s&w pistol User Guide

Owner’s Manual

Metal Frame Centerfire Pistols

Read the instructions and

warnings in this manual

CAREFULLY BEFORE using

this firearm.

2100 Roosevelt Avenue • Springfield, MA 01104

1-800-331-0852 • Fax: [phone]

www.smith-wesson.com

Single/Double Action Modes

Double Action Only Modes

READ THESE INSTRUCTIONS

AND W ARNINGS CAREFULLY. BE

SURE Y OU UNDERSTAND THESE

INSTRUCTIONS AND WARNINGS

BEFORE USING THIS FIREARM.

This SAFETY, INSTRUCTION

and PARTS MANUAL should
always accompany this firearm
and be transferred with it upon

change of ownership or presented

to another person. A copy of the

SAFETY, INSTRUCTION, & PARTS

MANUAL is available FREE upon

request from:

SMITH & WESSON

CUSTOMER SUPPORT CENTER

2100 ROOSEVELT AVENUE

SPRINGFIELD, MA 01104

TEL.: [phone]

E-mail: [e-mail]

INDEX

SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

BASIC FIREARMS SAFETY RULES . . . . . . . . . . . . . . . .5-6

MODEL NUMBER IDENTIFICATION . . . . . . . . . . . . . . . . .7

SAFE STORAGE AND TRANSPORTATION . . . . . . . . . . .8-9

NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . .9-10

PREPARATION FOR FIRING . . . . . . . . . . . . . . . . . .10-11

AMMUNITION . . . . . . . . . . . . . . . . . . . . . . . . . . .11-12

INSPECTING YOUR PISTOL . . . . . . . . . . . . . . . . . .13-14

LOADING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15-17

FIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

MANUAL COCKING . . . . . . . . . . . . . . . . . . . . . . . . . .19

DECOCKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

CLEARING MISFIRES . . . . . . . . . . . . . . . . . . . . . . . .19

PRODUCT WARNING . . . . . . . . . . . . . . . . . . . . . . . . .20

UNLOADING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

SIGHT ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . 20-21

FIELD STRIPPING DISASSEMBLY . . . . . . . . . . . . . .21-22

FIELD STRIPPING REASSEMBLY . . . . . . . . . . . . . . .22-23

MAGAZINE DISASSEMBLY . . . . . . . . . . . . . . . . . . . . .23

MAGAZINE REASSEMBLY . . . . . . . . . . . . . . . . . . . . . .24

CLEANING & MAINTENANCE . . . . . . . . . . . . . . . . . . . .24

SERVICE/SHIPPING/PARTS . . . . . . . . . . . . . . . . . .25-26

WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

EXTENDED SERVICE POLICY . . . . . . . . . . . . . . . . . . . .28

COMPONENT PARTS . . . . . . . . . . . . . . . . . . . . . . .29-30

WARNINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

3

SAFETY IS YOUR

NUMBER ONE

RESPONSIBILITY!!!!

W

ARNING: YOU MUST FOLLOW
ALL OF THESE SAFETY RULES TO
ENSURE THE SAFE USE OF YOUR
FIREARM

• Safe gun handling is YOUR personal

responsibility at all times. Firearms are dangerous

and can cause serious injury and death if they are
misused or used inappropriately. Safety must be the
prime consideration of anyone who owns or handles
firearms.

•You are responsible for the firearm at all times.

In owning a firearm, you must undertake full-time
responsibility for your firearm’s safety and security.
You must protect yourself and all others against
injury or death from misuse of the firearm.

• Saf

e storage is your responsibility.

In particular,
you must secure firearms safely from children and
unauthorized users. A lock has been provided for
your use with this firearm. A lock is not a substitute
for safe and secure storage as defined in the “Safe
Storage and Transpor tation” section of this manual.

• Accidents are the result of violating the rules of
safe gun handling and common sense.

• For your safety and the safety of others, never
rel

y on mechanical features alone.

Only your
safe gun-handling habits will ensure the safe use of
your firearm. This is your responsibility.

•Ne

ver keep ammunition in the same location as

the handgun. Store in a separate and secure

place.

• READ

and UNDERSTAND these instructions

before using y

our firearm.

4

SAFETY

At home, in the field, at the range, or anywhere, the first
concern of every firearm owner should be safety. Apply the fol­lowing safety rules in every situation, with any kind of firear m.

• BEFORE HANDLING ANY FIREARM,
UNDERSTAND ITS OPERA

TION.

Not all firearms
are the same. Familiarize yourself with the
mechanical features of any firearm you intend to
use. If you feel uncertain about any operational aspects
of your handgun, please contact Smith & Wesson
at 1-800-331-0852 before proceeding with its operation.

•AL

WAYS SAFELY STORE AND SECURE YOUR

FIREARM. Safe and secure storage of your firearm

is one of the most important responsibilities of
firearms ownership. It is a full-time responsibility.
You must always secure your firearm and
ammunition separately so that they are not
accessible to children or other unauthorized persons.
(See Safe Storage Instructions)

•AL

WAYS

TREAT EVERY FIREARM AS IF IT

WERE

LO

ADED AND WOULD FIRE IF

THE TRIGGER

IS PULLED. Do not take anyone’s word that the

firearm is unloaded – always check for yourself.
Never pass your firearm to another person until the
cylinder or action is open and you visually check that it
is unloaded. Keep your firearm unloaded and safely stored
when not in use.

•AL

WAYS KEEP YOUR FIREARM POINTED IN A

SAFE DIRECTION. Never point a firearm at anyone

or anything you do not intend to shoot whether or not
it is loaded.This is particularly important when
loading, unloading, or field stripping the gun. ALWAYS
control the direction of the firearm.

• NEVER PLACE YOUR FINGER INSIDE THE
TRIGGER GUARD UNLESS YOU INTEND TO FIRE.

Your firearm cannot fire unless the trigger is pulled.
Ensure that other objects do not touch the trigger.

•AL

WAYS BE SURE OF YOUR TARGET AND WHAT

IS BEYOND IT. Always be sure of where the bullet

will strike and shoot only where there is a safe
backstop free of obstructions, water or other
surfaces which can cause ricochets. Do not fire into
the sky.

BASIC FIREARM

SAFETY RULES

5

WARNING!

THE F AILURE TO FOLLOW THESE BASIC
FIREARM SAFETY RULES MAY RESULT IN AN
UNINTENDED DISCHARGE WHICH COULD CAUSE
SERIOUS PERSONAL INJURY OR DEATH.

ADDITIONAL IMPORTANT SAFETY RULES

• Never carry or store a firearm with the hammer or striker in

the cocked position.

• Do not allow a firearm to be used by individuals who have

not read these basic firearms safety rules and do not under­stand its safe operation and the rules of safe gun-handling.

• Be sure all accessor ies, such as holsters and grips,

are compatible with the firearm and that the
accessories do not interfere with safe operation.

• Use the correct ammunition for your particular

firearm as indicated by the marking on the barrel.
Never use non-standard, reloaded, or “handloaded”
ammunition which has not been subjected to internal
ballistic pressure testing.

• Discharging firear ms in poor ly ventilated areas,

cleaning firearms, or handling ammunition may result
in exposure to lead and other substances known to
cause birth defects, reproductive harm, and other
serious physical injury. Review the warnings and
labels for all ammunition and cleaning products
carefully. Have adequate ventilation at all times.
Wash hands thoroughly after exposure.

• Never use alcohol or drugs before or while shooting.

Do not use your firearm if you are on any medication
which impairs, even slightly, your mental or physical
ability.

• Wear eye and hearing protection appropriate for

firearm use every time you discharge your firearm.
Make sure others in the vicinity of where you will be
shooting do so as well.

• Do not allow any alteration or replacement of parts in

your Smith & Wesson firearm unless performed by a
qualified gunsmith using genuine Smith & Wesson
parts. If you do otherwise, improper functioning of
your firearm may occur and serious injury may result.

• Never cross obstacles such as fences or streams

with a loaded firearm.

• Firear m safety training is available. Contact your dealer,

Law Enforcement Agency, local sportsman’s club, etc.for
availability.

• Appropr iate use for your firearm means using your firearm

for legal purposes. For example - target shooting and
lawful resistance of deadly criminal force.

• These are basic firear ms safety rules. There are other

common sense safety rules that should be followed at all
times under the circumstances then presented.

SAFE USE OF A FIREARM IS YOUR PERSONAL
RESPONSIBILITY AND THE FAILURE TO FOLLOW ALL
OF THESE BASIC SAFETY RULES MAY RESULT IN
SEVERE PERSONAL INJURY OR DEATH.

BASIC FIREARM SAFETY RULES CONT’D.

6

7

WARNING:

SAFE AND SECURE STORAGE OF
YOUR FIREARM IS ONE OF THE MOST
IMPORTANT RULES OF FIREARM SAFETY.
YOUR F AILURE T O FOLLOW THESE RULES
MAY RESULT IN SERIOUS INJURY OR DEATH.

• You must always secure your firearm and ammunition

separately so that they are not accessible to children
or other unauthorized persons.

• Safe and secure storage and transportation of your

firearm are your responsibility. It is a full-time
responsibility.

•AL

WAYS STORE YOUR FIREARM UNLOADED.

Your firearm and ammunition should be stored separately in
places and in a manner inaccessible to children and
unauthorized persons.

•SMITH &

WESSON HAS PROVIDED A LOCK FOR

USE WITH YOUR FIREARM. There are also a variety of

other locks and safe storage containers available in the
marketplace which may be appropriate for your particular
needs. Consult your local gunshop, hardware store, or
local police department for guidance on the variety of other
safe storage devices or practices which may be appropriate
for your particular needs. By purchasing this firearm you
have taken on the responsibility of safely securing the
firearm at all times and preventing its unauthorized use. It
is your personal responsibility to select and use whatever
devices or practices that will enable you to safely secure
your firearm at all times.

DO NOT USE A LOCK ON A LOADED HANDGUN

AND NEVER LOAD A LOCKED HANDGUN!!

Onl

y you can determine what devices or practices are

appropriate for the safe storage of your firearm and

your ammunition.

• NEVER ASSUME THAT A “HIDING” PLACE IS A

SECURE STORAGE METHOD. Others may be aware of

your storage location or come upon it by chance. It is your
personal responsibility to use common sense when storing
and securing your firearm and ammunition and to always
make sure that it is not accessible to children or other
unauthorized persons.

• FOLLO

W THE LAW!! You must be familiar with all local,

state, and federal laws regarding the safe storage and
transportation of your firearm. Failure to know and follow
the law may result in unauthorized access or use of your
firearm by another. Obey all laws relating to the storage
and transportation of firearms.

• NEVER

TRANSPORT A LOADED FIREARM.

When transporting your firearm, be sure it is unloaded
and that the cylinder or action is open.

SAFE STORAGE &

TRANSPORTATION

8

• Your local police department or gunshop will furnish you

with available information on storing and/or transporting a
firearm legally.

•Y

OUR FIREARM IS YOUR RESPONSIBILITY.

Protect your firearm from theft or misuse by untrained or
unqualified individuals.

MAINTENANCE BEFORE ST

ORAGE

When storing, do not encase your firearm in anything that will attract or
hold moisture, for example, leather or heavy cloth. Also, do not store
guns with a plug inserted in the barrel for this can be a contributing
factor to moisture accumulation. If your firearm is to be stored for an
extended period, the bore, chambers and internal working mechanism
should be oiled with acid-free lubricating oil or preservative, and the
external working mechanisms, frame, cylinder and barrel should be
coated with an anti-rust oil. Before using your firearm again, be sure to
clean it. Every time you clean your firearm, check it for signs of wear.
If wear is noted, do not use the firearm. Retur n it to Smith & Wesson
for service or have it checked by a qualified gunsmith.

MAINTENANCE BEFORE USE

Before using your firearm, it should be cleaned. (See Cleaning
Instructions) Your firearm has been treated with either a preser vative
or oil to protect it against corrosion. Before using it, all excess oil
should be wiped from the bore, chambers (charge holes), and exposed
areas using a clean swab or patch. A light coat of high quality gun oil
should be applied to the outside surfaces and mechanism. Care
should be taken not to oil the mechanism to the degree that dust and
lint may be trapped by the oil.

SAFE STORAGE & TRANSPORTATION CONT’D.

Smith & Wesson handguns are reliable and safe to use when
the basic firearm safety rules are followed. There are a
number of internal safety mechanisms within the
lockwork of the handgun which ensure that the firearm will
not discharge unless the trigger of the handgun is pulled.
That is one reason why it is important to never modify or
alter your firearm. Before you use your handgun, you
should be fully familiar with its operation.

Here is a list of basic firearms terminology.

AMMUNITION - CENTERFIRE

- Ammunition which
contains the primer in the center of the base of the case. Among
the most common centerfire handgun cartridges are the .32,
.38 Special, .380, 9mm, .357 Magnum®, .40 S&W®, .45 ACP
and the .44 Magnum®.

AMMUNITION - RIMFIRE

- Ammunition which contains the
primer material in the rim. Among the most common rimfire
handgun cartridges are the .22 Long, .22 Shor t, .22 LR, .22CB,
.22BB, and .22 Magnum.

CALIBER

- The diameter of a bullet, designated in
hundredths or thousandths of an inch (.357) or in
millimeters (9mm).

DECOCK

- The process by which the hammer or striker is safely

lowered.

NOMENCLATURE

9

DOUBLE ACTION -A firing action where the hammer or striker

is drawn back, released, and the gun fired by a single pull of the
trigger.

DOUBLE ACTION ONLY

-A firearm designed so that it can only

be fired in double action.

PIST

OL -A handgun that contains the cartr idges in a magazine.

REVOLVER -A handgun that contains the cartridges in a

cylinder that revolves at the rear of the barrel.

SINGLE A

CTION -A firing action where the hammer or striker is

released from the cocked position by pulling the trigger.
The operation of your handgun will be explained in greater detail

in the pages that follow, as well as a greater description of key
component parts.

NOMENCLATURE CONT’D.

PREPARATION FOR

FIRING

AL

WAYS WEAR EYE AND EAR PROTECTION WHICH IS

SPECIFIED FOR FIREARM USE.

• Failure to wear adequate and proper ear protection on

even one occasion can permanently damage your hearing.
Make sure others who are nearby are wearing ear
protection as well.

• Always wear safety glasses, whether indoors or out.

Safety glasses protect your eyes from the firing flash and
particles associated with the discharge of ammunition.

• DO NO

T SHOOT A

T HARD SURFACES, WATER OR UP

INTO THE SKY. Always select a place to shoot that has a

safe backstop, is free from obstructions and water surfaces
which cause ricochets.

• Alw

ays be aware of other people so that persons cannot

accidentally walk into the line of fire.

• Position the shooter and all others so that they are not

within an area where they may be struck by particle-spitting
from a revolver or by ejected cases from other types of
firearms.

• Keep fingers and other parts of your body away from the

muzzle and away from the gap between the revolver barrel
and cylinder, and away from the pistol slide and ejection
port.

• Be aler t and always follow the safety instruction of the

range officer.

10

• Be sure that all cylinders and actions of firearms are

open, that chambers are clear of cartridges,
magazines are removed, and that firearms are
pointing in a safe direction before anyone is allowed
in front of the firing position.

• Be aler t at all times. Never shoot if you are tired,

cold or impaired in any way.

• Treat your firearm as if it were loaded at all times.

AMMUNITION

PREPARATION FOR FIRING CONT’D.

A. GENERAL PRINCIPLES

• A firearm and ammunition are a system and must work

together. Their performance is closely related. There are
different types of ammunition for different types of firearms.
Your firearm has been designed for ammunition of a specific
type and a specific caliber. It is important to select the
proper ammunition for your firearm.

!! W

ARNING !!

• Never use ammunition not specifically designated for

use in your firearm. Failure to use the correct type or
caliber of ammunition may cause the firearm to jam, fail
to fire or even generate excessive pressure which can
damage or even rupture your firearm, causing personal
injury or property damage.

• You are responsible for selecting ammunition that meets

industry standards and is appropriate in type and caliber for
this firearm.

• Locate the caliber designation printed on the handgun.

This information indicates the ammunition caliber that
should be used in this firearm. (See figure #1)

B.

HANDLOADED OR RELOADED AMMUNITION

!! WARNING !!

• Never use non-standard, reloaded or “handloaded”

ammunition which has not been subjected to internal
ballistic pressure testing. Reloaded or handloaded

ammunition, may have many manufacturing and quality
variables (such as the type and amount of gun powder).

• Any ammunition that is improperly manufactured,

even in the slightest degree,
may fail to fire or may
generate excessive
internal pressures which
can damage or even
rupture the firearm,
causing personal injury to
the shooter or those in the
immediate vicinity.

FIGURE 1

11

• Use only commercially manufactured ammunition with

internal ballistic pressures which are in strict accordance
with the specifications of the Sporting Arms and
Ammunition Manufacturers’Institute (SAAMI).

• Be certain all ammunition you use complies with the

SAAMI specifications. If you are uncertain, contact your
ammunition supplier for verification.

C.

MISFIRES

• If your firearm fails to fire when the trigger is pulled

(misfires), keep the firearm pointed in a safe direction,
remove your finger from the trigger, and wait 10 seconds.
Only after you have completed all of the above steps,
remove the magazine or open the cylinder and remove the
cartridge from the chamber and dispose of it properly.
Keep your firearm pointed in a safe direction at all times.

• If you have heard an unusual sound or felt an unusual recoil

on firing, stop firing, wait 10 seconds, unload the firearm,
and examine the barrel bore for obstructions.

• Make sure your barrel is clear and free of obstructions.

If you see an obstruction, return your firearm to
Smith & Wesson or take it to a qualified gunsmith. Never
fire a firearm with an obstructed barrel.

D

.

AMMUNITION SPECIFICS

• Use only ammunition specifically recommended by

Smith & Wesson for your firearm.

• Never mix ammunition.

• Never use a car tridge not specifically designated for use in

your firearm. Pressure from the wrong type of ammunition
may be beyond the capability of your firearm to withstand
and may damage or even rupture your firearm.

• Whenever rimless pistol car tr idges are used in the cylinder

of a Smith & Wesson revolver, (except M547) full or
half-moon clips MUST be used to both position and extract
such cartridges. Failure to use ammunition clips with
rimless cartridges may result in malfunction of the revolver.

• Additional ammunition calibers can be fired from the

following list of select calibers.

Caliber on Barrel

Can also Fire
.45 Colt .45 Schofield, .45 S&W
.45 S&W .45 Schofield
.44 Magnum .44 Special
.357 Magnum .38 Special, .38 Special +P
.22LR .22L, .22 Short, .22CB, .22BB

(in revolvers only)
10mm .40 S&W (in revolvers only)

• In some cases, a round of ammunition not specified on your

handgun may fit into the chamber or cylinder. Firing
ammunition not specified on your handgun may cause it
to rupture and cause serious injury or death.

AMMUNITION CONT’D.

12

AMMUNITION CONT’D.

E. AMMUNITION WARNINGS

• “Plus-P” (+P) ammunition generates pressures in excess of

the pressures associated with standard ammunition. Such
pressures may affect the wear characteristics or exceed the
margin of safety built into some revolvers and could
therefore be DANGEROUS.

• “Plus-P” ammunition should not be used in medium

(K frame) revolvers manufactured prior to 1958. Such
pre-1958 medium (K-frame) revolvers can be identified by
the absence of a model number stamped inside the yoke
cut of the frame. (i.e., the area of the frame exposed when
the cylinder is in the open position, see Figure 2).

• “Plus-P-Plus (+P+) marking on the ammunition merely

designates that it exceeds established industry standards,
but the designation does not represent defined pressure
limits and therefore such ammunition may vary significantly
as to the pressures generated.

• “Plus-P-Plus (+P+) ammunition is not recommended for use

in Smith & Wesson firearms.

• In the Model 940 revolver, some brands of 9mm parabellum

ammunition may cause difficulty in extracting spent
cartridge cases from the cylinder. If this situation occurs,
thoroughly clean the cylinder charge holes with solvent. If
this condition persists, we recommend changing to another
brand of 9mm parabellum ammunition.

• Smith & Wesson has found wide variations in primer

sensitivity between some brands and types of .22LR
ammunition. Smith & Wesson recommends that before you
put your .22LR handgun into regular use, that you fire
several boxes of your choice of ammunition through it to
determine reliability of ignition. If “failure to fire”occurs, try
different types of brands of .22LR ammunition until a
reliable loading is found.

13

MODEL NUMBER
IDENTIFICATION

The serial number and the model number appear here on your
pistol.

FIGURE 1

FIGURE 2

Equipment Rail

Trigger Guard

Trigger

Grip

Magazine

Magazine

Release

Front Sight

Rear Sight

Hammer

Frame

Slide

Slide Stop

Notch

Decocking

Safety Lever

Ejection

Port

Slide Stop

Extractor

Slide

Stop Pin

Barrel

Front Sight

Barrel

Bushing

Recoil Spring

Guide Rod

14

INSPECTING YOUR

PISTOL

When you inspect your pistol, you should first check for yourself
to insure that it is unloaded.To do this, grasp the pistol with your
finger off the trigger and outside the trigger guard, point the
muzzle in a safe direction, rotate the decocking lever fully down
into the "safe" position as shown in Figure 4, depress the
magazine release, and remove the magazine.

With the muzzle still pointing in a safe direction, grasp the
serrated sides of the slide from the rear with the thumb and
fingers as shown in Figure 5, and briskly draw the slide fully
rearward in order to extract any cartridge from the barrel
chamber and clear it from the pistol. Do not obstr uct the ejection
port because doing so can interfere with ejection of a cartridge
and thereby creates the risk of exploding an unchambered
cartridge and possible injury.In order to lock the slide in the
open position, allow the slide to move slightly forward from the
rearmost position while press­ing upward on the slide stop.
You are now able to safely
check the barrel chamber and
bore visually for any
obstructions.You must follow
this procedure every time your
firearm is inspected, cleaned,
handed to another person, transported or stored. Unload the
magazine by holding it with the bullet end of the cartridge
pointing away from you and others and pressing each car tridge
forward and out of the magazine.

Familiarize yourself with the decocking lever on your autoloading
pistol.When the decocking lever is fully up (parallel to the top of
the slide) as shown in figure 6, it is in the "fire" position; when
the decocking lever is fully down, as shown in Figure 4, it is in
the "safe" position. Notice how the decocking lever looks and
feels in each of the two positions of its extreme travel - fully up
for "fire" and fully down for "safe".Your pistol may have a red dot
which is totally visible when the decocking lever is in the "fire"
position; however, do not rely on your inability to see a red dot
as the only indication that the decocking safety lever is engaged.

Please be advised that other model or brand pistols
may have a safety or decocking lever that operates
differently

.

Tr aditional Single and Double Action Pistols

FIGURE 4

FIGURE 5

FIGURE 6

The Smith & Wesson “double action only” pistol does not have a
decocking lever or manual safety.It does not require such a
mechanism because the hammer does not remain in the single
action (or fully-cocked) position when the slide is released after
loading and because the hammer does not remain in the
single action position after each shot.

The hammer of this pistol cannot be manually cocked before
firing.The hammer is manufactured without a single action
notch so that it cannot be placed manually into the single action
position.

With a magazine fully inserted in the pistol and with a cartr idge
in the barrel chamber, this pistol can be fired simply by pulling
the trigger fully to the rear (“double action”).This action of pulling
the trigger moves the hammer rearward and then allows the
hammer to fall forward firing the cartridge.

When you inspect your pistol, you should first check for yourself
to ensure that it is unloaded.To do this, grasp the pistol with
your finger off the trigger and outside the trigger guard and point
the muzzle in a safe direction.Depress the magazine release,
and remove the magazine.With the muzzle still pointing in a
safe direction, grasp the serrated sides of the slide from the rear
with the thumb and fingers as shown in Figure 5, and briskly
draw the slide fully rearward in order to extract any cartr idge
from the barrel chamber and clear it from the pistol. Do not
obstruct the ejection port because doing so can interfere with
ejection of a cartridge and thereby creates the risk of exploding
an unchambered cartridge and possible injury.(Figure 7)
In order to lock the slide in the open position, allow the slide to
move slightly forward from the rearmost position while pressing
upward on the slide stop. You are now able to safely check the
barrel chamber and bore visually for any obstructions.

You must follow this procedure every time your pistol is
inspected, cleaned, handed to another person, transported or
stored. Unload the magazine by holding it with the bullet end
of the cartridge pointing away from you and pressing each
cartridge forward and out of the magazine.

INSPECTING YOUR PISTOL CONT’D.

DOUBLE ACTION ONLY PISTOLS

FIGURE 7

15

DO NOT BLOCK EJECTION PORT!!!

LOADING

TRADITIONAL DA/SA & DOUBLE ACTION ONLY

• Do not load the pistol until you are ready to use it.
Keep your finger outside the trigger guard until you are ready
to fire.

Once the magazine is removed from the pistol and the
trigger is fully released, subsequent cycling of the trigger
will not fire the pistol until the magazine is fully reinserted.
(This may not apply to certain pistols that have been
marked “CAUTION - CAPABLE OF FIRING WITHOUT
MAGAZINE”)

WARNING: Some Smith & Wesson centerfire pistols
are designed to disengage the trigger linkage, and
thereby prevent the trigger from firing the pistol

when the magazine is removed from the pistol. Be certain
to fully release the trigger and remove your finger from
within the trigger guard when the magazine is removed from
the pistol. Failure to fully release the trigger could result in
firing the handgun. After inserting a magazine, always test
to make sure it is locked in place by applying some removal
pressure to the exposed portion of the magazine butt plate.

• Only use Smith & Wesson magazines specifically
manufactured for your par ticular model of pistol. Do not
interchange magazines from one model pistol into another
model pistol.

• Smith & Wesson has provided you with a magazine
designed to operate in your specific model of pistol.While
your magazine may be able to be inserted into another
model pistol, it will only function properly in the specific
model for which it was designed.

•Follow instructions in this manual and any other specific
instructions which may be marked onto, or accompany, a
magazine. Failure to use the particular type of Smith &
Wesson magazine specified for your model and caliber of
pistol may result in a malfunction.

• Load the magazine by pressing a cartridge head (rear of
cartridge) downward on the forward portion of the magazine
follower (or downward on the case of the previously loaded
cartridge) and sliding the car tridge fully under the lips of the
magazine until the cartridge head is against the rear wall of
the magazine. Repeat the procedure for the number of
cartridges you wish to load, up to the magazine capacity.
Do not attempt to load your magazine with more than the
specified number of cartridges because doing so can cause
a feeding failure.

• Inspect your pistol as previously described in the “Inspecting
Your Pistol” section. Hold the pistol in one hand with the
muzzle pointing in a safe direction and with your finger off
the trigger and outside the trigger guard. Insert the loaded
magazine into the magazine well of the pistol until it is locked
in place.

WARNING: Do not use excessive upward force when
inserting a loaded magazine into the pistol. Excessive
upward force could cause the slide to move forward,
chambering a round and making the pistol ready to fire.

•To make sure that the magazine is fully and securely
inserted, apply some removal pressure to the exposed
portion of the magazine butt plate.

• Press down on the slide stop to release the slide and allow it
to carry fully forward. This strips a cartridge from the
magazine and seats it in the chamber of the barrel.

16

LOADING CONT’D.

The pistol can now be fired by pulling the trigger to the
rear.

FOR TRADITIONAL DA/SA

• Rotate the decocking safety lever to the down (safe) position
and leave it in that position.

• If you wish to restore the magazine in your pistol to its full
capacity, depress the magazine release and remove the
magazine from the pistol. Remember that there is a round in
the chamber; therefore, the weapon should be holstered or
safely secured during this process. Load one cartr idge into
the magazine to replace the one which was chambered
when you allowed the slide to carry forward.

• Re-insert the loaded magazine into the magazine well of the
pistol until it is locked in place.To make sure that the
magazine is again fully and securely inserted, apply some
removal pressure to the exposed portion of the magazine
butt plate.

•Your pistol is now fully loaded.The hammer is down and
resting against the decocking safety lever body, the trigger is
forward and the firing mechanism is disengaged.Your pistol
is now in a safe condition to be holstered and carried. Never
holster, carry or store your pistol with the hammer cocked.
Remember to keep your pistol pointed in a safe direction
under all conditions and always keep your finger or any other
object off the trigger and outside the trigger guard until you
have made the commitment to fire the handgun.
Never leave a loaded firearm unattended.

LOADING CONT’D.

CAUTION

NOTE: Certain specially manufactured Law Enforcement
products may have a safety or a safety decocking lever
which will lower the hammer and then automatically return
to the fire position.

FOR DOUBLE ACTION ONLY

• If you wish to restore the magazine in your pistol to its full
capacity, depress the magazine release and remove the
magazine from the pistol. Remember that there is a round in
the chamber; therefore, the weapon should be holstered or
safely secured during this process and the trigger should
never be moved. Load one cartridge into the magazine to
replace the one which was chambered when you allowed the
slide to carry forward.

• Re-insert the loaded magazine into the magazine well of the
pistol until it is locked in place.To make sure that the
magazine is again fully and securely inserted, apply some
removal pressure to the exposed portion of the magazine
butt plate.

•Your pistol is now fully loaded.The hammer is in the down
position and the trigger is forward. Your pistol is ready to be
holstered and carried and will fire when the trigger is pulled.
Remember to keep your pistol pointed in a safe direction
under all conditions and always keep your finger or any other
object off the trigger and outside the trigger guard until you
have made the commitment to fire the handgun.
Never leave a loaded firearm unattended.

17

18

WARNING:
ALL Traditional SA/DA pistols with model
designations called out by 3 or more digits,

i.e. 410, 411, 5906, 4506TSW, etc. are manufactured
with an automatic firing pin block. The automatic firing pin
block prevents the firing pin from moving forward and firing
a chambered cartridge unless the trigger is held fully
rearward. Loaded Smith & Wesson Pistols, Model 39, 52, 59,
Super 9, 4006 S/A, 5906 S/A, 745 and some 945’s have iner­tial firing pins without an automatic firing safety plungers. If
the decocking safety lever is in the fire position, the pistol
will fire when subjected to a sufficient impact.

THEREFORE, IT IS ABSOLUTELY ESSENTIAL THAT
THE DECOCKING SAFETY LEVER OF ANY LOADED
MODEL 39, 52, 59, SUPER 9 4006 S/A, 5906 S/A, 745
AND SOME 945’S BE KEPT IN THE "SAFE" POSITION
UNTIL YOU HAVE MADE THE COMMITMENT TO FIRE
THE HANDGUN. ALSO, REMEMBER THAT PULLING
THE TRIGGER WITH THE DECOCKING SAFETY
LEVER IN THE "FIRE" POSITION WILL FIRE A
LOADED PISTOL.

LOADING CONT’D.

FIRING

WARNING: During firing, always keep the barrel
pointed in a safe direction.

WARNING: Upon firing the pistol or releasing the
slide from the slide stop, the slide moves rearward
or forward with significant force and speed. To
avoid injury be sure no part of your body is in the
path of the slide’s travel.

WARNING: Single action firing requires significantly
less pressure on the trigger and reduced trigger
travel than double action firing.

• With the muzzle pointed in a safe direction and your finger
outside the trigger guard, rotate the decocking safety lever
fully up into the "fire" position. Except for the Models 52, 745,
845, 5906S/A, 4006 S/A and Super 9 which can only be fired
single action, the first shot from an uncocked center fire
pistol will be fired in the double-action mode.

• As the trigger is drawn fully to the rear, the hammer moves
rearward and is released to strike the firing pin. Upon firing,
the slide moves rearward thereby extracting and ejecting the
spent cartridge case and rotating the hammer to the fully­cocked position.

• The slide then returns forward feeding the next cartr idge
from the magazine to the barrel chamber.The hammer
remains in cocked position and the trigger is in the rearward
position so that subsequent shots will be fired in the single
action mode.This sequence can be repeated until the last
round has been fired at which time the magazine follower
exerts upward pressure on the slide stop causing it to
engage the slide and hold it in the "open" position.

MANUAL COCKING

• On a pistol with an exposed hammer spur, the first shot may be
fired in the single action mode when so desired.You can prepare
your pistol for single action firing by pointing the muzzle in a safe
direction, removing your finger from the trigger, rotating the
decocking safety lever fully up into the "fire" position, and pulling
the hammer rearward until it locks into the fully-cocked position.

DECOCKING

• If you decide not to fire after you have manually cocked the hammer
or if you decide to suspend firing, keep the pistol pointed in a safe
direction, remove your finger from within the trigger guard, and
rotate the decocking lever fully down into the "safe" position. This
action will decock the hammer allowing it to fall against the decock­ing safety body and will release the trigger to its forward position.
The pistol may now be holstered and carried safely. This does not
apply to those handguns listed in red on page 18.

CLEARING MISFIRES

DOUBLE ACTION ONLY

•If, dur ing fir ing, a car tr idge fails to fire, the chamber must be
manually cleared.Wait ten seconds while keeping the muzzle
pointed in a safe direction. Grasp the serrated sides of the slide
from the rear and briskly pull the slide fully rearward to eject the
misfired round. Keep your finger off of the trigger and out of the
trigger guard. Do not obstr uct the ejection por t, and do not
attempt to catch the round by placing your hand over the ejection
port. (See figure 7) Also, remember that any time you release the
slide while a magazine containing cartridges is in the pistol,
you will have reloaded the chamber.

•Keep the muzzle pointed in a safe direction and your finger
outside the trigger guard until you are ready to fire. Each
shot will be fired in the double action mode.While holding
the grip firmly, pull the trigger fully to the rear. As the trigger
is drawn fully to the rear, the hammer moves rearward and is
released to strike the firing pin. Upon fir ing the slide moves
rearward thereby extracting and ejecting the spent cartridge
case.The slide then returns forward feeding the next
cartridge from the magazine into the barrel chamber.

• After firing you must allow the trigger to move forward fully
before you can fire another shot.Failure to do so will prevent
the lockwork from fully cycling and will prevent your being
able to fire the next shot.Keep your finger off the trigger and
outside the trigger guard until you are ready to fire again.
This sequence can be repeated until the last round has been
fired, at which time the magazine follower exerts upward
pressure on the slide stop causing it to engage the slide and
to hold it in the “open” position.

DOUBLE ACTION ONLY

FIRING CONT’D.

19

PRODUCT WARNING

All Smith & Wesson Handguns Capable of Double Action
Firing

• It has come to our attention that some users of
Smith & Wesson handguns capable of firing in double action
mode may stage the trigger in anticipation of firing a shot in
the double action mode.Staging is the act of pulling the
trigger rearward toward — but just short of — the point
where the hammer falls and the handgun fires.Such
manipulation of the trigger can reduce the user’s control of
the handgun and can result in an unintentional discharge.
Furthermore if the user decides not to fire, release of the
trigger from a position close to the firing point in the staging
process could result in a discharge.

•Obviously “staging” the trigger violates a basic rule of firearm
safety which warns you to keep your finger off the trigger and
outside the trigger guard until ready to fire.

•We warn all users of our handguns capable of firing in
double action to refrain from “staging”the trigger.

UNLOADING

•Point the muzzle in a safe direction. Make sure your finger is
off the trigger, and the trigger is in the "at rest" or forward
position. Depress the magazine release, and remove the
magazine.

• With the muzzle still pointing in a safe direction,
and with your finger off the trigger and outside the trigger
guard, grasp the serrated sides of the slide from the rear with
the thumb and fingers, and briskly draw the slide fully
rearward in order to extract any cartridge from the barrel
chamber and clear it from the pistol.

20

CLEARING MISFIRES

TRADITIONAL DA/SA

•If, during firing a car tr idge fails to fire, the pistol will remain in the
double action mode.If the situation permits, the trigger may be
pulled once or twice more. If ignition still fails, the chamber must be
manually cleared. Rotate the decocking safety lever fully down into
the "safe" position and wait ten seconds while keeping the muzzle
pointed in a safe direction. Grasp the serrated sides of the slide
from the rear and briskly pull the slide fully rearward to eject the
misfired round. Do not obstr uct the ejection por t, and do not
attempt to catch the round by placing your hand over the ejection
port. (See figure 7) (Also, remember that any time you release the
slide while a magazine containing cartridges is in the pistol,
you will have reloaded the chamber.)

SIGHT ADJUSTMENT

• Certain model Smith & Wesson Pistols are equipped with a
FIxed Rear Sight that is adjustable for windage only.To
adjust, move the Rear Sight in the direction you wish the
group to move on the target.For example, if the group
should move to the right, move the Rear Sight to the right.
Use a brass or plastic drift or punch to prevent marring the
Rear Sight. If the Rear Sight has a set screw, loosen the set
screw prior to moving the Rear Sight.Tighten the set screw
after the sight has been adjusted to the desired position.

• Certain model Smith & Wesson Pistols are equipped with a

screw type rear sight adjustable for elevation and windage.

ADJUSTING FOR ELEVATION

Rotate the Adjusting Screw installed on the top of the
Rear Sight body clockwise to lower the Rear Sight or
counterclockwise to raise the Rear Sight. (Raising Rear Sight
will raise the group, etc.)

ADJUSTING FOR WINDAGE

Rotate the Adjusting Screw installed in the right side of Rear
Sight body clockwise to move the Rear Sight Blade to the right
or counterclockwise to move it to the left.(Moving Rear Sight to
the right will move the group to the right, etc.)

FIELD STRIPPING

DISASSEMBLY

WARNING: Wear safety glasses every time you
assemble or disassemble your firearm.

• Remove the magazine by depressing the magazine release
button, clear the chamber and verify it is empty. Fir mly
grasp the frame and slide with the left hand as shown in
Figure 8. Apply backwards pressure on the slide and move it
back until the slide stop notch in the left side of the slide is
aligned with the forward, rounded portion of the slide stop as
shown in Figure 9. Press inward on the slide stop pin from
the opposite side of the frame and remove the slide stop.
(Figure 10)

21

• Do not obstruct the ejection port because doing so can
interfere with ejection of a cartridge and thereby creates the
risk of exploding an unchambered cartridge and possible
injury.(See figure 7) Visually check the barrel chamber to be
sure it is empty.

• Unload the magazine by holding it with the bullet end of the
cartridge pointing away from you and pressing each cartridge
forward and out of the magazine.

UNLOADING CONT’D.

WARNING: The recoil spring is under pressure .
Control the recoil spring and the guide so that they
do not fly out and cause injury.

• Allow the slide to move forward until it is aligned with the
frame in its normal closed position. *The hammer will fall as
the slide moves forward. Pull the slide forward off the frame
while grasping the recoil spring assembly and slide together
as shown in Figure 11. Remove the recoil spring assembly
by depressing the spring slightly and releasing it carefully
from the small radial undercut in the barrel lug. Figure 12
shows the parts you will have after field stripping.

NOTE:

No further disassembly is recommended, as the pistol may be
properly cleaned and lubricated when field-stripped as described
above.

* SA/DA Pistols Only

FIELD STRIPPING DISASSEMBLY CONT’D.

FIGURE 12

22

FIGURE 11

FIGURE 8

FIGURE 9

FIGURE 10

Slide Stop Notch

Slide
Stop

FIELD STRIPPING

REASSEMBLY

• With the rear of the slide pointed in a safe direction and the
bottom of the slide turned up, replace the barrel in the slide
so the muzzle is flush with the end of the slide and the barrel
lug is turned up (away from the ejection port). Replace the
recoil spring on the recoil spring guide. Insert the spring end
of the recoil spring guide assembly in the guide housing.
Grasp the recoil spring guide bushing and pull it toward you
enough so the bushing can be securely engaged in the small
radial machine cut in the barrel lug. Be careful that it does
not become disengaged, fly out and cause injury.Make sure
it is properly centered in the cut as it will protrude from the
slide after assembly if it is not centered.
(See Figures 13 & 14)

DOUBLE ACTION ONLY

• Holding the slide and recoil spring guide firmly in one hand,
move the rear of the slide onto the frame rails.Continue
moving the slide onto the frame by depressing the ejector
and firing pin safety levers down into their respective frame
slots (See Figure 15). Position the slide so that the slide stop
notch on the slide is aligned with the slide stop hole in the
frame. Inser t the slide stop and allow the slide to return to the
"in battery" position. Reinsert the magazine.

TRADITIONAL DA/SA ONLY

• With the hammer in the full-up position and holding the slide
and recoil spring guide firmly in one hand, move the rear of
the slide onto the frame rails.Continue moving the slide onto
the frame by depressing the ejector, sear release and firing
pin safety levers down into their respective frame slots.
Position the slide so that the slide stop notch on the slide is
aligned with the slide stop hole on the frame. Inser t the slide
stop and allow the slide to return to the "in battery" position.
Move the decocking safety lever down to the safe position.
Reinsert the magazine.

FIGURE 15

FIGURE 14

FIGURE 13

23

CLEANING AND

MAINTENANCE

!!

WARNING !!

Ensure your firearm is unloaded before beginning to clean
it. At all times follow the basic rules of safe gun handling.

Your firearm is a precision instrument. To insure reliable
function it is necessary to follow a routine maintenance
procedure. After firing your handgun, be sure to unload it
following the procedure outlined in the section entitled
“Unloading” on page 21 before performing any cleaning or
maintenance procedure.

ASSEMBLY (see Figure 16)

1. Install magazine follower (2) in bottom of the magazine tube
(1) with the notched edges of the magazine follower (2)
toward the round side of the magazine tube (1).

2. Install magazine spring (3) and floorplate catch (4) in
magazine tube (1).

3. While holding floorplate catch (4) in magazine tube (1), slide
magazine floorplate (5) into magazine tube (1) so that the
round projection of the floorplate catch (4) engages the
magazine floorplate (5).

MAGAZINE ASSEMBLY

24

DISASSEMBLY (see Figure 16)

1. Using a drift punch, depress floorplate catch (4) through hole
in magazine floorplate (5).

2. Slide magazine floorplate (5)
out of magazine tube (1)
while holding floorplate
catch (4) in the magazine
tube (1).

3. Remove floorplate catch (4)
and magazine spring (3) out
through bottom of magazine
tube (1).

4. Turn magazine tube (1)
right side up and remove
magazine follower (2)
through bottom of
magazine tube (1).

MAGAZINE DISASSEMBLY

(1)

(2)

(3)

(4)

(5)

FIGURE 16

Your handgun should be cleaned by brushing the barrel bore and
chamber (charge holes) with a good powder-removing solvent
and bore brush. Wipe the areas clean with patches or a swab.
Using a small brush dipped in
solvent, remove all deposits from around the breech of the
barrel, chamber (charge holes), extractor and adjacent areas
which have been subjected to the action of powder or primer
residue. Remove any residue on the frame with light brushing
and a solvent. After cleaning the entire gun, use a cloth to apply
a light film of high quality gun oil to all external metal surfaces
and wipe clean.

CAUTION:

You must follow the instructions provided with your gun cleaner
and gun lubricant. Some cleaners can cause damage to your
handguns.

CAUTION:

You should avoid prolonged solvent immersion and prolonged
ultrasonic cleaning of your firearm. Choice of solvent should be
restricted to those products specifically developed for firearms
maintenance. Instances of damage to a firearm’s finish have
been recorded when these cautions have been ignored.
Ammoniated solvents or other strong alkaline solvents, should
not be used on any Smith & Wesson firearm. As a rule of thumb,
if you would be comfortable applying the solvent of your choice to
the finish of your automobile, it will probably be safe for use on
your firearm.
After the initial cleaning, there is usually some residue in both the
barrel and cylinder that works out and becomes apparent within
24-48 hours. This can be removed with a bristle brush and a
light re-application of powder removing solvent after which the oil
film should be re-established on all surfaces.

Cleaning is considered essential in order to ensure the proper
functioning of your handgun.

For additional maintenance, we recommend the services of a
qualified gunsmith. Please refer to the section entitled “Service”.
If your firearm will be used or stored in a cold climate, be sure to
use an oil that will not thicken at low temperatures.

25

SERVICE,

SHIPPING & PARTS

SERVICE

Customer Service

2100 Roosevelt Avenue

Springfield, MA 01104

Tel: [phone] • 413-781-8300

E-mail: [e-mail]

For Owners Within The United States

CLEANING AND MAINTENANCE CONT’D.

26

Should your Smith & Wesson firearm require service, it should
be returned to Smith & Wesson in its original case or in a
similarly secure container. It is not necessary to take the gun to
a dealer for shipment. However, before shipping your firearm,
call or e-mail our Customer Service Dept. for authorization and
shipping instructions.

Before shipping your handgun, ensure that the firearm is
unloaded, package it securely, and do NOT ship any ammunition.
The package must NOT bear any markings which indicate the
identity of the contents. Enclose a letter which includes your full
name and address (no P.O. Boxes, please), daytime telephone
number, e-mail address, the serial number of the firearm, and
details of the problem experienced or work desired. Record the
serial number before shipping, in case you wish to check on the
repair status of your firearm.

SHIPPING

When shipping a firearm, it is most important that you comply
with federal, state, and local laws and regulations. The following
guidelines are meant to help, but you must seek assistance from
the appropriate authorities if necessary.

• Check magazines and chambers to ensure that they

are unloaded. Do not ship ammunition.

• Do not attempt to ship a handgun via US Mail; only

federally licensed dealers may ship a firearm by US
Mail.

• If your firearm must be replaced, it may be necessary

to ship the replacement to a dealer rather than directly
to you. You will be requested to furnish a signed FFL
(Federal Firearms License) from your dealer in such an
instance.

• When returning a pistol, please include all magazines

ensuring they are unloaded; they are impor tant to the
proper function of the handgun.

Ship Centerfire pistols and ALL

revolv

ers to:

Customer Service, 2100 Roosevelt Avenue, Springfield, MA 01104

Ship ALL .22 caliber pistols to:

Customer Service, 19 Aviation Drive, Houlton, ME 04730

Please call the above telephone number or e-mail the above

address before shipping!!

Since we cannot assume responsibility for custom parts and
accessories, such as stocks, special sights, or holsters, please
remove these items before returning your firearm.

Warranty repair work will begin upon receipt and examination of
the firearm. In the case of repairs or work not covered by the
warranty, a quotation covering the cost of the work plus round
trip transportation charges will be sent to you. Repairs or
modification will begin upon receipt of payment.

SERVICE, SHIPPING, & PARTS CONT’D.

ACCESSORIES & PARTS

Replacement parts and accessories for your Smith & Wesson firearm
are available from your local Smith & Wesson Stocking Dealer, or
directly from the Smith & Wesson Parts Depar tment.

27

This warranty is granted by Smith & Wesson, 2100 Roosevelt
Avenue, Springfield, MA 01102-2208. This warranty is effective
from the date of purchase after February 1, 1989 and applies to
the original owner of any handgun purchased after that date.
With respect to such handguns, this warranty supersedes any
and all other warranties.

Smith & Wesson handguns are warrantied to be free from defects
in material and workmanship. Any such defects of which
Smith & Wesson receives written notice within one year from the
date of purchase by the original owner, will be remedied by
Smith & Wesson without charge within a reasonable time after
such notification and delivery of the handgun as provided below.
If any unsafe and/or illegal condition if found during warranty
inspection, Smith & Wesson will return the handgun to its original
specification.

Warranty claims (in writing) and the handgun concerned should
be delivered to Smith & Wesson’s Customer Service Department
at the above address. In addition, a copy of the bill of sale in the
owner’s name, or a copy of ATF Form 4473 indicating date of
purchase must be included.

Warranty claims should state the model and serial number of the
handgun concerned and the description of the difficulty experi­enced. It is recommended that shipments be insured by the
owner, since Smith & Wesson will accept no responsibility for loss
or damage in transit. Transportation and insurance charges for
return to owner will be paid by Smith & Wesson if the claim is
covered by the warranty.

UNDER NO CIRCUMSTANCES SHALL SMITH & WESSON BE
RESPONSIBLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES WITH RESPECT TO ECONOMIC LOSS, INJURY OR
PROPERTY DAMAGE,WHETHER AS A RESULT OF BREACH
OF EXPRESS OR IMPLIED WARRANTY, NEGLIGENCE OR
OTHERWISE.

WARRANTY

For Owners Within The United States

SERVICE, SHIPPING, & PARTS CONT’D.

ACCESSORIES &

PARTS

When ordering parts directly from the factory, please provide the
following information:

• Model Number

• Dash Number

• Serial Number

• Approximate date of purchase

•Par t view Number (refer to diagram)

• Complete Return Address

• VISA/Discover/MasterCard Number and
Expiration Date

•For Foreign Orders Only, Fax Number or E-mail
Address

Installation of all replacement parts must be performed by a

trained gunsmith only.

EXTENDED

SERVICE POLICY

For Owners Within The United States

Even after the warranty period has expired, Smith & Wesson will
repair, without charge, any handgun purchased by the original
owner on or after February 1, 1989 that is found to have defect in
material or workmanship. Eligibility for this extended service
policy requires returning the Product Registration Card within thir­ty days of purchase. A copy of the bill of sale in the owner’s name
and the sales receipt should accompany the handgun.

If any unsafe and/or illegal condition is found during warranty
inspection, Smith & Wesson will return the handgun to its original
specification.

This policy covers functional defects;it does not include the hand-

gun’s finish, grips, magazines or sights.

This policy is in addition to and not an extension of the

Smith & Wesson Warranty.

Lifetime Service Policy

Fast Reliable Service

If you have any questions or concerns regarding your
Smith & Wesson product, please give us a call. Our customer
service representatives are product knowledgeable and are here
to help you.

911 Priority Repair Ser

vice

In the event of an emergency (repairs needed by law enforce­ment, an upcoming match or hunting trip), call 1-800-331-0852
and ask for 911 Priority Repair Service. This allows you to speak
with a Smith & Wesson representative. Immediately upon receipt,
your handgun will be assigned to a gunsmith. After the work is

completed, we will return your Smith & Wesson handgun via
overnight delivery.

28

WARRANTY CONT’D.

Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may
not apply to you in whole or in part.

Smith & Wesson will not be responsible for defects resulting from
careless handling, unauthorized adjustments or modifications,
defective or improper ammunition, corrosion, neglect, abuse,
ordinary wear and tear, or unreasonable use.

Smith & Wesson reserves the right to determine what constitutes
ordinary wear and tear. However, we can rebuild handguns that
have experienced extreme usage or are beyond their normal useful
life at a fee that will be quoted to the owner.

This warranty gives you specific legal rights. You may also have
other rights that vary from state to state.

COMPONENT PARTS

29

TRADITIONAL DA/SA

1. Ambidextrous Decocking Safety

2. Ambi. Decocking Safety Lever

3. Ambi. Decock. Saf. Lever Detent Spring

4. Ambi. Decocking Saf.Lever Plunger

5. Ambi. Decock. Saf. Lever Plunger Spring

6. Barrel

7. Barrel Bushing

8. Disconnector

9. Drawbar

10. Drawbar Plunger

11. Drawbar Plunger Spring

12. Ejector Depressor Plunger

13. Ejector Depressor Plunger Spring

14. Ejector Magazine Depressor

15. Ejector Spring

16. Extractor

17. Extractor Pin

18. Extractor Spring

19. Firing Pin

20. Firing Pin Safety Lever

21. Firing Pin Safety Lever Plunger

22. Firing Pin Safety Lever Spring

23. Firing Pin Saf. Lever Spring Retainer

24. Firing Pin Spring

25. Frame Assembly

26. Front Sight

27. Grip

28. Grip Pin / Hammer Assembly

29. Hammer / Hammer Pin

30. Magazine Butt Plate

31. Magazine Butt Plate Catch Assembly

34. Magazine Catch (Right Hand)

35. Magazine Catch Nut

36. Magazine Catch Plunger

37. Magazine Catch Spring

38. Magazine Follower

39. Magazine Spring

40. Magazine T ube

41. Mainspring

42. Mainspring Plunger

43. Rear Sight

44. Rear Sight (extended fixed)

45. Rear Sight Set

46. Rear Sight Base

47. Rear Sight Base Screw

48. Rear Sight Body

49. Rear Sight Body Plunger

50. Rear Sight Body Plunger Spring

51. Rear Sight Elevation Plunger

52. Rear Sight Elevation Screw

53. Rear Sight Elevation Spring

54. Rear Sight Plunger

55. Rear Sight Plunger Spring

56. Rear Sight Slide

57. Rear Sight Windage Nut

58. Rear Sight Windage Screw

59. Recoil Spring

60. Recoil Spring Guide Assembly,
Recoil Spring Guide, Recoil Spring
Guide Bushing, Recoil Spring Guide
Plunger, Recoil Spring Guide Plunger
Spring

61. Sear

62. Sear Pin

63. Sear Release Lever

64. Sear Spring

65. Sear Spring Retainer Pin

66. Sideplate Assembly, Sideplate, Slide
Assembly

67. Slide (Fixed), Slide Assembly (Adj.)

68. Slide Assembly (Extended Fixed)

69. Slide (Adj. Sight)

70. Slide Stop

71. Slide Stop Pin

72. Slide Stop Plunger

73. Slide Stop Plunger Spring

74. Stirrup

75. Stirrup Pin, Trigger Assembly

76. Trigger

77. Trigger Pin

78. Trigger Play Spring

79. Trigger Play Spring Rivet

80. Trigger Plunger

81. Trigger Plunger Pin

82. Trigger Plunger Spring

FOR USE BY TRAINED GUNSMITHS ONLY

COMPONENT PARTS

30

4. Retainer Safety Plunger

5. Retainer Plunger Spring

6. Barrel

7. Barrel Bushing

8. Disconnector

9. Drawbar

10. Drawbar Plunger

11. Drawbar Plunger Spring

12. Ejector Depressor Plunger

13. Ejector Depressor Plunger Spring

14. Ejector Magazine Depressor

15. Ejector Spring

16. Extractor

17. Extractor Pin

18. Extractor Spring

19. Firing Pin

20. Firing Pin Safety Lever

21. Firing Pin Safety Lever Plunger

22. Firing Pin Safety Lever Spring

23. Firing Pin Safety Lever Spring Retainer

24. Firing Pin Spring

25. Frame Assembly

26. Front Sight

27. Grip

28. Grip Pin

29. Hammer Assembly

30. Magazine Butt Plate

31. Magazine Butt Plate Catch Assembly

34. Magazine Catch

35. Magazine Catch Nut

36. Magazine Catch Plunger

37. Magazine Catch Spring

38. Magazine Follower

39. Magazine Spring

40. Magazine T ube

41. Mainspring

42. Mainspring Plunger

44. Rear Sight

45. Rear Sight Set Screw

59. Recoil Spring

60. Recoil Spring Guide Assembly

61. Sear

62. Sear Pin

63. Sear Release Lever

64. Sear Spring

65. Sear Spring Retainer Pin

66. Sideplate Assembly

68. Slide

70. Slide Stop

71. Slide Stop Pin

72. Slide Stop Plunger

73. Slide Stop Plunger Spring

74. Stirrup

75. Stirrup Pin

76. Trigger Assembly

77. Trigger Pin

78. Trigger Play Spring

79. Trigger Play Spring Rivet

80. Trigger Plunger

81. Trigger Plunger Pin

82. Trigger Plunger Spring

87. Firing Pin Retainer

91. Firing Pin Retainer Spacer

This schematic diagram and part description conforms to current
specifications. From time to time, changes may be made, and the
gun which you own may not correspond exactly with the information
provided on this sheet.

7

26

17

16

18

12

13

22

45

21

44

23

24

19

87

6

59

60

68

70

71

73

72

76

77

81

35

36

37

82

80

66

14

74

75

29

25

91

20

42

27

41

28

9

10

11

78

79

30

31

39

38

40

61

64

65

8

62

34

15

4

5

Double Action Only

FOR USE BY TRAINED GUNSMITHS ONLY

This handgun is not equipped with a
device that fully blocks use by
unauthorized users. More than 200,000
firearms like this one are stolen from their
owners every year in the United States. In
addition, there are more than a thousand
suicides each year by younger children
and teenagers who get access to firearms.
Hundreds more die from accidental dis­charge. It is likely that many more chil­dren sustain serious wounds or inflict such
wounds accidentally on others. In order to
limit the chance of such misuse, it is
imperative that you keep this weapon
locked in a secure place and take other
steps necessary to limit the possibility of
theft or accident. Failure to take reason­able preventative steps may result in inno­cent lives being lost, and in some circum­stances may result in your liability for
these deaths.

The certification below is required only for handguns sold in the
United States with a barrel length shorter than 3”.

Smith & Wesson Corp. hereby certifies average accuracy test results for
all new handguns with a barrel shorter than 3” as follows:

7 yards 14 yards 21 yards

1.7” 3.9” 6.3”

This certification is based on tests conducted by Smith & Wesson Corp.
using a fixed handgun, rest and firing ammunition manufactured by a
member of the Shooting Arms and Ammunition Manufacturers Institute
(SAAMI) as defined in ANSI/SAAMI Z299.3-1993.

This certification represents actual tests based on several handguns,
selected at random. Your particular handgun may have accuracy better
than the results stated in this certification.

31

Smith & Wesson

2100 Roosevelt Avenue • Springfield, MA 01104

www.smith-wesson.com

REV:PSTL071701
