User Manual
A Interface
B Touch & Press
C Quick Info Screens
D Functions
1 Watch
2 Pedometer
3 Beach Volleyball
4 Fan
5 Set
6 Goal
7 Bluetooth
E Various
F Legal Notices
............................................................4
..................................................5
...........................................6
..........................................................7
..................................................8
.........................................10
................................11
....................................................13
.....................................................15
...................................................17
...........................................18
..............................................................20
.................................................22
Summary
4
1
When you reach 10,000, the 10K icon is displayed (20,000 = 20K, 30,000 = 30K)
2
Displayed on each screen when the alarm is activated
3
Displayed when the battery is running low
4
Displayed on all the T1/T2 screens when the 12 hour format is selected
A Interface
Conrmation is always
accompanied by a sound.
Information that can be entered
or changed ashes.
Functions
Minutes
Hours
Functions (ctd.)
Number of steps
1
Statistics
Bluetooth
Goal
Seconds
Alarm²
12 hour clock
mode
4
Battery³
Touch zone
5
B Touch & Press
LONG PRESS (2s)
SHORT PRESS (0.5s)
SWIPE (from left to right or right to left)
Screen locked Screen unlocked
Unlock screen
Quick info screen
Lock screen
Go into a menu, conrm
a setting
Navigate into a menu,
edit numbers
6
C Quick Info Screens
When the screen is locked, a
Short Press automatically displays
information from the Pedometer,
Beach Volleyball or Fan function.
Volleyball and
Fan deactivated
Fan activated
Volleyball activated
7
D Functions
Watch
1
Pedometer
2
Volleyball
3
Fan
4
Your Touch Zero One has 7
main functions/menus.
Long Press: Unlocks the watch
Swipe: Browse functions
Short Press: Enter a function
Goal
6
Set
5
Bluetooth
7
8
1 Watch
1.1. Set the time (T1/T2) and date
Go to T2 and DATE, then use
the same procedure to set
a) b)
c) d)
T1/T2/Date can be set in the app
9
1.2. Set the alarm
1.3. Use the stopwatch
Idem 1.1.
b) + c)
a) b)
1.4. Set timer
Idem 1.1.
b) + c) + d)
Can be set and
activated in the app
Other tunes can be
set in the app
Other tunes can be
set in the app
R
E
L
O
A
D
T
I
M
E
R
B
E
E
P
S
T
O
P
A
L
A
R
M
B
E
E
P
S
T
O
P
2 Pedometer
2.1. Statistics
l
The pedometer function is always activated.
l
To see the number of steps you have taken in real time, go to the
Pedometer Quick Info Screen.
l
The number of steps is reset to zero at midnight every day (T1 time).
(total steps) (total calories burned)
(total distance
traveled)
(total time)
The watch can transfer data from the
Pedometer to the smartphone app (Steps
/ kCal / km / Time)
Weight and Height can be set in the app to
provide a more precise calculation of kCal
burned and distance travelled
Steps kCal km Time
3 Beach Volleyball
3.1. Options
lWhen it is activated, the pedometer will stop counting steps.
(power of the last shot)
(total number of
shots)
3.2. Activate/deactivate
a) b) c)
Beach Volleyball ON:
Automatic counter for Power
Hits and Hits
Beach Volleyball OFF:
Counter for Power Hits and
Hits frozen
The watch can transfer match data to the app
(Power Hits / Hits)
In the app, you can set the watch to
Right handed / Left Handed, Amateur
/ Pro
You can hide this function on your
watch in the app
Wear the watch on the wrist with
which you hit the ball.
OFF/ON
Power Hits Hits
3.3. Memory full (erase data)
a) b) c) d)
When the memory is full, Beach
Volleyball displays this.
If the memory is full, the Power
Hits and Hits counters are
frozen.
dEL
(delete data)
a)
b) c)
4 Fan
4.1. Options
(power of the last applause)
The ice cream is displayed in relation to
the last Power Claps:
(total number of claps)
4.2. Activate/deactivate
a) b) c)
The watch can transfer Fan data to the app
You can hide this function on your watch in
the app
33 to 65
claps
99 claps
66 to 98
claps
l
When it is activated, the pedometer will stop counting
steps.
Fan ON:
Automatic counter for Power
Claps and Claps
Fan OFF:
Counter for Power Claps
and Claps frozen
OFF/ON
Power Claps Claps
4.3. Memory full (erase data)
a)
a)
b)
b)
c)
c)
d)
When the memory is full, Fan
displays this.
If the memory is full, the Power
Claps and Claps counters are
frozen.
(delete data)
dEL
5.1. Settings
5 Set
a) b) c) d)
All settings can be changed in the app
a) b) c)
Date EU/USA
km/miBeep 24h/12h
c)
c)
c)
b)
b)
b)
a)
a)
a)
6 Goal
6.1. Activate/deactivate
6.2. Set
To set a goal, Goal must be
activated.
An ice cream icon lls up as you make
progress towards your goal.
1) You have achieved one third of your goal
2) You have achieved two thirds of your goal
3) You have achieved or exceeded your goal
a)
1) 2) 3)
a)
b)
b)
c)
Goal settings can be
changed in the app.
7 Bluetooth
7.1. Activate/deactivate
7.2. Pairing
Activate Bluetooth on your
smartphone.
BLUE will change to the MAC
address for your watch. The icon
ashes.
a) b) c)
Enter the MAC address for your
watch into your smartphone. Select
to set up the pairing.
You can change the name of your watch
in the app
20
E Various
1. Backlight
2. Battery low
3. Changing the battery
Remove the battery using a coin or
a at-headed screwdriver, turning
counterclockwise.
Note: If you remove the battery from your watch, for example to replace it, the data
saved (e.g. hits, claps, km, etc.) will not be deleted. However, other settings such
as time and date may require resetting.
When the battery is running low,
this icon is displayed.
Screen locked
Long Press (hold):
Turns on the backlight.
Screen unlocked
Long Press (hold):
Turns on the backlight.
or or
or
21
4. Restore default user factory settings
1. Remove the battery
2. Wait for the LCD to turn black
3. Replace the battery, keeping a nger under-
neath
4. After reconnecting the battery:
- the watch emits a 2 second beep
- the software loads
- the beep stops
- the screen lights up for 5 seconds
5. Wait for 1 second, touch the 3 touch zones at
the same time when the screen is lit up
6. Wait for the screen to display ‘test’
Remove your ngers
Short Press to enter
7. Go to the Init screen by swiping
8. Short Press to enter
9. Short Press to change
10. Swipe to choose YE (Yes)
Short Press to validate
Your watch has been restored to its factory
settings.
5) 6)
7)
8) 9)
10)
22
F Textes légaux
Les parties en rouges nécessitent des changements ultérieurs.
Equipment type: Bluetooth Smart digital watch
Model: SUV 1
Manufacturer: Swatch
Address: Jakob-Staempi Strasse 94, 2502 Bienne Switzerland
Country of origin: Switzerland
EU, Switzerland, Turkey - CE Marking
This device complies with the R&TTE Directive (1999/5/EC), the EMC Directive
(2004/108/EC), and the Low Voltage Directive (2006/95/EC) issued by the Commis-
sion of the European Community.
Country list :
Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherland, Poland, Portugal, Romania, Slovakia, Slovenia, Spain,
Sweden, United Kingdom, Switzerland, Turkey.
(Registration manual : English
Launch manual : In respective languages of EU)
USA Federal Communications Commission Interference Statement
FCC ID:2AD9FSUV1
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interfe-
23
rence to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the re-
ceiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Caution:
Any change or modications not expressly approved by the grantee of this device
could avoid the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
RF exposure warning:
The equipment complies with FCC RF exposure limits set forth for an uncontrolled environment.
The equipment must not be co-located or operating in conjunction with any other antenna or transmitter.
Canada, Industry Canada (IC) Notices
IC: 1957A-SUV1
This device complies with Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation of the device.
This device complies with Industry Canada license-exempt RSS standard(s).
CAN ICES-3(B)/NMB-3(B)
Canada, avis d’Industry Canada (IC)
Cet appareil est conforme avec Industry Canada exemptes de license RSS
sandard(s). Son fonctionnement est soumis aux deux conditions suivantes :
24
(1) cet appareil ne doit pas causer d’interférences et (2) cet appareil doit accepter toute
interférence, notamment les interférences qui peuvent affecter son fonctionnement.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils exempts de licence.
CAN ICES-3(B)/NMB-3(B)
Australia
This device has been tested according to the RCM requirements.
Brazil
(User Manual in Portuguese)
Applicable standards : Bluetooth Low Energy 4.0
See www.anatel.gov.br
Anatel : HHHH-AA-FFFF
Anatel logo :
(The codes and bar code will be updated when we shall receive the certicate).
Este equipamento opera em caráter secundário, isto é, não tem direito a proteção
contra
interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário.
25
China
CMIIT : XXXXYYZZZZ
(Registration manual : English
Launch manual : Chinese)
Custom Union : Russian Federation, Kazakhstan, Belarus
(User Manual needed in russian)
Russian certication number : XXXX (to be updated when known)
Japan
This device is certied based on Japan Technical Standard Conformity Certication.
(Registration manual : English
Launch manual : Japanese)
CCC-jjxxxx
(Code to be updated when it is communicated by AT4W).
Korea
MSIP-CRI-ABC-SUV1
(ABC to replace by Swatch company ID when communicated by AT4)
26
(Meaning that, as this radio equipment has the possibility of radio interference, this
equipment cannot be used for any services related to human life safety)
(To translate in korean with correct information – need a corean translator)
Mexico
(User Manual in Spanish – open point : Do we need the NOM or NYCE logo ?)
La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo
o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su
operación no deseada.
a) Leer el manual antes de instalar u operar
b) Name, address and contact telephone of the importer or Mexican manufacturer
c) Brand Swatch – SUV1 model name Brand
d) Any warnings applicable to the installation and operation
of the product and needed to protect the safety and health of the users.
e) Clear instructions about the installation and operation of the equipment
f) Electrical specications: 3V, Bluetooth 2.4 GHz frequency
This device complies with the Federal law for Protection of the Consumers (Ley Federal
de Proteccion del Consumidor.
a) Name and address of the importer or Mexican manufacturer responsible for the product.
b) Brand name and model name of the product
c) Name and address of the places where the warranty can be served.
d) Name and address of the places where to acquire spare parts, consumables and
accessories.
e) Warranty period (not less than three months for electrical and electronic
products and one year for electrical appliances)
f) Items covered by the warranty and its possible limitations or exceptions
g) Warranty procedure
27
Singapore
(Add dealer’s license No in rectangle).
South Africa
(Add type approval communicated by AT4).
United Arab Emirates
(To update with registration and dealer number communicated by AT4).
Taiwan
(Registration manual : English
Launch manual : in Chinese).
(To update with XXYyZZ data).
Made by ETA
Version 1.4
Gautier Rebetez
Loading...
