English
PRO-760
M760CAM190312E
1
About the Camera
Congratulations on your purchase of this PRO-760 from Swann! You’ve chosen well: we think this
is one of the finest CCTV video cameras available. The PRO-760 is great for monitoring a wide open
space whilst maintaining a high level of detail, even at night - it can see up to 30m/100ft in the dark.
Placement Guide
The PRO-760 has a 3.6mm wide-angle lens built-in which allows it to see almost 80 degrees
horizontally. What does this mean for you when placing it?
• You will be able to see a really wide area. If it’s mounted high up
in a square corner, you’ll probably be able to see along both walls.
You’ll be able to monitor a large area with only one camera.
• Things may look further away than they really are. Anything
further than a few meters (ten feet or so) from the camera may
appear to be too small for the level of detail you require.
• Vertical and horizontal lines might appear curved when they near
the edge of the camera’s view. This is normal, and it’s the side
effect of cramming so much viewing area onto one screen.
The PRO-760 is great for monitoring rooms or areas as wide as, or wider than, they are long. For really
wide areas, you may need a second camera.
It’s best mounted high-up in a corner looking down into the room, so that it can look over intervening
obstacles. Also, the higher the camera is mounted, the harder it’ll be for an intruder to access the
camera or interfere with it.
Installing the Camera
The camera mounts onto a flat, vertical surface using screws. The surface must have sufficient strength
to hold the camera. Materials such as hardwood, brick or masonry are good options, and we’ve included
all the gear you’ll need to mount it there (except the tools - sorry, you’ll still need your own drill). You
can mount the camera onto a metal surface, but you’ll need to supply your own mounting hardware.
To mount the camera:
• Using the holes on the camera stand as a guide, mark the locations on your wall to drill. Make
sure the wall is thick and strong enough that you won’t drill through it.
• If the wall is masonry, brickwork or similar, use the provided wall plugs. If the wall is made of
wood, then the camera can be screwed directly onto the wall.
• Ensure that the cable is protected from the weather. The camera is weatherproof, but the cable
(particularly the power and video-out plugs) is not.
• Once the camera has been mounted, ensure that it is securely fixed in place. The camera is vandal
resistant, but that won’t help if an intruder can remove the whole camera!
Troubleshooting
Problem: At night, all I see is white.
Solution: The camera is most likely looking through a window. At night, the infrared light the camera
uses to see in the dark can ‘bounce back’ off a reflective surface (such as glass, water, spider webs,
some ceramics and so on) and effectively blind the camera. If you want to see outside, mount the
camera outside - we made it weatherproof for a reason!
Problem: I see only a blank screen where my image should be.
Solution: Check the wiring to the camera, and ensure the camera is being supplied power from
the included power adapter. Try using a different video lead, or connecting the camera to a different
television or monitor. Be sure there are no devices interrupting your signal, such as a DVR or VCR that
isn’t outputting the signal correctly.
Problem: I can’t see anything at night.
Solution: The maximum range of the night vision is just that, the maximum range. If there’s nothing
in this range, you won’t see anything. Also, some dark objects (like the proverbial black cat) may not
reflect enough light to be seen except as a silhouette if the background is brighter. Some objects which
can easily be seen in visible light don’t reflect much infrared light.
16.8m
55ft
80°
10m
33ft
222
Connection Guide and Specifications
The green plug is used to connect the OSD (on-screen display)
controller. This is an advanced feature, and recommended only
for experienced users. To access a comprehensive guide for the
advanced features of this camera, log onto our website at:
www.swann.com/osdpro
Connect the extension cables
DC socket to the DC plug on
3
the power adapter
4
Connect the camera’s DC
and BNC socket cable to the
1
extension cable’s DC and BNC plugs
2A. Connecting Directly to TV 2B. Connecting to Your Existing DVR
Connect a BNC to RCA
adapter and connect to video
2
input on your TV or VCR
INPUT
Connect the BNC extension
cable to an open channel on
2
the back of the DVR
Plug in the camera
power adapter into
a wall socket
Tips & Tricks
• Try to aim the camera at an area which is evenly lit. Objects or people in shadows near brightly lit objects are
very hard to see. It’s better to have the camera in the shade looking into the light than vice-versa.
• When running your cable, try to avoid bending it at sharp angles.
• Don’t put your cable near live electrical wiring. AC electricity generates radio “noise” which can
interfere with the signal from your camera.
Technical Specifications
Video
Image Sensor 1/3” Sony ‘Effio’ CCD
Video Quality 700 TV Lines
Effective Pixels NTSC: 976 x 494
PAL: 976 x 582
Min. Illumination 0 Lux (IR on)
Night Vision
Range Up to 30m (100ft)
IR Cut Filter No
Number of IR LEDs 24
Infrared Wavelength 850nm
IR LED Life (Average) 10, 000 hours
White Balance Automatic
Electronic Shutter NTSC: 1/60 ~ 1/100 000
PAL: 1/50 ~ 1/100 000
Gain Control Automatic
Backlight Comp. Yes
Wide Dynamic Range Yes
Lens 3.6mm
Viewing Angle Avg: 75° (H: 80°, V: 70°)
General
Operating Power DC 12V @ 300mA
Operating Temp. -20°C ~ 45°C (-4°F ~ 113°F)
Casing Aluminium
Dimensions 165mm x 115mm x 67mm
(6.5” x 4.5” x 3.15”)
Weight 465g / 17.5oz (approx)
3
Helpdesk / Technical Support Details
USA toll free
1-800-627-2799
(Su, 2pm-10pm US PT)
(M-Th, 6am-10pm US PT)
(F 6am-2pm US PT)
USA Exchange & Repairs
1-800-627-2799 (Option 1)
(M-F, 9am-5pm US PT)
See http://www.worldtimeserver.com for information on time zones and the current time in Melbourne,
Australia compared to your local time.
Swann Technical Support
All Countries E-mail: tech@swann.com
Telephone Helpdesk
AUSTRALIA toll free
1300 138 324
(M 9am-5pm AUS ET)
(Tu-F 1am-5pm AUS ET)
(Sa 1am-9am AUS ET)
NEW ZEALAND toll free
0800 479 266
UK
0203 027 0979
Warranty Information
Swann Communications USA Inc.
12636 Clark Street
Santa Fe Springs CA 90670
USA
Swann Communications warrants this product against defects in workmanship and material for a period
of one (1) year from its original purchase date. You must present your receipt as proof of date of purchase
for warranty validation. Any unit which proves defective during the stated period will be repaired without
charge for parts or labor or replaced at the sole discretion of Swann. The end user is responsible for all
freight charges incurred to send the product to Swann’s repair centers. The end user is responsible for all
shipping costs incurred when shipping from and to any country other than the country of origin.
The warranty does not cover any incidental, accidental or consequential damages arising from the use of
or the inability to use this product. Any costs associated with the tting or removal of this product by a
tradesman or other person or any other costs associated with its use are the responsibility of the end user.
This warranty applies to the original purchaser of the product only and is not transferable to any third
party. Unauthorized end user or third party modications to any component or evidence of misuse or
abuse of the device will render all warranties void.
By law some countries do not allow limitations on certain exclusions in this warranty. Where applicable by
local laws, regulations and legal rights will take precedence.
For Australia: Our goods come with guarantees which cannot be excluded under Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to major failure.
USA
Swann Communications
Unit 13, 331 Ingles Street,
Port Melbourne Vic 3207
Australia
United Kingdom
Swann Communications LTD.
Stag Gates House
63/64 The Avenue
SO171XS
United Kingdom
This equipment has been tested and found to comply with the limits for Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio or television reception, which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and the receiver
Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected
Consult the dealer or an experienced radio/TV technician for help
WARNING: Modications not approved by the party responsible for compliance could void user’s authority
to operate the equipment.
444
FCC Verication
© Swann Communications 2012
