Sweex NA015, NA018 Quick start guide
English version
English version
NA005/NA007/NA015/NA016/NA018
Sweex WiFi Antenna 5 DBI / 7 DBI / 5 DBI / 6 DBI / 8 DBI
Introduction
First of all, many thanks for purchasing this Sweex WiFi Antenna. With the Sweex WiFi Antenna you can easily expand the wireless range of your
router or PCI card.
To ensure this product operates correctly, we advise you to carefully read this manual first. If despite this manual you still experience problems during
installation or operation of this product, go to www.sweex.com and look under the heading service & support.
In order to fully enjoy the Sweex WiFi Antenna, it is important to observe a number of things:
• Do not expose the Sweex WiFi Antenna to extreme temperatures. Do not place the antenna in the direct vicinity of heating elements.
• Do not use the Sweex WiFi Antenna in extremely moist surroundings.
• Protect the cable against powerful shocks or jolts – they may damage the internal electronics.
• Never attempt to open the device yourself – it will cause the warranty to lapse.
Contents of the box
Prior to using the Sweex WiFi Antenna, check if all required parts are present. The following parts must be present in the box:
• WiFi Antenna
• CD-ROM with manual
If one of the above parts is missing, please contact the retail outlet.
Specifications NA005
• Amplification: 5 dBi, omni-directional
• Supports: 802.11b and 802.11g
• Connector: RP SMA
• Frequency range: 2.4 ~ 2.4835 GHz
• VSWR ratio:
• Impedance: 50 Ohm nominal
2.0
4
Specifications NA007
• Amplification: 7 dBi, omni-directional
• Supports: 802.11b and 802.11g
• Connector: RP SMA
• Frequency range: 2.4 ~ 2.4835 GHz
• VSWR ratio:
• Impedance: 50 Ohm nominal
2.0
Specifications NA015
• Amplification: 5 dBi, omni-directional
• Supports: 802.11b and 802.11g
• Cable: 1.5 metre coax, type RG174
• Connector: SMA
• Frequency range: 2.4 ~ 2.4835 GHz
• VSWR ratio:
• Impedance: 50 Ohm nominal
2.0
Specifications NA016
• Amplification: 6 dBi, omni-directional
• Supports: 802.11b and 802.11g
• Cable: 1.5 metre coax, type HPP100
• Connector: SMA
• Frequency range: 2.4 ~ 2.4835 GHz
• VSWR ratio:
• Impedance: 50 Ohm nominal
2.0
English version
English version
Specifications NA018
• Amplification: 8 dBi, directional
• Supports: 802.11b and 802.11g
• Cable: 1.5 metre coax, type HPP100
• Connector: SMA
• Frequency range: 2.4 ~ 2.4835 GHz
• VSWR ratio:
• Impedance: 50 Ohm nominal
2.0
5
