Page 1
www.sven.fi
Gx-970
Gaming
Gaming Optical Mouse
USER’S MANUAL
Page 2
Congratulations on your purchase of the Sven mouse!
Please read this Operation Manual before using the unit and retain this
Operation Manual in a safe place for future reference.
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights
reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The information of this Manual is given on “as is”
terms. The author and the publisher do not bear any liability to a person or an
organization for loss or damages which have arisen from the information
contained in the given Manual.
SPECIAL FEATURES
• High-precision optical technology
• Effective on most surfaces
• Stylish ergonomic design
• Two modes — gaming and multimedia
• Double click button
• 6 + 1 buttons (scroll wheel)
• 800/1200/1600/2000 dpi switchable
• Gold-plated USB connector
• Soft-touch case
• Weighted construction
• Blue scroll wheel backlight in multimedia mode
• Drivers installation not required for Windows XP/Vista/7/8
ENG
1
Gx-970
Gaming
User’s Manual
Page 3
ENG
2
Gaming Optical Mouse
SYSTEM REQUIREMENTS
• Windows XP/Vista/7/8 or higher, Mac OS 10.4 or higher, Linux
• Free USB port
DESCRIPTION
Attention! Functions of additional buttons d and e change according to
the active mode (gaming or multimedia).
Gaming mode:
a Scroll wheel
b Double click button
c Dpi switch
d Move forward
e Move backward
Multimedia mode:
a Scroll wheel
b Double click button
c Dpi switch
d Next track
e Previous track
Notes:
• To change resolution, press button
c and hold
it down for less than 5 seconds; to change the
mode, hold it down more than 5 seconds.
• In multimedia mode, the scroll wheel adjusts volume level.
• To pause the playing track, just press the scroll wheel.
INSTALLATION
• Connect the mouse to an available USB port of your PC.
• Installation of the mouse is automatic after its connection to a PC USB port.
d
a
c
e
b
Fig. 1. Top view
Page 4
ENG
3
Gx-970
Gaming
User’s Manual
Technical support is on www.sven.fi
TROUBLESHOOTING
Problem
The mouse is not
working.
Solution
1. Disconnect the mouse from the PC and check
connector pins for possible damage. If there is no
external damage found and connector pins are
OK, connect the mouse to the PC.
2. Address your nearest authorized service center.
Notes:
• Technical specifications given in this table are supplemental information and
cannot give occasion to claims.
• Technical specifications are subject to change without notice due to the improvement of SVEN production.
TECHNICAL SPECIFICATIONS
Parameter, measurement unit
OS required
Type of mouse
Resolution, dpi
Q-ty of buttons
Interface
Conformity with
Сable length, m
Dimensions, mm
Weight, g
Value
Windows XP/Vista/7/8
optical
800/1200/1600/2000
6 + 1 (scroll wheel)
USB
FCC, CE
2
115 × 77 × 39
140
Page 5
Модель:
GX-970 Gaming
Импортер в России: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация в России:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
в гарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, № 02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано в Китае.
Manufacturer: SVEN PTE. LTD., 176 Joo Chiat Road,
№ 02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
Gx-970
Gaming
Gaming Optical Mouse
