Page 1
Wireless Optical Mouse
USER’S MANUAL
RX-195
Wireless
www.sven.fi
Page 2
ENG
User’s Manual
Congratulations on purchasing the SVEN PC mouse!
Please read the following User’s Manual carefully before connecting,
operating or adjusting this product. Besides, please keep this Manual in a
safe place for future reference.
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights
reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some
discrepancies may occur. The information of this Manual is given on «as is»
terms. The author and the publisher do not bear any liability to a person or
an organization for loss or damages which have arisen from the information
contained in the given Manual.
СОДЕРЖАНИЕ
1. SPECIAL FEATURES ..................................................
2. PACKAGE CONTENTS ................................................
3. SYSTEM REQUIREMENTS ..........................................
4. DESCRIPTION .........................................................
5. INSTALLATION .........................................................
6. TROUBLESHOOTING .................................................
7. TECHNICAL SPECIFICATION ........................................
Technical support: www.sven.fi
RX-195
Wireless
1
2
2
2
3
3
5
5
Page 3
ENG
Wireless Optical Mouse
1. SPECIAL FEATURES
• RF 2.4GHz USB nano receiver (range – up to 10 m)
• High-precision optical technology
• Effective on most surfaces
• High speed operation
• Resolution 800 dpi
• USB interface
• 2 AAA Alkaline type batteries
• Drivers installation is not required for Windows XP/Vista/7/8
• Natural shape of the mouse convenient for the hand
• Energy saving system increases battery life up to 6 months (see
comparison table)
Operating mode
During work 4.8 — 6 mА
Motionless 0.5 — 0.55 mА
Standby mode 0.1 — 0.12 mА
Sleeping mode 0.03 — 0.05 mА
2. PACKAGE CONTENTS
• Optical mouse — 1 рс
• 2.4 GHz USB nano receiver — 1 рс
• AAA type batteries — 2 рсs
• User’s Мanual — 1 рс
• Warranty card — 1 рс
3. SYSTEM REQUIREMENTS
• Windows XP/Vista/7/8.
• Free USB port.
RX-195W
Other mice
10 m А
8 mА
3 mА
0.15 mА
2
Page 4
User’s Manual
4. DESCRIPTION
a Scroll wheel
b Battery compartment
c Optical sensor
d USB connector
e Nano receiver
ENG
RX-195
Wireless
a
b
c
Fig. 2. Bottom view
5. INSTALLATION
• Open the cover of the mouse battery compartment b, insert two AAA
type batteries into the battery compartment matching polarity, and close the
cover of the battery compartment (see Fig. 4).
• Unpack the nano receiver e and connect it to an available PC USB port
(Fig. 5). To activate the mouse, it is necessary to press any button of the
mouse or scroll the wheel. If the mouse has been connected correctly, it will
turn on automatically.
Fig. 1. Top view
d
e
Fig. 3. Nano receiver
3
Page 5
ENG
Wireless Optical Mouse
Improper installation of batteries can
result in failure of
the mouse!
Battery com-
partment cover
Fig. 4. Installation of batteries
• Do not place the receiver in confined
metal space (table drawer, box, safe), as
a metal screen does not transmit radio
signals.
• If the batteries run down, the mouse
works by fits. It means that batteries
should be replaced with new ones, as it
is shown in Fig. 4. Always install only
identical new batteries.
Important
This device meets highest standards of energy conservation.
During long pauses in operation the mouse enters the economical
Sleep mode. To enter the working mode, just press any button or
scroll the wheel.
Battery
compartment
2 х AAA type batteries
Fig. 5. Receiver connection
4
Page 6
ENG
User’s Manual
6. TROUBLESHOOTING
Problem
The mouse does not work.
Batteries are in good order,
but the mouse still does not
work.
7.
TECHNICAL SPECIFICATIONS
Parameter
OS compatibility
Type of mouse
Resolution, dpi
Q-ty of buttons
Interface
Conformity with
Notes:
• Technical specifications given in this table are supplemental infor-
mation and cannot give occasion to claims.
• Technical specifications are subject to change without notice due to
improvement of SVEN production.
Solution
1. Make sure that the nano receiver has
been inserted into the USB port and its
distance to the mouse is less than 10 m.
2. Check whether the batteries have been
installed correctly.
3. Check if the batteries have run down, replace them with new ones if necessary.
Install software to coordinate the mouse
and the receiver. Software can be downloaded from Support on www.sven.fi
Value
Windows XP/Vista/7/8
wireless 2.4 GHz
800
2 + 1 (scroll wheel)
USB
FCC, CE
RX-195
Wireless
5
Page 7
Wireless Optical Mouse
Модель:
RX-195 Wireless
Импортер в России: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация в России:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
в гарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, № 02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано в Китае.
Manufacturer: SVEN PTE. LTD., 176 Joo Chiat Road,
№ 02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
RX-195
Wireless
