USER’S MANUAL

Web Camera with Headset

ICH-8600

1

User’s Manual

ENG

ICH-8600

2
2
2
2
3
3
4

Thank you for choosing the SVEN unit!

Please read this operation manual before using the unit and retain this
operation manual in a safe place for future reference.

COPYRIGHT

© 2011. SVEN Company Ltd. Version 1.0 (V 1.0).
This manual and information contained in it are copyrighted. All rights
reserved.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted efforts to make this manual more exact, some
discrepancies may occur. The information of this manual is given on «as is»
terms. The author and the publisher do not bear any liability to a person or an
organization for loss or damages which have arisen from the information
contained in the given manual.

CONTENTS

1. SAFETY PRECAUTIONS . . . ..................................

2. PACKAGE CONTENTS .. . ...................................

3. SPECIAL FEATURES ........................................

4. SYSTEM REQUIREMENTS ..................................

5. CONNECTION AND INSTALLATION . . . . . ....................

6. DESCRIPTION . . . ...........................................

7. TECHNICAL SPECIFICATION .. . .............................

Technical support: www.sven.fi

ENG

2

Web Camera with Headset

1. SAFETY PRECAUSIONS

• Protect your web camera from high humidity, dust or high temperatures.

• Do not use gasoline, spirit or other dissolvents for cleaning. This may

cause damage of the surface. Clean the outside of the camera with soft
cloth.

• Do not attempt to disassemble or repair your device.

• Protect the device against powerful shocks and falls – they may damage

the internal electronics.

2. PACKAGE CONTENTS

• Web camera — 1 pc

• User’s manual — 1 pc

• Warranty card — 1 pc

3. SPECIAL FEATURES

• Headset with volume control

• Adjustable focal distance

• Comfortable mounting clip for camera fixation

• Ball-type hinge for camera rotation

• Automatic face tracking*

• 16 video effects and 10 types of frames*

• Tight-fitting headband

• Headset volume control

• Microphone holder

• Comfortable ear cushions

4. SYSTEM REQUIREMENTS

• Windows 2000/XP/Vista/7 or up

• Pentium P4 1.4GHz or AMD Athlon 1GHz

• 128 MB RAM

* To have more opportunities and functions of the web camera, please
download additional software from www.sven.fi

ENG

3

ICH-8600

User’s Manual

Fig. 1. Web Camera

b

c

a

d

e

Fig. 2. Headset

f

g

h

i

j

• 200 MB Free Hard Disk Space

• Video adapter 24-bit color

• Available USB 1.1 or 2.0 port

(high-speed USB 2.0 port is
required for higher resolution)

5. СONNECTION AND
INSTALLATION

• Connect the web camera to an

available USB port.

• This web camera supports
Plug and Play technology. Instal­lation of the device is automatic
after its connection to USB port.

6. DESCRIPTION

a Lenses
b Focus
c Ball-type hinge
d Mounting clip
e Stand
f Tight-fitting headband
g Мicrophone
h Мicrophone holder
i Comfortable ear cushions
j Volume control

ENG

4

Web Camera with Headset

7. TECHNICAL SPECIFICATION

Parameter, unit

Sensor type
Resolution, pix

Frame rate, frames/sec
Focus distance, mm
Weight, g

Impedance, Ω
Sensitivity, dB/1 kHz
Frequency response, Hz
Max. output power, mW
Jack type, mm
Module dimensions, mm
Directional selectivity
Response level of microphone, dB/1 kHz
Frequency response of mic-phone, Hz
Cable length, m
Weight, g

Value

CMOS
1280 × 1024, max. 3200 × 2400

(enhanced by software)
up to 30 fps
3 to infinity
195

32
11 4
20 — 20000
50
mini-jack Ø 3.5
6 × 5
omnidirectional (360°)
–58 ± 2
30 — 16000

2.3
100

Notes:

• Technical specification given in this table is supplemental information and
can not give occasion to claims.

• Technical specification is subject to change without notice due to
improvement of SVEN production.
