Page 1
Model E1L & E2L
Outdoorsman LED Flashlight
3-Watt LED Flashlight
Operator’s Manual
Revision N/C 1-1-2005
Page 2
E1L & E2L Outdoorsman
Introduction
The E1L and E2L Outdoorsman LED flashlights are fitted with a three-watt LED module.
Powered by 3-volt lithium batteries (E1L -1 battery, E2L - 2 battery), each feature digital current
regulation circuitry that matches the LED’s current requirements to the batteries’ output to
achieve a consistent level of light output for the
useable life of the batteries. The E1L and E2L
feature a click-on/click-off tailcap pushbutton
switch.
Light Activation
Partially depress the tailcap pushbutton switch
for momentary activation. Note: If light fails to
function, the tailcap may be in the lock-out position; the tailcap must be tightened for the light to
activate. For constant light, fully depress the
tailcap pushbutton switch to the “click-on” position.
CAUTION: The E1L and E2L are high-output
lighting devices and should not be left on unattended. External surface temperature will rise
during prolonged operation; this is a normal
operating phenomenon.
Lock-out Tailcap
The lock-out position disables the pushbutton
switch and prevents accidental light activation
during storage or transportation. From the
momentary-on position, rotate the tailcap
approximately 1.5 turns counter-clockwise to
lock the light in the off position.
Page 3
Operation
Battery Replacement
Unscrew the LED assembly and insert new batteries with positive ends towards LED head
assembly. Replace LED assembly and hand
tighten. Press tailcap pushbutton switch to test.
Note: If batteries are inserted with positive ends
towards the tailcap, the unit will not light.
Damage will not occur. Reinsert batteries with
positive ends towards the LED assembly.
WARNING: Lithium batteries can explode or
cause burns if disassembled, shorted, recharged.
exposed to water, fire, or high temperatures. Do
not place loose batteries in a pocket, purse or
other container containing metal objects, mix
with used or other battery types, or store with
hazardous or combustible materials. Store in
cool, dry, ventilated area. Follow applicable
laws and regulations for disposal.
Maintenance
Clean and lubricate threads with a clean cloth
and apply thin coat of silicon-based lubricant to
rubber O-rings.
Note: Do not use petroleum-based lubrication
on SureFire O-rings. After prolonged exposure
to moisture, the bezel and batteries should be
removed, inspected, and dried if necessary.
This unit has approval
Page 4
SureFire
®
LED HEAD ASSEMBLY
FLASHLIGHT BODY
SF123A
BATTERIES
PUSHBUTTON SWITCH
CLICK ON/OFF TAILCAP
E2L OUTDOORSMAN SHOWN IN ILLUSTRATION
Page 5
E1L & E2L LED Flashlight
Runtime
E1L
This extremely compact flashlight features a
virtually indestructible, long-running LED with
as much light output as a large 2 D-cell flashlight. Electronic power regulation provides a
total useful runtime of four hours from a single
lithium battery.
Construction: aerospace-grade aluminum,
Military Specification Type III hard-anodized;
tempered Pyrex®window; O-ring seals; steel
pocket clip; tailcap switch — push/momentary
on, twist/constant on, patented lock-out feature.
E2L
Similar to the E2e Executive Elite but featuring
a virtually indestructible, long-running LED
with electronic power regulation to squeeze 6
hours of useful runtime from each set of batteries while producing more light than a much
larger 2 D-cell flashlight.
Construction: aerospace-grade aluminum,
Military Specification Type III hard-anodized;
tempered Pyrex
®
window; O-ring seals; steel
pocket clip; push/momentary on, twist/constant
on, patented lock-out feature.
SureFire E1L E2L
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
Page 6
E1L & E2L Outdoorsman
Warranty Claims
For repair or replacement contact Customer
Service at 800-828-8809 (toll free) or 714-
545-9444 and obtain a Return Merchandise
Authorization number (RMA#). Then package the unit carefully and return (no COD’s
please) to:
SureFire
Repairs Department, RMA#___
17680 Newhope Street, Suite B
Fountain Valley, CA 92708-6122
SureFire will pay any reasonable shipping
costs to return the unit to you.
Warranty
SureFire®warrants its products to be free
from defects in materials and workmanship.
SureFire will repair or replace, at its option
without charge, any product or part found to
be defective under normal use and service.
Such repair or replacement shall be the purchaser’s sole and exclusive remedy under
this warranty. This warranty does not
include normal maintenance and services
and does not apply to any products or parts
that have been subjected to modification,
misuse, negligence, accident, improper
maintenance or repair by anyone other than
SureFire.
Warranty Limitation
There is no other express warranty.
SureFire®hereby disclaims any and all
implied warranties, including but not limited
to fitness for a particular purpose. SureFire
shall not be liable for incidental, consequential, or special damages arising out of, or in
connection with, product use or performance.
UM_E1L E2L
71-01-661
18300 Mt. Baldy Circle, Fountain Valley, CA 92708-6122
www.surefire.com 800-828-8809
