USER’S MANUAL
Stereo Headphones
with Microphone
www.sven.fi
AP-170M
ENG
1
User’s Manual
Congratulations on your purchase of the SVEN headphones!
APPLICATION
Sven AP-170M stereo headphones with a microphone are designed for
operation with PC sound cards and other compatible systems. They can be
also used in VoIP
telephony, video conferencing, for speech recognition and
learning foreign languages.
PACKAGE CONTENTS
• Stereo headphones – 1 pc
• User’s Manual – 1 pc
• Warranty card – 1 pc
SAFETY PRECAUTIONS
• Don’t use the stereo headphones while driving.
• Don’t use the stereo headphones at high volume for a long time (more
than 15 minutes), as this may cause hearing impairment.
SPECIAL FEATURES
• Compact size
• Microphone on the cable
• 3,5 мм (4 pin) connector for mobile devices
• Call acceptance / Pause button
CONNECTION AND OPERATION
• Connect the headphones connector to the audio output jack of your audio
source (PC, laptop, MP3 player, etc.), as shown in Fig. 1.
• Adjust the headphones volume level as desired with the volume control of
a sound source.
AP-170M
Sound card
Headphones
out
Headphones
connector/ 4 pin
Call acceptance / Pause button
Microphone
Fig. 1. Connection diagram
TECHNICAL SPECIFICATIONS
Notes:
• Technical specifications given in this table are supplemental information
and cannot give occasion to claims.
• Technical specifications are subject to change without notice due to the
improvement of SVEN production.
Parameter, measurement unit
Sensitivity, dB
Frequency range, Hz
Membrane, mm
Connector type
Cable length, m
Weight, g
Value
headphones: 105 ± 3
microphone: -58 ± 2
headphones: 18 – 20,000
microphone: 30 – 16,000
Ø 36
Ø 3.5 mm mini-jack/4 pin
1.2
80
Technical support is on www.sven.fi.
ENG
2
Stereo Headphones
with Microphone
Модель:
AP-170M
Импортер в России: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация в России:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
в гарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, № 02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано в Китае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№ 02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
Stereo Headphones
with Microphone
AP-170M
