SVAT Electronics CV503-8CH User Manual

SVAT ELECTRONICS
now you can see
8 Channel H.264 Smart LCD-DVR Security System
w/ Coaching iMenu and Night Vision Surveillance Cameras
COMPLETE SYSTEM
INSTRUCTION MANUAL
CV503-8CH-19M
Model#:
CV503-8CH
www.SVAT.com
1
1
IMPORTANT! PLEASE READ!
SVAT ELECTRONICS
now you can see
NEED HELP?
DO NOT RETURN THIS
PRODUCT TO THE STORE
Please contact a SVAT customer support representative rst regarding any additional information on product features, specications or assistance with setup.
Please contact us via one of the methods below:
Email:
support@SVAT.com
Online live web chat:
Visit www.SVAT.com
Toll free telephone:
1.866.946.7828
Toll free fax:
1.888.771.1701
For more product information visit www.SVAT.com
Note: This is manual version 1.0 for this product, you may nd updated versions by visiting our website.
CV503-8CH CV301-8CH
2
IMPORTANT! PLEASE READ!
SVAT ELECTRONICS
now you can see
PRODUCT WARRANTY INFORMATION
Please visit our website at www.SVAT.com
for information about your product’s warranty.
We take quality very seriously. That is why all of our products come with a one year warranty from the original purchase date against defects in workmanship and materials. If you have warranty or support issues please contact us using any of the following
methods:
Phone: 1.866.946.7828 SVAT USA SVAT CANADA Fax: 1.888.771.1701 60 Industrial Parkway #Z64 4080 Montrose Road Email: support@SVAT.com Cheektowaga, NY Niagara Falls, ON Website: www.SVAT.com USA 14227 Canada L2H 1J9
Warranty Terms
1. SVAT products are guaranteed for a period of one year from the date of purchase against defects in workmanship and materials. This warranty is limited to the repair, replacement or refund of the purchase price at SVAT’s option.
2. This warranty becomes void if the product shows evidence of having been misused, mishandled or tampered with contrary to the applicable instruction manual.
3. Routine cleaning, normal cosmetic and mechanical wear and tear are not covered under the terms of this warranty.
4. The warranty expressly provided for herein is the sole warranty provided in connection with the product itself and no other warranty, expressed or implied is provided. SVAT assumes no responsibilities for any other claims not specically mentioned in this warranty.
5. This warranty does not cover shipping costs, insurance, or any other incidental charges.
6. You MUST call SVAT before sending any product back for repair. You will be sent a Return Authorization number with return instructions. When returning the product for warranty service, please pack it carefully in the original box with all supplied accessories, and enclose your original receipt or copy, and a brief explanation of the problem (include RA #).
7. This warranty is valid only in Canada and the continental U.S.
8. This warranty cannot be re-issued.
CV503-8CH
CAUTION
RISK OF ELECTRIC SHOCK, DO NOT OPEN MONITOR
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
www.SVAT.com
3
TABLE OF CONTENTS
SVAT ELECTRONICS
now you can see
TABLE OF CONTENTS .............................................................................................. 1
INTRODUCTION .................................................................................................... 3
WHAT IS INCLUDED ............................................................................................... 3
FEATURES ............................................................................................................4
OPTIONAL ACCESSORIES ........................................................................................ 5
BUTTONS AND CONNECTIONS .................................................................................6
BASIC SETUP ........................................................................................................ 8
Things to Consider Before Installation ........................................................................8
Mounting the Cameras ...............................................................................................8
Connecting Peripheral Cable ....................................................................................... 9
Wiring Diagram for Cameras ....................................................................................... 9
CONNECTING ADDITIONAL DEVICES ....................................................................... 10
Connecting a USB Mouse .......................................................................................... 10
Connecting a Monitor ............................................................................................... 10
Connecting a PTZ Camera .........................................................................................10
POWERING ON DVR ............................................................................................. 11
GETTING STARTED ............................................................................................... 11
Using the Mouse ....................................................................................................... 11
Viewing Your Cameras .............................................................................................. 11
FUNCTION MENU ................................................................................................ 12
Function Menu Options ............................................................................................ 12
MAIN MENU ....................................................................................................... 15
Using the Keyboard ..................................................................................................16
Camera Setup ...........................................................................................................16
Privacy Zone .............................................................................................................18
Record Setup ............................................................................................................20
Network Setup Menu ................................................................................................ 22
Video Search ............................................................................................................. 25
Devices .....................................................................................................................27
HDD ..........................................................................................................28
Alarm Setup.............................................................................................. 30
PTZ Setup ................................................................................................. 31
Mobile Setup ............................................................................................31
Motion Detection ...................................................................................... 32
System Setup ............................................................................................................ 34
Date and Time ........................................................................................... 34
Password Setup ........................................................................................ 37
Video Setup ..............................................................................................38
Language ................................................................................................. 39
System Information .................................................................................. 39
Maintenance.............................................................................................40
CV503-8CH-19M
1
TABLE OF CONTENTS
SVAT ELECTRONICS
now you can see
PLAYBACK .......................................................................................................... 41
Playback through DVR .............................................................................................. 41
Computer Playback ................................................................................................... 42
File Viewing.............................................................................................. 43
Software Functions ..................................................................................44
Bottom Playback Functions ...................................................................... 45
NETWORK GUIDE ................................................................................................ 48
Requirements ...........................................................................................................48
Connecting DVR to a Router ...................................................................................... 48
Finding your DVR’s IP Address ................................................................................... 49
Preparing your Computer for Viewing the DVR .........................................................49
Log in to the DVR ...................................................................................................... 52
Installing ActiveX Controls ........................................................................................ 52
Viewing DVR Outside Of your Network .....................................................................53
Option 1 ................................................................................................... 54
Option 2 .................................................................................................... 55
Testing Port Forwarding ........................................................................... 56
If You Cannot Connect ............................................................................... 57
DDNS Setup ..............................................................................................................58
Logging into Software ..............................................................................................61
ONLINE SOFTWARE ............................................................................................. 62
Live Mode .................................................................................................................63
PTZ Options .............................................................................................................. 64
PLAYBACK ......................................................................................................... 65
PLAYING BACK FOOTAGE ...................................................................................... 66
SETUP ........................................................................................................... 67
NETWORK SETUP MENU ....................................................................................... 70
MOBILE VIEWING ................................................................................................ 74
DVR TROUBLESHOOTING...................................................................................... 79
DVR SPECIFICATIONS ........................................................................................... 81
CAMERA MANUAL ............................................................................................... 83
What’s Included ........................................................................................................83
Features .................................................................................................................... 83
Wiring Diagram for Cameras ..................................................................................... 84
Drilling Template ......................................................................................................84
Camera Specications ............................................................................................... 85
Camera Troubleshooting ...........................................................................................86
REPLACEMENT PARTS .......................................................................................... 87
ADDITIONAL ACCESSORIES ................................................................................... 87
CV503-8CH-19M
2
INTRODUCTION
SVAT ELECTRONICS
now you can see
Congratulations on your purchase of the ClearVu 503 8 Channel LCD-DVR! This user friendly system will allow you to monitor and protect your home or business. The coaching iMenu makes setting up and using your DVR very easy with helpful information bubbles that to assist you in using and setting up your system. The CV503-8CH comes equipped with H.264 compression which allows you to record and store more footage using less space, so you will never miss an important event. This manual was written to ensure that you get the most out of your CV503-8CH DVR.
WHAT IS INCLUDED
19” LCD-DVR (500GB Hard Drive Installed)
4 x 60ft 4 PIN DIN to RCA
(male) Power Cables
10 x RCA to BNC Connectors
• 4 x Camera Mounts
• Camera Mounting Hardware
4 x Outdoor Night
Vision Cameras
10ft RJ-45 Cable
Peripheral Cable
• Quick Start Guide
• Power Adapter for Camera
4 x Window Warning Stickers
Software and Manual CD 4 port power supply
IR Remote Control
• 1 Year Warranty
• 24/7 Lifetime Live Customer Support
DC12V Power Adapter
for DVR
for Cameras
USB Mouse
CV503-8CH-19M
3
FEATURES
SVAT ELECTRONICS
now you can see
View Online or on a Smartphone
This system allows you to check on your footage, no matter white time it is or where you are in the world. You have the power to access your DVR’s footage over the internet1 or directly from your iPhone® or BlackBerry ®2 smartphone.
All-In-One Security System
Sync combines a vibrant 19” LCD monitor with a powerful DVR system. The compact design is sleek, stylish and easy to setup. The LCD DVR can even be wall mounted, allowing you to save more space when protecting your property.
500GB HDD Records in Real Time
Using cutting edge H.264 compression, you can record over a month of continuous video.3 The footage records in real time (30 frames per second) so that when you play your footage back, it streams awlessly and ensures that you never miss a thing.
Night Vision Equipped Cameras
Each camera comes equipped with 12 infrared LEDs allowing you to see any monitored area in total darkness, up to 15ft away!
Four Professional Grade Weather Resistant Cameras
Each camera comes equipped with a Sharp® CCD image sensor which provides you with a clear picture at 420 TV lines of resolution. Made with professional grade aluminum and a sunshade to prevent glare and deterioration.
Protect your assets with Privacy Masking
The unique privacy masking option protects privacy and liability by allowing you to block certain objects from being viewed or recorded. Mask out employee rest areas or alarm systems where special codes need to be entered so that you and your employee’s rights are protected.
4
5
Multiple Viewing Options
Multiple viewing options allow you to view eight cameras at once, four cameras in quad screen or one camera at a time. You can also cycle through each camera in sequence mode or view up to three cameras with the unique Picture in Picture option.
Multiple USB Backup Options
A built-in USB port gives you multiple back up options. If you want to keep footage for safety purposes or if you need to give the authorities footage, you can choose to transfer to a USB ash drive, external hard drive or an external CD/ DVD writer.6
Advanced Recording options
The motion detection option allows you record only when motion is detected so that you save hard drive space and still record all the important events. You can even ensure that false alarms are not triggered by easily blocking out areas with constant movement.
24/7 Scheduled Recording
You have the option to record constantly, record based on a set schedule or record when only motion is detected. You can set each camera to record a specic schedule and choose which days of the week and hours of the day, you want to record.
CV503-8CH-19M
4
FEATURES
SVAT ELECTRONICS
now you can see
Expandable up to 8 Total Cameras
This system comes with four cameras and allows you expand it to up to eight cameras total. This allows you to expand your system as your monitoring needs expand, so that you won’t have to purchase an entirely new system.
any SVAT VU301-C or VU5-C cameras.
Included Mouse and Remote Control
The Included Mouse and remote control allow you to navigate through the menu easily and hassle free.
Password Protection
Password protection ensures that only authorized people can view your footage or adjust your DVR settings.
Search by Date, Time or Event7
You can search for footage by date, time or event so that you can nd the specic footage you are looking for quickly.
Removable HDD with Key Lock
The 500GB HDD is removable for easy access if you need to give footage to the authorities. It is also locked into your system with a key so that unauthorized people cannot remove your HDD.
24/7 Lifetime Live Customer Support
Assistance is available whenever you need it. Our customer support team can be reached by phone 24/7, email or live web chat, so you will always have access to an expert.
Disclaimers
1. Requires broadband router and broadband Internet connection–not included. Internet Explorer® is required.
2. Compatible with BlackBerry® Bold™, Tour™ and Storm™. For an updated list of compatible models please visit www.svat.com
3. Recording capacity may vary based on recording resolution and quality, lighting conditions and movement in the scene. Based on a 500GB hard drive, using lowest quality settings.
4. IR illumination range up to 15ft under ideal conditions. Objects at or beyond this range may be partially or completely obscured, epending on the camera application.
5. Although the cameras are water resistant, they are not waterproof. Cameras are not intended for use in direct exposure to water, rain or snow.
6. USB ash drive, CD/DVD writer, and external hard drive not included.
7. Video playback software is not Mac compatible.
iPhone is a registered trademark of Apple Inc. BlackBerry is a registered trademark of Research in Motion Limited, Internet Explorer is a registered trademark of Microsoft Corporation and Sharp is a registered trademark of Sharp Corporation
Compatible with
OPTIONAL ACCESSORIES
CVW62 (60 ft. Extension Cable)
For more optional accessories, please see the back of the manual or visit: www.SVAT.com
CV503-8CH-19M
5
BUTTONS AND CONNECTIONS
LCD-DVR LEFT SIDE
1. Power Connection: LCD-DVR Power Connection
2. LAN Connection: Connects to Router
3. Mouse Connection: Connection for USB Mouse
4. USB Connection: Connection for USB device
5. Audio Out: Connection for audio device
6. Video Out: RCA video out jacks for spot monitors
7. Power Switch: Power on/o switch
8. External I/O Connect “PERIPHERAL CABLE” here
SVAT ELECTRONICS
now you can see
1
2 5
7
3 4
6
8
1
2 3
4 5
CV503-8CH-19M
LCD-DVR RIGHT SIDE
1. Removable HDD: The Hard Drive is located here for
quick and easy access
2. ON/O: Turns monitor display on / o
3. Menu: Toggles adjustment for monitor
display
4. Up: When changing monitor display, this button increases the value
5. Down: When changing monitor display, this button increases the value
6
BUTTONS AND CONNECTIONS
REMOTE CONTROL
1
2
5
6
8
9
10
3
4
7
11
12
13
SVAT ELECTRONICS
now you can see
1. Numerical Keypad: Buttons 1-8 will display the corresponding camera on full screen
2. All: Switch to quad viewing mode
3. Menu: Access the main menu and exit
the current menu
4. Select/Enter: Allows you to select options
5. Directional Keys: Allow you to navigate through
the menu
6. Audio/Search: Searches and nds any channels that have an audio supported camera attached to it (not included)
7. Mute: Mutes sound
8. Rewind: Rewinds footage
9. Record: Begins recording based on the
24 hour schedule
10. Pause: Pauses playback footage and starts/stops sequence mode
11. Play: Calls up the playback menu
12. Fast Forward: Fast forwards through
playback footage and allows you to navigate the menu to the right
13. Stop: Stops recording and/or playback footage
MOUSE
1
CV503-8CH-19M
2
1. Select: Click this button to select
highlighted object
2. Scroll Wheel: This wheel has no function on
3
3. USB Connection: Connects to the USB mouse
4. Deselect: Pressing this exits the menu
4
this DVR
port on the left side of the DVR
you are in. If you are in live view it will open the sub menu
7
BASIC SETUP
SVAT ELECTRONICS
now you can see
THINGS TO CONSIDER BEFORE INSTALLATION
The camera should be installed between 8 to 13ft above the area to be monitored
Decide whether the camera will be wall mounted, ceiling mounted or sitting on a desk/table top. Before mounting the camera, ensure there is nothing obstructing the camera’s view
Placing the camera in an open, visible area can help deter criminals
To cover large, dark areas such as backyards, garages and driveways, place cameras in locations such as the roof or deck
Ensure that your camera is positioned away from light sources and that the sunshade is properly adjusted to avoid glare
For best viewing results, the lighting in front of the camera should be about the same brightness as the lighting around the area being monitored
Each camera comes with 60ft of video/power wire. If longer wiring distance is required, 60ft extensions can be purchased (DF10W) from your local re-seller or at www.svat.com
We recommend using a surge protected power bar to protect the camera’s internal circuitry
MOUNTING THE CAMERAS
1. Rotate the camera mount so that camera is pointed in the desired position.
2. Screw the mounting bracket into the camera’s mounting hole, turning it clockwise.
3. Mount the camera in the desired location no more than 60 ft from the DVR unless you have purchased additional wiring. You may mount the cameras on a wall, ceiling or desk.
4. Ensure that the cameras are strongly secured into the wall.
5. Adjust cameras to the desired viewing angles.
6. For additional help on mounting the cameras, please see the drilling template, located at the end of the manual.
CV503-8CH-19M
Adjust camera to desired viewing angle
Ensure the camera is secured into place
8
BASIC SETUP
CONNECTING PERIPHERAL CABLE
1. Connect the “PERIPHERAL CABLE” to the jack on the left side of the LCD-DVR named, “EXTERNAL I/O.”
2. With the cable in place, turn the plastic screws clockwise to lock the connection.
3. The “PERIPHERAL CABLE” is where you will connect all of your security cameras, PTZ cameras and alarm system.
WIRING CAMERAS
SVAT ELECTRONICS
now you can see
A
B
C
D
G
H
F
K
L
J
E
INSTRUCTIONS
1. Plug 12V adapter (A) into electrical wall outlet or surge protecting power bar.
2. Plug the single end of the four port power supply (C) into the male end of the 12V adapter (B).
3. Connect the 4PIN DIN female connection on the camera (E) into the 4PIN DIN male connection on the 60ft video power wire (F).
4. Plug the power jack (G) from the 60ft video/power wire into one of the ports of the four port power supply (D).
5. Attach the BNC to RCA connector (L) to the video inputs of the LCD-DVR’s “PERIPHERAL CABLE.” (J)
6. Connect the yellow male RCA plug (H) from the 60 ft cable to the BNC to RCA (K) connector and your “PERIPHERAL CABLE”(J).
7. Repeat the above steps for all of the included cameras.
CV503-8CH-19M
9
BASIC SETUP
CONNECTING ADDITIONAL DEVICES
SVAT ELECTRONICS
now you can see
CONNECTING A USB MOUSE
Connect the included USB mouse before powering on the CV503-8CH. This will speed up the initializing process as well as make the DVR easier to use.
1. Plug the USB connection on the mouse into the top USB connection on the left side of the DVR marked with a mouse icon.
CONNECTING A PTZ CAMERA
The CV503-8CH supports a 2 wire RS-485 connection for a PTZ camera to be connected (PTZ camera not included). Please see the PTZ camera manual for further instructions on required PTZ settings.
To connect a two-wire PTZ camera:
1. With a small at head screwdriver, press down on the plastic RS485 screw to open the port.
2. With the screw pushed down, insert the wire into the wire port.
3. Release the screw to lock the wire in place. Pull lightly on the wire to test for a secure connection.
4. For further instruction on connecting your PTZ camera, please consult the PTZ camera’s instruction manual.
Plug Mouse into USB port
1.
2.
3.
CONNECTING A SPOT MONITOR
The CV503-8CH supports up to two spot monitors in addition to your 19” LCD screen.
To Connect a Spot Monitor:
1. Connect a BNC-to-RCA connector to the video output jack, labeled “VIDEO OUTPUT.” This is located on the left side of the LCD-DVR.
2. Plug the included RCA cable into the BNC connector.
3. Attach the other end of the RCA cable to a yellow RCA video input on your tv/monitor.
CV503-8CH-19M
Plug RCA cable to Video Output
10
GETTING STARTED
POWERING ON DVR
SVAT ELECTRONICS
now you can see
1. Insert the power cord into the power supply.
2. Plug the power cord into a power outlet (surge protected power outlet recommended).
3. Insert the power supply wire into the DC 12V port on the left side of the LCD-DVR.
4. There is a power on/o switch located on the left side
of the CV503-8CH, press this down to turn on your security system. After a few moments, your DVR system will immediately begin recording!
Connect to a power source to turn on DVR
GETTING STARTED
The CV503-8CH is deisgned to be user friendly - you will notice the iMenu bubbles located toward the bottom of your screen which will describe your menu options.
USING THE MOUSE
The included USB mouse makes using the CV503-8CH quick and easy. The mouse functions just like a mouse for a computer - it allows you to click on items to select and change them. To get the most out of your CV503-8CH, we recommend using the mouse.
Note: Ensure that the mouse is connected to the
designated USB port before powering on
SCREEN VIEWING
By double clicking one of the eight camera screens, the viewing mode will switch to full screen mode. Double clicking again will bring you back to quad or eight screen mode (pending on what was set before).
Full Screen
CV503-8CH-19M
Quad Screen
Eight Camera Screen
11
FUNCTION MENU
SVAT ELECTRONICS
now you can see
FUNCTION MENU
The Function Menu can be accessed two dierent ways:
1. Right clicking the mouse.
From the viewing screen, right click the mouse to
access the function menu. As you scroll through the menu with your mouse, you will notice that the option becomes highlighted. Left click to select your desired command or move your cursor away from the menu and left click to close.
2. Pressing select (SEL) on the remote control.
Then use the up and down arrow keys to navigate
the menu. Press “SEL” to select a command or “MENU” to close.
FUNCTION MENU OPTIONS
Main menu
When accessing the Main Menu, you may be prompted for a password. The default password is 123456. For more information regarding passwords, see page 38.
Unlock Menu Prompt
Function Menu
DEFAULT PASSWORD
123456
Video Search
Selecting this prompts the Video Search which allows you to search through recorded footage. For more information, please see Video Search on page 25.
CV503-8CH-19M
12
SHORTCUT MENU
SVAT ELECTRONICS
now you can see
PTZ Camera
Selecting this shortcut opens the PTZ menu (PTZ camera not included). PTZ stands for Pan/Tilt/Zoom. This menu option will only control PTZ cameras properly congured in Device Management. To view instructions on how to congure a PTZ camera, please see Connecting a PTZ Camera on page 10.
The controls for the PTZ camera are as follows:
Slow/Fast: This bar allows you to adjust the speed that
the camera will move
Zoom: Pressing the + zooms in and pressing the –
zooms out
Focus: Pressing the + focuses the picture and
pressing the – takes the focus away. This is useful if an object is either close range or long range and is being displayed blurry
Iris: Pressing the + lets in more light and pressing
the – takes light out of the picture. This is useful for varying lighting situations as well as correcting backlight issues
Cruise Setup: This function allows you to setup preset
positions for the PTZ to follow, the PTZ camera will cruise through your set positions and times. Not all PTZ cameras have this function
Directional keys: Clicking on the directional arrows moves the
camera in the direction of that arrow
To set up cruise:
1. Right click the mouse and open PTZ.
2. Select “Cruise Set”.
3. Select the channel that the PTZ camera is connected to. (The PTZ camera must already be congured).
4. Use the directional buttons to adjust the camera to the places you would like the PTZ camera to view in cruise mode. Press the SET button at each desired position.
5. Click on stop time and set the time (in seconds) for how long you would like the PTZ camera to stay at each position.
6. To review your set points, select the current point you would like to view and click on “go to”.
7. Click “save” and then “exit”.
8. To erase all preset cruise points click on “clean.”
9. To start the PTZ cruise, open the shortcut menu and select “start cruise”. To stop the PTZ cruise, open the shortcut menu and select “stop cruise”.
PTZ setup menu
PTZ Cruise
CV503-8CH-19M
13
SHORTCUT MENU
SVAT ELECTRONICS
now you can see
Start Record
• Selecting this prompts the LCD-DVR to begin manual recording (if it is not already recording). Selecting this
will override any set recording schedule
Stop Record
• Selecting this prompts the LCD-DVR to stop manual recording
Start Cruise
Selecting this option prompts the PTZ cruise to start (if you have congured a compatible PTZ camera). Selecting the cruise option again will stop the PTZ cruise
Start Auto Sequencing
Selecting this option prompts the cameras to sequence through each camera displayed on full screen. This function will only work if you have more than one camera connected. Double click the screen to stop the automatic sequencing. For more information, please see Camera Sequence on page 19
PIP Mode
Picture-in-picture (PIP) allows you to view one camera in full screen and up to two other channels (of your choice) in smaller windows on the bottom corners of your screen. You must have at least two cameras connected to your LCD­DVR to utilize PIP Mode.
Operating PIP Mode:
1. Scroll to “PIP Mode,” once highlighted, two options will appear: “1 X 1” and “1 X 2.”
2. Selecting “1 X 1” will display a second channel in the bottom-left corner of the screen, while “1 x 2” will display a second and third channel on the two bottom-left and right corners of the screen.
3. To select which camera you are viewing in the picture-in-picture, left click the smaller image to cycle through to the desired channel.
4. To exit “PIP Mode,” right click the mouse.
PIP Mode 1x1
CV503-8CH-19M
PIP Mode 1x2
14
SHORTCUT MENU
SVAT ELECTRONICS
now you can see
Digital Zoom
When viewing in full screen mode, the function menu features a “Digital Zoom” option. This allows you to select an area to view more closely.
To zoom in:
1. From the function menu, navigate to and select
“DIGITAL ZOOM.”
2. Left click and hold to drag a square over the area you
wish to zoom in.
3. To exit, right click the mouse.
MAIN MENU
The main menu can be accessed by selecting it from the function menu or by pressing the “MENU” button on the remote control. While navigating the main menu, left click to select and right click to exit. The iMenu will inform you of the details for each option.
Many of the Submenus will Feature the Following Common Options:
1. DEFAULT: This option will restore all settings, on the current screen, to the default settings
2. APPLY: This option will conrm and save all of the adjustments made from this screen
3. EXIT: This button will exit the current screen without saving the adjustments
Main Menu
Note: All sub menus have some or all of the above options.
CV503-8CH-19M
15
MAIN MENU
SVAT ELECTRONICS
now you can see
USING THE KEYBOARD
The keyboard is used when keying in passwords, names, dates and times.
To Operate the Keyboard:
1. Navigate to a desired character and then left click to input your selection.
2. By selecting the “ABC” button the case and type of characters will change. Upper case, lower case and numbers
are the options available.
3. To erase a character select the backspace button ( ).
4. When the desired entry has been nished, select the enter key ( ).
Keyboard(s)
CAMERA SETUP
The camera setup menu allows you to title each camera, adjust where the title will be located as well as conguring the coloring, name and position.
Name
Selecting this option will prompt a keyboard to appear on screen and allow you to type in a title for each camera.
To change the name of your camera:
1. Under the “NAME” column,
navigate to and select the
channel you would like to edit.
2. The keyboard will prompt, input desired title, then select enter.
3. Select “APPLY” to save changes.
CV503-8CH-19M
Camera Menu
16
MAIN MENU
SVAT ELECTRONICS
now you can see
Position
This will determine where the title of the camera will be displayed. Selecting “OFF” will provide no title on screen for desired camera.
To Change the Position of your Camera’s Name:
1. Under the “POSITION” column, navigate to and select the drop down list of the channel’s name you would like to reposition.
2. Select which quadrant of the screen you want that camera’s title to appear.
3. Repeat for all desired cameras.
4. Select “APPLY” to save changes.
Color
Selecting this prompts four adjustable values for each camera: hue, brightness, contrast and saturation.
To Adjust Coloring:
1. After selecting the color option in the “CAMERA SETUP,” navigate to a color setting you would like to adjust.
2. When the desired color setting is highlighted, left click to a location on the line to adjust the settings accordingly.
3. When desired changes have been made, select “APPLY” to save your changes.
Color Setup
Live
This option allows you to turn a camera on or o in live viewing mode. When selected o, the camera will still record but it will not be displayed on screen. This is useful if you have a camera placed in a condential area or if you have a camera location you wish to remain hidden.
To turn the live viewing of a camera on or o:
1. Navigate to and select the “LIVE” drop down list next to the camera you would like to turn on/o.
2. Select “OFF” to prevent live camera display or “ON” to remain live.
3. Repeat for all desired cameras.
4. Select “APPLY” to save your changes.
CV503-8CH-19M
17
MAIN MENU
SVAT ELECTRONICS
now you can see
Time Display
The CV503-8CH allows you to select if you would like the time and date displayed while in live view or while recording.
To Enable/Disable the Time Display:
1. Select the drop down list next to the time display mode you would like to change.
2. Select “OFF” or “ON.”
3. Select “APPLY” to save your settings.
Time Display Options
Privacy Zone
“PRIVACY ZONE” allows you to set up to four adjustable areas per camera that you wish to mask or remain private. When enabled, the desired private location(s) will appear black on the viewing screen.
To Setup Privacy Zone:
1. Select “PRIVACY ZONE” from the Camera Setup menu.
2. Navigate to the desired channel, then, from the “PRIVACY ZONE” drop down list, select the option from “OFF” to “ON.”
3. There will be four check boxes titled “AREA” 1 through 4. Choose how many individual privacy zones you would like to have by selecting the corresponding check box.
4. When the desired amount of privacy zones have been chosen, select “SETUP” to congure the location and size of each zone.
5. Left click, hold and drag the green privacy zone box over the desired area you would like to be made private.
6. To adjust the size of the privacy zone, navigate to the green border of the privacy zone, then left click, hold and drag the box to desired size.
7. When the privacy zones have been set, right click to exit.
8. Select “APPLY” to save settings, then “EXIT” to close.
Privacy Zone Setup Screenshot
CV503-8CH-19M
18
MAIN MENU
SVAT ELECTRONICS
now you can see
Auto Sequence
This option allows you to choose the duration for each camera on the screen while in auto sequencing mode; choose anywhere from zero to ten seconds. You can also choose whether to sequence only channels one through four or ve through eight for a specic duration.
Auto Sequence Menu
To Adjust Automatic Sequencing:
1. Select “AUTOSEQ” from Camera Setup menu.
2. Navigate to and select desired channel and a drop down list, select desired duration.
3. Select “APPLY” to save settings.
RECORD SETUP
This menu option allows you to turn on or o each camera, adjust the video quality, choose a recording mode or decide on the recording segment length.
Channel (On/O)
To turn channels on or o from recording:
1. Select the drop down list next to to
the channel you would like adjusted.
2. Navigate to and select whether or not to record the channel.
3. Select “APPLY” to save settings.
Quality
To change the quality of the recorded video:
1. Navigate to and select the quality level you would like to choose (BEST, GOOD or NORMAL). Selecting “BEST” will
provide you with the best video quality but will also use up the most HDD space.
2. Select “APPLY” to save settings.
CV503-8CH-19M
19
MAIN MENU
SVAT ELECTRONICS
now you can see
Audio Rec.
To turn audio recording On or O:
1. Navigate to and select the drop down menu beside “Audio Rec”.
2. Select which camera you would like the audio to record from and press select.
3. Select “APPLY” to save settings.
Note: Only audio enabled cameras (sold seperately) are able to record audio.
File Size
The DVR allows you choose the maximum length that each recorded video clip will be. This is for backup purposes.
To adjust and/or set a le size:
1. Select the drop down menu beside “File size”.
2. Highlight the time you would like each recorded video clip to be (15, 30, 45 or 60 min) and press select.
3. Select “APPLY” to save settings.
Note: Higher quality and resolution settings use up more space on your hard drive.
Rec. Mode
The CV503-8CH allows you to select if you want continuous recording or to record on a set schedule.
To program your LCD-DVR to always record:
1. Select the drop down list next to “REC. MODE.”
2. Navigate to and select “ALWAYS.”
3. Select “APPLY” to save settings.
To set your LCD-DVR for schedule record:
1. Select the drop down list next to “REC. MODE.”
2. Navigate to and select “TIME SCHEDULE RECORD.”
3. Select “APPLY” to save settings.
Note: The default schedule is set to record on a 24/7 schedule
CV503-8CH-19M
20
MAIN MENU
SVAT ELECTRONICS
now you can see
To customize your record schedule :
The CV503-8CH allows you to set dierent recording schedules and recording types for each individual channel. (Normal record, motion record or no record)
1. From the camera setup menu, ensure that “TIME SCHEDULE RECORD” is selected.
2. Navigate to and select “SCHEDULE.”
To adjust the recording schedule:
1. Select the drop down list titled, “CHANNEL.”
2. Navigate to and select which camera you wish to set a schedule for.
3. Towards the bottom of the screen, navigate to and select the desired recording type. A check mark will conrm your selection.
Alarm record: (Red) Records only when motion is detected
General Record: (Green) Constantly records
No Record: (Transparent) No recording
4. Once the recording type has been chosen, navigate to and select the desired hours for the desired recording type.
5. Repeat as needed for each channel.
6. Once you have set all schedules for the desired cameras, days, times and record modes select “APPLY” to save your settings.
Schedule Menu
Schedule Copy Function
Selecting the “COPY” button will copy one days schedule and use it for other days that you specify. This is useful if you customize a schedule for a particular day and would like to apply the same schedule for other days of the week.
To copy one day’s schedule to another or all other days:
1. Select the start day by opening the drop down list located next to “FROM.”
2. Select the end date that you would like to use the same recording schedule for by opening the drop down list located next to “TO.”
3. Navigate to and select “COPY.”
4. Once you have completed all desired scheduling, select “APPLY” to save settings.
File Size
This option allows you to adjust the duration of your blocks of recordings. You can select to record in 15, 30, 45 or 60 minute blocks of time.
CV503-8CH-19M
21
MAIN MENU
NETWORK SETUP MENU
The network setup menu is your gateway to viewing your footage online. This menu holds the information you need to set up on-line viewing. The DVR is pre-congured to work with most basic network setups and the values shown on the screen are the values you will be using to setup and view the DVR on a computer.
The network setup menu allows you to congure all the settings necessary to view your DVR online. You can congure the way the DVR acquires an IP address, adjust which ports are used to communicate with the DVR, adjust your DNS as well as set your information for a DDNS account.
Type:
Determines how the LCD-DVR will acquire and IP address: DHCP, Static IP or PPoE.
DHCP:
Dynamic Host Conguration Protocol (DHCP) is the most common setup for home or oce networks. This allows the LCD-DVR to automatically acquire an IP address from the router. By default, the IP mode will mode will be set to DHCP.
Network Menu
SVAT ELECTRONICS
now you can see
Static IP: Static IP addresses are manually assigned by the administrator. A static IP
address would be benecial if your internal IP changes frequently.
PPPoE: Used for DSL services where individuals connect to a DSL modem. It is
recommended to store PPPOE information in the router. If the information is not stored in the router, the DSL model will need to be congured. Contact your Internet Service Provider for details on modem conguration.
To adjust the type of IP Mode you are using:
1. Select the drop down menu beside the word TYPE.
2. Highlight the IP Mode you would like to use and press select.
3. Select “apply” to save your changes.
CV503-8CH-19M
22
MAIN MENU
SVAT ELECTRONICS
now you can see
Media Port:
This port is used to initiate communication with the LCD-DVR. The media port is entered at the end of the IP address to connect to the DVR. If using the default port (80), your internet browser will automatically add port 80 to the end of the address even though it may not display it. If using a port other than 80, you will need to add that port to the end of the IP address when typing it into a web browser. (Ex. If using port 2000 and IP address is 192.168.1.69, you would type: http://192.168.1.69:2000 in the address bar.
Web Port:
This port is used for the LCD-DVR to communicate with your network and is required for proper internet viewing.
Media Port vs. Web Port
This DVR requires two separate ports for internet viewing. Most of the communication goes through the Web Port and is used for accessing DVR footage, software and the menu. The Media Port is used to initiate communication to the DVR and serves as a gateway. The Media Port should be left as 80 unless port 80 is being blocked by your Internet Service Provider.
To Change the port you are using:
1. Navigate to and select the drop down list next to the port you would like to change, this will prompt the keyboard to open.
2. Using the keyboard, input desired port number then select enter. The Media and Web ports cannot be the same number.
3. Select “APPLY” to save your changes.
IP ADD:
(IP ADDRESS) The numbers here represent the Internal IP address of your DVR. If your DVR is not properly connected to the router, the address will appear as 0.0.0.0. or “Getting IP. . .”
To Acquire an IP Address:
1. Ensure the IP Mode is set to “DHCP” and that you have connected an Ethernet cable (included) to the jack titled “LAN” on the left side of the LCD-DVR.
2. Once adjusted, select “APPLY” to save changes.
3. Exit the Network Menu, then exit the Main Menu. This will prompt your LCD-DVR to restart and implement the new settings.
Note: The internal IP address is the most important number on the Network Setup Menu screen
and the ports will be used to set up Port Forwarding which is necessary for viewing the DVR outside of the current network.
CV503-8CH-19M
23
MAIN MENU
SVAT ELECTRONICS
now you can see
DNS:
Domain Name System (DNS) is for advanced network setup. DNS is used to convert names into IP addresses. It is recommended to leave these settings as they will be automatically congured by the router.
To adjust the DNS address:
1. Navigate to the DNS address bar, select it to adjust the value.
2. The keyboard will prompt, input the desired address then select the enter key.
DDNS:
Dynamic Domain Name Service (DDNS) allows you to set up a common name for the LCD-DVR instead of typing an IP address. This feature is used if you have a dynamic IP address from Internet Service Provider and the IP address is constantly changing. For setting up a DDNS server, please see page 61.
To setup your DDNS on the DVR:
1. Navigate to and select “DDNS SETUP.”
2. Navigate to and select the “DDNS” drop down list, then select “ON.”
3. Navigate to and select “SERVER.” DynDNS is the default server but you may choose another DDNS provider from the list.
4. Navigate to and select “HOST NAME.” Keyboard will prompt to input host name.
5. Highlight “USER NAME” and press select, the keyboard will appear to input your user name.
6. Navigate to and select “PASSWORD.” Keyboard will prompt to input a password.
7. Navigate to and select “APPLY” to save your settings.
CV503-8CH-19M
DDNS Setup
24
MAIN MENU
SVAT ELECTRONICS
now you can see
VIDEO SEARCH
This option allows you to search through your previously recorded footage organized by date and time. You can access the video search from the main menu, the function menu or by pressing the “PLAY” button on the remote control.
To access and play back footage:
1. Select the channel to view recorded footage from (1).
2. Navigate to and select the date to view footage from, (2) this will prompt a keyboard to input date. Once the date has been inserted, select “SEARCH” (3).
• The calendar will reveal the dates which footage has been recorded on:
• Motion/Alarm recordings are red (4)
• General recordings are green (4)
• If date is neither red nor green, there are no recordings
3. Navigate to the day and select the hour you would like to view footage from (7).
To access and playback footage from a certain time:
1. Select the channel to view recorded footage from (1).
2. Navigate to and select the date to view footage from (2), this will prompt a keyboard to input date.
3. Navigate to and select the time to view footage from (5), this will prompt a keyboard to input time.
4. Navigate to and select “PLAYBACK.”
CV503-8CH-19M
25
Loading...
+ 63 hidden pages
