Suzuki XF650 Freewind Service Manual
Specifications and Main Features
3a. Model – SUZUKI XF650 Freewind
3b. Engine: Inboard four-stroke engine air-cooled with SACS and OHC systems.
3c. Bore: 100 mm (3.937 in)
3d. Piston displacement: 644 cm³ (39.3 cu in)
3e. Compression ratio: 9.5:1
3f. Carburetor type: Equipped with a twin BSR32 carburetor.
3g. Starter type: Electric starting system.
3h. Lubrication type: This motorcycle has a wet sump lubrication system.
3i. Transmission type: Five, constant mesh transmission.
3j. Patterns of gear shift: 1 down and 4 less.
3k. Primary reduction ratio: 2.178 (61/28)
3l. Gear ratios: Low 2.416 (29/12), 2nd 1.625 (26/16), 3rd 1.238 (26/21), 4th 1.000 (21/21), 5th 0.826 (19/23)
3m. Final Reduction Ratio: 2.866 (43/15)
3n. Drive Chains: DUR525 V9 with 110 links.
3o. Dimensions:
- Length overall: 2205mm (86.8)
- Width overall: 2190 mm (86.2)
- Height overall: 865 mm (34.1)
- Wheelbase: 1465 mm (57.7)
- Dry mass: 162 kg (357 lbs) What would u like me to do for ur specifications
front brackets only.
Front suspension: Oil damped telescopic coil spring.
Rear suspension type: Coil spring gas/oil damped link type fully adjustable spring preload shocks.
Front brake: Disk brake.
Rear brake: Disk brake.
Front tire size: 100/90-19 57H with inner tubes
Rear tire size:130/80 R17 65H with inner tubes.
Ignition type: Electronic ignition or CDI
Battery: 12V 28.8 kC(8Ah)/10 HR
- Capacities:
- Fuel Tank: Base 18.5 l, 4.9 US gal, 4.1 imp gal Engine Oil (Oil change): 2.3 L, 2.4 US qt, 2.0 imp qt Engine Oil (with filter change): 2.4 L, 2.5 US qt, 2.1 imp qt Engine Overhaul Oil: 2.6 L, 2.7 US qt, 2.3 Imp qt Front Fork Oil (Each Leg): 655 ml, 22.1 US oz, 23.1 Imp oz
Frequently Asked Questions
- What type of fuel would I use for an SUZUKI XF650?
- Use gasoline grade 85-95 octane (research method) or higher, preferably unleaded type. - What engine oil w it y HI recommend for use in the SUZUKI XF650? - Recommended motor oil for this engine should have API classification of SF or SG and a viscosity rating of 10W/40 single grade. - What are the tire pressure specifications for the SUZUKI XF650? - Vacuum for the front tire during solo riding should be 175 kpa(1.75 kg/ cm2, 25 psi). For the rear tire it can go up to 200 kpa (2.00 kg / cm2, 29 psi). During dual riding the rear tire vacuum should be raised to 225kpa (2.25 kg/cm2, 33 psi).
- For regular maintenance on the SUZUKI XF650, how often do I need to carry it out?
- The maintenance plan is 1,000 km (600 miles) intervals, after that per 6,000 km (4,000 miles) and then after reaching 12,000 km (7,500 miles) of distance. Such maintenance can include both inspections and replacements of some equipment.
- Can you share the specifications for the compression pressure of an engine?
- The optimal compression pressure they expect is in 850Kpa or roughly 120 psi.
- On my SUZUKI XF650 When is the best time to replace the brake fluid?
- Every 2 Year a change is required so the brake fluid does not stay longer and moisture does not accumulate, while the brake hoses need to be swapped every 4 years.
- Is there a specific recommended brake fluid?
- Only использовать спецификация гликолевого тормозного топлива DOT 4, Лить в тормоза нельзя смешивать с другими жидкостями.
- Lastly, what would the overall weight of a SUZUKI XF650 in my possession be?
- Суха или, другими словами, без сплошной массы этого тяжелого мотоцикла составляет 162 килограмма или 357 фунтов.
