SureCall Fusion2Go Max User Manual

Fusion2Go™ Max

Vehicle Voice and 4G Data Signal Booster

User Manual

06.18.2019

Thank you for purchasing SureCall’s Fusion2Go Max cell phone signal booster kit.

Fusion2Go Max provides enhanced voice, text and 4G data signal for any vehicle.

If you have any questions during setup, please reach out to our US-based experienced

support technicians:

• Call: 1-888-365-6283

• Email: [e-mail]

Table of Contents

How It Works ........................................................................................................................... 3

Package Contents ................................................................................................................... 4

Step 1: Attach Outside Antenna to the Vehicle’s Roof ............................................................ 4

Step 2. Install the Inside Patch Antenna ................................................................................. 5

Step 3. Place Booster and Connect Cables........................................................................... 6

Step 4. Connect Power ........................................................................................................... 7

LED Indicators ........................................................................................................................ 8

Troubleshooting ....................................................................................................................... 8

Specications .......................................................................................................................... 9

Antenna Kitting Information ................................................................................................... 11

Consumer Guidelines ............................................................................................................ 12

Three-Year Product Warranty ................................................................................................ 13

www.SureCall.com | 1-888-365-6283 | [e-mail]2

SureCall Fusion2Go Max User Guide

How It Works

The SureCall Fusion2Go Max is a high-quality bidirectional booster that enhances cellular

signals for vehicles.

The Fusion2Go Max works with two antennas:

• An inside antenna that communicates with your cell phone.

• An outside antenna that communicates with the cell tower.

Signals sent from a cell tower are received by the outside antenna, amplied by the booster

and then sent to your cell phone via the inside antenna. When your phone transmits, the sig-

nal is sent to the inside antenna, and then sent to the cell tower via the outside antenna.

Magnetic
Antenna

Patch
Antenna

Booster

www.SureCall.com | 1-888-365-6283 | [e-mail] 3

Power AdapterPower Adapter

Package Contents

SureCall offers many accessories to customize your signal booster kit to your specic needs.

To learn more about these accessories or to replace damaged or missing items contact your

reseller.

For exchanges or returns, your reseller may request original packaging and basic product

information. Turn over the signal booster and record the model and serial number for easy

reference:

Serial #: __________________________________________________________________________

Purchase Date: ____________________________________________________________________

Your Fusion2Go Max signal booster package includes the following items:

1. One outside magnetic mount antenna

2. One SureCall Fusion2Go Max signal booster

3. One inside patch antenna

4. DC power adapter

1. Outside Magnetic-

Mount Antenna with Optional
Adhesive Mount

www.SureCall.com | 1-888-365-6283 | [e-mail]4

2. Signal Booster

3. Multi-Device

Inside Patch
Antenna

3. 12V DC Power

Adapter

SureCall Fusion2Go Max User Guide

Step 1: Attach Outside Antenna to the Vehicle’s Roof

Attach the Outside Antenna to the roof of your vehicle and at least 12-inches away from

obstructions and other radiating elements, like other antennas.

Suggestion: For non-metal or non-magnetic
vehicle surfaces use the optional adhesive tape.

Next, run the cable from the outside antenna across

the car’s roof and into the car. To hide and protect

the antenna cable, carefully pull down the door

seal, run cable underneath it and push the seal

back into place. Run the cable to the inside of the

vehicle near the planned location of the booster

(under the seat of the vehicle, or in the front or

middle console).

Note: The outside antenna must not be collocated or operating with any other antenna or booster.

Step 2. Install the Inside Patch Antenna

Identify a location for the inside antenna on or near your front dashboard that is

1. Within 2-3 feet of the typical cell phone location

2. At least 8 inches (20cm) from cellular devices

and

3. At least 4 inches (10cm) from metal

Next, peel Velcro backing and apply to a clean dry

surface in your chosen location.
