Packing list
Parts Qty Parts Qty
Heat Sink 1 Fan & fan guard 1
Heat sink Installation
1. The case should be laying flat on a table.
2. Lightly coat the CPU with the provided Céramique™ thermal compound. Detailed instructions can be found at
Spring loaded screw assemblies 2 Thermal grease – Céramique 1
http://www.arcticsilver.com/ceramique_instructions.htm
Rub some compound in base
of water-block first, and then
clean off with lint-free cloth.
Apply small amount of
compound on the CPU heat
spreader
6-32x1 7/8“
p h ilip s s c re w
Washer
Spring
Tension lim iter
Heatsink assy.
Motherboard assy.
Pla stic rete n tio n fra m
& backplate
sold separately
Figure 1
Copyright Swiftech 2002 – All rights reserved – Last revision date: 11-8-04
Rouchon Industries, Inc., dba Swiftech – 1703 E. 28
E Mail: Swiftech @swiftnets.com – URL: http://www.swiftnets.com
th
Street, Signal Hill, CA 90755 – Tel. 562-595-8009 – Fax 562-595-8769
Page 1
Information subject to change without notice
3. Heatsink installation
Simply place the heatsink onto the processor as shown in Figure 1, page 1, and gradually tighten the spring loaded screws: Tighten
one side a few turns, then switch to the other side and tighten a few turns, and continue this procedure until full tension has been
reached.
Because a majority of motherboard manufacturers already
include the retention frame and backing plate with their
offerings, and in an effort to spare this cost to the majority of
users, Swiftech does not include these items with the MCX64V™ heatsink. These items are nonetheless offered as an
option under part # AJ00172, as shown below.
When using the backing plate shipped with their motherboard,
users are advised to inspect it, and to note that a metallic
backing-plate featuring threaded standoffs is required. An
example is shown below, and is available under part #
AJ00264.
Final inspection
Now that the heat sink is installed, startup your computer, go into the BIOS and observe the CPU temperature. CPU temperature is
completely dependant on ambient temperature inside the case, type of fan used, and processor frequency. At the lowest air flow level,
the MCX6400-V heatsink should never exceed AMD’s specifications, as defined in the link below:
http://www.amd.com/us-en/assets/content_type/white_papers_and_tech_docs/30430.pdf
In all cases, and irrespective of any of the factors listed above, processor temperature should never exceed 65°C as you monitor the
temperature in the Bios. If it does, shut down the computer immediately, and review your entire installation. Troubleshooting help is
available on our web site at www.swiftnets.com
, or by calling customer support at 562-595-8009.
Fan specifications:
Manufacturer: Delta
Bearing type: dual Ball Bearing
Features: RPM sensor
Part #
AFB0812M
-F00
Voltage
(V)
12
Operating
Range
(V)
7.0 to
13.8
Rated
curren
t
(mA)
0.12 2700 31.4 28.0
Speed
(RPM)
Max.
Air
Flow
(CFM)
Noise
(dB-
A)
IMPORTANT DISCLOSURES
While all efforts have been made to provide the most comprehensive tutorial possible, Swiftech assumes no liability expressed or implied for
any consequential damage(s) occurring to your components as a result of using Swiftech cooling products, either due to mistake or omission
on our part in the above instructions, or due to failure or defect in the Swiftech cooling products.
WARRANTY
Our products are guaranteed for 12 months from the date of delivery to the final user against defects in materials or workmanship. During
this period, they will be repaired or have parts replaced provided that: (I) the product is returned to the agent from which it was purchased; (II)
the product has been purchased by the end user and not used for hire purposes; (III) the product has not been misused (*), handled
carelessly, or other than in accordance with any instructions provided with respect to its use. This guarantee does not confer rights other than
those expressly set out above and does not cover any claims for consequential loss or damage. This guarantee is offered as an extra benefit
and does not affect your statutory rights as a consumer.
