Page 1
www.sven.fi
USER’S MANUAL
Wireless Combo Set
Keyboard + Mouse
Comfort
4400W
Page 2
ENG
1
User’s Manual
CONTENTS
1. SPECIAL FEATURES ...............................................................................
2. PACKAGE CONTENTS ..............................................................................
3. SYSTEM REQUIREMENTS .........................................................................
4. INSTALLATION ........................................................................................
5. CONNECTION ........................................................................................
6. DESCRIPTION OF SHORTCUT KEYS FUNCTIONS ............................................
7. TROUBLESHOOTING ...........................................................................
8. TECHNICAL SPECIFICATION .....................................................................
Technical support is on www.sven.fi
Congratulations on your purchase of the Sven Multimedia Keyboard!
Please read this User’s Manual before using the unit and retain this User’s Manual in safe place for
future reference.
COPYRIGHT
© 2013. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The
information of this Manual is given on «as is» terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damages which have arisen from the information,
contained in the given Manual.
UNPACKING
Unpack the device carefully. Make sure there are no accessories left in the box. Check up the device
for damages; if the product was damaged during transportation, address the firm which carried out
the delivery; if the product functions incorrectly, address the dealer at once.
2
2
2
2
3
3
3
4
COMfort
4400W
Page 3
ENG
2
1. SPECIAL FEATURES
• Modern slim design, high quality, economical solution
• Wireless mouse with 5 buttons and a scroll wheel included
• Resolution 1000 dpi
• 2.4 GHz USB Nano receiver
• Coverage range up to 10 m
• Automatic detection not requiring matching of receiver with pointing device
• Compatible with Windows XP/Vista/7/8
• USB Interface
• High-quality membrane
• 14 shortcut buttons to Internet and Multimedia
2. PACKAGE CONTENTS
• Wireless keyboard — 1 pc
• Wireless mouse — 1 pc
• 2.4 GHz USB Nano receiver — 1 pc
• ААА type batteries — 4 pcs
• User’s manual — 1 pc
• Warranty card — 1 pc
3. SYSTEM REQUIREMENTS
• Windows XP/Vista/7/8, MacOS 10.4 or higher, Linux
• Free USB port
4. INSTALLATION
• Open the cover of the mouse battery compart-
ment, insert two AAA type batteries into the battery
compartment matching polarity, and close the cover
of the battery compartment (see Fig. 1).
• Open the cover of the battery compartment at the
bottom of the keyboard, insert two AAA type
batteries matching polarity, and close the cover of
the battery compartment.
Cover of the
mouse battery
compartment
Mouse battery
compartment
Cover of the mouse
battery compartment
AAA type
batteries
AAA type
batteries
Cover of the keyboard battery
compartment
Keyboard battery compartment
During installation of batteries please match
polarity. Incorrect polarity can cause
malfunction of the device, which gives no
claims for warranty servicing.
!
!
Always install only the same type batteries, because installation of different types of batteries
with different level of charge can cause leaking
of one of the batteries, which can damage the
device.
Fig. 1
Wireless Combo Set
Keyboard + Mouse
Page 4
3
ENG
User’s Manual
5. CONNECTION
• Connect the 2.4 GHz USB Nano receiver to a free USB port of the keyboard. The distance between
the keyboard and the USB Nano receiver should be not more than 6-8 m.
• To activate the set, press any button of the mouse or turn the scroll wheel. If the set has been connected correctly, it will turn on automatically.
• For setting the mouse press at the same time the right button and the scroll wheel and by holding
them pull out and insert the 2.4 GHz Nano receiver to the USB port. For setting the keyboard press at
the same time «ESC» and «Q» keys and while holding them, pull out and insert the 2.4 GHz receiver to
the USB port.
6. DESCRIPTION OF SHORTCUT KEYS FUNCTIONS
Оpen home web page
Start default e-mail program
Refresh
Start media player
Go to previous media track
Volume control
Turn off media player
Open My Computer
Open My Favorites
Go to search page
Stop downloading web page
Start/Pause playback of media track
Go to next media track
Mute/turn on sound volume
Start/Close Calculator
7. TROUBLESHOOTING
Problem
The keyboard and mouse are
not working.
Problems with using
additional shortcut
keys of the keyboard.
Solution
1. Check whether the batteries have been installed correctly.
If necessary, replace the batteries with new ones matching
polarity .
2. Pull out the USB receiver and insert it back to make sure
that it is not damaged.
3. Reprogram the USB Nano receiver using the software you
can download at www.sven.fi .
4. We recommend to address your nearest service center.
We recommend to address your nearest authorized service
center.
If none of the above methods can solve the problem, please seek professional advice at your nearest
service center. Never attempt to repair the product yourself.
Notes:
• Do not place the receiver in metal confined space (drawer of the table, box, safe). Metal screen
does not transmit radio signals.
• If batteries run down, there will be «lapses» in operation of the mouse or keyboard. In such case
replace the batteries with new ones.
• If there is a long pause in operation of the mouse or keyboard, they enter sleeping mode. To enter
operation mode just press any button.
COMfort
4400W
Page 5
ENG
4
Value
105 + 14 shortcut keys
5 + 1
available
Rus/Ukr/Eng
Windows XP/Vista/7/8
USB
more than 20,000,000 strokes
up to10
1000
2.4
490 × 20 × 180
118 × 42 × 75
803 + 80
Parameter, measurement unit
Q-ty of keyboard keys
Q-ty of mouse buttons
Volume control
Keyboard layout
OS required
Interface
Extrapolated mean life
Coverage range, m
Mouse resolution, dpi
Frequency, GHz
Keyboard dimensions (W × H × L), mm
Mouse dimensions (W × H × L), mm
Weight of keyboard and mouse, g
8. TECHNICAL SPECIFICATION
Notes:
• Technical specification given in this table is supplemental information and cannot give
occasion to claims.
• Technical specification is subject to change without notice due to improvement of SVEN
production.
Wireless Combo Set
Keyboard + Mouse
Page 6
Модель: COMFORT 4400 Wireless
Импортер в России: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация в России: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
в гарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, № 02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано в Китае.
Manufacturer: SVEN PTE. LTD., 176 Joo Chiat Road,
№ 02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
