Swan NWAS1020 Specifications

SSUS Swanstone Large Utility Sink
Manufactured from Swanstone 
(See page 2 for detailed information.)
FEATURES
• Highest resistance of impact from heavy objects with no surface
25"
12-1/4"
B
A
22"
25" W x 22" D
(635 mm x 559 mm)
A 21-1/2", B 16", C 13-9/16"
Capacity: 17-1/2 gallons
coating to chip or crack.
• Will not mold or mildew.
• Available in solid and aggregate colors.
• Flat deck—allows for a variety of faucet applications and includes five drill points.
• Easily installs as a drop-in or undermount for an upgraded laundry room look.
• Drain included.
16"
2"
Diameter
SSUS Swanstone Large Utility Sink     Nominal   Ship  Ship  Carton 
Model  Part  Dimensions  Wt. Lb.  FedEx  Dims. In.  Cu. Ft.
SSUS SSUS1000 25" W x 22" D 18 FedEx 26 x 23 x 16 5.43 (635 mm x 559 mm)
Fits opening of 23-5/8" W x 20-5/8" D (600 mm x 524 mm)
WARRANTY Limited Lifetime – Residential Limited 10-year – Commercial
C
8-1/2"
COLORS
Solid Colors:
• White (010)
• Bisque (018)
Aggregate Colors:
• Gray Granite (042)
• Midnight Sparkle (101)
3-3/4"
13-9/16"
Includes: One utility sink with matching drain, hardware for countertop attachment and installation instructions.
Packaging: Individual cartons. Note: Five starter holes are countersunk on the underside of the utility sink to accommodate a single, 4-inch or 8-inch faucet.
STANDARDS AND RATINGS
American National Standard Institute—ANSI Z124.6
International Association of Plumbing and Mechanical Officials (IAPMO)—Listed
CSA Test Standard B45.5
Uniform Plumbing Code (UPC)
SUPPORT DOCUMENTS
Installation instructions available at swanstone.com.
095-03-16
Swan • St. Louis, MO 63101 • (800)325-7008 • swanstone.com • help@swanstone.com122 |
MAINTENANCE AND  CLEANING INFORMATION
Clean your Swanstone sink regularly with common household liquid cleaners and a sponge or soft cloth. Use of a nylon scouring pad or Mr. Clean® Magic Eraser® is also recommended. For rust or other mineral stains, rust-removing products are acceptable. To protect finish, fiberglass wax or automotive past can be applied. Do not abrasive cleaners 
or metal scouring pads. 
