run
sp_iqcheckdb on foo.
9.5.5 Improved output in stored procedures
Several stored procedures now display output in units that are easier to
understand. The following table describes the new column names. The stored
procedure
stored procedures
display all of these columns except Info.
sp_iqindexsize displays all of these columns except Nblocks. The
sp_iqdbsize, sp_iqtablesize, and sp_iqjoinindexsize
-iqfrec switch:
dbstop to bring
-iqfrec in the dbstop command.)
-iqdroplks switch:
Table 3: New Stored Procedure Columns
Column name Description
Kbytes Physical object size in KB
Pages Number of IQ pages ne ed e d to hold the object in
memory
Compressed Pages Number of IQ pages when the object is compressed (on
disk)
41
Column name Description
Nblocks Number of I Q blocks
Info Component of the IQ index for which the Kbytes, Pages,
and Compresse d Pa ge s are be ing reported. The
components vary by index type . For example, the default
(FP) index includes BARRAY and Bitmap (BM)
components. The Low_Fast (LF) index includes Btree
(BT) and Bitmap (BM) components.
9.5.6 SP_IQSTATUS now di splays IQ Page Size
The sp_iqstatus sto red pr ocedu re now di s plays the IQ page size in addit ion t o
the block size. For example, Adaptive Server IQ used to display:
Block Size: 512/2bpc
It now displays:
Page Size: 1024/512blksz/2bpc
9.5.7 MIN_PASSWORD_LENGTH option
The MIN_PASSWORD_LENGTH option is new in this version.
Function
Allowed values
Sets the minimum length for new passwords in the database.
Integer, greater than or equal to zero.
The value is in bytes. For single-byte character sets, this is the same as the
number of characters.
Scope
Can be set for the PUBLIC group. Takes effect immediately . DBA perm issions
are required to set this option.
Default
Description
0 characters
This option allows the database administrator to impose a minimum length on
all new passwords for greater security. Existing passwords are not affected.
Example
• Set the minimum length for new passwords to 6 bytes.
9.5.8 T ransaction Log utility
The following information on the Transaction Log utility should be added to
the Adaptive Server IQ Administration and Performance Guide and the
Adaptive Server IQ Reference.
42
SET OPTION PUBLIC.MIN_PASSWORD_LENGTH = 6
When you use the
RESTORE statement to move and/or rename a database, you
can rename all of the files except the transaction log. Transactions continue to
be written to the old log file name, in the location where the Catalog Store file
(the .db file) is located after the database is restored.
When you rename or mo ve al l o ther files in the database, it is preferable to do
the same for the log file. To move or rename the log file, you use the
Transaction Log utility (
DBLOG). You should run this utility:
• After using
• After using
Note The database server must not be running on that database when the
transaction log filename is changed. If you try to use this utility on a running
database, you get an error message.
You can access the Transaction Log utility fro m the system command line,
using the
The DBLOG command-line utility
Syntax dblog
Switches
Description
Switch Description
-m mirror-name Set transaction log mirror name.
-t log-name Set the transaction log name
The DBLOG command line utility allows you to display or change the name
of the transaction log or transaction log mirror associated with a database. You
can also stop a database from maintaining a transaction log or mirror, or start
maintaining a transaction log or mi rro r.
RESTORE with a new database name
RESTORE with the RENAME option
DBLOG command-line utility.
[switches] database-file
Transaction log utility options
Set the name of the transaction log mirror file (-m )
filename for a new transaction log mirro r . If the database i s not currently us ing
a transaction log mirror, it starts using one. If the database is already using a
transaction log mirror, it changes to using the new file as its transaction log
mirror . Most Adaptive Server IQ databases do not use a transaction log mirror,
so this switch is rarely used.
This option sets a
43
Set the name of the transaction log file (-t ) This option sets a filename,
including an optional directory path, for a new transaction log. If the database
is not currently using a transaction log, it starts using one . If the datab a se is
already using a transaction log, it changes to using the new file as its
transaction log.
9.5.9 Error message for buffer cache settings
The following paragraph describes a change in behavior as of Version 12.4.0.
It should be added to the section “Do not exceed physical memory ” in Chapter
12, Managing System Resources,” in the Adaptive Server IQ Administration
and Performance Guide.
If you set buffer cache sizes higher than your system will accommodate,
Adaptive Server IQ will not successfully open the database. The new cache
options for start up
-iqmc and -iqtc should now be used to open the database
and reset the defaults.
9.5.10 Setting Prefetch_Buffer_Limit opti on
The SET op tion PREFETCH_BUFFER_LIMIT defines the number of cache
pages available to Adaptive Server IQ for use in prefetching (the read ahead of
database pages). This option has a default value of 20, which can degrade
multi-user performance. Sybase recommends that you set this option to 0 for
multi-user applications. This option was omitted from Chapter 12, “Managing
System Resources,” of the Adaptive Server IQ Administration and
Performance Guide. For more information, see the Adaptive Server IQ
Reference.
9.5.11 GRANT CONNECT for existing user ID
The following clarification should be added to Chapter 10, “Managing User
IDs and Permissions” in Adaptive Server IQ Administration and Performance
44
Guide, and to the
If you have DBA authority, you can change the password of any existing user
with the following command:
GRANT CONNECT TO
GRANT statement in Adaptive Server IQ Reference.
userid
IDENTIFIED BY
password
The same command can also be used to add a new user. For this reason, if you
inadvertently enter the user ID of an existing user when you mean to add a new
user, you are actually changing the password of the existing user. You do not
receive a warning because this behavior is considered normal. This behavior
differs from pre-Version 12 Adaptive Server IQ.
T o avoid this situation, use the syst em procedures sp_addlog in and sp_adduser
to add users. These procedures give you an error if you try to add an existing
user ID, as in Adaptive Server Enterprise, and pre-Version 12 Adaptive Server
IQ.
9.5.12 Dropping users may delete tables
The following warning should be added to “Revoking user permissions” in
Chapter 10, “Managing User IDs and Permissions” in Adaptive Server IQ
Administration and Performance Guide, and to the
Adaptive Server IQ Reference.
Warning! If you revoke a user's connect privileges, any database objects
owned by that user are delet ed without warni ng. Likewise, if you u se the stored
procedure sp_dropuser to drop a user, database objects owned by that user are
dropped without warning. To avoid this problem, remove objects owned by a
user or assign them to another user before issuing
sp_dropuser.
REVOKE statement in
REVOKE CONNECT or
Note Procedures like sp_dropuser provide minimal compatibility with
Adaptive Server Enterprise stored procedures. If you are accustomed to
Adaptive Server Enterprise (or Adaptive Server IQ 11.x) stored procedures,
you should compare their text with Adaptive Server IQ 12 procedures before
using the procedure in
sp_helptext
dbisql. To compare, use the command
sp_name_in_question
9.5.13 Documentation on Data Backup and Recovery
The chapter on backup and data recovery in the Adaptive Server Anywhere
User’s Guide has been superseded by new information in Chapter 11, “Backup
and Data Recovery” of the Adaptive Server IQ Administration and
Performance Guide. The Adaptive Server Anywhere data backup and reco very
information should not be used.
45
9.5.14 Changes to BACKUP statement
In the Adaptive Server IQ Reference, the SIZE and STACKER option
descriptions in the
SIZE option Specifies maximum tape or file capacity (some platforms do
not reliably detect end-of-tape markers). No volume used on the corresponding
device should be shorter than thi s value. This val ue applies to both tap e and
disk files but not 3rd party devices. Units are KB so , for example, for a 3.5 GB
tape you specify 3500000. Default for disk files is 2GB. No default exists for
tape on UNIX platforms.
For tape devices on Windows NT:
BACKUP statement should read:
• The value of
• If you specify a
SIZE must be a multiple of 64.
SIZE that is not a multiple of 64, it is automatically
rounded down to a multiple of 64.
• If you do not specify
STACKER option Specifies that the device is automatically loaded, and
specifies the number of tapes it is loaded with. This value is not the tape
position in the stacker, which could be zero. When ATTENDED is OFF and
STACKER is ON, Adaptive Server IQ will wait for a pre-determined amount
of time waiting for the next tape to be auto-loaded. The number of tapes
supplied along with the SIZE option will be used to determine whether there is
enough space to store the backed up data. Do no t use this option with 3rd par t
media management devices.
9.5.15 Cleaning up after abnormal exit
Killing processes may result in semaphores or shared memory b eing left
behind instead of being cleaned up automatically. To eliminate unneeded
semaphores, you should periodically run the
status of semaphores and shared memory.
The
ipcs –a command lists the ID numbers, owners, and create times of
semaphores and shared memory segments. When all Adaptive Server IQ
instances are started by the same user (as Sybase recommends), you can search
the OWNER column for that username. Identify shared memory segments and
semaphores that have a very old create date but have not been used recently.
SIZE explicitly, it is automatically set to 1.5GB.
-ipcs command to check the
46
After verifying with the owner that these are indeed unused, run
command to remove them. Use the
segment id and the
–s command to specify the semaphore id number, in the
–m parameter to specify the memory
ipcrm
following format:
ipcrm -m mid1 -m mid2 ... -s sid1 -s sid2 ...
For example:
% ipcrm -m 40965 -s 5130 -s36682
9.5.16 Monitoring server activity
It may be helpful, especially for new users, to monitor server activity. When
you start a server with the
ASCII text file placed in the directory defined by $ASLOGDIR. (If
$ASLOGDIR is not defined, it defaults to $ASDIR/logfiles.)
The log file name has this format:
your_server_name.###.srvlog
Each time you start the server, the number is incremented. For example, your
directory may look like this:
demo.001.srvlog demo.002.srvlog
janedemo.001.srvlog
For information about your most recent session, choose the log with the largest
number for the desired server . Issue a
For example:
% tail -f demo.002.srvlog
When you run start_asiq, specify the –Z option to enhance the log file with
additional information about connections. This will help new users or those
troubleshooting connection problems.
start_asiq utility, server activity is logged in an
tail –f command to view the log contents.
To check if a particular server is running, log into the machine where it was
started, and issue the command:
% ps -eaf | grep asiqsrv12
maryc 24836 25554 0 Feb 09 - 17:36
asiqsrv12 -c 16m -gc 6000 -gd all
-gr 6000 -gm 10 -gp 4096 -ti 4400
-tl 300 -iqmt 450 -iqsmem 2560
@fnma.cfg asiqdemo.db
janed 28932 38122 0 11:39:24 - 2:10
asiqsrv12 -c 16m -gc 6000 -gr 6000
-gm 10 -gp 4096 -ti 4400
-tl 300 -iqsmem 2560 -n janedemo -gd all
-iqmt 256 -x tcpip(port=1872)
In addition, the command % stop_asiq wil l display all Adaptive Server IQ
processes ru nning.
47
9.6 Client applications
9.6.1 ODBC AutoPreCommit omitted
The ODBC AutoPreCommit option was omitted from the Adaptive Server IQ
Reference. Turning this option ON causes each statement to do a COMMIT
before execution (as opposed to a COMMIT after execution for the
AutoCommit option). The default for AutoPreCommit is OFF.
Set the AutoPreCommit option in either the Windows (NT/95) registry or the
.ini file (Windows 3.1). For example:
[Sample DSN]
UID=DBA
PWD=SQL
AutoPreCommmit=y
9.6.2 Using PC client applications
The following notes apply to PC client applications certified with Adaptive
Server IQ:
• With BrioQuery, each query requires you to connect to the database. Be
sure to close the query after processing to ensure that the connection to
Adaptive Server IQ is closed. If you leave multiple queries open, you
could consume more connections than you realize, eventually preventing
other users from connecting to Adaptive Server IQ (since the number of
configured connections would be exceeded).
• With Business Objects, you should chan ge Password_Encryption = 1 to
Password_Encryption = 0.
9.6.3 Creating attribute tables for PowerBuilder
In order to create attribute tables for PowerBuilder properly, you need to run
the iqpb.sql script located i n the Server di rectory on th e PowerBui lder produ ct
CD against Sybase Adaptive Server IQ v.12.0.x using the provided Adaptive
Server IQ ODBC driver. Earlier versions of PowerBuilder (6.5 and below) do
not include the script. In this case, you may ob tain the script from the Sybase
FTP website. Contact your PowerBuilder support representative if you need
additional information or PowerBuilder 7.0.
9.7 Help files
48
9.7.1 Adaptive Server IQ plug-in help reflects Multiplex support
Adaptive Server IQ Multiplex 12.4.0 is a separate product from Adaptive
Server IQ 12.4.0. If you have not purchased or installed Adaptive Server IQ
Multiplex, the functionality described in the online help topic Managing
Multiplexes is not available.
10. Technical Support
Each Sybase installation that has purcha sed a support cont ract has one or more
designated people who are authorized to contact Sybase Technical Support. If
you have any questions about this install ation or i f you need as sist ance during
the installation process, ask the designated person to contact Sybase T echnical
Support or the Sybase subsidiary in your area.
Before you contact
Technical Support
Before contacting Technical Support, collect the following:
• operating system platform (For example, Sun Solaris 2.6 (SPARC))
• front end tool or connectivity protocol used (For example, Brio Query)
• configuration type (single user or multi-user)
• message log file
File named dbname.iqmsg in the directory, located by default where you
started the database server.
• stack trace file
File named stktrc.iq in the directory where you started the database server.
• command or query that produced the error
• query plan
Enter the following commands and then rerun the com mand that produced
the error
SET TEMPORARY OPTION Query_Plan = ’ON’
SET TEMPORARY OPTION Query_Detail = ’ON’
The plan will be in the message log file.
• startup option settings
• connect option settings
• database option settings
• schema and indexes for the database
49
• Output from sp_iqstatus procedure
You may find additional help from the Sybase online support database,
MySupport. MySupport lets you search through closed support cases, latest
software bulletins, resolved and known problems, using a view customized for
your needs. You can even open a technical support case online.
MySupport can be used from most Internet browsers. Open the MySupport
home page, mysupport.sybase.com, and follow the instr uctions provided there
to sign up for and use this free service.
11. Other sources of information
Use the Sybase T echnical Libr ary (av ailable on CD and the web) resou rces to
learn more about your product:
• T echnical Lib rary CD contains p roduct manuals and technical do cuments
and is included with your software. The DynaText browser (included on
the Technical Library CD) allows you to access technical information
about your product in an easy-to-use format.
Refer to the Techn i cal Library Installation Guide
package for instructions on installing and starting Technical Library.
• T echnical Library W eb site includes the Product Manuals site, which is an
HTML version of the Technical Library CD that you can access using a
standard Web browser. In addition, you’ll find links to the Technical
Documents Web site (formerly known as Tech Info Library), the Solved
Cases page, and Sybase/Powerso ft newsgroups.
To access the Technical Library Web site, go to
support.sybase.com
, scroll down to
Library heading.
Support Services, and select a link under the Technical
11.1 Sybase Certifications on the Web
Technical documentation at the Sybase Web site is updated frequently.
❖ For the latest information on product certifications and/or the EBF
Rollups:
1 Point your Web browser to Technical Documents at the following Web
site:
in your documentation
50
techinfo.sybase.com
2 In the Browse section, click on the What’s Hot entry.
3 Explore your area of interest: Hot Docs covering various topics, or Hot
Links to Technical News, Certification Reports, Partner Certifications,
and so on.
❖ If you are a registered SupportPlus user:
1 Point your Web browser to Technical Documents at the following Web
site:
techinfo.sybase.com
2 In the Browse section, click on the What’s Hot entry.
3 Click on the EBF Rollups entry.
You can research EBFs using Technical Documents, and you can
download EBFs using Electronic Software Distribution (ESD).
4 Follow the instructions asso ciated with the SupportPlus
SM
Online
Services entries.
❖ If you are not a registered SupportPlus user and you want to become
one:
You can register by following the instructions on the Web.
To use SupportPlus, you need:
1 A Web browser that supports the Secure Sockets Layer (SSL), such as
Netscape Navigator 1.2 or later
2 An active support license
3 A named technical support contact
4 Your user ID and password
❖ Whether or not you are a registered SupportPlus user
You can use Sybase’s Technical Documents. Certification Reports are among
the features documented at this site
1 Point your Web browser to Technical Documents at the following Web site
techinfo.sybase.com
2 In the Browse section, click on the What’s Hot entry.
3 Click on the topic that interests you.
51
52
Loading...
