Swann T855 User Manual

T855

Day & Night Security Camera

For use with Swann 4500 DVR

EN

INSTRUCTION MANUAL

MT855_091014E | © Swann 2014

Before you begin

Introduction

Congratulations on your purchase of this T850 Day & Night Securit y Camera from
Swann. This camera can operate in almost all lighting conditions, from bright
daylight (provided it’s not pointed straight toward the sun) to pitch darkness.

The camer a is very sensitive to light and therefore can make use of even the smallest
amount of light to provide an image of what it sees. In low light, this comes through
as a black and white image.

In complete or near-total darkness, the camera uses built-in infrared LEDs to
illuminate the area in front of it. This light is invisible to the human eye, although you
might notice a faint red glow coming from the front of the camera - this is normal.

In day or well-lit environments, the IR Cut Filter feature of the camera activates to
filter out wavelengths of light the camera does not need in order to provide a clear
colour image.

Important note - All jurisdictions have specific laws and regulations relating to

the use of cameras. Before using any camera for any purpose, it is the buyer’s
responsibility to be aware of all applicable laws and regulations that prohibit or
limit the use of cameras and to comply with the applicable laws and regulations.

Warning - Modifications not approved by the party responsible for compliance

could void user’s authority to operate the equipment.

Important safety instructions

• Make sure product is fixed correctly and stable if fastened in place.

• Do not operate if wires and terminals are exposed.

2

Choosing a location for the Camera

The camera is very flexible, and can be installed practically anywhere. Some of the
things you’ll have to consider when choosing a location are -

• What you want to monitor and where you’ll get the best view of it.

• How you’re going to connect the camera to your monitoring system; remember
that cables and connections should be kept out of the weather.

• How to keep the camera out of harm’s way.

Things to consider when placing your camera -

• Place your camera as close to the area of interest as practicable. The best
position is from about 4m (13ft) above looking slightly down, keeping in mind the
details you are looking for such as faces and vehicle number plates.

• Although the sky looks nice when you look at the live view from your camera, it
is an unlikely direction for an offender to approach, make sure your camera has
minimal sky in it as the light in daylight can make the foreground of the image
darker.

• Think about the most likely way a potential offender may approach your home,
use your cameras to give you the best coverage of these areas.

Weather & Tampering

• The camera’s casing is resistant to water, different weather conditions and
tampering. It would take an overwhelming event of this kind to damage the
housing of the camera. However, the cable and connector are vulnerable and
require protection.

• Even though the camera is weather and water-resistant, prolonged exposure
to adverse weather conditions (direct sunlight or excessive moisture) may
eventually damage the internal components of the camera and adversely
affect its performance. Install the camera in a shady spot!

Positioning the Cables

• When running your cable, try to avoid bending it at sharp angles.

• Don’t put your cable near live electrical wiring. AC electricity generates radio
“noise” which can interfere with the signal from your camera.
