SVP CDC-7580 Specifications

CDC-7580

7.0 Mega Pixels Max, 5MP Panasonic CCD Sensor, 3X Optical
Zoom, 4X Digital Zoom, 2.4" TFT-LCD

Specifications

Sensor

Type
Effective

Pixels
Total Pixels

Lens

Focal Length
F No.
Digital Zoom

LCD Display
Viewfinder Optical Viewfinder
Focusing

Type
Range

Shutter

Type
Speed

Exposure

Control
Compensation
ISO Equivalent

1/2.5" CCD
Approx. 5.19 Mega Pixels

Approx. 5.36 Mega Pixels
Wide: 5.8 , Tele: 17.4 mm (35mm Film Equivalent: 35 ~ 105 mm)
Wide: F2.8, Tele: F4.8
Capture Mode:4x, Play Mode:2-8x ( Base on the different image size

setting)

2.4" color TFT LCD, 110k Pixels
No
Auto Focus with 3.0 x Optical Zoom

Macro mode:10cm;Normal:50 cmto infinity
Mechanical shutter and Electrical shutter

Normal: 2 sec. - 1/1000 sec., Night Sense: 8 sec. - 1/1000 sec.

Programmed AE
±2EV (0.5EV / steps)
Auto, 100, 200, 400

Flash

White Balance
Shooting

Modes
Range

Still Image
Live View

Auto / Auto & Red - Eye Reduction / Slow Sync / Fill-in / Off

0.2 ~3.0 m, Wide mode (Recharging time: approx.: 7 sec.)
Auto/Daylight/Cloudy/Fluorescent/Tungsten/Sunset/Custom

Modes: Single Image, Continuous Shooting (Base on the small image
size )
Max. 30 fps for 320x240 with Normal Light Level

Movie Clip

Effect
Sharpness
Metering

Photo Frame
Self-timer
Voice record
Speaker
Storage

Media
File Format
Image Size

7.0 Million
Max.

PictBridge (Direct Printing)
Image Play
Supports Editing functions
Supports Gaming
Interface

Power Source

Size support: 640x480, 320X240 with audio (Quality support: 30 fps
and 15 fps) Recording time is based on memory capacity
B/W,Normal, Sepia, RGB custom

Soft, Normal, Vivid
MULTI, SPOT

9 Frame Options
10 sec., 2 sec., double(no flash) with LED indicator
Yes
No

Internal memory: 32MB flash memory
External memory: supporting SD/MMC Card
Still Image: JPEG EXIF2.2, DCF1.1, DPOF1.2
Movie Clip: AVI with Audio
[7.0M]: 3072x2304 via interpolation, [5M]: 2560x1920,
[4M]: 2304x1728, [3M]: 2048x1536, [2M]: 1600x1200 pixels,
[1M]: 1024x768 pixels

Yes
Single Image / AVI Play / Thumbnails / Slide Show

Trimming, Rotation (Base on the small image size)
Yes
Digital output connector: USB 1.1

Other interface: MIC-in, Video-out (Use same connector as USB),

2 pcs of AA alkaline / 2 pcs of Ni-MH

Dimensions (WxHxD)
Weight
Software

Camera Driver
Application

System Requirements

For Window

For Macintosh

99.94 x 55.4 x35.29 mm(Body:31.81mm)
Approx.140g (without batteries and card) (TBD)
Mass Storage Driver for Windows 98 SE

(Window 2000/ME/XP, Mac OS 9.2 or later don’t need driver)
Ulead Photo Explorer 8.5 SE Basic / Explorer 2 (MAC version)

l PC with processor better than MMX Pentium 233MHz
(XP: Pentium II 300MHz)
l Windows 2000/ME/XP
l Minimum 32MB RAM (XP: 128MB)
l 140MB of available hard-disk space
l USB port, CD-ROM drive
l 800×600 pixels, 16-bit color display compatible monitor
l Power Mac G3 or later
l Mac OS 9.2 or later
l Minimum 64MB RAM
l 110MB of available hard-disk space
l USB port, CD-ROM drive
l QuickTime 6.01 or later for Movie Clip

Silicon Valley Peripherals Inc.

www.svp-tech.com Email: [e-mail]
