User guide
| KEiPad |
|
KEiPad
|
| KEiPad | User Guide
1. System Requeriment
2. Main Features
3. Installation Guide
Installation with iPad
Connect with computer
5. FAQ
2
List of Contents
ENGLISH
| KEiPad | User Guide
3
Thanks for purchasing this Bluetooth Keyboard, its with standard 78 keys as well as
13 function keys. This creative and easy-to-use Bluetooth Keyboard will bring you a
whole new wireless life experience.
System Requirement
• iPad, Mac OS.
• Windows OS (Windows XP, Windows Vista, Win7).
Main Features
• Bluetooth Version: Bluetooth V2.0, in BROADCOM 2042 chipset •78keys design, with 13
multi-function keys
• Scissor-switch keypad design, comfortable and ergonomic design •Built-in intelligent power
manage software for power conservation
• Built-in software solutions with Bluetooth human interface device and comply with the
standard version of the Bluetooth SIG Bluetooth 2.0
• Power by 2pcs AAA battery
• Working range: 10m
More information at: www.suvil.com
| KEiPad | User Guide
4
INSTALL ATION GUIDE
1. Connect with iPad
1.1. Open the battery cabinet, insert two
AAA alkaline batteries.
1.2. Turn the keyboard ON, and press the
pairing button. The blue light is flashing,
now the keyboard is in pairing mode.
1.3. On your iPad, go to “setti.ugs”. Then
from the “settings” screen select “General”.
1.4. l`m “Bluetooth” on, it will start
searching bluetooth devices.
1.5. Once your device finds the KEiPad BT
keyboard select “Bluetooth Keyboard” from
the list.
1.6. Your device will now give you a 6 digit
passkey. Enter this key onto the keyboard,
and press Enter to complete the pairing
(also on the keyboard).
Now the keyboard is connected with your
iPad successfully.
MULTIMEDIA FUNCTION
WITH IPAD
Virtual keyboard
Spotlight search
Picture frame mode
Turn off backlight
Screen lock
Music stop
Previous track
Play / Pause
Next track
Volume down
Mute
Volume up
Home
FN + F12
FN + F10
FN + F8
FN + F6
FN + F4
FN + F2
FN + F11
FN + F9
FN + F7
FN + F5
FN + F3
FN + F1
| KEiPad | User Guide
5
CONNECT WITH THE COMPUTER
Before you connect the Bluetooth Keyboard,
please make sure there is blnetooth function
in your computer. Software available like
Widcomm recommended), IVT or the
Microsoft built-in software...
1. Open the battery cabinet, inset two AAA
alkaline batteries.
2. Turn the keyboard ON, and press the
pairing button. The blue light is flashing,
now the keyboard is in pairing mode.
A: Install with Widcomm (recommended)
1. Double click the Icon, the main Window
pops up, select Bluetooth -Add Bluetooth
facility. Click Next button In the Setup Guide
window.
2. When the system finds the keyboard,
select it and click Next.
3. Input the stochastic Match Code in
Bluetooth keyboard, and press Enter.
4. Now you can use your keyboard at ease.
TIPS: If no signal received after 10
minutes, the keyboard will change to the
power safe mode. If you want to make it
into use, just click the “Enter” key. After the
connection between the keyboard and the
dongle, if you drag off the Dongle or turn off
the computer, the keyboard will shut down,
clicking the “Enter” key of the keyboard will
wake it up.
| KEiPad | User Guide
6
B: Install with Microsoft built-in software
1. Make sure that the Bluetooth Function has
been activated. Double click in the Bluetooth
Icon on the Task Bar or in the Control Panel,
open the “Bluetooth Management” window,
click “Add, tick off” facility is ready for
searching, click Next.
2. Wait till the keyboard is found, select
keyboard and click Next.
3. Select Choose a pass key for me, click
Next.
4. Input the pass key and press Enter in
Bluetooth keyboard, click Next, the system
will finish the installation of the new facility
automatically.
| KEiPad | User Guide
7
C: Install with IVT Software
1. Make sure that the Bluetooth Function
has been activated. Double click the
Bluetooth Icon, open Management window,
select Search for Bluetooth facilities or click
the Round Ball in the middle of the window.
2. Click the Bluetooth Keyboard found, click
the right button for Refresh Service.
3. Select the Bluetooth Keyboard again, click
the right button for Connect-Bluetooth Input
Service, input the stochastic pass key, the
system will auto install the HID facility. After
that you can use your Bluetooth Keyboard at
ease.
| KEiPad | User Guide
8
FAQ
If unable to connect the Bluetooth Keyboard
to the computer, or the Keyboard work
unconventionally, please try the steps
below:
1. Before you use your Bluetooth Keyboard,
please make sure you have done the
Bluetooth Dongle installation procedure, and
the Bluetooth facility is turned on.
2. Make sure that the Computer is
connected to the Bluetooth Keyboard. If
they are matched to each other before,
then under the Standby State, just click the
“enter” key of the keyboard.
3. Make sure that the keyboard is within the
effective range---10M.
4. Make sure that there’s no change in the
Bluetooth facility. If anything have been
changed, please reinstall the Bluetooth
Keyboard.
5. If your Bluetooth facility is connected
to other Bluetooth products, please kindly
confirm that the speed of the Bluetooth
facility is enough.
6.Please kindly check the batteries. If they
are short of power, replace them for new
ones.
