INSTALLATION
INSTRUCTIONS
Pierre Vanity
Swiss Madison
®
®
Share your pictures for a feature
using #SwissMadison
www.swissmadison.com | 1-434-623-4766 | info@swissmadison.com
Thank you for your purchase!
Thank you for purchasing a Swiss Madison Vanity.
We appreciate your business and know you will enjoy your product for many years to come.
If you have any questions or require assistance we would be happy to help,
please contact us at 1-434-6234766 or info@swissmadison.com.
To learn more about our products, please visit:
www.swissmadison.com
Sincerely,
The Swiss Madison Team
Prior to Installation:
· Inspect vanity to ensure no damages have occurred during shipping.
· Observe all plumbing and building codes in accordance with your state and local requirements.
· Additional floor and wall preparations may be necessary to avoid damage to the product.
· Height of console frame is NOT adjustable.
· All dimensions are nominal! Be sure to measure your vanity prior to installation.
General Recommendations: Read installation and maintenance instructions thoroughly before installing.
Be sure to use proper tools and always wear proper personal safety accessories for your protection.
If you have any questions or concerns please contact us:
1-434-623-4766
info@swissmadison.com
— 1 —
VANITY MODELS
H”
Collection
D” x W” x H”
W”
24”
D”
Model - Frame Color
18 5⁄16”
19 ¹⁄8”
25 ³⁄8”
Pierre
9 7⁄8” x 19 ¹⁄8” x 25 ³⁄8”
*Matching Drain: SM-PD23
SM-BV551
SM-BV551C
SM-BV551G
9 7⁄8”
- Matte Black Frame
- Chrome Frame
- Gold Frame
24 ¹⁄4”
Pierre
18 5⁄16” x 24” x 24 ¹⁄4”
*Matching Drain: SM-PD23
SM-BV552
SM-BV552C
SM-BV552G
- Matte Black Frame
- Chrome Frame
- Gold Frame
35 7⁄8”
24 ¹⁄4”
Pierre
18 5⁄16” x 35 7⁄8” x 24 ¹⁄4”
*Matching Drain: SM-PD23
SM-BV553
SM-BV553C
SM-BV553G
18 5⁄16”
- Matte Black Frame
- Chrome Frame
- Gold Frame
*Compatible drains sold separately - multiple color options available.
NOTE: Pictures may not define contour of china and components.
— 2 —
VANITY MODELS
24 ¹⁄4”
Pierre
18 5⁄16” x 47 5⁄8” x 24 ¹⁄4”
*Matching Drain: SM-PD23
47 5⁄8”
SM-BV554
SM-BV554C
SM-BV554G
18 5⁄16”
- Matte Black Frame
- Chrome Frame
- Gold Frame
29 ¹⁄2”
24 ³⁄16”
Pierre
18 5⁄16” x 29 ¹⁄2” x 24 ³⁄16”
*Matching Drain: SM-PD23
SM-BV556MB
SM-BV556C
SM-BV556G
18 5⁄16”
- Matte Black Frame
- Chrome Frame
- Gold Frame
*Compatible drains sold separately - multiple color options available.
NOTE: Drawings may not exactly define contour of china.
— 3 —
VANITY INSTALLATION INSTRUCTIONS
The step-by-step guidelines in the installation instructions are a general reference for installing a Swiss Madison Vanity.
Should there be any discrepancies, Swiss Madison cannot be held liable.
It is recommended to install all Swiss Madison products by hiring a licensed professional
1. Read the complete instruction manual before beginning installation.
2. Confirm that your model will fit in intended location and plumbing fixtures are
located where legally required before beginning installation.
3. Not all drawings on this manual are drawn to scale. Please refer to the model chart.
4. Two people are recommended to install and move this product.
5. Floor must be level PRIOR to installation.
SUGGESTED TOOLS AND MATERIALS
Drop Cloth Silicone
Glasses
Adhesive Screw
Drivers
GlovesSafety
Pencil Allen
Wrench
Level
Wall Anchors
(not included)
PARTS LIST
· Swiss Madison Sink · Console Components · Faucet (not included) · Drain (not included)
1. Assemble Vanity Base
· Using the provided hardware, assemble
the vanity base as illustrated below.
1
5
4
3
2
NOTE: Drawings may not exactly define contour of china.
— 4 —
VANITY INSTALLATION INSTRUCTIONS
2. Install Vanity Base
· Secure vanity base to the wall in your
desired location.
NOTE: Use wall anchors along with
included hardware.
3. Install Faucet and Drain
· Following manufacturer's instructions,
install drain and faucet onto vanity top.
4. Apply Adhesive
· Using your chosen adhesive, apply a bead of
silicone around the rim of the console base.
5. Secure Sink
· Carefully lower sink into place so that it is
resting on the vanity base.
· Press sink firmly into place and wipe away
excess sealant with a damp cloth.
· Allow for adhesive to cure for 24 hours.
NOTE: Curing time may differ depending on
which adhesive you use. Be sure to check
the instructions on your adhesive prior to use.
NOTE: Drawings may not exactly define contour of china.
— 5 —
VANITY INSTALLATION INSTRUCTIONS
6. Seal Sink
· Apply a bead of caulk along the back
edge of the sink against the wall.
· Wipe away any excess.
7. Install Plumbing Fixtures
· Connect drain trap to drain & water supply
connections to the faucet according to
manufacturer’s instruction.
· Run water and check for leaks.
8. Install Glass
· Place glass inside of console so it rests
on the bottom of the base.
OPTIONAL: Use your desired adhesive to
permanently set glass into place.
NOTE: Drawings may not exactly define contour of china.
— 6 —
®
Swiss Madison
1-434-MADISON
(623-4766)
19 Stults Road
Dayton, NJ 08810
ONE YEAR LIMITED WARRANTY
Swiss Madison® products are made with quality materials and excellent craftsmanship to provide our
customers with beautiful, durable, long-lasting products. Should there be any defects in materials or
craftsmanship under regular use that are discovered within the first year of installation, Swiss Madison®
will provide replacement parts at no charge, or at its discretion, replace any product or part of the product
that is deemed defective, under normal installation, use, service or maintenance. This warranty applies
only to the original purchaser. Proof of purchase will be required in the instance of a claim.
Swiss Madison® recommends all installations of Swiss Madison® products to be conducted by a
licensed, professional plumber or contractor. Swiss Madison® will not be held responsible for any
damage or product failure due to improper installation, misuse, or failure to utilize a licensed professional
for installation. Swiss Madison® is not responsible for any installation or removal costs.
This One Year Limited Warranty Will Be Voided If:
• The installation recommendations were not followed by the installer
• The product has been moved from its initial place of installation
• The product has in any way been modified from its packaged state
• The product has been subjected to improper maintenance, abuse, misuse, excessive use of
chemicals, accidents, or other damages, etc.
www.swissmadison.com
Swiss Madison® makes no implication that its products comply with any local building or plumbing
codes. It is the consumer’s responsibility and obligation to determine local code compliance prior to and
during installation. This warranty extends only to the original purchaser and first consumer.
Swiss Madison® is not responsible for any special, incidental or consequential damages associated with
the installation, replacement, return or use of the original purchaser’s product. This includes, but is not
limited to: freight costs, labor, travel time, lost profit, home damages and other contingent liabilities and
costs (including, without limitation, costs associated with ‘professionals’ or ‘experts’, investigations,
audits, analyses, attorneys and any other professional/hired services).
The Swiss Madison® warranty is a comprehensive and explicit limit of liability. All items not disclosed
within the warranty are not addressable within the responsibility of Swiss Madison®. Certain states have
variances regarding implied warranties; in those situations, we remain fully compliant.
If you have any questions or concerns, please contact us directly at
1-434-MADISON (623-4766)
WARNING: Contents of your order may contain sharp and possibly other harmful pieces and may
cause hazard to children and adults. Swiss Madison® is not responsible in any way for personal damages.
