Switzernet A-100 User Manual
A-100 SIP Phone User Manual (V1.39)
A-100 SIP Phone User Manual
A-100 IP phone Appearance Introduction:..................................................................... 1
Function Keys of A-100 IP Phone Introduction (Normal State).....................................2
Features ................................................................................................................................3
Standard and Protocol......................................................................................................... 3
Operating requirements.......................................................................................................4
Electric requirements........................................................................................................... 4
Size ........................................................................................................................................ 5
Installation............................................................................................................................. 5
Configuration......................................................................................................................... 5
Phone Keypad set................................................................................................................ 5
Configured by WEB............................................................................................................. 9
Configured by PalmTool.................................................................................................... 21
Telnet Configuration........................................................................................................... 21
Upgrade A-100 IP phone ................................................................................................ 37
Usage of the phone............................................................................................................ 38
A-100 IP phone Appearance Introduction:
● A-100 IP Phone Front Illustration (Refer to Fig 1.1):
A-100 SIP Phone User Manual (V1.39)
2
Fig 1.1 A-100 IP Phone Illustration
Function Keys of A-100 IP Phone Introduction (Normal State):
Keys Function
LOCIP
With handset hung, press this key to get local IP address of the phone
MISCAL
With handset hung, press this key to review missed number
ANSCAL
With handset hung, press this key to review received number
NUMBER
With handset hung, press this key to get phone number
DIACAL
With handset hung, press this key to review dialed number
REDIAL
While reviewing missed, received or dialed number, press this key to dial current number
A-100 SIP Phone User Manual (V1.39)
3
SPEAKER
Press this key to have a call without lifting the handset
VOL+
Increase the volumes of handset or speaker; turn over the record backward
VOL-
Decrease the volumes of handset or speaker; turn over the record forward
Features
Hardware
● Main chip—PA1688 50MHz
● Data Memory—2MB SDRAM
● Program Memory—1 MB Flash memory
● Ethernet Jack—1/2 10/100M jacks
● AC/DC adapter—Input AC100--- 230V，Output 9V DC, 1A
Software
● DHCP support for LAN or Cable modem
● PPPoE support for ADSL or Cable modem
● Set phone by HTTP web browser (IE6.0) or Telnet
● Upgrade by FTP
● Support major G.7XX ;GSM610 audio codec
● VAD(Voice active detect)
● CNG (Comfort noise generation)
● Dynamic voice jitter buffer
● G.168/165 compliant 16ms echo cancellation
● Tone generation and Local DTMF re-generation according with ITU-T
● E.164 dial plan and customized dial rules
● 100 entries for quick dial
● 80 entries each for missed calls, answered calls and dialed calls
● Adjustable volume for both handset and speaker
● Voice prompt
● Hotline
Standard and Protocol
A-100 IP Phone supports following standard and protocol:
A-100 SIP Phone User Manual (V1.39)
4
● IEEE 802.3 /802.3 u 10 Base T / 100Base TX
● Major G.7XX; GSM610 audio codec
● SIP(RFC 2543;RFC3261)
● TCP/IP: Internet transfer and control protocol
● RTP: Real-time Transport Protocol
● RTCP：Real-time Control Protocol
● VAD/CNG save bandwidth
● DHCP：Dynamic Host Configuration Protocol
● PPPoE：PPP Protocol over Ethernet
● DNS：Domain Name Server
● Telnet：Internet's remote login protocol
● FTP：File Transfer protocol
● HTTP：Hyper Text Transfer protocol
Operating requirements:
● Operation temperature: 0 to 50° C (32° to 122° F)
● Storage temperature: -30° to 65° C (-22° to 149° F)
● Humidity: 10 to 90% no dew
Electric requirements:
● Voltage: 9V~24V
● Power adapter: output DC 12V/450mA
● Network interface:1/2X RJ-45 Ethernet Connectors
A-100 SIP Phone User Manual (V1.39)
5
Size：
200 x 195 x 87 mm (L x W x H)
Installation:
1． Connect handset to base: insert handset cord into handset cord jack at the
left side of the base.
2． Connect IP phone to Internet: plug the RJ-45 Ethernet cable into the
Ethernet Jack. Plug the other end of the cable into HUB.
Power on IP phone: p
lug the power cord adapter into the Power Jack. Then
plug the other end of the power cord adapter into the appropriate wall outlet.
Configuration
Four different ways can be used to configure A-100 IP phone: phone
keypad, web browser, Telnet commands and PalmTool configuration tool on
computer.
Phone Keypad setup
● Function Keys Introduction: When using keypad and LCD to
configure the settings of IP phone, following keys will be used:
Keys Function Keys Function
LOCIP
Enter setting mode
SPEAKER/OK
Enter submenu; confirm change
VOL+
Turn over menu
backward
VOL-
Turn over menu forward; move
cursor backward
LOCIP/SET
Modify values
REDIAL/EXIT
Exit current menu; exit setting mode
Refer to above operation; you can reach any menu to modify any value.
A-100 SIP Phone User Manual (V1.39)
6
Please refer to following structure illustrations to learn the values of each
menu item. As for the meaning of each item and value, please refer to Web
Browser Setting chapter.
● Menu Structure:
A-100 SIP Phone User Manual (V1.39)
7
A-100 SIP Phone User Manual (V1.39)
8
A-100 SIP Phone User Manual (V1.39)
9
Configured by WEB
Double click icon to open the IE browser. Input the IP address of the
phone into address bar ( ), and then input password
of the phone into the following page. Default password 1234 is ordinary
password and super password is 12345678. With Debug set 0[disable],
please input super password; while Debug is not set as 0[disable], please
input ordinary password. Then click button. The following
configured page wills popup. Refer to Fig 3.1 please.
Fig 3.1 Http Setting
Network Setting：
A-100 SIP Phone User Manual (V1.39)
10
Fig 3.2 Network Setting
● iptype: Set how IP phone gets relevant network parameters by selecting
corresponding item from drop down list.
static ip: Select this item to authorize users set IP address, subnet
mask and router IP address of IP phone manually.
dhcp: Select this item to enable DHCP mode. With this system, your
LAN or router automatically assigns all the required network parameters
to any device connected to it when the device log on. A-100 IP phone
is shipped from the factory with DHCP on. So, if your LAN or router is
configured to use DHCP addressing, the IP phone’s LAN parameters
will automatically be configured as soon as it is connected to the LAN or
router and powered up.
pppoe：Those ADSL and Cable Modem users please select this item for
it is a protocol especially designed for them. With this system, ADSL ISP
automatically assigns all the required IP parameters to any device
connected to it when the device log on.
modem：If the IP phone used with modem, please select this item to get
relevant network parameters auto. Then please fill ID and pin into ppp id
A-100 SIP Phone User Manual (V1.39)
11
and ppppin fields.
● ppp id: With pppoe or modem selected in iptype drop down list, please
enter the user name here.
● ppp pin: With pppoe or modem selected in iptype drop down list,
please enter the password here.
● local ip: With static ip selected in iptype drop down list, please enter IP
address of IP phone here.
● subnet mask: With static ip selected in iptype drop down list, please
enter subnet mask of IP phone here.
● router ip: With static ip selected in iptype drop down list, please enter
router IP address of IP phone here.
● dns: With static ip selected in iptype drop down list, please enter IP
address of DNS server here.
● dns 2: With static ip selected in iptype drop down list, please enter IP
address of backup DNS server here.
● mac: MAC address is the physical address supplied by the Ethernet
NIC. A-100 phone is shipped from the factory with a unique algorism
MAC address printed on the back of the base.
Protocol Setting：
A-100 SIP Phone User Manual (V1.39)
12
Fig 3.3 Protocol Setting
● use service: Enable/disable service by checking/clearing this box. To
make calls through SIP Proxy Server, please check this box; otherwise,
phone can only make IP-to IP calls.
● register ttl : IP phone will send a keep-alive registration message to SIP
proxy server every “register ttl” seconds. The minimum value is 10,
maximum value is 65535.
Default is 60.
● jitter size : Set buffer size of RTP package. The value range is 0-32.
● service type: This option is used to accommodate the miscellaneous
requirements of the system providers. When IP phone is connected to
these systems, please select the corresponding service type.
Common: no special requirements
utstarcom: Use UtstarCom’s SIP system
zte: Use ZTE’s SIP system
ngtel: Use NGTEL’s SIP system
Sipphone: Free SIP service on internet, please visit
www.sipphone.com for more information.
Inphonex: Free SIP service on internet, please visit
www.inphonex.com for more information.
Fwd: Free SIP service on internet, please visit
www.freeworldialup.com for more information.
net2phone: Use Net2phone’s SIP system
stanaphone: Use Stanaphone’s SIP system
italkbb: Use ItalkBB’s SIP system
A-100 SIP Phone User Manual (V1.39)
13
● service addr, service id:
If “use service” is checked, please put the URI of the SIP proxy server
into “service addr”. Put the domain name of the SIP proxy server into
“service id” or leave “service id” empty. If the system has an Outbound
Proxy，please put the URI of the Outbound proxy into “service addr” and
put the domain name of SIP proxy server into “service id”. The default
service port is 5060. If “use service” is not checked, please clear
“service addr” and “service id”.
● nat traversal: When the IP phone with private IP address need
communicate with other IP phones in a different LAN or on Internet,
please select an item from dropdown list to set the proxy used by the
phone.
disable: Select this item when the log in server and IP phone in the
same LAN, or the log in system supports the IP phone working behind
the LAN.
enable: When the system does not support IP phone working behind
the LAN, please select this item to search public IP address of the
NAT device. With this item selected, “nat addr” field will be activated.
Besides, port mapping (port forwarding) needs to be properly set up
on NAT device.
stun: Select this item with SIP protocol used according to
requirement of system. With this item selected, nat addr field is
activated.
● nat addr: When “nat traversal” is set to “enable”, please put the domain
name of the servers ( These web server helps to find out the public IP of
the IP phone) into “nat addr”, such as www.whatismyip.com
.
When “nat traversal” is set to “stun”, please put the URI of the stun server
into “nat addr”, in the format as “domain name/IP address : service port”.
The default service port for stun is 3478.
● nat ttl: When IP phone sit behind a NAT device, it will send packets to
server every “nat ttl” seconds to keep the port mapping on the NAT
device alive. “nat ttl” is an integer between 10 and 65535, default value is
20.
● phone number: The local phone number or username of this phone,
