SWEEX PA320 User Manual
SP300
ARENA
2.0 Speaker Set
PA320
90 Watt Universal
Notebook Adapter
PA320_quickstart_V1.indd 1 18-11-11 12:44
1x
Please visit our website for CE declaration: sweex.com
1x
1x
1x
10x
PA320_quickstart_V1.indd 2 18-11-11 12:44
Connecting product
2. Check the label on your notebook or your notebook’s original adapter for
a power rating. The power rating may not be higher than 90 W. If no power
rating is supplied, check that the current rating does not exceed the specified
current rating of the adapter for the listed voltage (see specifications).
1. Remove Voltage Protection Cap.
PA320_quickstart_V1.indd 3 18-11-11 12:44
3. Check which tip type fits your notebook best or check our website.
Don’t connect the tip to the adapter cable yet!
Note: The fixed tip can also fit on several notebooks!
WARNING! DO NOT USE ADAPTER BEFORE SETTING THE CORRECT OUTPUT VOLTAGE.
FAILURE TO DO THIS MAY RESULT IN DAMAGE TO YOUR NOTEBOOK.
Connecting product
10 + 1
PA320_quickstart_V1.indd 4 18-11-11 12:44
Connecting product
4. Check the label on your notebook for the correct input voltage, then select
the correct output voltage on the adapter.
DC RATING
19V
12 V
2 4 V
16 V
15 V
18 .5 V
18 V
19 .5 V
19 V
2 0 V
12 V
2 4 V
16 V
15 V
18 .5 V
18 V
19 .5 V
19 V
2 0 V
12 V
2 4 V
16 V
15 V
18 .5 V
18 V
19 .5 V
19 V
2 0 V
