Svantek SV 103 User Manual

SV 103 USER'S MANUAL________________________________________________________

_

1

SV 

Daily Vibration Exposure Meter

USER’S MANUAL

USER’S MANUALUSER’S MANUAL

USER’S MANUAL

SVANTEK Sp. z o.o.

SV 103 USER'S MANUAL________________________________________________________

_

2

WARSAW, September 2014

Notice: The SV103 instrument contains no user serviceable parts. Opening product case

invalidates the warranty.

Notice: Battery power indicator - To improve accuracy of remaining battery life indicator, run
the instrument until it is fully discharged; then proceed with a full charge via the micro USB port.
The procedure is recommended before first use. Repeat this procedure every few months of use to maintain
more accurate current battery condition indication.

Notice: On account of continuous product improvement SVANTEK reserves the right
to make changes to product specifications without notice. To download the most up to date user's manual
please visit our web site at www.svantek.com.
This user’s manual presents the firmware revision named 1.07.1 (see the Unit Label review to check version
details).
This user’s manual presents some aspects of SUPERVISOR software revision named 1.4.4 (see the
software start-up splash screen).
The succeeding software revisions (marked with the higher numbers) can change the view of some displays
presented in the text of the manual.

WEEE Notice: Do not throw the device away with the unsorted municipal waste at the end
of its life. Instead, hand it in at an official collection point for recycling. By doing this you will help to preserve
the environment.

Trademarks

Microsoft and Windows are registered trademarks of Microsoft Corporation

Copyright © 2014, SVANTEK sp. z o.o.

All rights reserved. No part of this publication may be reproduced or distributed in any form,
or by any means, without prior written consent from SVANTEK, Warsaw, Poland

SV 103 USER'S MANUAL________________________________________________________

_

3

CONTENTS

1

INTRODUCTION 5

1.1 Vibration risk and it’s assessment 5

1.2 SV 103 as a new generation vibration exposure meter 6

2

SV 103 SYSTEM DESCRIPTION 7

2.1 SV 103 key features 7

2.2 Kit components 7

2.3 Related equipment & accessories 8

2.4 Instrument Software (Firmware) options available 8

3

GETTING STARTED 9

3.1 SV 103 control panel 9

3.2 Input output interfaces description 9

3.3 Mounting of SV 103 vibration exposure level meter 10

3.4 LED status indicator 11

3.5 Status bar icons 11

3.6 Manual control of the instrument 11

3.6.1 Primary key functions 12

3.6.2 Alternate key functions 13

3.6.3 Alternate combined keys function 14

3.7 Charging 14

3.8 Turning on/off 15

3.9 Starting and stopping measurement run 16

4

RUNNING AND OPERATING BASIC PROCEDURES 17

4.1 The VIEW mode presentation concept 17

4.1.1 Running RMS view mode 17

4.1.2 Primary “ONE-RESULT” parameters view mode 17

4.1.3 Results for channels view mode 18

4.1.4 OCTAVE analysis spectrum view mode 18

4.1.5 Instrument Status view mode 19

4.1.6 File information view mode 20

4.2 ALARM screen review 20

4.3 Reviewing unit label 20

4.4 Loading Measurement Setups 21

4.5 Calibration and verification of the instrument 21

4.5.1 Calibration the Instrument 22

4.5.2 Verification the Instrument’s calibration 23

4.5.3 Calibration the contact forces transducer 24

4.6 Auto-run mode information 25

4.7 Security lock 25

4.8 Measurement procedures 26

SV 103 USER'S MANUAL________________________________________________________

_

4

4.9 Reviewing measurements 27

5

BASIC OPERATIONS WITH THE PC SOFTWARE 28

5.1 Installing and connecting to PC 28

5.2 Main software window 29

5.3 Instruments inventory panel 30

5.3.1 Manage the instrument options 31

5.4 Configuration setup 32

5.4.1 Working with configuration setup files 32

5.4.2 Measurement parameters settings tab 36

5.4.3 Triggering settings tab 37

5.4.4 Time-history data logging settings tab 38

5.4.5 Display VIEW configuration tab 39

5.4.6 General settings tab 40

5.4.6.1 Security settings panel 41

5.4.6.2 Auxiliary settings panel 42

5.4.7 Auto-Run settings (timer, pauses) tab 43

5.4.8 Signal recording options tab 44

5.4.8.1 Recording on trigger 44

5.4.8.2 Continuous recording 44

5.5 Working with data files 45

5.5.1 Downloading instrument files 45

5.5.2 Local files “Data Browser” 46

5.6 Working with sessions and reporting 48

5.6.1 Force threshold slider 50

5.6.2 Report panels 50

6

SV103 MAINTENANCE 54

6.1 General recommendations for use 54

6.2 Cleaning 54

6.3 Changing the accelerometer 54

6.4 Firmware upgrade 54

6.5 Storing the instrument 55

6.6 Transportation and carrying 55

7

SVANTEK SERVICE 56

7.1 Troubleshooting 56

7.2 Resetting the instrument 56

SV 103 USER'S MANUAL________________________________________________________

_

5

1

INTRODUCTION

1.1 Vibration risk and it’s assessment

During human contact with the surface of the vibrating machine, mechanical vibrations are transmitted
directly to the human body, affecting the individual tissues or even the whole body. Vibration that affects
humans is called human vibration and is divided into whole-body and hand-arm vibration.

In practice, the most dangerous are hand-arm vibrations which can cause pathological changes in the
nervous, vascular (cardiovascular) and osteoarticular system. Hand-arm vibration occurs when one or both
of the upper limbs is in contact with a vibrating surface. Typical sources of such vibration are any kind of
hand tools that generate vibration, steering wheels and levers to control vehicles. The characteristic feature
of hand-arm vibration is their variability in time. Therefore, very often, measurement results depend on the
point in time that measurement takes place. This is a very important feature that defines both the test
methods and measurements describing this kind of vibration. This variability in time influences another
significant factor in determining the body's response to the vibration which is the exposure time (duration of
exposure to vibration).

The fundamental parameter used in the evaluation of hand-arm vibration is the vector sum of tri-axial
vibration called AEQ which is the basis for the calculation of daily exposure A(8). To identify the daily
exposure it is necessary to identify all the sources of vibration, which means identifying all working modes of
tools (e.g. drilling with hammer and without), and changes in the conditions of use of the device. This
information is necessary for the proper organization of measurement and to include as many common tasks
of the operator during which he is exposed to hand-arm vibration. Daily exposure should be calculated for
each source of vibration.

After determining the sources of mechanical vibrations affecting the employee, the next step is to choose the
most appropriate accelerometer mounting. According to ISO 5349, hand-arm vibration should be measured
in place, or at the point of contact with the hand tool. The best location is the centre of the handle which is
the most representative location. ISO 5349 suggests using lightweight sensors to reduce measurement
errors. Measurements directly at the hand are performed using special adapters and measurement in all
three axes is recommended.

Typical vibration exposure consists of short periods in which the operator is in contact with the tool.
Measuring time should include a representative tool operation time and the measurement should start from
the moment the vibrating device is touched and should end when the contact is broken or the vibration stops
(ISO 5349-2:2001).

SV 103 USER'S MANUAL________________________________________________________

_

6

1.2 SV 103 as a new generation vibration exposure meter

SV 103 is the first ever made personal hand-arm Daily Vibration Exposure Meter (DVEM). Instrument meets

ISO 8041 standard and it is an ideal choice for the measurements according to ISO 5349. The SV 103 is
typically attached to the user’s arm. Similarly to noise dosimeters, SV 103 daily vibration exposure meter is
small enough not to interfere with working activities. New technology of SV 107 accelerometer gives
advantages such as shock resistance, no DC offset effect, very low power and frequency response down to
DC. Inside the hand adapter is the latest MEMS accelerometer and a contact force sensor.

Contact forces act between the hand and the vibrating surface: the push/pull force and the gripping force.
Studies on the hand-arm vibration prove that contact forces modify exposure to vibration and the health
effects it causes The need of simultaneous assessment of the contact forces and vibration magnitudes has
been universally recognized and reflected in ISO 15230.

Figure 1-1 Examples of contact forces measurement given by ISO 15230

The high resolution colour OLED screen displays information in both text and graphical form and offers
excellent visibility in dark sites as well as in full daylight conditions.

Using the computational power of its digital signal processor the SV 103 instrument can simultaneously
measure the all results (RMS, Max, Peak, Peak-Peak, Vector, A(8), Dose, ELV, EAV) simultaneously in
three channels and perform real time 1/1 Octave or 1/3 Octave analysis.

Advanced time history logging provides safe and complete information about measured signal in the internal
large 8GB memory.

The instrument is powered from internal new generation Ni-MH rechargeable batteries offering circa 30
hours of continuous operation. The powering and charging of the instrument from the USB interface is
provided which also enables easy data exchange connection between the SV 103 and a PC without the
requirement of a special docking station.

The instrument works with “Supervisor” PC software which allows instrument configuration, measurement
results viewing and exporting as well as daily vibration exposure recalculation.

SV 103 USER'S MANUAL________________________________________________________

_

7

2

SV 103 SYSTEM DESCRIPTION

2.1

SV 103 key features

• Hand-arm Personal human vibration meter conforming to ISO 8041:2005 standard;

• Measurement under gloves

• SV 107 hand-arm triaxial MEMS accelerometer including hand straps according to ISO 5349-2

• OLED colour display with super brightness and contrast

• Large 8GB memory

• USB 2.0 high speed interface

• In order to comply with ISO 5349-1:2001, the input signals from all measurement channels are

frequency weighted with the Wh weighting filters and corresponding Band Limiting filter

• Digital true RMS detector with Peak detection, resolution 0.1 dB

• Frequency Range 1 Hz ÷ 2 kHz

• Measurement range 0.2 ms

-2

RMS ÷ 2000 ms-2 Peak

• Simultaneous measurement results: PEAK, P-P, RMS, AEQ, CExp, A(8), EAVTT, AEVTL, ELVTT,
ELVTL, OVL, Fmax, F_1s, Fave, FUT, TIME

• 3 user configurable measurement channels

• Easy in use predefined setups

• Time-history data logging of PEAK/P-P/RMS/Vector/Force with variable 0.1 s to 1 h logger step for

three channels

• Time-domain signal recording (optional)

• 1/1 Octave or 1/3 Octave real time analysis (option)

• Operational time > 30 hours (display off, octave analysis off)

• Extremely compact, lightweight and robust case with IP65 ingress protection: dimensions 88

mm x 49.5x 19.2 mm, weight 150-160 grams with SV107 accelerometer and one of vibration contact
adapters

2.2

Kit components

• SV 107 – hand-arm triaxial accelerometer for SV 103 instrument including hand straps

• SC 156 - micro USB 2.0 cable

• CD with instruction

• Built-in rechargeable batteries (charger/ power supply wall adapter not included)

The following Figure 3- shows the SV 103 standard set and way of mounting.

SV 103 USER'S MANUAL________________________________________________________

_

8

Figure 2-1 SV 103 standard mounting set

2.3

Related equipment & accessories

Accessories

• SA 54 – Charger/power supply for 1 x SV 103

• SA 156 – USB HUB for charging and data download from 5 x SV103 instruments

• Supervisor Software for configuration, viewing and exporting data, USB drivers (MS Windows XP,

Vista, Windows 7) for 32 and 64 bit operating systems available as freeware

Related equipment and accessories

• SV 111 –Vibration calibrator for in-situ check to ISO 8041:2005

• SA 73 - Carrying case for SV 103 instrument and accessories (waterproof)

2.4

Instrument Software (Firmware) options available

• SF 103 OCT 1/1 –11 band 1/1 Octave real time analysis option

• SF 103 OCT 1/3 –34 band 1/3 Octave real time analysis option

• SF 103 WAV - Time Domain / Wave recording option

Notice: The software options can be purchased in any time as only the introduction of a special

code is required for their activation.

SV 107 hand

-

arm

triaxial

accelerometer

Mounting

accessories

SV 103 USER'S MANUAL________________________________________________________

_

9

3

GETTING STARTED

3.1 SV 103 control panel

The following Figure 3-ure shows the SV 103 controls and ports:

Figure 3-1 SV 103 view

3.2 Input output interfaces description

SV 103 instrument is equipped with a set of useful interfaces:

• accelerometer connector (essential for measuring)

• micro USB connector (charging, and data download)

• charging connector (reserved for future use)

• fast infrared port (reserved for future use)

Figure 3-2 SV 103 side view – accelerometer and micro USB connector

m

icro USB

connector

accelerometer

mounting head

Colour display

128 x 64 pixel resolution

LED status indicator

 AMBER: stop mode

 GREEN: measuring

 RED: alarm

Keypad

SV 103 USER'S MANUAL________________________________________________________

_

10

Figure 3-3 SV 103 back view - charging and infrared port (reserved for future use)

3.3

Mounting of SV 103 vibration exposure level meter

The SV 103 should be attached to the arm of the operator and the accelerometer mounted on the hand.

Figure 3-4 Typical mounting of SV 103 on an operator’s arm

The transducer is supplied with 3 adapters of different shape. Before measurements, select the appropriate
shape adapter to the projected work, and unite it with the transducer using screws. The transducer should be
mounted on the hand with the cable in the direction of the elbow as pictured The cable is to be secured with
a mounting band on the wrist not interfering with working activities.

Figure 3-5 Mounting the adapter on the hand

infrared

port

charging

connector

SV 103 USER'S MANUAL________________________________________________________

_

11

3.4

LED status indicator

There is a three-colour instrument LED status indicator on the SV 103, located to the right
of the accelerometer mounting head and above the display. Błąd! Nie można odnaleźć źródła odwołania.
explains conditions under which the specific LED colour appears.

LED

status

indication

Description

GREEN flashing

once per second

Indicates the

instrument

is running

and has not

exceeded the alarm level.

AMBER

flashing

once per over a dozen seconds

Indicates the

instrument

is stopped

and has not

exceeded the dose alarm level.

RED flashing quickly

,

four times per second

Indicates the

alarm conditions

:

for instance: the dose has exceeded the alarm level.

3.5 Status bar icons

The upper part of the display is designed as basic status information provider. See the description below.

Figure 3-6 SV 103 display icons description

3.6

Manual control of the instrument

Although the Instrument is small, its keypad is designed to be minimal, but still highly ergonomic and easy to
use providing effective operational capabilities. Thanks to that, the number of the control push-buttons of the
instrument is reduced to only three.

Generally the user can operate the instrument by:

- change the VIEW mode with the <ENTER> key

- select the required VIBRATION AXIS with the <AXIS> key

- and SCROLL thru the results with the or keys

Notice: To save power consumption and extend battery life SV 103 will automatically switch off
the display after 30 seconds if no button on the keypad is pressed. The LED indicator will still inform the user
about the current state of operation and any possible alarm conditions. Press any key, to reactivate the
display.

current

VIBRATION

AXIS

LOGGER

activation

indicator

UNDER

-

RANGE

indicator

MEASUREMENT RUN

flashing indicator

BATTERY

STATUS
indicator

incremental

flashing during

charging

CURRENT TIME

when in stopped mode

or

MEASURMENT TIME

during measurement run

.

OVERLOAD

indicator

SV 103 USER'S MANUAL________________________________________________________

_

12

3.6.1 Primary key functions

On the front panel of the instrument the following control push-buttons are located. See below for primary
(short press) key functions description:

Figure 3-7 Control keypad on the front panel – primary key functions

The <SCROLL> or keys allow to:

- scroll down thru results in the RESULTS VIEW modes;

- move cursor left and right in the SPECTRUM VIEW modes;

- scroll down and up thru menu Calibration positions;

- scroll down and up thru setups in the Load Setup menu;

- decrease and increase the values of the Level parameter in the Calibration axis screens;

- reject or confirm Warnings or other confirmation messages.

The <ENTER> key allows to:

- change VIEW modes;

- enter different positions in the Calibration screens ;

- confirm changed parameters (for example, Level parameter in the Calibration axis screens).

The <AXIS> key allows to:

- change presented vibration channels;

- escape from Load Setup and Calibration screens.

<SCROLL> key

.

<SCROLL> key

<ENTER> key

<AXIS> key

SV 103 USER'S MANUAL________________________________________________________

_

13

3.6.2 Alternate key functions

Alternative long press of single key (keypad icons marked with red colour) allows quick access to special
functions:

- POWER ON/OFF the unit by holding down the <ENTER> key

- Calibration menu activation by holding down the <SCROLL>

key

- LOCK keypad and screen by holding down the <SCROLL> key

- SETUP loading by holding down the <AXIS> key

Figure 3-9 Control keypad on the front panel – alternate key functions

Holding down individual key for few seconds a countdown is displayed. If you release the key too early,
SV 103 returns to the last used VIEW mode and the selected control is not executed.

<SCROLL> key

Enter Calibration
menu

<SCROLL> key

LOCK ON

the keypad and screen

<ENTER> key

POWER on/off

<CHANNEL

> key

Enter Load Setup

screen

SV 103 USER'S MANUAL________________________________________________________

_

14

3.6.3 Alternate combined keys function

Additionally, combined short press of two keys simultaneously allow quick access to even more

functionalities:

- Start/Stop measurement by pressing the <SCROLL> and

keys simultaneously

- Enter Pause screen by pressing the <ENTER> and <SCROLL>

keys simultaneously during the measurement run

- Enter Units screen by pressing the <SCROLL> and <AXIS>

keys simultaneously

- Enter Unit Label screen by pressing the <AXIS> and

<ENTER> keys simultaneously

3.7 Charging

SV 103 instrument is equipped with an internal charger, so that the fixed internal batteries can be charged

directly from USB port or optionally provided charger (SA 54).

Ensure the SV 103 is fully charged prior to use by connecting it to a USB port or to USB charger. Ensure the
power supply is connected and the supply is switched on. The SV 103 will automatically switch on during
charging and display how much charge is within the instrument. The SV 103 will display ‘Fully charged’ once
charging is complete. This should take approximately 6 hours from a fully discharged state. A charging time
of about 2 hours will be sufficient to perform greater than 8 hours of measurement. A fully charged
instrument holds enough charge to run for approximately 30 hours.

Note that once disconnected from USB power supply, the instrument will automatically switch off. If returned
to the USB connection or put again onto the docking station the instrument keeps trickle charging regardless
of whether or not it is fully charged. This keeps the battery performance in steady condition. If the battery is
fully discharged prior to being placed on a charger, the SV 103 trickle charges for a short time prior to the
fast charge cycle, this prevents damage to the batteries.

Notice: To charge a fully discharged battery, it would take approximately 4-6 hours. Note also, that
instrument under charging condition is slightly warm. It is normal state for NiMH type cells and does not
affect the measurement accuracy.

SV 103 USER'S MANUAL________________________________________________________

_

15

Notice: To charge multiple units at the same time via the USB port, ensure your computer or
possibly the powered USB hub such as the SA 156 or switch is capable in terms of providing enough current
performance. Standard hub or switches without external power supply are not capable to charge multiple
SV103 units due to insufficient current supply.
Current estimation: Assume the current consumption on 0.2A level, and calculate required power supply
requirement (N x 0.2A).
Power wattage estimation: With nominal voltage of 5V per USB, the power supply wattage should be 1.0W
per unit (Nx1.0W).
For example 5 units charged at once require: 1.0A/12.5W USB power supply
For example 3 units charged at once require: 0.6A/7.5W USB power supply
For example 1 unit charged alone requires: 0.2A/2.5W USB power supply

Notice: Use only high quality USB cables. Many poor quality cables do not ensure low resistance
of the cable, thus disabling proper charging of the internal cells.

3.8 Turning on/off

TURNING ON: To switch the power on the operator should hold the <ENTER> key for a couple of

seconds. The instrument switches on and goes the self-test routine (during this time the manufacturer's logo,
the name of the instrument and firmware version is displayed).

Then the SV 103 will enter the stopped (ready to measure) mode and enter the running instantaneous RMS
mode if enabled.

Notice: Warm up time - After power on, the instrument should be warmed up for at least
60 seconds before starting measurement.

Notice: If you leave the instrument in stopped (ready to measure) mode, the display will be
switched off after 30 seconds, and the unit will turn off after some period of no keypad activity to save the
batteries. The above mentioned period can be program and is set up for 1 hour by default.

Notice: SV 103 will show a warning screen if the battery capacity is below 2 hours of
potential measurement time.

TURNING OFF: To shut down the unit the operator should hold the <ENTER> key for a couple

of seconds during which a countdown (“Shutting down” 3 2 1 ) is displayed. Thus, the SV 103 gives
you time to decide if you really want to turn off the instrument. If you release the key too early, the SV 103
returns to the last presented VIEW mode.

SV 103 USER'S MANUAL________________________________________________________

_

16

If enabled in the configuration setup there may be presented an additional,
double-check, warning screen. This is for the operator to be aware and
convinced the unit is really to be turned off.

Notice: If auto-run (timer) mode is active, SV 103 will automatically stop the measurement when
the set time is over and then turn off. If no auto-run mode is used and specific time has not been preset, the
unit will continue to measure until the battery is exhausted. Just before switch off, the measurement run will
be stopped and all data until that point will be saved securely for later download to the PC.

3.9 Starting and stopping measurement run

START:

Before starting a measurement ensure that:

1 the instrument is turned on,
2 there is sufficient battery operating life and free memory by checking the status screen,
3 the required configuration setup selected,
4 the SV 103 is calibrated, because it affects the results.

To start the measurements the user has to press the <SCROLL> and keys at the same time.
The results of the measurement are displayed in the last used result’s display view mode. One profile mode
is always available for most Functions of the instrument. The results of the measurements can also be
presented in other display modes, which can be enabled or disabled and adjusted to the user’s needs.

STOP:

The same combination of keys: <SCROLL> and allows the user to stop the measurement run.
All run results are always saved automatically, there is no need to save them manually.

After stopping the measurement run, make sure that:

1 the data to PC for further analysis is download,
2 the instrument turned off.

SV 103 USER'S MANUAL________________________________________________________

_

17

4

RUNNING AND OPERATING BASIC PROCEDURES

4.1 The VIEW mode presentation concept

Such an advanced vibration instrument as the SV 103 offers a large amount of parameters for the operator
to inspect. Therefore all information is divided in neatly organized manner as VIEW modes for each channel.

The VIEW mode is a way in which the measurement parameters are presented to the operator. In other
words, when you change the VIEW mode, specific measurement parameters and status information will be
presented in different manner as distinct screen content.

SV103 features the following VIEW modes, where most of them can be individually disabled:

 Running RMS for three channels view mode
 Primary “one-result” parameters view mode - cannot be disabled
 Results for channels list view mode
 1/1 and 1/3 Octave analysis RMS spectrum view mode
 1/1 and 1/3 Octave analysis spectrum MAX view mode
 Instrument Status view mode
 File Information view mode

4.1.1 Running RMS view mode

Running RMS presentation mode is used when measurement run is not actually running, that is when the
instrument is in standby mode before or after a measurement. In this mode the current RMS results for all
channels are calculated and displayed, but not stored in the instrument's memory. The purpose of this
information is to give the user a first indication of the vibration levels about to be measured. The instrument
behaves as a simple general purpose vibration level meter in this view mode.

Figure 4-1 Running RMS view mode screen

4.1.2 Primary “ONE-RESULT” parameters view mode

The one result mode is always available in all measurement modes, and cannot be disabled. In one result

mode any measurement result, selected via <SCROLL> or key, may be presented. The user

may change the actual channel view by pressing <AXIS> key. This view mode is useful if in low vision
conditions or is suitable for operators with some visual impairment.

Detector type: RMS;

W

eighting filter:

Wh,..

Measured value and units

Axis: X, Y,

Z

Real time

Force bar indicator

SV 103 USER'S MANUAL________________________________________________________

_

18

Figure 4-2 Primary parameters view mode screen

4.1.3 Results for channels view mode

To get information about a number of results at one time it is handy to switch to the “results list” view mode.
Up to three parameters at a time are accessible for the operator.

Figure 4-3 Results list view mode screens

4.1.4 OCTAVE analysis spectrum view mode

If enabled, the instrument operates as a 1/1 or 1/3 octave band real time analyser (RTA). In addition and if
enabled, 1/1 or 1/3 octave analysis is performed in parallel with the exposure level meter operations. All 1/1­octave digital pass-band filters (with 11 centre frequencies from 1 kHz down to 1 Hz; in base two system) or
1/3-octave digital pass-band filters (with 34 centre frequencies from 1.6 kHz down to 0.8 Hz; in base two
system) are working in real-time with the RMS detector for all three channels.

Notice: The two overall TOTAL RMS results are measured with the weighting filters (Wh and
BL(Wh)) without taking into account the settings of the instrument for channels. The spectra are always

linearly averaged.

The results of 1/1 and 1/3 Octave analysis (so-called spectrum) can be examined by the user on a display
in Spectrum VIEW presentation mode. 1/1 and 1/3 Octave spectra for all centre frequencies of pass-band
filters together with the 2 total overall values measured with the Wh and BL(Wh) frequency weighting filters
are presented in the Spectrum mode if enabled in configuration setup. Spectrum cursor can be moved left

and right with <SCROLL> , <SCROLL> keys respectively.

weighting filter

parameter units

channel name

p

arameter value

measured parameter name

Channel name: X, Y, Z

Measured value and units

Measured function for c

hannels

Real time

SV 103 USER'S MANUAL________________________________________________________

_

19

Figure 4-4 1/1 and 1/3 Octave analysis spectrum graph RMS view mode screens

Figure 4-5 1/1 and 1/3 Octave analysis spectrum graph MAX view mode screens

4.1.5 Instrument Status view mode

Instrument Battery view presents:

• the battery charge status

• estimated working time which is Left until the battery is expected to be completely drained

• and current Setup information

Instrument Battery screen is moved down and up with <SCROLL> and keys respectively.

Figure 4-6 Instrument Battery view mode screens

Notice: Battery state of charge calculation is based on internal charge counter and should be
considered only as an overall, not very precise, determined estimation. Therefore the time left could be
noticeably different. Although the newest technology cells are used the slight degradation over time
is inevitable thus aging requires occasionally factory based (or authorised service centre) replacement of the
rechargeable battery cells.

Notice: Battery power indicator - To improve accuracy of remaining battery life indicator, run the
instrument until it is fully discharged; then proceed with a full charge via the micro USB port or docking
station. The procedure is recommended before first use. Repeat this procedure every few months of use
to maintain more accurate current battery condition indication.

current

centre

frequency

value of the

spectrum
at cursor
position

weighting

filter

cursor

SV 103 USER'S MANUAL________________________________________________________

_

20

4.1.6

File information

view mode

Instrument File information view presents current file name and size.

4.2 ALARM screen review

Apart from simple LED alarm indications (see chapter 0) there are a two alarm
conditions (EAV and ELV), when ALARM presentation screens will appear.
During a measurement run the SV 103 will immediately turn on the display at
the time that the programmable alarm condition is exceeded. Press any key, to
confirm the information.

Notice: At any time when battery power is almost exhausted the “low battery” alarm screen may
inform you about immediate recharging requirement.

4.3 Reviewing unit label

Unit Label screen is accessed by pressing the <AXIS> and <ENTER>

keys simultaneously and provides information about elementary

instrument properties such as:

• Copyrighted manufacturer name: SVANTEK

• Instrument name: SV 103

• Unit serial number: SN 

• Accelerometer serial number: SN(SV107) 

• Unit name: John_Smith [user programmable name]

• Firmware v ersion: 1.06.02

• CRC(OK): BBB8

• Standards list, that instrument conforms to ISO 8041:2005

Unit Label screen is moved with <SCROLL> or keys.

To exit the Unit Label screen just short press the <ENTER> or <AXIS>

key. Then SV 103 will return to the last presented VIEW mode.

Notice: The personalized Unit Name can be set arbitrarily with SUPERVISOR software.

SV 103 USER'S MANUAL________________________________________________________

_

21

4.4 Loading Measurement Setups

Press and hold <SCROLL> key. The “Load
Setup” menu will appear with the list of loaded

configuration setups to choose.

To abandon setup selection, press the <AXIS> key. Otherwise select the

required configuration setup with <ENTER> key navigating thru the list

with <SCROLL> or key.

The following screen will appear, that will allow you to confirm you really want
to load the selected setup or cancel the selection and return to configuration
setup list.

Press <SCROLL> key to cancel the setup loading, or <SCROLL>
key to confirm loading selected setup configuration.

Confirming the loading of configuration setup leads to the screen with status of
the loading procedure.

After successfully setup loading it is possible to return back to list of predefined setups by pressing the

<SCROLL> key, or go further to measurement screen by pressing the <SCROLL> key.

4.5 Calibration and verification of the instrumentBłąd! Nie zdefiniowano zakładki.

Three levels of performance testing are defined in ISO 8041:2005 International Standard:

a) Pattern evaluation (targeted at manufacturers): A full set of tests, to be performed on samples of an
instrument type. Pattern evaluation may be used for product type testing or pattern approval of vibration
measuring instruments. The objective of these tests is to demonstrate an instrument design can meet the
specifications defined in this International Standard.

b) Periodic verification (targeted at manufacturers and users): An intermediate set of tests to be
performed periodically (e.g. prior to, or at the time of purchase, and every 1 or 2 years thereafter) to verify
that the performance remains within the specifications of this International Standard, to demonstrate that
one-off instrument systems comply with the requirements of this International Standard, and following
modification or repair that may affect the performance of the instrument.

c) In-situ check (targeted at users): A minimum level of testing, indicating that an instrument is likely to
be functioning within the required performance specification. These tests shall be carried out immediately
before and after measurements are made.

The SV 103 instrument is offered with the dedicated SV 107 hand-arm accelerometer. It makes the
calibration very easy by direct usage of commonly available vibration calibrators. The instrument is factory
calibrated with the supplied accelerometer.

The

SV 103

instrument is equipped with both periodic verification

(By Measurement calibration) and in-situ check (System Check) functions,
which can be run from the Calibration menu. The Calibration menu is opened

by holding down the <SCROLL> key.

SV 103 USER'S MANUAL________________________________________________________

_

22

Notice: The manufacturer’s recommended factory calibration interval is every 12 months for this

instrument to be confident in its continuing accuracy and compliance with the international specifications.
Please contact your local SVANTEK distributor for further details.

4.5.1 Calibration the Instrument

To calibrate the instrument the user has to perform next steps:

1. Select

By Measurement

position in

the Calibration menu and press the

<ENTER> key, select the
appropriate channel (axis X, Y or Z)

and press the <ENTER> key
again.

2. Adjust the actual calibration level of the calibrator to be used with the

<SCROLL> or keys. The Factor position demonstrates the
current calibration factor.

3. Mount the calibration adaptor on a shaker table.

4. Mount the accelerometer on calibration adaptor and tighten it up with screw

5. Switch on the calibrator and wait ca 30 seconds for its stabilisation before starting the calibration
measurement

6. Start the calibration measurement by pressing the <ENTER> key.
Delay before starting calibration measurement is counted down on the
display.

The calibration measurement lasts minimum 30 second and stops until
the same result is obtained 3 consecutive times. It is possible to stop the

calibration measurement by pressing the <AXIS> key. After the
measurement, its result is presented on the display.

It is recommended to repeat the calibration measurement a few times. The obtained results should be
almost the same (with ±0.1 dB difference). The reasons for the unstable results are as follows:

• the calibrator is not properly attached to the instrument

• there are external vibration disturbances

• the calibrator or the measurement channel is damaged.

7. Press the <ENTER> key in order
to accept the measurement result.

SV 103 USER'S MANUAL________________________________________________________

_

23

Notice: If a calibration factor does not meet tolerance criteria
the unit informs the user and proposes to exit the calibration
measurement without saving its results.

Post calibration. If enabled, the post processing is performed automatically under acceptance of calibration
measurement.

Notice: If it is required to perform so called post-calibration of the instrument (in case the
Post Calibration is pre-programmed within configuration setup) the SV 103 automatically adds the calibration
factor to the header of the result files. This doesn’t modify the saved results and gives the user to possibility
to compare the possible changes of accelerometer sensitivity before and after the measurements.

Notice: The calibration factor is always considered in all instrument’s function (like
1/1 Octave or 1/3 Octave analysis).

4.5.2 Verification the Instrument’s calibration

To check (verify) the calibration factor the user has to:

1. Select

System

Check

position in the

Calibration menu and press the

<ENTER> key, select the

appropriate channel (axis X, Y or Z)

and press the <ENTER> key
again.

2. Adjust the actual calibration level of the calibrator to be used with the

<SCROLL> or keys. The Factor position demonstrates the
current calibration factor.

3. Mount the calibration adaptor on a shaker table.

4. Mount the accelerometer on calibration adaptor and tighten it up with screw

5. Switch on the calibrator and wait ca 30 seconds for its stabilisation before starting the calibration
measurement

6. Start the measurement by pressing the <ENTER> key. Delay before
starting measurement is counted down on the display.

SV 103 USER'S MANUAL________________________________________________________

_

24

The measurement lasts minimum 30 second and stops until the same
result is obtained 3 consecutive times. It is possible to stop the

measurement by pressing the <AXIS> key.

After the measurement, its result is presented on the display. The user
can now check if the result of the measurement is close enough to the
calibration level.

7. Press the “Exit” in order to return to the System Check screen.

4.5.3 Calibration the contact forces transducer

This calibration should be performed every time the SV 107 hand straps are changed. As reference
calibration level unit the user may use simple bathroom scale.

Figure 4-7 Using bathroom scale as reference level for contact force calibration

To calibrate the contact force transducer the user has to:

1. Select

Calibr.

Force

position in the

Calibration

menu and press the

<ENTER> key.

2. Execute the command of application of
contact force in the range 18-20kg and press
“Done”.

3. Input the contact force displayed at the
reference unit with the “Level+” or “Level-“
buttons and press <Enter> to accept and go
to the next step.

SV 103 USER'S MANUAL________________________________________________________

_

25

4. Execute the command of application of
contact force in the range 9-10kg and press
“Done”.

5. Input the contact force displayed at the
reference unit with the “Level+” or “Level-“
buttons and press <Enter> to accept and go
to the next step.

6. Be sure that there is no any contact force
and press “Done”.

7. The user may check the contact force
measurement and accept or reject it.

8. In case of acceptation new contact force calibration factor is saved.

4.6 Auto-run mode information

Note, that when auto-run mode (timer and/or pause) is configured, there is information on the screen
available for the user. There is no need to turn on the instrument manually. All the timer procedures can be
easily pre-programmed with the use of the SUPERVISOR software.

Figure 4-8 Auto-run mode – timer and programmable pause screen

4.7 Security lock

Locking the keypad and display during the measurement serves to prevent from tampering with the
measurement run. That automatically prevents any tampering, but the unit can still be unlocked if necessary
with proper sequence of key presses.

The programming of lock/unlocking function of the instrument can be done via the SUPERVISOR software
(see chapter 5.4.6 General settings tab).

Locking SV 103 unit:

The SV 103 can be set up to automatically go into locked mode when it starts. For this purpose the
“Lock During Measurement” position in the SUPERVISOR software should be set to On.

It is always possible to lock the instrument manually. In this case the user should hold the <SCROLL>
key for a couple of seconds during which a countdown (“Keyboard lock” 3 2 1) is displayed and the unit

SV 103 USER'S MANUAL________________________________________________________

_

26

gives you time to decide if you really want to activate security lock. If you release the key too early, SV 103
returns to the last presented VIEW mode.

Unlocking SV 103 unit:

There are two ways for unlocking the instrument, which can be programmed via the SUPERVISOR software.

If “Unlock on Key” position in the SUPERVISOR programme is set to Off, SV 103 can be unlocked without

providing Lock/Unlock sequence. Simply hold the <SCROLL> key for a couple of seconds during which
a countdown (“Keyboard lock” 3 2 1 ) is displayed.

If the “Unlock on Key” position in the SUPERVISOR programme is set to On, SV 103 can be
locked/unlocked by providing Lock/Unlock keys sequence.

To unlock the unit the user has to press the keys in the correct sequence.

Figure 4-9 Unlocking the unit sequence screens

4.8

Measurement procedures

Preferably, when taking measurements, the vibration instrument should be attached to the employee at the
start of a shift and collected at the end of the whole shift. In case a shorter period is sampled then care
should be taken to ensure that the result is representative of the full shift exposure. Shorter sampled periods
require that the sampler has a deep and full understanding of the expected working tasks during the shift and
the duration cycles of those tasks.

Before performing any vibration measurements, ensure that employees selected for evaluation are operating
equipment or performing tasks under normal (representative) conditions, and emphasise the importance of
continuing to work in their usual manner (wearing the instrument should not interfere with normal duties).
Explain the purpose and procedures of sampling to the employee who will be wearing the instrument and the
importance of not touching, tapping or interfering with it. Instruct the employee not to remove the instrument
unless absolutely necessary.

The general procedure for taking measurements could be as follows:

1. Check that the indicated instrument battery life is at least twice the time required for the measuring
period.

2. Check the instrument setup mode is appropriate and change if necessary.

3. Check the calibration of the instrument and adjust the settings if required.

4. Secure the instrument onto the employee’s arm selected for sampling.

5. Start the recording session manually if it is not programmed for an automatic timed start.

6. At the end of the measurement period, stop the recording session, and remove the instrument from
the employee.

7. Follow your organisation’s specific procedure for personal vibration exposure recordings analysis.

8. Ensure the report is submitted to the appropriate person

9. Distribute copies of vibration exposure recordings to test participants and explain the results.

SV 103 USER'S MANUAL________________________________________________________

_

27

4.9 Reviewing measurements

Most of the results can be inspected in real-time during either measurement run or stopped mode of
operation. If the display screen is turned off just press any key (but watch notice below).

The keys on the keypad of the instrument enable you to navigate thru most of the parameters. For specific
information on the VIEW modes.

• Use the <SCROLL> or keys to move thru the measurement results

• Use the <AXIS> key to change the channel you would like to inspect

• Use the <ENTER> key to change the VIEW mode

Notice: In most cases the keypad will be probably locked. To gain access to the results and unlock

the keypad see chapter 4.7.

Notice: After reviewing results remember to lock the keypad again in order to maintain the integrity

of the measurement run by preventing uncontrolled access to the instrument.

SV 103 USER'S MANUAL________________________________________________________

_

28

5

BASIC OPERATIONS WITH THE PC SOFTWARE

This chapter explains data storage, the configuration setup of the instrument, and how to customize
the parameters via the “Supervisor” PC software.

With use of micro USB cable, software, and SV 103, it is easy to:

• set up required configuration parameters and download these, so called SETUPS, straight to the
SV 103 instrument

• retrieve time history data to view and analyse your vibration recorded charts, graphs, with extended
reporting functionality.

Notice: In case of detailed description of the Supervisor software functions, please refer to

the Supervisor user manual.

5.1 Installing and connecting to PC

Insert the Supervisor software CD/DVD into your PC and run the installation program.
After installation we are ready to connect the SV 103 instrument.

• Plug the USB cable into the computer

• Plug the opposite end of the cable (micro USB) into the instrument itself

• The SV 103 is powered and charged directly through the computer; thus, you do not need separate

charger. The instrument screen will be switched on automatically with current charging information
only

• Turn on the instrument - long press of the <ENTER> key

• The user should install drivers for Svantek instruments if not previously installed

• Once switched on, run the Supervisor software.

Figure 5-1 Supervisor splash screen

Notice: Supervisor software enables communication with multiple instruments. Therefore, with the

use of a USB hub such as the SA 156 it is pretty straightforward to connect all of them at the same time.

SV 103 USER'S MANUAL________________________________________________________

_

29

5.2 Main software window

The main screen of the SUPERVISOR is divided into few panels. Panels expose areas of interest
of professional users and satisfy user’s needs to find, configure, download, review and assess stored data
in a very simple but still professional way.

• Control panel enables you to select: Instrument control, Data browser or Session you work with

• Instrument filter enables SV 103 device selection, or other Health and Safety dedicated instruments

• Inventory panel detects all SV 103 connected devices (see chapter 5.3)

• Quick access file manager enables you to copy configuration setup files between computer and

instrument internal memory (see chapter 5.4.1)

• Instrument configuration panel enables access to all measurement run configuration settings
(see chapter 5.4.1 for details)

Figure 5-2 Supervisor main window

instrument

filter

setup files

manager

Instrument

configuration
panel

inventory

panel

control

panel

SV 103 USER'S MANUAL________________________________________________________

_

30

5.3 Instruments inventory panel

Click the SV 103 big instrument icon in the left “Instrument filter” Panel (see

Figure 5-2) to get access to the devices.

Inventory panel (Figure 5-3) enables you to see all currently connected, or previously connected instruments
of the same type. There are a number of columns with information related to each particular instrument
related to the correct allocation of instrument and calibrator calibration report details.

configurable

columns

right click
on top menu row

“Settings”

configure setup files and the instrument”

“Download”

download measurement data from the device

small clock update icon button

SV 103 USER'S MANUAL________________________________________________________

_

31

Figure 5-3 Inventory panel and its capabilities

There are two control buttons near the Inventory Panel top menu:

- Settings button enables to configure current local configuration file, that can be later uploaded to

the SV 103 instrument;

- Download button enables to navigate and download files directly from the instrument.

Notice: To download any setup, or data file, first click the row related to the chosen instrument.

5.3.1 Manage the instrument options

The user may add new purchased options or functions to the instrument. For this purpose it is necessary to
know the activation code. Once the activation code is submitted the customer should follow the next steps to
activate the new function:

- right click on the Instrument row and select the Manage options/functions position in the list,

- in the Manage instrument options/functions window select your option and click on Unlock button

- key in the code in the opened Enter code: window and press Ok

possible context

operations

right click on instrument row

SV 103 USER'S MANUAL________________________________________________________

_

32

- the unblocked function is now enabled in the instrument current Settings

Notice: The above algorithm unblocks the function in the instrument, but not switches it on. To be
able to change settings of newly unblocked function the user has to download the current Settings file from
the instrument to the computer, select the new function and appropriate settings and upload new Settings file
to the instrument.

5.4 Configuration setup

Customizing and saving set-ups are performed via the Supervisor. The following sections discuss each of
the setup screens and explain how to save and send the parameters to the multiple instrument(s).

Settings described here apply to the type SV 103 model. If you are also using other instruments and have
them connected, they will appear in the Inventory section panel, but no device will appear unless you first
select the appropriate model picture on the left side of the application in instrument filter section. The clicked
instrument picture denotes that the models are selectable from inventory panel when setup changes are
applied and the “send setup to instruments” is selected.

To gain access to settings window click the “Settings” button near the Inventory panel (see chapter 5.3)

5.4.1 Working with configuration setup files

The idea behind the configuration setup is to download the configuration setup file from the instrument to the
computer you are working on and referred as “Local files” destination. Then it is possible to modify the
settings, and save with a custom name.

SV 103 USER'S MANUAL________________________________________________________

_

33

Figure 5-4 Setup files manager panel

For example: To download current settings file from the SV 103, modify it, save with custom name, send
it back to the device, export the setup to USB flash memory, and make sure the uploaded settings
are applied in the instrument follow the presented procedure described below:

Once connected and selected in the inventory panel (Figure 5-3) SV 103 instrument is ready for
the operation:

1. Select the “Settings” row position in left side panel named “Instrument files” (Figure 5-4)

2. Click the right arrow pictogram to download instrument “Settings” configuration setup to “Local

files” right side panel (Figure 5-4)

Select the just copied “Settings” with a click: this will display quite a few configuration tabs

on the right side so called Instrument configuration panel of the main Supervisor

window (

upload

selected
setup file

download

selected setup file
or current
Settings

list of setup files

that are in
instrument
internal memory

list of setup files

saved in local
database

SV 103 USER'S MANUAL________________________________________________________

_

34

3. Figure 5-2)

4. Go through all the tabs to verify, or change required parameters of the measurement runs.

Follow the chapters from Błąd! Nie można odnaleźć źródła odwołania. to 0 to understand and
configure the instrument

5. Once configured, come back to setups file manager (Figure 5-4) and click the just edited “Settings”
in “Local files” panel

6. Next click the “save” button in bottom area of the panel (Figure 5-4)

7. To change the name right click on the selected row, and choose “Rename” command, which
enables you to input a custom name for the setup that has just been edited (see the figure below)

8. To export the setup file right click again on the selected row to open context menu and select the
“Export” command (see the figure below). This will open standard save file window, where you can
choose the USB flash memory disk, and save the configuration file to use on a different PC. Note, it
is also possible to import the previously saved settings file to re-use a created setup configuration.

Figure 5-5 Exporting the configuration setup file

9. Now it is time to upload the configuration back to the instrument. Just click the left arrow pictogram.

10. Once copied select the copied file in the Instrument files, and right click onto it to open context menu.
Then choose “Apply” command (Figure 5-6). Alternatively you can enter the “Load Setup” menu
directly in the instrument and load it as the current configuration. See chapter 4.4 for details.

upload

selected
setup file

SV 103 USER'S MANUAL________________________________________________________

_

35

Figure 5-6 "Instrument files" panel and context commands

11. This ends the procedure. Disconnect the instrument and the instrument is now ready for a new
measurement run using the settings you have just uploaded.

Notice: During configuration there are quite a number of parameters to set. To understand detailed

meaning of parameters and how the results are calculated refer to Appendix D and check the following by
chapters.

SV 103 USER'S MANUAL________________________________________________________

_

36

5.4.2 Measurement parameters settings tab

The main settings where specific vibration configuration can be set are located under “Dosimeter” tab. There
are already predefined pre-set fields with grey text. Others fields must be setup by the user.

Within the Dosimetry tab you can choose in which mode of operation the SV 103 should work: Dosimeter,
or Dosimeter with 1/1 or 1/3 octave analysis.

Notice: Enabling octave analysis shortens battery life, so take it into consideration and double

check the battery status before measurement run.

Figure 5-7 Dosimetry configuration setttings tab

Other basic parameters configuration is per figure provided below:

• The Start Delay parameter defines the delay period from the moment the <Start/Stop> button is
pressed to the start of the actual measurements (the digital filters of the instrument constantly
analyse the input signal even when the measurement is stopped). This delay period can be set from
0 second to 5 minutes.

• The Start Sync. parameter defines maximum delay period from pressing the <Start/Stop> button to
the start of the measurements to allow synchronisation with the instrument’s RTC. The Start Sync.
parameter can be set as: Off, 1m, 15m, 30m and 1h. For example, if 1h was selected, then each
measurement starts from the first second of next real time hour after pressing <Start/Stop> push­button, and then each hour after Integr. Per, if Rep. Cycles is greater than one.

• The Integration Time parameter (integration period) defines the period during which the signal is
being measured (integrated) and stored as the set of Summary Results.

select

measurement
mode of
operation

SV 103 USER'S MANUAL________________________________________________________

_

37

• The No. of Measurements parameter defines the number of cycles (with the measurement period
defined by Integration Time) to be performed by the instrument. The No. of Measurements
number values are within the limits [1, 1000] of infinitive (Inf.).

• The Standard parameter defines the limits of Exposure Action Value (EAV) and Exposure Limit
Value (ELV) for the measurements of the hand-arm vibration, which are obligatory in: England,

German, France, Italy and Poland. It is possible to define also User limits.

• The Exposure Time parameter defines the desired value of the workday exposure time that is used
for the calculation of the hand-arm Dose results.

• The Alarm parameter defines whether to set the alarm for EAV or/and ELV.

• The FL+threshold (Force under threshold) parameter defines total time during the measurement

when the grip strength is less than the value defined in this position.

5.4.3 Triggering settings tab

To enable triggering measurement and logger go to the “Triggering” settings tab and switch on these
functions by selecting triggering Mode: Slope+, Slope-, Level+ or Level-.

Figure 5-8 Triggering settings tab

The Measure Trigger position activates or deactivates the measure trigger function. The Logger Trigger
parameters define the way the measurement results are saved in the logger.
If Slope + is selected, the measurement starts when the rising result value (Source) passes above the level
determined by the selected decibel Level. If Slope – is selected, the measurement starts when the falling

SV 103 USER'S MANUAL________________________________________________________

_

38

result value (Source) passes below the level determined by the selected decibel Level. The measurement is
stopped when the conditions set in the General Settings sub-list are fulfilled or after pressing the
<Start/Stop> push-button or after receiving the proper control code remotely.

If Level + or Level – is selected for the measurement or logging the triggering condition is checked every 1
millisecond. The measurement or logging is recorded only when the result value (Source) has the greater /
lower level than that determined in the Level position otherwise the measurement or logging result is
skipped.

The Source of the triggering signal can be defined as one of or all channels of tri-axial accelerometer: X, Y,
Z.

The level of the triggering signal (Level) can be set in the range from 80 dB to 180 dB.

The user may also select the number of the results saved in the logger before the fulfilment of the triggering
condition (Pre) and the number of the results saved in the logger after the fulfilment of the triggering
condition (Post). If the triggering condition is fulfilled, the logger contains:

o the measurement results registered directly before the fulfilment of the triggering condition. Time of this

recording can be calculated by multiplying the value set in the Pre position by the time period taken
from the Logger Step position;

o all measurement results up to the moment the triggering condition disappears;

o the results registered directly after the moment the triggering condition disappears. Time of this

recording can be calculated by multiplying the value set in the Post position by the time period taken
from the Logger Step position.

In the Pre/Post line the number of the results recorded in the logger’s file before or/and after the fulfilment of
the triggering condition can be set. This number is within the limit 0..6 for Pre trigger and 1..200 for Post
trigger.

5.4.4 Time-history data logging settings tab

To enable logging time-history data go to the “Time History” settings tab and switch the very first switch
button on the left panel.

• In the left panel named “Time History Setup” there are basic configuration fields related to: how

frequently do you want to log the parameters, what name the logger file should have, and if
extended summary results should be saved.

Notice: Summary results are saved on “Integration Period” basis (not on “Logger Step” time).

See Figure 5-7 how to set “Integration Period” parameter.

• Right panel named “Display Results” is accessible only if “Logger” switch button is set to “On”.

You have the ability to choose, which basic results for each channel should be logged during
measurement run and saved in internal storage memory.

SV 103 USER'S MANUAL________________________________________________________

_

39

Figure 5-9 Time History (logger) settings tab

5.4.5 Display VIEW configuration tab

As mentioned in chapter 4.1 there are quite a few VIEW modes accessible on the display, when
the instrument is performing a measurement run.

• In the left panel named “Modes & Views” you can select which VIEW mode will be present when

you press the <ENTER> key on the instrument keypad

Notice: The “ONE-RESULT” is the only VIEW mode that is always present, and cannot be

disabled.

In this panel you can also switch on the automatic screen off function (Auto off), which saves the
energy of internal power source, the display rotate function, which positions the screen text always
horizontally. You can choose the units of the displayed results in the position Units as
Logarithmic, Linear Metric or Linear Non-Metric.

• In the right panel named “Display Results”, you will find a list of twenty
measurement parameters, that can be configured to be presented on the SV 103 display, when

logger

enable

SV 103 USER'S MANUAL________________________________________________________

_

40

you press <SCROLL> and key. See Appendix D to review acronyms for each
parameter.

Figure 5-10 Display VIEW configuration tab

5.4.6 General settings tab

General settings tab concerns to many different usability options: See the followed by chapters
to understand exactly how to configure these instrument settings.

SV 103 USER'S MANUAL________________________________________________________

_

41

Figure 5-11 General settings tab

5.4.6.1 Security settings panel

The security setting enables you to protect access to the instrument when in use with a simple keypad
password to prevent users from inadvertently terminating a measurement run. This feature is set through
the Supervisor’s “General” settings tab.

To turn on the security option: switch on “Lock During Measurement” button. Once turned on, the SV 103
will disable the keyboard every time, the measurement run is started.

See the chapter 4.7 how to lock, and unlock the SV 103 instrument.

If “Unlock on Key” is set to On, SV 103 will require special code to be input by pressing four keys defined in
this panel in a particular sequence.

If “Unlock on Key” is set to Off, SV 103 can be locked/unlocked without providing Lock/Unlock sequence.

Simply hold the <SCROLL> key for a couple of seconds during which a countdown (“Keyboard lock”
3 2 1 ) is displayed and the unit gives you time to decide if you really want to activate/deactivate the
security lock. If you release the key too early, the operation will be cancelled.

SV 103 USER'S MANUAL________________________________________________________

_

42

Figure 5-12 Keyboard security settings panel

5.4.6.2 Auxiliary settings panel

Under auxiliary settings panel it is possible to:

• Set the calibration level and enable to perform additional calibration after a measurement session
and add the results to the file saved in the memory. In the panel below, there are three options for
saving results: not to save “Off”, save in the last file “Last File” or save in the files which will be
created after last calibration (“Files after last calibration”).

• Enable additional warning screens to be displayed under certain conditions:

o “Logging disabled” it warns the operator that time history results will not be stored.

“Power off” additional confirmation just before switching off (see

o Turning on/off0)

• Set the Reference Level for the results presentation in logarithmic units

• Set Time To Automatic Shutdown the instrument

• To change menu Language, displayed on the screen of the instrument. The default language is

English.

Figure 5-13 Auxiliary settings panel

SV 103 USER'S MANUAL________________________________________________________

_

43

5.4.7 Auto-Run settings (timer, pauses) tab

The Auto-Run panel enables the user to program the internal real time clock to act as a delayed start and
stop timer. The instrument can be switched on by itself at the pre-selected programmed time and it can then
perform the measurement run, which was used before it was last switched off. Auto-run feature is useful
if you wish to pre-set the instruments to run and stop for a specific time period, such as a week-long study.

Figure 5-14 Auto-run configuration tab

The timer configured in right panel named Timer can be:

• switched off – Off

• switched on – On

In the case the timer function is active (On) and the instrument is switched on the Time screen appears until
the programmed measurement runs are finished.

Setting hour and day of the measurement’s start

The Start (hh:mm) and Stop (hh:mm) positions determines the time for the measurement to start and to
stop automatically. The required hour and minute shpuld be selected.

SV 103 USER'S MANUAL________________________________________________________

_

44

The Day of week determines the days in a week when the measurements should start. The timer can be
programmed (Max. no.

of measurements days) up

to 100 days ahead or without limitation (Infinity) and

during these days settings of the current state of the Real Time Clock is taken into account. Make sure to
check that the real time clock settings for the measurement location are correct before beginning a delayed
timer measurement.

There is also possibility to program five independent PAUSES in the form of real time programming. See

Figure 5-14 for detailed settings in magnified area.

5.4.8 Signal recording options tab

Signal recording is an optional function, which should be unblocked. Signal recording can be performed as
Time Domain recording to the same file as main and history results or as a separate Wave file. Both modes

are mutually exclusive functions and the one option should be turned off in order enable the other one. The
difference is that the Time Domain signal is recorded to the logger file, while Wave signal is recorded as a
separate PCM file (or file in extensible format).

Both recordings may be configured in different “Recording Mode”. The signal may be recorded during
whole measurement time (Continuous or Whole Measurement) or may be triggered with Slope or Level
trigger.

5.4.8.1 Recording on trigger

It is possible to define three sources of triggering condition (Trigger Source) from all channels. Four last
parameters define: level of signal for triggering (Trigger Level), pre-trigger recording (Pre-Trigger), time of
recording after triggering (Recording Time) and step of checking the triggering condition (Step).

Figure 5-15 Recording on trigger configuration panel

5.4.8.2 Continuous recording

SV 103 USER'S MANUAL________________________________________________________

_

45

If Whole Measurement is chosen the panel consists only positions, where the user may select three signals
for record (Record) from tri-axial transducer.

Figure 5-16 Continuous recording configuration panel

5.5 Working with data files

5.5.1 Downloading instrument files

If you want to download any recorded files, whatever it is: logger, wave or time domain files, you should click
the Download button on the control area.

Figure 5-17 SV 103 Download window

Press the Download button, located in bottom area, and the previously selected run data files will be
downloaded to local computer and the SUPERVISOR will enter “Data Browser” (see chapter 5.5.2) to

Press here to download

selected files.

Click the Download button

SV 103 USER'S MANUAL________________________________________________________

_

46

further manage downloaded files. Run data files in the instrument can be optionally deleted after download
by checking the box under the Download button.

To change the working directory or scan other folders, press the
“Change dir” button, and appropriate window will appear, see figure
below.

Figure 5-18 Change instrument working directory window

5.5.2 Local files “Data Browser”

Within the Data Browser tab you can see the list of previously downloaded files ready for further processing.
Note that selected files will generate a short preview in the bottom area giving the operator an initial idea of
the time history of the measurement results.

All files are simply divided per specific function: In the case of a instrument: hand-arm dosimetry and Wave
are relevant file groups.

To further process the selected file or files, right click on selection, and choose “New session” command.
This will bring you to the “Session” window (see chapter 5.6), where the reporting tool will allow you quickly
and professionally review and asses the data.

Figure 5-19 Local files “Data Browser” - window layout

SV 103 USER'S MANUAL________________________________________________________

_

47

SV 103 USER'S MANUAL________________________________________________________

_

48

5.6 Working with sessions and reporting

One of the main advantages of the SUPERVISOR is its incredibly simple but professional and user
customizable report creation. Once you get familiar with the power of document design you will love it and
probably never come back to the old fashioned way of reporting.

When the measurement data is downloaded via the download feature, the data is stored and viewable via
the local file “Data Browser” window. Further work with data downloaded from instrument is based on, so
called, SESSIONS – the most advanced charting, tables, and reporting capability in its class.

Each SESSION is highly configurable and the template of a document once created (Figure 5-22) can be
saved for future use with other measurement data. That gives the operator quick solutions at the fingertip.
The information is divided into panels and viewable in customizable graphs and/or with selected
measurement data/parameters.

Figure 5-20 SUPERVISOR main SESSION window

generate report

report preview

report options

(see Figure 5-24)

template manager

(see Figure 5-22)

zoom

change sound units

change vibration units

font control

SESSION configuration panel

report detailed configuration area

SV 103 USER'S MANUAL________________________________________________________

_

49

SESSION configuration panel enables you to see the currently selected
measurement data in the “Session data” sub-panel.

“Add panel” contains a list of available information sections or chunks
so called panels that are available to place in the report. Just double
click to add a new panel section to the report detailed configuration
area. Note, that each panel can be added more than once. It is possible
to change the information in each panel: for example: one panel with
parameters sorted in a table layout, and the other with a graph, or a
zoomed graph.

“Panels” contains the list of currently added information chunks to the
report detailed configuration area. Here you can change the names of
the individual added panels.

“Reports” contains information about user generated documents
saved by the software.

SESSIONS can be archived, or deleted with single button click.

Figure 5-21 SESSION configuration panel

Figure 5-22 Managing templates with SUPERVISOR

d

ouble click

to

add panel to the

report

d

ouble click

to jump to

SV 103 USER'S MANUAL________________________________________________________

_

50

5.6.1 Force threshold slider

The contact force plot is shown in the Logger results panel. Supervisor provides set of tools for creating
automatic marker in relation to the force threshold:

Figure 5-23 Force threshold slider

Changing the value of the force threshold adjusts the marker Force level+ for which results such as
Current Exposure or Vector are calculated beneath the graph.

Selection of Duration enables to remove those markers which time is shorter than a set Duration value. The
default value is 8 seconds which means that events shorter than 8 s will not be included in Force level+
marker.

Smoothing function enables to smooth the contact force plot in order to eliminate sudden peaks in the force
time history and include short contact breaks into a Force level+ marker helping to analyze signals of the
impulsive characteristics.

5.6.2 Report panels

See the following panels, then configure, and generate report.

Report options: With “Report options” window it is very straightforward to edit basic report information
and predefined graphics, colour and style.

SV 103 USER'S MANUAL________________________________________________________

_

51

Figure 5-24 SUPERVISOR Report Options

Figure 5-25 Hand-Arm vibration exposure (ISO 5349-A) panel

Figure 5-26 Instrument configuration panel

SV 103 USER'S MANUAL________________________________________________________

_

52

Figure 5-27 Logger results panel

Figure 5-28 Logger results (table) panel

Figure 5-29 Session header panel

SV 103 USER'S MANUAL________________________________________________________

_

53

Figure 5-30 Configurable Text panel

Figure 5-31 Total results panel

SV 103 USER'S MANUAL________________________________________________________

_

54

6

SV103 MAINTENANCE

6.1 General recommendations for use

• Use only high quality USB cables, such as SC 156. Many poor quality cables do not ensure

low resistance of the cable, thus disabling proper charging of the internal cells

• It is not recommended to leave the instrument in direct sunlight conditions for prolonged
periods of time. Extended exposure such as behind the car window may affect
the performance.

• To improve accuracy of remaining battery life indicator, run the instrument until it is fully
discharged; then proceed with a full charge via the micro USB port. The procedure
is recommended before first use. Repeat this procedure every few months of use to maintain
more accurate current battery condition indication.

6.2 Cleaning

Few things to remember:

• Every time the SV 103 gets too dirty, clean the surface of the instrument with damp soft cloth.

6.3 Changing the accelerometer

To change the hand-arm triaxial accelerometer, you have to:

- turn the instrument off and disconnect it from the charger or USB,

- unfasten the connector from the mounting head,

- unscrew the connector in a counter-clockwise direction,

- attach a new accelerometer, screw the connector on clockwise until it fits tightly.

Notice: The TEDS data (accelerometer serial number and calibration factor) for

the accelerometer will automatically be downloaded to the SV 103 internal memory.

6.4 Firmware upgrade

SVANTEK is committed to continuous innovation path of development, and as such reserves the right to

provide firmware enhancements based on user’s feedback.

To update the instrument firmware:

• Unpack the provided firmware package. (provided as a suitable compressed file)

• Make sure the unit is turned off.

SV 103 USER'S MANUAL________________________________________________________

_

55

• Hold down the <SCROLL> key and press the <ENTER> key to turn on the unit.
This ensures the unit will switch on and enter the special reprogramming BOOTLOADER
mode.

• Then connect the USB cable. The <USB> text will now appear on the instrument display.

• Run the start.bat file.

• Successful firmware update will be indicated by relevant message.

• Turn off the unit.

Notice: With use of SUPERVISOR software it is very easy to check if there are any new

firmware releases available for download (see Figure 5-3 commands).

6.5 Storing the instrument

• To preserve the life of the internal batteries, it is recommended that the SV 103 instrument

is turned off when it is stored.

• Do not store the instrument permanently connected to the USB port. It shortens battery lifecycle

• When the SV 103 is turned off, it still draws a small amount of battery power. Therefore

it is recommended to charge the cell every few months if it is not going to be used regularly.

6.6 Transportation and carrying

For transportation or storage purpose, always use the packaging provided by the manufacturer. In a
potentially dirty industrial environment it is advisable to use the carrying case provided by the manufacturer
such as the SA 73 (see chapter 2.3), which ensures excellent mechanical and environmental protection and
long term storage conditions.

SV 103 USER'S MANUAL________________________________________________________

_

56

7

SVANTEK SERVICE

7.1 Troubleshooting

1. Upon connection to the USB port, if automatic charging is not started: check the USB cable and
power supply ratings of the source.

2. If the incorrect time or date is displayed when turning on the instrument connect the device to the
computer and use Supervisor software to set the time and date (see) ensuring PC clock is set
correctly.

3. In case the instrument is not able to turn on ensure the unit is charged by connecting to USB
or recommended charger. This ensures the battery is not exhausted. Then proceed with hardware
reset (chapter 7.2).

4. In case your instrument does not respond proceed with turn-off/turn-on procedure (chapter 3.80),
and hardware reset of the instrument (chapter 7.27.2).

5. In case the measurement of the vibration level is frozen or set to a fixed value proceed with turn­off/turn-on procedure (chapter 3.8), then with hardware reset of the instrument (chapter 7.2).

6. In case the reset does not help call Local Authorized Distributor or Svantek Service Office.

7.2 Resetting the instrument

• SYSTEM RESET: (internal software reset clears any setup configuration, and brings back the

default factory settings).

See Appendix A for remote control commands description.

• HARDWARE RESET: (internal hardware reset, no user data is changed)

Make sure the battery is not exhausted, and the unit is turned off. Hold down the <ENTER> key for
more than 15 seconds, and then release it. Turn on the instrument as usually.

Notice: Hardware reset is only to be used in extreme situations such as an instrument hang-up.

Be aware, that a hardware reset:

- will stop any pre-programmed auto-run modes

- will stop measurement run

- HARDWARE RESET works, even if the keyboard becomes locked out!

Should your SVANTEK professional measurement equipment need to be returned for repair or for
calibration, please contact the service office at the following number or contact via the SVANTEK’s website.

Service Office: [phone] or [phone].
Office hours are 8:00 a.m. to 4:00 p.m. Central European Time.

- E-mail at [e-mail]

- Internet at www.svantek.com

- Address:

SVANTEK Sp. z o.o.

Strzygłowska 81
04-872 Warszawa,
Poland

SV 103 USER'S MANUAL________________________________________________________

_

57

Notice:

International customers:

Contact your local authorized distributor from whom the product was purchased. You can obtain the name
and contact information of your local authorized distributor from SVANTEK by using the e-mail or telephone
information listed above or use our website to find nearest distributor office.
