TRITON
MECHANICAL
GAMING KEYBOARD
READY TO PLAY
Congratulations
on purchasing your very own
Triton mechanical keyboard –
a gaming keyboard engineered
to suit the needs of every gamer.
Featuring advanced mechanical
switches, it is the keyboard
of choice for optimizing the
Gaming experience.
HOW TO CONFIGURE YOUR KEYBOARD
Multimedia Keys
With these keys you can easily control music & video.
Mute Play/
Pause
Volume Previous
Down Track
Volume Up Next Track
TRITON MECHANICAL KEYBOARD QUICK GUIDE
Package Contents
• Triton Mechanical Keyboard x 1
• Quick Guide x 1
• USB Cable
Compatibility
USB 1.1/2.0 Compatible with Windows® 7 / 8 / 10
System Requirements
• PC with built-in USB pos
• Windows® 7 / 8 / 10
Hardware Installation
1. Plug your keyboard into the USB po of your computer.
2. Windows® will automatically install all the necessary
drivers for the keyboard.
Fn
+
Fn
+
Fn
+
Fn
+
Fn
+
Fn
+
How to select eects
LED Mode
Change
LED Mode
Change
How to adjust light intensity
Lighting
Up
Lighting
Down
Fn
+
Fn
+
Fn
+
Fn
+
Profile Keys
With the Profile Keys you can select between 5 profiles for
background light. Each profile has a base color as indicated
in the illustration below, and for each profile 6 dierent
lighting eects can be selected; Solid, Breathing, Trigger,
Exploding, Random and Wave.
How to select profiles
Profile 1 Profile 4
(Red) (Green)
Profile 2 Profile 5
(Cyan) (Yellow)
Profile 3
(White)
PC Mode
When using one of the lighting profiles the keyboard is in
Gaming Mode and the Windows key is disabled. The first
indicator lamp lights Blue as long as any profile is selected.
When selecting PC Mode the indicator LED is turned o and
the Windows key is enabled. The LED light profile is in Blue
color when keyboard is in PC Mode.
Select PC Mode with these function keys;
Default and Profile Switch (Blue)
Fn
+
Fn
+
Fn
+
Fn
+
Fn
+
Fn
+
Fn
+
Macro Record
You can also configure your own macros for your keyboard.
Use the following steps;
Step 1
Press FN+R-Alt to sta Macro
Record process, Gmode Led will flash.
Step 2
Type any key you want to record.
Step 3
Press FN+R-Alt again, Gmode Led
will flash more quickly.
Step 4
Assign a key you want to save this record.
Step 5
Gmode LED will stop flash,
Macro record process finish.
Notice: FN and Win Key can’t
be assign to macro key.
Hardware Reset
If the keyboard has unexpected problem,
you can reset the keyboard by holding FN+ESC
for 3 seconds. LED will flash once and current
profile will be reset to default seing.
N-Key Control
You have the option of choosing 2 dierent Rollover
seings; 6-key Rollover (6KRO) where 6 keys can be pressed
simultaneously and n-key Rollover (NKRO) where an unlimited number of keys can be pressed simultaneously.
Select your preferred seing with these function keys;
6-Key N-Key
(Default)
Fn
+
Fn
+
RGB COLOR
LED
MECHANICAL
SWITCHES
PLUG
& PLAY
NORDIC
LAYOUT
BRAIDED
CABLE
MACRO
BUTTONS
MULTIMEDIA
BUTTONS
