SWEEX SC005 User Manual

English version
4
English version
SC005 Sweex Sound Card 7.1 with Digital In/Out PCI
Introduction
First of all, many thanks for purchasing this Sweex 7.1 PCI Sound Card. To ensure this product operates correctly, we advise you to carefully read this manual first. If despite this manual you still experience problems during installation or operation of this product, go to www.sweex.com and look under the heading service & support.
Prior to installation, check if all required parts are present. The following parts must be present in the box:
• 7.1 Sound Card PCI
• Extension cable for audio connectors
• SPDIF optical cable
• CD-ROM with manual and drivers
If one of the above parts is missing, please contact the shop or supplier.
Specifications
• 32-bit PCI BUS master
• Full-duplex recording and play-back
• C-MEDIA chipset
• PCI revision 2.2
• 7.1 connection
• SPDIF coaxial and optical digital output
• MPU-401 game/midi port
• Supports: Windows 98SE, 2000 and XP
• Dolby Digital EX, DTS ES
• AD3, EAX 2.0
English version
5
English version
Installation of hardware
Take the following precautionary measures prior to installing the hardware:
1. Ensure the PC is switched off and disconnected from the mains.
2. Also, disconnect the printer and monitor cables (they have their own power supplies) to make absolutely sure the PC is not live.
3. Now unscrew the computer casing.
4. Subsequently, remove any static electricity you may carry on your body. Do this by touching a (neutral) pipe of the central heating system or an unpainted water pipe, among other things. Please note that you must not use a magnetic screwdriver for this. Before you proceed any further, briefly touch the iron frame of the PC casing. Make sure that you minimise contact with any contact points of the PC, PC Card or the memory.
5. Find a vacant PCI slot and remove the metal guard plate part of the computer casing in front of the relevant slot. On occasion the card does not allow for it to be inserted in the PCI slot smoothly. Should this be the case, do not force anything, but try another available slot.
6. Once the card has been successfully installed, check whether all other cards are still properly inserted in the PCI slots. It is possible that the other PCI cards are lifted up slightly when installing a new PCI card; as a result, the relevant cards or even the entire PC may no longer operate correctly.
7. Replace the casing on the computer base and correctly reconnect all cables.
8. Switch on the PC again.
Installation
When starting up the PC, Windows will recognise the Sound Card and the following screen will appear.
Here click “Cancel” (Cancel).
After the PC has started up, insert the Sweex CD-ROM in the CD player. If you have already done so, open the CD-ROM player and close it again. The CD-ROM will start automatically. Click on “Driver” to start the driver installation process.
