ePur e

Digital Cordless telephone (DECT 6.0)

User manual

ePure

Welcome to Swissvoice

The ePure is a cordless telephone designed for connection to an analog telephone
network. International DECT (GAP)-standard digital technology offers excellent voice
quality.
You can register up to 5 handsets to your base and make internal calls free of charge.

The ENERGY STAR
encourages the use of products that save energy and help protect our
environment. We are proud to mark this product with the ENERGY STAR
label indicating it meets the latest energy efficiency guidelines.

Warning

Be sure to read this user guide and the safety precautions before using your
telephone. Explain their content and the potential hazards associated with using the
telephone to your children.

$

Use only the charging cradle supplied with the power adapter.

Use only recommended, rechargeable batteries. Failure to do so
could damage your health and cause injury.
Do not charge the handset in charging unit or base station while the
headset is connected.

Using your telephone may affect nearby medical equipment. Be
aware of the technical conditions in your particular environment
(such as a doctor's office).

Do not hold the rear of the handset to your ear when it is ringing or
when the handsfree function is activated. Otherwise, you risk serious
and permanent damage to your hearing.

Do not install the charging cradle in bathrooms or shower areas. The
charging cradle is not waterproof.

Do not use your phone in environments that pose a explosion
hazard (e.g., paint shops).

®

program (www.energystar.gov) recognizes and

®

ƒ

If you give your phone to someone else, make sure you also give
them the user guide.

Please remove faulty base stations from use, as they could interfere
with other wireless services.

ePure

ePure

Contents

Keys 2
Display symbols 3
Range / Location 3
Battery advice 4
Insert the battery 4
Connecting the phone 5
Set date and time 5
Set language 5
Making a call 6
Redial 7
PBX operation 7
Paging – Locate mislaid handsets 8
Phonebook 8
Direct memory 9
Calls list and caller ID operation 9
Extending the ePure 11
Making a call with several call partners 12
Personal settings 13
Advanced settings 13
Appendix 14

ePure 1

ePure

Menu / Select

Intercom

Redial

Flash

abc

def

ghi

jkl

mno

pqrs

tuv

wxyz

16

15

14

13

1

2

3

4

5

8

12

6

11

10

7

9

1

Page

Keys

Handset

1 Earpiece
2 Display
3 Redial key

During a call: Mute the microphone

4 Menu/Select key

In standby: open the menu
In a menu or list: select the highlighted

item
5 End call key / back to idle mode
6 Talk key
7 Key 1: Insert a space
8 Digit keys
9 Star key
10 Key 0 / Intercom key

Press 3 sec. for internal calls
11 Microphone
12 Loudspeaker (for ring signal and

hands-free)
13 Hash key

switches between lower and upper

case letters / switches off ringer / press

3 sec. when editing an entry: insert a

Base

2 ePure

pause
14 Flash key (press 3 sec. key "9")

Send a hook flash signal to the

currently connected line
15 Control LED (flashes when you have

one or more missed calls, flashes

quickly with an incoming call)
16 Navigation key / set volume

1 Page key (on the bottom)

Display symbols

12:03

Steady on: batterie’s charge level.
Flashing: batteries have to be charged.

Time.

Call in progress.

Steady on : the caller’s list is open.
Flashing : new calls in the caller’s list.

The phonebook is open.

Scroll up/down in a list or a menu.

Confirmation.

Ringer off.

Handsfree active.

Alarm is set.

Steady on, when the handset is near the base. Flashes, if out of range or
not registered.

Range / Location

To obtain the best possible range, we recommend positioning the telephone in a
location central to your sphere of activity. Avoid positioning the telephone in niches,
recesses and behind steel doors.
The maximum range between base station and handset is approximately 900 feet
outdoors. Depending on the surrounding conditions as well as spatial and structural
factors, the range may be smaller. Silent zones can occur due to the digital transmis­sion in the frequency range used – even within the range, depending on the structural
environment. In this case the transmission quality may be reduced through the
increased incidence of short breaks in transmission. Normal call quality can be
restored if you move slightly out of the silent zone. If the range is exceeded, the call
will be disconnected unless you move back into range within ten seconds.

ePure

ePure 3

ePure

Battery advice

Use only the original battery (Li-Ion 3.7 V / 550 mAh) as well as the original power sup­ply (7.5 VDC, 300mA).

The handset operating times (standby 150 hours/active 10 hours) and charging times
apply only if the battery is charged to the defined minimum capacity.

Charging is electronically controlled to ensure optimal charging and care of battery in
different charge states. Full capacity is achieved only after several charging cycles.

Note:
Using other rechargeable battery or non-rechargeable battery/primary cells
can be dangerous and cause malfunctions or damage to the telephone. Do
not short-circuit the battery (danger). In particular, avoid inadvertent short­circuits during storage and transport e.g. bunch of keys, metal panels or
similar objects, and make sure the battery do not come into contact with
greasy materials. When not in the handset, therefore, battery should be
stored only in insulating packaging. Ensure also that the contacts do not
touch greasy parts.
Rechargeable battery can become warm while recharging. This is a normal
occurrence and is not dangerous.

Insert the battery

The battery compartment is situated in
the handset.
Open the handset cover.
Insert the battery in the battery compart­ment.
Replace the handset cover.

Make sure you install the battery pack and fit the cover the right way round:

- position the 3 metal contacts of the battery pack against the 3 blade
contacts,

- align the green dot on the handset with the one on the cover.

4 ePure

Green dots

ePure

Tel. Line

Power

Connecting the phone

Telephone line socketMains power socket

• Before you can start using your telephone you must plug in the telephone
connector cable and the mains cable.

• When the phone is delivered, the battery is not yet charged.

• To charge the battery, insert the handset in the base station. The battery will take
around 6 hours to fully charge (initial charge).

Set date and time

After setting up the telephone first, date and time are not set.

• Press , select

• Select

Date&Time

Clock/Alarm

and press OK.

with the navigation key

π/†

and press OK.

• Enter date and press OK.

• Enter the time and press OK.

Set language

• The language of the display texts can be changed in the menu:

Personal set/Language

ePure 5

Redial

ePure

Making a call

• Dial the desired number using the keypad.

• Press the Talk key .

End the call

Press the End call key.

Receiving a call

• Incoming calls are signalled by a ring tone and a quick flashing of the control LED

on the handset.

• Press the Talk key and conduct your conversation.

End the call

Press the End call key.

Calls cannot be made if the battery is almost discharged or the handset is
out of range of the base station.

Switch ringer off

When a call is coming in, press and hold the key for approx. 3 seconds. The
ringer is switched off for this call.

Mute handset microphone

Press to deactivate the microphone in your handset during a call.
Press the key again to reactivate the microphone.

Set speaker/loudspeaker volume

You can adjust the speaker/loudspeaker volume during a conversation.
Set the desired volume using the navigation key

π/†

.

Switch handset off

• Press and hold the End call key (approx. 5 sec).

• Press and hold again the End call key to reactivate the handset.

6 ePure

Set alarm

Redial

• Press , select
OK.

• Select

Set alarm

• Select the desired alarm function (e.g. On once), enter the alarm time and press
OK.

Clock/Alarm

using the navigation key

using the navigation key

π/†

and press OK.

π/†

and press

Set alarm tone

• Press , select
OK.

Alarm tone

• Select

• Select the desired alarm melody and press OK.

The activated alarm is displayed in standby mode by .
The alarm sounds for 60 seconds or can be deactivated immediately by pressing
any key.

Clock/Alarm

using the navigation key

using the navigation key

π/†

and press OK.

π/†

and press

Redial

The Redial list contains up to 10 entries.

• Press and select the desired entry using the navigation key

• Press the Talk key.

Edit redial list

• Open the Redial list, press OK.
You have the following options:

- Save Number

- Delete entry

- Delete All

– Add number to the phonebook.

– Delete the entry.

– Delete the entire redial list.

π/†

.

ePure

PBX operation

Your telephone is designed for use in the analogue telephone network and can be
operated on a PBX that supports DTMF dialling and flash signalling. To enter the R key
(e.g. needed to establish a connection) press key for 3 sec.
You can adjust the flash/recall time for key R (see chapter "Advanced settings").

ePure 7

ePure

Paging – Locate mislaid handsets

All registered handsets ring for one minute, when the Page key on the base is
pressed. To stop the ring press the End call key on the handset or the Page key

on the base.

Phonebook

You can store up to 100 names and numbers in the phonebook on each handset.

Digits / Characters

Different characters are printed on each key. The entries in the phonebook are sorted
alphabetically.

Key # Change from upper case to lower case letters (ABC/abc).

Key 1 Insert a space.

Add new entries in the phonebook

• Press , select

• Select

• Enter the desired name and press the navigation key

• Press OK to save the entry.

Edit phonebook

• Press , select

• Select

• Select the desired entry using the navigation key

• Press the Talk key to call the number.

Press 3 sec. to insert a pause inside a phone number (“P” appears).

New entry

Phonebook

and press OK.

and press OK.

π/†

options.

View entry

the name.

Phonebook

and press OK.

and press OK.

π/†

or enter the first letter of

for further input

In the phonebook menu you have the following options:

- New entry

- View entry

- Delete all

- Direct mem

- PB Transfer

8 ePure

- Call a programmed direct memory number.
– Copy phonebook to another handset.
