Installation Guide

Replication Server

15.0

[ UNIX ]

DOCUMENT ID: DC32237-01-1500-03 LAST REVISED: November 2006

Information in this document is subject to change without notice. The software described herein is furnished under a license agreement, and it may be used or copied only in accordance with the terms of that agreement.

To order additional documents, U.S. and Canadian customers should call Customer Fulfillment at (800) 685-8225, fax (617) 229-9845. Customers in other countries with a U.S. license agreement ma y co ntac t Customer Fulfillment via the above fax number. All other

international customers should contact their S ybase subsidiary or local distributor. Upgrades are provided only at regularly scheduled software release dates. No part of this publication may be reproduced, transmitted, or translated in any form or by any means, electronic, mechanical, manual, optical, or otherwise, without the prior written permission of Sybase, Inc.

Sybase, SYBASE (logo), ADA Workbench, Adaptable Windowing Environment, Adaptive Component Architecture, Adaptive Server, Adaptive Server Anywhere, Adaptive Server Ente rprise, Ada ptive Ser ver Enter prise Monitor , Adaptive Ser ver Enterprise Replica tion, Adaptive Server Everywhere, Advantage Database Server, Afaria, Answers Anywhere, Applied Meta, Applied Metacomputing, AppModeler, APT Workbench, APT-Build, APT - Edit, APT-Execute, APT-Translator, APT-Library, ASEP, Avaki, Avaki (Arrow Design), Avaki Data Grid, AvantGo, Backup Server, BayCam, Beyond Connected, Bit-Wise, BizTracker, Certified PowerBuilder Developer, Certified SYBASE Professional, Certified SYBASE Professional Logo, ClearConnect, Client-Library, Client Services, CodeBank, Column Design, ComponentPack, Connection Manager, Convoy/DM, Copernicus, CSP, Data Pipeline, Data Workbench, DataArchitect, Database Analyzer, DataExpress, DataServer, DataWindow, DataWindow .NET, DB-Library, dbQueue, Dejima, Dejima Direct, Developers Workbench, DirectConnect Anywhere, DirectConnect, Distribution Director, Dynamic Mobility Model, e-ADK, E-Anywhere, e-Biz Integrator, E-Whatever, EC Gateway , ECMAP, ECRTP, eFulfillment Accelerator, EII Plus, Electronic Case Management, Embedded SQL, EMS, Enterprise Application Studio, Enterprise Client/ Server, Enterprise Connect, Enterprise Data Studio, Enterprise Manager, Enterprise Portal (logo), Enterprise SQL Server Manager, Enterprise Work Architecture, Enterprise Work Designer, Enterprise Work Modeler, eProcurement Accelerator, eremote, Everything Works Better When Everything Works Together, EWA, ExtendedAssist, Extended Systems, ExtendedView, Financial Fusion, Financial Fusion (and design), Financial Fusion Server, Formula One, Fusion Powered e-Finance, Fusion Powered Financial Destinations, Fusion Powered STP , Gateway Manager, GeoPoint, GlobalFIX, iAnywhere, iAnywhere Solutions, ImpactNow, Industry W a r ehouse St udio, InfoMaker, Information Anywhere, Information Everywhere, InformationConnect, InstaHelp, Intelligent Self-Care, InternetBuilder, iremote, iScript, Jaguar CTS, jConnect for JDBC, KnowledgeBase, Legion, Logical Memory Manager, lrLite, M2M Anywhere, Mach Desktop, Mail Anywhere Studio, Mainframe Connect, Maintenance Express, Manage Anywhere Studio, MAP, M-Business Anywhere, M-Business Channel, M-Business Network, M-Business Suite, MDI Access Server, MDI Database Gateway, media.splash, Message Anywhere Server, MetaWorks, MethodSet, mFolio, Mirror Activator, ML Query, MobiCATS, MobileQ, MySupport, Net-Gateway, Net-Library, New Era of Networks, Next Generation Learning, Next Generation Learning Studio, O DEVICE, OASiS, OASiS logo, ObjectConnect, ObjectC ycle, OmniConnect, OmniQ, OmniSQL Access Module, OmniSQL Toolkit, OneBridge, Open Biz, Open Business Interchange, Open Client, Open ClientConnect, Open Client/Server, Open Client/Server Interfaces, Open Gateway, Open Server, Open ServerConnect, Open Solutions, Optima++, Partnerships that Work, PB-Gen, PC APT Execute, PC DB-Net, PC Net Library, Pharma Anywhere, PhysicalArchitect, Pocket PowerBuilder, PocketBuilder, Power++, Power Through Knowledge, power.stop, PowerAMC, PowerBuilder, PowerBuilder Foundation Class Library, PowerDesigner, PowerDimensions, PowerDynamo, Powering the New Economy, PowerScript, PowerSite, PowerSocket, Powersoft, PowerStage, PowerStudio, PowerTips, Powersoft Portfolio, Powersoft Professional, PowerWare Desktop, PowerWare Enterprise, ProcessAnalyst, Pylon, Pylon Anywhere, Pylon Application Server, Pylon Conduit, Pylon PIM Server, Pylon Pro, QAnywhere, Rapport, Relational Beans, RemoteWare, RepConnector, Report Workbench, Report-Execute, Replication Agent, Replication Driver, Replication Server, Replication Server Manager, Replication Toolkit, Resource Manager, RFID Anywhere, RW-DisplayLib, RW-Library, SAFE, SAFE/PRO, Sales Anyw he re , Search Anywhere, SDF, Search Anywhere, Secure SQL Server, Secure SQL T oolset, Security Guardian, ShareLink, ShareSpool, SKILS, smart.partners, smart.parts, smart.script, SOA Anywhere Trademark,SQL Advantage, SQL Anywhere, SQL Anywhere Studio, SQL Code Checker, SQL Debug, SQL Edit, SQL Edit/TPU, SQL Everywhere, SQL Modeler , SQL Remote, SQL Serve r, SQL Server Manager, SQL SMART, SQL Toolset, SQL Se rver/CFT, SQL Server/D B M , SQ L Se rv e r SNMP SubAgent, SQL Station, SQLJ, Stage III Engineering, Startup.Com, STEP, SupportNow, S.W.I .F.T. Message Format Libraries, Sybase Central, Sybase Client/Server Interfaces, Sybase Development Framework, Sybase Financial Server, Sybase Gateways, Sybase Learning Connection, Sybase MPP , Sybase SQL Desktop, Sybase SQL Lifecycle, Sybase SQL Workgroup, Sybase Synergy Program, Sybase Virtual Server Architecture, Sybase User Workbench, SybaseWare, Syber Financial, SyberAssist, SybFlex, SybMD, SyBooks, System 10, System 11, System XI (logo), SystemTools, Tabular Data Stream, The Enterprise Client/Server Company, The Extensible Software Platform, The Future Is Wide Open, The Learning Connection, The Model For Client/Server Solutions, The Online Information Center, The Power of One, TotalFix, TradeForce, Transact-SQL, Translation Toolkit, Turning Imaginatio n Into Real ity, UltraLite, UltraLite.NET, UNIBOM, Unilib, Uninull, Unisep, Unistring, URK Runtime Kit for UniCode, Viafone, Viewer, VisualWriter, VQL, WarehouseArchitect, Warehouse Control Center, W a rehouse Studio, W a rehouse WORKS, W atcom, W atcom SQL, Watcom SQL Server, Web Deployment Kit, Web.PB, Web.SQL, WebSights, WebViewer, WorkGroup SQL Server, XA-Library, XA-Server, XcelleNet, XP Server, XTNDAccess and XTNDConnect are trademarks of Sybase, Inc. or its subsidiaries. 07/06

Unicode and the Unicode Logo are registered trademarks of Unicode, Inc. All other company and product names used herein may be trademarks or registered trademarks of their respective companies. Use, duplication, or disclosure by the government is subject to the restrictions set forth in subparagraph (c)(1)(ii) of DFARS 52.227-7013

for the DOD and as set forth in FAR 52.227-19(a)-(d) for civilian agencies. Sybase, Inc., One Sybase Drive, Dublin, CA 94568.

Contents

About This Book............................................................................................................................ v

CHAPTER 1 Before You Begin............................................................................ 1

Introduction ...................................................................................... 1

Replication Server components ................................................ 1

Installation task overview .......................................................... 2

Sybase Software Asset Management.............................................. 2

How SySAM works.................................................................... 3

Using an unserved license ........................................................ 3

Using a network license server ................................................. 4

Using multiple network license servers ..................................... 6

Using three-server redundancy................................................. 7

Using alternative license file locations....................................... 8

Co-existing with earlier versions of SySAM............................... 8

License usage and enforcement............................................. 10

License availability and grace periods..................................... 11

Pre-installation tasks...................................................................... 13

Read the release bulletin......................................................... 13

Plan your replication system ................................................... 14

Review system requirements .................................................. 14

Understand the installation directory structure........................ 16

Set the required environment variable for dsedit utility ........... 19

Perform administrative tasks................................................... 20

SySAM pre-installation tasks................................................... 21

CHAPTER 2 Installing Replication Server........................................................ 25

Using InstallShield for installation................................................... 25

Installing Replication Server........................................................... 27

Installing in command line mode............................................. 33

Troubleshooting installation..................................................... 36

Uninstalling Sybase products......................................................... 37

CHAPTER 3 Post-Installation Tasks................................................................. 39

Installation Guide for UNIX iii

Contents

Review the log files........................................................................ 39

Start Adaptive Server for the RSSD............................................... 40

Start the sample Replication Server............................................... 40

Set environment variables.............................................................. 41

APPENDIX A SySAM Administration.................................................................. 43

Managing licenses ......................................................................... 43

Using the options file to manage licenses............................... 45

Starting and stopping network license servers............................... 46

Borrowing a license to work offline................................................. 48

Enabling the network license server REPORTLOG file ................. 50

Using SAMreport............................................................................ 50

SAMreport system requirements............................................. 51

Installing the Java Runtime Environment................................ 52

Post-installation tasks for SAMreport...................................... 54

Starting and Stopping SAMreport............................................ 54

Managing and collecting logs.................................................. 55

Using SySAM utilities..................................................................... 55

Index ............................................................................................................................................. 57

Replication Server

About This Book

Audience

How to use this book

Introduction

Before You Begin

This chapter provides information about system and licensing requirements for installing Replication Server. It also discusses other pre-installation tasks you must complete before you install Replication Server.

Topic Page

Introduction 1 Sybase Software Asset Management 2 Pre-installation tasks 13

This section describes the components of Replication Server and provides an overview of the tasks involved in installing and setting up Replication Server.

Replication Server components

Replication Server consists of the following components:

• Replication Server

• RepAgent™ for Adaptive Server Enterprise

• Replication Server support files (for example, scripts and configuration files)

• Adaptive Server® Anywhere for Embedded Replication Server System Database (ERSSD)

• RepAgent for ERSSD

Installation Guide fo r UNIX 1

Sybase Software Asset Management

• The Replication Server Administration tool, which consists of:

• Sybase Central version 4.3

• Replication Manager plug-in (RM) to Sybase Central

• Replication Monitoring Services (RMS)

Installation task overview

The Replication Server Installation Guide for UNIX explains how to unload the Replication Server software from the distribution media to your hard disk.

The Replication Server Configuration Guide for UNIX explains how to:

• Gather the information you need to prepare your system for the installation

• Install Replication Servers and add databases to your replication system

• Upgrade existing Replication Server System Databases (RSSDs)

• Downgrade existing RSSDs and then reinstall an earlier version of the software

• Enable password encryption for a Replication Server or RepAgent

• Start and stop Replication Server or RepAgent

Sybase Software Asset Management

Replication Server version 15.0 includes a new Sybase Software Asset Management System (SySAM) implementation. SySAM configuration is no longer optional, which results in installation and configur ation changes.

SySAM product licensing software allows you to:

• Manage Replication Server entitlements

• Perform asset management tasks by viewing and analyzing historic use data

• Control Replication Server use within your organization

2 Replication Server

How SySAM works

Replication Server uses SySAM to “check out” a license for product functionality, then checks the license back in when the product is no longer in use. The basic SySAM components are:

• Replication Server linked with SySAM libraries

• One or more local license files

• Optionally, a SySAM network license server When you install the product, you select whether to configure an unserved

license or a network license server. Both configurations create a local license file on the same machine as Replication Server in $SYBASE/SYSAM-2_0/licenses. When you start Replication Server, the product searches for a license in the default location—$SYBASE/SYSAM- 2_0/licenses—looking at all files with a .lic extension. The local license file contains the actual licenses or a pointer to a SySAM network license server. When a license is successfully checked out, Replication Server starts.

Using an unserved license

When you configure an unserved license, Replication Server d oes not connect to a network license server, but obtains the required license information directly from the local license file.

CHAPTER 1 Before You Begin

When you use an unserved license configuration, there is no network license server. In this configuration, Replication Server reads the unserved license an d directly checks out the required license. You activate the licenses for each machine separately; that is, you do not have centralized control over licenses. You also do not have asset managemen t or reporting capabilities, and the license must be rehosted if you mov e Replicat ion Server from one machi ne to another.

When using an unserved configuration, the local $SYBASE/SYSAM-2_0/licenses directory contains all necessary licenses. You do not maintain a license server.

Installation Guide fo r UNIX 3

Sybase Software Asset Management

Setting up an unserved configuration

During Replication Server installation, select the option to use a local license file. When you are activating licenses from

Download Center (SPDC) at https://sybase.subscribenet.com

“unserved” license format and save the license in the local license directory $SYBASE/SYSAM-2_0/licenses.

Using a network license server

When you configure a network license server, the server uses two daemons— the

lmgrd FLEXlm daemon and the vendor (SYBASE) daemon—to handle

license check-in and check-out for licensed products. Using the pointer in the local license file, Replication Server connects to the network license server and attempts to check out a license (REP_SERVER).

In a network license server configuration, the license server host runs the network license server. The local license file on the Replication Server machine contains a pointer to the network license server.

Figure 1-1: Network license server configuration

the Sybase Software Product

, select the

4 Replication Server

Multiple users connect to the network license server to obtain the required license. You can activate several licenses at once, you have full control over license use, and you have acces s to co mplete as s et man agement and reporting capabilities.

You can use an existing network license server or install a new one. You can install network license server on the same host with Replication Serv er , or as a standalone system. The number of free cycles on the machine with R eplication Server and the total expected license server activity should dictate whether a standalone system is needed. For system requirements, see Chapter 4, “Selecting License Server Machines,” in the FLEXnet Licensing End User Guide.

Setting up a network license server

To install a network license server on a separate system, use the Replication Server installation program, select only the SySAM server components, and complete the installation. When activating licenses at the Sybase Product Download Center, select the “Served” license model. Save the activated license file in your machine’s $SYBASE/SYSAM-2_0/licenses directory. See “Installing a new license server” on page 22 for instructions.

CHAPTER 1 Before You Begin

T o configure Replication Server to use the network server , specify the network server host name and port number during installation. Specify the host ID for the network license server host when you obtain a license from the Sybase Software Product Download Center. After installation, you can edit the SYBASE.lic file in $SYBASE/SYSAM-2_0/licenses and change the network license server host name and port number if necessary.

Note A license responds only to the license server that you specify when you

obtain the license from the Sybase Software Product Download Center.

Limitations

The SySAM network license server has the following limitations: 1 You cannot st art the SySAM network license server until there is at least

one “Served” license copied into the licenses directory . Obtain a “Serve d” license from the Sybase Software Product Download Center before starting the license server. See “Managing licenses” on page 43.

Installation Guide fo r UNIX 5

Sybase Software Asset Management

2 Replication Server version 15.0 uses a newer version of the SySAM

licensing technology and an updated license format. On any one machine, you can have only one instance of a licens e server running. You must make some adjustments to use earlier versions with Replication Server 15.0. See “Co-existing with earlier versions of SySAM” on page 8.

Using multiple network license servers

As part of a failover plan or a load-balancing system, you can have multiple SySAM network license servers running a subset of the total licenses. The SySAM network license servers can be connected by a local area network (LAN) or by a wide area network (WAN).

This configuration is an excellent load-balancing mechanism for physically distant locations. You can specify the local servers ahead of the remote servers in the license location list.

To specify multiple license servers, set up the SYBASE_LICENSE_FILE or LM_LICENSE_FILE environment variable to contain a list of license files, where each license file refers to one of the network license servers. Replication Server uses this list to checkout licenses, starting with the first server on the list. If check-out fails for any reason, Replication Server attempts to check out licenses using the second server in the list, and so on.

Although this configuration provides a basic level of failover protection, if one or more license servers in the list are down, the licenses served by these servers are no longer available, so the total number of available licenses is reduced until the servers restart.

Note See “Redundant License Server Systems” in Chapter 4, “Selecting

License Server Machines,” of the FLEXnet Licensing End User Guide.

Setting up multiple network servers

T o use multiple network license s ervers, install a network license serv er on two or more servers using the instructions in “Installing a new license server” on page 22.

To configure Replication Server to use multiple network servers, specify the network server addresses in the SYBASE_LICENSE_FILE environment variable as port@host separat ed by a semicol on. Fo r example:

6 Replication Server

set SYBASE_LICENSE_FILE=1700@tokyo;1700@chicago

Replication Server attempts to use the first server in the list. If that fails for any reason, Replication Server tries to use the second server.

Using three-server redundancy

T o achieve true high availability, you can set up Replication Server to acquire a license that is used in a three-server redundant configuration. The same license is served by all three license servers. With three-server redundancy, if any two of the three license servers are running (referred to as a quorum), the system is functional and serves its total complement of licenses.

Machines in a three-server redundant configuration must:

• Run the same operating system

• Communicate with each other

• Reside on the same subnet The three servers must be located physically close to each other. This form of

redundancy requires that the servers exchange heartbeats periodically, and poor communication can cause poor performance. Avoid configuring redundant servers with slow communication or dial-up links.

CHAPTER 1 Before You Begin

Three-server redundancy prov ides on ly har dware fai lover pro tection an d does not provide load-balancing because only one of the three servers is “master,” capable of issuing licenses. Because all clients must contact the “master,” all clients must have reliable networ king to a si ngle machine. To implement loadbalancing, see “Setting up multiple network servers” on page 6.

Note Because Sybase provides grace periods for any licensing issues, setting

up the license servers for failover may be unnecessary. Replication Server operations are not compromised as long as license server issues are fixed within the grace period.

Setting up three-server redundancy

To use three-server redundancy, you must obtain licenses that are set up for such an environment. When you activate your licens es, specify the three-server redundancy option.

Installation Guide fo r UNIX 7

Sybase Software Asset Management

Install the network license server on the three selected machines and deploy the license obtained on all three machines. See “Installing a new license s erver” on page 22 for instructions.

To configure Replication Server to use these redundant network servers, specify the addresses for three servers in SYBASE_LICENSE_FILE environment variable as port@host separated by a semicolon. For example:

set SYBASE_LICENSE_FILE 1700@srv1;1700@srv2;1700@srv3

Any two of the servers specified in SYBASE_LICENSE_FILE must be running for checkout to succeed.

Using alternative license file locations

You can specify alternate license locations using the SYBASE_LICENSE_FILE and LM_LICENSE_FILE envir onment variable s. The product looks at the locations provided in these variables before looking in the default location.

Note See “Specifying Location of the License File” in Chapter 2, “License

File Basics,” of the FLEXnet Licensing End User Guide.

Co-existing with earlier versions of SySAM

Replication Server version 15.0 us es a newer version of the SySAM licens ing technology and an update d license format. On any machine, you can have only one instance of a license server running. You must make some adjustments to use earlier versions of Sybase products with Replication Server 15.0.

Case 1: If you are using a central network server f or Replication Ser ver 15.0,

and a network license server-based SySAM license for earlier versions of the product, migrate to Replication Server version 15.0:

1 Update the network license software with the version provided in

Replication Server 15.0. Use the instructions in “Setting up a network license server” on page 5.

2 Copy the earlier license files (typically, a single file named license.dat)

into the new $SYBASE/SYSAM-2_0/licenses directory and rename license.dat to license.lic.

8 Replication Server

CHAPTER 1 Before You Begin

3 Shut down the old license server and start the new license server. 4 Copy any new licenses into this new directory. Old and new Sybase software now use this license server.

Case 2: If you are using individual license servers for earlier versions of

Replication Server, with each mach ine running earlier Sybase s oftware hosting a local license server, Sybase recommends that you move to a single network license server model to migrate to Replication Server version 15.0.

❖ Using a central license server only for new licenses

1 Select the machine for the new network license server and install the

SySAM network license server supplied with Replication Ser ver version

15.0 on that machine.

2 If this machine is already running an older license server, use the

instructions in Case 1 to migrate the local licenses. All new licenses are now installed on this machine.

3 Point the Replication Server version 15.0 installation to this license server.

Use the

lmpath utility (see “Using SySAM utilities” on page 55) to do this

or edit license.dat and add these lines at the beginning of the file:

SERVER <network license server hostname> ANY <license server port> VENDOR SYBASE USE_SERVER

❖ Migrating old licenses to a new central license server

1 Set up the new SySAM network license server using the instructions in

“Setting up a network license server” on page 5.

2 Collect licenses from all old local license servers to deploy to the new

network license server. a Create a new license file that includes the contents of all individual

licenses from each earlier local license server. When you create the new license file, discard the license h eader from

each file. The header is the first three lines that start with “SER VER,” “VENDOR,” and “USE_SERVER .”

b Create one license header with the above three lines in the merged file

to match the requirements on th e new network license ser ver and save this file as license.lic in the licenses directory.

Installation Guide fo r UNIX 9

Sybase Software Asset Management

3 Shut down the earlier individual license servers on each machine and point

the software to the new license server. Use the SySAM utilities” on page 55) to do this, or edit the license.dat file on each installation by adding these lines at the beginning of the file:

SERVER <network license server hostname> ANY <license server port> VENDOR SYBASE USE_SERVER

lmpath utility (see “Using

Case 3

If you are not using the network license serv er for Replication Server version 15.0, no changes are required t o the previous software. When fulfi lling Replication Server vers ion 15.0 licenses, select the unserved license model and copy the license locally on each installation. The software runs appropriately, however, you lose the asset management functionality in this approach. See “Choosing the appropriate license server configuration” on page 21 for the pros and cons of using a network licens e server versus using a local license file .

Managing licenses from multiple vendors

If you use software from multiple vendors that use Macrovision’s FLEXnet technology , you can consolidate licenses from all vendors to centrally manage the licenses. See Chapter 3, “Managing Licenses from Multiple Vendors,” in the FLEXnet Licensing End User Guide.”

License usage and enforcement

This section describes the licenses used by Replication Server and other enforcement mechanisms.

• License Features Used – when Replication Server starts, it first check s out

a license for the base Replication Server, which is REP_SERVER.

• Number of licenses used – the number of licenses used for Replication

Server depends on the license type under which Replication Server was licensed.

For Replication Server licensed under any of the Server license types such as SR, SV, and so on, one license is checked out per Replication Server. Starting additional Replication Server instances on the same machine does not check out additional licenses.

For Replication Server licensed under any of the CPU license types such as CP, SF, and so on, the number of licenses used is the number of physical CPUs.

10 Replication Server

Some Windows and Linux machines use technologies such as “Hyper Threading” which presents one physical CPU as two logical CPUs. This is still considered one CPU for counting licenses.

License availability and grace periods

If Replication Server cannot obtain a su itable license, the product does n ot run. A license is considered unavailable if it cannot be checked out, or if the license cannot be issued during a grace period. Licenses can be unavailable during start-up or heartbeat runtime.

When SySAM detects a checkout failure, the event is logged in the Replication Server error log, which you can use to diagnose any unexpected licensing failures. After the initial checkout failure, periodic events are logged during a grace period.

If a suitable license cannot be found when requested, Replication Server evaluates if a license can be issued during a grace period. There are three types of grace periods:

• Install time – when you co nfigure a new Replicat ion Server (or up grade an earlier version to 15.0), you have 30 days to activate and configure the appropriate license.

CHAPTER 1 Before You Begin

• Runtime – a runtime grace period is evaluated when one of these conditions occurs:

• A license was not checked out at start-up, but there is a history of

successfully using the requested license on this machine.

• A license that was successfully checked out at start-up becomes

unavailable at a later time.

If Replication Server encounters either situation, it enters into a 30-day runtime grace period. If the problem is not resolved within 30 days, Replication Server stops running; however, the us er can save any work and exit. If the problem that causes the license to be unavailable is fixed during the runtime grace period, Replication Server automatically picks up the license and no longer operates in the grace period.

• Support renewal time – this grace period allows you enough time to update the license after renewing support. The support grace period for Replication Server is one year.

This means that you can install and use EBFs and updates that are released up to one year past the end-of-support date recorded in the license.

Installation Guide fo r UNIX 11

Sybase Software Asset Management

If Replication Server cannot obtain a license, SySAM evaluates whether the license can be issued under a grace period. The grace periods evaluated are described in “License availability and grace periods” on page 11.

If a SySAM license cannot be acquired

If the license cannot be issued during the grace period, Replication Server does not start and errors are reported in the error log file.

The error messages indicate the product’s inability to obtain a valid license, and why the license could not be obtained. You must fix the license failure before you can use Replication Server.

Acquiring SySAM licenses during the grace period

If the license can be issued during the grace period, the issue is logged and Replication Server starts. The log entry looks similar to this:

I. 2005/11/24 22:11:43. SySAM: Using licenses from: /opt/sybase/SYSAM-2_0/licenses I. 2005/11/24 22:11:44. SySAM: Checked out graced license for 1 <license_name> (2005 .1114) will expire Sat Dec 24 22:10:31 2005. I. 2005/11/24 22:11:44. SySAM: Failed to obtain 1 license(s) for <license_name> feature from license file(s) or server(s). I. 2005/11/24 22:11:44. SySAM: Cannot find license file.

12 Replication Server

CHAPTER 1 Before You Begin

Replication Server continues to operate normally until the issue causing the license failure is fixed, or until the grace period expires. The error message indicates the date and time the grace period is scheduled to end. The error log entry is repeated with increasing frequency while Replication Server operates in the grace period until you fix the issue causing the license failure. When the issue is fixed, Replication Server automatically acquires the license and moves from grace period mode into normal mode. If Replication Server cannot obtain the license before the grace period expires, Replication Server stops running.

Note If you obtain a Replication Server license from a network license server,

Replication Server periodically executes a heartbeat with the network license server. A successfully acquired license could be invalidated during the heartbeat; for example, if the license has an expiration date or the network license server was restarted an d other Replication Server instances acquired all available licenses before this instance could reacquire a license. If this happens, Replication Server enters a grace period. This information is written in the error log, and is similar to the information written to the error log when you initially start the product.

Pre-installation tasks

Before you install Replication Server, follow the steps outlined in this section.

Read the release bulletin

The release bulletin contains last-minute information about installing and upgrading Replication Server software.

Your Sybase products shipment includes printed release bulletins. They are also available on the

http://www.sybase.com/support/manuals

Installation Guide fo r UNIX 13

Product Manuals Web page at

Pre-installation tasks

Plan your replication system

The Replication Server Configurat ion Guide for UNIX provides th e necessary information, including an installation worksheet and a database setup worksheet to help you plan your replication system. Become familiar with Chapter 1, “Preparing to Install and Configure Replication Server” and the requirements of you r replication system befo re continuing with t he installation.

Review system requirements

Replication Server requires a computer with the system configuration described in Table 1-1.

Table 1-1: System requirements for UNIX

Item Requirement

Disk storage A minimum of 450MB of available hard disk space:

• 400MB for the Replication Server software, supporting files, and log files.

• An additional 20MB for each Replication Server disk partitio n. The disk partit ion may be on a different disk than your Sybase software.

• One of the following:

• Disk space for your Adaptive Se rver Enterprise database, whic h serves as your Replicati on Server System Da tabase (RS SD) if yo u are not us ing the Emb edded R SSD (ERRS D). See your Adaptive Server Enterprise documentation for system requirements.

• 80MB for your Adaptive Server Anywhere database, which serves as your ERSSD. The database directory , transaction log directory, and backup directory that make up the 80MB should each reside on different disks.

More disk space may be required, depending on your replication system application.

Operating system

Supported protocols

One of the following platforms:

• Sun Solaris SPARC 8, 9, and 10

• Sun Solaris Opteron x64 10

• HP–UX 11.11 and 11.23

•IBM AIX 5.2 TCP/IP

Review operating system patch requirements

Contact your operating syst em provider for any patches recommended for your installation, or check the Replication Server release bulletin for your platform.

14 Replication Server

If your operating system requires patches, install them before you install Replication Server components.

Note Do not use a patch that is earlier than the version suggested for y our

operating system. If a patch has b een superseded by a newer p atch, use the most recent one.

Solaris: T o list all currently installed patches and display the operating system version

level, enter:

showrev -p

Increase operating system threads

HP-UX only – Beginning with version 12.5, Replication Server uses operating system threads instead of Open Client/Server threads™. This requires the operating system kernel to allocate many more threads per process than previously. However, because many HP-UX systems have relatively low default limits on the number o f threads per p rocess and total n umber of threads per kernel, Replication Server can report the following error message:

CHAPTER 1 Before You Begin

F. 2002/05/28 12:23:37. FATAL ERROR #1030 ?(?) - /errhand.c(730) Open Server error: Error: 16361, State: 0, Severity 20 -'CreateEvent() failed in srv__spawn_thread'. T. 2002/05/28 12:23:37. (2): Exiting due to a fatal error

To prevent this error message, increase the value of max_thread_proc to 256, and the value of

nkthread to 2048 in your operating system:

1 Log in as the superuser (SU), and go to the root directory. 2Start

sam.

3In sam, select “Kernel configuration.” 4 Select “Configurable parameters.” 5 Scroll down to “ 6 Increase the value of

max_thread_proc.”

max_thread_proc.

7 Select Actions | ProcessNew Kernel to rebuild the kernel. 8 Restart the system.

Installation Guide fo r UNIX 15

Pre-installation tasks

Configure the operating system for asynchronous I/O

HP-UX only – To optimize asynchronous I/O and to prevent the paging of shared memory, you must grant MLOCK permissions before you install Replication Server.

To grant MLOCK permissions to a group, enter:

/etc/privgrp add mlock <group name>

or:

/etc/setprivgrp <group name> MLOCK

Understand the installation directory structure

Most components of Replication Server are installed in their own subdirectories, with the executable program, installation and configuration tools, and display-related files needed by the component. The naming convention for subdirectories includes a component identifier, such as REP (for Replication Server) or OCS (for Open Client™ and Open Server™), and the software release version, such as 15_0.

Replication Server 15 .0 includes a new vers ion of Replication Server and many of its supporting components. Other Sybase products may contain earlier versions of the same components. Installing Replication Server 15.0 into the same directory containing these exis ting products, will not impact the products .

However, if you are using other Sybase products, installing Replication Server

15.0 in a separate directory may cause some environm ent variables to change. Y ou will have to reset the environment variables in order to make the individual products work.

Note Replication Server 15.0 may be installed in the same directory as

Adaptive Server Enterprise (ASE) and OCS versions 12.5.1 or later.

16 Replication Server

CHAPTER 1 Before You Begin

You can install Replication Serv er 15.0 on top of Replication Server 12.6, in the same $SYBASE directory . Installing 15. 0 on top of R eplication S erver 12.6 will create a duplicate entry in the interfaces file for SAMPLE_RS, which is the sample Replication Server. rs_init will warn you about the duplicate entry and will use the first instance of SAMPLE_RS found in the interfaces file.

Warning! Do not install Replication Server version 15.0 on top of the

following Sybase products:

• Replication Server version 12.5 or earlier

• Adaptive Server version 12.5.0.x or earlier

• Open Client/Server version 12.5.0 or earlier

• OpenSwitch version 12.5 or earlier

• DirectConnect™ version 12.5 or earlier Doing so incapacitates ol der versions of these product s, and can also adversely

affect other Sybase products. If you perform one of these installations, you cannot reverse it with an uninstallation, as uninstalling might remove required components of the older Sybase products updated by Repl icat i on Ser ver version 15.0. For this reason, Sybase recommends that you back up your current directory before installing Replication Server version 15.0.

Note If you are installing Replication Server 15.0 in an existing Sybase

installation directory that contains Adaptive Server version 15.0, you may be asked if you wish to install older locales or charset files on top of newer files. To ensure that you have the latest version of these files select “No to all.”

Installation Guide fo r UNIX 17

Pre-installation tasks

Shared components are installed in subdirectories that are separate from component subdirectories. For example, the Replication Server subdirecto ry is

$SYBASE/REP-15_0. However, Open Client is installed in $SYBASE/OCS-15_0, and the Replicat ion Manager plug-in for Sybase Central, RMPlugin.jar and its associated files are installed in $SYBASE/RMP-15_0.

The exception is Adaptive Server Anywhere (ASA), which is installed in $SYBASE/REP-15_0/ASA9, as it is used only for Replication Server. As a result, the directory structure enables you to install into an existing $SYBASE directory structure, as well as to install and use multiple versions of some components.

Note If your earlier installation includes custom applications or scripts that

refer to $SYBASE, change them to reflect the new installation directory structure.

A diagnostic server REP-15_0/bin/repserver.diag is installed to capture and display information about internal processes. Do not delete this program as you may need to use it at the direction of Sybase Technical Support, to diagno se and resolve Replication Server problems.

Note The directory structure listed in this section is a partial directory

structure. Your actual directory structure may differ, depending on the components you choose to install.

Review the Sybase installation directory contents

The section lists the contents of the Sybase installation directory in alphabetical order.

Installation directory after installation from the CD

The following items are installed on your machine. Within $SYBASE:

Components of Replication Server

18 Replication Server

• charsets – character sets and sort order.

• collate – Unicode.

• config – configuration files.

• interfaces – interfaces file.

• locales – localization files.

CHAPTER 1 Before You Begin

• log.txt – the log of the installation process.

• OCS-15_0 – Open Client and Open Server files, including bin, config, devlib, include, lib, lib3p, sample, sybhelp, and xappdefaults.

• REP-15_0 – Replication Server 15.0 files, including ASA9, bin,

certificates, doc, init, install, samp_repserver, scripts, sysam, ThirdPartyLegal, and upgrade.

• SYBASE.csh, SYBASE.sh, SYBASE.env – files created by InstallShield that you use to reset environment variables.

• SYSAM-2_0 – software license manager files, including bin, licenses, an d log.

• _jvmrep – files used by InstallShield.

• uninstall – files used by InstallShield to uninstall Repl ication Server software.

• ua– the Replication Monitoring Service (RMS) files in the plugin directory, including common, ldap, log, server, services, bin, conf, rtlib, utility, thirdparty and shared.

• vpd.properties – file used by InstallShield to keep track of version of installed and uninstalled software. The vpd.properties

file gets installed in

the $SYBASE directory.

Warning! Do not modify or remove vpd.properties. Modifying or removing this file prevents InstallShield from accurately managing installed component versions when you install or uninstall Sybase software subsequent to this installation.

Components of Replication Manager plug-in to Sybase Central

• RMP-15_0 – files and directories for Replication Manager plug-in to Sybase Central, including bin, help, install, lib, and scripts.

• Shared – co mmon components shared across products, including the Java runtime environment and files and directories for Sybase Central 4.3.

Set the required environment variable for dsedit utility

The Replication Server installation also includes a utility called dsedit, which lets you configure the interfaces file. The environment variables to be set:

• Solaris – LD_LIBRARY_PATH

Installation Guide fo r UNIX 19

dsedit utility requires the following

Pre-installation tasks

• HP-UX – SHLIB_PATH

• IBM AIX – LIBPATH Set the environment variable as follows:

$SYBASE/$SYBASE_OCS/lib

If you do not set this environment variable, dsedit does not start, and an error message reports that a shared library cannot be found. All libraries needed to run

dsedit are in the $SYBASE/$SYBASE_OCS/lib directory. Use the

SYBASE.csh and SYBASE.sh files to set this environment variable. See “Set

environment variables” on page 41 for more information. For more information on

Server Enterprise Utility Guide.

Perform administrative tasks

This section describes administrative tasks that you must complete before you begin the installation process.

1 Back up your current replication system. 2 Create the “sybase” user account and make sure it has

execute permissions. See “Creating the “sybase” user account” on page

20 for more information.

3 Verify that the directory location for the Sybase installation has sufficient

space.

4 Verify that your network software is configured.

Sybase software uses network software, even if Replication Server and Sybase client applications are installed on a machine that is not connected to a network.

5 If you are using an RSSD, verify that Adaptive Server Enterprise is up and

running.

dsedit, see Chapter 5, “Using dsedit” in the Adaptive

read, write, and

Creating the “sybase” user account

To make sure that Sybase product files and directories are created with consistent ownership and privileges, one user (typically the Sybase System Administrator, who has installation, configuration, and upgrade tasks.

20 Replication Server

read, write, and execute privileges) should perform all

T o create a Sybase System Administrator account, choose an existing account, or create a new account and assign a user ID, group ID, and password for it. This account is sometimes called the “sybase” user account. See your operating system documentation for instructions on creating a new user account.

If you have already installed other Syba se software, the “sybase” user probably already exists. Verify that you can log in to the machine using this account.

SySAM pre-installation tasks

Before you install Replication Server, you must plan the type of SySAM license configuration you want to use. Depending on your configuration choice, you may also need to perform additional pre-installation tasks before installing Replication Server.

In this section you: 1 Choose the appropriate SySAM licensing configuration. SySAM allows

you to acquire a license using a local file o r you can acquire a license from a network license server. See “Choosing the appropriate license server configuration” on page 21.

CHAPTER 1 Before You Begin

2 Install a new network license server if necessary. See “Installing a new

license server” on page 22.

Choosing the appropriate license server configuration

When you configure your li cense server , you must choose between c onfiguring for a local license file, or for a network license server.

Unserved configuration

Network license server configuration

Installation Guide fo r UNIX 21

If you are using an unserv ed co nfigu ration , the local licenses directory should contain all necessary licenses. You do not maintain a license server.

When you use an unserved configuration, you must activate the licenses for each machine separately; that is, you do not have centralized control over your licenses. Y ou also do not have asset management or reporting capabilities, and your license must be rehosted if you move Replication Server from one machine to another.

In this setting, you can activate several licenses at once. You have full control over license use, and complete asset management and reporting capabilities.

Pre-installation tasks

Before you install Replication Server, decide which SySAM configuration to use:

• Unserved model usin g unserved li censes

• Network license server using Served licenses If you are going to use a netwo rk license s erv er, decide whether to use an

existing license server or a new license server.

• If you use an existing license server, you must know the server host

name and port number.

• To create a new license server before installing Replication Server,

see “Installing a new license server” on page 22.

Note Sybase recommends that you obtain the license files from the Sybase

Product Download Center (SPDC) at https://sybase.subscribenet.com

begin installati on.

Installing a new license serve r

Perform the following steps to install a new license server on a machine separate from the Replication Server you want to run:

before you

1 Mount the CD by running the following command:

•

HP-UX

Enter the following where device_name is the name of the CD device drive, and /RS150HP/cdrom is the name of the directory where the CD is to be mounted:

/etc/mount -F cdfs -o ro device_name /RS150HP/cdrom

•IBM AIX

Enter the following where device_name is the name of the CD device drive, and /RS150IBM/cdrom is the name of the directory where the CD is to be mounted:

/usr/sbin/mount -v 'cdrfs' -r device_name /RS150IBM/cdrom

The location of the mount command is site-specific and may differ from what is shown in these instructions.

•Solaris

The operating system mounts the CD automatically.

22 Replication Server

CHAPTER 1 Before You Begin

2 Launch the Sybase installer program by entering:

./setup

3 The Welcome Window displays. Click Next. 4 Accept the license agreement. 5 Enter or select the destination directory. 6 Select the custom installation. 7 Select only SySAM Network License Server for installation. 8 Unselect other components, to install the Net License Server only. 9 Click OK for the installer to install SySAM licensing tools. 10 Get the host ID for the machine on which the new license server will run.

To get the host ID: aGo to $SYBASE/$SYBASE_SYSAM/bin where $SYBASE is the Sybase

installation directory and $SYBASE_SYSAM is the directory for SYSAM-2_0.

bEnter:

./lmutil lmhostid

Note If your machine has multiple network adapters, lmutil lmhostid

returns host IDs associated with each adapter. Choos e one of the IDs. Avoid using IDs for removable network adapter s .

c S ave the host ID to use at the Sybase Product Download Center.

11 Go to

the Sybase Product Download Center (SPDC) at

https://sybase.subscribenet.com

12 Get the license you want to install.

a Log in to your account. When you place an order for Sybase software,

the Sold To and Ship To contacts become members of the Sybase Product download Center account, and their e-mail addresses are automatically added as a login. The Sold To Contact is also established as the administrator of the account. Each m ember receives a welcome message from the Sybase Product Download Center, which contains a login name and password. In addition, Technical Support contacts are added as members to the Sybase Product Download Center account.

Installation Guide fo r UNIX 23

Pre-installation tasks

The administrator can add new members to the Sybase Product

Download Center account at any time. b Select the product for which to activate licenses. c Complete the License Activation wizard to generate required

licenses. The generated licenses are displayed when the wizard

completes. d Click Save All to save the licens e file. Make sure you have saved the

license file with the extension .lic.

13 Copy the license file in the licenses directory

$SYBASE/$SYBASE_SYSAM/licenses on the network license server machine.

14 Start the SySAM network license server:

aGo to:

$SYBASE/$SYBASE_SYSAM/bin

bEnter:

sysam start

15 Validate that the license daemon is running by entering:

sysam status

24 Replication Server

CHAPTER 2

Installing Replication Server

This chapter describes how to install the Replication Server software from a CD using InstallShield.

Topic Page

Using InstallShield for installation 25 Installing Replication Server 27 Uninstalling Sybase products 37

Note When you have completed the installation instructions in this

chapter, return to the Replication Server Configuration Guide for UNIX to begin customizing your newly installed Replication Server.

Using InstallShield for installation

When you first install a Sybase product, InstallShield creates a Sybase installation directory, if it does not already exist, which contains the support files for all Sybase products.

When you install Replication Server using InstallShield, its software and support files are stored in the Sybase installation directory. You can install all Sybase software in the same installation directory.

Warning! Do not install Replication Server into an existing Adaptive

Server Enterprise 12.x (64-bit) directory. This may cause some localization (.loc) files to be overwritten, resulting to problems in starting Adaptive Server Enterprise.

InstallShield is Java-based, so the installation process is similar on both UNIX-based and Windows-based computers.

InstallShield enables you to:

Installation Guide fo r UNIX 25

Using InstallShield for installation

• Install all Replication Server components. Y ou can choose the installation option that works best for you:

• Typical (default) – installs the Replication Server components

• Full – installs every Replication Server component including all the

• Custom – allows you to select the components to install.

• Easily view software release version and proper ties for components on the installation CD.

considered to be useful for most customers. In this type of installation, only the U.S. English language module and its supported character sets are installed. The components that will be installed and the total disk space required display prior to installation.

supported language m odu l es f rom the CD. The components t hat w il l be installed and the total disk space required display prior to installation.

Recommended for advanced users. When you select Custom install, the next window displayed is the Component Selection window, which allows you to select the components to install.

Note Certain components are automatically installed if they are

required to run other selected components.

• Uninstall all Replication Server 15.0 components.

In addition, InstallShield:

• Creates the SYBASE.csh or SYBASE.sh script files. You can later use these files to reset environment variables after exiting InstallShield and before configuring Replication Server. See “Set environment variables” on page

41.

• Starts the sample Replication Server when the installation process is complete, if you installed the defaults.

• You must manually start other components, such as Replication Monitoring Services, and the license manager, if needed.

If you did not install the defaults, follow the instructions in the Replication Server Configuration Guide for UNIX to start, then configure Replication Server.

26 Replication Server

Installing Replication Server

Follow the procedures in this section to install Replication Server components.

❖ Installing Replication Server components

1 Choose one of the following installation modes:

• Graphical user interface (GUI) – lets you install the comp onents using the InstallShield interface.

• Console – lets you install components in a command line environment.

• Response file – lets you record or create a response file. You can install Replication Server in two different ways using a response file:

• Silent – lets you save the installation settings in a response file

and install the product without any interaction required on your part. This is convenient if you are performing identical installations on multiple machines.

• Console installation using response fi le – lets you install in

console mode but with all the responses already filled in, so that you can accept all the defaults and install Replication Server according to the responses in the response file. This can be convenient if several sites are installing Replication Server in a nongraphical user interface environment and must conform to a standard installation with minor changes.

CHAPTER 2 Installing Replication Server

Note If you encounter problems during installa tion, check the instal lation

log file to see a record of the installation process. The file is located in $SYBASE/log.txt, where $SYBASE is the Replication Server installation directory.

2 Mount the Replication Server CD:

•Solaris:

Installation Guide fo r UNIX 27

Installing Replication Server

/etc/mount -F cdfs -o ro device_name /RS150HP/cdrom

The operating system mounts the CD automatically. If you get CD-reading errors, check your operating system ker nel to make sure the ISO 9660 option is turned on.

Note If your CD shows up as anythi ng other than sybasecd, it means

you previously install ed a Sybase C D on your syst em. Perform eit her of these two options to install your current CD:

• Restart your system.

• Delete the sybasecd file in /vol/dsk.

•

HP-UX:

a Log out. b Log in as “root.” c Enter the following where device_name is the name of the CD

device drive, and /RS150HP/cdrom is the name of the directory where the CD is to be mounted:

d Log out as “root.” e Log in as “sybase.”

• IBM AIX: Mount the CD using the following command, where device_name is

the name of the CD device drive, and /RS150IBM/cdrom is the name of the directory where the CD is to be mounted:

/usr/sbin/mount -v 'cdrfs' -r device_name /RS150IBM/cdrom

The location of the mount command is site-specific and may differ from what is shown in these instructions.

If you cannot mount the CD drive, consult your operating system documentation or contact your operating system administrator.

3 Verify that you are logged in as the “sybase” user with “root” privileges.

❖ Installing in GUI mode

1 At the UNIX prompt, enter the following, where cdrom is the directory

you specified when mounting the CD drive, and ./setup unloads the components in GUI mode:

• IBM AIX:

28 Replication Server

CHAPTER 2 Installing Replication Server

cd /device_name ./setup -is:javahome JVM

•HP-UX:

cd /cdrom ./setup

•Solaris:

cd /cdrom/rs150solaris ./setup

2 You might see the following error message:

Error writing file = There may not be enough temporary disk space. Try using -is:tempdir to use a temporary directory on a partition with more disk space.

If so, set the temporary directory to another directory that has more disk space by entering the following at the command line, where directory_name is the name of the temporary directory to which InstallShield will write its temporary files:

setup -is:tempdir directory_name

This directory should have at least 100MB of disk space.

3 Select Next. 4 Choose your geographic location in the license and copyright agreement

window.

5 Read the Sybase license agreement and select “I agree.” Click Next. You

must agree to the license and copyright before you can continue.

6 In the install directory window, click Next to accept the default directory

for the installation ($SYBASE or /opt/sybase), or enter a different directory name.

7 If the installation directory you chose does not exist, InstallShield

prompts:

The directory does not exist. Do you want to create it?

8 Click Yes. If the installation directory you selected exists, and contains a

prior installation, InstallShield prompts you with the following message:

You have chosen to install into an existing directory. Any older versions of the products you choose to install that are detected in this directory

Installation Guide fo r UNIX 29

Installing Replication Server

9 Select the type of installation:

will be replaced. Do you want to continue with installation into this directory?

Click Yes if you w ish to in stall on top of the previous installation. If the products were previously installed with:

• Studio Installer (for example, if yo u installed a ver sion of Replication Server earlier than 12.6 or a version of Adaptive Server earlier than

12.5.1), InstallShield overwrites common components.

• InstallShield, the correct course of action is determined by InstallShield without prompting you.

• If you choose Full or Typical, InstallShield displays the following default components:

• Sybase Servers – Replication Server

• Connectivity

• Language Modules for Replication Server

• Language Modules – Connectivity

•Shared

• Replication Monitoring Services

• Replication Server Administration Tools – Sybase Central and

Replication Manager Plugin

• Sybase Software Asset Management

• If you choose Custom, select the components to install. Certain components are automatically installed if they are required to run your selected components.

10 Click Next. InstallShield displays a progress indicator as it installs the

components. If you do not have enough disk space for the installation, InstallShield

displays an error message. In this case, exit InstallShield, remove any programs or files that you do not need, and clean out temporary directories. Then, restart InstallShield.

11 On successful installation, InstallShield displays the following message:

Click Next.

The InstallShield Wizard has successfully installed Replication Server Software, Version 15.0. Choose

30 Replication Server

CHAPTER 2 Installing Replication Server

next to continue the wizard.

12 The SySAM License Server window opens and displays this prompt:

Will licenses be obtained from the License Server?

• Select Yes if you have a preexisting SySAM network license server

installed or installed a new license server using “Installing a new license server” on page 22.

Enter the host name and the port number of the license server.

• Select No if you do not have a SySAM license server installed and are

going to use a local license file. A message displays telling you to download the license file.

If you select Yes and the license server i s not found, or you select No and the local license file is not installed on your local machine, this message displays:

Installer can’t check out a license. Do you want to continue with a license?

Click Yes to complet e the installation. If you select No, this message displays:

Please remember to download and install the license file after this installation.

Click OK to return to the beginning of step 12.

Note See “Choosing the appropriate license server configuration” on

page 21 for information on which choice is appropriate for your installation.

13 The SySAM Notification window asks you to configure your server for

e-mail notification. When configuration is enabled, you will receive information about license management events requir ing attent i o n.

•SMTP server host name

• SMTP server port number

• E-mail Return Address

• Recipient e-mail addresses

• Message severity that triggers e-mail messages

14 On the sample Replication Server option window, select:

Installation Guide fo r UNIX 31

Installing Replication Server

15 Click Next. If you chose to configure and start a sample Replication

This page contains detailed information regarding the sample Replication Server. Please record this information.

The sample Replication Server will be called SAMPLE_RS and will run on port 11752. It will be configured with a user of sa and no password.

The sample Replication Server will use an embedded RSSD called SAMPLE_RS_ERSSD that runs on port 11751. It will be configured with a user of SAMPLE_RS_RSSD_prim and a password of SAMPLE_RS_RSSD_prim_ps.

• Y es – to configure and start a sample Replication Server . InstallShield displays the configuration information for the sample Replication Server. Write this information down.

• No – to complete the installation and configure a fully-featured Replication Server manually.

If you select No, you can configure and start a sample Replication Server after installation. See “Start the sample Replication Server” on page 40 for more information.

Server, InstallShield displays the configuration information related to the sample Replication Server:

The installer has updated the appropriate interfaces file or sql.ini file.

All files and logs associated with the sample Replication Server will be located in the directory $SYBASE/REP-15_0/samp_repserver.

The sample Replication Server will be configured using the file $SYBASE/REP-15_0/samp_repserver/SAMPLE_RS.res.

16 Click Next. The Configure New Replication Server window displays the

progress of the server configuration.

17 Click Next. The Installation Completed window appears, verifying that

the Replication Server software is now installed. If you chose to start a sample Replication Server, it is started

automatically. If you did not choose to start a sample Replication Server, you must configure and then start your Replication Server manually.

See the Replication Server Configurati on Guide for UNIX for informatio n about configuring your new Replication Server.

18 Click Finish. The InstallShield wizard closes.

32 Replication Server

CHAPTER 2 Installing Replication Server

❖ Installing in console mode

The steps for installing components in an interactive text mode are the same as those described in “Installing in GUI mode” on page 28, except that you execute InstallShield from the command line using the

setup -console

command, and you enter text to select installation options. 1 At the command line, enter:

• HP-UX and Solaris:

./setup -console

•IBM AIX:

./setup -console -is:javahome JVM

InstallShield starts and displays the welcome window as follows:

--------------------------------------------------

Welcome to the InstallShield Wizard for Sybase Replication Server Software, Version 15.0.

The InstallShield Wizard will install Replication Server Software, Version 15.0 on your computer.

To continue, choose Next.

Press 1 for Next, 3 to Cancel or 4 to Redisplay [1]

-------------------------------------------------

2 Follow the remaining prompts to install R eplication Server software.

Installing in command line mode

This section discusses the various installation methods available to you from the command line.

Note If the environment variable $SYBASE is set, the installer uses it as the

default directory for installation. However, you can explicitly specify a different directory during the installation process to override $SYBASE.

Installation Guide fo r UNIX 33

Installing Replication Server

Installing with a response file

You can install Replication Server using a response file in combination with a console or silent installation. You must first create the response file.

Note Y ou mus t provide the absolute p ath name for the res ponse file you create.

To create a response file, do one of the following at the command line:

• Enter the following command, where REP.response is name you choose for the response file:

• HP-UX and Solaris:

./setup -options-template REP.response

• IBM AIX:

./setup -options-template REP.response -is:javahome JVM

InstallShield creates an options template called REP.response. Edit the template with the values you want to use during installation.

• Enter the following command at the command line, where REP.response is a name you choose for the response file:

Note You must provide the absolute path name for the response file you

create.

• HP-UX and Solaris:

./setup - options-record REP.response

• IBM AIX:

./setup - options-record REP.response -is:javahome JVM

InstallShield runs the installation in GUI mode and captures all user choices to a file called REP.response. You can also specify the

-console

option to get the same results.

You can use REP.response for future installations of Replication Server, either as is or edited for the new installation.

❖ Editing the response file

1 Specify the installation location, where path is the full path and file name:

-P installLocation=path

34 Replication Server

Do not use special characters for the p ath name, such as blanks or per iods.

2 Specify the setup type, where installation_type specifies the type of

installation (Full, Typical, or Custom):

-W setupTypes.selectedSetupTypeId=installation_type

If you specify either the Full or Typical installation, you do not need to uncomment the individual features; these features have been predefined as installed.

If you choose the Custom installation, you must uncomment the desired features and set their values to “true.”

3 The last line in the response file allows you to specify if you want to start

a sample Replication Server. You must uncomment this line and specify either “yes” or “no” (case sensitive; use all lowercase):

-W ConfigureReplicationServer.Yes-or-No="no"

Installing in console mode with a response file

A console mode installation using a response file lets you accept all def aults as you move through an interactive text installation, because the values come from a response file that you have set up.

CHAPTER 2 Installing Replication Server

Follow the same steps as you would for a regular console installation, but at the command line, enter:

• HP-UX and Solaris:

./setup -console -options REP.response -W\ SybaseLicense.agreeToLicense=true

•IBM AIX:

./setup -console -options REP.response -is:javahome JVM\

-W SybaseLicense.agreeToLicense=true

Installing in silent mode

A silent mode installation, sometimes referred to as an unattended installation, allows you to install the product using a response file to set default values, without any interaction required on your part.

Follow the same steps as y ou would for a console installation, but at the command line, enter:

• HP-UX and Solaris:

Installation Guide fo r UNIX 35

Installing Replication Server

./setup -console -options REP.response -W\ SybaseLicense.agreeToLicense=true

• IBM AIX:

./setup -console -options REP.response -is:javahome JVM\

-W SybaseLicense.agreeToLicense=true

Where:

• REP.response – is th e name of the file containing the installation options you chose.

•

-W SybaseLicense.agreeToLicense=true – specifies that you agree with the

Sybase License Agreement text.

Checking for a valid inst allation

1 View the $SYBASE/log.txt file and check for errors. 2 Verify that the vpd.properties file has been written in the $SYBASE

directory.

3 Check that the date of the vpd.properties file reflects the date of this

current installation.

Troubleshooting installation

For troubleshooting during GUI, console, or silent mode installation using an option file, enter the following at the command line where ERROR.log is the name of the log that will capture events specific to the console or silent mode installation:

• HP-UX and Solaris:

./setup -silent -options Rep.response -W\ SybaseLicense.agreeToLicense=true -is:log Error.log -is:javaconsole

• IBM AIX:

./setup -silent -options Rep.response -is:javahome JVM\

-W SybaseLicense.agreeToLicense=true -is:log ERROR.log -is:javaconsole

36 Replication Server

The

-is:log parameter creates an ERROR.log log file, and the -is:javaconsole

parameter causes errors to be written to the screen.

Note If you encounter errors during installation, check the installation log file

to see a record of the installation process. The log file is located in $SYBASE/Iog.txt.

If this is the first time you have installed a Sybase product on this machine, InstallShield creates a Sybase installation directory . This directory contain s the support files for all Sybase products.

Uninstalling Sybase products

InstallShield includes an uninstall feature that removes the Sybase components you have installed.

You can invoke the uninstall procedure using either GUI or console methods. Sybase recommends that you use the GUI method.

CHAPTER 2 Installing Replication Server

Before uninstalling Sybase software, log on to your m achine using an account with administrator pri vileges. Then s hut down Replicat ion Server and all other processes for the components you are uninstalling.

Note InstallShield removes only those files that were loaded from the

installation media. Some Sybase files, such as log and configuration files, are left intact for administrative purposes. The installed or _jvmrep directories are also not removed by InstallShield.

❖ Uninstalling in GUI mode

1 To uninstall the products in GUI mode, first source the SYBASE.csh or

SYBASE.sh as appropriate, then execute the following at the command

line: IBM AIX, HP-UX, and Solaris:

$SYBASE/uninstall/REP150/uninstall

The Uninstaller window opens.

2 Click Next.

Installation Guide fo r UNIX 37

Uninstalling Sybase products

3 Select the product you want to remove from the list, then click Next. 4 Verify the summary information, then click Next.

5 Click Finish.

6 If you are uninstalling the Replicat ion Manager plug-in to Sybase Central ,

❖ Uninstalling in console mode

1 T o un insta ll the p roducts in cons ole mode, fi rst s ource th e SYBASE.csh or

The uninstaller removes the files associated with the software.

Note You may be prompted to decide whether to remove shared files.

Sybase recommends that you do not remove shared files.

Java Edition, and you have previously installed both the Replication Manager plug-in and the Adaptive Server plug-in to Sybase Central, Java Edition, unregister the Replication Manager plug- in in Sybase Cen t ral.

See the Replication Manager plug-in online help for more information.

SYBASE.sh as appropriate, then execute the following at the command line:

IBM AIX, HP-UX, and Solaris:

$SYBASE/uninstall/REP150/uninstall -console

The uninstaller program starts.

2 Choose the Replication Server software product you want to uninstall.

The Replication Server software product you chose and its as sociated files are removed.

Note You may be prompted to decide whether to remove shared files.

Sybase recommends that you do not remove shared files.

3 If you are uninstalling the Replicat ion Manager plug-in to Sybase Central ,

See the Replication Manager plug-in online help for more information.

38 Replication Server

CHAPTER 3

Post-Installation Tasks

This chapter describes the post-installation tasks that you need to perform after installing the Replication Server software.

For more information, see the Replication Server Configuration Guide for UNIX.

Topic Page

Review the log files 39 Start Adaptive Server for the RSSD 40 Start the sample Replication Server 40 Set environment variables 41

Review the log files

Information about the configuration of Repl ication Server is stored in the following log files:

• InstallShield error log file:

$SYBASE/log.txt

• Adaptive Server Anywhere error logs:

$SYBASE_REP/samp_repserver/errorlog/

•

rs_init log file:

$SYBASE/$SYBASE_REP/init/logs/logmmdd.xxx

For example: $SYBASE/$SYBASE_REP/init/logs/log1106.001

• Replication Server log file:

$SYBASE/$SYBASE_REP/install/rs_name.log For example: $SYBASE/$SYBASE_REP/install/REP_redtail.log

Installation Guide fo r UNIX 39

Start Adaptive Server for the RSSD

To use the RSSD stored on Adaptive Server Enterprise, install the Adaptive Server Enterprise database, if you have not done so already. For installation instructions, see the Adaptive Server Enterprise Installation Guide for your platform.

After successful installation, start Adaptive Server Enterprise. For more information, see Chapter 2, “Starting and Stopping Servers” in the Adaptive Server Enterprise Configuration Guide for your platform.

Note If you are upgrading to a later version of Adaptive Server Enterprise and

you have replicated databases, read Appendix B, “Upgrading Servers with Replicated Databases,” in the Adaptive Server Enterprise Installation Guide for your platform.

Start the sample Replication Server

During installation, InstallShield asks if you want to configure and start a sample Replication Server. InstallShield creates a resource file, $SYBASE/REP-15_0/samp_repserver/SAMPLE_RS.res, for the sample Replication Server and u pdates the interfaces file regardless of your choice. If you select No, you can still configure and start the sample Replication Server after installation using this resource file.

To create and start the sample Replication Server after installation, at the command prompt, enter:

$SYBASE/REP-15_0/install/rs_init -r\

$SYBASE/REP-15_0/samp_repserver/SAMPLE_RS.res

The rs_init utility displays commands as it executes them, and writes this output to its log.

If you encounter errors during configuration and start-up of the sample Replication Server, read this log file, $SYBASE/REP-15_0/init/logs/logmmdd.xxx, where:

• mm – is the month.

• dd – is the day.

40 Replication Server

CHAPTER 3 Post-Installation Tasks

• xxx – is the number of that instance of the log on that day. The sample Replication Server is configured using the SAMPLE_RS.res

resource file. All files and logs associated with the sample Replication Server are in the directory $SYBASE/REP-15_0/samp_repserver.

Table 3-1 contains the sample Replication Server configuration information. Keep this information in a safe place for later reference.

Table 3-1: Sample Replication Server configuration information

Sample Replication Server item Definition

Name SAMPLE_RS Port 11752 User name sa Password None ERSSD server name SAMPLE_RS_ERSSD ERSSD server port 11751 ERSSD user name SAMPLE_RS_RSSD_prim ERSSD password SAMPLE_RS_RSSD_prim_ps

For more information about rs_init, see Chapter 2, “Configuring Replication Server and Adding Databases with rs_init,” in the Replication Server Configuration Guide for UNIX.

Set environment variables

InstallShield automatically sets system environment variables that are needed by InstallShield. InstallShield installs three files that contain these environment variables:

• $SYBASE/SYBASE.sh

• $SYBASE/SYBASE.csh

• $SYBASE/SYBASE.env After you exit InstallShield , you ma y need to reset environment variables, for

example, if someone other than the Sybase administrator must use the software.

To set these environment variables, you can either:

Installation Guide fo r UNIX 41

Set environment variables

•Use the source command to source SYBASE.sh or SYBASE.csh and update the component’ s RUN environ ment immediately for your cu rrent session, before invoking any component, or

• Modify the component’s RUN environment permanently using the environment variable values from the shell files.

Table 3-2 describes the environment variables.

Table 3-2: Environment variables for UNIX

Environment variable Description

Solaris:

$LD_LIBRARY_PATH IBM AIX: $LIBPATH HP-UX: $SHLIB_PATH $LM_LICENSE_FILE The subdirectory path to the license.dat file, which SySAM needs to run the license

$PATH The directory path to Replication Server files. $SYBASE The home directo r y wh e r e you ins tall all Sybase pro du cts. $SYBASE_JRE The subdirectory path to the Java Runtime Environment (JRE). $SYBASE_OCS The subdirectory path to Open Client files. $SYBASE_REP The subdirectory path to Replication Server. $SYBASE_RMP The subdirectory path to the Replication Manager plug-in to Sybase Central, Java

$SYBASE_SYSAM The subdirectory path to SySAM license manager. $SYBASE_UA The subdirectory path to the Unified Age nt Framework and Replic ation Monitoring

$SCROOT The subdirectory path to Sybase Central. $SYBROOT The parent directory of $SCROOT. If Sybase Central is installed in the same

The subdirectory path to the Open Client and Open Server runtime shared library.

manager.

Edition.

Services.

directory as Replication Server, $SYBASE and $SYBROOT will be the same.

42 Replication Server

APPENDIX A

SySAM Administration

Replication Server uses Sybase Soft ware Asset Management (SySAM) to perform lice nse administration and asse t management t asks.

Topic Page

Managi ng licenses 43 Starting and stopping network license servers 46 Borrowing a license to work offline 48 Enabling the network license server REPORTLOG file 50 Using SAMreport 50 Using SySAM utilities 55

Managing licenses

The Sybase Product Download Center is an where you ob tain license keys to enable Sybase software.

When you purchase software from Sybase, go to

https://sybase.subscribenet.com

receive an e-mail message that includes the above URL, your login, and your password for the Sybase Product Download Center.

When you purchase software from a Sybase reseller, go to

site at https://sybase.subscribenet.com/webkey

received in your software package to enter the activation string. Before you go the Sybase Product Download Center, determine:

• Your license configuration – whether to use the network license server or an unserved SySAM configuration.

• The host ID for the servers you want to run.

• If you are going to use an unserved configuration, you need the

host ID for the machine where Replication Server will run.

Installation Guide fo r UNIX 43

. When your order is processed, you

the download site at

the download

. Use the certificate that you

Managing licenses

• If you are going to use a network license server, you need the host ID of the machine where the license server will run.

To obtain a host ID, go to $SYBASE/SYSAM-2_0/bin and execute:

./lmutil lmhostid

Note If you want to obtain the hostid before installing Replication Server,

the

lmutil executable binary is available as a standalone download from the

Sybase Product Download Center.

• The host name for the network license server if you are using a license server.

• The TCP/IP port number to be used by the network lic ense server if you are using a license server. If you do not specify the port number, the network license server uses the first available port number in the 27000 through 27009 range.

At the Sybase Product Download Center, you can:

• Generate a license file for an order.

• Generate a license file for partial fulfilment of an order. For example, if you want ten copies of the s oftw are, y ou can acquire five now and obtain the remaining copies later.

• Download ordered software.

• Complete the remaining fulfilment for an order.

• Rehost a license. To change the machine where a license is located, you must generate a new license file at the Sybase Product Download Center.

• View a history of fulfilled licenses and re-download the licenses.

44 Replication Server

• Obtain updated licenses after renewing support.

Note When you renew your software support with Sybase, the SySAM

licenses are updated with the new support date. Download updated licenses from the Sybase Product Download Center after renewing support. The designated support contact receives an e-mail message when a support renewal is processed. The support date is checked when you install Replication Server to verify your support is current when the update is posted.

If you cannot access the Sybase Product Download Center or have problems generating license keys, contact S ybase Custo mer Services and Supp ort. They can generate the license keys on your behalf and provide the keys to you.

The Sybase Product Download Center keeps a record of the license keys you have activated, and allows you access the records of the software for which you are licensed.

Using the options file to manage licenses

APPENDIX A SySAM Administration

Use the options file ($SYBASE/SYSAM-2_0/licenses/SYBASE.opt) to provide control to the Replication Server license from the network server . For example, you may want to limit the machines on which Replication Server can be run, or restrict usage to particular users.

For example, the following options file restricts the use of Replication Server to the users Tom, Sam, and Harry:

# the sse_group are GROUP sse_group tom sam harry INCLUDE REP_SERVER GROUP sse_group

Note When you specify INCLUDE, you must include all machines or all users

licensed for the product in the host group. A machine or a user that is not included in the host group cannot use the product.

Installation Guide fo r UNIX 45

Starting and stopping network license servers

❖ Manually starting SySAM servers

1Go to $SYBASE/SYSAM-2_0/bin. 2 Execute:

sysam start

❖ Manually stopping a SySAM server

1 In a Command Prompt window, go to $SYBASE/SYSAM-2_0/bin. 2Enter:

sysam stop

❖ Starting and stopping SySAM as an automatic service

• T o configure SySAM to start automatically when a ho st server is restarted: 1 Using an account with root privileges, log on to the machine where

you installed the Sybase Software Asset Management (SySAM) software.

2 Create a script that the system will use to start and shutdown. The

main purpose of such a scr ipt is to avoid runn ing the License Manager with root privileges, as these are not required. The following example script assumes that the SySAM License Manager will be run as the user sybase, and was installed into /opt/sybase. Change these parameters to match your specific installation:

#!/bin/sh # SYBUSER=sybase SYBASE=/opt/sybase SYSAM=$SYBASE/SYSAM-2_0 case "$1" in 'start') su $SYBUSER -c "echo `date` starting lmgrd >> $SYSAM/log/boot.log" nohup su $SYBUSER -c "umask 022; $SYSAM/bin/sysam start >> $SYBASE/log/boot.log" ;; 'stop') su $SYBUSER -c "echo `date` stopping lmgrd

>> $SYSAM/log/boot.log" su $SYBUSER -c "$SYSAM/bin/sysam stop -q

46 Replication Server

APPENDIX A SySAM Administration

>> $SYSAM/log/boot.log" ;; *) echo "Usage: $0 { start | stop }" exit 1 ;; esac exit 0

3 Save the script to the file name appropriate for your operating s ystem.

Solaris:

/etc/init.d/sysam.boot

IBM AIX:

/etc/rc.d/init.d/sysam.boot

HP-UX:

/sbin/init.d/sysam.boot

4 Change the permissions, ownership, and group for the script. For

example, assuming the script was stored as /etc/init.d/sysam.boot enter:

chmod 744 /etc/init.d/sysam.boot chown root /etc/init.d/sysam.boot chgrp sys /etc/init.d/sysam.boot

5 Create an appropriately named link to start the License Manager

during start-up (typically, S + run number + script name): Solaris:

ln -s /etc/init.d/sysam.boot /etc/rc3.d/S70sysam

IBM AIX:

ln -s /etc/rc.d/init.d/sysam.boot /etc/rc.d/rc3.d/S70sysam

HP-UX:

ln -s /sbin/init.d/sysam.boot /sbin/rc3.d/S070sysam

6 Create an appropriately named link to stop the License Manager

during shutdown (typically, K + run number + script name): Solaris:

ln -s /etc/init.d/sysam.boot /etc/rc2.d/K02sysam

Installation Guide fo r UNIX 47

Borrowing a license to work offline

IBM AIX:

ln -s /etc/rc.d/init.d/sysam.boot /etc/rc.d/rc2.d/K02sysam

HP-UX:

ln -s /sbin/init.d/sysam.boot /sbin/rc2.d/K002sysam

Note The run number (2 above) should be cho sen such that it is lower than

that of subsystems required by SySAM such as networking services and higher than the run number of applications that require SySAM such as Adaptive Server Enterprise.

Borrowing a license to work offline

Use the lmborrow option to check out licenses from the network license server, if you will be disconnected from the network for extended period of time.

Replication Server periodically executes a “heartbeat” on the network license server to update license status. If the machine running Replication Server is disconnected from the network, these heartbeats fail and eventually the software becomes unavailable. Borrowing a license before disconnecting from the network suspends the heartbeat checks and provides full use of the sof tware while disconnected.

Specify the end time when you perform the borro w operation. At the end of the lease, you can obtain a new lease by connecting back to the network. You can also return a license earlier than the lease end time.

Note You cannot borrow a license when you are use local license files.

❖ Borrowing a license using lmborrow

1 Before disconnecting from the network, shut down Replication Server. 2Go to $SYBASE/SYSAM-2_0/bin.

48 Replication Server

APPENDIX A SySAM Administration

3Enter:

./lmutil lmborrow SYBASE enddate [ time ]

where endate [time] is the desired b orrow end date .

Note Run lmborrow from the same machine on which licenses are being

borrowed, and from the same user that starts Replication Server.

For example, the following command sets the end date at 1 p.m. on August 20th, 2005:

lmutil lmborrow SYBASE 20-aug-2005 13:00

The maximum borrow time is 30 days. Your license administrator can reduce the maximum borrow time followi ng the instructions in “Returning

a borrowed license early” on page 49. 4 Start Replication Server. The checked out license is borrowed. 5 Disconnect from the network.

❖ Displaying status on a borrowed license

1Go to $SYBASE/SYSAM-2_0/bin. 2Enter:

./lmutil lmborrow -status

❖ Returning a borrowed license early

1 Connect to the network. 2 Shut down Replication Server. 3Go to $SYBASE/SYSAM-2_0/bin. 4 Return each borrowed license by entering:

./lmutil lmborrow -return [-c licfile] [-d display_name] feature

For example, the following command returns the REP_SERVER license:

./lmutil lmborrow -return -c $SYBASE/SYSAM-2_0/licenses -d myhost REP_SERVER

❖ Renewing a borrowed license

1 Connect to the network. 2 Shut down Replication Server.

Installation Guide fo r UNIX 49

Enabling the network license server REPORTLOG file

3 Return the currently borrowed license if the lease has not expired. 4 Execute the steps to borrow licenses with a new lease end date. See Chapter 8, “Mobile Licensing,” and Chapter 7, “License Administration

Tools,” in the FLEXnet Licensing End User Guide for more details.

Enabling the network license server REPORTLOG file

The network license server can produce a REPORTLOG file that records license use.

Note Asset management reporting capabilities require a report log.

The report log is enabled by adding this command in the options file:

REPORTLOG [+]report_log_path

where report_log_path is the report log file for this vendor daemon. Sybase recommends that you prepend the report_log_path with a plus (+) character to append logging entries, otherwise, the file is overwritten each time the daemon starts.

Note The Replication Server installation automatically creates an options file

with REPORTLOG enabled. The options file, SYBASE.opt, is located in $SYBASE/SYSAM-2_0/licenses.

Using SAMreport

SAMreport is a report generator that records the license use of FLEXnetlicensed applications. SAMreport records license use based on license activity recorded in the FLEXnet report logs, and on selected criteria that includes product and feature name, user, date and time, and display or host.

50 Replication Server

APPENDIX A SySAM Administration

The SAMreport install program is on the Replication Server installation media in the /samreport directory.

Note The recommended $SAMreport_home location is

$SYBASE/SYSAM-2_0/samreport.

The report types provided by SAMreport are:

• Usage Over Time – a line graph that shows the maximum number of

licenses in use over a period of time.

• High Water Mark – a line graph that shows the maximum number of

licenses used during the specified time period.

• Summary Barchart – a format to compare license use across users and

features, based on calculations made in the Usage Summary report.

• Usage Efficiency – how long each successive license for a given product

was in use.

• Usage Summary – text output that summarizes usage statistics for each

product.

• Server Coverage – the time durin g which the license server was servicing

licenses.

• Raw – individual use events, not a summary of license use. In general, a

Raw report provides one line of data for every license checkout, listed in

chronological order of check-in.

SAMreport system requirements

SAMreport v3.6 is supported on the following platforms:

• Solaris Sparc 2.7 and later

• HP-UX 11and later

•IBM AIX 5.1

Installation Guide fo r UNIX 51

Using SAMreport

Installing the Java Runtime Environment

Before you install SAMreport, you may need to install the Java Runtime Environment (JRE), specific to your platform. Refer to your platform documentation or web si te for more details.

To install the JRE, follow the instructions that come with the program.

Installing SAMreport

To install SAMreport as a new installation: 1 Run the SAMreport installer, located in the samreport directory on the

Replication Server version 15.0 installation media.

2 Use console mode if your display supports only characters, not graphics.

• To run in console mode, enter the following command:

HP-UX:

samreport-3_6-hp700_u11.bin -console

Solaris:

samreport-3_6-sun4_u5.bin -console

IBM AIX:

samreport-3_6-ppc_u4.bin -console

• To run in GUI mode, enter the following command:

HP-UX:

samreport-3_6-hp700_u11.bin

Solaris:

samreport-3_6-sun4_u5.bin

IBM AIX:

samreport-3_6-ppc_u4.bin

3 If the installer does not find a JRE installed on your system, specify the

location where JRE 1.4 is installed using the following command:

-is:javahome <JAVA HOME DIR>

For example:

52 Replication Server

APPENDIX A SySAM Administration

HP-UX:

samreport-3_6-hp700_u11.bin -is:javahome JRE directory

Solaris:

samreport-3_6-sun4_u5.bin -is:javahome JRE directory

IBM AIX:

samreport-3_6-ppc_u4.bin -is:javahome JRE directory

In the above examples, the JRE directory is the JRE directory that was

installed in “Installing the Java Runtime Environment” on page 52.

If the install program cannot use the JRE, install the JRE that is supplied

with the SAMreport installation program. 4 The Welcome screen displays. Click Next. 5 Choose an installation location. Sybase recommends that you install

SAMreport in $SYBASE/SYSA M-2_0/samreport. SAMreport i s installed

in a v3.6 directory under the specified directory. A symbolic link to a

directory named current is created in the installation directory in the v3.6

directory. Click Next to continue with the installation. 6 Choose the license file location. Browse to the directory where you

launched the SAMreport installation program. Select the license file

named SAMreport_SYBASE.lic and click Open.

The installation does not continue until it locates the specified license file.

The contents of the license file are not checked until you try to run

SAMreport.

The Installer copies the specified file into the following directory:

SAMreport_home/machind/license/license.dat. 7 If the Installer does not find the JRE you installed, you are prompted to

enter the location of that JRE directory. For example: /usr/local/jre.

Click Next. 8 The installation directory and space requirements are displayed. Click

Next to begin the extraction of files and installation of SAMreport. 9 Click Finish to complete the installation.

Installation Guide fo r UNIX 53

Using SAMreport

Post-installation tasks for SAMreport

Set the following enviro nment variabl e before l aunching SAMrep ort. Perf orm the following task, each time you start SAMreport.

Note SAMreport may not launch without this variable defined.

From a C or a Bourne Shell enter the following command, where platform name is “hp700_u11” for HP-UX, “sun4_u5” for Solaris and “ppc_u4” for

IBM AIX. C Shell:

setenv GPLATFORM platform name

Bourne Shell:

export GPLATFORM=platform name

Starting and Stopping SAMreport

This section provides information on how you can start and stop SAMreport.

To start SAMreport

To stop SAMreport:

Go to the $SAMreport_home directory, and enter:

report

T o stop SAMreport, select File | Exit or click the Exit button in the SAMreport interface.

54 Replication Server

Managing and collecting logs

SAMreport must access report logs on the SySAM license server on which you want the report. If you are using an unserved license, the report log files must be on the local machine. If you are using a network license server, the report log files must be accessi ble via a network-mounted s erver. S AMreport does not manage this task; you must manually copy the reports to the appropriate local or network machine and map a drive to the network server if necessary.

Note For information on how to manage report logs, including scripts to

automate collection of such logs, see Appendix A of the SAMreport User’s Guide. To access this guide, go to the Sybase Product Manuals Web site at

Product Manuals at http://www.sybase.com/support/manuals/.

Portions of the FLEXnet Licensing End User Guide and the SAMreport User’s Guide are included with permission of Macrovision Corporation.

Using SySAM utilities

APPENDIX A SySAM Administration

SySAM provides these utilities, which allow the license administrator to manage network licensing activities:

•

lmborrow – supports license borrowing.

•

lmdiag – diagnoses license checkout problems.

•

lmdown – shuts down selected license daemons.

•

lmhostid – reports the system hostid.

•

lminstall – converts license files to different formats.

•

lmnewlog – moves existing report log information to a new file name or

starts a new report log file with the existing file name.

•

lmpath – allows direct control over license file path settings.

•

lmremove – releases a failed license to the pool of free licenses.

•

lmreread – directs the license daemon to reread the license file and to start

any new vendor daemons.

•

lmstat – displays the license server system status.

•

lmswitch – controls the size and location of the debug log.

Installation Guide fo r UNIX 55

Using SySAM utilities

• lmswitchr – switches the report log to a new file name.

•

lmver – reports the FLEXnet licensing version of a library or binary file.

For more information, see Chapter 7 in the FLEXnet Licensing End-User Guide.

The sysam script located in $SYBASE/SYSAM-2_0/bin provides a wrapper for the most frequently used FLEXlm utilities. To display the help text, which provides complete instructions, enter the following command in a Command Prompt window:

sysam help

To display detailed help on a specific action, enter:

sysam help <action>

56 Replication Server

Index

accounts, creating sybase user 20 Adaptive Server

for the Replication Server System Database 40 upgrading 40

administration tasks 20

SySAM licenses 46 alternate SySAM license locations 8 automatically starting and stop pin g a netwo rk lic ense

server 46

borrowing SySAM licenses 48

charsets subdirectory 18 checking for a valid installation 36 check-out options, SySAM 3 choosing appropriate SySA M license server 21 collate subdirectory 18 command line installation mode 33 commands

source 42

complete installation 26 components of Replication Server 1 config subdirectory 18 configuratio n options, SySAM 3 console mod e

installation 33

installation using a response file 27, 35

troubleshooting 36

uninstallation 38 conventions

document style viii

examples ix

syntax statements ix

creating

response files 34 sybase user accounts 20, 21

custom installation 26, 30

default directory 29 details

Replication Server Configuration Guide for UNIX

Replication Server Installation Guide for UNIX 2 diagnosing software problems 18 directories

Sybase installation 25 directory

default 29

structure 16 disk space, not enough for installation 30 disk storage requirements 14

dsedit utility 19

editing the response file 34 Embedded Replication Server System Da tabase

(ERSSD) 40

environment variables

$LM_LICENSE_FILE 42

$PATH 42

required for

setting 26, 41

$SYBASE 42

$SYBASE_JRE 42

$SYBASE_OCS 42

$SYBASE_REP 42

$SYBASE_RMP 42

dsedit 19

Installation Guide for UNIX 57

Index

$SCROOT 42 $SYBROOT 42 $SYBASE_SYSAM 42 $SYBASE_UA 42

table of 42

examples

style conventions ix

existing Adaptive Server Enterprise 12.x (64-bit) directory

warning about installing into 25

existing installation directorie s 29

files

installation log 37

log.txt 19, 37 SYBASE.csh 19, 26, 41 SYBASE.env 19, 41 SYBASE.sh 1 9, 26, 41

SySAM licenses 3 vpd.properties 19

full installation 26

geographic location 29 grace periods

acquiring SySAM licenses during 12

SySAM licensing 11 graphical user interface (GUI) installation 27 GUI mode

installation 28

uninstalling 37

HP-UX operating system threads 15

console mode 33 Java Runtime Environment 52 methods 27 not enough disk space for 30 SAMreport 52 troubleshooting during silent or console mode 36 typical software components 30

installation directories

contents 18 existing 29 new 29

Sybase 25 installation log file 37 installation methods

console with response file 27

GUI 27

response file 27

silent 27 installing

a network license server 22

Adaptive Server for the Replication Server System

Database 40 console mode with a response fil e 35 in command line mo de 33 Replication Server 27 silent mode 35 using InstallShield 25

-W flag 36

using with a response file 34

InstallShield

complete installation 26 custom installation 26, 30 definition of 25 GUI mode 28 log.txt 27 previous installation with 30 standard installation 26, 30 starting 28

interfaces subdirectory 18

installation

CD, mounting 28

Java Runtime Environment

installation 52

_jvmrep subdirectory 19

Replication Server

Index

license agreement 29 license f i les 3 licenses

acquiring SySAM duri ng a grace period 12 administration of SySAM 46 borrowing SySAM to work offline 48 choosing appropriate SySAM license server 21 installing a network license server 22 managing SySAM 43 renewing borrowed 49 returning borrowed 49 usage and enforcement, SySAM 10

limitations

network license server SySAM 5 $LM_LICENSE_FILE 42 LM_LICENSE_FILE environment va riable 8

lmborrow 48

locales subdirectory 18 location

geographic 29

mount command 22, 28

log files, reviewing after installation 39 log.txt file 19, 27, 37

OCS-15_0 subdirectory 19 operating system

patch requirements 14 threads, increasing in HP-UX 15

operating systems

requirements 14 options file installation. See response file installation overview

SySAM licensing 2

$PATH 42 planning replication system 14 post-installation tasks 39

SAMreport 54 pre-installation requirements

SySAM 21 pre-installation tasks 13 previous installation

with InstallShield 30

with Studio Installer 30 programs

repserver.diag 18

managing

SySAM licenses 43

SySAM licenses from multiple vendors 10 managing and collecting logs 55 methods of installation 27 migrating old SySAM licenses to a new license server

mount command location 22, 28

mounting the installation CD 28 multiple SySAM server configuration 6

network license server configuration, SySAM 4 network license server, SySAM

setting up 5 new installation directories 29

Installation Guide for UNIX 59

redundancy

setting up SySAM three-server 7 release bulletin 13 renewing borrowed SyS A M licenses 49 REP.response template file 34 REP-15_0 subdirectory 19 Replication Server

components 1

details 1

Replication Server Configuration Guide for UNIX 2 Replication Server Installation Guide for UNIX 2

REPORTLOG file, SySAM 50

repserver.diag program 18

requirements

disk storage 14

operating system 14

Index

operating system patches 14

system 14 resetting environme nt variables 26 response files

creating 34

editing 34

installations 27, 34 returning borr owed SySAM licenses 49 reviewing log files after installing 39

RMP-15_0 subdirectory 19 RMS plug-in subdirectory 19

SAMreport

installation 52

post-installation tasks 54

system requirements 51 servers

installing a network license server 22 setting environment variables 26, 41

LD_LIBRARY_PATH 19

LIBPATH 20

SHLIB_PATH 20 setting up

multiple server SySAM configuration 6

network license ser ver SySAM configuration 5

three-server redundancy SySAM 7

three-server redundancy SySAM configuration 7

unserved SySAM con figuration 4 Shared subdirectory 19 silent mode installations 27, 35

troubleshooting 36 software, diagnosing problems 18

source command 42

standard installation 26, 30

InstallShield 30 starting

SySAM licens e server 46

SySAM network license server 46

the sample Replication Server 40 stopping

SySAM licens e server 46

SySAM network license server 46 Studio Installer, previous installation with 30

subdirectories

charsets 18 config 18 interfaces 18 _jvmrep 19 locales 18 OCS-15_0 19 REP-15_0 19 RMP-15_0 19 RMS plug-in 19 Shared 19 SYSAM-2_0 19 ua 19 uninstall 19

supported protocols 14 $SYBASE environment variable 42 Sybase installation directories 25

contents 18 Sybase Product Download Center 43 Sybase Software Asset Manag e ment System. See

SySAM

sybase user 20, 28

creating accounts 20, 21

SYBASE.csh file 19, 26, 41 SYBASE.env file 19, 41 SYBASE.sh file 19, 26, 41 $SYBASE_JRE environment variable 42

SYBASE_LICENSE_FILE environment variable 8

$SYBASE_OCS environment variable 42 $SYBASE_REP environment variable 42 $SYBASE_RMP environment variable 42 $SCROOT environment variable 42 $SYBROOT environment variable 42 $SYBASE_SYSAM environment variable 42 $SYBASE_UA environment variable 42

syntax statements, conventions ix SySAM 3

acquiring licenses during the grace period 12

administration 46

alternate license locations 8

automatically starting and stopping a network license

server 46 borrowing a license to work offline 48 check-out options 3 choosing appropriate license server 21 co-existing with earlier versions 8

Replication Server

Index

configuration options 3 description 2 enabling the network license server REPORTLOG

file 50 installing a network license server 22 license availability and grace periods 11 license dir e c t o r y 3 licenses f i les 3 licenses usage and enforcement 10 licensing instruction overview 2 managing and collecting logs 55 managing licenses 43 managing licenses from multiple vendors 10 manually starting a network license server 46 manually stopping a network license server 46 migrating old licenses to a new central license

server 9 multiple license files 3 multiple servers 6 network license server configuration 4 network license server limitations 5 pre-installation requirements 21 renewing borrowed l icenses 49 returning borr owed licenses 49 setting up a network license server 5 setting up a three-server redundancy configuration

7 setting up an unserved configuration 4 setting up multiple servers 6 unserved configu ration 3, 21 using a central license server only for new license

9 using SAMreport 50 utilities 55

SYSAM-2_0 subdirectory 19 system patches

listing currently installed 15

system requirements 14

SAMreport 51

tables

system requirements 14

tasks, administration 20

three-server redundancy configuration, SySAM

setting up 7

troubleshooting

during console or silent mode installation 36 log.txt 27

types of installations

complete installation 26 custom 26, 30 full 26 standard installation 26, 30 typical 26, 30

typical installation 26, 30

software components for a 30

ua subdirectory 19 uninstall subdirectory 19

uninstalling

console mode 38 GUI mode 37 Sybase products 37

unserved configuration, SySAM 3, 21

setting up 4

upgrading

Adaptive Server Enterprise 40

using

a central license server only for new SySAM license

InstallShield for installation 25

utilities

dsedit 19

SySAM 55

valid installation check 36 variables, SYBASE_LICENSE_FILE and

LM_LICENSE_FILE environment 8

vpd.properties file 19

Installation Guide for UNIX 61

Index

-W flag and setup 36

warnings

installing into existing Adaptive Server Enterprise 12.x

(64-bit) directory 25

Replication Server

Sybase 15 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

About This Book

Introduction

Replication Server components

Sybase Software Asset Management

Installation task overview

How SySAM works

Using an unserved license

Setting up an unserved configuration

Using a network license server

Setting up a network license server

Limitations

Using multiple network license servers

Setting up multiple network servers

Using three-server redundancy

Setting up three-server redundancy

Using alternative license file locations

Co-existing with earlier versions of SySAM

Managing licenses from multiple vendors

License usage and enforcement

License availability and grace periods

If a SySAM license cannot be acquired

Acquiring SySAM licenses during the grace period

Pre-installation tasks

Read the release bulletin

Plan your replication system

Review system requirements

Review operating system patch requirements

Increase operating system threads

Configure the operating system for asynchronous I/O

Understand the installation directory structure

Review the Sybase installation directory contents

Set the required environment variable for dsedit utility

Perform administrative tasks

Creating the “sybase” user account

SySAM pre-installation tasks

Choosing the appropriate license server configuration

Installing a new license serve r

Using InstallShield for installation

Installing Replication Server

Installing in command line mode

Installing with a response file

Installing in console mode with a response file

Installing in silent mode

Checking for a valid inst allation

Troubleshooting installation

Uninstalling Sybase products

Review the log files

Start Adaptive Server for the RSSD

Start the sample Replication Server

Set environment variables

Managing licenses

Using the options file to manage licenses

Starting and stopping network license servers

Borrowing a license to work offline

Enabling the network license server REPORTLOG file

Using SAMreport

SAMreport system requirements

Installing the Java Runtime Environment

Installing SAMreport

Post-installation tasks for SAMreport

Starting and Stopping SAMreport

Managing and collecting logs

Using SySAM utilities

Index
