Page 1
OPERATOR’S
MANUAL
SureFire®Flashlights
Page 2
Lithium
Batteries
Pre-Focused
Metallic Vapor
Coated
Reflector
Xenon/Halogen
Lamp Assembly
With Tungsten
Filament
Tempered Pyrex
®
Lens with
Anti-Reflective Coating
Lock-Out
Tailcap
Momentary
Tailcap Switch
BASIC SUREFIRE
FEATURES
Features on various SureFire flashlight models
may differ but their operation is similar. The C2
Centurion® is shown because it encompasses
many features available in our highperformance flashlights.
SureFire C2 Centurion®
Exploded View
Stainless Steel
Pocket Clip
CombatLighttmBody
and Rubber Grip Ring
2
3
Page 3
4
Battery Installation
Unscrew the tailcap to install or replace the batteries.
Lock-out Tailcap
Models with a lock-out tailcap are shipped with
machined marks aligned in the lock-out position
to prevent accidental activation. To unlock and
place in momentary-on position, rotate the tailcap
clockwise approximately one turn.
Momentary-On
Depress the tailcap pushbutton to activate the light in
momentary mode.
Constant-On
From the momentary-on position, rotate the
tailcap clockwise approximately one-half turn to
achieve constant-on activation.
Lithium batteries can explode or cause burns if
disassembled, shorted, recharged, exposed to water,
fire, or high temperatures. Do not place loose
batteries in a pocket, purse, or other container
containing metal objects, mix with used or other
battery types, or store with hazardous or combustible
materials. Store in cool, dry, ventilated area. Follow
applicable laws and regulations for disposal.
Quick Start
Guide
55
Battery Installation
Lock-out tailcap
Momentary-On
Constant-On
CAUTION
CAUTION
Marks
Page 4
76
Battery Installation
Unscrew the tailcap and insert new batteries. Replace
tailcap and depress tailcap pushbutton switch to test.
If light fails to function the tailcap may be in the lockout position (excluding the G2 Nitrolon®, which does
not feature a lock-out tailcap). Rotate the tailcap
clockwise until momentary activation is possible.
Light Activation
For momentary light, press the tailcap pushbutton
switch. The light will stay on as long as the
pushbutton is pressed. Rotate the tailcap clockwise
for constant-on light.
Lock-out Tailcap (pat. # 6222138)
From the momentary-on position, rotate the tailcap
approximately 180º counter-clockwise. The lockout position prevents accidental activation during
storage or transport.
Maintenance
At least twice yearly, clean threads and O-rings with
clean cloth and apply a thin coat of silicone-based
grease or lubricant to both. If flashlight is used in
wet environment, lubricate O-rings frequently to
maintain watertight seal. After prolonged exposure
to moisture, the bezel, lamp, and batteries should be
removed, inspected, and dried if necessary.
Lamp Replacement
Rotate bezel (head) counter-clockwise to remove.
Remove lamp/reflector assembly and replace with
recommended assembly.
DETAILED OPERATING
INSTRUCTIONS
Lamp Replacement Guide
FOR TWO-BATTERY FLASHLIGHTS
HIGH-OUTPUT
ULTRA HIGH-OUTPUT
Runtime/lumen output
Runtime/lumen output
20 minutes/120 lumens
P60 Lamp Assembly
One hour/65 lumens
P61 Lamp Assembly
FOR THREE-BATTERY FLASHLIGHTS
HIGH-OUTPUT
ULTRA HIGH-OUTPUT
Runtime/lumen output
Runtime/lumen output
20 minutes/200 lumens
P90 Lamp Assembly
One hour/105 lumens
P91 Lamp Assembly
CAUTION
CAUTION
SureFire flashlights produce substantial heat during
operation. Do not leave activated flashlight unattended.
Do not set activated flashlight face (lens) down. Do not
place activated flashlight against combustible material or
material that could be damaged by heat. Do not hold
bezel or lens of activated flashlight against any portion of
human body. Keep away from children.
Ensure that the flashlight cannot be turned on when
stored or being transported. If the lamp is activated while
in a case or other container, the lamp could overheat and
cause damage to surrounding materials. For models not
equipped with a lock-out feature, remove the batteries or
unscrew the bezel enough to prevent accidental activation.
Do not touch a hot lamp assembly. Allow it to cool before
handling. Avoid touching reflector surface. SureFire lamp
assemblies are pressurized. Always wear safety glasses
when handling.
Page 5
9
Tungsten Filaments
With Xenon/Halogen Gas
To achieve maximum light output, SureFire
lamps feature a tungsten filament in a highpressure xenon/halogen gas atmosphere.
Metal Vapor
Coated Reflectors
To achieve a perfect beam free of dark rings
and shadows, reflectors are coated with a
proprietary finish that causes light to bounce off
the reflector at varied angles and cancel out any
beam irregularities.
Pre-Focused Reflectors
No need to twist the bezel to adjust the beam – it’s
already perfectly pre-focused. Lamps and reflectors
are individually mated and hand-adjusted to
within .005" for optimum beam quality at all
distances.
Lithium Batteries
In addition to packing a lot of power into a small
space, SureFire disposable lithium batteries have a
ten-year shelf life. Put a lithium-powered light in
a drawer and years later it will still work.
Rugged Construction
SureFire lights are CNC machined from
aerospace-grade aluminum or molded from
Nitrolon, a proprietary polymer that is nonconductive and extremely resistant to corrosion and
impact. Available finishes include a Military
Specification Type III hard-anodizing.
8
SureFire strives to design and manufacture lights
of ever-increasing brightness and quality while
setting new standards for maximum power with
minimal size. Three things characterize every
product: compact size, extreme ruggedness, and a
flawless high-output beam. Every SureFire
illumination tool is guaranteed to produce a
perfect center spot of intense light surrounded by
a smooth corona of softer light.
THE SUREFIRE
DIFFERENCE
Page 6
11
WARRANTY CLAIMS
For repair or replacement contact Customer Service
at 1-800-828-8809 (toll free) or 1-714-545-9444
and obtain a Return Merchandise Authorization
number (RMA#). Then package the unit
carefully and return to:
SureFire, LLC
Repairs Department, RMA#____
17680 Newhope Street, Suite B
Fountain Valley, CA 92708
No COD’s please.
SureFire will pay any reasonable shipping
costs to return the unit to you.
10
WARRANTY
SureFire warrants its products to be free from defects in
materials and workmanship. SureFire will repair or
replace, at its option and without charge, any product
or part which is found to be defective under normal use
and service. Such repair or replacement shall be the
purchaser’s sole and exclusive remedy under this
warranty. This warranty does not include normal
maintenance and services and does not apply to any
products or parts which have been subject to
modification, misuse, negligence, accident, improper
maintenance or repair by anyone other than SureFire.
Warranty Limitation
There is no other express warranty. SureFire hereby
disclaims any and all implied warranties, including but
not limited to fitness for a particular purpose. SureFire
shall not be liable for incidental, consequential, or special
damages arising out of, or in connection with, product
use or performance.
Lamps will burn out, batteries
will be used up, and switches
for WeaponLights
™
will
eventually need to be replaced.
Everything else is covered by our
lifetime no-hassle guarantee —
If it breaks, we fix it!
NO–HASSLE
LIFETIME GUARANTEE
Page 7
13
Holsters
Choose from nylon and leather holsters.
Lanyard Kit
Attaches between body and tailcap or bezel for
secure retention.
Colored filters (FM Series)
Red, Blue and Infrared.
12
SureFire Lithium Batteries
Optimized for use in SureFire flashlights.
Spares Carrier
Holds lithium batteries and a replacement lamp in
a watertight case. Lanyard included.
Speed Holster
Carries light bezel-up or bezel-down.
FLASHLIGHT
ACCESSORIES
Page 8
15
Turbo Conversion Kit
Concentrates beam for long-range use.
LED Conversion Heads
Convert to a long-running LED light.
Click-On Tailcap
Click the light to constant-on without
having to rotate the tailcap.
14
Diffusion Filter
For a wider, softer beam.
Orange Directing Wand
Rechargeable Conversion Kit
Convert your flashlight to a rechargeable.
Page 9
18300 mount baldy circle
fountain valley, CA 92708
800.828.8809
surefire.com
71-01-630
Rev. B
®
