Swann PRO-750, PRO-751, PRO-746 User Manual

PRO-750 Dome
M750CAM190312E
English
Meijer.com
2
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are de­signed to provide reasonable protection against harmful interference in a residen­tial installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be deter­mined by turning the equipment off and on, the user is encouraged to try to cor­rect the interference by one or more of the following measures:
· Reorient or relocate the receiving antenna
· Increase the separation between the equipment and the receiver
· Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
· Consult the dealer or an experienced radio/TV technician for help
IMPORTANT NOTE: Prohibition against eavesdropping
Except for the operations of law enforcement officers conducted under lawful authority, no person shall use, either directly or indirectly, a device operated pursu­ant to the provisions of this Part for the purpose of overhearing or recording the private conversations of others unless such use is authorized by all of the parties engaging in the conversation.
WARNING: Modifications not approved by the party responsible for compliance could void user’s authority to operate the equipment.
IMPORTANT SAFETY INSTRUCTIONS:
· Make sure product is fixed correctly and stable if fastened in place
· Do not operate if wires and terminals are exposed
FOR BEST RESULTS:
This is a semi-professional 360º PTZ dome camera, conforming to PELCO P/D stand-
ards. To obtain the best image quality, please use a high quality cable, particularly if the cables required length exceeds 100ft/35m. For the highest video quality, use a cable with a solid copper inner conductor and shielded with copper braid.
Before You Begin
Meijer.com
3
Before you Begin 2 Table of Contents 3 Quick Reference 3 Overview 4 Package Contents 4 Layout of the Camera and PTZ Controller 5 Layout of Remote Control 6 Connecting the Camera 8 Mounting the Camera 10 Setting the Command Address 12 Configuring the PTZ Controller 12 Connecting Multiple PTZ Systems 13 Operating the Camera 14 Advanced Operation 16 Additional Functions 17 Troubleshooting Guide 18 Technical Specifications 19 Warranty / Technical Support Rear Cover
PRO-750 4” Pan, Tilt, Zoom Dome
Default PTZ Configuration
Default Command Address: 1 Protocol: Pelco-D Baud Rate: 2400bps
RS485 Polarity:
+A Purple Wire
- B White Wire
Contents
Quick Reference
Meijer.com
4
Congratulations on your purchase of this 360º PTZ Camera Dome! This system is an ideal solution for monitoring a large area – a combination of a high quality CCD image sensor mounted in a contained dome with the option to pan fully 360º. Nothing will be out of sight for long!
Whether you wish to do this using the full complement of manual controls, or program a detailed surveillance program for the camera to run, the PRO-750 gives you all the options you need to simply and effectively monitor a large range of locations without the hassle of multiple cameras.
The PRO-750 features an included fully functional PTZ controller, great low-light performance and a 3x optical zoom – great for getting up close to what you want to see. All this comes mounted in a simple but elegant 4” dome.
If any of these components are missing, contact Swann Technical Support. Contact details are on the back cover of this booklet.
Overview
Package Contents
• PRO-750 pan & tilt 4” Dome Cam­era
• Ceiling Mounting Arm/Bracket
• Wall Mount Arm
• Dome Controller
• Remote Control
• Mounting Screws
• Operating Instructions
• 18m (60ft) Hybrid Video/RS485
Cable
• Spare Camera Cable & Plug Board
• Power Adapter for Camera
• Power Adapter for Controller
Meijer.com
5
1. Wall-Mount Arm
For mounting the PRO-750 Dome to a wall, post or similar vertical surface.
2. Ceiling-mount Bracket
For mounting the PRO-750 Dome to the underside of a ceiling or overhang.
3. Camera Housing
Contains the camera, PTZ unit and associated circuitry and electronic components.
4. Dome Cover
Protects the camera.
4
132
5. LED Display
Displays the current status of the PTZ controller.
6. DC 12V
Connect the supplied power adaptor to this socket.
7. RS485 Port
Insert the RS485 plug into this socket.
8. RS485 Plug
Connect the end of the purple and white control wires into this plug, using the attached screws to secure wires in position. The PURPLE wire is “+”, the WHITE wire is “-”.
8
6
7
Rear View
Front View
5
Layout of the Camera and PTZ Controller
Meijer.com
6
DISP (Display)
Toggles the display on the front of the PTZ Controller, showing the Command Address, Protocol and Baud Rate.
PRESET (HOLD to define)
Changes or accesses preset points.
PATTERN (press and HOLD)
Allows for the programming of lists of preset points for the camera to view in sequence.
DELETE (press and HOLD)
Will remove a Preset Point or Pattern.
RUN
Commands the system to begin executing the programmed pattern.
HOME
Master Preset Point. Whilst not in Cruise Mode (see page 15) the camera will automatically return to this position whilst idle.
A & B
Master Preset Points. They are defined in the same way as other Preset Points (see page 14). They operate as shortcut buttons thereafter.
0 – 9
The number buttons. Used to enter a numerical value into the PTZ controller.
C
Clear. Removes the last digit entered into the controller, somewhat like the ‘backspace’ key on your computer.
-/--
Allows for the entry of more than one digit at a time. “-” represents a single digit, whilst “--” indicates space to enter two digits.
S1 ~ S4
Shortcut to the SPEED setting for the camera. 1 is the slowest shortcut speed, 4 is the highest.
P1 ~ P8
Shortcuts to PRESET POSITIONS. Pressing the button will send the camera directly to the corresponding PRESET POSITION.
5
Layout of Remote Control
Meijer.com
