Page 1
USER’S MANUAL
Stereo Headphones
with Microphone
www.sven.fi
ap-520
Page 2
ENG
1
User’s Manual
Congratulations on your purchase of the SVEN headphones!
APPLICATION
Sven AP-520 stereo headphones with a microphone are designed for
operation with PC sound cards and other compatible systems. They can be
also used in VoIP telephony, video conferencing, multimedia applications,
interactive games, for speech recognition and learning foreign languages.
SAFETY PRECAUTIONS
• Don’t use the stereo headphones while driving.
• Don’t use the stereo headphones at high volume for a long time (more
than 15 minutes), as this may cause hearing impairment.
SPECIAL FEATURES
• 2*3.5 mm (3 pin) connector for PC
• Unilateral connection of the cable
• Volume control on the cable
• Adjustable headband
• Heavy-duty non-tangling cable with fabric braid
• Extra cable attachment support
CONNECTION AND OPERATION
• Connect the headphones connector to the audio output jack of your audio
source (PC, laptop, MP3 player), as shown in Fig. 1.
• Insert the microphone connector into the microphone input jack of your
audio source.
• Adjust the headphones volume level as desired with the volume control wheel
on the cable.
AP-520
Page 3
TECHNICAL SPECIFICATIONS
Notes:
• Technical specifications given in this table are supplemental information
and cannot give occasion to claims.
• Technical specifications are subject to change without notice due to the
improvement of SVEN production.
Parameter, measurement unit
Sensitivity, dB
Frequency range, Hz
Membrane, mm
Connector type
Cable length, m
Weight, g
Value
headphones: 106 ± 2
microphone: -48 ± 3
headphones: 20 – 20,000
microphone: 50 – 16,000
Ø 40
Ø 2*3.5 mm (3 pin) mini jack (stereo)
2.2
160
Sound card
Phone out
Mic in
Headphones connector
Mic connector
Microfon
Volume control
and microphone on the cable
Technical support is on www.sven.fi
Fig. 1. Connection diagram
ENG
2
Stereo Headphones
with Microphone
Page 4
Модель:
AP-520
Импортер в России: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация в России:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
в гарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, № 02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано в Китае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№ 02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
Stereo Headphones
with Microphone
ap-520
